Jupiter Avionics JA33-001 User manual

Rev
B Page i
JA33-001
Bluetooth® Transceiver
Installation and Operating Manual
Rev C
Jupiter Avionics Corporation
1959 Kirschner Road
Kelowna BC
Canada V1Y 4N7
Tel: [phone]
Toll-Free: 1 855 478 2232
www.jupiteravionics.com

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page ii
Copyright 2015 Jupiter Avionics Corp.
All rights reserved
Jupiter Avionics Corporation (JAC) permits a single copy of this manual to be printed or downloaded for the express use
of an installing agency. Any such electronic or printed copy of this manual must contain the complete text of this copyright
notice. Any unauthorized commercial distribution of this manual is strictly prohibited. Except as described above, no part
of this manual may be reproduced, copied, transmitted, disseminated, downloaded, or stored in any storage medium for
any purpose without the express prior written consent of JAC.
RECORD OF REVISIONS
Revision
Rev Date
Description
ECR
A
Dec 2015
Initial release, Serial number 1001 and higher.
3819
B
May 2016
Changes to ProCS; updated Connector Map/Interconnect
4225
Prepared:
MPB
Checked:
Approved:
IMPORTANT:
Information in this document is subject to change without notice.
To confirm the current revision status of this manual, visit the JAC website:
www.jupiteravionics.com
CDec 2019 FCC and IC compliance statements added. 6848
JAC
MB
12-03-19 JAC
KDV
12-03-19

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page iii
Table of Contents
SECTION 1 - DESCRIPTION ................................................................................................................................................. 1
1.1 System Overview .................................................................................................................................................... 1
1.2 Features Overview .................................................................................................................................................. 1
1.3 Inputs and Outputs .................................................................................................................................................. 1
1.3.1 Inputs ............................................................................................................................................................... 1
1.3.2 Outputs ............................................................................................................................................................ 2
1.4 Specifications .......................................................................................................................................................... 2
1.4.1 Electrical Specifications................................................................................................................................... 2
1.4.2 Mechanical Specifications ............................................................................................................................... 3
SECTION 2 – INSTALLATION ............................................................................................................................................... 4
2.1 Introduction .............................................................................................................................................................. 4
2.2 Continued Airworthiness ......................................................................................................................................... 4
2.3 Unpacking and Inspecting Equipment..................................................................................................................... 4
2.3.1 Warranty .............................................................................................................................................................. 4
2.4 Installation Procedures ............................................................................................................................................ 4
2.4.1 Installation Limitations ......................................................................................................................................... 4
2.4.2 Cabling and Wiring .............................................................................................................................................. 4
2.4.3 Mechanical Installation ........................................................................................................................................ 5
2.4.4 Post Installation Checks ...................................................................................................................................... 5
2.5 System Operation.................................................................................................................................................... 5
2.5.1 Configuration Operation .................................................................................................................................. 5
2.5.2 Bluetooth® Audio Receive Operation .............................................................................................................. 5
2.5.3 Bluetooth® Serial Data Operation .................................................................................................................... 6
2.6 Adjustments and Configuration using ProCS™ ...................................................................................................... 6
2.6.1 Configuration Cabling Requirements .............................................................................................................. 6
2.6.2 ProCS™ Setup ................................................................................................................................................ 6
2.6.3 Configurable Settings ...................................................................................................................................... 6
2.6.4 JA33-001 Settings ........................................................................................................................................... 6
2.6.5 Aircraft Audio Systems List ............................................................................................................................. 9
2.6.6 Bluetooth® Devices List ....................................................................................................................................... 9
2.6.7 Serial Data Devices List .................................................................................................................................. 9
2.6.8 JA33-001 Connector Maps ............................................................................................................................. 9
2.6.9 Other Configuration Features .......................................................................................................................... 9
2.7 Installation Kit .......................................................................................................................................................... 9
2.7.1 Recommended Crimp tools ........................................................................................................................... 10
2.8 Installation Drawings ............................................................................................................................................. 10
SECTION 3 – OPERATION .................................................................................................................................................. 11
3.1 Introduction ............................................................................................................................................................ 11
3.2 Bluetooth® Operation ............................................................................................................................................. 11
3.3 Bluetooth® Pairing ................................................................................................................................................. 11
3.4 Bluetooth® Status Indicator ................................................................................................................................... 12
Appendix A - Installation Drawings ................................................................................................................................... A1
A1 Introduction ............................................................................................................................................................ A1
A2 Installation Drawings ............................................................................................................................................. A1
Appendix B - Installation Documents ............................................................................................................................... B1
B1 Airworthiness Approval ......................................................................................................................................... B2
B2 Instructions for Continued Airworthiness .............................................................................................................. B2
1.4.3 FCC Compliance Statement............................................................................................................................ 3
1.4.4 IC Compliance Statement ............................................................................................................................... 3
1.4.5 Co-location with Other Transmitters.................................................................................................................. 3

