Johnson Controls S300 Series Assembly instructions

December 2017
24-10239-359 Revision C
S300
Series
S300-DIN-S
Hardware Installation Manual

Copyright 2017
Johnson Controls
All Rights Reserved
No part of this document may be reproduced without the prior permission of Johnson Controls.
If this document is translated from the original English version by Johnson Controls, all reasonable endeavors will be
used to ensure the accuracy of translation. Johnson Controls shall not be liable for any translation errors contained
herein or for incidental or consequential damages in connection with the furnishing or use of this translated material.
Due to continuous development of our products, the information in this document is subject to change without notice.
Johnson Controls shall not be liable for errors contained herein or for incidental or consequential damages in
connection with furnishing or use of this material. Contents of this publication may be preliminary and/or may be
changed at any time without any obligation to notify anyone of such revision or change, and shall not be regarded as
a warranty.
Other Manufacturers’ Documentation
Johnson Controls does not duplicate documentation of other equipment manufacturers. When necessary, Johnson
Controls provides documentation that supplements that of other manufacturers. When unpacking equipment, keep all
original manufacturer documentation for future reference.
Technical Support
For factory technical support, Johnson Controls authorized field technicians or authorized dealer representatives can
contact Global Security Solutions Technical Support by phone at [phone] or [phone], or by email at
support.globalsecurit[email protected]. They can also call the Field Support Center at [phone] or (414)
524-5000 and use options 6, 1, 7.
End users and customers should contact their local Johnson Controls branch or authorized dealer for any of their
support needs (technical support, maintenance contracts, on-site field support, P2000 Software Service Agreements,
Service Partnerships, and so on). Visit http://www.johnsoncontrols.com/location-finder to find your local Johnson
Controls office.
For material returns contact the branch if the material was purchased through a Johnson Controls branch or through
the Product Sales Operations Team, if ordered through the Advanced Order Management System (AOMS) and follow
the RMA process; or contact the authorized dealer representative where the material was purchased directly.
Acknowledgments
Metasys® and Johnson Controls® are trademarks of Johnson Controls. All other company and product names are
trademarks or registered trademarks of their respective owners.

Declaration of Conformity
United States: This equipment, S300-DIN-S, has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The user is cautioned that changes and modifications made to the equipment without approval of the manufacturer
could void the user's authority to operate this equipment.
Canada: CAN ICES-3 (B)/NMB-3(B)

UNDERWRITERS LABORATORIES COMPLIANCE VERIFICATION SHEET
The following model number is listed under Underwriters Laboratories® (UL) 1076 for Proprietary Burglar Alarm
Units and Systems, UL 294 for Access Control Systems Units, and Underwriters Laboratories of Canada 
ULC/ORD-C1076-86.
S300-DIN-S
When installed at the site the following requirements must be met to comply with these standards.
1. The S300-DIN-S is intended to be used with listed sub-assemblies found in file BP4166, Vol. 2, Sec. 7.
2. The S300-DIN-S in combination with the listed sub-assembly must be connected to a UL Listed
Uninterruptible Power Supply that provides a minimum of 24 hours of AC emergency power.
3. The tamper switch must be connected to a listed sub-assembly and enabled at all times.
4. Transient protection devices that are installed must not be removed or defeated.
5. Do not connect equipment to an AC power source that is controlled by a switch.
6. Model S300-DIN-S must use a Class 2 direct plug-in transformer rated 120 VAC input and 24 VAC, 50 VA
output from one of the following manufacturers:
Basler, part number BE116450CAA or BE116450AAA
Potter Electric Signal Co. (Amseco), model XR-2450LED
Revere Industries, model RT-2450SL/M
7. Model S300-DIN-S power supply must have the voltage selection jumper set to 24VDC.
8. UL 294 Performance Levels
Destructive Attack Level I
Endurance Level IV
Line Security Level I
Standby Power Level II

24-10239-359 Rev. C 1
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
HARDWARE INSTALLATION
INTRODUCTION
This document provides information necessary for the installation of the S300-DIN-S
enclosure and related equipment, including field devices.
The S300-DIN-S is a small enclosure used to house a DIN-mountable electronic device and,
optionally, a backup battery unit.
Field device Power supplyBackplate
Backup batteries Tamper switchGround strap DIN rail
The S300-DIN-S comes with a backplate, a tamper switch, a lock, and a ground strap kit.
The backplate contains a power supply and a DIN rail for device mounting.
The figure below gives you an overview of the small enclosure with all components
installed. The device shown here is the S300-DIN-RDR2S.
APPLICATION
One device can be mounted on the DIN rail (for example, a S300-DIN-RDR2S module,
a CK722 controller, or a CK721-A controller).
You can also mount a backup battery unit. The unit is composed of two 12V lead-acid
batteries in one battery bracket.

