Johnson Controls RC Series User manual

RC Series Engineering Guide
Design Features
Factory Options
Accessories
Dimensional Data
Physical Data
Performance Data
Engineering Guide Specifications
Form: 146.00-EG4A (0315)
Supercedes: 146.00-EG4 (0210)
RC Series
CONSOLE
Geothermal/Water Source Heat Pump
• R-410A Refrigerant
• 0.75-1.5 Ton Single Speed

RC SERIES ENGINEERING GUIDE
Model Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
AHRI Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
The RC Series Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Inside the RC Series Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-15
Application Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-20
Selection Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21-22
Dimensional Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22-29
Unit Operating Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Unit Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Auxiliary Heat Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Fan Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Reference Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Legends and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Correction Factor Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Capacity Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36-39
Wiring Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40-45
Engineering Guide Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46-47
Revision Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Table of Contents

4
RC SERIES ENGINEERING GUIDE
All RC Series product is Safety listed under UL1995 thru ETL and performance listed withAHRI in
accordance with standard 13256-1.
Model Nomenclature
RC S
1-2 4-5 6 7 8
Model Type
RC –RC Series
Cabinet Configuration
C–Chassis Only
W–Chassis with Cabinet
S–Chassis with Slope Top
E–Chassis with Extended
Slope Top
Unit Capacity
09, 12, 15, 18
Piping Option
L–Left
R–Right
Voltage
0–208-230/60/1
2–265-277/60/1
9–115/60/1 (09 & 12 Only)
Unit Control
1–CCM
2–Versatec Microprocessor
4–FX10 Std. without Communication
5–FX10 with Open N2 Comm Card
6–FX10 with Lonworks Comm Card
7–FX10 with BacNet Comm Card
Vintage
C–ECM Blower & Aluminum Air Coil
Non-Standard Options
SS –Standard
Air Coil Option
5–AlumiSealTM, Extended Range
8–No Coating, Standard Range
Sound Kit
A–None
B–Blanket
Auxiliary Electric Heat
N–None
B–1.0kW (09-12)
C–2.0kW (09-12)
D–3.0kW (15-18)
Motorized Outdoor Air Damper
(Field Installed)
N–None
M–Motorized Damper
Coax Option
C–Copper
N–CuproNickel
Thermostat Control
1–Unit Mounted Thermostat
2–Remote Wall-Mount Thermostat
Rev.: 04 March 2015D
91011 13
09 L 0 1 1 C N N B
12
5
14
SS
15-16 17
C
Note: Chassis only available with left piping option
FX10 option is only available with remote wall-mounted thermostat control.
3

5
RC SERIES ENGINEERING GUIDE
AHRI/ISO 13256-1 Performance Ratings
ECM Motors
AHRI/ASHRAE/ISO 13256-1
English (IP) Units
Model Flow Rate Water Loop Heat Pump Ground Water Heat Pump Ground Loop Heat Pump
Cooling
EWT 86°F Heating EWT 68°F Cooling EWT 59°F Heating EWT 50°F Cooling EWT 77°F Heating EWT 32°F
gpm cfm Capacity
Btuh EER Btuh/W Capacity Btuh COP Capacity Btuh EER Btuh/W Capacity Btuh COP Capacity Btuh EER Btuh/W Capacity Btuh COP
09 2.5 300 8,500 13.4 10,500 4.4 10,200 22.5 8,700 3.8 9,000 16.0 6,700 3.1
12 3.5 350 10,500 12.3 14,400 4.3 12,400 19.5 11,800 3.7 11,000 14.2 9,500 3.5
15 4.5 450 13,500 13.6 17,000 4.9 16,200 22.0 14,000 4.1 14,200 15.9 10,500 3.4
18 5.5 500 16,200 12.5 21,000 4.4 19,000 19.6 17,000 3.7 16,600 15.1 13,300 3.1
12/14/09
Cooling capacities based upon 80.6°F DB, 66.2°F WB entering air temperature
Heating capacities based upon 68°F DB, 59°F WB entering air temperature
All ratings based upon operation at the lower voltage of dual voltage rated models.

6
RC SERIES ENGINEERING GUIDE
The performance standard AHRI/ASHRAE/ISO 13256-1 became effective January 1, 2000 and replaces ARI Standards 320, 325, and
330. This new standard has three major categories: Water Loop (comparable to ARI 320), Ground Water (ARI 325), and Ground Loop (ARI
330). Although these standards are similar there are some differences:
Unit of Measure: The Cooling COP
The cooling efficiency is measured in EER (US version measured in Btuh per Watt. The Metric version is measured in a cooling COP
(Watt per Watt) similar to the traditional COP measurement.
Water Conditions Differences
Entering water temperatures have changed to reflect the centigrade temperature scale. For instance the water loop heating test is
performed with 68°F (20°C) water rounded down from the old 70°F (21.1°C).
Air Conditions Differences
Entering air temperatures have also changed (rounded down) to reflect the centigrade temperature scale. For instance the cooling
tests are performed with 80.6°F (27°C) dry bulb and 66.2°F (19°C) wet bulb entering air instead of the traditional 80°F (26.7°C) DB
and 67°F (19.4°C) WB entering air temperatures. 80.6/66.2 data may be converted to 80/67 using the entering air correction table.
This represents a significantly lower relative humidity than the old 80/67 of 50% and will result in lower latent capacities.
Pump Power Correction Calculation
Within each model, only one water flow rate is specified for all three groups and pumping Watts are calculated using the following
formula. This additional power is added onto the existing power consumption.
• Pump power correction = (gpm x 0.0631) x (Press Drop x 2990) / 300
Where ‘gpm’ is waterflow in gpm and ‘Press Drop’ is the pressure drop through the unit heat exchanger at rated water flow in feet of
head.
Fan Power Correction Calculation
Fan power is corrected to zero external static pressure using the following equation. The nominal airflow is rated at a
specific external static pressure. This effectively reduces the power consumption of the unit and increases cooling capacity but de-
creases heating capacity. These Watts are significant enough in most cases to increase EER and COPs fairly dramatically over ARI
320, 325, and 330 ratings.
• Fan Power Correction = (cfm x 0.472) x (esp x 249) / 300
Where ‘cfm’ is airflow in cfm and ‘esp’ is the external static pressure at rated airflow in inches of water gauge.
ISO Capacity and Efficiency Calculations
The following equations illustrate cooling calculations:
• ISO Cooling Capacity = Cooling Capacity (Btuh) + (Fan Power Correction (Watts) x 3.412)
• ISO EER Efficiency (W/W) = ISO Cooling Capacity (Btuh) x 3.412 / [Power Input (Watts) - Fan Power Correction (Watts) + Pump
Power Correction (Watt)]
The following equations illustrate heating calculations:
• ISO Heating Capacity = Heating Capacity (Btuh) - (Fan Power Correction (Watts) x 3.412)
• ISO COP Efficiency (W/W) = ISO Heating Capacity (Btuh) x 3.412 / [Power Input (Watts) - Fan Power Correction (Watts) + Pump
Power Correction (Watt)]
Comparison of Test Conditions
Conversions:
Airflow (lps) = CFM x 0.472; WaterFlow (lps) = GPM x 0.0631;
ESP (Pascals) = ESP (in wg) x 249; Press Drop (Pascals) = Press Drop (ft hd) x 2990
ARI 320
ISO/AHRI
13256-1
WLHP
ARI 325
ISO/AHRI
13256-1
GWHP
ARI 330 ISO/AHRI
13256-1 GLHP
Cooling
Entering Air - DB/WB °F 80/67 80.6/66.2 80/67 80.6/66.2 80/67 80.6/66.2
Entering Water - °F 85 86 50/70 59 77 77
Fluid Flow Rate * ** ** ** ** **
Heating
Entering Air - DB/WB °F 70 68 70 68 70 68
Entering Water - °F 70 68 50/70 50 32 32
Fluid Flow Rate * ** ** ** ** **
Note *: Flow rate is set by 10°F rise in standard cooling test Note **: Flow rate is specified by the manufacturer
Part load entering water conditions not shown.
WLHP = Water Loop Heat Pump; GWHP = Ground Water Heat Pump; GLHP = Ground Loop Heat Pump
Performance Standard (AHRI/ISO/ASHRAE 13256-1)

