jotron Tron SART20 User manual

Tron SART20
Radar Transponder
User Manual

This page is intentionally left blank

Doc. No.: 84145 Rev. L jotron.com Page 3 of 40
Abbreviatons
EIRP
Effective Isotropic Radiated Power
GHz
Gigahertz
GMDSS
Global Maritime Distress and Safety System
IEC
International Electrotechnical Commission
IMO
International Maritime Organization
ITU
International Telecommunication Union
LED
Light Emitting Diode
MED
EU Marine Equipment Directive
NM
Nautical mile
SART
Search and Rescue Transponder
SOLAS
Safety of Life at Sea (An international maritime safety treaty)
VHF
Very High Frequency

Doc. No.: 84145 Rev. L jotron.com Page 4 of 40
Table of Contents
1List of Figures............................................................................... 6
2List of Tables................................................................................ 7
3General ........................................................................................ 8
4Standards..................................................................................... 9
5Product description ................................................................... 11
6Functional description ............................................................... 13
6.1 Transmitter module ..........................................................13
6.2 Battery module .................................................................14
6.3 Bottom lid..........................................................................15
7Installation ................................................................................. 16
7.1 Brackets.............................................................................16
7.1.1 Mounting the wall bracket ..................................16
7.1.2 Mounting a lifeboat bracket ................................18
7.2 Non bracket mounting options.........................................21
7.2.1 Mounting the lanyard ..........................................22
7.2.2 Mounting the Liferaft mounting strap ................23
7.2.3 Mounting the telescopic pole..............................23
7.3 Replacing the battery module ..........................................25
7.3.1 Disassembly..........................................................25
7.3.2 Assembly ..............................................................26
8Operation instructions............................................................... 28
8.1 Activation ..........................................................................28
8.2 Deactivation ......................................................................29
9Maintenance.............................................................................. 29
9.1 Testing...............................................................................30
10 Test and maintenance records .................................................. 33
11 Battery safety information ........................................................ 34
11.1 Handling and storage........................................................34
11.1.1 Transportation .....................................................34
12 Technical specifications............................................................. 35
12.1 Product specification ........................................................35
12.2 Radar transponder............................................................35

Doc. No.: 84145 Rev. L jotron.com Page 5 of 40
12.3 Brackets.............................................................................36
12.3.1 Wall bracket .........................................................36
12.3.2 Lifeboat bracket ...................................................36
13 Optional accessories.................................................................. 36
14 Spare parts................................................................................. 36
14.1 Counterfeit spare parts.....................................................36
15 Recycling and disposal............................................................... 36
16 Warranty.................................................................................... 37
17 Service ....................................................................................... 37
17.1 Service agents ...................................................................37
18 Document revision log............................................................... 38

Doc. No.: 84145 Rev. L jotron.com Page 6 of 40
1List of Figures
Figure 1 Tron SART20....................................................................................12
Figure 2 Illustration: Tron SART20 disassembled .........................................13
Figure 3 Illustration: Transmitter module ....................................................13
Figure 4 Image: Tron SART20 battery label ..................................................14
Figure 5 Illustration: Battery label on housing .............................................14
Figure 6 Illustration: Battery module (no cable or connector) ....................15
Figure 7 Illustration: Bottom lid....................................................................15
Figure 8 Illustration: Wall bracket dimensions.............................................16
Figure 9 Illustration: Tron SART20 mounted in wall bracket .......................17
Figure 10 Illustration: Placement of Tron SART20 in a wall mount .............17
Figure 11 Illustration: Lifeboat bracket disassembled .................................18
Figure 12 Illustration: Lifeboat bracket dimensions.....................................19
Figure 13 Illustration: Mounting - interior/exterior wall..............................20
Figure 14 Illustration: Mounting on a pipe...................................................20
Figure 15 Illustration: Mounted ready on a pipe .........................................21
Figure 16 Illustration: Placing the Tron SART20 into the lifeboat bracket...21
Figure 17 Illustration: using the lanyard on a lifeboat .................................23
Figure 18 Image: Tron SART20 with the Liferaft mounting strap attached .23
Figure 19 Illustration: Tron SART20 with telescopic pole attached .............24
Figure 20 Illustration: using the telescopic pole on a lifeboat .....................25
Figure 21 Image: Tron SART20 operating instructions label........................28
Figure 22 Image: Tron SART20 - Test instruction label ................................32

