T22 / T25 / T26 Series
Line Voltage Wall Thermostat
(Heating, Cooling, or Heating and Cooling)
Code No. LIT-1922255
Issued February 1, 2009
Description
For line voltage control of residential,
commercial, or industrial heating or year-
round air conditioning. Heat or cold
anticipators are not required. The liquid-
charged temperature sensing element and
highly efficient diaphragm and leverage
provide close temperature control.
Features
• attractive beige colored, high-impact
plastic enclosure (T26 Series)
• close differential without the need for
anticipators
• bi-metalthermometersuppliedas standard
except where indicated
• equipped with adjustable dial stops
(T26 Series)
Specifications
Temperature range is 40 to 90°F (5 to 30°C),
except energy conservation models.
Accessories
• replacement knobs and faceplates
• for double trim plate for mounting two T22s
or T26s
Applications
Use for line voltage control of heating and cooling equipment.
Series T25
Action on Increase
of Temperature
R
B
Y
Low Stage
R
B
Y
High Stage
SeriesT26
Action on Increase
of Tem
p
erature
1
2
3
t28cd.eps t28cd.eps
T25, T26 Series Action Diagrams
Selection Chart
T22 / T25 / T26 Series Line Voltage Wall Thermostat (Heating, Cooling, or Heating and Cooling
Code
Number1Type of
Adjustment Application Selector Switch Differential Approximately °C (°F) Ship Wt. (lb)
Heating Cooling
HEATING
T22AAA-1C Knob SPST Off-Auto 1-3/4 (1) – 1.3
T22ABC-1C Auto-Off-Fan
T22ABC-3C Concealed
T22BBC-1C Knob SPST, Medium Duty 3 (1.7)
T22CBC-1C SPST, Heavy Duty
T22CBC-3C Concealed
T26A-14C
(No thermometer) Knob SPST, Energy Conservation Heating model, max. setting 75°F (24°C) None 2 (1.1) 1.0
T26A-15C
(No thermometer) SPST, Energy Conservation Heating model, max. setting 65°F (18°C)
COOLING
T22JAA-1C Knob SPST Off-Auto – 2-1/4 (1.3) 1.3
T22JCC-1C Auto-Off-Fan
T26J-7C
(No thermometer) SPST, Energy Conservation Cooling model, min. setting 75°F (24°C) None
T26J-9C
(No thermometer) SPST, Energy Conservation Cooling model, min. setting 78°F (26°C) 2 (1.1) 1.0
T26
T25
T22

The performance specifications are nominal andconform to acceptable industry standards. For applications at conditions beyond these specifications, consult the local Johnson Controls office.
Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. © 2009 Johnson Controls, Inc. www.johnsoncontrols.com
2 of 2
Line Voltage Wall Thermostat (Heating, Cooling, or Heating and Cooling) (Continued)
HEATING AND COOLING
T22SDA-1C Knob SPDT, permits system shutdown
at the thermostat Off-Auto 1-3 /4 (1) 2-1/4 (1.3) 1.3
T22SEB-1C SPDT, used when the same device
controls heating and cooling Heat-Off-Cool
T22SFB-1C 2SPDT, used to control separate
loads on heating and cooling
T22TFB-1C 2SPDT, heavy duty, used to control
separate loads on heating and cooling 3 (1.7) 3 to 4 (1.7 to 2.2)
T26S-18C 3SPDT None 1-3/4 (1) 2-1/4 (1.3) 1.0
T26T-3C 2SPDT, heavy duty 3 (1.7) 3 to 4 (1.7 to 2.2)
TWO-STAGE
T25A-1C Knob Two SPDT switches
Two-stage heating, cooling or one
stage heating and one stage cooling
None 1-3/4 (1) 2-1/4 (1.3) 1.5
3 (1.7) between stagesT25A-16C Concealed
1. For the thermostat guard, refer to G Series Thermostat and Humidistat Guards Catalog Page, LIT-1922145.
2. Can also be used where one unit provides both heating and cooling by adding a jumper between terminals 2 and 3. (See Typical Wiring Diagram and Electrical
Ratings for Line Voltage Thermostats Catalog Page, LIT-1922600.)
3. Includes a faceplate for horizontal mounting. The plate is for on-the-job installation over a vertical plate.
Can field-convert to other configurations.
The T26S-18 is a universal replacement for Honeywell T451A, -B, T651A; White Rodgers 179-1, 180-1, 181-1, 182-101, -102; Robertshaw TA500, TH71,
-72, -79, -500, TX550.
T26T-3 replaces: Honeywell T4051A, -B, T6051A; White-Rodgers 151-6, 152-9, 159-3, -5.
T22 / T25 / T26 Series Line Voltage Wall Thermostat (Heating, Cooling, or Heating and Cooling (Continued)
Code
Number1Type of
Adjustment Application Selector Switch Differential Approximately °C (°F) Ship Wt. (lb)
Heating Cooling
