JS Automation FA-C2060 User manual

FA-C2060
ATX Motherboard
supports 32nm LGA1155 Intel®Xeon®E3
and Intel®Core™i3 CPU per
Intel®C206, DDR3, VGA/DVI/HDMI,
Dual Intel®PCIe GbE, 2 USB 3.0,
2 SATA 6Gb/s, Audio
User's Manual (V1.0)
健昇科技股份有限公司
JS AUTOMATION CORP.
新北市汐止區中興路 100 號6樓
6F., No.100, Zhongxing Rd.,
Xizhi Dist., New Taipei City, Taiwan
TEL：[phone]
FAX：[phone]
http://www.automation.com.tw
http://www.automation-js.com/
E-mail：[e-mail]

1
Contents
1. Forward................................................................................................................................................3
2. Features................................................................................................................................................4
3. Specifications.......................................................................................................................................5
4. Dimensions ..........................................................................................................................................7
5. Jumper and Connector Locations ........................................................................................................8
5.1 FA-C2060 Layout ........................................................................................................................8
5.2 Peripheral Interface Connectors...................................................................................................9
5.3 External Interface Panel Connectors..........................................................................................10
6. Connector and Jumper setting............................................................................................................11
6.1 Peripheral Interface Connectors.................................................................................................11
6.1.1 ATX Power Connector...........................................................................................................11
6.1.2 Battery Connectors ................................................................................................................11
6.1.3 CPU Power Connector...........................................................................................................12
6.1.4 DDR3 DIMM Slots................................................................................................................12
6.1.5 Digital I/O Connector ............................................................................................................12
6.1.6 Fan Connector (CPU) ............................................................................................................13
6.1.7 Fan Connector (System) ........................................................................................................13
6.1.8 Front Panel Audio Connector ................................................................................................13
6.1.9 Front Panel Connector...........................................................................................................14
6.1.10 I2C Connector....................................................................................................................14
6.1.11 Keyboard/Mouse Connector..............................................................................................14
6.1.12 Parallel Port Connector......................................................................................................15
6.1.13 PCI Slots............................................................................................................................16
6.1.14 PCIe x4 Slots .....................................................................................................................16
6.1.15 PCIe x8 Slot.......................................................................................................................17
6.1.16 PCI Express x16/x8 Slot....................................................................................................18
6.1.17 SATA3Gb/s Drive Connector............................................................................................18
6.1.18 SATA6Gb/s Drive Connector............................................................................................19
6.1.19 Serial Port Connector, RS-422/485....................................................................................19
6.1.20 Serial Port Connectors, RS-232.........................................................................................19
6.1.21 SMBus Connector..............................................................................................................20
6.1.22 SPDIF Connector...............................................................................................................20
6.1.23 SPI ROM Connector..........................................................................................................20
6.1.24 TPM Connector..................................................................................................................21
6.1.25 USB Connectors ................................................................................................................21
6.2 External Interface Connector.....................................................................................................22
6.2.1 Audio Connector....................................................................................................................22
6.2.2 Ethernet and USB Connector.................................................................................................22
6.2.3 HDMI Port Connector ...........................................................................................................23

2
6.2.4 Keyboard/Mouse Connector..................................................................................................23
6.2.5 Serial Port Connectors (COM6) ............................................................................................24
6.2.6 VGA and DVI Connector ......................................................................................................24
7. Ordering information.........................................................................................................................25

3
1. Forward
Thank you for your selection of FA-C2060 cpu card.
Any comment is welcome,
please visit our website: www.automation.com.tw for the up to date information.

