Joyner JNSZ650UV4S User manual

Owner’s manual
JNSZ650UV4S

1
INTRODUCTION
Thank you for choosing JOYNER JNSZ650UV4S. It represents the result
of many years of JOYNER experience in the production of utility
vehicles. With the purchase of this JOYNER, you can now appreciate the
high degree of craftsmanship and reliability that have made JOYNER a
leader in this field .This manual will provide you with a good basic
understanding of the features and operation of this vehicle. It also
includes basic maintenance and inspection procedures. If you have any
questions regarding the operation or maintenance of your vehicle, please
consult a JOYNER dealer.
Please read this manual carefully before operating this vehicle. Do not
attempt to operate this vehicle until you have attained adequate
knowledge of its controls and operating features. Regular inspections and
careful maintenance, along with good operating techniques, will help
ensure that you safely enjoy the capabilities and reliability of this vehicle.

2
CONTENTS
WARRANTY POLICY ..........................................................................................................................5
LOCATION OF THE WARNING AND SPECIFICATION LABELS.........................................16
SAFETY INFORMATION..................................................................................................................19
CONTROL FUNCTIONS....................................................................................................................21
MAIN SWITCH......................................................................................................................................21
MULTI-FUNCTION METER UNIT............................................................................................................22
SWITCHES ...........................................................................................................................................22
PEDAL.................................................................................................................................................23
PARKING BRAKE LEVER.......................................................................................................................24
DRIVE SELECT LEVER..........................................................................................................................25
FUELTANK CAP ...................................................................................................................................25
SEATS AND SAFETY BELTS ...................................................................................................................25
GLOVE COMPARTMENT........................................................................................................................26
ARE YOU READY TO DRIVE ..........................................................................................................27
PROTECTIVE APPAREL.........................................................................................................................28
HELMETS AND EYES PROTECTION.......................................................................................................28
DRIVE TRAINING.................................................................................................................................28
AGE RECOMMENDATION .....................................................................................................................29
NO ALCOHOL OR DRUGS.....................................................................................................................29
IS YOUR VEHICLE READY TO DRIVE.........................................................................................30
PRE-DRIVE INSPECTION.......................................................................................................................30
SAFE DRIVING PRECAUTIONS .....................................................................................................32
OFF-ROAD USE ONLY .........................................................................................................................32
KEEP HANDS AND FEET ON CONTROLS ...............................................................................................33
CONTROL SPEED .................................................................................................................................33
DO NOT PERFORM STUNTS .................................................................................................................34
SPECIFICATIONS ..............................................................................................................................35
OPERATION........................................................................................................................................38
OPERATION CONTROLS........................................................................................................................38
BRAKE ................................................................................................................................................39
CLUTCH ..............................................................................................................................................39
START ENGINE .....................................................................................................................................40
ENGINE STOP KEY................................................................................................................................41
PRE-DRIVE INSPECTION ......................................................................................................................41
PASSENGER .........................................................................................................................................42
SEATADJUSTMENT..............................................................................................................................43
PARKING ADJUSTMENT .......................................................................................................................43

3
GEAR SHIFT ADJUSTMENT ..................................................................................................................44
BREAK-IN............................................................................................................................................44
STARTING AND OPERATING INSTRUCTIONS .........................................................................................44
SERVICE INSTRUCTION .................................................................................................................45
SERVICE AIR CLEANER........................................................................................................................45
ENGINE LUBRICATION.........................................................................................................................45
TRANSMISSION LUBRICATION..............................................................................................................46
ENGINE COOLANT...............................................................................................................................47
SPARK PLUG........................................................................................................................................49
CARBURETOR ADJUSTMENT................................................................................................................49
REPAIR.................................................................................................................................................50
FRONT WHEEL REPLACEMENT............................................................................................................50
REAR WHEEL REPLACEMENT..............................................................................................................50
CLUTCH REPLACEMENT.......................................................................................................................51
TIMING SETUPAND BALANCING SHAFT SETUP .....................................................................................55
WATER PUMP DISASSEMBLY.................................................................................................................58
DISTRIBUTOR REPLACEMENT ..............................................................................................................61
FRONT WHEELALIGNMENT ................................................................................................................65
THE USING，MAINTENANCE AND REPAIR OF THE FRONT/REAR REDUCER...............66
PERIODIC MAINTENANCE.............................................................................................................70
WIRING DIAGRAM ...........................................................................................................................71
JNSZ650UV4S LIMITIED WARRANTY..........................................................................................72
DEALER PRE-DELIVERY INSPECTION ............................................................................................ 159

