JPL PROPELLER Spitfire User manual

JPL Spitre
User Guide
www.jpltele.com
Mini Conference Room Video Sound Bar with Intelligent Zoom

JPL Spitre 2
Unpacking
Remove your camera from its packaging and
ensure you have the correct specied accessories.
Retain the camera box for storage, and also in
the unlikely event that it needs to be returned for
servicing or repair.
Warning
Ensure that all electrical connections (including
extension leads and interconnections between
pieces of equipment) are properly made and in
accordance with the relevant manufacturer’s
instructions.
• Do not continue to operate the equipment if
you are in any doubt about it working normally,
or if it is damaged in any way. If this is the case,
disconnect the unit from your PC equipment
and consult your dealer.
• Do not allow electrical equipment to be
exposed to rain or moisture.
• Never push anything into holes, slots or any
other opening on your camera as this could
result in a fatal electrical shock.
• Do not open the camera housing as doing so
will void the warranty.
• Never guess or take chances with electrical
equipment.
Safety
For your own safety, this product should only be
used with UKCA, CE, FCC, and RoHS approved
equipment. Using this camera with non-approved
equipment can void this products warranty.
Unplug this product from the power outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
Do not overload outlets and extension cords as
this can result in risk of re or electric shock.
Environmental Notice
This camera has been made to UKCA, CE, FCC,
RoHS, and WEEE standards. In the interest of
recycling raw materials, please do not dispose of
this camera in the household waste at the end of
its useful life. Disposal can take place at approved
recycling or disposing locations in accordance
with local regulations.
Consult your responsible authority for
information about the professional and
environment-friendly disposal of your device. If
you want that we handle the disposal for you, you
can send the device at your costs to JPL Telecom
Limited.
Declaration of Conformity
This device complies with the basic health, safety and environmental requirements in all relevant directives.
You will nd the Declaration of Conformity on our website. www.jpltele.com
General Limitation of Liability
The device is not designed, manufactured, or intended for use or resale, in environments that require fail-
safe performance, such as in the operation of life-support systems and/or nuclear facilities. The device may
only be used for these purposes with prior written permission from the manufacturer in each individual case.

JPL Spitre 3
Contents
What’s Included .................................................................................................................................... 4
Overview ................................................................................................................................................ 5
Features .................................................................................................................................................. 6
Setting up your conference room camera ...................................................................................... 7
Connecting your 4K camera .............................................................................................................. 8
Using your 4K camera ......................................................................................................................... 8
Optimal Performance .......................................................................................................................... 8
Technical Information ......................................................................................................................... 9
- Camera Parameters
- Microphone Parameters
- Speaker Parameters
- Other Parameters
Trouble Shooting ............................................................................................................................... 10
Conditions of Warranty ..................................................................................................................... 11

JPL Spitre 4
Thank you for choosing the JPL Spitre Mini Conference Room Video Sound Bar with Intelligent Zoom.
What’s Included
Wall BracketMini Tripod
Mini Conference Room Video Sound Bar
with Intelligent Zoom
Clam Shell Carry Case
Wall Bracket Fixings
USB-C to
USB-A or USB-C Cable

JPL Spitre 5
Overview
Dual stereo duplexed microphones for smooth natural conversations
Input: DC5V 1000mA
CONFERENCE ROOM VIDEO SOUND BAR
Model: JPL Spitfire SKU: 575-350-001
www.jpltele.com
Made in China
Integrated privacy lens slider cover
Full HD glass lens
Camera in-use LED indicator (red
indicates power to the camera and
green indicates active camera)
Universal bracket (desk mount,
monitor mount and tripod thread
for optional tripod)
AI intelligent zoom on/o
touch sensitive area under the
JPL logo
Speakers located at the back of the camera
USB-C connectivity to computer
with either USB-A or USB-C

JPL Spitre 6
• 4K UHD 3840 x 2160p
• Plug & play solution - No soware download needed
• Intelligent zoom, powered by AI - Tracking to focus on the people in the room
• Full HD 4K Sony glass lens - No optical distortion
• 96° Field of view - 8 person conference room suitable
• Integrated privacy lens cover
• 2 x Built-in duplex stereo microphones, 5m voice pick up
• 2 x Built-in speakers
• Desk mount, monitor mount and universal thread for tripod option
• Full 360° rotation including 90° tilt for over desk viewing
• Built-in, camera in-use, LED indicator
• Automatic low-light correction
• AEC - Automatic Echo Cancellation
• ANS - Automatic Noise Suppression
• Protective carry case, lightweight desktop tripod and wall bracket included
• USB 2.0 Type-A and USB Type-C connectivity
• Compatible with all computers (Mac or PC) and sophones
• *3 years limited warranty
(*2 years standard repair or replacement warranty plus a 3rd year cover on the camera only)
Features

JPL Spitre 7
Setting up your conference room video sound bar
1. Designed with a fully adjustable mount, the JPL Spitre can be placed above a computer monitor,
positioned on a desktop, or mounted on a wall or ceiling.
(a) Monitor Mount
Grasp the camera in one hand and open the exible clip base with your other hand. Mount the
camera onto the top of the monitor, making sure that the foot on the exible clip base is at with the
back of the monitor.
(b) Mini Tripod
The mini tripod can be attached to the base of the adjustable bracket
and placed on a desk or counter top.
(c) Wall Mount
Drill holes in the wall that match the pre-drilled holes
on the back of the mount.
Make sure to check you are not drilling into any
electrical wires hidden within the wall.
Put rawl plugs into the drilled holes and then attach the
mount to the wall using the screws supplied.
360° camera rotation 90° camera forward tilt
90°
96°
96°
Wall Mount with
pre-drilled holes

