Julabo FL300 User manual

19514818-V1.doc 17.01.13
Operating manual
Recirculating Coolers
FL300
FL601
English
RS232 ALARM
FL300

2
Congratulations!
You have made an excellent choice.
JULABO thanks you for the trust you have placed in us.
This operating manual has been designed to help you gain an understanding of the principles of
operating and possibilities of our circulators. For optimum utilization of all functions, we recommend
that you thoroughly study this manual prior to beginning operation.
The JULABO Quality Management System
Temperature control devices for research and industry are developed,
produced, and distributed according to the requirements of
ISO 9001:2008. Certificate Registration No. 01 100044846
Unpacking and inspecting
Unpack the recirculating cooler and accessories and check for damages incurred
during transit. These should be reported to the responsible carrier, railway, or postal
authority, and a request for a damage report should be made. These instructions
must be followed fully for us to guarantee our full support of your claim for protecting
against loss from concealed damage. The form required for filing such a claim will be
provided by the carrier.

3
EC Conformity
The products described in the operating instructions conform to the
requirements of the following European guidelines:
Directive of the European Parliament and of the Council on the approximation of the laws of
the Member States relating to machinery.
Low voltage regulations with respect to legal harmonization of the member countries
concerning electric devices for use within certain voltage limits.
EMC guideline with respect to legal harmonization of the member countries concerning
electromagnetic compatibility.
JULABO GmbH
Eisenbahnstr. 45
77960 Seelbach / Germany

4
TABLE OF CONTENTS
1. Intended use................................................................................................................... 6
1.1. Description ........................................................................................................... 6
2. Operator responsibility – Safety instructions................................................................... 6
2.1. Disposal.............................................................................................................. 10
3. Technical specifications................................................................................................ 11
4. Safety notes for the user............................................................................................... 17
4.1. Explanation of safety notes ................................................................................ 17
4.2. Explanation of other notes.................................................................................. 17
4.3. Safety instructions.............................................................................................. 18
5. Installation..................................................................................................................... 20
5.1. Tubing ................................................................................................................ 23
6. Operating controls and functional elements.................................................................. 24
7. Operating procedures................................................................................................... 26
7.1. Bath fluids........................................................................................................... 26
7.2. Power connection............................................................................................... 27
7.3. Filling.................................................................................................................. 28
7.4. Switching on / Start - Stop.................................................................................. 29
7.5. Setting the temperatures.................................................................................... 30
7.6. AUTOSTART ON / OFF..................................................................................... 31
7.7. Remote control: activate – deactivate ................................................................ 32

5
8. Safety installations.........................................................................................................33
8.1. Excess temperature protection............................................................................33
8.2. Low level protection ............................................................................................33
9. Troubleshooting guide / Error messages.......................................................................34
10. Electrical connections............................................................................................36
11. Remote control......................................................................................................37
11.1. Setup for remote control......................................................................................37
11.2. Communication with a PC or a superordinated data system...............................38
11.3. List of commands................................................................................................40
11.4. Status messages.................................................................................................41
11.5. Error messages...................................................................................................41
12. Cleaning / repairing the unit ..................................................................................42
13. Adequate storing of operating manual ..................................................................44
14. Draining.................................................................................................................45
15. Warranty conditions ..............................................................................................46

6
1. Intended use
JULABO recirculating coolers have been designed for temperature application to specific fluids. The
pump connections can be used for cooling applications in an external circuit at a constant
temperature.
JULABO water baths are not suitable for direct temperature control of foods, semi-
luxury foods and tobacco, or pharmaceutical and medical products. Direct temperature
control means unprotected contact of the object with the bath medium (bath fluid).
1.1. Description
PID1
RS232
The recirculating coolers are operated via the splash-proof keypad. The
implemented microprocessor technology allows to set and to store the setpoint that
can be indicated on the LED temperature display.
The PID temperature regulation is used to withdraw heat from the bath fluid by
means of the cooling machine and to automatically regulate the required need.
Electrical connections:
1. The serial interface RS232 allows modern process technology without
additional interface.
2. Alarm output for external alarm message.
2. Operator responsibility – Safety instructions
The products of JULABO ensure safe operation when installed, operated, and maintained according
to common safety regulations. This section explains the potential dangers that may arise when
operating the circulator and also specifies the most important safety precautions to preclude these
dangers as far as possible.