Rev C Page 1
JA33-001 Bluetooth® Transceiver
SECTION 1 - DESCRIPTION
1.1 System Overview
The JA33-001 Bluetooth® Transceiver allows the aircraft audio management system to receive high-quality stereo
audio from a Bluetooth®-enabled device.
The JA33-001 can provide a full duplex Bluetooth interface with a cell phone or mobile device.
The JA33-001 can also act as a Bluetooth®-to-RS-232 interface, allowing a Bluetooth®-enabled device to interact with
an RS-232 device connected to the JA33-001. The JA33-001 provides fully isolated audio output to allow a noise free
installation.
The JA33-001 is set up on a per installation basis using a Configuration Cable and downloading the system
configuration settings from a PC into non-volatile control devices.
1.2 Features Overview
All internal settings are quickly adjusted using Jupiter's proprietary ProCS (Product Configuration Software).
A configuration port is provided for configuration loading.
All audio outputs are floating and balanced.
The JA33-001 provides artificial sidetone generation and microphone voltage biasing for easily cell phone integration.
The JA33-001 contains a Bluetooth® Audio Module and is a Bluetooth® class 3 device with a <10 meters operating
range.
The JA33-001 is a Bluetooth® 3.0 compliant device with the following supported profiles:
•SPP (Serial Port Profile)
•A2DP (Advanced Audio Distribution Profile) Sink or Source
•HFP (Hands Free Profile)
1.3 Inputs and Outputs
Refer to the JA33-001 connector map for the mating connector designators and contact assignments for the
input and output signals.
1.3.1 Inputs
Name
Qty
Type
BLUETOOTH DISABLE
1
Discrete signal
CONFIG DATA TO JA33
1
Data signal
DATA TO JA33
1 Data signal
MODE SELECT
1
Discrete signal
+28 VDC POWER
1
Power Supply
MIC INPUT
1
Audio signal
MUSIC INPUT
1
Audio signal (Configurable via ProCS)

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 2
1.3.2 Outputs
Name Qty Type
BLUETOOTH STATUS ANNUNCIATOR 1 Discrete signal
CONFIG DATA FROM JA33 1 Data signal
MUSIC LEFT 1 Audio signal
MUSIC RIGHT 1 Audio signal
MODE SELECT OUTPUT 1 Discrete signal
RECEIVE OUTPUT 1 Audio signal
DATA FROM JA33 1 Data signal
1.4 Specifications
1.4.1 Electrical Specifications
Power Input
Nominal voltage 28 Vdc
Maximum voltage 30.3 Vdc
Minimum voltage 22.0 Vdc
Emergency voltage 18.0 Vdc
Input current 0.5 A max
1.4.1.1 Audio Performance
Rated Input Level
MIC 0.250 Vrms ± 10%
Music - Rated Input Level 0.400 Vrms ± 10%
Rated Output Power
MUSIC 6.00 Vrms ± 10%
RECEIVE 6.00 Vrms ± 10%
Audio Frequency Response
MUSIC ≤ 3dB from 60 to 20000 Hz
RECEIVE ≤ 3dB from 300 to 6000 Hz
Distortion Characteristics
Distortion at rated power ≤ 10%
Input Impedance
MIC 150 Ω ± 10%
Music 1000 Ω ± 10%
Output Load
Receive Load 600 Ω ± 10%
Music Load 600 Ω ± 10%
Audio Noise Level without Signal
Noise level below rated output ≥ 60 dB
1.4.1.2 Audio Performance, Other
RECEIVE AND MUSIC Output circuitry type Capacitively Coupled
MIC INPUT circuitry type Single Ended

