Joyner Go-kart JNSZ650DS User manual

Owner’s manual
Parts manual
READTHISMANUALCAREFULLY
IT CONTAINS IMPORTANT SAFETY INFORMATION.
MINIMUM
RECOMMENDED
OPERATOR AGE
JNSZ650DS
FOR OFF-ROAD USE ONLY
This vehicle is designed and manufactured for off-road use only.
USA only;
It does not confirm to federal motor vehicle safety standards, and operation on public streets,
roads, or highways is illegal
0

JNSZ650DS Limited Warranty
The warranty policy applies to those cases where the new seller vehicle is unloaded
from its shipping container, set up and delivered by authorized dealer, and under normal
use and service is found to have defects in parts or workmanship under the following
terms and conditions. This warranty covers the engine and engine related components
for a period of 90 days.
This warranty does not apply to any part, which in opinion of seller was defective
because of improper maintenance, improper assembly, alterations, abuse, negligence or
accident.
Should warranty service be required on your JNSZ650DS during the 90 days warranty
period, please contact your nearest authorized dealer for repairs.
What is not covered under this warranty
This warranty does not cover any seller vehicle that has been subjected to:
a. This warranty does not cover any seller vehicle in any way so to adversely affect its
safety or reliability.
b. Renting
c. Disassembly, adjusting, or repairing of the vehicle in any way so as to adversely
affect its safety or reliability.
d. Competition or racing
The warranty does not cover loss of use of the seller vehicle, loss of time,
inconvenience, or other consequential damage which includes, but is not limited to,
loss or damage to persons or property or any expense of returning any damaged
units to the seller distributor or its authorized dealer.
Seller has the right to make changes without notice.
1

CONTENTS
OWNER’S MANUAL
Page
1. FOREWORD------------------------------------------------------------------------------------------------------------------------------------ 3
2. A FEW WORDS ABOUT SAFETY--------------------------------------------------------------------------------------------------------- 4
3. IMPORTANT SAFETY INFORMATION------------------------------------------------------------------------------------------------- 5
4. SAFETY LABELS------------------------------------------------------------------------------------------------------------------------------ 7
5. ARE YOU READY TO DRIVE? ------------------------------------------------------------------------------------------------------------ 8
6. IS YOUR VEHICLE READY TO DRIVE? --------------------------------------------------------------------------------------------- 10
7. SAFE DRIVING PRECAUTIONS -------------------------------------------------------------------------------------------------------- 12
8. SPECIFICATIONS ----------------------------------------------------------------------------------------------------------------------------14
9. OPERATIONS ------------------------------------------------------------------------------------------------------------------------------------15
10. SERVICE INSTRUCTIONS ---------------------------------------------------------------------------------------------------------------- 20
11. REPAIR ----------------------------------------------------------------------------------------------------------------------------------------- 24
12. PERIODICAL CHECK AND SERVICE ------------------------------------------------------------------------------------------------- 36
13. WIRING DIAGRAM ------------------------------------------------------------------------------------------------------------------------- 37
PARTS MANUAL
PREPARATION ATTACH INSTRUCTIONS
2

FOREWORD
Thank you for choosing JOYNER Go-kart. We hope you will have fun
with it. Before you start to operate the Go-Kart, please read through this
Owner’s Manual carefully as it contains important safety and maintenance
information. Failure to follow the warnings contained in this manual can
result in serious injuries.
Be sure to follow the recommended maintenance schedule and service
your kart accordingly. Preventative maintenance is extremely important to
the longevity of your Go-Kart.
JOYNER believes in conservation and protection of earth’s natural
resources. To that end, we encourage every vehicle owner to recycle, trade
in, or properly dispose of, as appropriate, used motor oil, coolant, and other
fluids, batteries, and tires.
We hope you will have a pleasant experience with our products.
3