5
Warranty policy

6

7

8

9

10

11

12

13

14

15

16
LOCATION OF THE WARNING AND
SPECIFICATION LABELS
Read and understand all of the labels on your vehicle. They contain important
information for safe and proper operation of your vehicle.
Never remove any labels from your vehicle. If a label becomes difficult to read or
comes off, a replacement label is available from your Joyner dealer.
WARNING
The enclosure cannot protect occupants in
all foreseeable accidents,including rollover.
JOYNER
!
S650.09.04.00.01(2)
WARNING
!
Keep hands,body,other persons
away when closing bed.
Do not operate the vehicle
with bed up.
JOYNER S650.09.04.00.03(2)
WARNING
!
IMPROPER TIRE PRESSURE OR OVERLOADING CAN
CAUSE LOSS OF CONTROL.
LOSS OF CONTROL CAN RESULT IN SEVERE INJURY
OR DEATH.
OPERATING TIRE PRESSURE:Set with tires cold.
RECOMMENDED:FRONT:210kPa, 2.1kg/cm2,30psi
REAR: 210kPa, 2.1kg/cm2,30psi
Never set tire pressure below minimun.Tire may
dislodge from rim.
Gross Vehicle Weight Rating:1200kg(2640lbs)
maximum including weight of operator,passenger,
accessories,cargo,and trailer tongue weight.
JOYNER S650.09.04.00.02(1)

17
JOYNER
WARNING
!
Severe INJURY or DEATH can result if you ignore the following:
Maximum Load in Cargo Bed:350kg.(770lbs).
Never carry passengers in cargo bed.
Cargo can affect handling and stability.Read Owner's Manual before
loading or towing.
When loading with cargo or towing a trailer:Reduce speed and allow
more room to stop.Avoid hills and rough terrain
Be sure cargo is secured,a loose load could change handling
unexpectedly.
Keep weight in the cargo bed centered,and as low an far forward as
possible.
Top-heavy loads increase the risk of overturn.
S650.09.04.00.04(1)
JOYNER
MAX3.9INCH
(100MM)
S650.09.04.00.05(1)
JOYNER
WARNING
Improperly loading a trailer
and failure to use extra care
when pulling trailer can
cause an accident or injury.
Never load more than 50kg
(110lbs) tongue weight on
the towing bracket. Do not
tow more than 550kg
(1212lbs) rolling weight
(trailer plus cargo). Operate
in low-range gears only,
allow far increased braking
distance,and use extreme
caution when operating on
inclines.Read carefully the
loading information and
trailer hitch sections in the
owners manual.
S650.09.04.00.06(1)
JOYNER
WARNING
Turning the off road vehicle in 4WD
takes more effort.
Operate at a slow speed and allow
extra time and distance for
maneuvers to avoid loss of control.
S650.09.04.00.07
WARNING
This off-highway utility vehicle will
handle and maneuver differently from
an ordinary passenger car or other
vehicle.
Vehicle capacity: 1 operator and 1 passenger
.Passenger must be able to reach
and hold the handgrip inside enclosure.
This vehicle is recommended only for
operators 16 and older with a valid motor
vehicle license.Adults must supervise use
by minors. Check state laws for minimum
age requirements.
Gross Vehicle Weight Rating:1200kg(2600lbs)
maximurn Including operator, passenger,
accessories, cargo and trailer tongue weight.
Passenger and cargo can affect vehicle
handling
ALWAYS
wear a seat belt when riding in the
vehicle.
keep your hands and feet
inside the vehicle at all times-watch
for branches, brush, or other hazards
that could enter the vehicle.
drive straight up and down
inclines-driving across the side of an
incline increase the risk of overturn.
NEVER
operate through water deeper than
12"(305mm) or fast flowing water-if
you must cross shallow, slow
moving water, choose your path
carefully to avoid sharp drop-offs
large rocks, or slippery surfaces that
could cause the vehicle to overturn.
make sharp, high-speed turns-the
vehicle could roll over or go out
of control.
Improper use can result in Severe INJURY or DEATH.
LOCATE AND READ THE OWNER'S MANUAL. FOLLOW ALL INSTRUCTIONS AND WARNINGS.
JOYNER S650.09.04.00.08(1)