7
RC SERIES ENGINEERING GUIDE
High Efficiency
RC Series is the highest efficiency units available. Large
oversized air coils, water to refrigerant heat exchangers and rotary
compressors provide extremely efficient operation. This efficiency
means the RC Series requires less loop than any product on the
market. This can mean significant savings on commercial projects.
Quiet Operation
All RC Series Console product is ARI 350 sound rated using third
party sound testing. Room Noise Criteria Curves (NC Curve)
may be calculated using data from the ARI 350 ratings giving the
engineer total flexibility in assuring a quiet environment.
Standard Features
• Slope and Flat top configurations
• Extended cabinet options
• Footprint matches “legacy” products for easy retrofits.
• Attractive rounded corners heavy gauge cabinet.
• Quiet rotary compressors in all models.
• 2-dimension refrigerant piping vibration loops to isolate
the compressor.
• All interior cabinet surfaces including the compressor
compartment are insulated with 1/2˝[12.7mm] thick
• 1-1/2lb [681g] density, surface coated, acoustic type glass
fiber insulation.
Flexible Control Options
The standard CCM (compressor control module) is a more reliable
replacement for electro-mechanical control applications. It features
a small microprocessor board that handles the lockout function of
the unit. A second microprocessor handles the unit mounted dial
thermostat for maintaining accurate room temperature. Thermostat
options include unit mounted or remote thermostat.
The optional Versatec microprocessor control board provides
complete monitoring and control with optional field monitoring fault,
status and I/O LED indication for easy servicing. The Versatec
features a robust microprocessor control that monitors LP, HP,
Condensate, field selectable thermistor freeze sensing, while
providing a flexible accessory relay and fault output scheme.
Thermostat options include unit mounted or remote thermostat.
The optional FX10 control provides unparalleled capability
in several areas including performance monitoring, zoning,
humidity, energy management, and service diagnosis, and then
communicates it all thru standard DDC protocols like N2, Lon and
BACnet (MS/TP @ 19,200 Baud rate).
The most unique feature is integrating the FX10 into the RC Series
as both the heat pump and DDC controller providing both a cost
advantage and features not typically found on WLHP controls.
This integration allows heat pump monitoring sensors, status and
service diagnosis faults to be communicated thru the DDC direct to
the building automation system (BAS), giving building supervisors
detailed and accurate information on every piece of equipment
without removing an access panel. Thermostat options include unit
mounted sensor or remote sensor or remote thermostat.
Optional user interface for diagnostics & commissioning of
FX controls.
Easy Maintenance and Service Advantages
• 2 removable compressor access panels
• Separate air handler and compressor section access panels
permit service testing without bypass.
• Easy access to low voltage connector for easy thermostat wiring
(remote & thermostat option).
• Quick attach wiring harnesses are used throughout for
fast servicing.
• High and low pressure refrigerant service ports.
• Internal slide out blowers.
Factory Quality
• All refrigerant brazing is performed in a nitrogen environment.
• Computer controlled deep vacuum and refrigerant
charging system.
• All joints are leak detected for maximum leak rate of less than
1/4 oz. per year.
• Computer bar code equipped assembly line insures all
components are correct.
• All units are computer run-tested with water to verify both
function and performance.
VERSATEC FX10CCM
The RC Series Console
n
and
performance.

