SERVICE MANUAL
COPYRIGHT © 2009 Victor Company of Japan, Limited No.MB706<Rev.002>
2009/7
BLU-RAY DISC PLAYER
MB706<Rev.002>20097SERVICE MANUAL
XV-BP1J, XV-BP1C, XV-BP1B,
XV-BP1E, XV-BP1EN, XV-BP1EV,
XV-BP1EE, XV-BP1US,
XV-BP1UX, XV-BP1UJ
COPYRIGHT © 2009 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
(Except J,C,UJ)

1-2 (No.MB706<Rev.002>)
SPECIFICATION
For Northern America
Design and specifications are subject to change without prior notice.
General
Power requirements AC 120 V~, 60 Hz
Power consumption 18W
Dimensions (W ×H ×D) Approx. 16.9 x 2.1 x 9.7 inches (430 x 54 x 245 mm) without foot
Net Weight (Approx.) 6.2 lbs (2.8 kg)
Operating temperature 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity 5 % to 90 %
Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack ×1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack ×1
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack ×2
HDMI OUT (video/audio) 19 pin (HDMI standard, Type A)
ANALOG AUDIO OUT 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) ×1
DIGITAL OUT (COAXIAL) 0.5 V (p-p), 75 Ω, RCA jack ×1
DIGITAL OUT (OPTICAL) 3 V (p-p), Optical jack ×1
System
Laser Semiconductor laser, wavelength: 405nm / 650 nm
Signal system Standard NTSC Color TV system
Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio More than 100 dB (ANALOG OUT connectors only)
Harmonic distortion Less than 0.008%
Dynamic range More than 95 dB
LAN port Ethernet jack ×1, 10BASE-T/100BASE-TX

(No.MB706<Rev.002>)1-3
For Europe
Design and specifications are subject to change without prior notice.
General
Power requirements AC 220-240 V ~, 50/60 Hz
Power consumption 18W
Dimensions (W ×H ×D) Approx. 430 ×54 ×245 mm without foot
Net Weight (Approx.) 2.8 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack ×1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack ×1
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack ×2
HDMI OUT (video/audio) 19 pin (HDMI standard, Type A)
ANALOGUE AUDIO OUT 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) ×1
DIGITAL OUT (COAXIAL) 0.5 V (p-p), 75 Ω, RCA jack ×1
DIGITAL OUT (OPTICAL) 3 V (p-p), Optical jack ×1
System
Laser Semiconductor laser, wavelength: 405nm / 650 nm
Signal system Standard PAL/NTSC Colour TV system
Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio More than 100 dB (ANALOGUE OUT connectors only)
Harmonic distortion Less than 0.008%
Dynamic range More than 95 dB
LAN port Ethernet jack ×1, 10BASE-T/100BASE-TX
Bus power supply DC 5 V 500 mA

1-4 (No.MB706<Rev.002>)
For Asia
Design and specifications are subject to change without prior notice.
General
Power requirements AC 110-240 V ~, 50/60 Hz
Power consumption 18W
Dimensions (W ×H ×D) Approx. 430 ×54 ×245 mm without foot
Net Weight (Approx.) 2.8 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack ×1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack ×1
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack ×2
HDMI OUT (video/audio) 19 pin (HDMI standard, Type A)
ANALOGUE AUDIO OUT 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) ×1
DIGITAL OUT (COAXIAL) 0.5 V (p-p), 75 Ω, RCA jack ×1
DIGITAL OUT (OPTICAL) 3 V (p-p), Optical jack ×1
System
Laser Semiconductor laser, wavelength: 405nm / 650 nm
Signal system Standard PAL/NTSC Colour TV system
Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio More than 100 dB (ANALOGUE OUT connectors only)
Harmonic distortion Less than 0.008%
Dynamic range More than 95 dB
LAN port Ethernet jack ×1, 10BASE-T/100BASE-TX
Bus power supply DC 5 V 500 mA

(No.MB706<Rev.002>)1-5
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

1-6 (No.MB706<Rev.002>)
1.5 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1M
Conductive material
(conductive sheet) or iron palate
(caption)
Anti-static wrist strap

