Jonsson JO-5100 User manual

JO-5100
Owner’s Manual
www. jönssonaudio.com

Jönsson Audio
THE ART OF OUND REPRODUCTION
In the long search for the perfect hi-fi, the Kevlar Acoustics’ philosophy is simple: to
maintain the purity and integrity of the original signal at all times. This, we believe, is
the only route to achieving true hi-fi sound uality.
At Jönsson Audio we believe music should be heard as originally intended by,
composers, and performers we admire. So when we design state-of-the-art Theatre
System, we begin by shortening signal pathways to minimize the possibility of
distortion. Even our signal switches are built to audiophile specification with high
uality contacts and electronic relay switched input circuitry, all in a sealed and
dust-free environment. Power supplies are highly specified, using only top uality
components. Left and right signal paths are symmetrical to ensure perfect imaging
across the stereo field. Thus, Jönsson Audio systems deliver a broad and accurate
soundstage, with each instrument perfectly focused in its position in the stereo picture.
We believe musical expression is at the heart of our search for perfect hi-fi. That’s
why we design uality components to deliver the best possible rendering of musical
dynamics. A Linear Drive Power Supply works in conjunction with current feedback
amplification to act as a limitless reserve of power for our whole range of products.
With this depth of power, even the most extreme dynamic moments are delivered with
perfect expression.
Jönsson Audio Systems are built to respond to the signal to the steepest signal attacks
with incredible speed and accuracy, so none of the subtleties in the ebb and flow of
the music are lost. The short symmetrical signal paths and discrete surface-mount
components of Jönsson Audio’ own Super Dynamic Amplifier Modules (SDAM)
make them superior to traditional integrated circuit Op-Amps-which have a poorer
slew rate and are too-slow-acting to deliver the audio signal’s transient character
faithfully.
Jönsson Audio Systems encapsulate perfectly our determination to achieve the highest
possible uality audio performance.
1

Fitting
-----------------------------------------------------------------------------------------
On The Wall
The front, centre and surround speakers include mount holes for wall
mounting. You can hang the front and surround speakers on the wall
vertically, and the centre speaker horizontally. For vertical mount, you
use only one screw and hang the speaker from its upper mount hole only.
For horizontal mount, you need to set two screws into the wall at the
appropriate distance so that you can hang the speaker from both mount
holes.
1. To drill a 6 to 7 mm diameter and 30 to 40 mm depth hole in the wall at
the desired location and fill the plastic stopper into the hole.
2. Screw a single screw into the plastic stopper. Screw it only part way in,
so that the screw projects 15 to 18 mm outward from the wall surface.
3.Hang the speaker by fitting the top mount hole (at the upper rear of the
speaker) over the extending part or the screw. Confirm that the speaker is
held firmly and securely in place.
2

Connection 1(If you use 5 channels output amplifier, please refer this connection)
Be sure to turn off your amplifier before connecting or disconnecting speakers
3

Connection 2(If you use 5.1 channels output amplifier, please refer this connection)
Be sure to turn off your amplifier before connecting or disconnecting speakers.
4

pecifications
-----------------------------------------------------------------------------------------
Front speakers, urround speakers
Nominal impedance.........................................8Ω
Maximum input power..................................280w
Sensitivity................................................80 ±3dB
Fre uency Range.....................200 – 16 KHz
Center speaker
Nominal impedance..........................................8Ω
Maximum input power...................................280w
Sensitivity.................................................85 ±3dB
Fre uency Range.....................200 – 16 KHz
ubwoofer
Nominal impedance.........................................8Ω
Maximum input power...................................600w
Sensitivity.................................................87 ±3dB
Fre uency Range.....................35– 220 Hz
This is a basic User’s Manual, which can be used for any model of the Jönsson Audio 5.1
passive systems. pecifications may differ from model to model. Jönsson Audio reserves the
right to cancel, change, modify or upgrade any of its product or specification without any
prior notice. For any further clarification please check with your distributor for the
specification, accessories and the service you are eligible to receive on the purchase of this
product.
5

JO-5100
Owner’s Manual