8
RC SERIES ENGINEERING GUIDE
Refrigerant
RC Series products all feature zero ozone depletion and low global
warming potential refrigerant R-410A.
Cabinet
All units are all constructed of corrosion resistant galvanized sheet
metal with white polyester powder coat paint rated for more than
1000 hours of salt spray. Refrigerant circuit is designed to allow
primary serviceability from the front. One access panel allows
servicing of the fan motor, blower, and drain pan. Cabinet is
designed to match "industry" foot print for ease of replacement.
Drain Pan
All condensate connections are welded stainless steel tubes for
economical corrosion free connections. Bacteria resistant stainless
steel drain pan is designed to promote complete drainage and will
never rust or corrode. Complete drainage helps to inhibit bacterial or
microbial growth. Units feature an internally trapped condensate line.
Compressors
High efficiency R410Arotary compressors are used on every
model. Rotary compressors (available in 208-230V & 265V 60Hz
Single Phase) provide both the highest efficiency available and
great reliability.
Electrical Box
Unit controls feature quick connect wiring harnesses for easy
servicing. Large 75VA transformer assures adequate controls
power for accessories.
Thermostatic Expansion Valve
All RC Series models utilize a balanced port
bi-directional thermostatic expansion valve
(TXV) for refrigerant metering. This allows
precise refrigerant flow in a wide range of
entering water variation (20 to 120°F [-7 to
49 °C]) found in geothermal systems.
Water to Refrigerant Coaxial Heat Exchanger Coil
Large oversized coaxial refrigerant to water
heat exchangers provide unparalleled
efficiency. The coaxes are designed for
low pressure drop and low flow rates.
All coaxes are pressure rated to 450 psi
water side and 600 psi on the refrigerant
side. Optional ThermaShield coated water-
to-refrigerant coaxial heat exchanger is
available to prevent condensation in low
temperature loop operation.
Service Connections and
Serviceability
Two Schrader service ports are provided
in every unit. The suction side and
discharge side ports are for field charging
and servicing access. All valves are 7/16˝
SAE connections. All water and electrical
connections are made from the front of
the unit. Unit is designed for front access
serviceability.
4-Way Reversing Valve
RC Series units feature a reliable all-brass pilot operated refrigerant
reversing valve. The reversing valve operation is limited to change
of mode by the control to enhance reliability. (Versatec and
FX10 Only).
3-Speed ECM Constant Torque Motors
The 3-speed ECM is a ‘Constant Torque’ ECM motor and delivers air
flow similar to a PSC but operates as efficiently as a variable speed
ECM motor. Because it is an ECM motor, the 3-speed ECM can
ramp slowly up or down like the variable speed ECM motor. There
are 3 possible speed taps available on the 3-speed ECM motor with
#1 being the lowest airflow and #3 being the highest airflow. These
speed selections are preset at the time of manufacture and are easily
changed in the field if necessary.
All-Aluminum Air Coil
Beginning in Spring of 2014, all models in the RC line began shipping
with all-aluminum air coils. These air coils are constructed of lanced
fin and rifled tube aluminum that is not susceptible to formicary
corrosion. For additional condensate runoff and meeting project
specifications, an optional AlumiSeal e-coating is available.
Inside the RC Series Console

9
RC SERIES ENGINEERING GUIDE
Control General Description Application Display/Interface Protocol Thermostat Options
CCM Control The CCM (Compressor control module)
is a more reliable replacement for
electro-mechanical control applications.
It features a small microprocessor
board that handles the lockout function
of the unit.Asecond microporcessor
handles the unit mounted thermostat for
maintaining accurate room temperature.
Residential and commercial
applications requiring minimal but
reliable controls. Includes Random
Start, High and low pressure
switches and auto changeover
capability.
Dial thermostat with Hi and
Low fan speeds, and auto
changeover or cont fan
selection switches.
None Unit Mounted Digital
Dial Thermostat
Remote Mounted
Standard Thermostat
Versatec Control The Versatec Control is a
microprocessor based board that adds
the features of emergency shutdown
(ES), night setback (NS), water freeze
sensing (FS), Load Shed (LS) and
condensate overflow (CO). The
Versatec Control also features Optional
Field servicing LED's for mode, Fault
and diagnostic indication.
Residential and commercial
applications requiring more controls
features than CCM and Includes
Random Start, High and low
pressure switches, auto changeover
capability, emergency shutdown
(ES), night setback (NS), load shed
(LS), water freeze sensing (FS), and
condensate overflow (CO).
Optional field servicing LED
board for mode, fault and
diagnostic indication
None Unit Mounted Digital
Dial Thermostat
Remote Mounted
Standard Thermostat
FX10 The FX10 microprocessor control is self
contained control featuring LP, LOC,
HP, LWT, and condensate overflow
fault modes can be displayed on BAS
system. Optional handheld Medium User
Interface (MUI) Control can be used for
additional setup or servicing. Program
customization is possible. This control is
suited for both single and dual capacity
compressors as well as PSC and ECM
fan motors.
Commercial applications using sin-
gle and dual capacity compressors
with either PSC or ECM fan motors.
Also suitable for multi-compressor
products. Cannot be integrated
with centralized building automation
systems. Software can be custom-
ized for specific projects.
Optional Medium User
Interface (MUI) can be
used as a
field service tool.
Standalone Remote Mounted
Standard Thermostat
Remote Mounted
Sensor
FX10 w/ N2 FX10 Control functions as both unitary
heat pump control and DDC communica-
tion, therefore detail operational and
fault information is available to BAS.
Other features are same as FX10 with
addition of Johnson Controls N2 compat-
ibility.
Same as FX10 with Johnson
Controls N2 BAS compatibility. Optional Medium User Interface (MUI) can be
used as a
field service tool.
Johnson
Controls
N2 network
Remote Mounted
Standard Thermostat
Remote Mounted
Sensor
FX10 w/ LonWorks FX10 Control functions as both unitary
heat pump control and DDC communica-
tion, therefore detail operational and
fault information is available to BAS.
Other features are same as FX10 with
addition of LonWorks compatibility.
Same as FX10 with LonWorks BAS
compatibility. Optional Medium User Interface (MUI) can be
used as a
field service tool.
LonWorks Remote Mounted
Standard Thermostat
Remote Mounted
Sensor
FX10 w/ BACnet FX10 Control functions as both unitary
heat pump control and DDC communica-
tion, therefore detail operational and
fault information is available to BAS.
Other features are same as FX10 with
addition of BACnet compatibility.
Same as FX10 with BACnet BAS
compatibility.
Due to communication speed,
no more than 30 units should
be connected to a single trunk
of the network.
Optional Medium User Inter-
face (MUI) can be mounted
or used as a
field service tool.
BACnet - MS/
TP
(19,200 Baud
Rate)
Remote Mounted
Standard Thermostat
Remote Mounted
Sensor
Standard CCM Control Features
Compressor control module (CCM) controls are standard on the
RC Series console heat pump. This control features unit mounted
thermostat and switches,
Features of the standard control are:
• Easy to understand color coded thermostat adjustment markings.
• Large, rocker type mode and fan switches.
• Internally mounted fan switch to choose cycled or constant
fan operation.
• High pressure and low pressure safety controls to protect the
unit components.
• Lockout circuit to shut down unit operation upon receipt of a fault
indicator from the safety controls.
• A 24 volt control circuit allows for safe and easy diagnosis.
Controls

