RC ART LLC
Skin Care Unit
DiaDENS Cosmo
Operating Manual
RC ART 14.0-03.71-03 RE
Россия/
Russia
ЕС, все
страны/
EU, all
США/
USA
Канада/
Canada

32
1. Safety rules............................................................................34
2. General information........................................................37
3. Intended use........................................................................38
4. Unit description.................................................................39
5. Operating instructions.................................................44
6. Box contents.....................................................................50
7. Maintenance and battery replacement........51
8. Troubleshooting................................................................52
9. Technical information...................................................53
10. Manufacturer’s warranties.......................................56
11. Manufacturer’s address.............................................57
12. Contacts...............................................................................58
Warranty maintenance form.......................................89
Acceptance certicate........................................................92
TABLE OF CONTENTS

33
To ensure eective and safe usage of the unit,
please read carefully all sections of this manual.
THANK YOU FOR PURCHASING THE
DiaDENSCosmo UNIT!

34
The unit is not waterproof. Protect is
from moisture.
All maintenance works on the unit must
be performed by skilled technicians at
the manufacturer’s factory.
Transportation conditions:
—temperature -50 to +50 0С;
— relative air humidity 30 to 93 %;
— atmospheric pressure 70 to 106 kPa
(525 to 795 mm Hg).
Storage conditions:
—temperature -50 to +40 0С;
— relative air humidity 30 to 93 %;
— atmospheric pressure 70 to 106 kPa
(525 to 795 mm Hg).
Please pay special attention to the
information marked with this sign. This
information is important for ensuring safe
and eective use of the unit.
The information contained
in this Operating Manual is
important for your safety
and for correct application
and maintenance of the unit.
Operation of the unit in the vicinity of
short-wave or microwave equipment
may cause the output parameters of
the unit to become unstable.
Avoid long-term exposure of the unit to
direct sunrays at a high air temperature
(over 25 oC). This may cause failure of
the unit display or destroy its batteries.
The product contains fragile
components. Take care to protect it
from shocks.
SAFETY RULES
1

35
Separate collection of electric and
electronic equipment.
Warning! The unit contains precious
materials that may be used repeatedly
after disposal with consideration of the
environmental protection regulations.
Operating conditions:
— temperature +10 to +35 0С;
— relative air humidity 30 to 93 %;
— atmospheric pressure 70 to 106 kPa
(525 to 795 mm Hg).
Warning! If the unit was stored at the
ambient temperature lower than 10 0С,
before operating keep it under normal
climatic conditions for at least two hours.
Recycling: the unit packaging materials
are not hazardous for the environment;
they can be recycled.

36
Such materials must be taken to specially
designated collection and recycling facilities
(please consult in the relevant services in
your locality).
The use of low currents in beauty therapy is
safe for people who have no health issues.
However there are a number of diseases
and pathological conditions, the presence
of which may restrict or preclude from the
application of the unit for medical reasons.
They include:
— an implanted heart pacesetter or other
implanted electronic devices;
—idiosyncrasy to electric current;
— epilepsy with frequent seizures;
—fever of unknown etiology;
—neoplasia;
— general severe condition of a patient;
— infectious diseases of the skin.
If you have any of the health issues, you have
to consult a physician before using the unit.
No controlled studies of the application of
the unit by pregnant women have been
conducted.

37
GENERAL INFORMATION
2
It is no secret that facial skin can lose its
attractiveness due to wrinkles, pigment spots,
scaling, loss of elasticity or dehydration. On the
one hand, this can be caused by aging changes
related to the whole body. Such changes may
become evident at any age because the skin is
constantly exposed to aggressive environmental
factors that lead to impairment of normal
circulation and therefore skin nutrition.
It becomes dry and less elastic, changes its colour
and becomes wrinkled.
While we cannot stop the pace of time, modern
cosmetology provides every opportunity to
protect our skin and minimize the consequences
of continuous exposure to the environment.
The beauty therapy eect of the unit is accounted
for by the exposure of the skin to low current
electric impulses (microcurrents). Microcurrent
treatment restores muscular and vascular tonus,
improves skin microcirculation and nutrition. This,
in its turn, boosts metabolism and rejuvenates the
skin. It looks fresh and radiant.

38
INTENDED USE OF THE DEVICE
3
The DiaDENS-Cosmo unit is designed for
cosmetological treatment of the facial skin. The
treatment does not require any special conditions.
The unit can be used at home or at beauty salons.