Doc. No.: 84145 Rev. L jotron.com Page 7 of 40
2List of Tables
Table 1 List of components - lifeboat bracket..............................................19
Table 2 Maintenance requirements .............................................................29

Doc. No.: 84145 Rev. L jotron.com Page 8 of 40
3General
Jotron manufactures safety products designed for search and rescue of
human lives and property. For this product to be effective according to the
design parameters, it is imperative that it is handled, maintained, serviced
and stowed in accordance with this manual.
All information contained within this manual has been verified and is to
Jotron’s knowledge correct. Jotron reserves the right to make changes to
any product(s) or module(s) described herein to improve design, function
or reliability without further notice.
Jotron is not liable and cannot be held responsible for
any injury or damages caused directly or indirectly by an
error or omission of information, incorrect or misuse,
breach of procedures or failure of any specific
component or part of this product.
Jotron documentation can be downloaded from jotron.com.

Doc. No.: 84145 Rev. L jotron.com Page 9 of 40
4Standards
Jotron declares that this this product is compliant in accordance with IMO,
SOLAS and GMDSS regulations.
A copy of the declaration of conformity can be downloaded from
jotron.com.
The Tron SART20 has been verified, tested and meets the following product
standards:
Commission Directive
2009/26/EC
Testing standards for international
instruments, lifesaving marine
equipment.
COMSAR/Circ. 32 (Aug. 2004)
Harmonization of GMDSS requirements
for radio installations on board SOLAS
ships.
IEC 61097-1:1992
(withdrawn)
Global maritime distress and safety
system (GMDSS) - Part 1: Radar
transponder - Marine search and rescue
(SART) - Operational and performance
requirements, methods of testing and
required test results.
IEC 61097-1:2007
Global maritime distress and safety
system (GMDSS) - Part 1: Radar
transponder - Marine search and rescue
(SART) - Operational and performance
requirements, methods of testing and
required test results.
IEC 60945-4:2002
Maritime navigation and
radiocommunication equipment and
systems - General requirements -
Methods of testing and required test
results.
IMO Resolution
MSC.97 (73) 14.7.1.3
International code of safety for high-
speed craft (2000) (Instructions for the
guidance of surveyors).

Doc. No.: 84145 Rev. L jotron.com Page 10 of 40
IMO Resolution
MSC.247 (83)
Performance standards for survival craft
radar transponders for use in search and
rescue operations.
IMO Resolution
MSC.256 (84)
International convention for the safety
of life at sea. Includes: construction
(structure and electronics), construction
(fire protections, detections, and
extinction), Life-saving appliances and
arrangements and
radiocommunications.
IMO Resolution - A.530 (13)
Use of radar transponders for search
and rescue purposes.
IMO Resolution - A.802 (19)
Performance Standards for Survival Craft
Radar Transponders for Use in Search
and Rescue Operations.
IMO Resolution - A.694 (17)
General requirements for shipborne
radio equipment forming part of the
global maritime distress and safety
system (GMDSS) and for electronic
navigation aids.
ITU-R M.628-3 (11/93)
Technical characteristics for search and
rescue radar transponders.
SOLAS (74 amended)
Chapter IV/7.1.3
Radiocommunications.
SOLAS (74 amended)
Chapter III Regulation 6.2.2
Communications - Search and rescue
locating devices
SOLAS (74 amended)
Chapter III Regulation 26.
Additional requirements
This regulation applies to ro-ro
passenger ships.
SOLAS (74 amended)
Chapter IV, Regulation 7.1.3
Required radio communication
equipment on mobile offshore units.

Doc. No.: 84145 Rev. L jotron.com Page 11 of 40
5Product description
The Tron SART20 is a 9 GHz radar transponder in a sealed waterproof and
buoyant enclosure. It is water, oil and sunlight resistant. The Tron SART20 is
designed for easy operation and can withstand a drop of 20 meters into
water.
A radar transponder is a location device. The purpose of the Tron SART20 is
to assist a seafarer in distress during a search and rescue operation.
When the Tron SART20 is interrogated by a radar signal, it will immediately
start to transmit several sweeps covering the complete maritime 3cm radar
band. The sweeps are used to navigate directly towards the Tron SART20
which is located on a lifeboat/liferaft.
A radar transponder should respond when interrogated by a shipborne X-
band radar with a scanner height of 15m within 8nm. The Tron SART20 will
also respond when interrogated by a compatible X-band radar fitted to an
aircraft operating at a height og 3000 feet at a distance of at least 30nm.
Tron SART20 includes the following components:
•Tron SART20 unit
•Mounting rope for liftboat/liferaft
•Wall bracket