7
The operator is responsible for the qualification of the personnel operating the units.
The personnel operating the units should be regularly instructed about the dangers involved with
their job activities as well as measures to avert these dangers.
Make sure all persons tasked with operating, installing, and maintaining the unit have read and
understand the safety information and operating instructions.
When using hazardous materials or materials that could become hazardous, the unit may be
operated only by persons who are absolutely familiar with these materials and the unit. These
persons must be fully aware of possible risks.
If you have any questions concerning the operation of your unit or the information in this manual,
please contact us!
Contact JULABO GmbH
Eisenbahnstraße 45
77960 Seelbach / Germany
Tel. [phone] [email protected]
Fax [phone] www.julabo.de
Safety recommendations for the operator
You received a product conceived for industrial use. Nevertheless, avoid strikes to the housing,
vibrations, damages to the keypad foil (keys, display) or contamination.
Make sure the product is regularly checked for proper condition. Regularly check (at least every
2 years) the proper condition of the mandatory, warning, prohibition and safety labels.
Take care that the mains supply features a low impedance to avoid any negative affects on the
instrument being operated in the same mains.
This unit is designed for operation in a controlled electromagnetic environment. This means that
transmitting devices (e.g. cellular phones) should not be used in the immediate vicinity. Magnetic

8
radiation may influence other units with components susceptible to magnetic fields (e.g. a
monitor). We recommend to keep a minimum distance of 1 m.
Permissible ambient temperature: max. 40 °C, min. 5 °C.
Permissible relative air humidity: 50 % (40 °C).
Do not store in an aggressive atmosphere. Protect from contaminations.
Do not expose to sunlight.
Appropriate Operation
Only qualified personnel is authorized to perform configuration, installation, maintenance and repairs
of the water bath.
Routine operation can also be carried out by untrained personnel who should however be instructed
by trained personnel.
Use
For the use according to the intended purpose, special material requirements have to be respected
(bath fluids). Only use non-acid and non corroding materials.
Observe all warnings for the used materials (bath fluids) and the respective instructions (safety data
sheets). Only use the unit in well ventilated areas. (see page 20).
The recirculating coolers are not for use in explosive atmosphere

9
When using hazardous materials or materials that could become hazardous, the operator must affix
the enclosed safety labels (1 + 2) to the front of the unit so they are highly visible:
1
Warning label W00: Colors: yellow, black
Danger area. Attention! Observe instructions.
(operating manual, safety data sheet)
2
or
Mandatory label M018: Colors: blue, white
Carefully read the user information prior to beginning operation.
Scope: EU
2
Semi S1-0701 Table A1-2 #9
Carefully read the user information prior to beginning operation.
Scope: USA, NAFTA
Observe the instructions in the manuals for instruments of a different make that you connect to the
circulator, particularly the corresponding safety instructions. Also observe the pin assignment of
plugs and technical specifications of the products.

10
2.1. Disposal
This unit contains the refrigerants R134a or R404A, which at this time are not considered harmful to
the ozone layer. However, over the long operating period of the unit, disposal rules may change.
Therefore, only qualified personnel should handle the disposal.
Valid in EU countries:
Directive 2002/96/EC of the European Parliament and of the Council of 27 January
2003 on waste electrical and electronic equipment (WEEE).
This directive requires electrical and electronic equipment marked with a
crossedout trash can to be disposed of separately in an environmentally friendly
manner.
Contact an authorized waste management company in your country.
Disposal with household waste (unsorted waste) or similar collections of municipal
waste is not permitted!

