JS Automation JD50SHB120 User manual

SHB120 Series
Intel®Socket 1155 Core™i7 /
Core™i5 / Core™i3 /
Processor PICMG®1.3 Full-Size
CPU Card
USER’S MANUAL (V1.1)
健昇科技股份有限公司
JS AUTOMATION CORP.
新北市汐止區中興路 100 號6樓
6F., No.100, Zhongxing Rd.,
Xizhi Dist., New Taipei City, Taiwan
TEL：[phone]
FAX：[phone]
http://www.automation.com.tw
http://www.automation-js.com/
E-mail：[e-mail]

1
Correction record
Version
Record
1.1
Add Correction record and Warranty

2
CONTENTS
1. Forward...............................................................................................................................................3
2. Features...............................................................................................................................................5
3. Specifications......................................................................................................................................6
4. Dimensions(mm) ................................................................................................................................8
5. Layout.................................................................................................................................................9
6. Jumper Settings.................................................................................................................................10
6.1 COM1 Mode Select Jumpers for RS232/422/485 (JP3, JP4, JP5)..........................................10
6.2 Audio Amplifier Jumper (JP1).................................................................................................10
6.3 Clear RTC Jumper (JP8)..........................................................................................................11
7. Connectors........................................................................................................................................12
7.1 SMBUS Connector (CN1).......................................................................................................13
7.2 Floppy Disk Port Connector (CN4).........................................................................................13
7.3 Internal USB Connectors (CN5)..............................................................................................14
7.4 Internal USB Connectors (CN8, CN10, CN13).......................................................................14
7.5 LAN2 LED Connectors (CN6)................................................................................................14
7.6 LAN1 LED Connectors (CN7)................................................................................................15
7.7 DB15 CRT Connector (CN11) Co-layout with CN12.............................................................15
7.8 DVI-D Pin Header (CN14)......................................................................................................15
7.9 Front Panel Connector (CN15)................................................................................................16
7.10 PS/2 Keyboard, Mouse Connectors (CN17, CN18)................................................................16
7.11 External USB 3.0 Port Connectors (CN16, CN19) .................................................................17
7.12 RS232/422/485 Pin Assignment (COM1) ...............................................................................17
7.13 COM Port RS-232 Pin Assignment (COM2) ..........................................................................18
7.14 Intel®HD Audio Digital Header (AUDIO1) ...........................................................................18
7.15 ATX 8 Pin 12V IN Connector (ATX2)....................................................................................18
7.16 A CPU fan is always needed for cooling CPU heat (FAN3) ...................................................19
7.17 System & Auxiliary Fan Connectors (FAN1, FAN2)..............................................................19
7.18 Ethernet RJ-45 Connectors (LAN1, LAN2)............................................................................19
7.19 Parallel Port Connector (PRINT1) Print Port Connector.........................................................20
7.20 SATA Connectors.....................................................................................................................21
8. Ordering Information........................................................................................................................22

3
Warranty
The SHB120 series are warranted against defects in materials and workmanship for a period of two
years from the date of shipment, as evidenced by receipts or serial no. on board. JS automation Corp.
will, at its option, repair or replace product that proves to be defective during the warranty period. This
warranty includes parts, labor and shipping costs of returning.
Except as specified herein, JS automation Corp. makes no warranties, express or implied, and
specifically disclaims any warranty of merchantability or fitness for a particular purpose. Customer’s
right to recover damages caused by fault or negligence on the part of JS automation Corp. shall be
limited to the amount theretofore paid by the customer. JS automation Corp. will not be liable for
damages resulting from loss of data, profits, use of products, or incidental or consequential damages,
even if advised of the possibility thereof. This limitation of the liability of JS automation Corp. will
apply regardless of the form of action, whether in contract or tort, including negligence. Any action
against JS automation Corp. must be brought within one year after the cause of action accrues.
JS automation Corp. shall not be liable for any delay in performance due to causes beyond its reasonable
control. The warranty provided herein does not cover damages, defects, malfunctions, or service failures
caused by owner’s failure to follow the JS automation Corp. installation, operation, or maintenance
instructions; owner’s modification of the product; owner’s abuse, misuse, or negligent acts; and power
failure or surges, fire, flood, accident, actions of third parties, or other events outside reasonable control.
If any defect occurs, you should email to us as the following form to get the fast response:
Detailed Company Information
Company/Organization:
Contact Person:
E-mail:
Address:
Country:
Tel/Fax:
Web Site:
Product information
product model:
serial no.:
Environment to Use: such as CPU board, Operating System, target application...
description of defect: (as detail as possible)

4
1. Forward
Thank you for your selection of SHB120 Series cpu card.
Any comment is welcome,
please visit our website: www.automation.com.tw for the up to date information.

