Johnson 40-6551 User manual

©2015 Johnson Level & Tool 1
Electronic Self-Leveling Horizontal
Exterior Rotar Laser Kit
Model No. 40-6551
Instruction Manual
Congratu ations on your choice of this E ectronic Se f-Leve ing
Horizonta Exterior Rotary Laser. We suggest you read this instruction
manua thorough y before using the instrument. Save this instruction
manua for future use.
This is a Class a laser tool and is manufactured to comply with CFR 21,
parts 1040.10 and 1040.11 as well as international safety rule EC 285.
!

8488H-English_Manuals 11/11/14 2:36 PM Page 1

2©2015 Johnson Level & Tool
Table of Contents
1. Kit Contents
2. Features and Functions
3. Safety nstructions
4. Location/Content
of Warning Labels
5. Location of Parts/Components
6. Operating nstructions
7. Using the Product
8. Self-Check & Fine Calibration
9. Technical Specifications
10. Application Demonstrations
11. Care and Handling
12. Product Warranty
13. Warranty Registration
14. Accessories
15. Trouble Shooting
1. Kit Contents
Description for Model 40-6551 Qty.
Electronic Self-Leveling Horizontal Exterior Rotary Laser 1
NiMH Rechargeable Battery Pack 1
6.4V Battery Adapter 1
4 “C” Alkaline Battery Pack (batteries not included) 1
Detector with 9V Battery 1
nstruction Manual with Warranty Card 1
Hard-Shell Carrying Case 1
2. Features and Functions
• Large ±5° electronic auto-level range. When beyond the leveling
range, the laser line will flash, rotation of the beam will stop, and an
audible alarm will activate.
• Vibrate mode ignores slight movements as in windy conditions.
• Height of nstrument/T LT alarm function ensures product accuracy.
• Projects a laser horizontal plane.
• Dust and rain resistant.
• Detector included for more convenient operation.
8488H-English_Manuals 11/11/14 2:36 PM Page 2

©2015 Johnson Level & Tool 3
3. Safety Instructions
Please read and understand all of the following instructions, prior
to using this tool. Failure to do so, may void the warranty.
DANGER!
Class a Laser Product
Max. Power Output: ≤5mW
Wavelength: 625-645nm
THIS T L EMITS LASER RADIATI N.
D N T STARE INT BEAM.
AV ID DIRECT EYE EXP SURE.
ATTENTION IMPORTANT
• Read all instructions prior to operating this laser tool. Do not remove any labels from tool.
• Do not stare directly at the laser beam.
• Do not project the laser beam directly into the eyes of others.
• Do not set up laser tool at eye level or operate the tool near a reflective surface as
the laser beam could be projected into your eyes or into the eyes of others.
• Do not place the laser tool in a manner that may cause someone to unintentionally
look into the laser beam. Serious eye injury may result.
• Do not operate the tool in explosive environments, i.e. in the presence of gases or
flammable liquids.
• Keep the laser tool out of the reach of children and other untrained persons.
• Do not attempt to view the laser beam through optical tools such as telescopes as
serious eye injury may result.
• Always turn the laser tool off when not in use or left unattended for a period of time.
• Remove the batteries when storing the tool for an extended time (more than 3 months)
to avoid damage to the tool should the batteries deteriorate.
• Do not attempt to repair or disassemble the laser tool. f unqualified persons attempt
to repair this tool, warranty will be void.
• Use only original Johnson®parts and accessories purchased from your Johnson®
authorized dealer. Use of non-Johnson®parts and accessories will void warranty.
8488H-English_Manuals 11/11/14 2:36 PM Page 3

4©2015 Johnson Level & Tool
4. Location/Content of Warning Labels
8488H-English_Manuals 11/11/14 2:36 PM Page 4

©2015 Johnson Level & Tool 5
5. Location of Part/Components
Handle
Keypad
Laser Output
Window
Battery Cover
5/8" - 11 Screw
Thread in Bottom
Battery Pack
Locking Screw
Rotary Head
8488H-English_Manuals 11/11/14 2:36 PM Page 5

