JS Automation FA-Q670 User manual

FA-Q670
ATX LGA1155 Motherboard for
Intel®Core™i7/i5/i3 Quad/
Dual Core CPU, Intel®Q67 Chipset,
DDR3, VGA/DVI/HDMI,
Dual Intel®PCIe GbE,
Intel®AMT 7.0 Support, Two USB 3.0
Ports, Five COM Ports,
Two SATA 6Gb/s Ports and RoHS
USER’S MANUAL (V1.0)
健昇科技股份有限公司
JS AUTOMATION CORP.
新北市汐止區中興路 100 號6樓
6F., No.100, Zhongxing Rd.,
Xizhi Dist., New Taipei City, Taiwan
TEL：[phone]
FAX：[phone]
http://www.automation.com.tw
http://www.automation-js.com/
E-mail：[e-mail]

1
CONTENTS
1. Forward....................................................................................................................................................3
2. Features....................................................................................................................................................4
3. Specifications...........................................................................................................................................5
4. Dimensions(mm) .....................................................................................................................................7
5. Jumper and Connector.............................................................................................................................8
5.1 Jumper and Connector Locations ...................................................................................................8
5.2 Peripheral Interface Connectors......................................................................................................9
5.3 External Interface Panel Connectors.............................................................................................10
6. Connector and Jumper setting................................................................................................................11
6.1 Internal Peripheral Connectors .....................................................................................................11
6.1.1 ATX Power Connector (ATX1) .......................................................................................11
6.1.2 Battery Connector (BAT1, BT2)......................................................................................11
6.1.3 CPU Power Connector (CPU12V1) ................................................................................12
6.1.4 DDR3 DIMM Slots (CHA_DIMM1, CHA_DIMM2, CHB_DIMM1, CHB_DIMM2) .12
6.1.5 Digital I/O Connector (DIO1)..........................................................................................12
6.1.6 Fan Connector (CPU)(CPU_FAN1)................................................................................13
6.1.7 Fan Connector (system)(SYS_FAN1, SYS_FAN2) ........................................................13
6.1.8 Front Panel Audio Connector (FP_AUDIO1) .................................................................13
6.1.9 Front Panel Connector (F_PANEL1)...............................................................................14
6.1.10 I2C Connector (I2C_1)....................................................................................................14
6.1.11 Keyboard/Mouse Connector (KB_MS1).........................................................................15
6.1.12 Parallel Port Connector (LPT1).......................................................................................15
6.1.13 PCIe Mini Card Slot(PCI1, PCI2, PCI3, PCI4)...............................................................15
6.1.14 PCIe x1 Slot (PCIEX4_1)................................................................................................16
6.1.15 PCIe x4 Slot (PCIEX4_2)................................................................................................16
6.1.16 PCIe x16 Slot (PCIEX16_1)............................................................................................16
6.1.17 SATA3Gb/s Drive Connectors (SATA34, SATA56).......................................................17
6.1.18 SATA6Gb/s Drive Connector (SATA1, SATA2).............................................................17
6.1.19 Serial Port Connector, RS-422/485 (COM4)...................................................................17
6.1.20 Serial Port Connectors, RS-232 (COM1, COM2, COM3, COM5).................................18
6.1.21 SMBus Connector (SMBUS_1) ......................................................................................18
6.1.22 SPDIF Connector (SPDIF1) ............................................................................................18
6.1.23 SPI ROM Connector (JSPI1)...........................................................................................18
6.1.24 TPM Connector (TPM1)..................................................................................................19
6.1.25 USB Connectors (USB1, USB2, USB3, USB4)..............................................................19
6.2 External Peripheral Interface Connector Panel.............................................................................20
6.2.1 Audio Connector (AUDIO_CV1)....................................................................................20
6.2.2 Ethernet and USB Connector (LAN1_USB01, LAN2_USB23).....................................20
6.2.3 HDMI Port Connector (HDMI1).....................................................................................21

2
6.2.4 Keyboard/Mouse Connector (KB_MS2) ........................................................................ 21
6.2.5 Serial Port Connectors (COM6)...................................................................................... 22
6.2.6 VGA and DVI Connector (VIDEO1).............................................................................. 22
7. Ordering Information............................................................................................................................ 23

3
1. Forward
Thank you for your selection of FA-Q670 cpu card.
Any comment is welcome,
please visit our website: www.automation.com.tw for the up to date information.