5
2. Features
LGA1155 for 3rd Generation Intel®Core™i7/ i5/ i3 processors (Ivy Bridge)
Intel®Q77 PCH
2 DDR3 DIMM support up to 16 GB memory
Intel®iAMT 8.0 & TPM (optional) supported
PCIe Gen. 3 at 8GT/s supported
USB 3.0 supported
DVI and VGA for dual displays

6
3. Specifications
CPU :
Intel®Core™i3 Desktop Processor
Intel®Core™i5 Desktop Processor
Intel®Core™i7 Desktop Processor
System Chipset : Intel®Q77
CPU Socket : LAG1155 Socket
DRAM Transfer Rate : 1333/1600 MHz
BIOS : AMI BIOS via SPI interface with socket
System Memory
Two 240-pin DDR3 1333/1600 DIMM sockets
Maximum up to 16GB DDR3 memory
L1, L2, L3 Cache : integrated in CPU
Onboard Multi-I/O :
Parallel Port: one 26-pin 2.54-pitch box-header, SPP/EPP/ECP supported
Serial Port: one for RS-232/422/485 with 10-pin, 2.54-pitch box-header (COM1) and
one port for RS-232 with 10-pin, 2.54-pitch box-header (COM2)
Floppy controller: one 34-pin, 2.54-pitch box-header supports two drives (1.44MB for
each)
USB Interface :
Ten USB ports compliant with USB Spec. Rev. 2.0 (6 ports on board, 4 ports to SHB
connector-C golden fingers)
Four USB ports compliant with USB Spec. Rev. 3.0 (2 ports on rear I/O, 2 ports on
board)
Onboard Graphic :
Intel®Arrandale integrated a Graphic processing unit processor which goes with Q77
chipset with VGA, DisplayPort (co-lay with VGA) and DVI.
Memory Size : Intel®DVMT 5.0 supported; preallocated memory for frame buffer
option as OS option :
Windows XP :
* For Total System Memory < 1GB,
Graphics sharing memory = 128 MB Maximum;
* For 1 GB to 1.5 GB Total System Memory,
Graphics sharing memory = 512 MB Maximum;
* For 1.5 GB to 2 GB Total System Memory,
Graphics sharing memory = 768 MB Maximum;
* For 2 GB and Above Total System Memory,
Graphics sharing memory = 1GB Maximum.
Windows Vista:
* Graphics sharing memory max to 0.5* (OS Ram Size –512)

7
Resolution -- Analog output -- the analog port utilizes an integrated 400MHz 24-bit
RAMDAC that can directly drive a standard progressive scan analog monitor up to a
resolution of 2048x1536 pixels with 32-bit color at 75 Hz
Analog Output Interface -- CRT from DAC output via 15-pin D-Sub connector on the
edge; CRT always ON supported
Ethernet : The LAN1/LAN2 are Intel 82579LM with iAMT 7.0 / Intel 82574L Ethernet
controller support 10/100/1000 Mb/s
Serial ATA : Two Serial ATA-6Gb/s and Four Serial ATA-3Gb/s performance and
SATA RAID 0/1/5/10 by Q77
Audio : 10-pin 2.0 pin-header (Intel®HD Audio Digital Header)
Hardware Monitoring : Monitoring temperatures, voltages, and cooling fan status
Watchdog Timer : Reset Supported (1-255 level)
Dimensions : 338mm x 126mm
Expansion interface:
1 PCI-E x16(Gen.3)
1 PCI-E x4(or 4 PCI-E x1) (Gen.2)
4 PCI

8
4. Dimensions(mm)

9
5. Layout