Hardware Installation S300-DIN-S
2 24-10239-359 Rev. C
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
INSTALLATION
This section describes the hardware installation of the S300-DIN-S enclosure and its
components.
Unpacking the Equipment
Carefully inspect the shipping containers as soon as you receive them (with the
delivery agent present). Some shipping companies want to have an agent present
when a damaged container is opened. If a container is damaged, open it
immediately, inspect the contents, and have the agent make note on the shipping
document. Check the purchase order against the packing slips to ensure the order is
complete. If the contents of a container are damaged in any way, notify the carrier
and your Johnson Controls representative immediately. Report any discrepancies to
your Johnson Controls representative. Save the packing materials for possible return
shipments.
Package Contents
Backplate
Tamper switch
Lock
Ground strap kit
This document
Tools Needed
Mounting tools, such as a drill and anchors (depending on where you mount
the enclosure)
Phillips screwdriver
Small common screwdriver
Standard wiring tools
Hammer and punch
MOUNTING
Small Enclosure (S300-DIN-S)
Four mounting holes are provided. The top and left side panel of the enclosure have
knockouts that can be used for the AC power input. Bottom panels are equipped
with knockouts for other cables.

Mounting holes 12"
(30cm)
6"
(15cm)
12"
(30 cm)
24-10239-359 Rev. C 3
S300-DIN-S Hardware Installation
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
Ground Strap
The ground strap is used to provide ground to the enclosure door.
To install the ground strap:
1. Put one ring terminal over the screw in the side panel and secure with a nut.
2. Put the other ring terminal over the screw in the enclosure door and secure
with a nut.
Mounted ground strap

Hardware Installation S300-DIN-S
4 24-10239-359 Rev. C
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
Backplate
To mount the backplate:
1. Place the backplate inside the enclosure and align the backplate’s four
mounting holes with posts in the enclosure.
2. Secure the plate with nuts provided.
Installed
backplate
Grounding shield
termination points
Transformer (S300-XFMR)
The power supply in the small enclosure should be powered from the S300-XFMR
plug-in wall transformer. This transformer converts the 120 VAC line power to
24 VAC for the power supply. The transformer is rated at 24 VAC, 50 VA.
A transformer is required for each panel or enclosure to connect the power supply to
local power.
Cable for the transformer must be constructed using listed 18 AWG wire.
NOTE
For Canadian installations use Basler transformer part number BE116450AAA,
or Revere Industries model RT-2450SL/M.
Constructing the Transformer Cable
Use a 2-conductor listed 18 AWG cable between the connector and the transformer.
Connect the transformer to the nearest source of clean, unswitched AC power, and
ensure you use the correct voltage for your S300-DIN-S model. The transformer
output is 24 VAC, 50 VA. The input is 120 VAC. At the S300-DIN-S, connect AC
power as follows.
To connect AC power:
1. Put the cable from the S300-XFMR transformer through the knock out in the
left or top panel of the enclosure.

24-10239-359 Rev. C 5
S300-DIN-S Hardware Installation
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
2. Connect the cable to the power supply.
3. A separate wire, 18AWG minimum, must be run from the dedicated ground
stud inside the S300-DIN-S enclosure to the building’s electrical ground. The
dedicated ground is marked with the symbol .
To verify DC ground:
1. Verify the wire connection between the power supply and COM on the
DIN-mounted device.
2. Verify the wire connection between the power supply and its standoff.
To verify chassis ground:
1. Verify the wire connection between the DIN-mounted device earth and the
backplate.
2. Verify the wire connection between the AC power source and the backplate.
3. Verify the wire connection between the DC and one of the power supply’s
mounting holes.
Power Supply (S300-DIN-S-PS)
S300-DIN-S-PS is a power supply to be used with S300-DIN-S. It is shipped already
mounted on the backplate. S300-DIN-S-PS is equipped with an AC power indicator.
A battery charger is included with the power supply package.
This power supply has a Listed 4A, 3AGC standard fuse.
Input
Continuous
output
AC LED
indicator
Battery
connector
Voltage
selector
Mounting hole
(one of 4)