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 3
1.4.1.3 Radio Frequency Performance
RF output power 0 dBm (maximum)
Antenna gain ≤ 1.7 dBi
EIRP ≤ 1.7 dBm
Transmit frequency band 2400 to 2483.5 MHz
Radio performance operation Class 3 radio power mode.
1.4.1.4 Bluetooth Performance
The JA33-001 is always discoverable by Bluetooth® devices when not connected to another Bluetooth
device.
The JA33-001 supports Bluetooth® A2DP, HFP and SPP profiles.
1.4.2 Mechanical Specifications
Height 1.21 in [30.7 mm] maximum
Depth 2.42 in [61.5 mm] maximum
Width 4.52 in [114.8 mm] maximum
Weight 0.31 lb [0.14 kg] maximum
Enclosure Material brushed aluminum with conversion
coating
Enclosure Features RF-Transparent window
Connectors J1 One 15-pin D-Sub male V5 locking
J2 One 4 pole 3.5mm jack
Mounting 4 x 10-32 fasteners
Bonding ≤ 2.5 mΩ
Installation kit part number INST-JA33
Contains Transmitter Module FCC ID: QOQWT32AE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
1.4.3 FCC Compliance Statement
1.4. ,C Compliance Statement
Contains Transmitter Module Industry Canada ID: 5123A-BGTWT32AE
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil est conforme aux normes RSS sans licence d'Industrie Canada. Son fonctionnement est soumis aux
conditions suivantes :
(1) cet appareil ne doit pas causer d'interférences et
(2) doit accepter toute interférence, y compris les interférences pouvant entraîner un fonctionnement indésirable de
xxxl'appareil.
Co-location with Other Transmitters
1.4.5
(QVXUHDOO-$XQLWVDUHLQVWDOOHGZLWKDWOHDVWFPEHWZHHQRWKHU%OXHWRRWK®XQLWVDQGDQWHQQDHIURPRWKHU
WUDQVPLWWLQJHTXLSPHQW

Rev C Page 4
JA33-001 Bluetooth® Transceiver
SECTION 2 – INSTALLATION
2.1 Introduction
This section contains unpacking and inspection procedures, installation information, and post-installation checks.
2.2 Continued Airworthiness
Maintenance of the JA33-001 is on condition only. Scheduled inspection and/or periodic maintenance of this unit is
not required.
2.3 Unpacking and Inspecting Equipment
Unpack the equipment carefully. Check for shipping damage and report any problems to the relevant carrier. Confirm
that the Authorized Release Certificate or Certificate of Conformance is included. Complete the on-line warranty card
from the Jupiter Avionics Corporation (JAC) website – www.jupiteravionics.com.
2.3.1 Warranty
Products manufactured by JAC are warranted to be free of defects in workmanship or performance for 2 years from
the date of installation by an approved JAC dealer or agency. This warranty covers the cost of all materials and labour
to repair or replace the unit, but does not include the cost of transporting the defective unit to and from JAC or its
designated warranty repair centre, or of removing and replacing the defective unit in the aircraft. This warranty does
not cover failures due to abuse, misuse, accident, or unauthorized alteration or repairs.
THIS WARRANTY IS VOID IF THE PRODUCT IS NOT INSTALLED BY AN AUTHORIZED JAC DEALER. If the on-
line warranty card is not completed, the product will be warranted from the date of manufacture.
Contact JAC for return authorization, and for any questions regarding this warranty and how it applies to your unit(s).
JAC is the final arbiter concerning warranty issues.
2.4 Installation Procedures
WARNING: Loud noise can cause hearing damage. Set the headset volume to minimum before
conducting tests, and slowly increase the volume to a comfortable listening level.
CAUTION: The power input circuitry of the unit may be damaged if the installation does not conform to the
wiring instructions in this manual.
2.4.1 Installation Limitations
The JA33-001 may be installed only by following the applicable airworthiness requirements.
2.4.2 Cabling and Wiring
All wire shall be selected in accordance with the original aircraft manufacturer’s maintenance instructions, or AC43.13-
1B Change 1, Paragraphs 11-76 through 11-78. Unshielded wire types shall qualify to MIL-W-22759 as specified in
AC43.13-1B Change 1, Paragraphs 11-85, 11-86, and listed in Table 11-11. For shielded wire applications, use Tefzel
MIL-C-27500 shielded wire with tag ring or equivalent (for shield terminations) to make the most compact and easily
terminated interconnect. Follow the Connector Map in Appendix A of this manual.