6©2015 Johnson Level & Tool
6. perating Instructions
IMP RTANT: t is the responsibility of the user to verify the
calibration of the instrument before each use.
Battery Installation
Note: Always check to be sure that the laser is off before removing
and replacing battery packs.
Alkalin Batt ry Pack Installation
1. Put 4 “C” batteries into the battery pack
according to polarity direction.
2. Attach the battery pack to the laser.
Ni-MH R charg abl Batt ry Charging
Using the 6.4V battery adapter (included), charge the
rechargeable battery pack directly to the battery pack
(Fig 1.) or while the battery pack is connected to the
laser (Fig. 2). When the charge indicator LED turns
from red to green (after approximately five hours) on
the 6.4V battery adapter (Fig. 3), the Ni-MH recharge-
able battery pack has been fully charged.
Note:
(1) For the first two charges of new
rechargeable batteries, it is recommended
to charge for 12 plus hours.
(2) The unit can still work during charging
with the adapter.
(3) Do not charge alkaline batteries to avoid explosion.
Fig. 1
Fig. 2
Fig. 3
Charging
ndication LED
8488H-English_Manuals 11/11/14 2:36 PM Page 6

©2015 Johnson Level & Tool 7
(4) Used (discharged) batteries are hazardous waste and should be
disposed of properly.
Before Using the Laser
When you charge the new battery or one which has not been used for
long periods of time, it may not reach full charge until after you have
discharged it fully in use and recharge it several times.
Instrument Usage
1. Put in Ni-MH rechargeable battery pack, or 4 “C” alkaline battery pack.
2. Place the laser on a tripod, connect it to the tripod using the 5/8"
screw thread at the bottom of the laser.
Note: f the laser is inclined beyond the self-leveling
range, the laser will deliver an audible alarm. You will
need to re-position the laser.
3. Press power button to turn power on.
4. Press the Tilt button to lock in the height of the laser.
5. After finishing operation or before moving the laser, turn the power off.
8488H-English_Manuals 11/11/14 2:36 PM Page 7

8©2015 Johnson Level & Tool
7. Using the Product
perating Panel
Power LED
LED On = power on
LED Off = power off
LED Flashing = low battery
Tilt Mode LED
LED Flashing Slowly = laser is entering Tilt mode
LED On = laser Tilt mode is on
LED Flashing Quickly = laser has been moved and height of laser
may have been changed
LED Off = Tilt mode is turned off
Vibrate/V-W-S Mode LED
LED On = laser is in vibrate/V-W-S mode
LED Off = laser is not in vibrate/V-W-S mode
Power LED
Tilt Mode LED
Tilt Mode
Button
Vibrate/V-W-S Mode LED
Vibrate/V-W-S
Mode Button
Power On/Off Button
8488H-English_Manuals 11/11/14 2:36 PM Page 8

©2015 Johnson Level & Tool 9
Power n/ ff
1. Press the power on/off button to power the laser on. The
power LED will light up and the laser will electronically self-
level itself, with rotation occurring once the unit is level at 600
rpms. The laser will automatically enter into the Tilt mode and the
Tilt LED will flash slowly for 30 seconds then become solid.
2. Press the power on/off button again to power off.
Low Battery Indication
f the power LED is flashing, the battery is low. To ensure normal
operation, replace alkaline batteries or charge the rechargeable
Ni-MH battery pack.
Alarm If Beyond Range
f the laser is inclined beyond the self-leveling range of ±5°, it will
deliver an audible alarm, and will not rotate. You will need to
re-position the laser until it is within the leveling range.
Tilt Mode Button
After turning on the laser, the laser will self-level and begin to
rotate. The Tilt mode LED will blink for 30 seconds after the
laser begins to rotate. During these 30 seconds if the laser is moved,
the laser will stop rotating, re-level and begin to rotate again. After 30
seconds, the Tilt mode LED will stop blinking and will become solid. f
the laser is moved when the Tilt mode LED is solid, the laser will stop
rotating. The laser beam will blink on and off and the Tilt mode LED
will blink quickly alerting the user the height of the laser may have
been changed. Pressing the tilt mode button on the laser keypad will
8488H-English_Manuals 11/11/14 2:36 PM Page 9

10 ©2015 Johnson Level & Tool
turn off the tilt mode and will allow the laser to re-level and start
rotating again. Press the tilt mode button again to enter tilt mode.
Vibrate V-W-S Button
Press the Vibrate V-W-S button and the Vibrate V-W-S LED
will turn on, which means the laser is in vibrate mode.
Vibrate mode allows continuous operation during high winds,
vibrations and shocks. Slight movements are ignored and the laser
only enters Tilt mode if significant movement occurs. Press the
Vibrate V-W-S button again to turn vibrate off.
8488H-English_Manuals 11/11/14 2:36 PM Page 10

