Juniper FLUTES LYDIAN 8 IN User manual

8 IN
12 IN
24 IN
36 IN
FLUTES LYDIAN Pendant
Remote Installation Guide
SHOWN ARE EXAMPLES OF CONFIGURATION POSSIBLITIES. SPECIFIC FIXTURE CONFIGURATION MAY VARY.
8 IN, OAK WOOD ACCESSORY
1

WARNING
A LICENSED ELECTRICIAN SHOULD PERFORM INSTALLATIONIN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE (NEC) AND RELEVANT LOCAL CODES.
DISCONNECT MAIN POWER AT THE SOURCE PRIOR TO INSTALLATION.
INSTRUCTIONS MEANT FOR A REMOTE CLASS 2 DRIVER.
Canopy
Set screw
Cover plate
1/8" IPS x 1" length
threaded nipple
Top cap
1/8" IPS nut
1/8" IPS nut
Set screw
FIGURE 5
Bottom cap
Power cord
from fixture
Canopy
Cap screw
Set screw
POWER FEED OPTIONS
STEP 1A: JUNCTION BOX COVER PLATE INSTALLATION INSTRUCTIONS
FIGURE 1
FIGURE 2
CEILING MOUNTED
FOR FIXTURE MOUNTED DIRECTLY TO
THE CEILING.
SEE STEP 1B FOR DETAILED
INSTALLATION AND WIRING
INFORMATION.
JUNCTION BOX MOUNTED
FOR FIXTURES WIRED TO A JUNCTION
BOX.
SEE
STEP 1A FOR DETAILED INSTALLATION
AND WIRING INFORMATION.
1 2
3
4
Pass low voltage wires from junction box through cross bar and
through 1/8" IPS x 1" length threaded nipple attached to cover
plate as shown. Screw 1/8" IPS into the crossbar to connect cover
plate to crossbar.
FIGURE 3
Attach the crossbar to the junction box using provided screws.
FIGURE 4
Loosen cap screw in bottom cap to release the bottom cap.
Pass power cord from fixture through the cap and canopy as
shown. Adjust the length of power cord to adjust fixture's drop
height. Tighten set screw after adjusting power cord length.
Attach bottom cap by tightening the cap screw.
Make sure bottom cap and canopy are aligned properly
before securing cap screw.
FIGURE 6
Remove set screws from canopy to release top cap.
Install cover plate on the top cap as shown.
FLUTES LYDIAN PENDANT INSTALLATION GUIDE 2
WWW.JUNIPER-DESIGN.COM | [email protected] | [phone] | 157 WATER STREET SOUTHINGTON, CT 06489

+
-
L
N
INPUT
AC - LINE
AC - NEUTRAL
OUTPUT
REMOTE
LED
DRIVER
Low voltage wires
from LED driver
White lead (+)
from fixture
+ 24VDC lead from
remote driver
- 24VDC lead
from remote
driver
Silver Shielding
(-) from fixture
Set screw
Set screw
Set screw
Canopy
1/8IPS nut
Top cap
Cover plate
FIGURE 9
Set screw
Bottom cap
Power cord
from fixture
Canopy
Cap screw
Set screw
FIGURE 10
Wires from
remote
driver
Wood screw
Washer
2
STEP 1B: CEILING MOUNTING INSTALLATION INSTRUCTIONS
5 6
3
Pass low voltage wires from the remote
driver through the smaller hole in the
top cap. Using provided wood screw
and washer, connect the top cap to
ceiling. Wood screws are provided for
default installation. Alternate screws
may be used at the recommendation
of an electrician.
Loosen cap screw in bottom cap to release the
bottom cap. Pass power cord from fixture through
the cap and canopy as shown. Adjust the length of
power cord to adjust fixture's drop height. Tighten
set screw after adjusting power cord length. Attach
bottom cap by tightening the cap screw.
Make sure bottom cap and canopy are aligned
properly before securing cap screw.
Connect wires according to diagram (wire nuts provided).
Wires to and from the driver are not included.
FIGURE 7
Push wires inside the canopy and use set screws (removed
in first instruction) to connect canopy to cover plate.
FIGURE 8
Remove set screws from canopy to
release the top cap.
1
FIGURE 11
FLUTES LYDIAN PENDANT INSTALLATION GUIDE 3
WWW.JUNIPER-DESIGN.COM | [email protected] | [phone] | 157 WATER STREET SOUTHINGTON, CT 06489

CARE INSTRUCTIONS
Gently wipe with a damp cloth to remove dirt, dust, and fingerprints.
Do not use any chemical cleaning solution.
Use indoors only.
+
-
L
N
INPUT
AC - LINE
AC - NEUTRAL
OUTPUT
REMOTE
LED
DRIVER
Low voltage wires
from LED driver
Silver Shielding
(-) from fixture
- 24VDC lead
from remote driver
+ 24VDC lead from
remote driver
White lead (+)
from fixture
FIGURE 13
Set screw
Set screw
4
5
FIGURE 12
Connect wires according to diagram (wire nuts provided). Wires to and
from the driver are not included.
Push wires inside the canopy and use set screws
(removed in first instruction) to connect canopy to
cover plate.