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 5
Allow 3” from the end of the shielded wiring to the shield termination to allow the connector hood to be easily installed.
Refer to the Interconnect drawing in Appendix A of this manual for shield termination details. Note that this unit has a
‘clamshell’ hood that is installed after the wiring is complete.
Maintain wire segregation and route wiring in accordance with the original aircraft manufacturer’s maintenance
instructions.
Unless otherwise noted, all wiring shall be a minimum of 24 AWG, except power and ground lines, which shall be a
minimum of 22 AWG. Refer to the Interconnect drawing for additional specifications. Check that the ground
connection is clean and well secured, and that it shares no path with any electrically noisy aircraft accessories such
as blowers, turn-and-bank instruments, or similar loads.
2.4.3 Mechanical Installation
The JA33-001 can be mounted in any attitude and location with adequate space and sufficient clearance for the
connector and wiring harness. It requires no direct cooling.
2.4.4 Post Installation Checks
2.4.4.1 Voltage/Resistance checks.
Do not attach this unit until the following conditions are met:
a) Check P1 pin 1 for +28 Vdc power.
b) Check P1 pin 9 (Power Ground) for continuity to ground (less than 0.5 Ω).
c) Check P1 pin 10 (Chassis Ground) for continuity to ground (less than 0.5 Ω).
d) Check P1 pin 13 (Bluetooth disable) for continuity to ground when switch is closed (less than 0.5 Ω).
e) Check all pins for shorts to ground or adjacent pins.
2.4.4.2 Configuration
Ensure that the JA33-001 contains the correct configuration settings. This may be done at the factory, on the
maintenance bench or in the aircraft before the power on checks are performed. Refer to section 2.5.
2.4.4.3 Power on Checks.
Power up the aircraft’s systems and confirm normal operation of all functions of the JA33-001 (see section 2.5).
a) Unusual buzzes, hums or other background audio are symptomatic of multiple grounds, or noisy external
systems such as blowers or pumps sharing wiring with the audio system.
b) Check that all configurations settings are correct.
When all performance checks are satisfied, complete the necessary regulatory documentation before releasing the
aircraft for service. Refer to Appendix B.
2.5 System Operation
The JA33-001 is a remote mount unit and has no user accessible controls.
2.5.1 Configuration Operation
The JA33-001 accepts commands on the Configuration connector via the configuration cable (JA99-001) and the
configuration tool (ProCS™). Refer to section 2.6 Adjustments and Configuration.
2.5.2 Bluetooth® Audio Receive Operation
The Bluetooth® Audio Input is level controlled and routed to the MUSIC LEFT HI/LO and MUSIC RIGHT HI/LO
outputs.