©2015 Johnson Level & Tool 11
1. T chnical Sp cifications
Detecting accuracy: Fine: ±0.039" (±1mm)
Coarse 1: ±0.098" (±2.5mm)
Coarse 2: ±0.394" (±10mm)
Automatic Shut-off: 6 minutes ±1 minute
Power Supply: 9V battery, 30 hrs continuous use
(with LCD illumination off)
Sound indicator: slow short beep, rapid short beep
and continuous sound
LED display: down arrow, up arrow, horizontal
on grade bar
Dimensions: 6.30" x 3.35" x 1.10" (160 x 85 x 28mm)
Weight: 1 lb. (0.45kg)
Others: Rain and dust resistant
Detector Usage
Two-Sided Laser Detector with Clamp Model No. 40-6715
The 40-6715 aser detector is an indispensab e accessory when
using rotary aser eve s. The main function of the detector is to
detect the position of the aser signa s that are transmitted by rotary
asers. This detection quick y and precise y provides the user with the
horizonta and vertica references.
This product features high sensitivity, a doub e-faced disp ay, ow
power consumption, good re iabi ity and easy manipu ation. It can be
used with most types of rotating asers.
8488H-English_Manuals 11/11/14 2:36 PM Page 11

12 ©2015 Johnson Level & Tool
2. Compon nts
(a) Exterior nstruction
1) Horizontal vial
2) Front display window
3) Front on grade mark
4) Vertical vial
5) LED key
6) Power key
7) Beeper
8) Reception window
9) Fine/Coarse accuracy key
10) Beeper key
11) Back display window
12) Back on grade mark
13) Bracket screw thread
14) Battery cover screw
15) Battery cover
8488H-English_Manuals 11/11/14 2:36 PM Page 12

©2015 Johnson Level & Tool 13
(b) Display
1. Power on symbol
2. Low battery indicator
3. Fine/Coarse symbol
4. Beeper symbol
5. Position indication arrows
Power Key: Turn on/off the power
Fine/Coarse Accuracy Key: Switch detecting accuracy
LED Key: Turn on/off the LCD’s light
Volume Key: Cycles between high, low and off
3. Op ration Guid
(a) Battery nstallation
• Open the battery cover door by turning the
battery cover screw counter-clockwise.
Put the battery into the battery case noting the polarity shown in
the battery compartment.
• Put the battery cover door back, and tighten the screw.
Note: 1) Remove the battery when the unit is being stored for a
long time.
2) When the low battery indicator is displayed, change the
battery soon.
8488H-English_Manuals 11/11/14 2:36 PM Page 13

14 ©2015 Johnson Level & Tool
4. Op rating Instructions
Pow r On
Press the power key to turn the unit on. The LCD
display will illuminate all the indicator segments
for 0.5 second (Fig.2). When the indicator
segments are no longer illuminated, the detector
is ready for use.
Note: The LCD display will still have the power,
detection and sound indicators illuminated (Fig. 3).
Fin /Coars accuracy k y
Power on and press the fine/coarse
accuracy key, the unit will cycle
between three accuracy options:
fine, coarse 1, coarse 2. The
accuracy symbol displayed on the LCD will change.
Figure 2 Figure 3
Volum K y
Power on and press the volume
key, the unit will cycle between a
high sound, low sound and mute.
The sound symbol displayed on the LCD will change accordingly.
Note: There will be two beeps when turning the unit on and off.
There will be one beep when changing functions.
8488H-English_Manuals 11/11/14 2:36 PM Page 14

©2015 Johnson Level & Tool 15
D t cting Las r L v l Signals
While detecting laser signals, the LCD will display as follows: (take
the set-up state of high sound and fine detection as an example)
When the laser signal is near the on-grade mark, the displayed up
and down arrows will decrease as the distance to the on-grade
mark decreases.
Laser signal
The laser signal is down
Sound: rapid short beeps
Laser signal
The laser signal is up
Sound: slow short beeps
Laser signal
Horizontal bar indicated on-grade
Sound: continuous sound
No laser signal is detected
Sound: no sound
Laser signal Laser signal Laser signal Laser signal
1. When detecting a horizontal laser signal, it is
important to have the horizontal bubble vial
centered, as the deflection of the receiver will
influence its receiving accuracy.
8488H-English_Manuals 11/11/14 2:36 PM Page 15

