JuiceGoose PS1-24 User manual

PS1-24
7320 Ashcroft, Suite 104
Houston, Texas 77081
p: 713-772-1404
f: 713-772-7360
e: [email protected]
www.juicegoose.com
OWNERS MANUAL
24 VAC
90 WATT
WALL MOUNTED
CCTV POWER SUPPLY
06-06
PS1-24 Owners Manual.pub
page 1 Tuesday, September 26, 2006 13:27

CONGRATULATIONS
You have purchased a practical source for CCTV power. The Juice Goose PS1-24 is a
wall mountable 24 VAC power supply for attachment to a single high power consumption
camera.
FEATURES SUMMARY
PS1 features include:
WALL MOUNT NEMA 1 ENCLOSURE
EXTERNAL MOUNTING BRACKET
POWER CONNECTION FOR 1 CAMERA
3.75 AMPS @ 24VAC
MASTER POWER FUSE
SAFETY PRECAUTIONS
The PS1 is designed to operate with 120VAC, 60 Hz input. Operation with 220 or 240
volts will damage the unit and possibly cause personal injury.
CAUTIONS
1. The PS1 should always be grounded. Defeating the unit’s grounding capability
could create a hazard.
2. There are no user serviceable parts inside the PS1. Do not attempt service
yourself. Contact Juice Goose as directed in this manual if service is required.
3. Do not expose the PS1 to moisture. Avoid severe physical impacts to the
unit.
DISCLAIMER
Juice Goose shall under no circumstances be held responsible for any loss, damage or
injury resulting from the use of the PS1 in a manner inconsistent with any of the proce-
dures outlined in this document. The user is responsible for determining whether this
product is appropriate for the intended application.
Juice Goose is not responsible for any indirect, secondary or ancillary loss or damage,
including personal injury, loss of or damage to property or loss of income resulting
from the operation or failure of this unit.
MAIN POWER FUSE
The PS1-24 is equipped with a current overload fuse on the 120 volt, power input, side of
the transformer. A maximum 1 amp fuse should be used in this product.
INSTALLATION
1. Make sure the PS1 is NOT connected to power when installing it and making connec-
tion to a camera.
2. The PS1 is to be hardwired by a qualified electrician.
PS1-24 Owners Manual.pub
page 2 Tuesday, September 26, 2006 13:27

3. Remove desired “knock out” to route utility power input and camera power output leads
into the enclosure. Mount the PS1 in the desired location using the four screw holes on the
mounting bracket.
4. Power Leads
The blue wire leads on the transformer are to be connected to 120 volt, utility power. One
blue lead is connected to the fuse holder. Connect the fuse holder lead and one blue lead to
main utility hot and neutral leads. Connect the utility ground (green) lead to the ground lug
on the chassis. Connect the red, 24 volt output, leads to the camera.
5. Replace front panel and secure with the 4 screws provided.
6. Fuse Replacement –Always turn off power to the PS1 before replacing the fuse. Use a
maximum 1 amp fuse in the PS1-24.
TROUBLE SHOOTING
Before trouble shooting this power supply disconnect the power. If there is no power output check the
fuse and power connections, both input and output.
REPAIR
Should your PS1 need service contact Juice Goose for assistance and authorization to return the unit.
PLEASE NOTE: a return authorization number is required in order for the service personnel to correctly
and promptly identify, repair and return your unit.
You may obtain a Return Authorization Number by calling: 713-772-1404 or sending email to
[email protected].
DIMENSIONS (INCHES) 6.0 x 6.0 x 4.0
WEIGHT (LBS) 7
POWER INPUT 120 VAC, 60Hz
POWER OUTLETS RED WIRE LEADS
CURRENT CAPACITY .75 Amps @ 120 VAC
3.75 AMPS @ 24 VAC
CURRENT OVERLOAD PROTECTION 1 AMP MASTER CIRCUIT
CHASSIS DESIGN NEMA 1 METAL ENCLOSURE
CHASSIS FINISH POWDER COAT ENAMEL –TAN
SPECIFICATIONS
PS1-24 Owners Manual.pub
page 3 Tuesday, September 26, 2006 13:27

