Jun Shade JSR-4300 User manual

0
NO
1 2 3
Model . JSR - 4300
RF REMOTE CONTROLLER
1
3V
Operationg Voltage
SPECIFICATION
Curtain Motor
RF Receiver
HOW TO ERASE SET-UP CHANNEL
HOW TO SET-UP
Operationg Distance Within 1km
Operationg Frequency 447.775 MHz or
433.92 MHz
Radio Wave type
Wireless Standard
F10
Communication System
Wireless device for wireless
minimal output
1 Way RF
1 2 3
0
NO
Curtain motor : Put 1st terminal of DIP switch to "ON". The LED of the curtain motor blinks when you do this.
Receiver : If you release PROGbutton after pressing it for 2 seconds, the Red LED blinks.
1. Set installed curtain motor or receiver to Set-Up mode
2. Select desired any channel by button. The number of the desired channel is indicated by LED Light comes ‘ON’
3. Press PROG Button on the back of Controller for 2 seconds.
1. Turn NO.1 dip S/W to ‘on’, right side, LED in motor blinks.
4. If Remote Controller complete Set-Up correctly, the buzzer sound once.
Curtain Motor : Buzzer sounds once
RF Receiver : Red LED Light comes ‘ON’
5. Turn the 1st terminal of the DIP switch to "OFF". Then, if the LED of the curtain motor lights ‘ON’.
The Remote controller Set-Up is finished.
6. Set the rest of the channels in the same way.
RF Remote Controller retains the last selected channel.
Each Set-Up channel is memorized for collective control without additional Set-Up Procedure.
2. After selecting the applied channel, press PROG button for 2 seconds. If erasing completes correctly,
the buzzer sounds two times from motor and controller.
1. Red LED Light comes off when you press PROG button for 2 seconds and take off.
2. Press PROG button for 2 seconds after selecting the applied channel.
If erasing completes correctly, the buzzer sounds two times from Romote controller & Red LED L ight comes off.
( Caution : If there are remained Set-Up channel in Remote Controller, Red LED Light keeps ‘ON’)