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 6
2.5.3 Bluetooth® Serial Data Operation
The BLUETOOTH SERIAL DATA IN input is level-translated to RS-232 levels and routed to the DATA FROM JA33
output. The DATA TO JA33 input is routed to the BLUETOOTH SERIAL DATA OUT.
2.6 Adjustments and Configuration using ProCS™
All the JA33-001 internal adjustments are set from the Product Configuration Software ProCS™. Configuration data is
sent to the JA33-001 via the front panel connector (♫/io), using the Configuration Cables and a computer running the
ProCS™ software. For configuration requirements, see section 2.5.1.
For full information on the configuration process, and for installation of ProCS™ on your computer, refer to the
ProCS™ manual on the Jupiter Avionics website - www.jupiteravionics.com/productsoftware.
2.6.1 Configuration Cabling Requirements
To configure the JA33-001, it is necessary to load the Product Configuration Software ProCS™ onto a Windows-
based computer as described in the ProCS™ manual.
The cables required to configure the JA33-001 are not included with the unit.
Cabling option 1:
Quantity Description JAC Part #
1 USB A to RS232 9-Pin Cable CAB-USB-0002
1 Configuration Cable JA99-001
Cabling option 2:
Quantity Description JAC Part #
1 USB A Male to RS232 3.5mm Plug CAB-USB-0006
2.6.2 ProCS™ Setup
The ProCS™ JA33-001 menu item 'ProCS Setup' provides Setup drawings showing the cabling arrangement
for connecting the JA33-001 to a computer running the ProCS™.
2.6.3 Configurable Settings
A standard unit is shipped from the factory with all internal adjustments configured to the default levels. At installation,
it may be desirable to change some of these settings to suit the local operating environment.
Within ProCS™, the configurable settings are grouped together into the following sections:
2.6.4 JA33-001 Settings
The Settings window is divided into five sections:
•the Aircraft Audio System
•the Serial Data Devices
•the JA33-001 Bluetooth® Transceiver adjustments
•the Bluetooth® Transceiver
•the Bluetooth® Device Selection.
Each section is colour-coded to keep the relevant information together.
The Settings window will show different screens for MUSIC TRANSMITTER (A2DP SOURCE) (Fig. 1), Music Sink
(Fig. 2) or Cell Phone (Fig. 3) selection (see below).

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 7
Fig. 1: MUSIC TRANSMITTER (A2DP SOURCE)
Fig. 2: HANDS-FREE + MUSIC RECEIVER (HFP + A2DP)

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 8
2.6.4.1 AIRCRAFT AUDIO SYSTEM SELECTION (Green block)
The appropriate aircraft audio system is selected from a drop-down list at the top of the block, and all relevant configuration
information is added automatically. Other aircraft Audio systems can be added to the list (see section 2.6.5).
2.6.4.2 SERIAL DATA DEVICE (Magenta block)
The appropriate Serial Data Device is selected from a drop-down list at the top of the block, and all relevant configuration
information is added automatically. Other Serial Data Devices can be added to the list (see section 2.6.7).
2.6.4.3 BLUETOOTH® TRANSCEIVER ADJUSTMENTS (Dark blue block)
The blue block refers to the adjustments and settings for the JA33-001.
MUSIC RIGHT LEVEL
The level of the MUSIC RIGHT LEVEL may be adjusted from 1.00 to 5.5 Vrms. (Default 5.5 Vrms)
MUSIC LEFT LEVEL
The level of the MUSIC LEFT LEVEL may be adjusted from 1.00 to 5.5 Vrms. (Default 5.5 Vrms)
MIC BIAS
The MIC BIAS may be adjusted from 0.10 to 6.50 Vrms. (Default 6.00 Vrms)
SIDETONE AUDIO
The SIDETONE AUDIO may be selected as Off or On. (Default Off)
2.6.4.4 BLUETOOTH® TRANSCEIVER (Light blue block)
A custom Bluetooth® device name can be typed in to identify the JA33-001 in the user's cell phone.
A slider is used to set the volume (minimum 0 – maximum 10) to suit the user's preference. (Default 9).
The Bluetooth® Profile is selected as Music Transmitter (A2DP Source) for playing audio from a smartphone or
other music source, or Hands-Free + Music Receiver (HFP + A2DP Sink) for connecting to a cell phone. (A2DP =
Advanced Audio Distribution Profile)
Bluetooth® Security allows the user to select between 'Normal (Connect Anytime)' and 'Secure (User must connect
within 60 seconds of Bluetooth reset)'.
If a device is connected, the 'Clear Pairing' and 'Set Defaults' buttons will be available for use.
If a Status Indicator is installed, the Bluetooth Status Indicator table describes how an indicator lamp will behave at
various stages of the connection process.
2.6.4.5 BLUETOOTH® DEVICE SELECTION (Orange block)
The appropriate Bluetooth® Source is selected from a drop-down list at the top of the block (as shown), and all relevant
configuration information is added automatically. Other Bluetooth® Sources can be added to the list (see section 2.6.6).