Hardware Installation S300-DIN-S
6 24-10239-359 Rev. C
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
To replace the S300-DIN-S-PS power supply:
1. Disconnect the AC input wires from the terminal block on the power supply.
2. Disconnect the battery cable.
3. Disconnect the two DC power wires.
4. Unscrew the power supply unit.
5. Mount the new power supply unit.
6. Ensure the voltage selector switch is set to 24.
7. Re-connect the cables in the reverse order.
IMPORTANT
Connect the AC power source last.
DIN-Mountable Devices
The DIN-mountable device (for example: a S300-DIN-RDR2S module, a CK722
controller, or a CK721-A controller) is mounted on the backplate’s DIN rail.
To mount a device, align it with the rail and snap it on (on some devices, you may
need to extend the white clips located on the bottom of the device prior to snapping
it on). To remove a device, pull down the bottom clips, then pull the bottom of the
device out and lift it up.
IMPORTANT
Do not connect the DC power cable to the DIN-mounted device until all
wiring is complete.
An S300-DIN-RDR2S module
mounted in the S300-DIN-S

CK722 module mounted in
the S300-DIN-S
24-10239-359 Rev. C 7
S300-DIN-S Hardware Installation
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
WIRING
This section describes how to wire the DIN-mounted devices. For cable requirements, refer
to the user documentation for the particular device.
IMPORTANT
Do not connect the DC power cable to the DIN-mounted device until all
wiring is complete.
Cable Requirements
Use the DC power harness for power and ground wiring. This cable assembly
contains the +24 VDC connector.
Chassis
ground
COM
+24 VDC
connector
black
red
green
Connects to the DIN-mounted device
Figure 1: DC Power Harness
Power Wiring
To construct the power wiring, use listed 18 AWG wires.

Hardware Installation S300-DIN-S
8 24-10239-359 Rev. C
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
Ground Wiring
The ground wire should be connected to the backplate by fastening the ring terminal
to any one of the 0.11" holes located at the bottom of the plate with a #6 self-tapping
screw.
To construct the ground wiring, use listed 18AWG wires.
Cable Routing
All low-level input cables, such as system data and reader cables, must be shielded
types. The cables should run in grounded conduit or at least two feet from
AC power, fluorescent lights, or other high energy sources.
IMPORTANT
All data cables should be physically separated from power lines. If conduit is
used, do not run data cables in the same conduit as power cables or certain
door strike cables, e.g. strike voltage greater that 42V or Magnetic door locks
without EMI suppression.
All cables must conform with the following regulations:
National Electrical Code
NFPA 70
Local electrical codes
Canadian Electric Code C22.1 (installations in Canada)
Cabling should be made using good wiring practices and should be long enough to
allow service loops at their terminations in the enclosure.
Grounding Cable Shields
The grounding screws used are #6 x 1/4” self-tapping, and are provided in the
hardware installation kit.
Chassis Grounding
Proper grounding of the S300-DIN-S enclosure is essential for the protection of
electronic components against electrostatic discharge. A ground wire, 18 AWG
minimum, must be run from the dedicated ground stud inside the enclosure to the
building’s electrical ground.
The dedicated ground stud is marked with the following symbol: .
IMPORTANT
Conduit ground, cold water pipes, unbrazed joints or dissimilar metals are
unacceptable in the path of either building or supplemental ground. Where
grounding is required, connect only to the proven building electrical system
ground (earth).