A FORWORDS ABOUT SAFETY
In order to keep everyone safe, you must take responsibility for the safe operation
of your Go-Kart.
To help you make informed decisions about safety, we have provided operating
procedures and other information on labels and in this manual. This information alerts
you to potential hazards that could hurt you or others.
It is not practical or possible to warn you about all hazards associated with
operating or maintaining a Go-Kart. You must use your own good judgment.
You will find important safety information in a variety of forms, including:
Safety Labels - On the Go-Kart.
Safety Messages – Preceded by a safety alert symbol and one of two signal
words: WARNING, or CAUTION.
These signal words mean:
Physical harm may result from failure to adhere to the instructions that are described
within the WARNING labels.
Safety Headings --- such as Important Safety Reminders or Important Safety
Precautions.
Safety Section --- such as Go- Kart Safety.
Instructions --- how to use this Go –Kart correctly and safely.
This entire manual is filled with important safety information----please read it
carefully.
4

IMPORTANT SAFETY INFORMATION
Your Go-Kart will provide you with many years of service and pleasure. Providing
you take responsibility for your own safety and understand the challenges you can meet
while driving.
There is a lot you can do to protect yourself when you drive. You’ll find many
helpful recommendations throughout this manual. The following are a few that we
consider most important.
Follow theAge Recommendation
It is strongly recommended that no one under the age of 16 be permitted to drive
this Go-Kart without adult supervision.
Always Wear a Helmet
It’s a proven fact: helmets significantly reduce the number and severity of head
injuries. Always wear an approved motorcycle helmet. We also recommend that you
wear eye protection, sturdy boots, gloves, and other protective gear.
Drive Off-Road Only
Your Go-Kart is designed and manufactured for off-road use only. The tires are not
made for pavement, and the Go-Kart does not have turn signals and other features
required for use on public roads. If you need to cross a paved or public road, get off and
walk your Go-Kart across.
Take Time to Learn & Practice
Even if you have driven other Go-Kart, take time to become familiar with how this
Go-Kart works and handles. Practice in a safe area until you build your skills and get
accustomed to this Go-Kart’s size and weight.
Because many accidents involve inexperienced or untrained drives, we urge all
drivers to take a training course approved by the Go-Kart Safety Institute. Check with
your dealer for more information on training courses.
Be Alert for Off-Road Hazards
The terrain can present a variety of challenges when you drive off-road.
Continually “read” the terrain for unexpected turns, drop-offs, rocks, ruts, and other
hazards. Always keep your speed low enough to allow time to see and react to hazards.
Drive within Your Limits
Pushing limits is another major cause of Go-Kart accidents. Never drive beyond
your personal abilities or faster than conditions warrant. Remember that alcohol, drugs,
fatigue, and inattention can significantly reduce your ability to make good judgments
and driver safely.
Don’t Drink and drive
Alcohol and driving don’t mix. Even one drink can reduce your ability to respond
to changing conditions, and your reaction time gets worse with every additional drink.
So don’t drink and drive, and don’t let your friends drink and drive either.
Never run your Go- Kart indoors.
The exhaust from the engine contains a tasteless, odorless and poisonous gas called
carbon monoxide.
5

IMPORTANT SAFETY INFORMATION
Keep away from moving parts of the Go-Kart
The operator of the Go-Kart should never place their hands or other parts of their
body near any moving part of the Go-Kart. Failure to adhere to this warning will cause
physical harm to your body.
Skidding or Sliding
The terrain surface can be a major factor affecting turns, Skidding a turn is more
likely to occur on slippery surfaces such as snow, ice, mud and loose gravel. If you skid
on ice, you may lose all directional control. To avoid skidding on slippery terrain, keep
you speed low and drive carefully.
6

SAFETYLABELS
This section presents some of the most important information and recommendations
to help you drive your Go-Kart safely, please take a few moments to read these pages.
The labels are considered permanent parts of the Go-Kart. If a label comes off or
becomes hard to read, contact your dealer for warning labels replacements.
7