10
RC SERIES ENGINEERING GUIDE
Figure 6: Unit Mounted Control
The user selects either “Heat/Cool” or “Fan Only” on the mode switch,
then either “High” or “Low” at the fan speed switch. The temperature
can be controlled by rotating the thermostat control knob.
The “Fan Only” setting provides constant fan operation.
In the “Heat” mode, a call for heat by the thermostat closes the
compressor contactor contacts, energizing the compressor, which
will run until the thermostat is satisfied.
In the “Cool” mode, a call for cooling by the
thermostat energizes the reversing valve and closes the
compressor contactor contacts, energizing the compressor, which
will run until the thermostat is satisfied.
The emergency electric heat operation in the “Heat/Cool” mode
is subject to the setting of the internally mounted mode switch.
The optional, factory installed electric heat will operate when the
internally mounted mode switch is in the “Emergency Heat” mode.
In the “Heat” mode, a call for heating energizes the fan and electric
heater contactor, energizing the electric heat elements and fan,
which will run until the thermostat is satisfied. When the internally
mounted mode switch is in the “Normal/Boilerless” mode the unit
operates in its normal “Heat/Cool” operation, unless there is an
aquastat controller. When the normally open circuit of the aquastat
closes and the unit is in the heating mode, it will switch to the
“Emergency Heat” condition until the thermostat is satisfied or the
aquastat opens restarting the compressor.
If either the low or high pressure safety switches are opened, the
compressor and reversing valve are disabled by the lockout relay.
Unit operation will resume only after the voltage to the unit is
interrupted or the mode switch is placed in the “Off” position.
If the electric heat limit switches are opened, the electric heat
is disabled.
Optional Versatec Microprocessor
Control Features
The Versatec microprocessor board provides control of the entire
unit as well as outputs for status modes, faults and diagnostics.
The control system is a microprocessor-based control board that
is located in the unit control box. This feature is available for either
unit mounted controls or optional remote wall mounted thermostat.
A 9-pin low voltage terminal strip provides all necessary terminals
for the wall mounted thermostat.
Startup
The unit will not operate until all the inputs and safety
controls are checked for normal operating conditions.
Fault Retry
All faults are retried twice before finally locking the unit out to
prevent nuisance service calls.
Component Sequencing Delays
Components are sequenced and delayed for optimum unit
performance.
Short Cycle Protection
The control allows a minimum on or off time of 5 minutes for short
cycle protection.
Load Shed
A grounded signal to common or connecting 24 VAC to the LS
terminal places the controller into the load shed mode. The
compressor will become disabled and the fan will start upon a
thermostat call for heating or cooling.
Emergency Shutdown
A grounded signal to common or connecting 24 VAC to the ES
terminal places the controller into the emergency shutdown mode.
The compressor and fan operation are suspended while in the
emergency shutdown mode.
Condensate Overflow Protection
The board incorporates an impedance liquid sensor at the top of
the condensate drain pan. Upon a continuous 30-second sensing
of the condensate, the cooling operation of the unit is suspended.
Safety Controls
The microprocessor board receives separate signals from a high
pressure switch for safety, a low pressure switch to prevent loss of
refrigerant charge and a low suction temperature thermistor for freeze
sensing. Upon a continuous 30-second measurement of the fault
(immediate for high pressure), compressor operation is stopped.
Controls cont.

11
RC SERIES ENGINEERING GUIDE
Mode Inputs Fan Comp RV
Htg Y ON ON OFF
Clg Y,OONONON
Fan G ON OFF OFF
Switch OFF ON
SW1 - 1 Test - Selected timings sped up to facilitate troubleshooting Normal - Standard timings
SW1 - 2 Loop - Closed loop freeze sensing setting (15°F) Well - Open loop freeze sensing setting (30°F)
SW1 - 3 Commercial - Enables NS features when TA32U02 thermostat is used Normal - Standard thermostat operation
SW1 - 4 IO Display* - Enables Input/Output display on external LED board Normal* - Unit status display
SW1 - 5 Configures board for 2-speed compressor without fan Configures board for 2-speed compressor with fan
Logic Board DIP Switch Settings
Blower off delay 30 seconds
Compressor on delay 10 seconds
Short cycle delay 5 minutes
Miniumum compressor on time 2 minutes (except for fault condition)
High pressure fault recognition delay Less than 1 second
low pressure fault recognition delay 30 seconds
Freeze sensing fault recognition delay 30 seconds
Condensate overflow fault recognition delay 30 seconds
Low pressure fault bypass delay 2 minutes
Freeze sensing fault bypass delay 2 minutes
Power on delay 5 minutes
Normal Control Timing Operational Logic
Blower off delay 5 seconds
Compressor on delay 2 seconds
Short cycle delay 15 seconds
Miniumum compressor on time 5 seconds (except for fault condition)
High pressure fault recognition delay Less than 1 second
low pressure fault recognition delay 30 seconds
Freeze sensing fault recognition delay 30 seconds
Condensate overflow fault recognition delay 30 seconds
Low pressure fault bypass delay 0 seconds
Freeze sensing fault bypass delay 0 seconds
Power on delay 15 seconds
Fault off time 5 minutes
Test Control Timing
LED Current Fault Status
SW1 - #4 On, SW2 On
Inputs
SW1 - #4 Off, SW2 Off
Outputs
SW1 - #4 Off, SW2 On
Drain Drain pan overflow Y Compressor
Water Flow FS thermistor (loop <15°F, well <30°F) G FAN
High Press High pressure >600 PSI O O
Low Press Low pressure <40 PSI ES ES
Air Flow Not used NS NS
Status Not used LS LS
DHW Limit Not used Not used Not used
HWD SW2 in the On position Off position On position
Diagnostic Modes
Control Tables for Optional Versatec Microprocessor
Controls cont.