(No.MB706<Rev.002>)1-7
1.6 Importance administering point on the safety
W109
W110
W114
ZD121
R122
6.2B (2.7B)
R150
R151
R152
R131
R191
R181
C133
R156
R155
R154
W108
W103
W107
W113
W115
W119
W105
IC152
IC154
378R05
278R12
(278R05)
R157
16.FD(+) 15.FD(-) 14.-29VA 13.GND 12.5.3VA 11.5.3VA 10.GND
9.GND 6.GND 3.GND 2.3.3V 1.3.3V 5.12V 4.12V
audio
8.P-CON 7.5V
loader
W117
W104
W102
W106
C152
L123
C126
D131
R121
R144 R145 R146 R143
C143
C125
D126
C124
C122
C121
C123
C131
D133
D122 SB360
SB360
D124 D132
HER303
SB360
D121
D123
(B5A60VI)
B5A60VI
10A06
L127
IC151
78R12
C154
C151
C153
R153
J101
P101
78R33
IC153
W116
W182
IC103
D130
W183
W111
D125
R141
R142
W112 L124
C132
C111
C103
W101
R104
C105
C106
D101
BC101
R105
D102
C107
C109
IC102
T101
C104
ZD103
ZD101
10B
33B
R109
FH102
C115
W118
IC101
R101
C102
C110
C101
R100
V101
BD101
F101
T1.6AL 250V
FH101
L102
PW101
Graphic symbol mark
(This symbol means fast blow type fuse.)
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE, REPLACE ONLY WITH SAME TYPE
AND RATING OF FUSES ;
should be read as follows ;
F901 : 3.5A 125V F901 : 3.5A 125V
Full Fuse Replacement Marking
FUSE CAUTION
Le symbole graphique (Ce symbole signifie
fusible de type a fusion rapide.)
POUR UNE PROTECTION CONTINUE CONTRE
DES RISQUES D'INCENDIE, REMPLACER
SEULEMENT PAR UN FUSIBLE DU MEME TYPE ;
Marquage Pour Le Remplacement
Complet De Fusible
PRECAUTIONS SUR LES FUSIBLES
doit etre interprete comme suit ;
^
fast blow type / type a fusion rapide

1-8 (No.MB706<Rev.002>)
1.7 Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION OF LABELS and PRINT
!Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
WARNING LABEL and PRINT

(No.MB706<Rev.002>)1-9
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

1-10 (No.MB706<Rev.002>)
SECTION 3
DISASSEMBLY
3.1 Main body
3.1.1 Removing the Top cover (See Fig.1)
(1) Remove the three screws Aattaching the Top cover.
Fig.1
3.1.2 Removing the Front panel (See Fig.2 to 4)
(1) Disconnect the card wire from Front panel connected to
connector CN202 of the Main board. (See Fig.2)
(2) Disengage four hooks aengaged top side of the Front pan-
el. (See Fig.2)
Fig.2
(3) Disengage two hooks bengaged both side of the Front
panel. (See Fig.3)
Fig.3
(4) Disengage three hooks cengaged bottom side of the Front
panel. (See Fig.4)
Fig.4
3.2 Removing the Blu-ray drive unit (See Fig.5)
(1) Disconnect the connector wire from Blu-ray drive unit con-
nected to connector CN801 of the Main board.
(2) Disconnect the FFC cable connected to connector CN802
of the Main board.
(3) Remove the four screws Battaching the Blu-ray drive unit.
Fig.5
3.3 Removing the SMPS board (See Fig.6, 7)
(1) Remove the one screw Cattaching the AC jack. (See
Fig.6)
Fig.6
A
hook aCN202
hook b
hook c
CN801
CN802
B
B
C

(No.MB706<Rev.002>)1-11
(2) Remove the four screws Dattaching the SMPS board.
(See Fig.7)
(3) Disconnect the B-B connector P101 of the SMPS board
from Main board. (See Fig.7)
Fig.7
3.4 Removing the Main board (See Fig.8, 9)
(1) Remove the two screws Eattaching the RCA jacks. (See
Fig.8)
(2) Remove the one screw Fattaching the HDMI jack. (See
Fig.8)
Fig.8
(3) Remove the three screws Gattaching the Main board.
(See Fig.9)
Fig.9
3.5 Removing the Timer board (See Fig.10)
(1) Remove the five screws Hattaching the Timer board.
Fig.10
3.6 Removing the Key board (See Fig.11)
(1) Remove the one screw Jattaching the Key board.
Fig.11
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
D
P101
EF
G
G
H
J

1-12 (No.MB706<Rev.002>)
SECTION 5
TROUBLESHOOTING
5.1 Power supply (SMPS)
No 5.3VA
Power Line or Main PCB is short
Check or replace the D102
Is BD101 normal? Replace BD101
Is the
F101 normal? Replace F101 (same fuse)
Is the IC102
normal? Replace IC102
Is there about
2.5V at the IC103
Pin1?
Replace IC103
Is VCC
(13~27V) supplied to
IC101 Pin4?
Is D102 normal?
Is R101 normal? Replace R101
NO
YES
NO
YES
NO
YES
YES
NO
YES
NO
YES
NO
YES