11
3. Technical specifications
Recirculating Cooler FL300
Working temperature range °C -20 ... +40
Temperature stability °C ±0.5
Temperature selection: digital
via key pad indication on LED-DISPLAY
remote control via personal computer indication on monitor
Temperature indication: LED-DISPLAY
Resolution °C 0.1
Temperature control PID 1
Temperature sensor Pt 100
Excess temperature protection 85 °C - fixed value
Low liquid level protection float switch
Electrical connections:
Computer interface RS232
Alarm output for external alarm signal
Circulating pump:
discharge, max.at 0 bar l/min 15
pressure, max. at 0 Liters bar 0,35

12
Recirculating Cooler FL300
bar
Filling level indicator sight glass
Filling volume from ... to Liters 3 ... 4.5
Dimensions (WxLxH) cm 25x50x60
Weight kg 39
Ambient temperature range °C 5 ... 40
Return flow temperature °C 80 max.
IP class according to IEC 60 529 IP 21
Cooling compressor 1- stage / air cooled
Refrigerant R134a
Cooling capacity (at A, B, C) °C +20 +10 0 -10 -20
Medium: Mixture water-glycol kW 0.3 0.25 0.2 0.15 0.1
AMains power connection 230 V/50 Hz V/ Hz 207-253 / 50
Current input at 230 V A 3.0
BMains power connection 208 - 220 V/60 Hz V/ Hz 197 - 242 / 60
Current input at 208V / 220 V A 3.0 / 3.0
CMains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current input at 115 V A 6.0

13
Recirculating Cooler FL300
Cooling capacity (Dat 200 V/50 Hz) °C +20 +10 0 -10 -20
Medium: Mixture water-glycol kW 0.3 0.25 0.2 0.15 0.06
Cooling capacity (Dat 200 V/60 Hz) °C +20 +10 0 -10 -20
Medium: Mixture water-glycol kW 0.3 0.25 0.2 0.15 0.09
DMains power connection 200 V/50-60 Hz V/ Hz 190-254 / 50
190-244 / 60
Current input at 200 V A 3.0
All measurements have been carried out at: rated voltage and frequency,
ambient temperature: 20 °C

14
Recirculating Cooler FL601
Working temperature range °C -20 ... +40
Temperature stability °C ±0.5
Temperature selection: digital
via key pad indication on LED-DISPLAY
remote control via personal computer indication on monitor
Temperature indication: LED-DISPLAY
Resolution °C 0.1
Temperature control PID 1
Temperature sensor Pt 100
Excess temperature protection 85 °C - fixed value
Low liquid level protection float switch
Cooling capacity °C +20 +10 0 -5 -20
Medium: Mixture water-glycol kW 0.6 0.5 0.4 0.33 0.2
Cooling compressor 1- stage / air cooled
Refrigerant R404A
Electrical connections:
Computer interface RS232
Alarm output for external alarm signal

15
Recirculating Cooler FL601
Circulating pump:
discharge, max.at 0 bar l/min 23
pressure, max. at 0 Liters bar 1.0
bar -----
Filling level indicator sight glass
Filling volume from ... to Liters 5.5 ... 8
Dimensions (WxLxH) cm 32x50x60
Weight kg 48
Ambient temperature range °C 5 ... 40
Return flow temperature °C 80 max.
IP class according to IEC 60 529 IP 21
Mains power connection 230 V/50 Hz V/ Hz 207-253 / 50
Current input at 230 V A 4.6
Mains power connection 208 - 220 V/60 Hz V/ Hz 197 - 242 / 60
Current input at 208V / 220 V A 5.0
Mains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current input at 115 V A 9.1
All measurements have been carried out at: rated voltage and frequency,
ambient temperature: 20 °C