12
RC SERIES ENGINEERING GUIDE
Optional FX10 Control
The optional FX10 control provides unparalleled capability
in several areas including performance monitoring, zoning,
humidity, energy management, and service diagnosis, and then
communicates it all thru standard DDC protocols like N2, Lon and
BACnet (MS/TP @ 19,200 Baud rate).
The most unique feature is integrating the FX10 into the unit as
both the heat pump and DDC controller providing both a cost
advantage and providing features not typically found on WLHP
controls. This integration allows heat pump monitoring sensors,
status and service diagnosis faults to be communicated thru the
DDC direct to the building automation system (BAS), giving building
supervisors detailed and accurate information on every piece of
equipment without removing an access panel.
FX10 Advanced Control Overview
The Johnson Controls FX10 board is specifically designed for
commercial heat pumps and provides control of the entire unit
as well as input ports for Open N2, LonTalk, BACnet (MS/TP @
19,200 Baud rate) communication protocols as well as an input
port for a user interface. The user interface is an accessory item
that can be used to aid in diagnostics and unit setup. A 16-pin
low voltage terminal board provides terminals for common field
connections. The FX10 Control provides:
• Operational sequencing
• High and low-pressure switch monitoring
• General lockout
• Freeze detection
• Condensate overflow sensing
• Lockout mode control
• Emergency shutdown mode
• Random start and short cycle protection
Short Cycle Protection
Allows a minimum compressor “off” time of four minutes and a
minimum “on” time of two minutes.
Random Start
A delay of 1 to 120 seconds is generated after each power-up to
prevent simultaneous startup of all units within a building after the
release from an unoccupied cycle or power loss.
Emergency Shutdown
A field-applied dry contact can be used to place the control into
emergency shutdown mode. During this mode, all outputs on the
board are disabled.
Freeze Detection Limit
Field selectable for 15° or 30°F (-9° or -1°C)
Installation Options
• Standalone controlled by standard room thermostat
• Standalone with a Zone Temperature Sensor (must have user
interface to change set points beyond the allowed +/- 5°F)
• Integrated into BAS by adding communication module
Accessory Outputs
Quantity 2. One cycled with blower, other with compressor.
User Interface
4 x 20 backlit LCD.
Optional Plug-in Communication Modules -
(compatible with standard BAS protocols)
• Open N2
• LonTalk
• BACnet (MS/TP @ 19,200 Baud rate)
Display
Requires DLI Card/Kit. Up to 2 displays, either 1 local and 1
remote, or 2 remote. (A 2-display configuration requires identical
displays.) Local display can be up to 3 meters from the controller,
power supply, and data communication. Remote display can be
up to 300 meters from the controller. Remote display must be
independently powered with data communication done via 3 pole
shielded cable.
Control Timing & Fault Recognition Delays
Lead compressor “ON” delay ............................................90 seconds
(not applicable for single compressor models)
Minimum compressor “ON” time...........................................2 minutes
(except for fault condition)
Short cycle delay..................................................................5 minutes
Random start delay ......................................................0-120 seconds
High pressure fault ............................................................. <1 second
Low pressure fault.............................................................30 seconds
Freeze detection fault ..........................................................30 seconds
Condensate overflow fault.................................................30 seconds
Low pressure fault bypass....................................................2 minutes
Freeze detection fault bypass...............................................2 minutes
Main FX 10 Board
Controls - FX10

13
RC SERIES ENGINEERING GUIDE
Optional FX10 Microprocessor
and BAS Interface
The FX10 is a microprocessor based control that not only monitors
and controls the heat pump but also can communicate any of this
information back to the building automation system (BAS). This
means that not only does the control monitor the heat pump at the
unit you can also monitor and control many the features over the
BAS. This clearly puts the FX10 in a class of its own.
The control will enumerate all fault conditions (HP, LP, CO, LOC,
and Freeze Detection) over a BAS as well as display them on a
medium user interface (MUI). HP, LP, CO and Freeze Detection
faults can all be reset over a BAS. A Loss Of Charge fault can not
be reset or bypassed until the problem has been corrected. A MUI
is invaluable as a service tool for the building service team.
The unit can be commanded to run by a typical heat pump
thermostat or run based on heating and cooling set points supplied
by a BAS. The control board is wired with quick connect harnesses
for easy field change out of a bad control board. An alarm history
can be viewed through the MUI and will be held in memory until the
unit is power cycled. Relative humidity can be read by a 0-5VDC
humidity sensor that is displayed over the network.
The FX10 control has unused analog and digital inputs for field
installed items such as air temperature, water temperature, CO2
or current status switches. The control has unused binary and
PWM outputs that can be commanded over the BAS for field use.
An optional Medium User Interface (MUI) for control setup and
advanced diagnostics is available with some mounting kits, MUIK3 -
Panel mount version and the MUIK4 - Wall mount version.
Zone Sensors
There are two options for zone sensors that can be used with the
FX10 control. Both sensors use a Johnson controls A99 positive
temperature coefficient type sensor. The TAXXJ02 has a set point
adjustment now which will give the end user a +/- 5°F adjustment
from the set point as well as a push button that can be used
for temporary occupancy. The control leaves the factory set to
operate with a TAXXJ02 sensor and can be changed to read the
TAXXA04 sensor through a building automation system or with a
user interface.
Standard Features
• Anti Short Cycle
• High Pressure Protection
• Low Pressure Protection
• Freeze Detection
• Loss Of Charge Detection
• Random Start
• Display for diagnostics
• Reset Lockout at disconnect or through BAS
• 2 Accessory outputs
• Optional BAS add-on controls
DDC Operation and Connection
Other optional network protocol boards that can be added to the
FX10 are:
• Johnson Control N2
• LonWorks
• BACnet
- MS/TP @ 19,200 Baud rate
- Limit devices to 30 on a single trunk line.
Control and Safety Feature Details
Emergency Shutdown
The emergency shutdown mode can be activated by a command
from a facility management system or a closed contact on BI-2. The
default state for the emergency shutdown data point is off. When the
emergency shutdown mode is activated, all outputs will be turned
off immediately and will remain off until the emergency shutdown
mode is de-activated. The first time the compressor starts after the
emergency shutdown mode has been de-activated, there will be a
random start delay present.
Lockout Mode
Lockout mode can be activated by any of the following fault
signals: refrigerant system high pressure, refrigerant system low
pressure, freeze detection, and condensate overflow. When any
valid fault signal remains continuously active for the length of its
recognition delay, the controller will go into fault retry mode, which
will turn off the compressor. After the Compressor short cycle
delay, the compressor will attempt to operate once again. If three
consecutive faults occur in 60 minutes during a single heating
or cooling demand, the unit will go into lockout mode, turning off
the compressor, and enabling the alarm output until the controller
is reset. If the control faults due to the low pressure input (BI-3)
being open during the pre-compressor startup check, the control
will go into lockout mode immediately, disabling the compressor
from starting and enabling the alarm output (BO-6). The lockout
condition can be reset by powering down the controller, by a
command from the BAS, or by the holding the ESC and Return
keys on the MUI for 5 seconds.
Freeze Detection Limit (AI-5)
The freeze detection limit sensor will monitor the liquid refrigerant
temperature entering the water coil in the heating mode. If the
Controls - FX10 cont.

