Josoo Electric Appliance ZS-A88 User manual

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
1
INSTRUCTION MANUAL
ZS-A88

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
2
● Wine Cooler Package Contents
Instruction Manual
6 Standard Racks
●Important Safety Instructions
WARNING: To reduce the risk of fire, electric shock or personal injury, unplug or
disconnect the appliance from the power supply before servicing.
Read all instructions before using the wine cooler.
DANGER: Risk of child becoming trapped in new wine cooler, old wine
cooler/refrigeration unit, or large boxes. Junked or abandoned appliances, boxes and
other containers are still dangerous, even if they will just in the garage for a few days.
Before you throw away your old wine cooler:1.take off the door. 2.Leave the shelves in
place so that children cannot climb inside.
Never allow children to operate, play with, crawl inside the appliance.
Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or
explosion.
Do not store in the vicinity of any other appliance. Do not store near gasoline or any other
flammable vapors. The fumes can create a fire hazard or explosion.
Before Using Your Wine Cooler
Remove the exterior and interior packaging.
Before connecting the wine cooler to power source, let it stand upright for approximately
2 hours. This will reduce the possibility of a malfunction in the cooling system from
handling during transportation.
Clean the interior surface with lukewarm water using a soft cloth.
Installation the free standing wine cooler, make sure that there is at least 50 mm
clearance on each side and at least 100 mm clearance on the back, because this is the
main exit of hot air, to leave sufficient ventilation system

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
3
Main Structure Of Product
1Cabinet
2Stainless steel glass door
3Stainless steel handle
4Exhaust grill
5Leveling leg
6Fan
7Control panel
8Shelves
9Lock
Operation For Temperature
Temperature Range: 5-20℃,
41-68℉

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
4
Installation
Handle Installation
1. Door seal
2. Screw
3. Door body
4. Handle
First remove the door seal from the groove of the door body profile, insert the screw
into the hole on the door body, align the screw hole on the handle, tighten the
handle screw in the direction shown by the arrow, and then reinstall the door seal
into the door In the groove of the body profile.
How to Built in

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
5
Temperature Setting
The setting should be operate in the control panel.
（1）Functions of each keys in the control panel.
1.Up
Used to raise (warm)the set temperature by 1℃or 1℉. When the screen is flashing, press it
once, the temperature setting is up by 1℃or 1℉, the highest setting temperature is
20℃(68℉). Stop to press any button for 5 seconds, then the number stop flashing to show
the actual temperature of the cabinet.
2.Temperature Display
The LED display will show the setting temperature when “flash”; Display will show the
temperature for the actual temperature of the cabinet when normal.
3.Down
Used to lower (cool) the set temperature by 1℃or 1℉. When the screen is flashing, press it
once, the temperature setting is down by 1℃or 1℉, the lowest setting temperature is 5℃
（41℉）. Stop to press any button for 5 seconds, then the number stop flashing to show the
actual temperature of the cabinet.
4. Temperature unlock key
Tap this key to unlock the temperature. After unlocking, you can use the temperature
up/down keys to adjust the temperature. After the temperature adjustment is completed, the
temperature will be automatically locked after flashing.
5.℃/℉Switch key/light switch key
Touch this button to control the LED light switch, press for 5 seconds to switch ℃/℉.
6.Power

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
6
To control the appliance turn on/off. To turn off the appliance, touch the button and
hold for at least 5 seconds. Press again, turn on the appliance. The LED readout will
show the original temperature set previously when restart the appliance or reconnect after
power cuts .
(2)There is automatic storage memory when power off in this wine cooler, that means the
setting temperature is memorized automatically even in power off, so the setting temperature
is the same as last setting when the wine cooler is running again.
(3)Defrosting
The unit defrosts automatically.
The evaporator behind the rear wall of the unit defrosts automatically. The condensate
collects in the drainage channel behind the rear wall of the unit, and flows through the
drainage hole into the drip tray by the compressor where it evaporates. When the wine cooler
run for some time, the wine cooler will enter to defrosting, the compressor stop running and
the fan will keep running. The temperature will up to about 5℃when defrosting, then keep on
running normally; It takes more time for the temperature to come up to 5℃when the setting
temperature is low(for example the setting temperature is -2℃), and there are full of wines in
the cabinet, and this is not a breakdown.
The switch of interior light is under the control panel to control the light on
or off.
Points Of Intentions
1, The vent grill outside the cabinet is the heat dissipation way of cooling system in wine
cooler, please prevent anything from covering or blocking, or it will make the wine cooler
overheating and cause damage to product.
2, Please prevent blocking cooling fan, or it will make the temperature too high or uneven in
the cabinet.
3, Please close the door tightly, it will cause the refrigerating inefficiency, overflow in the
cabinet, or unnormal temperature once the door is not closed tightly for a long time.
4, Please shut off the power, and open the door to let the cabinet dry enough if you don’t use
the wine cooler for a long time.
5. This product is not suitable for areas with an altitude of 2000 meters.
●Product Parameters
1, Voltage: 115V
2, Rated power: 90W
3, Climate type: ST/SN/N
4, Temperature range in cabinet: 5-20℃ （41-68℉）