4
2. Features
ATX form factor
RoHS compliant
LGA1155 CPU socket
Three PCI card expansion slots
Multiple PCIe expansion card configurations:
Slot
PCIe x16
PCIe x8
PCIe x4
PCI
Configuration 1
1
N/A
2
3
Configuration 2
N/A
2
2
3
Configuration 3
N/A
1
2
3
Supports four dual-channel DDR3 DIMMs
One external RS-232 serial port
Four internal RS-232 serial ports connectors
One internal RS-422/485 serial port connector
Two Intel® PCIe Gigabit Ethernet connectors (LAN2 with Intel® AMT 7.0 support)
Four SATA 3Gb/s connectors
Two SATA 6Gb/s connectors
High Definition audio
Intel® C206 chipset

5
3. Specifications
Form Factor : ATX
CPU Supported : LGA1155 Intel®Xeon®or Core™ i3 quad/dual core CPU
Chipset : Intel®C206
Integrated Graphics : Supports DirectX 10.1/OpenGL 3.0 Full MPEG2, VC1, AVC Decode
Memory : Four 240-pin 1333/1066 MHz dual-channel DDR3 SDRAM DIMMs support
(system max. 32.0 GB)
Audio : Realtek ALC888 HD Audio codec (Line-in, Line-out, Mic)
BIOS : UEFI BIOS
Digital I/O : 8-bit, 4-bit input/4-bit output
Ethernet Controllers : Intel®82574L PCIe Ethernet controller Intel® 82579 PHY with
Intel®AMT 7.0 support (LAN2)
Super I/O Controller : Fintek F81866
Watchdog Timer : Software programmable supports 1~255 sec. system reset
Expansion
Three PCI slot
Two PCIe x4 slot
One PCIe x16 (x8 mode) slot
One PCIe x16 (x16 or x8 mode) slot
I/O Interface Connectors
Audio Connectors : Three external audio jacks (line-in, line-out, mic-in)
One internal front panel audio connector (10-pin header)
Display port : One VGA Integrated in the Intel®C206
One HDMI Integrated in the Intel®C206
One DVI-D Integrated in the Intel®C206
Ethernet : Two RJ-45 GbE ports
Keyboard/Mouse : Dual PS/2 port One internal keyboard and mouse connector via 6-pin wafer
TPM : One via 20-pin header
Serial Ports : One external RS-232 serial port
Four RS-232 via internal box headers
One RS-422/485 via internal 4-pin wafer
Parallel Port : One parallel port via internal 26-pin box header
USB ports : Two external USB 3.0 ports on rear IO by NEC D720200F1
Two external USB 2.0 ports on rear IO Four internal USB 2.0 ports by pin header
Serial ATA : Four SATA 3Gb/s channels with 3Gb/s data transfer rates Two SATA 6Gb/s
channels with 6Gb/s data transfer rates

6
Environmental and Power Specifications
Power Supply : ATX power supported
Power Consumption : [email protected], [email protected] , [email protected], [email protected], [email protected]
(3.10 GHz Intel® Core™i5 2400 CPU with four 1333 MHz 4GB
DDR3 memory)
Operating temperature : -10ºC ~ 60ºC
Humidity : 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions : 244 mm x 305 mm
Weight GW/NW : 1200 g / 700 g

7
4. Dimensions

8
5. Jumper and Connector Locations
5.1 FA-C2060 Layout

9
5.2 Peripheral Interface Connectors
Connector
Type
Label
ATX Power connector
24-pin ATX
ATX1
Battery connector
2-pin wafer
BT2
Battery holder
CR2032 battery holder
BAT1
CPU power connector
4-pin Molex
CPU12V1
DDR3 DIMM slots
DDR3 DIMM slot
CHA_DIMM1 CHA_DIMM2
CHB_DIMM1 CHB_DIMM2
Digital I/O
10-pin header
DIO1
Fan connector (system 1)
3-pin wafer
SYS_FAN1
Fan connector (system 2)
3-pin wafer
SYS_FAN2
Fan connector (CPU)
4-pin wafer
CPU_FAN1
Front panel audio connector
10-pin header
FP_AUDIO1
Front panel connector
14-pin header
F_PANEL1
I2C connector
4-pin wafer
I2C_1
Keyboard and mouse connector
6-pin wafer
KB_MS1
Parallel port connector
26-pin box header
LPT1
PCI slots
PCI slots
PCI1, PCI2, PCI3
PCIe x4 slot
PCIe x4 slot
PCIEX4_1
PCIe x16/x8 slot
PCIe x16 slot
PCIEX16_1
PCIe x4 slot
PCIe x4 slot
PCIEX4_2
PCIe x8 slot
PCIe x16 slot
PCIEX8_1
SATA 3Gb/s drive connector
14-pin SATA connector
SATA34, SATA56
SATA 6Gb/s drive connector
7-pin SATA connector
SATA1, SATA2
Serial port, RS-422/485
4-pin wafer
COM4
Serial port, RS-232
10-pin box header
COM1, COM2, COM3, COM5
SMBus connector
4-pin wafer
SMBUS_1
SPDIF connector
5-pin header
SPDIF1
SPI ROM connector
8-pin header
JSPI1
TPM connector
20-pin header
TPM1
USB connectors
8-pin header
USB1, USB2, USB3, USB4