JPL Spitre 8
Connecting your conference room video sound bar
Connecting the USB adapter to your computer’s USB-A or USB-C port is a simple plug & play process.
No other action is required. There is no soware download needed.
To enable full functionality of the video sound bar, the JPL Spitre must be connected directly to your
computer, or to a powered hub.
Optimal Performance
• Do not sit in front of a window or other bright light source.
• Having an uncluttered background to ensure your viewers are
concentrating on you.
• The mounting system allows for tilting and aiming the camera.
While sitting in your normal position, your entire face or
conference room should be just above the middle of the picture.
Tilt and move the camera to frame up a good view.
Using your conference room video sound bar
Once you have connected the camera to your computer via the USB cable you can open the visual
collaboration soware of your choice: Microso Teams®, Zoom®, WebRTC, Webex, Bluejeans® etc.
Most collaboration soware packages allow you to choose your devices. Simply select the JPL Spitre
for both microphone and camera.

JPL Spitre 9
Technical Information
Camera parameters:
Total Pixels 8.3 million pixels - 4K resolution
Aperture F/No. =2.5 ±5%
Focal length F=2.95mm
Maximum eective pixel 3840 x 2160
Output image format MJPG and YUV
Field of view 96°
AI Zoom 5 x AI Zoom
Minimum Illumination 0.5 Lux at F2.0
Exposure Automatic Exposure (AE)
Automatic image control functions Auto White Balance (AWB), Dynamic Black Level, Calibration (ABLC)
Resolution @ 30fps 3840 x 2160, 2560 x 1440, 1080p, 720p, VGA
Microphone parameters:
Microphone quantity 2
SNR ≥60dB
Sensitivity -38±3dB (2.0V 2.2KΩ)
Far-eld distance 5 meters voice pickup
Horizontal voice pickup Omnidirectional microphone
Communication mode USB 2.0
Digital Signal Processing Automatic: gain control, noise reduction and echo noise reduction control
Speaker parameters:
Sampling rate 48kHz
Speaker power 1W*2pcs
Directivity Omnidirectional
Rated impedance 8Ω ± 5%
Other parameters:
Interface type USB 2.0 Type-A or USB Type-C
Voltage DC 5V / 1000mA
OS Support Win 7/Win 8/Win 10
Mac - OS X 10.10 or later
Android 5.0 or above with UVC
Power 1.5W

JPL Spitre 10
Trouble Shooting
1. No image displayed
a) Check if the USB port and USB cable of the terminal device are connected correctly.
b) Check if the USB cable is stable.
c) Check if the USB port is working.
d) Check your sophone soware is selecting the JPL Spitre.
2. The image breaks frequently
a) Check if the USB port and USB cable of the terminal device are connected correctly.
b) Check if the USB cable is stable.
3.Thedenitionisnotgoodaeraccessingsoware
a) Check your soware video input settings to see if the camera video input is set correctly.
4.NomicrophoneTXsound
a) Check your sophone soware is selecting the JPL Spitre.
b) Check you have not muted the sound by accident.
5.Ismycamera’svideopreviewimagetoobrightortoodark?
a) Change brightness settings in camera application.
For further support you can visit our website https://www.jpltele.com/product/jpl-spitre/ and chat via
LiveChat with one of our technical team or email us on [email protected]om.

JPL Spitre 11
Conditions of Warranty
1. JPL Telecom Limited, Head Oice: Units 1 & 2, Church Close Business Park, Church Close, Todber,
Sturminster Newton, Dorset DT10 1JH, England, grants 3 year limited manufacturer’s warranty* from
the date of purchase, as the manufacturer of this product.
2. For you, as a consumer, this means: We guarantee that our devices are error-free when supplied. If a
manufacturing error is identied within 36 months* of the delivery date we will repair or replace the device
free of charge without you, as the consumer, having to provide the usual legally required proof that this fault
was present when you received the device. We either use new parts or parts in mint condition for the repair or
replacement delivery. Any parts removed from the device become our property and can be destroyed by us.
3. In addition to this warranty, you have the unlimited legal right to claim against the supplier on the basis
of the terms of the warranty for defects on the basis of the purchase contract. However, in contrast to
our Manufacturer’s Warranty, the legal warranty for defects only applies to the device’s state when sold.
4. You can only claim against this warranty if you return the faulty device to JPL Telecom Limited or our
local general importer or distributor, outside England, at your own cost, with a valid proof of purchase
(invoice or till receipt). When you return it to us, please provide a detailed description of the fault that
has occurred, and also tell us your telephone number, in case we need to contact you. To prevent
shipping damage, provide suitable transport packaging (e.g. original packaging with a secondary
shipping box).
5. The Manufacturer’s Warranty excludes damage caused by mishandling, operating errors, misuse,
external inuences, lightning strikes/power surges, modications to the product and extensions.
Shipping damage, consequential damage, and costs arising from down times and travel times are also
excluded.
6. Do not open the camera housing as doing so will void the warranty. The warranty is cancelled if repairs
are carried out by unauthorised agents.
*3 years limited warranty (2 years standard repair or replacement warranty plus a 3rd year cover on the
camera only)

REGISTERED ADDRESS
UK Oice: JPL Telecom Limited
Units 1 & 2, Church Close Business Park, Church Close, Todber, Sturminster Newton, Dorset, DT10 1JH, England
USA Oice: JPL Telecom Holdings LLC
445 W Merritt Ave, Merritt Island, FL 32953, USA
Registered in England No. 5250754 www.jpltele.com