ARE YOU READY TO DRIVE?
Before each drive, you need to make sure you and your Go-Kart are both ready to
drive. To help get you prepared, this section discusses how to evaluate your driving
readiness, what items you should check on your Go-Kart, and adjustments to make for
your comfort, convenience, or safety.
Before you drive your Go-Kart for the first time, we urge you to:
■ Read this owner’s manual and the labels on your Go-Kart carefully.
■ Make sure you understand all the safety messages.
■ Know how to operate all the controls.
■ Never drive this Go-kart if under 16 years old.
Before each drive, be sure:
■ You feel well and are in good physical and mental condition.
■ You are wearing an approved motorcycle helmet (with chin strap tightened securely),
eye protection, and other protective clothing.
■ You don’t have any alcohol or drugs in your system.
ProtectiveApparel
For your safety, we strongly recommend that you always wear an approved
motorcycle helmet, eye protection, boots, gloves, long pants, and long-sleeved shirt
or jacket whenever you drive.
Although complete protection is not possible, wearing proper gear can reduce the
chance of injury when you drive.
The following suggestions will help you choose the proper driving gear.
Helmets and Eyes Protection
Your helmet is your most important piece of driving gear because it offers the best
protection against head injuries. A helmet should fit your head comfortably and
securely.
An open-face helmet offers some protection, but a full-face helmet offers more.
Regardless of the style, look for a DOT (Department of Transportation) sticker in any
helmet you buy. Always wear a face shield or goggles to protect your eyes and help
your vision.
Operating this Go-Kart without wearing an approved motorcycle helmet, eye protection,
and protective clothing could increase your chances of head and/or eye injury, possibly
death in the event of severe accident.
Always wear approved motorcycle helmet that fits properly and wear eye protection
(goggles or face shield), gloves, boots, long-sleeved shirt or jacket and long pants.
8

ARE YOU READY TO DRIVE?
Additional Driving Gear
In addition to a helmet and eye protection, we also recommend:
■ Sturdy off-road motorcycle boots to help protect your feet, ankles, and lower legs.
■ Off-road motorcycle gloves to help protect your hands.
■ Driving pants with knee and hip pads, a driving jersey with padded elbows, and a
chest/shoulder protector.
Drive Training
Developing your driving skills is an on-going process. Even if you have driven other
Go-Karts, take time to become familiar with how this Go-Kart works and handles.
Practice driving the Go-Kart in a safe area to build your skills. Do not drive in rough
terrain until you get accustomed to the Go-Kart’s controls, and feel comfortable with its
size and weight.
Operating Go-Kart without proper instruction could increase your risk of an accident
which could lead to serious injury or death.
Attempt supporting with your hands to the ground when the Go-cart turning over could lead
to serious injury or death.
Never support with your hands to ground when the Go-cat will turn over.
Age Recommendation
It is strongly recommended that no one under the age of 16 be permitted this Go-Kart
without adult supervision.
A child driving a Go-Kart that is not recommended for his/her age could lose Go-Kart
control and result in severe injury or death.
A child under 16 should have adult supervision when operate on the Go-Kart.
9

No Alcohol or Drugs
Alcohol, drugs and Go-Karts don’t mix. Even a small amount of alcohol can
impair your ability to operate a Go-Kart safely. Likewise, drugs, even if prescribed by a
physician, can be dangerous while operating a Go-Kart. Consult your doctor to be sure
it is safe to operate a vehicle after taking medication.
Operating this Go-Kart after consuming alcohol or drugs can seriously affect your
judgment, cause you to react more slowly, affect your balance and perception, and could
result in serious injury or death.
Never consume alcohol or drugs before or while operating this Go-Kart.
IS YOUR VEHICLE READY TO DRIVE?
Before each drive, it is important to inspect your Go-Kart and make sure any
problems you find are corrected. A pre-drive inspection is a must, not only for safety,
but because having a breakdown, or even a flat tire, can be a major inconvenience.
If your Go-Kart has overturned or has been involved in a collision, do not drive it
until your Go-Kart has been inspected by your dealer, There may be damages or other
problems you can not see.
Improperly maintaining this Go-Kart or failing to correct a problem before driving can
cause a crash in which you can be seriously hurt or dilled.
Always perform a pre-drive inspection before every drive and correct any problems.
Pre-drive Inspection
Check the following items before you get on the Go-Kart:
■ Engine Oil
Check the level and add oil if needed. Check for leaks.
■Coolant
Check the coolant and add coolant if need. Check for the leaks.
■ Fuel
Check the level and add fuel if needed. Also make sure the fuel fill cap is securely
fastened. Check for leaks.
■ Tires
Use a gauge to check the air pressure. Adjust if needed. Also look for signs of
damages or excessive wear.
10