24-10239-359 Rev. C 9
S300-DIN-S Hardware Installation
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
BACKUP BATTERIES
Battery Bracket Kit (S300-DIN-BRK)
The S300-DIN-BRK battery bracket kit is used to mount the batteries in the
enclosure. The same kit is used for small and large enclosures, and, depending on
your installation, you will need only some of the parts that are included.
The batteries and bracket kit are sold separately and the batteries can be replaced
without ordering an additional kit.
Each kit contains the following:
Two brackets
Mounting hardware
Short battery wiring (used with small enclosures only)
Long battery wiring (used with large enclosures only)
S300-DIN battery wiring
Two adhesive cable tie mounting pads
Two cable ties
Mounting
hardware
Short and long
battery wiring
Adhesive
cable tie
mounting
pads
Cable ties
Brackets
S300-DIN
battery wiring
Figure 2: Battery Bracket Kit

Hardware Installation S300-DIN-S
10 24-10239-359 Rev. C
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
S300-BAT-2.8AH
Two optional S300-BAT-2.8AH backup batteries are used with S300-DIN-S. Their
addition to the enclosure provides an Uninterruptible Power Supply (UPS).
The batteries to be used are Power Sonic, Model PS-1228. These are rechargeable
lead-acid batteries, 12VDC, 2.8Ah. For maintenance guidelines see page 13.
The backup batteries are rated for a minimum of 1 1/2 hours on a fully loaded
system.
To install S300-BAT-2.8AH batteries:
1. Place the batteries inside the bracket and position over the mounting screws.
2. Secure the bracket with the nuts.
3. Wire the batteries in series using the short battery wiring.
4. Using the S300-DIN battery wiring, connect the batteries to the power supply.
5. Secure the wires to the enclosure using mounting pads and cable ties.
connectors
Battery’s
Bracket
Mounting
hardware
+
–
–
+
Figure 3: Properly Installed S300-BAT-2.8AH Batteries

24-10239-359 Rev. C 11
S300-DIN-S Hardware Installation
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
TAMPER SWITCH KIT
The Tamper Switch Kit is supplied with the enclosure.
Bracket
mounting nuts
Tamper
switch with
cable
Bracket
Tamper switch
mounting nut
To install the tamper switch:
1. Position the bracket on the inside of the right side panel so that the two
screws go though the bracket holes.
2. Secure the bracket with nuts.
3. Put the tamper switch through the single bracket hole and secure with a nut.
4. Wire the tamper switch. The switch must be wired to an input point on a
DIN-mounted device.
Figure 4: Tamper Switch Properly Installed

Hardware Installation S300-DIN-S
12 24-10239-359 Rev. C
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
HARDWARE KIT
The S300-DIN Hardware Kit consists of:
Ground strap - The ground strap, used to provide ground to the enclosure door,
contains a ground strap with two ring terminals and two nuts. For an installation
procedure see page 3.
Self-tapping screws - On the backplate, there are two rows of holes along the long
edges of the plate. These are to be used with self-tapping screws. Use the
self-tapping screws to connect the aluminum shield of a shielded cable to the
backplate.
Snap-spade terminals - These terminals are used with S300-DIN-S enclosures only.
The snap-spade terminals are to be crimped to the cable coming from the
S300-XFMR transformer and terminating at the power supply in the S300-DIN-S.
NOTE
For terminating the snap-spade terminal lugs found in the hardware kit use
Molex crimp tool P/N 64001-0100, 64001-0300 or 64001-1200.
TECHNICAL SPECIFICATIONS
Model Number Description Specification
S300-DIN-S Small enclosure Made of 16 gauge steel with gray polyester
powder coating. 
Dimensions: 12x12x6 in (30x30x15 cm)
Approximate weight fully loaded: 24lb (11 kg)
S300-XFMR Plug-in
transformer
120 VAC to 24 VAC
S300-DIN-S-PS Power supply 24VDC out, 24VAC in.
Input
AC nominal: 24-28VAC
Power rating: 50VA
Output
Output voltage (switch selectable, must be
selected): 24VDC
Output voltage (typical): 27.5VDC
Output current (continuous): 1.6A
Load regulation (no load to max): 0.05% typical
Other
Battery charge current: 150mA
Battery cutoff voltage: None
Battery fuse: Listed 4A, 3AGC standard fuse.
S300-DIN-BRK Battery bracket kit N/A