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
7
●Layout And Storage
Your cabinet was designed to store a maximum number of bottles securely. We recommend
that you observe the below tips to optimize loading.
Remove tape from shelves once unit is stable and ready for storage.
Disperse the bottles evenly to avoid concentrating weight in one place. Bottles must not
touch either the back of the cabinet.
Make sure that the bottles are not all grouped together either at the top or bottom of the
cabinet.
Only pull out one shelf at a time. Never attempt to pull more than one.
Maximum weight capacity per shelf is 55lbs
You can crease your wine cooler storage capacity by removing shelves and stacking
bottles on top of one another. Do not stack more than 3 rows of bottles per shelf.
●Care Maintenance
Cleaning your wine cooler
Turn off the power, unplug the appliance, and remove all items including shelves and
rack.
Wash the inside surfaces with a warm water and baking soda solution. The solution
should be about 2 tablespoons of baking soda to a pint of water.
Wash the shelves with a mild detergent solution.
Wring excess water out of the sponge or cloth when cleaning any area of the controls.
Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe
dry with a clean soft cloth.
Power Failure
Most power failures are corrected within a few hours should not affect the temperature of
your appliance if you minimize the number of times the door is opened. If the power is
going to be off for a longer period of time, you need to take to take other measures to
protect your contents.
If the unit is unplugged, loses power,or is turned off you must wait 3to 5 minutes before
restarting. Attempting to restart the wine cooler before this time has elapsed may prevent
the wine cooler from starting..
Vacation Time
Short holidays: You may leave the Wine Cooler powered on and unattended for
absences of less than three weeks.
Long absences: If the appliance will not be used for several months, remove all items,
turn off the appliance and unplug. Clean and dry the interior thoroughly. To prevent odour
and mold growth, leave the door open slightly : blocking it open if necessary.

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
8
Moving Your Wine Cooler
Remove all items.
Securely tape down all loose items ( shelves) inside your appliance.
Turn the adjustable leg up to the base to avoid damage.
Tape the door shut.
Be sure the appliance stays secure in the upright position during transportation. Also
protect outside of appliance with a blanket, or similar item.
Energy Saving Tips
The Wine Cooler should be located in the coolest area of the room, away from heat
producing appliances, and out of the direct sunlight.
Ensure that the unit is adequately ventilated. Never cover air vents.
Only open the door for as long as necessary.
●Troubleshooting Guide
Problems with Your Wine Cooler
Many common issues with your wine cooler can be solved very easily. Try the
troubleshooting tips below should you experience any problems.
PROBLEM POSSIBLE CAUSE
Wine Cooler does not operate. Not plugged in.
The appliance is turned off.
The circuit breaker tripped or a blown fuse.
Wine Cooler is not cold enough. Check the temperature control setting.
External environment may require a higher setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly
Turns on and off frequently The room temperature is hotter than normal.
A large amount of contents has been added to the Wine
Cooler.
The door is open too often
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work. Not plugged in.
The circuit breaker tripped or a blown fuse.
The light switch is “OFF”.
Vibrations Check to assure that the Wine Cooler is level.
The door will not close properly. The Wine Cooler is not level.
The door was reversed and not properly installed.
The gasket is dirty.

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
9
The shelves are out of position.
The Wine Cooler seems to make
too much noise
The rattling noise may come from the flow of the refrigerant,
which is normal. As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in your Wine
Cooler.
Contraction and expansion of the inside walls may cause
popping and crackling noises.
The Wine Cooler is not level.
Sensor Trouble shooting
Fault situation Reason Solution
Fault code E1
Upper room/lower room
temperature sensing head short
circuit display
Please contact customer service
before returning to our service
center for inspection/repair.
Fault code E0
Upper room/lower room
temperature sensing head open
circuit display
Please contact customer service
before returning to our service
center for inspection/repair
Fault code E5 Communication failure display
Please contact customer service
before returning to our service
center for inspection/repair
Wine Cooler surface condensation
Condensation is a natural phenomenon, wine cooler in the summer high temperature and
high humidity environment work, box shell and glass door body surface because of the low
temperature, the moisture in the air will condense in the box shell and glass door surface,
touch a wet feeling. Condensation phenomenon mainly occurs in the door seal, door body
surface and other parts. When the relative temperature of the air exceeds 80%, the glass
door surface of the wine cooler will appear bead condensation, which is a normal
phenomenon, you can use a soft cloth to wipe off the condensation, when the relative
reduction in ambient temperature condensation phenomenon will disappear naturally, will not
affect the performance of the wine cooler, in addition to reduce the phenomenon of
condensation, please pay attention to the following points when you use:
1. wine cooler in the summer rainy season, often use soft cloth to wipe the glass door surface
and other condensation department, can reduce the condensation phenomenon.
2. the wine cooler will be placed to the location of better ventilation, which can also reduce
the phenomenon of condensation.

Zhongshan Josoo Electric Appliance Co., Ltd.
No.9, Qiye North Road, Maxin Industrial Zone, Huangpu Town , Zhongshan, GD, CN
Website: www.josoocooler.com Email: [e-mail]
10
●Warranty
This product has been manufactured by Zhongshan Josoo Electric Appliance Co.,Ltd.
The warranty does not apply to damage resulting from abuse, accident, natural disaster, loss
of electrical power to the product for any reason, alteration, outdoor use, improper installation,
and improper operation, repair or service of the product by anyone other than an authorized
by us, service agency or representative.