■ Nuts & Bolts
Check the wheels to see that the axle nuts are tightened, Use a wrench to make
sure all accessible nuts, bolts, and fasteners are tight.
■ Pre-drive Inspection
■ Underbody & Exhaust System
Check for, and remove any dirt, vegetation or other debris that could be fire hazard
or interfere with the proper operation of the Go-Kart.
■ Air Cleaner
Check the air filter. Replace it if needed.
■ Leaks, Loose Parts
Walk around you Go-Kart and look for anything that appears unusual, such as a
leak or loose cable.
■ Lights
Make sure the headlight, brake light and tail light are working properly.
■ Throttle
Check the free play and adjust if needed. Press the throttle to make sure it moves
smoothly without sticking, and snaps back automatically when it is released.
Clutch cable
Check the free play of clutch cable and adjust if needed. Press the clutch cable to
make sure it moves smoothly without sticking, and snaps back automatically when
it is released.
■ Brakes
Press the brake pedal several times, check for proper brake pedal free play. Make
sure there is no brake fluid leakage.
■ Engine Stop
When engine is running, turn the switch key counterclockwise. Make sure engine
stops.
■ Steering Wheel
Check that the wheels turn properly as you turn the steering wheel.
■ Cable
Check the cable housing for wear. Check the fittings are tight. Replace or tighten as
needed.
■ Tie rod
Check the tie rod housing for wear. Check the fittings are tight. Replace or tighten
as needed.
11

SAFE DRIVING PRECAUTIONS
Off-Road Use Only
Your Go-Kart and its tires are designed and manufactured for off-road use only, not
for pavement. Driving on pavement can affect handling and control. You should not
drive your Go-Kart on pavement.
Operating this Go-Kart on paved surfaces may seriously affect handling and control of
the Go-Kart, and may cause the vehicle to go out of control.
Never operate the Go-Kart on any paved surfaces, including sidewalks, driveways,
parking lots and streets.
When driving off-road, also remember to always obey local off-road driving laws
and regulations. Obtain permission to drive on private property. Avoid posted areas and
obey “no trespassing” signs.
You should never drive your Go-Kart on public streets, roads or highways, even if
they are not paved. Drivers of street vehicles may have difficulty seeing and avoiding
you, which could lead to a collision. In many states it is illegal to operate Go-Karts on
public streets, roads and highways.
Operating this Go-Kart on public streets, roads or highways can cause collision with
other vehicle.
Never operate this Go-Kart on any public streets, roads or highways, even a dirt or
gravel one.
Keep Hands and Feet on Controls
Always keep both hands on the steering wheel and both feet on the foot controls.
When driving your Go-Kart. It is important to maintain your balance and control of the
Go-Kart. Removing hands or feet away from the controls can reduce your ability to
react and control the kart.
Removing hand from Steering wheel or feet from foot controls during operation can reduce
your ability to control the Go-Kart or could cause you to lose your balance and fall off the
Go-Kart.
Always keep both hand on the steering wheel and both feet on the foot controls of your
Go-Kart during operation.
12