POWER FACTS AND CALCULATIONS
TERMINOLOGY
& RELATIONSHIPS
Amperage is a measure of current flow. (Similar to capacity or volume
of flow.) A power supply with greater amperage capacity than the current
demand of the equipment being powered is OK.
Amps = Watts / Volts (100 Watts at 24 Volts = 4.17 Amps)
Current (Amps) = Voltage / Resistance(Ohms)
Impedance in an AC circuit is very similar to resistance in a DC circuit
and is often used interchangeably.
Resistance is a force that opposes current flow in a circuit.
Voltage is a measure of potential electromotive force (similar to pres-
sure).
A power supply with higher voltage than recommended for a camera is
NOT OK.
Voltage Drop/100 Feet = .2 x Amperage x 1.26 (AWG-10)
Watts = Volts x Amps(24 Volts with 4.17 Amps = 100 Watts)
PS1-24 Owners Manual.pub
page 4 Tuesday, September 26, 2006 13:27

0.5 1.0 2.0 4.0 10.0
Distance
(Feet)
25 22 22 22 20 18
50 22 22 20 18 14
100 22 20 18 16 12
200 22 18 16 12 -
300 20 16 14 10 -
400 18 16 12 10 -
500 16 14 12 --
0.5 Amps 1.0 Amps 2.0 Amps 4.0 Amps 10.0 Amps
AWG
10 .10 .20 .40 .80 2.00
12 .16 .32 .64 1.25 3.2
14 .25 .50 1.0 2.0 5.0
16 .40 .80 1.60 3.20 8.00
18 .64 1.32 2.64 5.28 12.80
20 1.01 2.02 4.04 8.08 20.20
22 1.60 3.20 6.40 12.80 32.00
VOLTAGE DROP
MINIMUM WIRE GAUGE FOR
MAXIMUM 3.2 VOLT DROP
This table lists the required minimum wire size necessary to complete a paired
wire run of the stated length and experience no more than a 3.2 volt drop be-
tween the power supply and the camera or other powered device. In the exam-
ple above, should the cable run have been 200 feet rather than 100, with a 2
amp load, in order to not have a drop in excess of 3.2 volts, the wire size would
need to be at least 16 AWG. An alternative solution would be to power the load
with an original voltage of 28 VAC.
This chart illustrates voltage drop per 100 feet of paired wire as a function of
wire gauge and load current. By matching load current (Amps) across the top of
the chart with wire gauge (AWG) down the left side of the chart, one can deter-
mine voltage drop per 100 feet of paired wire run. Note: at 24 volts, 2 amps = 48
watts. For that size load the voltage drop for 100 feet of 18AWG would be 2.64
volts.
PS1-24 Owners Manual.pub
page 5 Tuesday, September 26, 2006 13:27

JUICE GOOSE
CCTV POWER SUPPLIES
PART NUMBER DESCRIPTION
RPS16-RX-24-12 AC PROTECTION, 24VAC + 12 VDC, 16 CAMERAS
RPS16-RX-24-24 AC PROTECTION, 24VAC + 24VAC, 16 CAMERAS
RPS16-RX-24-0AC PROTECTION, 24VAC, 8 CAMERAS
RPS16-RX-12-12 AC PROTECTION, 12VDC + 12 VDC, 16 CAMERAS
RPS12-RX-12-0AC PROTECTION, 12 VDC, 8 CAMERAS
RPS16-0-24-12 24VAC + 12 VDC, 16 CAMERAS
RPS16-0-24-24 24VAC + 24VAC, 16 CAMERAS
RPS16-0-24-024VAC, 8 CAMERAS
RPS16-0-12-12 12VDC + 12 VDC, 16 CAMERAS
RPS16-0-12-012 VDC, 8 CAMERAS
PS1-24 24VAC, 90W, 1 CAMERA.
PS1-24-424VAC, 90W, 1 CAMERA, NEMA 4 ENCLOSURE
PS4-24 24VAC, 90W, 4 CAMERAS, INCL. POWER CORD
PS4-24-424VAC, 90W, 4 CAMERAS, NEMA 4 ENCLOSURE
PS4-24-300 24 or 28VAC, 300W, 4 CAMERAS, INCL. POWER CORD
PS4-24-300-424 or 28 VAC, 300W, 4 CAMERAS, NEMA 4 ENCL.
PS8-24 24VAC, 90W, 8 CAMERAS, INCL. POWER CORD
PS8-24-424VAC, 90W, 8 CAMERAS, NEMA 4 ENCLOSURE
PS8-24-300 24 or 28VAC, 300W, 8 CAMERAS, INCL. POWER CORD
PS8-24-300-424 or 28VAC, 300W, 8 CAMERAS, NEMA 4 ENCL.
RACK MOUNTED
WALL MOUNTED
For additional Juice Goose products log on to our web site
www.juicegoose.com
or call
713.772.1404
PS1-24 Owners Manual.pub
page 6 Tuesday, September 26, 2006 13:27