(No.MB706<Rev.002>)1-13
Is the IC152
Pin4 "H"?
Check the DVD CTL
"H" signal from u-com
Is the Vcc
(5.5V) supplied to
D132 anode?
Check or Replace
the D132
NO
YES
No 5VA
YES
NO
YES
Check or Replace
the IC152
Is the IC153
Pin4 "H"?
Check the DVD CTL
"H" signal from u-com
Is the Vcc
(3.8V) supplied to
IC153 Pin1?
Check or Replace
the D123
NO
YES
No 3.3VA
YES
NO
YES
Check or Replace
the IC153
Is the IC154
Pin4 "H"?
Check the DVD CTL
"H" signal from u-com
Is the Vcc
(13.5V) supplied to
IC154 Pin1?
Check or Replace
the D121
NO
YES
No 12V_L
YES
NO
YES
Check or Replace
the IC154
Is the IC151
Pin4 "H"?
Check the DVD CTL
"H" signal from u-com
Is the Vcc
(13.5V) supplied to
IC151 Pin1?
Check or Replace
the D121
NO
YES
No 12V_A
YES
NO
YES
Check or Replace
the IC151

1-14 (No.MB706<Rev.002>)
5.2 Power ON
POWER on
"HELLO
PLEASE WAIT"
Display on VFD
OK?
Front I/F
cable connection
OK?
Front I/F cable connect
"JVC LOGO"
display on monitor
OK?
Display
cable connection
OK?
Proper display cable connect
VFD power
cable connection
OK?
VFD power cable connect
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
Normal TV
function OK

(No.MB706<Rev.002>)1-15
5.3 SYSTEM PART
POWER on
"HELLO
PLEASE WAIT"
Display on VFD
OK?
CN501, Pin18:
+5.3VA, Pin3: -29VA,
Pin17: -27V, Pin13:
-24V?
Check SMPS
"READING"
display on VFD
OK?
NO
NO
NO
CN701, Pin5:
12V, Pin7: 5V,
Pin2: 2.2V, Pin11:
5.3VA?
Check SMPS
NO
YES
YES
X501 10MHz
OK? X501 Change
NO
CA207: 5.3VA
CA210: 1.2V
CA211: 5V
IC202, IC203, IC204 Change
NO
YES
R516
About 625kHz Serial
Clock OK?
IC501 Change
NO
YES
R523
About 500kHz
OK?
IC502 Change
NO
YES
YES
X301: 27MHz
OK? X301 Change
NO
X302: 25MHz
OK? X102 Change
NO
YES
YES
YES
YES
System part OK
DIG501 Change
Check IC301
Timer board
Main board

1-16 (No.MB706<Rev.002>)
5.4 COMPONENT (Y,Pb,Pr) VIDEO OUT
5.5 CVBS VIDEO OUT
Component video no display
L906 +3.3V
OK? Re-soldering
NO
YES
C913, C914, C915
Signal OK? Re-soldering
NO
YES
R923, R924, R925
Signal OK? Re-soldering
NO
YES
JK904
Soldering OK? Re-soldering
NO
YES
Component Video OK
CVBS video no display
C910
Video signal input
OK?
C913
Video signal output
OK?
IC301 Check
NO
YES
IC901 Check
NO
YES
JK904
Soldering OK? Re-soldering
NO
YES
Component Video OK

(No.MB706<Rev.002>)1-17
5.6 AUDIO (S/PDIF, OPTICAL)
No Audio
C917
Digital Audio
output OK?
JK903 Red
Lighting OK?
IC301 Check
NO
NO
YES
JK903 (Pin2)
+5.0V OK? IC204 Check
NO
JK903 Re-soldering
YES
S/PDIF, OPTICAL
audio out OK

1-18 (No.MB706<Rev.002>)
5.7 AUDIO (ANALOG)
No Audio
IC603 (Pin8)
12V AUDIO
OK?
Q905 (Pin2)
LOW? Q902 Re-soldering
NO
NO
YES
YES
IC903
Pin 6, 7, 8, I2S
Output OK?
IC301 Check
NO
YES
IC903 Pin 14, 15
audio output before
Amp OK?
IC903 Check
NO
YES
CA907, CA908
audio output
OK?
IC904 Check
NO
YES
R949, R950
JK904 (Pin2, 5)
soldering OK?
Re-soldering
NO
YES
CN201 (Pin4)
12V AUDIO
OK?
Check SMPS
NO
R947 Re-soldering
Audio Output OK

(No.MB706<Rev.002>)1-19
5.8 HDMI
No A/V
JK902
Soldering OK?
JK902 Pin 18
VCC +5V OK? Re-soldering
NO
NO
YES
YES
JK902 Pin 19
+2.0V < Voltage < +5.3V
OK?
TV hot plug detect signal
check (from IC301)
NO
YES
JK902 Pin 15, 16
(SCL, SDA)
OK?
Check HDMI Voltage
Level Shifter
NO
YES
L902
soldering OK?
Re-soldering
NO
HDMI out OK
IC204 Pin 4 Check

(No.MB706<Rev.002>)
VSE
Printed in Japan
Victor Company of Japan, Limited
Audio/Video Systems Division 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
