JVC Everio GZ-MS240 User manual

*
LYT2202-001A-M*
LYT2202-001A-M
MEMORY CAMERA
GZ-MS240 
Basic User Guide
Dear Customers
Thank you for purchasing this JVC product.
Before use, please read the Safety Precautions and Cautions on P.2 and P.25 to ensure safe
use of this product.
This product comes with a “Basic User Guide” (this manual) and a “Detailed User Guide”.
Detailed User Guide
.
Explains the ways of shooting in various situations and the
useful features.
■Access the following website on your PC
http://manual.jvc.co.jp/index.html/
For Future Reference:
Enter the Model No. (located on the bottom of the camera) and Serial No.
(located on the battery pack mount of the camera) below.
Model No.
Serial No.
Getting StartedRecordingPlaybackCopying
Further
Information

Safety Precautions
.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, withinan
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point withinanequilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
NOTES:
•The rating plate and safety caution are on the
bottomand/or the back of the main unit.
•The serial number plate is on the battery pack
mount.
•The rating information and safety caution of the
AC adapter are on its upper and lower sides.
Caution on Replaceable lithiumbattery
The battery used in this device may present a fire
or chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C
or incinerate.
Danger of explosion or Risk of fire if the battery is
incorrectly replaced.
•Dispose of used battery promptly.
•Keep away fromchildren.
•
Do not disassemble and do not dispose of in fire.
For USA-California Only
This product contains a CR Coin Cell Lithium
Battery which contains Perchlorate Material
– special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
When the equipment is installed in a cabinet or on
a shelf, make sure that it has sufficient space on all
sides to allow for ventilation (10 cm(3-15/16") or
more on both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a
newspaper, or cloth etc.the heat may not be able
to get out.)
No naked flame sources, such as lighted candles,
should be placed on the apparatus.
When discarding batteries, environmental
problems must be considered and the local rules or
laws governing the disposal of these batteries must
be followed strictly.
The apparatus shall not be exposed to dripping or
splashing.
Do not use this equipment in a bathroomor places
with water.
Also do not place any containers filled with water
or liquids (such as cosmetics or medicines, flower
vases, potted plants, cups etc.) on top of thisunit.
(If water or liquid is allowed to enter this
equipment, fire or electric shock may be caused.)
Do not point the lens directly into the sun.This
can cause eye injuries, as well as lead to the
malfunctioning of internal circuitry.There is also a
risk of fire or electric shock.
CAUTION!
The following notes concern possible physical
damage to thisunit and to the user.
Carrying or holding this unit by the LCD monitor
can result in dropping the unit, or in a malfunction.
Do not use a tripod on unsteady or unlevel surfaces.
It could tip over, causing serious damage to the
unit.
CAUTION!
Connecting cables (Audio/Video, S-Video, etc.) to
this unit and leaving it on top of the TV is not
recommended, as tripping on the cables will cause
the unit to fall, resulting in damage.
CAUTION:
WARNING:
The battery pack, this unit with battery installed,
and the remote control with battery installed
should not be exposed to excessive heat such as
direct sunlight, fire or the like.
The mains plug shall remain readily operable.
•Remove the mains plug immediately if the
camcorder functions abnormally.
2For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

.
Remember that this camcorder is intended for
private consumer use only.
Any commercial use without proper permission
isprohibited.(Even if you record an event such
as a show, performance or exhibition for personal
enjoyment, it is strongly recommended that you
obtain permission beforehand.)
Trademarks
•
Manufactured under license fromDolby
Laboratories.Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
•
Windows
®
is either registered trademark or
trademark of Microsoft Corporation in the United
States and/or other countries.
•
Macintosh is a registered trademark of Apple
Inc.
•
iTunes, iMovie, iPhoto are trademarks of Apple
Inc., registered in the U.S.and other countries.
•
YouTube and the YouTube logo are trademarks
and/or registered trademarks of YouTube LLC.
•
Other product and company names included in
this instruction manual are trademarks and/or
registered trademarks of their respective holders.
•
Please do not pull or bend the AC adapter plug
and cable.This may damage the AC adapter.
If thissymbol is shown, it is only valid
in the European Union.
CAUTION:
It is recommended to copy your important recorded
data to a DVD or other recording media for storage.
JVC will not be responsible for any lost data.
Make a backup of important recorded data
IMPORTANT SAFETY INSTRUCTIONS
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean only with dry cloth.
7.Do not block any ventilation openings.Install in
accordance with the manufacturer’s instructions.
8.Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9.Protect the power cord frombeing walked on
or pinched particularly at plugs, convenience
receptacles, and the
point where they exit
fromthe apparatus.
10.Only use attachments/
accessories specified by
the manufacturer.
11.Use only with the cart,
stand, tripod, bracket,
or table specified by the
manufacturer, or sold with the apparatus.When
a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from
tip-over.
12.Unplug this apparatus during lightning storms or
when unused for long periods of time.
13.Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 3