14
RC SERIES ENGINEERING GUIDE
temperature drops below the freeze detection limit trip point for the
recognition delay period, the condition will be recognized as a fault.
The freeze detection limit trip point will be factory set for 30°F and
will be field selectable for 15°F by removing a jumper wire on BI-5.
The freeze detection limit fault condition will be bypassed 2 minutes
at normal compressor startup, to allow the refrigeration circuit to
stabilize. If the freeze detection limit sensor becomes unreliable
at any time compressor operation will immediately be suspended
until the problem is corrected. This should be displayed as an alarm
on the BAS and the MUI. This alarm will be reported a “Water Low
Temp Limit” fault.
High Pressure (BI-11)
The high-pressure switch shall be a normally closed (NC) switch
that monitors the systems refrigerant pressure. If the input senses
the high-pressure switch is open it must disable the compressor
output immediately and count the fault. The compressor minimum
on time does not apply if the high-pressure switch opens. The
compressor will not restart until the compressor short cycle time
delay has been satisfied.
Low Pressure (BI-3)
The low-pressure switch shall be a normally closed (NC) switch
that monitors the systems refrigerant pressure. The input shall be
checked 15 seconds before compressor start up to be sure the
pressure switch is closed and then ignored for the first 2 minutes
after the compressor output (BO-2) is enabled. If the switch is open
continuously for (30) seconds during compressor operation the
compressor output (BO-2) will be disabled. The compressor will not
restart until the compressor short cycle time delay has been satisfied.
Condensate Overflow
The condensate overflow sensing circuit will monitor the
condensate level as a resistance input to AI-3. If the condensate
water level rises resulting in the input resistance rising above the
set point for the recognition delay period, the condition will be
recognized as a fault. The condensate will be subjected to a (30)
second lockout delay which requires that the fault be sensed for a
continuous (30) seconds before suspending unit operation.
Alarm Output (BO-6)
The alarm output will be enabled when the control is in the lockout
mode and will be disabled when the lockout is reset.
Test Mode
Raising the zone temperature input (AI-1) reading to 180–220°F or
by holding the ESC and down arrow keys on the MUI for 5 seconds
will put the control into test mode. In test mode the random start
delay and the compressor fixed on delay time will both be shortened
to 5 seconds and the reversing valve will be allowed to cycle with
out shutting down the compressor. If an MUI is connected to the
control LED 8 will flash and the words “Test Mode Enabled” will be
shown on the LCD display when the control is in test mode. Test
mode will be disabled after a power cycle, 30 minute timeout, or by
holding the ESC and Up arrow keys on the MUI.
Sequence of Operation
Power Fail Restart
When the controller is first powered up, the outputs will be
disabled for a random start delay. The delay is provided to prevent
simultaneous starting of multiple heat pumps. Once the timer
expires, the controller will operate normally.
Random Start Delay
This delay will be used after every power failure, as well as
the first time the compressor is started after the control exits
the unoccupied mode or the emergency shutdown mode. The
delay should not be less than 1 second and not longer than 120
seconds. If the control is in test mode the random start delay will be
shortened to 5 seconds.
Compressor Fixed On Delay Time
The Compressor Fixed On Delay Time will ensure that the
compressor output (B02) is not enabled for (90) seconds after
the control receives a call to start the compressor. This delay is
adjustable from 30 – 300 seconds over a BAS or a MUI. If the
control is in test mode the Compressor Fixed On Delay Timer will
be shortened to 5 seconds.
Compressor Minimum On Delay
The compressor minimum on delay will ensure that the
compressor output is enabled for a minimum of (2) minute each
time the compressor output is enabled. This will apply in every
instance except in the event the high pressure switch is tripped
or emergency shutdown then the compressor output will be
disable immediately.
Compressor Short Cycle Delay Time
The compressor short cycle time delay will ensure that the
compressor output will not be enabled for a minimum of (5) minutes
after it is disabled. This allows for the system refrigerant pressures
to equalize after the compressor is disabled.
Heating Cycle
On a call for heating, the blower enable output and accessory
output 2 will turn on immediately after the random start delay timer
has been satisfied. If the compressor short cycle time delay has
been satisfied, the compressor will turn on after the blower enable
and accessory output 2 are on and the fixed compressor start delay
timers have been satisfied.
Controls - FX10 cont.

15
RC SERIES ENGINEERING GUIDE
Cooling Cycle
On a call for cooling, the blower enable output and accessory
output 2 will turn on immediately after the random start delay timer
has been satisfied. If the compressor short cycle time delay has
been satisfied, the compressor will turn on after the blower enable
and accessory output 2 are on and the fixed compressor start delay
timers have been satisfied.
MUI Alarm History Reporting
If a fault occurs the fault will be recorded in history for display on
the medium user interface in the History Menu. Each fault type will
be displayed in the history menu with a number between 0 and 3.
A reading of 3+ will mean that fault has occurred more than three
times in the past. The history menu can be cleared with a power
cycle only. Alarm date and time are not included in the history.
Inputs and Outputs Configuration
Field Selectable Options
Freeze Detection Limit Set Point (BI-5)
The freeze detection limit set point input allows you to adjust the
freeze detection limit set point (AI-5). When the jumper is installed
on BI-5 (Wire #24) the freeze detection limit set point is factory
set for 30°F. When the jumper on BI-5 (Wire #24) is removed the
freeze detection limit set point will be 15°F.
Accessory Outputs (BO-7 and BO-8)
Accessory Output 1 will be energized 90 seconds prior to the
compressor output being energized. Accessory Output 2 will be
energized with the fan output (BO-1). When the corresponding
compressor output is turned off the accessory output will be
deactivated immediately. These outputs are selectable for normally
open or normally closed operation through the Medium User
interface or through the Building Automation System.
Control Accessories
Zone Sensors
• TAXXJ02 Room Command Module
• TAXXA04 LCD Room Command Module
• A99 Sensor
MUI (LCD User interface) for diagnostics and commissioning.
• MUIK3 - Panel Mount, Portable
• MUIK4 - Wall Mount
Controls - FX10 cont.
Input Name Input Output Name Output
Zone Temp 1 AI 1 Fan Enable BO1
Relative Humidity Input AI 2 Comp – Low Capacity BO2
Condensate Level AI 3 Reversing Valve BO3
Universal Temp Input AI 4 Comp – Full Capacity BO4
Water Coil Low Temperature Limit AI 5 Network Output/EH Output BO5
Warm/CoolAdjust and Temp Occ AI 6 Alarm BO6
Accessory 1 Output BO7
Occupied BI 1 Accessory 2 Output BO8
Emergency Shutdown BI 2 Network Controlled Output B09
Stage 1 Low Pressure BI 3
Network Viewable Input 1 BI 4 ECM2 Fan PWM1
Water Coil Low Temp Limit Set Point BI 5 Network Controlled Output PWM2
Network Viewable Input 2 BI 6
Thermostat Y1 BI 7
Thermostat Y2 BI 8
Thermostat O BI 9
Thermostat G B10
Stage 1 High Pressure BI11
Compressor Proving BI12
XP10 Expansion Card
Input Name Input Output Name Output
Unused AI 1 Unused BO 1
Unused AI 2 Unused BO 2
Unused AI 3 Unused BO 3
Unused AI 4 Unused BO 4
SINGLE and DUAL STAGE WATER-TO-AIR