10
5.3 External Interface Panel Connectors
Connector
Type
Label
Audio connector
Audio jack
AUDIO_CV1
Ethernet and USB 2.0 ports
RJ-45, USB
LAN1_USB01
Ethernet and USB 3.0 ports
RJ-45, USB
LAN2_USB23
HDMI connector
HDMI port
HDMI1
Keyboard and mouse connector
Dual PS/2
KB_MS2
Serial Port connector
9-pin male DB-9
COM6
VGA and DVI connector
15-pin female,
24-pin header
VIDEO1

11
6. Connector and Jumper setting
6.1 Peripheral Interface Connectors
6.1.1 ATX Power Connector
(ATX1: 24-pin)
The ATX power connector connects to an ATX power supply.
Pin
Description
Pin
Description
1
+3.3V
13
+3.3V
2
+3.3V
14
-12V
3
GND
15
GND
4
+5V
16
PS_ON
5
GND
17
GND
6
+5V
18
GND
7
GND
19
GND
8
NC
20
NC
9
+5V
21
+5V
10
+12V
22
+5V
11
+12V
23
+5V
12
+3.3V
24
GND
6.1.2 Battery Connectors
(BAT1, BT2 : Battery holder and 2-pin wafer)
This is connected to the system battery. The battery provides power to the system clock to
retain the time when power is turned off.
Pin
Description
1
GND
2
Battery+

12
6.1.3 CPU Power Connector
(CPU12V1: 4-pin Molex)
The CPU power input connector provides power to the CPU.
Pin
Description
1
GND
2
GND
3
+12V
4
+12V
6.1.4 DDR3 DIMM Slots
(CHA_DIMM1, CHA_DIMM2, CHB_DIMM1, CHB_DIMM2 : DDR3 DIMM slot)
The DIMM slots are for DDR3 DIMM memory modules.
6.1.5 Digital I/O Connector
(DIO1: 10-pin header)
The digital I/O connector provides programmable input and output for external devices. The
digital I/O provides 4-bit output and 4-bit input.
Pin
Description
Pin
Description
1
GND
2
VCC
3
Output 3
4
Output 2
5
Output 1
6
Output 0
7
Input 3
8
Input 2
9
Input 1
10
Input 0

13
6.1.6 Fan Connector (CPU)
(CPU_FAN1:4-pin wafer)
The fan connector attaches to a CPU cooling fan.
Pin
Description
1
GND
2
+12 V
3
FANIO1
4
PWM
6.1.7 Fan Connector (System)
(SYS_FAN1, SYS_FAN2: 3-pin wafer)
The fan connector attaches to a cooling fan.
Pin
Description
1
FANIO
2
+12 V (PWM)
3
GND
6.1.8 Front Panel Audio Connector
(FP_AUDIO1: 10-pin header)
This connector connects to speakers, a microphone and an audio input.
Pin
Description
Pin
Description
1
LMIC2_L
2
AUD GND
3
LMIC2_R
4
PRESENCE#
5
LLINE2-R
6
MIC2-JD
7
F_SENSE
8
NC
9
LLINE2-L
10
LINE2-JD