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 9
2.6.5 Aircraft Audio Systems List
This is a list of Aircraft Audio Systems, and shows the configuration information that will be added to the JA33-001
Settings page.
If it is desirable to add other Audio systems, click on the Aircraft Audio Systems List. A new audio system and its
parameters can be added by clicking on (the ‘New Aircraft Audio System' button). A new line will be added to the
bottom of the list, and double clicking on each part of the line will highlight it to allow changes. When the relevant
details have been added, use the (‘Save Changes’) or (‘Cancel All Changes’) button as required. The added
system will then appear on the appropriate drop-down menu list.
2.6.6 Bluetooth® Devices List
This is a list of Bluetooth® Sources and the configuration information that will be added to the JA33-001 Settings
page. The list is similar to the Aircraft Audio Systems list, and new Bluetooth® Sources can be added in the same
way.
2.6.7 Serial Data Devices List
This is a list of Serial Data Devices and the configuration information that will be added to the JA33-001 Settings
page. The list is similar to the Aircraft Audio Systems list, and new devices can be added in the same way.
2.6.8 JA33-001 Connector Maps
JA33-001 Connector Maps and Interconnects are included here for information only.
2.6.9 Other Configuration Features
In the JA33-001 Product Information Window, the model number, serial number and check sum of the JA33-001
Bluetooth® Transceiver can be viewed.
2.7 Installation Kit
The kit required to install this unit is not included with the unit.
The installation kit (Part # INST-JA33) consists of the following:
Quantity Description JAC Part #
1 TAG ring CON-5500-0375
1 D-Sub 15-pin connector, hood and 15 crimp pins CON-3420-0015
1 Heat Shrink Tubing WIR-HTSK-0750

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 10
2.7.1 Recommended Crimp tools
Standard D-Sub Crimp Tool Chart
Tool Type
Hand crimping tool
Positioner
Insertion/extractor tool
POSITRONIC
9507-0-0-0
9502-5-0-0
4711-2-0-0
DANIELS
AFM 8
K13-1
91067-2
MIL-SPEC
M22520/2-01
M22520/2-08
M81969/1-02
2.8 Installation Drawings
The drawings and documents required for Installation can be found in Appendix A of this manual.

Rev C Page 11
JA33-001 Bluetooth® Transceiver
SECTION 3 – OPERATION
3.1 Introduction
This section contains the operating instructions for the JA33-001.
The JA33-001 Bluetooth® Transceiver allows the aircraft audio management system access to a non-aviation radio
and Bluetooth® enabled devices.
3.2 Bluetooth® Operation
The JA33-001 is a remote mount unit and has no user accessible controls. However, a Bluetooth® disable input is
provided to allow remote switching to control Bluetooth® connectivity. When a Bluetooth® enabled device such as a
cell phone is introduced into the aircraft, it can be paired with the JA33-001.
The JA33-001 Bluetooth® Transceiver can be configured at installation or in the field by a dealer or installer, using the
Jupiter Avionics Corporation ProCS™ configuration software. At that time, the Bluetooth® volume and profile
(selected for either music input or cellphone use) and the device name can be chosen.
The default Bluetooth® device name is JA33-001-#### where #### represents the serial number of the device.
3.3 Bluetooth® Pairing
Pairing is initiated using your cellphone or other
Bluetooth® enabled device. Refer to your cellphone
operating manual for full pairing information.
Typically, from the phone 'Settings' screen, select
'Bluetooth' and ensure that it is turned on. Then
confirm that the list of discoverable devices includes
JA33-001-### or the selected device name. Select
this device.
The cellphone will pair with the JA33-001 in the
mode selected via ProCS™ - HFP (Hands-Free
Profile), A2DP Sink, or A2DP Source. If necessary,
confirm the mode with the installer.

JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Rev C Page 12
Note: If the Bluetooth® mode of the JA33-001 is changed at a later date, it may be necessary to un-pair the
cellphone and repeat the pairing process to reset to the updated mode of operation.
3.3.1 iPhone Connectivity Configuration
The default setting for Call Audio Routing allows the iPhone to select where to route calls; either to the built-in speaker
or a Bluetooth® headset. This can cause response delays and possible 'dropped calls'.
To ensure that the paired iPhone works more consistently, it should be configured to use the Bluetooth® device as a
default when answering incoming calls.
Example from the iPhone 5:
•Select Settings
•Select Accessibility
•Select Call Audio Routing
•Choose Headset
Example from the iPhone 6:
•Select Settings
•Select General
•Select Accessibility
•Select Call Audio Routing
•Choose Headset
Changing the setting to Headset ensures that the iPhone selects the Bluetooth® device as its first option, but will
revert to the iPhone's built-in speaker if no device is found.
3.4 Bluetooth® Status Indicator
If an optional Bluetooth® Status Indicator is installed, the table below describes how an indicator lamp will behave at
various stages of the connection process.
Light Bluetooth® Connection Status
Flashing Waiting for connection
Steady Connected
Off Bluetooth® off

Rev C Page A1
JA33-001 Bluetooth® Transceiver
Installation and Operating Manual
Appendix A - Installation Drawings
A1 Introduction
The drawings necessary for installation and troubleshooting of the JA33-001 Bluetooth® Transceiver are in this
Appendix, as listed below.
A2 Installation Drawings
DOCUMENT Rev
JA33-001 Connector Map B
JA33-001 Interconnect B
JA33-001 Mechanical Installation C

JUPITER AVIONICS TEMPLATE AUTOCAD PORTRAIT SIZEA REV B.DWT
TITLE
APPROVED
PREPARED
CHECKED
L00N3
NCAGE CODE PART NO. SHEET
DOC NO.
CONFIDENTIAL & PROPRIETARY
TO JUPITER AVIONICS CORP.
Bluetooth Transceiver
JA33-001 1/1
JA33-001 Connector Map Rev B.dwg
TAT
1 2 3 4 5
9 10 11 12
+28 VDC POWER DATA FROM JA33 DATA TO JA33 MIC INPUT HI / MUSIC LEFT INPUT HI
POWER GROUND CHASSIS GROUND SPARE / MUSIC RIGHT INPUT HI MIC INPUT LO / MUSIC INPUT LO
P1
15 PIN FEMALE DMIN
MATING CONNECTOR
VIEW IS FROM REAR OF MATING CONNECTOR
6 7 8
14 1513
MUSIC RIGHT OUTPUT HI MODE SELECT OUTPUT BLUETOOTH STATUS ANNUNCIATOR RECEIVE AND MUSIC LEFT OUTPUT HI
BLUETOOTH DISABLE RECEIVE AND MUSIC LEFT OUTPUT LO MUSIC RIGHT OUTPUT LO
P2
4 POLE MALE 3.5MM STEREO
TIP: TX DATA
1ST RING: RX DATA
2ND RING: GROUND
3RD RING: MODE SELECT
JA99 CONFIGURATION CABLE
MATING PLUG NAMES JA33 SIGNAL NAMES
CONFIG DATA TO JA33
CONFIG DATA FROM JA33
GROUND
MODE SELECT
CONFIGURATION CONNECTOR
1Configurable Contact
1
1 1
JAC
DS
05-19-16
JAC
KDV
05-19-16

JUPITER AVIONICS TEMPLATE AUTOCAD PORTRAIT SIZEA REV B.DWT
TITLE
APPROVED
PREPARED
CHECKED
L00N3
NCAGE CODE PART NO. SHEET
DOC NO.
CONFIDENTIAL & PROPRIETARY
TO JUPITER AVIONICS CORP.
Bluetooth Transceiver
JA33-001 1/6
JA33-001 Interconnect Rev B.dwg
TAT
JA33-001 INTERCONNECT WIRING NOTES
NOTES
All wire size should be 24 AWG min unless otherwise specified. Unshielded wire should be selected
per FAA AC43.13-1B change 1 para 11-76 TO 11-78. Wire types should be in accordance with
MIL-W-22759 as described in FAA AC43.13-1B change 1 para 11-85 and 11-86 and listed in table
11-11 or 11-12. All shielded cable should be in accordance with MIL-DTL-27500 (Revision H or later).
Ground pin to disable Bluetooth operation.
Open-drain output for Bluetooth status indicator lamp.
Outputs are Balanced.
Connection to airframe ground should not exceed 3 FT (0.9 M).
Cable shields at the JA33-001 connector pins should be terminated to airframe ground using a tag ring
P/N: MS27741-3 or equivalent.
2
1.
3
4
5
6
CONNECTOR PIN LEGENDS
LEGEND
N/C No Connection
JAC
DS
05-19-16
JAC
KDV
05-19-16

