OWNER’S
MANUAL
JG 8 SERIES
POWER DISTRIBUTION
COVERS MODELS
JG 8, JG 8L, JG 8LED & JG 8LMTM
APRIL 2013

SAFETY PRECAUTIONS
The JG 8 series products (JG 8) are designed to operate with 120VAC, 60 Hz.
Operation with 220 or 240 volts will cause damage and possibly cause personal
injury.
CAUTIONS
1. The JG 8 must be grounded. Defeating the unit’s grounding capability could
create a hazard.
2. There are no user serviceable parts inside. Do not attempt service yourself.
Contact Juice Goose as directed in this manual if service is required.
3. Do not expose the JG 8 to moisture. Avoid severe physical impacts to the
unit.
DISCLAIMER
Juice Goose shall under no circumstances be held responsible for any loss,
damage or injury resulting from the use of the JG 8 in a manner inconsistent
with any of the procedures outlined in this document. The user is responsible for
determining whether this product is appropriate for the intended application.
Juice Goose is not responsible for any indirect, secondary or ancillary loss or
damage, including personal injury, loss of or damage to property or loss of in-
come resulting from the operation or failure of this unit.
FRONT PANEL
Lighted Power On/Off Switch –This switch controls power to all 8 outlets on
the back of the chassis.
Light Tubes (JG 8L, JG 8LED and JG 8LM) –The JG 8L, JG 8LED and JG
8LM feature two pull out dimmable lights that can be rotated to control the inten-
sity and direction of the two light beams. After use, the lights slide inside the
chassis to store conveniently away. The JG 8LED features long lasting and cool
operating LED lights that should never need replacing. The 8L and 8LM use 7
Watt “night light” style bulbs which install from the front of each light tube as-
sembly. To replace bulbs, unscrew front tube cap and rotate bulb counter clock-
wise.
Voltage Meter (JG 8LM) –The JG 8LM includes a 20 segment Voltage Meter
that indicates levels of incoming AC voltage. This color coded meter displays
safe (green), marginal (yellow) and dangerous (red) levels of incoming voltage.
This meter can help diagnose problems that result from common AC power
sags and swells.
REAR PANEL
AC Outlets –These 8 outlets (NEMA 5-15R) are rated for current loads up to
15 amps per outlet at 120 volts.

Power Cord –The power cord has a third pin safety ground connector. Do not
defeat this feature. Doing so could subject user to a hazardous condition.
INTERNAL PROTECTION COMPONENTS
The JG 8 Series products have a basic level of AC power protection consisting
of a fast acting metal oxide varistor between hot and neutral and a line capacitor
between hot and neutral to reduce high frequency line noise and AC line
surges.
TROUBLE SHOOTING
The JG 8 is well designed and constructed. Every JG 8 is submitted to a full
functional test before being shipped by Juice Goose. It requires neither mainte-
nance nor adjustment. It is unlikely to malfunction. However, there are potential
events to note:
The JG 8 will not come on or turns itself off.
a. Check the status of the power supplied to the unit. Use a voltage meter and/
or polarity tester to examine the status of incoming power.
b. Check that the circuit breaker is not tripped and that the current load on the
unit does not exceed its rated capacity. If the breaker is tripped, turn off the
power switch, remove sufficient current load to reduce the total to no more than
the rated current capacity, wait approximately 30 seconds after the tripping. Re-
set the circuit breaker and turn the power switch back on.
One or more lights will not turn on.
The incandescent bulbs in the JG 8L and JG 8LM have a long but limited ser-
vice life. Especially if only one of those lights does not function unplug the JG
unit, unscrew the cap on the end of the light tube, examine the bulb and replace
as necessary with a 7 watt candelabra based bulb. The lights on the JG 8LED
should last for the service life of the JG unit. If one of those lights does not work
contact Juice Goose for service assistance and possibly factory repair.
NOTE: If necessary, in order to turn off the JG 8, the power cord to the JG 8
can be unplugged from the wall or other power source.
If an observed problem can not be remedied, particularly if the problem seems
severe or dangerous, discontinue use of the JG 8 and contact Juice Goose di-
rectly.
REPAIR
Should your product need service contact Juice Goose for assistance and au-
thorization to return the unit. PLEASE NOTE: a return authorization number is
required in order for the service personnel to correctly and promptly identify,
repair and return your unit.
You may obtain a Return Authorization Number by calling: 713-772-1404 or
sending email to [email protected].

OTHER HIGH QUALITY PRODUCTS
RP Series -The Rackpower 100 and 200 feature a digital voltage / amper-
age power meter in addition to USB power ports on the front and back of
the chassis. Nine AC receptacles on the back are rotated and spaced to
accommodate power adapters.
CQ SERIES –Power sequencing and remote control products. No master
controller is required. Very flexible, economical and easy to install. Models
include rack mount, four circuit and 30 amp designs. Optional remote con-
trols include key or rotary switch.
RT SERIES -Remote control with contact closure without sequencing. The
RT 15 includes optional RX Series power conditioning.
PD SERIES –Custom configured multiple circuit power strips. Three chas-
sis styles offer various options regarding size, number and arrangement of
circuits, length and location of wire harness and mounting configuration.
Select exact configuration with a features menu.
RX SERIES –High voltage surge protection and high frequency line filtra-
tion, performance near that of an isolation transformer, but at a fraction of
the cost and size. Great normal mode and common mode line noise elimi-
nation.
UPS MODELS –Eight models to choose from, including power capacity
from 1,000 VA to 3,000 VA. Rack or tower mount units available in addition
to external battery packs for added run time.
LIGHTNING PROTECTION -Protect external components and head-end
systems from lightning damage. A broad range of devices are available to
protect CCTV, access control, fire alarm, audio and other electronic sys-
tems.
For more information go to www.juicegoose.com.