16
RC SERIES ENGINEERING GUIDE
The Closed Loop Heat Pump Concept
The basic principle of a water source heat pump is the transfer
of heat into water from the space during cooling, or the transfer
of heat from water into the space during heating. Extremely high
levels of energy efficiency are achieved as electricity is used only
to move heat, not to produce it. Using a typical RC Series, one unit
of electricity will move four to five units of heat.
When multiple water source heat pumps are combined on a
common circulating loop, the ultimate in energy efficiency is
created: Units on cooling mode are adding heat to the loop which
the units in heating mode can absorb, thus removing heat from the
area where cooling is needed, recovering and redistributing that
heat for possible utilization elsewhere in the system. In modern
commercial structures, this characteristic of heat recovery from
core area heat generated by lighting, office equipment, computers,
solar radiation, people or other sources, is an important factor in
the high efficiency and low operating costs of closed source heat
pump systems.
In the event that a building's net heating and cooling requirements
create loop temperature extremes, RC Series units have the
extended range capacity and versatility to maintain a comfortable
environment for all building areas. Excess heat can be stored
for later utilization or be added or removed in one of three ways;
by ground-source heat exchanger loops: plate heat exchangers
connected to other water sources, or conventional cooler/boiler
configurations. Your representative has the expertise and computer
software to assist in determining optimum system type for specific
applications.
The Closed Loop Advantage
A properly applied water source heat pump system offers many
advantages over other systems. First costs are low because
units can be added to the loop on an “as needed basis”- perfect
for speculative buildings. Installed costs are low since units are
self-contained and can be located adjacent to the occupied
space, requiring minimal ductwork. Maintenance can be done
on individual units without system shut-down. Conditions remain
comfortable since each unit operates separately, allowing cooling
in one area and heating in another. Tenant spaces can be
finished and added as needed. Power billing to tenants is also
convenient since each unit can be individually metered: each pays
for what each uses. Nighttime and/or weekend uses of certain
areas are possible without heating or cooling the entire facility.
A decentralized system also means if one unit should fault, the
rest of the system will continue to operate normally, as well as
eliminating air cross-contamination problems and expensive high
pressure duct systems requiring an inefficient electric resistance
reheat mode.
The RC Series Approach
There are a number of proven choices in the type of RC Series
system which would be best for any given application. Most often
considered are:
• Closed Loop/Ground-Source Systems utilize the stable
temperatures of the earth to maintain proper water source
temperatures (via vertical or horizontal closed loop heat
exchangers) for RC Series extended range heat pump system.
Sizes range from a single unit through many hundreds of
units. When net cooling requirements cause closed loop water
temperatures to rise, heat is dissipated into the cooler earth
through buried high strength plastic pipe “heat exchangers.”
Conversely if net space heating demands cause loop heat
absorption beyond that heat recovered from building core areas,
the loop temperature will fall causing heat to be extracted from the
earth. Due to the extended loop temperatures, AHRI/ISO 13256-1
Ground Loop Heat Pumps are required for this application.
Because auxiliary equipment such as a fossil fuel boiler and
Supply Water
Return Water
Pumps
R Series
Unit
R Series
Unit
R Series
Unit
R Series
Unit
R Series
Unit
R Series
Unit
Heater/
Rejector
Vertical - Closed Loop/Ground Source
Application Notes

17
RC SERIES ENGINEERING GUIDE
• Closed Loop/Ground Water Plate Heat Exchanger
Systems utilize lake, ocean, well water or other water sources to
maintain closed loop water temperatures in multi-unit RC Series
systems. A plate frame heat exchanger isolates the units from any
contaminating effects of the water source, and allows periodic
cleaning of the heat exchanger during off peak hours.
Operation and benefits are similar to those for ground-source
systems. Due to the extended loop temperatures, AHRI/ISO
13256-1 Ground Loop Heat Pumps are required for this application.
Closed loop plate heat exchanger systems are applicable in
commercial, marine, or industrial structures where the many
benefits of a water source heat pump system are desired,
regardless of whether the load is heating or cooling dominated.
cooling tower are not required to maintain the loop temperature,
operating and maintenance costs are very low.
Ground-source systems are most applicable in residential and
light commercial buildings where both heating and cooling are
desired, and on larger envelope dominated structures where core
heat recovery will not meet overall heating loads. Both vertical
and horizontally installed closed-loops can be used. The land
space required for the “heat exchangers” is 100-250 sq. ft./ton on
vertical (drilled) installations and 750-1500 sq. ft./ton for horizontal
(trenched) installations. Closed loop heat exchangers can be
located under parking areas or even under the building itself.
On large multi-unit systems, sizing the closed loop heat exchanger
to meet only the net heating loads and assisting cooling loads
with a closed circuit cooling tower may be the most cost effective
choice.
• Closed Loop/Ground-Source Surface Water Systems also
utilize the stable temperatures of Surface Water to maintain proper
water source temperatures for RC Series extended range heat
pump systems. These systems have all of the advantages of
horizontal and vertical closed loop systems. Due to the extended
loop temperatures, AHRI/ISO 13256-1 Ground Water or Ground
Loop Heat Pumps are required for this application.
In cooling dominated structures, the ground-source surface water
systems can be very cost effective especially where local building
codes require water retention ponds for short term storage of
surface run-off. Sizing requirements for the surface water is a
minimum of 500 sq. ft./ton of surface area at a minimum depth of 8
feet. WaterFumace should be contacted when designs for heating
dominated structures are required.
Surface Water - Closed Loop/Ground Source
Plate Heat Exchanger - Closed Loop/Ground Water
Application Notes cont.