4
2. Features
ATX form factor
RoHS compliant
LGA1155 CPU socket
Four PCI card expansion slots
One PCIe x16 card expansion slot
One PCIe x4 card expansion slot
One PCIe x1 card expansion slot
Supports four dual-channel DDR3 DIMMs
One external RS-232 serial port
Four internal RS-232 serial port connectors
One internal RS-422/485 serial port connector
Two Intel®PCIe Gigabit Ethernet connectors (LAN2 with Intel®AMT 7.0 support)
Four SATA 3Gb/s connectors
Two SATA 6Gb/s connectors
High Definition audio
Intel®Q67 Chipset

5
3. Specifications
Form Factor : ATX
CPU Supported : LGA1155 Intel® Core™i7/i5/i3 quad/dual core CPU
Chipset : Intel® Q67
Integrated Graphics : Supports DirectX 10.1/OpenGL 3.0
Full MPEG2, VC1, AVC Decode
Memory : Four 240-pin 1333/1066 MHz dual-channel DDR3 SDRAM unbuffered DIMMs
support (system max. 16.0 GB)
Graphics Engine : Support for DX10.1 and OpenGL3.0
Full MPEG2, VC1, AVC Decode
Audio : Realtek ALC662 HD Audio codec (Line-in, Line-out, Mic)
BIOS : UEFI BIOS
Digital I/O : 8-bit, 4-bit input/4-bit output
Ethernet Controllers : Intel®82583V PCIe Ethernet controller
Intel®82579 PHY with Intel® AMT 7.0 support (LAN2)
Super I/O Controller : Fintek F81866
Watchdog Timer : Software programmable supports 1~255 sec. system reset
Expansion :
PCI : Four PCI slots
PCIe : One PCIe x4 slot / One PCIe x1 slot / One PCIe x16 slot
I/O Interface Connectors :
Audio Connector : Three external audio jacks (line-in, line-out, mic-in)
One internal front panel audio connector (10-pin header)
Display port : One VGA integrated in the Intel®Q67
One HDMI Integrated in the Intel®Q67
One DVI-D Integrated in the Intel®Q67
Ethernet : Two RJ-45 GbE ports
Keyboard/Mouse : Dual PS/2 port
One internal keyboard and mouse connector via 6-pin wafer
TPM : One via 20-pin header
Serial Ports : One external RS-232 serial port
Four RS-232 via internal box headers
One RS-422/485 via internal 4-pin wafer
Parallel Port : One parallel port via internal 26-pin box header
USB Ports : Two external USB 3.0 ports on rear IO by NEC D720200F1
Two external USB 2.0 ports on rear IO
Eight internal USB 2.0 ports by four pin headers
Serial ATA : Four SATA 3Gb/s channels with 3Gb/s data transfer rates
Two SATA 6Gb/s channels with 6Gb/s data transfer rates

6
Environmental and Power Specifications :
Power Supply : ATX power supported
Power Consumption : [email protected], [email protected] , [email protected], [email protected],
[email protected](3.10 GHz Intel®Core ™i5 2400 CPU with four 1333 MHz 4GB DDR3
memory)
Operating Temperature : -10ºC ~ 60ºC
Humidity :5% ~ 95% (non-condensing)
Physical Specifications :
Dimensions : 244 mm x 305 mm
Weight (GW/NW) : 1200 g / 700 g

7
4. Dimensions(mm)

8
5. Jumper and Connector
5.1 Jumper and Connector Locations

9
5.2 Peripheral Interface Connectors
Connector
Type
Label
ATX Power connector
24-pin ATX
ATX1
Battery connector
2-pin wafer
BT2
Battery holder
CR2032 battery holder
BAT1
CPU power connector
4-pin Molex
CPU12V1
DDR3 DIMM slots
DDR3 DIMM slot
CHA_DIMM1 CHA_DIMM2
CHB_DIMM1 CHB_DIMM2
Digital I/O
10-pin header
DIO1
Fan connector (system 1)
3-pin wafer
SYS_FAN1
Fan connector (system 2)
3-pin wafer
SYS_FAN2
Fan connector (CPU)
4-pin wafer
CPU_FAN1
Front panel audio connector
10-pin header
FP_AUDIO1
Front panel connector
14-pin header
F_PANEL1
I2C connector
4-pin wafer
I2C_1
Keyboard and mouse connector
6-pin wafer
KB_MS1
Parallel port connector
26-pin box header
LPT1
PCI slots
PCI slots
PCI1, PCI2, PCI3, PCI4
PCIe x1 slot
PCIe x4 slot
PCIEX4_1
PCIe x4 slot
PCIe x4 slot
PCIEX4_2
PCIe x16 slot
PCIe x16 slot
PCIEX16_1
SATA 3Gb/s drive connector
14-pin SATA connector
SATA34, SATA56
SATA 6Gb/s drive connector
7-pin SATA connector
SATA1, SATA2
Serial port, RS-422/485
4-pin wafer
COM4
Serial port, RS-232
10-pin box header
COM1, COM2, COM3, COM5
SMBus connector
4-pin wafer
SMBUS_1
SPDIF connector
5-pin header
SPDIF1
SPI ROM connector
8-pin header
JSPI1
TPM connector
20-pin header
TPM1
USB connectors
8-pin header
USB1, USB2, USB3, USB4