16
Warning functions and safety installations
Excess temperature protection 85 °C - fixed value
Low liquid level protection float switch
Alarm message optical + audible (permanent)
Excess temperature - Warning function 75 °C
Overload protection for compressor and pump motor
Classification according to DIN 12876-1 class I
Environmental conditions according to IEC 61 010-1:
Use only indoor.
Altitude up to 2000 m - normal zero.
Ambient temperature: +5 ... +40 °C
Air humidity:
Max. rel. humidity 80 % for temperatures up to +31 °C,
linear decrease down to 50 % relative humidity at a temperature of +40 °C
Max. mains fluctuations of ±10 % are permissible.
The unit corresponds to Class I
Overvoltage category II
Pollution degree 2
Caution:
The unit is not for use in explosive environment.
Standards for interference resistance according to EN 61326-1
This unit is an ISM device classified in Group 1 (using high frequency for internal purposes) Class A
(industrial and commercial range).

17
4. Safety notes for the user
4.1. Explanation of safety notes
In addition to the safety warnings listed above, warnings are posted throughout the
manual. These warnings are designated by an exclamation mark inside an equilateral
triangle. “Warning of a dangerous situation (Attention! Please follow the
documentation).”
The danger is classified using a signal word.
Read and follow these important instructions.
Warning:
Describes a possibly highly dangerous situation. If these instructions are not followed,
serious injury and danger to life could result.
Caution:
Describes a possibly dangerous situation. If this is not avoided, slight or minor injuries
could result. A warning of possible property damage may also be contained in the text.
Notice:
Describes a possibly harmful situation. If this is not avoided, the product or anything in
its surroundings can be damaged.
4.2. Explanation of other notes
Note!
Draws attention to something special.
Important!
Indicates usage tips and other useful information.

18
4.3. Safety instructions
Follow the safety recommendations to prevent damage to persons or property.
Further, the valid safety instructions for working places must be followed.
Only connect the unit to a power socket with earthing contact (PE – protective
earth)!
The power supply plug serves as a safe disconnecting device from the line and
must always be easily accessible.
Place the instrument on an even surface on a pad made of non-inflammable
material.
Do not stay in the area below the unit.
Make sure you read and understand all instructions and safety precautions listed
in this manual before installing or operating your unit.
Never operate the unit without bath fluid in the bath.
Do not drain the bath fluid while it is hot or cold!
Check the temperature of the bath fluid prior to draining (by switching the unit on
for a short moment for example).
Use suitable connecting tubing.
Make sure that the tubing is securely attached.
Avoid sharp bends in the tubing, and maintain a sufficient distance from
surrounding walls.
Regularly check the tubing for material defects (e.g., for cracks).
Never operate damaged or leaking equipment.
Always turn off the unit and disconnect the mains cable from the power source

19
before performing any service or maintenance procedures, or before moving the
unit.
Always turn off the unit and disconnect the mains cable from the power source
before cleaning the unit.
Always empty the bath before moving the unit.
Transport the unit with care.
Sudden jolts or drops may cause damage in the interior of the unit.
Observe all warning labels.
Never remove warning labels.
Never operate equipment with damaged mains power cables.
Repairs are to be carried out only by qualified service personnel.
Risk of injury for hands. Close cover carefully.
Some parts of the bath tank and the pump connections may become extremely
cold during continuous operation. Therefore, exercise particular caution when
touching these parts.

20
5. Installation
Place the unit on an even surface on a base made of
nonflammable material.
Cooling machine, pump motor and electronics produce intrinsic
heat that is dissipated via the venting openings.! Never cover
these openings!
Keep at least 20 cm of open space on the front and rear venting
grids.
The place of installation should be large enough and provide
sufficient air ventilation to ensure the room does not warm up
excessively because of the heat the instrument rejects to the
environment. (Max. permissible ambient temperature: 35 °C).
For a fault (leakage) in the refrigeration system, the standard EN
378 prescribes a certain room space to be available for each kg
of refrigerant.
The necessary amount of refrigerant is specified on the type
plate.
> For 0.25 kg of refrigerant R134a, 1 m3 of space is required.
> For 0.52 kg of refrigerant R404A, 1 m3 of space is required.