39
UNIT
DESCRIPTION
4
Picture 1. Arrangement of the unit. Front

40 Picture 2. Arrangement of the unit. Back with the conducting cu
conducting layer

41
Cable input
Unit with the
cable connected
Picture 3. Arrangement of the unit. Cable input and unit
with the cable connected
Picture 4. Arrangement of the unit. Battery compartment
Battery compartment

42
Picture 6. Beauty care unit with mask electrode connected
Do not connect any detachable electrodes other
than the mask electrode designed for use with
DiaDENS Cosmo.
Picture 5. Mask electrode
Do not connect the mask electrode to any type
of device other than the DiaDENS Cosmo!

43
Nourishment mode
Lymph drainage mode
Time until procedure completion
Picture 7. Arrangement and purpose of the buttons on the keyboard
Treatment power step-up
Unit on/o
Operation mode change
(Nourishment/Lymph drainage)
Start/Pause (starts and stops
operation in the selected mode)
Treatment power step-down
Liquid crystal
display
Picture 8. Designation of symbols on the display
Treatment mode symbol
Skin contact symbol
Treatment power level
Battery status

44
5.1. No special conditions are required for the
procedure
The room should be dry and warm. During the
procedure the patient should be positioned
comfortably, seated or lying. After the procedure
it is recommended to remain relaxed for 10 – 15
minutes.
Products recommended for use with DiaDENS-
Cosmo:
— DiaDENS-Cosmo series facial beauty masks;
— tissue mask to be used with physiological
solution (0,9 % NaCl solution) or 1 % Karlsbad
salt solution
5.2. Beauty mask allergenicity test
All DiaDENS-Cosmo series facial beauty masks
are hypoallergenic. However if you are prone to
allergic reactions:
1) apply a drop of the cosmetic solution on a small
skin area close to the elbow and let it dry;
2) if skin redness is evident in the area where the
drop was applied within 1–2 hours, do not use
this beauty mask for treatment.
5.3. Skin preparation for treatment
Make sure that before the procedure you
take o all metal hairpins or decorations
that were on your head.
Do not use the unit if you have conductive
jewelry on as it may signicantly decrease
eect of the procedure.
Do not apply the unit to damaged skin or to
the skin showing signs of inammation on
the face or around it.
It is very important for your safety that during
treatment your facial skin should be free from
makeup.
The following steps should be taken:
1) remove all makeup from your face, using tonic;
2) wash your face thoroughly with a large quantity
of running water;
APPLICATION INSTRUCTIONS
5

45
3) remove the remaining moisture with a towel or
with dry tissue.
5.4. General recommendations concerning
treatment and program selection
When using the unit, please remember that the
maximum eect is achieved if you a course of
treatment is delivered. Its duration can be 5–6 to
10–12 procedures. The eect will become evident
gradually as restoration of the skin cells takes
certain time. The treatment also gives a long-term
post-eect. To maintain it you will have to conduct
1 or 2 procedures a week.
Long-term continuous use of one physical factor
increases tolerance to such factor and may
decrease treatment eect.
That is why we do not recommend continuous
use of the unit.
Besides, due to the stochastic nature of
physiological processes in the human body, an
insignicant number of people (maximum 2–3
%) show insucient response or complete lack of
response to the treatment (without any negative
consequences).
Depending on your skin type and its initial
condition, age and the objectives that you wish
to achieve, various unit application schemes are
possible.
You can develop them yourself or use the
suggested schemes.
There are two key approaches:
1) a course of 6 or 12 procedures once a quarter
and supporting therapy consisting of 1 or 2
procedure a week between the courses;
2) monthly courses including 5 or 6 procedures
without supporting therapy.
5.5. Nourishment mode
This mode is recommended as a basic program for
the beauty therapy course. It improves circulation
in the facial skin and enhances uptake of the
active components in the DiaDENS-Cosmo series
facial beauty masks.
5.6. Lymph drainage mode
The lymph drainage program is used for face lift
and anti-edema treatment.

46
We recommend to alternate it with the
Nourishment program your face has a tendency
to become edematic.
To conduct treatment in this mode, use the tissue
mask moistened with a saline solution, for example
in the physiological solution (0,9 % NaCl solution)
or 1 % Karlsbad salt solution.
5.7. Mode combination during the procedure
We recommend to use one of the unit modes
during the procedure. It needs to be decided
separately in each case whether it makes sense
to use two modes in consequence during one
procedure, depending on the treatment eect
and individual sensitivity of each patient.
Please adhere to the recommended
treatment schemes. If you apply the unit too
frequently, this may cause skin irritation.
5.8. Preparation of the unit for the procedure
Before using the unit, make sure that there are
no impact marks on its case and the liquid crystal
display of the unit is not damaged. Make sure that
there are no traces of foreign materials or signs of
damage on the cu electrode and on the mask
electrode.
Do not use the unit if it is damaged.
Do not use the mask electrode if the
conducting layer is damaged (change of
colour or mechanical destruction).
5.8.1. If there are no batteries in the battery
compartment, install the batteries. When installing
the batteries, make sure you observe the correct
polarity.
5.8.2. Before the rst use, wash the cu electrode
and the mask electrode with soap solution.
Wash o the remaining soap with running water.
Remove the remaining moisture with dry tissue.
5.8.3. Put the mask electrode in front of you with
the decorative side down.
5.8.4. Connect the cable to the mask electrode.
5.8.5. Slightly moisten the skin on the back surface
of your forearm. Fix the unit on your arm, making
sure that it ts tightly on your moistened skin.