10
5.3 External Interface Panel Connectors
Connector
Type
Label
Audio connector
Audio jack
AUDIO_CV1
Ethernet and USB 2.0 ports
RJ-45, USB
LAN1_USB01
Ethernet and USB 3.0 ports
RJ-45, USB
LAN2_USB23
HDMI connector
HDMI port
HDMI1
Keyboard and mouse connector
Dual PS/2
KB_MS2
Serial Port connector
9-pin male DB-9
COM6
VGA and DVI connector
15-pin female, 24-pin header
VIDEO1

11
6. Connector and Jumper setting
6.1 Internal Peripheral Connectors
6.1.1 ATX Power Connector (ATX1)
The ATX power connector connects to an ATX power supply.
Pin
Description
Pin
Description
1
+3.3V
13
+3.3V
2
+3.3V
14
-12V
3
GND
15
GND
4
+5V
16
PS_ON
5
GND
17
GND
6
+5V
18
GND
7
GND
19
GND
8
NC
20
NC
9
+5V
21
+5V
10
+12V
22
+5V
11
+12V
23
+5V
12
+3.3V
24
GND
6.1.2 Battery Connector (BAT1, BT2)
This is connected to the system battery. The battery provides power to the system clock to retain
the time when power is turned off.
Pin
Description
1
GND
2
Battery+

12
6.1.3 CPU Power Connector (CPU12V1)
The CPU power input connector provides power to the CPU.
Pin
Description
1
GND
2
GND
3
+12V
4
+12V
6.1.4 DDR3 DIMM Slots (CHA_DIMM1, CHA_DIMM2, CHB_DIMM1, CHB_DIMM2)
The DIMM slots are for DDR3 DIMM memory modules.
6.1.5 Digital I/O Connector (DIO1)
The digital I/O connector provides programmable input and output for external devices. The digital
I/O provides 4-bit output and 4-bit input.
Pin
Description
Pin
Description
1
GND
2
VCC
3
Output 3
4
Output 2
5
Output 1
6
Output 0
7
Input 3
8
Input 2
9
Input 1
10
Input 0

13
6.1.6 Fan Connector (CPU)(CPU_FAN1)
The fan connector attaches to a CPU cooling fan.
Pin
Description
1
GND
2
+12 V
3
FANIO1
4
PWM
6.1.7 Fan Connector (system)(SYS_FAN1, SYS_FAN2)
The fan connector attaches to a cooling fan.
Pin
Description
1
FANIO
2
+12 V (PWM)
3
GND
6.1.8 Front Panel Audio Connector (FP_AUDIO1)
This connector connects to speakers, a microphone and an audio input.
Pin
Description
Pin
Description
1
LMIC2_L
2
AUD GND
3
LMIC2_R
4
PRESENCE#
5
LLINE2-R
6
MIC2-JD
7
F_SENSE
8
NC
9
LLINE2-L
10
LINE2-JD

14
6.1.9 Front Panel Connector (F_PANEL1)
The front panel connector connects to the indicator LEDs and buttons on the computer's front
panel.
Function
Pin
Description
Function
Pin
Description
Power LED
1
ACPILED
Speaker
2
Beep Power
3
NC
4
NC
5
GND
6
NC
Power Button
7
PWRBT_SW#_C
8
PC Beep
9
GND
Reset
10
NC
HDD LED
11
HDDLED
12
EXTRST-
13
HDDLED-
14
GND
6.1.10 I2C Connector (I2C_1)
The I2C connector is for system debug.
Pin
Description
1
+5V_DUAL
2
PCH_GP38_PU
3
PCH_GP39_PU
4
GND