24-10239-359 Rev. C 13
S300-DIN-S Hardware Installation
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
ENVIRONMENTAL SPECIFICATIONS
The following general specifications apply to the system components:
Item Specification
Ambient temp. 32 to 122 °F (0 to 50° C)
Humidity 20% to 80% non-condensing
Ventilation Cabinets require free movement of air over all exposed surfaces.
MAINTENANCE
This section describes maintenance and troubleshooting procedures.
To properly maintain the equipment:
Periodically: check the continuity of the grounding unit.
Monthly: Test the operation of the power supply unit.
Every 3 years: replace the lead-acid backup batteries, if installed.
To check the backup battery operation (if installed):
1. Disable primary AC input voltage to the enclosure.
2. Verify that the DIN-mounted device installed in the enclosure continues to
operate.
3. Reapply primary AC voltage to the enclosure.
To replace the backup battery:
1. Ensure that AC power is supplied to the cabinet.
2. Disconnect battery cable leads from battery terminals; note the polarity
connections. Do not allow the leads to short or touch the case ground.
S300-BAT-2.8AH Optional backup
battery
12V, 2.8Ah battery.Two backup batteries are used
per enclosure to provide 24 VDC. Minimum 1 1/2
hours sustained operation in S300-DIN-S at full
load.
Dimensions: 5.24x3.82x1.3 in (13.3x9.7x3.3 cm)
S300-DIN-PA1 Parts accessory kit Contains a DC power harness, a lock, a tamper
switch, and two spare connectors (3-position and
4-position).
Model Number Description Specification

Hardware Installation S300-DIN-S
14 24-10239-359 Rev. C
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
3. Remove and retain nuts securing the battery bracket to the door.
4. Remove the old batteries, position the new ones within the bracket and secure
the bracket to the enclosure door with the nuts.
5. Connect the battery cable leads to the battery terminals, observing proper
polarity connections.
6. Allow the batteries to charge for 12 hours.
7. Verify proper battery operation as described on page 13.
Impaired Performance Conditions
The following conditions may cause impaired performance:
Condition Information
Unit environment not as specified. See page 13.
Unit power and grounding not as specified. See page 3, page 8, and page 12.
Cable length or type not as specified. See page 7.
Backup battery not replaced correctly. See page 13.
Field Servicing
Troubleshoot the enclosure by substituting the suspected component with a
replacement part.
Replacement Parts
All replaceable parts are available from Johnson Controls. For instructions on how
to obtain order replacement parts, consult your Customer Success Center
representative at [phone].
Table 4-1: Replacement Parts
Model No. Description
S300-DIN-S Large enclosure, DIN rails, 5A power supply. See page 1.
S300-XFMR Transformer. See page 4.
S300-DIN-S-PS Power supply, 24VDC out, 24VAC in. See page 5.
S300-DIN-BRK Battery bracket kit. See page 9.
S300-BAT-2.8AH 12V, 2.8AH battery for S300-DIN-S. See page 10.
S300-DIN-PA1 Accessory kit. See page 15.

24-10239-359 Rev. C 15
S300-DIN-S Hardware Installation
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
S300-DIN Parts Accessory Kit
This kit (S300-DIN-PA1), which must be ordered separately, contains the following
items:
A DC power harness
A lock
A tamper switch
Spare connectors: 3-position and 4-position
The DC Power Harness
Connects to the DIN-mounted device
Connects to
chassis ground
Connects to COM
of the power supply
Connects to +24
of the power supply
black
red
green
Figure 4-1: DC Power Harness
To replace the DC power harness:
1. Switch the power off.
2. Disconnect the DC power harness cables.
3. Replace the harness and reconnect the cables.
4. Switch the power on.
The Lock
To replace the lock, follow the instructions included with the hardware.
The Tamper Switch
To replace the tamper switch:
1. Disconnect the tamper switch wires from the input point of the DIN-mounted
device.
2. Remove the nut securing the switch to the bracket.
3. Replace the switch and secure it with the nut.
4. Wire the tamper switch to an input point of the DIN-mounted device.

Hardware Installation S300-DIN-S
16 24-10239-359 Rev. C
This document contains confidential and proprietary information of Johnson Controls
© 2017 Johnson Controls
The Spare Connectors
Two spare connectors are provided:
4-position terminal block, 12-24 AWG, to be used to connect the RS485 to the
DIN-mounted device.
3-position terminal block, 12-24 AWG, to be used to connect the power
supply to the DIN-mounted device.
