JUKI 0040113520 User manual

1) Take out main body 2of switch from switch case 1.
1) 从开关箱 1上卸下开关主体 2。
POWER SWITCH WIRING INSTRUCTIONS /
电源开关配线说明书
No.00
40113520
Connecting the power cable / 电源电缆线的连接
2) Make two holes, with a sharp instrument, in the cen-
ter of grommet 3located the lower part of the switch
case.
* Be careful not to prick your hand on the sharp instru-
ment when making the holes.
2) 有关开关箱下部的蒙蔽嵌管 3，用带尖的东西一扎蒙
蔽嵌管的中心就可以开孔。（2 处）
※ 开孔时，请注意不要扎到手。
2
1
3

Copyright C2011 JUKI CORPORATION
• All rights reserved throughout the world.
•
版权所有，严禁擅自转载、翻印本书的内容。
Please do not hesitate to contact our distributors or agents in your area for further information when
necessary.
＊
The description covered in this instruction manual is subject to change for improvement of the
commodity without notice.
对本产品如有不明之处，请向代理店或本公司营业部门询问。
※ 本使用说明书中的规格因改良而发生变更，请订货时确认。
11 · 08 Printed in China
SEWING MACHINERY BUSINESS UNIT
2-11-1, TSURUMAKI, TAMA-SHI,
TOKYO, 206-8551, JAPAN
PHONE : [phone]
FAX : [phone]
http://www.juki.com
3) Connect the cable coming from the control box and the one coming from the plug to main body 2of the switch as
shown in the figure.
3) 如图所示那样，把从电气箱和插头连接过来的电缆连接到开关主体 2上。
Cable coming from the control box / 从电气箱连接出来的电缆
Brown: Switch terminal 1 / 褐色 : 开关端子 1
Light blue: Switch terminal 3 / 浅蓝色 : 开关端子 3
Cable coming from the plug / 从插头连接出来的电缆
Brown: Switch terminal 2/褐色 : 开关端子 2
Light blue: Switch terminal 4/浅蓝色 : 开关端子 4
4) Connect the cables (green/yellow) coming from the
control box and coming from the plug to grounding
terminal 4of the switch case as shown in the figure at
left.
Install main body 2of the switch to case 1.
(The main body of the switch cannot be installed to the
case if it is oriented upside down.)
Attach two cable clip bands 5supplied with the unit as
illustrated in the figure.
4) 如左图所示那样，请把从电气箱和插头连接过来的地
线（绿／黄）连接到开关箱的地线端子 4上。
把开关主体 2安装到开关箱 1上。
（安装时请注意不要把开关主体的安装方向上下颠
倒。）
如图所示那样安装附属的扎线带 5。（2 处）
1
4
2
Brown
褐色
Light blue
浅蓝色 Brown
褐色
Light blue
浅蓝色
Control box /
电气箱
Plug /
插头
5