18
S650.09.04.00.11(3)
JOYNER
MAX . LOAD:
JOYNER CHINA
VIN/NIV:
NW:
MANUFACTURER:
TYPE:
S650.09.04.00.12(1)
JOYNER

19
Note:
WARNING
The enclosure cannot protect occupants in
all foreseeable accidents,including rollover.
JOYNER
!
S650.09.04.00.01(2)
SAFETY INFORMATION
THE SAFETY IS FRIST. Severe injury or death can result if you do not follow
these instructions。Read this manual and all labels carefully and follow the operating
procedures described:
1. This vehicle is designed to carry the driver and one passenger. Never carry
passengers in the cargo bed.
2. Always be sure the driver and passenger are wearing seat belts.
3. Never give a ride to a passenger who is too small to reach and hold the handgrip
on the enclosure.
4. Always avoid operating the vehicle on any paved surfaces, including sidewalks,
driveways, parking lots, and streets.
5. Never operate this vehicle on any public street, road, or highway, even a dirt or
gravel one.
6. Never operate this vehicle without wearing an approved motorcycle helmet that
fits properly. You should also wear eye protection (goggles or a face shield), gloves,
over-the-ankle boots, long-sleeved shirt or jacket, and long pants.
7. Never consume alcohol or drugs before or while operating this vehicle.
8. Never operate at speeds too fast for your skills or the conditions. Always go at a
speed that is proper for the terrain, visibility, operating conditions, and your
experience.
9. Never attempt jumps or other stunts.
10. Always inspect your vehicle each time you use it to be sure it is in safe
operating condition. Always follow the inspection and maintenance procedures and

20
schedules described in this manual.
11. Always keep both hands, arms, feet, and legs inside the vehicle at all times
during operation. Keep your feet on the floorboard. Never hold onto the enclosure
except when using the handgrip inside the enclosure. Otherwise, your hand could be
injured if it is caught between the enclosure and an obstacle outside the vehicle.
12. Always keep both hands on the steering wheel when driving.
13. Never wrap your thumbs and fingers around the steering wheel. This is
particularly important when driving in rough terrain. The front wheels will move right
and left as they respond to the terrain, and this movement will be felt in the steering
wheel. A sudden jolt could wrench the steering wheel around, and your thumbs or
fingers could be injured if they are in the way of the steering wheel spokes.
14.Always go slowly and be extra careful when operating on unfamiliar terrain.
Always be alert to changing terrain conditions when driving the vehicle.
15. Never operate on excessively rough, slippery, or loose terrain until you have
learned and practiced the skills necessary to control the vehicle on such terrain.
Always be especially cautious on these kinds of terrain.
16. Never turn at excessive speed. Practice turning at slow speeds before attempting
to turn at faster speeds. Do not attempt turns on steep inclines.
17. Never operate the vehicle on hills that are too steep for it or for your abilities.
Go straight up and down hills where possible. Maximum slope angle: 15º .
18. Never operate on hills that are slippery or ones where you will not be able to
see far enough ahead of you. Never go over the top of a hill at speed if you cannot see
what is on the other side.
19. Always follow proper procedures for going uphill. If you lose momentum and
cannot continue up a hill, back down the hill with the engine in reverse gear. Use
engine braking to help you go slowly. If necessary, use the brakes gradually to help
you go slowly.
20. Always check terrain carefully before going down hills. Go as slowly as
possible. Never go down a hill at high speed.
21. Always check for obstacles before operating in a new area.
22. Never operate the vehicle in fast flowing water or water deeper than the
floorboards on this model. Remember that wet brakes may have reduced stopping
ability. Test your brakes after leaving water. If necessary, apply them several times to
let friction dry out the linings.
23. Always be sure there are no obstacles or people behind you when you operate in
reverse. When it is safe to proceed in reverse, go slowly. Do not brake abruptly when
carrying loads in the cargo bed.
24. Always use the size and type of tires specified in this manual.
25. Always maintain proper tire pressure as described in this manual.
26. Never exceed the stated load capacity. Cargo should be as far forward in the bed
as possible, and distributed evenly from side to side. Be sure cargo is secured so that it
cannot move around during operation. Reduce speed and follow instructions in this
manual for carrying cargo or pulling a trailer. Allow greater distance for braking.