47
If the cu electrode does not t tightly, you
may have unpleasant sensations during the
procedure.
We recommend that one mask electrode
should not be shared by several users.
5.9. Procedure
5.9.1. Nourishment program
Pull one of the DiaDENS-Cosmo series masks
out of the package; unfold it and smooth it
out on your face.
Before use make sure that the package of
each individual beauty mask is undamaged.
Do not use the mask if the package is
damaged.
Do not use the beauty masks that were kept
in the open air for a long time or the masks
that show evidence of drying.
We recommend to use the masks within 20
or 30 minutes after they are pulled out of the
package.
Do not additionally moisten the beauty
mask with any solution not recommended
for use with DiaDENS-Cosmo.
Warning! Do not use any masks other than
those recommended for use with the unit!
Other masks were not tested for
compatibility with the unit.
Do notusethe beautymasks withan expired
shelf life.
5.9.2. Lymph drainage program
Prepare a saline solution (for example 1% Karlsbad
salt solution – 1 teaspoonful per 0.5 litre of water)
or use a pre-mixed physiological solution (0,9 %
NaCl solution). Take the tissue mask out of the
package. Soak it in the saline solution and squeeze
to remove extra moisture.
Smooth out the mask carefully and apply it to your
face.
5.9.3. Smooth out the mask over your face in
sliding movements, making sure that it ts tightly
on your facial skin.
5.9.4. Fix the mask electrode over the cosmetic
mask on your face. Make sure that the mask
electrode is not in direct contact with the facial skin!

48
Warning!Donottrytoxthemaskelectrode
so that it would be in complete contact with
your face. Several contact points around the
face perimeter will be sucient.
The nourishing mask conducts impulses up to the
distance of 6 to 8 cm of each point of contact with
the mask electrode.
5.9.5. Connect the cable of the mask electrode to
the unit.
5.9.6. Switch on the unit, using the button.
5.9.7. Select the required mode — Nourishment
of Lymph Drainage — using the button.
5.9.8. Press the button to start the procedure.
5.9.9. Gradually increase the power by pressing
the button until you feel a slight tingling or
vibration under the mask electrode or under the
cu on your arm.
Dierent people may have signicantly
dierent electric stimulation sensitivity, and
some people may not feel anything at the
maximum power.
This is not a defect of the unit and does not
decrease eect of the procedure.
If you have any unpleasant sensations
after the power is increases, use the
button to reduce the treatment power to a
comfortable level.
Do not conduct treatment at an
uncomfortable or intolerable power level!
5.9.10. Upon completion of the procedure, the
unit will sound an alarm and stop the treatment.
5.9.11. Take the mask electrode o your face, after
which remove the beauty mask.
The beauty mask is disposable and may not
be used repeatedly.
5.9.12. Take the unit o your arm. Disconnect the
cable from the mask electrode and from the unit.
Be careful when pulling the plug out of the unit:
hold the plug tightly, do not shake it loose or bend
it.
5.9.13. Remove the remaining parts of the beauty
mask from your face, using warm running water.

49
5.10. Obligatory maintenance of the mask
electrode
Immediately after the procedure, remove the
remaining cosmetic solution from the mask
electrode, using running water with soap.
Careful cleaning of the mask electrode carefully
after the procedure ensures safety of further
procedures and signicantly increases the lifetime
of the mask electrode.
The manufacturer recommends to replace the
mask electrode after 60 applications.
Warning! Store the mask electrode dry!
Make sure that the cosmetic solution does
not dry on the mask electrode.
Clean the mask electrode immediately after
each procedure.
Do not continue using the mask electrode if
it was not treated and show green oxidation
marks!
Clean the mask electrode and the
conducting layer of the cu carefully after
eachuse.The lack of adequatecleaning may
cause allergic reactions of cross-infection if
several people use the unit.
In case of idiosyncrasy, if you observe
aggravation of the patient’s condition
during the procedure or skin irritation after
the procedure, stop the treatment and
promptly consult a physician.