SAFE DRIVING PRECAUTIONS
Control Speed
Driving at excessive speed increases the chance of an accident. In choosing a
proper speed, you need to consider the capability of your Go-Kart, the terrain, visibility
and other operating conditions, plus your own skills and experience.
Operating this Go-Kart at excessive speeds increases your changes of losing control of the
Go-Kart, which can result in an accident.
Always drive at a speed that is proper for your Go-Kart, the terrain, visibility and other
operating conditions, and your experience.
Use Care on Unfamiliar or Rough Terrain
Before driving in a new area, always check the terrain thoroughly. Don’t drive fast
on unfamiliar terrain or when visibility is limited. (it’s sometimes difficult to see
obstructions like hidden rocks, bumps, or holes in time to react).
Failure to use extra care when Operating this Go-Kart on unfamiliar terrain could result in
the Go-Kart overturning or going out of control.
Go slowly and be extra careful when operating on unfamiliar terrain. Always be alert to
changing terrain conditions when operating the Go-Kart.
Never drive past the limit of visibility. Maintain a safe distance between your
Go-Kart and other off-road vehicles. Always exercise caution and use extra care on
rough, slippery and loose terrain.
Failure to use extra care when operating on excessively rough, slippery or loose terrain
could cause loss of traction or vehicle control, which could result in an accident, including
an overturn.
Do not operate on excessively rough, slippery or loose terrain until you have learned and
practiced the skills necessary to control the Go-Kart on such terrain. Always be especially
cautious on these kinds of terrain.
Do Not Perform Stunts
You should always operate your Go-Kart in a safe and reasonable manner. When
driving, always keep all four wheels on the ground.
Attempting wheelies, and other stunts increases the chance of an accident, including an
overturn.
Never attempt stunts, such as wheelies or jumps. Don’t try to show off.
13

SPECIFICATIONS
DIMENSIONS
Overall Length---------------------------------------------------------------------------------------113 in. (2880mm)
Overall Width ---------------------------------------------------------------------------------------68in. (1740mm)
Overall Height ---------------------------------------------------------------------------------------- 59in. (1500mm)
Wheelbase --------------------------------------------------------------------------------------------- 82 in. (2090mm)
Front Track ------------------------------------------------------------------------------------------- 58 in. (1475mm)
Rear Track -------------------------------------------------------------------------------------------58in.(1470mm)
Ground Clearance ---------------------------------------------------------------------------------- 121/2in. (320mm)
ENGINE
Type --------------------------------------------------------------------------------2-Bore,4-Stroke,Liquid-cooled
Bore x Stroke -------------------------------------------------------------------------------------------- 76mm×71mm
Displacement ------------------------------------------------------------------------------------------------------ 644 cc
Compression ratio ------------------------------------------------------------------------------------------------8.4:1
Carburetor ------------------------------------------------------------------------------------ BJH101E or CSH101E
Max Power --------------------------------------------------------------------------------------------20.6kw/5300rpm
Maximum Torque ---------------------------------------------------------------------------44/2700~3300Nm/r/min
Starting ---------------------------------------------------------------------------------------------------------Electric
Ignition ------------------------------------------------------------------------------------------------------------- C.D.I
Lubrication -------------------------------------------------------------------------------------------- Force & Splash
Transmission ----------------------------------------------------------------------- manual clutch, 4 shift/Reverse
Spark Plug ---------------------------------------- --------------------------------------------------------F6T or F6TC
Plug gap ---------------------------------------------------------------------------------------------------- 0.7±0.1mm
Fuel type --------------------------------------------------------------------------------------------- RQ93 (unleaded)
Lubricate oil ---------------------------------------------------------------------------------------------- ≥00C SAE-15W/40
＜00C SAE-10W/30
CAPACITIES
Maximum load ---------------------------------------------------------------------------------- -----------------200kg
Fuel tank ------------------------------------------------------------------------------------------------------------ 27.0L
Engine oil ----------------------------------------------------------------------------------------------------------2900ml
Coolant -------------------------------------------------------------------------------------------------------------4000ml
Starting ---------------------------------------------------------------------------------------------------------------- <5s
Climbing ------------------------------------------------------------------------------------------------------------- 30°
Battery ---------------------------------------------------------------------------------------------------------- 12V36Ah
Head Light ----------------------------------------------------------------------------------------------12V 150W/Both
Tail Light ------------------------------------------------------------------------------------------------- 12V 82W/Both
Fuse ---------------------------------------------------------------------------------------------------------------------30A
SPECIFICATIONS
Brake Track ----------------------------------------------------------------------------------------- < 7m @ 20miles/h
Top speed ------------------------------------------------------------ 58 miles/h (or limited as customers require)
CHASSIS
Front, Rear brake --------------------------------------------------------------- Hydraulic disc, right foot control
Front tire --------------------------------------------------------------------------------------------------------- 25×8-12
Rear tire ----------------------------------------------------------------------------------------------------------- 25×10-12
Front Suspension --------------------------------------------------------------------------- Independent DualA-Arm
Rear Suspension ---------------------------------------------------------- Independent Longitudinal Control Arm
Final Drive --------------------------------------------------------------------------------------------------- shaft driven
TIRE PRESSURE
Front ----------------------------------------------------------------------------------------- 70kpa 0.7kg/c ㎡10psi
Rear ------------------------------------------------------------------------------------------ 70kpa 0.7kg/c ㎡10psi
WEIGHT
Net Weight ---------------------------------------------------------------------------------------------------------490kg
WARRANTY
Parts and workmanship -------------------------------------------------------------------------------------- 90 Days
14

