Julian Bowen CHE201 User manual

Ø140cm
75cm
People Required to Assemble
ASSEMBLY
INSTRUCTIONS
Round Glass 140cm
Approximate Assembly Time Tools Required
0.5hr
Before you start...
Please carefully unpack and lay out all of the component parts to ensure nothing
is missing and to check each component for any obvious damage.
Should you identify any concerns at this stage please contact the retailer from
whom this product was purchased. Please quote your order number, details of
your issue, the product code, and the batch number from the cartons which will
help to resolve your issue as quickly as possible.
Version Number - 1.0 Product Code - CHE201
No Additional
Tools Required

No Additional
Tools Required

Please check all hardware matches the list below. Should
you notice any are missing please contact your retailer.
We strongly advise that you do not use Power Tools, such as
drills or electric screwdrivers during the assembly as this
may cause irreparable damage and will invalidate your
warranty.
A B C
T3.0mm x Ø15mm
Bump On
3/8" x OD25 x T1mm
Flat Washer
3/8"x OD14 x T8mm
Hexagon Nut
x4 x4 x4
3/8" Ring Spanner x1
D

PARTS
01
07
06
06
03
(4x)
08
02 12
04 09
11
10
05
05
05
05
Please ensure you carefully check all the pieces, should you have any
concerns please contact the retailer before assembly commences.
Please have your order number, details of the issue, the product code,
and the batch number from the cartons as this will help us to resolve
your issue much faster.
1
23
4

ASSEMBLY ADVICE
Please take the time to carefully read through these instructions
before you commence.
Keep these instructions for future reference.
We advise that the product is assembled in the room it is intended for.
We advise that you keep the hardware in a bowl during assembly to
avoid losing anything.
We strongly recommend that you keep children away from the work
area.
Small component parts could choke a child if swallowed.
We recommend you use a sheet or blanket to protect both floor and
product through the assembly stages.
This product is heavy, and we recommend a 2 person lift to avoid
personal injury or damage to the product.
Never push or pull the product as this could cause both personal injury
or irreparable damage to product or floor.
We have tried to make this piece of furniture easy to assemble if the
instructions are followed carefully.
In the unlikely event that you have problems with assembling the
product or have missing or damaged parts, please contact your
retailer and we will assist them in rectifying the problem as quickly as
possible.
Please remember we strongly urge you DO NOT use power tools such
as drill or electric screwdrivers as this could cause irreparable damage
to your product and will invalidate your warranty.

2
1
2
C4
32
B
4
D

4
3
180°
A
1

GENERAL CARE & MAINTENANCE
We advise that when cleaning the product that a damp cloth is used.
Avoid the use of all household cleaners and abrasive.
Never push or drag the furniture.
Never attempt to move the furniture when fully loaded.
We advise that periodically all fixing are re-tightened.