MUSIC LEFT INPUT HI MUSIC LEFT HI
5
JA33-001 J1 P1 15 PIN FEMALE DMIN
MATING CONNECTOR
JUPITER AVIONICS TEMPLATE AUTOCAD PORTRAIT SIZEA REV B.DWT
TITLE
APPROVED
PREPARED
CHECKED
L00N3
NCAGE CODE PART NO. SHEET
DOC NO.
CONFIDENTIAL & PROPRIETARY
TO JUPITER AVIONICS CORP.
Bluetooth Transceiver
JA33-001 2/6
JA33-001 Interconnect Rev B.dwg
TAT
MUSIC INPUT LO
MUSIC RIGHT INPUT HI
12
11 MUSIC RIGHT HI
DATA FROM JA33
DATA TO JA33 2
3
MODE SELECT OUTPUT 4
DATA TO JRAC
DATA FROM JRAC
+28 VDC POWER +28 VDC POWER1
POWER GROUND 9
CHASSIS GROUND 10
POWER GROUND
22 AWG.
22 AWG.
1A
520 AWG.
6
BLUETOOTH DISABLE 13
BLUETOOTH STATUS ANNUNCIATOR 63
2
LIGHT DIMMER
3
2
J3
N/C
5
OPTION: BLUETOOTH MUSIC TRANSMITTER (SOURCE) WITH SERIAL DATA
(SMART PHONE)
MUSIC SOURCE
MUSIC LO
AUDIO CONTROLLER
JRAC
MUSIC TRANSMITTER PROFILE
MUSIC LEFT OUTPUT HI
MUSIC RIGHT OUTPUT HI 7
8
MUSIC LEFT OUTPUT LO 14
MUSIC RIGHT OUTPUT LO 15
N/C
N/C
N/C
N/C
JAC
DS
05-19-16
JAC
KDV
05-19-16

JA33-001 J1 P1 15 PIN FEMALE DMIN
MATING CONNECTOR
RECEIVE AND MUSIC LEFT OUTPUT LO
RECEIVE AND MUSIC LEFT OUTPUT HI 14
7MUSIC LEFT LO
MUSIC LEFT HI
JUPITER AVIONICS TEMPLATE AUTOCAD PORTRAIT SIZEA REV B.DWT
TITLE
APPROVED
PREPARED
CHECKED
L00N3
NCAGE CODE PART NO. SHEET
DOC NO.
CONFIDENTIAL & PROPRIETARY
TO JUPITER AVIONICS CORP.
Bluetooth Transceiver
JA33-001 3/6
JA33-001 Interconnect Rev B.dwg
TAT
MUSIC RIGHT OUTPUT HI
MUSIC RIGHT OUTPUT LO 8
15 MUSIC RIGHT HI
MUSIC RIGHT LO
DATA FROM JA33
DATA TO JA33 2
3
MODE SELECT OUTPUT 4
DATA TO JRAC
DATA FROM JRAC
AUDIO CONTROLLER
SPARE 11
+28 VDC POWER +28 VDC POWER1
POWER GROUND 9
CHASSIS GROUND 10
POWER GROUND
22 AWG.
22 AWG.
4
1A
520 AWG.
6
BLUETOOTH DISABLE 13
BLUETOOTH STATUS ANNUNCIATOR 63
2
LIGHT DIMMER
3
2
J3
MIC INPUT HI
MIC INPUT LO 5
12
N/C
N/C
N/C
5
OPTION: BLUETOOTH MUSIC RECEIVER (SINK) WITH SERIAL DATA
JRAC
AUDIO CONTROLLER
JRAC
14
33
J1
15
34
4
HANDS-FREE AND MUSIC RECEIVER PROFILE
JAC
DS
05-19-16
JAC
KDV
05-19-16