14
6.1.9 Front Panel Connector
(F_PANEL1: 14-pin header)
The front panel connector connects to the indicator LEDs and buttons on the computer's front
panel.
Function
Pin
Description
Function
Pin
Description
Power
1
ACPILED
Speaker
2
Beep Power
LED
3
NC
4
NC
5
GND
6
NC
Power
7
PWRBT_SW#_C
8
PC Beep
Button
9
GND
Reset
10
NC
HDD
LED
11
HDDLED
12
EXTRST-
13
HDDLED-
14
GND
6.1.10 I2C Connector
(I2C_1 : 4-pin wafer)
The I2C connector is for system debug.
Pin
Description
1
+5V_DUAL
2
PCH_GP38_PU
3
PCH_GP39_PU
4
GND
6.1.11 Keyboard/Mouse Connector
(KB_MS1: 6-pin wafer)
The keyboard/mouse connector connects to a PS/2 Y-cable that can be connected to a PS/2
keyboard and mouse.
Pin
Description
1
+5 V KB DATA
2
MS DATA
3
MS CLK
4
KB DATA
5
KB CLK
6
GROUND

15
6.1.12 Parallel Port Connector
(LPT1: 26-pin box header)
The parallel port connector connects to a parallel port connector interface or some other
parallel port device such as a printer.
Pin
Description
Pin
Description
1
RSTROBE#
2
RPD0
3
RPD1
4
RPD2
5
RPD3
6
RPD4
7
RPD5
8
RPD6
9
RPD7
10
SIO_ACK#
11
SIO_BUSY
12
SIO_PE
13
SIO_SLCT
14
SIO_AFD#
15
SIO_ERR#
16
SIO_INIT#
17
SIO_SLIN#
18
GND
19
GND
20
GND
21
GND
22
GND
23
GND
24
GND
25
GND
26
NC

16
6.1.13 PCI Slots
(PCI1, PCI2, PCI3 : PCI Slot)
The PCI slot enables a PCI expansion module to be connected to the board.
6.1.14 PCIe x4 Slots
(PCIEX4_1, PCIEX4_2 : PCIe x4 slot)
The PCIe x4 slot is for PCIe x4 expansion cards.

17
6.1.15 PCIe x8 Slot
(PCIEX8_1: PCIe x16)
The PCIe x8 slot provide PCIe x8 signal for PCIe expansion cards.

18
6.1.16 PCI Express x16/x8 Slot
(PCIEX16_1 : PCIe x16 slot)
The PCIe x16 expansion card slot is for PCIe x16 or PCIe x8 expansion cards.
6.1.17 SATA 3Gb/s Drive Connector
(SATA34, SATA56: 14-pin SATA connector)
The SATA drive connectors can be connected to SATA drives and support up to 3Gb/s data
transfer rate.
Pin
Description
Pin
Description
1
GND
8
GND
2
SATATXP_A
9
SATATXP_B
3
SATATXN_A
10
SATATXN_B
4
GND
11
GND
5
SATARXN_A
12
SATARXN_B
6
SATARXP_A
13
SATARXP_B
7
GND
14
GND

19
6.1.18 SATA 6Gb/s Drive Connector
(SATA1, SATA2 : 7-pin SATA drive connectors)
The SATA drive connectors can be connected to SATA drives and support up to 6Gb/s data
transfer rate.
Pin
Description
1
GND
2
SATATXP
3
SATATXN
4
GND
5
SATARXN
6
SATARXP
7
GND
6.1.19 Serial Port Connector, RS-422/485
(COM4: 4-pin wafer)
This connector provides RS-422 or RS-485 communications.
Pin
Description
Pin
Description
1
RXD485#
3
RXD485+
2
RXD485+
4
RXD485#
6.1.20 Serial Port Connectors, RS-232
(COM1, COM2, COM3, COM5: 10-pin box header)
Each of these connectors provides RS-232 connections.
Pin
Description
Pin
Description
1
-NDCD1
6
-NCTS1
2
-NDSR1
7
-NDTR1
3
NSIN1
8
-XRI1
4
-NRTS1
9
GND
5
NSOUT1
10
GND