OPERATION
A. Operation controls
WARNING-Do not attempt to start or operate the engine until completely
familiar with the location and use of each control necessary to operate this vehicle.
The operator must know how to stop this machine before starting and driving it.
a. Throttle
The right foot pedal is the throttle that controls the Go-Kart speed. To disengage the
clutch at any time, allow the throttle to return to the idle position. (See Fig. 1)
Each time prior to starting the engine, check the throttle assembly to ensure that when
pedal is pushed all the way forward the assembly is working smoothly and returns to idle
when released. Do not operate if pedal or engine throttle linkage fail to return to idle. If
unable to correct the problem through lubrication, adjustment or replacement of worn parts,
contact your dealer for assistance.
b. Brake
The brake is located on the middle of the three control pedals (See Fig. 1).
Applying pressure to the pedal applies pressure to the brake caliper around the brake
disc at the front and rear wheels and slows or stops the kart.
c. Clutch
The left foot pedal controls the clutch cable (See Fig. 1). With the pedal
down, you can shift the shift lever.
Improper operation of the clutch will lead to excessive wear of the clutch friction surface.
15

Figure 1
OPERATION
d. Start engine
1. Engage the park brake
2. Press the clutch pedal down,
put the shift lever in neutral
3. Insert the key into the
ignition-switch
If the engine is cold;
1. Pull the choke out fully Figure 2
2. Press down the clutch pedal
3. Turn the key clockwise to the “on” position. Release the key and the clutch
pedal when the engine starts.
4. Push the choke back slowly to allow the engine to run smoothly. Keep engine
running for 1-2 minutes.
5. Push the choke back fully. If the idle of engine is not smooth, pull out the choke
to find the best running position and keep running for a while long until the engine ryns
smooth without choke.
If the engine is warm;
Press the throttle slightly and turn the key clockwise to the “on” position, release
the key and the throttle when the engine starts.
Each time prior to starting the engine, check the throttle assembly to ensure that when
pedal is pushed all the way forward the assembly is working smoothly and returns to idle
when released. Do not operate if pedal or engine throttle linkage fail to return to idle. If
unable to correct the problem through lubrication, adjustment or replacement of worn parts,
contact your dealer for assistance.
16