18
RC SERIES ENGINEERING GUIDE
• Closed Loop /Cooler-Boiler Systems utilize a closed heat
recovering loop with multiple water source heat pumps in the more
conventional manner. Typically a boiler is employed to maintain
closed loop temperatures above 60°F and a cooling tower to
maintain loop temperatures below 90°F. These systems are
applicable in medium to large buildings regardless of whether the
load is heating or cooling dominated. Due to the moderate loop
temperatures, AHRI/ISO 13256-1 Water Loop Heat Pumps are
required for this application.
Cooler/Boiler - Closed Loop
Application Notes cont.
In ground water situations where scaling could be heavy or where
biological growth such as iron bacteria will be present, a closed
loop system is recommended. The heat exchanger coils in ground
water systems may, over a period of time, lose heat exchange
capabilities due to a buildup of mineral deposits inside. These
can be cleaned, but only by a qualified service mechanic, as
special solutions and pumping equipment are required. Hot water
generator coils can likewise become scaled and possibly plugged.
Water Quality
Material Copper 90/10 Cupronickel 316 Stainless Steel
pH Acidity/Alkalinity 7 - 9 7 - 9 7 - 9
Scaling Calcium and
Magnesium Carbonate (Total Hardness) less than 350 ppm (Total Hardness) less than 350 ppm (Total Hardness) less than 350 ppm
Corrosion
Hydrogen Sulfide Less than 0.5 ppm (rotten egg
smell appears at 0.5 ppm) 10 - 50 ppm Less than 1 ppm
Sulfates Less than 125 ppm Less than 125 ppm Less than 200 ppm
Chlorine Less than 0.5 ppm Less than 0.5 ppm Less than 0.5 ppm
Chlorides Less than 20 ppm Less than 125 ppm Less than 300 ppm
Carbon Dioxide Less than 50 ppm 10 - 50 ppm 10 - 50 ppm
Ammonia Less than 2 ppm Less than 2 ppm Less than 20 ppm
Ammonia Chloride Less than 0.5 ppm Less than 0.5 ppm Less than 0.5 ppm
Ammonia Nitrate Less than 0.5 ppm Less than 0.5 ppm Less than 0.5 ppm
Ammonia Hydroxide Less than 0.5 ppm Less than 0.5 ppm Less than 0.5 ppm
Ammonia Sulfate Less than 0.5 ppm Less than 0.5 ppm Less than 0.5 ppm
Total Dissolved Solids (TDS) Less than 1000 ppm 1000 - 1500 ppm 1000 - 1500 ppm
LSI Index +0.5 to -0.5 +0.5 to -0.5 +0.5 to -0.5
Iron Fouling
(Biological Growth)
Iron, FE2+ (Ferrous)
Bacterial Iron Potential < 0.2 ppm < 0.2 ppm < 0.2 ppm
Iron Oxide Less than 1 ppm, above this level
deposition will occur Less than 1 ppm, above this level deposition will occur Less than 1 ppm, above this level deposition will occur
Erosion Suspended Solids Less than 10 ppm and filtered for
max. of 600 micron size Less than 10 ppm and filtered for max. of 600 micron size Less than 10 ppm and filtered for max. of 600 micron size
Threshold Velocity
(Fresh Water) < 6 ft/sec < 6 ft/sec < 6 ft/sec
NOTES: Grains = ppm divided by 17
mg/L is equivalent to ppm 2/22/12
In areas with extremely hard water, the owner should be informed
that the heat exchanger may require occasional flushing.
Units with cupronickel heat exchangers are recommended for
open loop applications due to the increased resistance to build-up
and corrosion, along with reduced wear caused by acid cleaning.
Failure to adhere to the guidelines in the water quality table could
result in the loss of warranty.

19
RC SERIES ENGINEERING GUIDE
Typical Unit Installation
Unit Location
Locate the unit in an indoor area that allows for easy removal of
the filter and access panels. Location should have enough space
for service personnel to perform maintenance or repair. Provide
sufficient room to make water and electrical connection(s).Any
access panel screws that would be difficult to remove after the unit
is installed should be removed prior to setting the unit. Care should
be taken when units are located in unconditioned spaces to
prevent damage from frozen water lines and excessive heat
that could damage electrical components.
Installing Console Units
Console units are available in left or right air return configurations.
Units should be mounted level on the floor. It is not necessary to
anchor the unit to the floor.
WARNING: Before performing service or maintenance
operations on a system, turn off main power switches to the
indoor unit. If applicable, turn off the accessory heater power
switch. Electrical shock could cause personal injury.
Installing and servicing heating and air conditioning equipment can
be hazardous due to system pressure and electrical components.
Only trained and qualified service personnel should install, repair
or service heating and air conditioning equipment. Untrained
personnel can perform the basic maintenance functions of cleaning
coils and cleaning and replacing filters.
All other operations should be performed by trained service
personnel. When working on heating and air conditioning
equipment, observe precautions in the literature, tags and labels
attached to the unit and other safety precautions that may apply.
Follow all safety codes. Wear safety glasses and work gloves.
Use a quenching cloth for brazing operations and have a fire
extinguisher available.
1=<A=:3
1/07<3B
1=<A=:3
16/AA7A
1=<23<A/B3
2@/7<:=1/B7=<
=>B7=</:6 =A3A
0/::D/:D3A
=>B7=</:
>B>:C5A
=>B7=</:
E/B3@
=CB
E/B3@
7<
1=<A=:31/07<3B
0/19>:/B3
=>B7=</:
E/::>3<3B@/B7=<
4=@E/B3@1=<<31B7=<
4:==@>3<3B@/B7=<
4=@E/B3@1=<<31B7=<
4CA323:31B@71/:
27A1=<<31B=>B7=</:
;=B=@7H32
2/;>3@
=>B7=</:
;=B=@7H32
2/;>3@
=>3<7<5
Application Notes cont.

20
RC SERIES ENGINEERING GUIDE
Water Piping
Piping is usually design as ‘reverse return’ to equalize flow paths
through each unit. A short flexible pressure rated hose is used to
make connection to the fixed building piping system. This hose
is typically stainless steel braid and includes a swivel fitting on
one end for easy removal and is flexible to help isolate the unit
for quieter operation . Isolation valves for servicing, y-strainers for
filtering and memory-stop flow valve or a balancing valve can be
provided for consistent water flow through the unit.
All unit source water connections are fittings that accept a male
pipe thread (MPT). Insert the connectors by hand, then tighten
the fitting with a wrench to provide a leakproof joint. The open and
closed loop piping system should include pressure/temperature
ports for serviceability. The proper water flow must be provided to
each unit whenever the unit operates. To assure proper flow, use
pressure/temperature ports to determine the flow rate. These ports
should be located at the supply and return water connections on
the unit. The proper flow rate cannot be accurately set without
measuring the water pressure drop through the refrigerant-to-
water heat exchanger. Check carefully for water leaks.
Condensate Drain
On console units, the internal condensate drain assembly consists
of a drain tube which is connected to the drain pan. A condensate
tube is inside all cabinets as a trapping loop; therefore, an
external trap is not necessary.
Application Notes cont.