Doc. No.: 84145 Rev. L jotron.com Page 12 of 40
Figure 1 Tron SART20

Doc. No.: 84145 Rev. L jotron.com Page 13 of 40
6Functional description
Tron SART20 consists of a housing sealed at the lower end with a bottom
lid. It may be split into the following main parts:
•Transmitter module
•Battery module
•Bottom lid
•LED indicator
Figure 2 Illustration: Tron SART20 disassembled
6.1 Transmitter module
Tron SART20 transmitter module is inserted into the Tron SART20 housing.
It consists of the transceiver board and antenna. It can be divided into the
following sections:
•Transceiver board in metal box
•Antenna
Figure 3 Illustration: Transmitter module

Doc. No.: 84145 Rev. L jotron.com Page 14 of 40
6.2 Battery module
The battery module consists of two C-size lithium batteries, a battery house
and connector and cable. A battery expiry label on the Tron SART20
housing displays the expiry date. A new battery comes complete with cable
and connector.
The battery module is inserted into the Tron SART20 housing. The battery
label on the housing displays the battery expiry date.
Figure 4 Image: Tron SART20 battery label
Figure 5 Illustration: Battery label on housing
The battery module is to be replaced every 5 years.

Doc. No.: 84145 Rev. L jotron.com Page 15 of 40
Only original Jotron batteries can be used with this
product.
Figure 6 Illustration: Battery module (no cable or connector)
6.3 Bottom lid
The bottom lid includes four items:
1. Lanyard
2. Screen ring
3. Light tower
4. O-ring
Figure 7 Illustration: Bottom lid

Doc. No.: 84145 Rev. L jotron.com Page 16 of 40
7Installation
Tron SART20 can be mounted several ways near the emergency exit of the
vessel. Normally, in the wheelhouse at the starboard or port exit (or both
depending on the requirements) and inside a lifeboat/liferaft.
7.1 Brackets
There are two different mounting brackets available.
•Wall bracket
•Lifeboat bracket (with or without a pipe clamp)
7.1.1 Mounting the wall bracket
A wall bracket is delivered with the Tron SART20 and should be used for
storage of the unit.
The bracket should be mounted in a vertical position
and placed where the Tron SART20 is easily available in
the case of an emergency.
Figure 8 Illustration: Wall bracket dimensions

Doc. No.: 84145 Rev. L jotron.com Page 17 of 40
Figure 9 Illustration: Tron SART20 mounted in wall bracket
Figure 10 Illustration: Placement of Tron SART20 in a wall mount

Doc. No.: 84145 Rev. L jotron.com Page 18 of 40
7.1.2 Mounting a lifeboat bracket
The lifeboat bracket should be mounted vertically and as high as possible
on the roof of the lifeboat. This bracket can be mounted either on a wall or
a pipe.
The Tron SART20 must not be permanently stored in
this bracket if mounted outside a freefall lifeboat. Move
the Tron SART20 to this bracket after the lifeboat is
deployed in water.
Figure 11 Illustration: Lifeboat bracket disassembled
Item
no.
Document No. Title
1
M-82746
Wall bracket
2
M-84163_VELDAMENT
M-84163_Bracket_Universal_Weldament D1
3
M-80312
Nut nylock M4 DIN 985
4
M-84676
Screw, DIN 965 – Pozidrive M4x12

Doc. No.: 84145 Rev. L jotron.com Page 19 of 40
5
M-84854
Screw, DIN 965 – Pozidrive M6x70
6
M-84855 Screw, DIN 965 – Pozidrive M6x90
7
M-84838
Pipe clamp
13
M-84875 Washer plate
14
M-91469
Nu nylock M6 DIN 985
15
M-82275 Washer, DIN 9021 – Ø6mm
Table 1 List of components - lifeboat bracket
Use the following dimensions when mounting the lifeboat bracket on a
wall.
Figure 12 Illustration: Lifeboat bracket dimensions

Doc. No.: 84145 Rev. L jotron.com Page 20 of 40
Figure 13 Illustration: Mounting - interior/exterior wall
The lifeboat bracket fits a pipe with a maximum diameter of 50mm.
Figure 14 Illustration: Mounting on a pipe