16 ©2015 Johnson Level & Tool
2. When detecting a vertical laser signal, it is important
to have the vertical bubble vial centered, as the
deflection of the receive will influence its receiving
accuracy.
3. Keep the reception window facing the laser while detecting.
4. Hold the unit stable while detecting.
LED Function
Power on and press the LED key, the LCD will now be backlit.
Automatic Shut-off Function
When the unit does not receive a laser signal for 6 minutes, the
unit will power off automatically.
Low Batt ry Display Function
When the battery sign blinks on the LCD, the battery is
low and needs to be replaced. f the battery is very low,
the unit will power off automatically. Replace the battery.
8488H-English_Manuals 11/11/14 2:36 PM Page 16

©2015 Johnson Level & Tool 17
Rod Clamp
Connecting to the rod clamp.
Connecting to the grade rod.
5. D t ctor Maint nanc
• Keep the unit, particularly the reception window, clean. f it does get dirty,
use a cloth to wipe it clean.
8488H-English_Manuals 11/11/14 2:36 PM Page 17

8. Self-Check and Fine Calibration
IMP RTANT: t is the responsibility of the user to verify the
calibration of the instrument before each use.
The instrument must be self-checked before operation. f the
accuracy is found beyond tolerance, user can make adjustment
according to directions as follows.
X-Direction Accuracy Self-Check
1. For clarity, we define the direction of handle as X-direction,
and the other direction as Y-direction
2. Place the unit on a platform or tripod that is 50’ away from a
wall indoors, with the handle facing the wall head-on. Turn the
unit on.
3. Using the detector mark on the wall where the beam hits the wall
and mark the beam as point A.
4. Turn the instrument by 180 degrees, mark the beam as point B.
5. Measure the vertical distance between point A and point B. f A &
B are more than 1/32" apart at 50’, the unit is out of calibration.
6. As shown, turn the instrument by 90° and place it on the
platform, with the operating panel facing you. Perform
18 ©2015 Johnson Level & Tool
50’
8488H-English_Manuals 11/11/14 2:36 PM Page 18

©2015 Johnson Level & Tool 19
Y-direction self-check with the same method as X-direction
self-check, and mark point C and point D by turns.
7. f point C and point D are within 1/32" at 50’, the accuracy is
within tolerance. Otherwise reference section 12 of this
document.
Fine Calibration via Remote Control (sold separately)
1. Access calibration mode by simultaneously pressing the
“Power” and “Tilt” buttons on the keypad.
2. Press on/off button and Tilt mode button at the same time,
then release the on/off button and continue pressing the Tilt
mode button. After the Tilt LED and V-W-S LED start to flash,
release the Tilt mode button and the instrument will enter into
X-calibration status, the Tilt LED flashes and V-W-S LED light
is on and the instrument keeps rotating.
3. Release the “Tilt” button. Note that the rotating head of the
laser is not rotating and the laser is flashing. The unit is now in
calibration mode and all other operations will be performed
with the unit’s remote control (sold separately).
4. Use the remote control to access the calibration.
Pressing the “X/Y” button changes calibration control between
the X-axis and Y-axis. The X-axis is selected when the Tilt
button is flashing while all other buttons are solid. The
Y-axis is selected when the V-W-S light is solid. Once the
desired axis has been selected, the “UP Arrow” and “Down
Aarow” buttons are used to adjust the position of the
horizontal laser beam plane.
8488H-English_Manuals 11/11/14 2:36 PM Page 19

20 ©2015 Johnson Level & Tool
X-axis Calibration
1. Place the unit into calibration mode as discussed above.
2. Position the unit so that the X-axis is directing to the target.
3. Press “X/Y” key on the remote control to toggle calibration
control to the X-axis.
4. Press the “UP Arrow” and “Down Arrow” buttons respectively
to adjust the laser height to coincide with the zero position of
the target.
5. Press the “Enter” button on the remote control to accept the
calibration value, noting that the status indicator goes “off”.
6. After calibration is completed, make sure to power off the unit
and then power on again to activate the calibration.
Y-axis Calibration
1. Place the unit into calibration mode as discussed above.
2. Position the unit so that the Y-axis is directing to the two targets.
3. Press “X/Y” button on the remote control to toggle calibration
control to the Y-axis.
4. Press the “UP Arrow” and “Down Arrow” buttons respectively
to adjust the laser height to coincide with the zero position of
the target.
5. Press the “Enter” button on the remote control to accept the
calibration value, noting that the status indicator goes “off”.
6. After calibration is completed, make sure to power off the unit
and then power on again to activate the calibration.
8488H-English_Manuals 11/11/14 2:36 PM Page 20