Before you start the engine, check that the parking brake is engaged, and the gear shift
lever is in neutral. Trying to start the engine in gear may damage the starter motor, clutch or
gearbox.
Release the key at once if the engine starts. Holding the key in start position when the
engine is running will cause damage to the starter motor.
If the engine does not start after 10 seconds, a second attempt to start the engine can be
allowed. Improper operation will damage the engine.
OPERATION
e. Engine stop key
Important-stop key test.
Before driving this vehicle, test the Engine Stop key to assure that it is operating
properly. With the engine running, turn the key counterclockwise to the “off” position
for the engine to shut down.
B. Pre-Drive Inspection
Perform this pre-drive inspection everyday before driving vehicle. If not performed,
serious damage to the vehicle or personal injury may result.
1. Check for Engine Oil Level. Check for transmission Oil Level. Check for leaks, add
oil if required.
2. Check the coolant. Check for leaks, add the coolant if required.
3. Check for Fuel Level. Add fuel as necessary and do not overfill. Check for leaks.
4. Check for Brakes. Depress the brake pedal several times, and then check for proper
brake pedal free play. Make sure there is no brake fluid leakage. Adjust if necessary.
5. Check the clutch cable, Assure the cable snaps back and has a smooth operation.
Ensure the clutch can operate smoothly. Adjust if necessary, or replace the clutch if
necessary.
6. Check Tires. Check tires condition and pressure. The pressure on both Front and Rear
tire is 12psi.
7. Check Throttle. Check for smooth operation. Ensure the throttle “snaps” back to idle.
17

8. Check Engine Stop key. Perform engine stop key test. Repair as necessary.
9. Check all Nuts, Bolts, and fasteners. Check wheels to see that all axle nuts and lug
nuts are tightened properly. Check and tighten as necessary all other fasteners to
specified torque.
10. Check Roll Cage Bars. Ensure all protective roll cage bars are in place before
operating the Go-Kart.
12. Check Brake Light. Check for proper operation.
13. Check Wheels. Check for tightness of wheel nuts and axle nuts; check that axle nuts
are secured by cotter pins.
14. Check Steering. Check for free operation and for any unusual looseness in any area.
Always follow rules for safe operation and wear a helmet.
OPERATION
C. Passengers
The vehicle allows for two riders only.
Combined maximum weight of driver
and the passenger should not exceed 180kg
or 400Ibs.
D. Seat Adjustment
The seat must always be securely
fastened in the position which best
allows the operator control of the foot
pedals, steering wheel, and the remote
stopkey. Figure4
a. Pull seat adjustment handle upward to disengage seat slide.
b. Move seat to desired position.
c. Be sure seat adjustment handle snaps back into place and that seat is locked
into position. (See Fig. 4 )
Before attempting to adjust the seat ensure that engine of the Go-Kart is stopped.
Never operate this Go-Kart when the provided seat is not securely fastened, to do so could
result in a strong possibility of severe personal injury or loss of life. Before attempting to
adjust the seat ensure that engine of Go-Kart is stopped.
18

E. Parking Adjustment
Parkbrake“OFF” Parkbrake“On”
Figure 6
a. Pull the park brake lever up so that the unit can engage park brake.
b. To release the unit, press button on front end of parking lever then push the parking
lever to the bottom.
c. Adjust the parking cable if necessary.
OPERATION
F. Gear Shift Adjustment
1. Loosen the bolts.
2. Press down the clutch pedal fully.
3. Operate the shift lever as to
change gearshift from 1 to 4 and
reverse smoothly.
4. First, tighten bolt 1 with
thread glue. Then second, tighten
bolt 2 with thread glue.
(See Fig. 7)
Figure 7
G. Break-in
The first month is most important in the life of your vehicle. Proper operation during
this break-in period will help assure maximum life and performance from your new
vehicle. The following guidelines explain proper break-in procedures.
1. After the engine starts, the engine is not allowed in high speed in the neutral gearshift.
2. Drive vehicle from stop to low speed slowly.
3. Avoid braking strongly.
4. Do not exceed the vehicle speed on the below schedule
The speed of vehicle The first 1000 km
1st Gear 15 km/h
2nd Gear 25km/h
3rd Gear 40 km/h
Max speed in each gear
4th Gear 75km/h
19