15
6.1.11 Keyboard/Mouse Connector (KB_MS1)
The keyboard/mouse connector connects to a PS/2 Y-cable that can be connected to a PS/2
keyboard and mouse.
Pin
Description
1
+5 V KB DATA
2
MS DATA
3
MS CLK
4
KB DATA
5
KB CLK
6
GROUND
6.1.12 Parallel Port Connector (LPT1)
The parallel port connector connects to a parallel port connector interface or some other parallel
port device such as a printer.
Pin
Description
Pin
Description
1
RSTROBE#
2
RPD0
3
RPD1
4
RPD2
5
RPD3
6
RPD4
7
RPD5
8
RPD6
9
RPD7
10
SIO_ACK#
11
SIO_BUSY
12
SIO_PE
13
SIO_SLCT
14
SIO_AFD#
15
SIO_ERR#
16
SIO_INIT#
17
SIO_SLIN#
18
GND
19
GND
20
GND
21
GND
22
GND
23
GND
24
GND
25
GND
26
NC
6.1.13 PCIe Mini Card Slot(PCI1, PCI2, PCI3, PCI4)
The PCI slot enables a PCI expansion module to be connected to the board.

16
6.1.14 PCIe x1 Slot (PCIEX4_1)
The PCIe x1 slot provides PCIe x1 signal for PCIe expansion cards.
6.1.15 PCIe x4 Slot (PCIEX4_2)
The PCIe x4 slot is for PCIe x4 expansion cards.
6.1.16 PCIe x16 Slot (PCIEX16_1)
The PCIe x16 expansion cards slot is for PCIe x16 expansion cards.

17
6.1.17 SATA 3Gb/s Drive Connectors (SATA34, SATA56)
The SATAdrive connectors can be connected to SATA drives and support up to 3Gb/s data transfer
rate.
Pin
Description
Pin
Description
1
GND
8
GND
2
SATATXP_A
9
SATATXP_B
3
SATATXN_A
10
SATATXN_B
4
GND
11
GND
5
SATARXN_A
12
SATARXN_B
6
SATARXP_A
13
SATARXP_B
7
GND
14
GND
6.1.18 SATA 6Gb/s Drive Connector (SATA1, SATA2)
The SATAdrive connectors can be connected to SATA drives and support up to 6Gb/s data transfer
rate.
Pin
Description
1
GND
2
SATATXP
3
SATATXN
4
GND
5
SATARXN
6
SATARXP
7
GND
6.1.19 Serial Port Connector, RS-422/485 (COM4)
This connector provides RS-422 or RS-485 communications.
Pin
Description
Pin
Description
1
RXD485#
3
TXD485+
2
RXD485+
4
TXD485#

18
6.1.20 Serial Port Connectors, RS-232 (COM1, COM2, COM3, COM5)
Each of these connectors provides RS-232 connections.
Pin
Description
Pin
Description
1
-NDCD1
6
-NCTS1
2
-NDSR1
7
-NDTR1
3
NSIN1
8
-XRI1
4
-NRTS1
9
GND
5
NSOUT1
10
GND
6.1.21 SMBus Connector (SMBUS_1)
The SMBus (System Management Bus) connector provides low-speed system management
communications.
Pin
Description
1
+5V_DUAL
2
SMBCLK
3
SMBDATA
4
GND
6.1.22 SPDIF Connector (SPDIF1)
Use the SPDIF connector to connect digital audio devices to the system.
Pin
Description
1
+5V
2
NC
3
SPDIFOUT
4
GND
5
SPDIFIN
6.1.23 SPI ROM Connector (JSPI1)
The SPI connector is used to flash the BIOS.
Pin
Description
Pin
Description
1
+3.3V
2
GND
3
SPI_CS0
4
SPI_CLK
5
SPI_SO0
6
SPI_SI
7
NC
8
NC

19
6.1.24 TPM Connector (TPM1)
The TPM connector connects to a TPM module.
Pin
Description
Pin
Description
1
LCLK
2
GND2
3
LERAME#
4
KEY
5
LRESRT#
6
+5V
7
LAD3
8
LAD2
9
+3V
10
LAD1
11
LAD0
12
GND3
13
SCL
14
SDA
15
SB3V
16
SERIRQ
17
GND1
18
GLKRUN#
19
LPCPD#
20
LDRQ#
6.1.25 USB Connectors (USB1, USB2, USB3, USB4)
The USB connectors connect to USB devices. Each pin header provides two USB ports.
Pin
Description
Pin
Description
1
+5V
2
GND
3
DATA-
4
DATA+
5
DATA+
6
DATA-
7
GND
8
+5V