Index
Safety Precautions ............................ 2
Index ................................................. 4
Verifying the Accessories .................. 4
Names of Parts and Functions .......... 5
▶Getting Started ........................ 6
Charging the Battery Pack ................ 6
Grip Adjustment ................................ 7
Inserting an SD card ......................... 8
Clock Setting ................................... 10
▶Recording .............................. 12
Video Recording .............................. 12
Still Image Recording ...................... 13
▶Playback ................................ 14
Playing Back/Deleting Files on this Unit
......................................................... 14
Playing Back on TV ......................... 15
▶Copying ................................. 16
Copying Files .................................. 16
Dubbing Files by Connecting to a DVD
Recorder or VCR ............................. 17
Copying to Computer ...................... 18
▶Further Information ................ 21
Using the Menu ............................... 21
Recordable Time/Number of Images
......................................................... 22
Troubleshooting .............................. 23
Cautions .......................................... 25
Specifications .................................. 27
▶Learning About Advanced Operations
Use the “Detailed User Guide” on your PC to find out more about the advanced
operations.
■Access the following address on your PC
http://manual.jvc.co.jp/index.html/
Verifying the Accessories
AC Adapter
AP-V30U*
Battery Pack
BN-VG107U
USB Cable
(Type A - Mini Type B)
AV Cable
.
.
.
.
CD-ROM Basic User Guide
(this manual) Core Filter
.
.
.
●SD cards are sold separately.
For details on the types of cards that can be used on this unit, refer to P.8.
* When using the AC adapter overseas, please prepare a commercially available
converter plug for the country or region of visit.
4For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Names of Parts and Functions
.
AV
p
o
q
1
2
3
4
5
678
90a
d
c
b
f
e
i
k
j
h
g
n
m
l
ALens/Lens Cover
BLight
CStereo Microphone
DLCD Monitor
Turns the power on/off by opening and
closing.
ESlider
Selects an image or item.
FOK Button
Confirms the selected image or item.
GOperation Buttons
Functions differently according to the
operation.
HMenu (menu) Button ( P.21)
ISpeaker
JACCESS (Access) Lamp
Lights up/blinks during recording or
playback.
KPOWER/CHARGE (Power/Charge)
Lamp ( P.6)
L+(Play) Button
Switches between recording and
playback modes.
M/(Video/Still Image) Button
Switches between video and still
image modes.
NUPLOAD/EXPORT
(Upload/Export to iTunes) Button
Recording ： Takes videos in YouTube or
iTunes format.
Playback ： Changes the video to
YouTube or iTunes format.
O,(Power/Information) Button
Recording ： Displays the remaining time
as well as the battery power
during continuous recording.
Playback ： Displays file information.
Press and hold to turn the power on/off
while the LCD monitor is opened.
PAV Terminal ( P.15, P.17)
QZoom/Volume Lever ( P.12, P.14)
RSNAPSHOT (Still Image Recording)
Button ( P.13)
SUSB Terminal ( P.20)
TDC Terminal ( P.6)
USTART/STOP (Video Recording)
Button ( P.12)
VLens Cover Switch ( P.12)
WGrip Belt Release Lever
XGrip Belt ( P.7)
YTripod Mounting Hole
ZSD Card Slot ( P.8)
aBattery Release Lever ( P.6)
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 5

Charging the Battery Pack
.
2Connect the DC
terminal.
3Plug in the power.
Charging in progress:
Blinks
Charging finished:
Goes out
To detach the battery pack
■
Charging Lamp
1Attach the battery pack.
The battery pack is not
charged at the time of
purchase.
*
Charging Lamp
Align the top of the battery
with the mark on this unit,
and slide in until the battery
clicks into place.
•
(Base)
Cover
AC Adapter
To AC Outlet
(110V to 240V)
CAUTION
Be sure to use JVC battery packs.
●If you use any other battery packs besides JVC battery packs, safety and
performance cannot be guaranteed.
●Charging time: Approx. 1 h 50 m (using supplied battery pack)
* If the battery pack is charged outside the room temperature range of 10°C to
35°C, charging may take a longer time or it may not start.
Attaching the Core Filter to the DC cord
The core filter reduces interference. Connect the end of the cable with the core filter to this unit.
.
Release the stopper.
To be connected
to this unit.
Wind twice
3 cm
Getting Started
6For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Grip Adjustment
.
1
Pullbackthebelt
2
Adjustthelength
3
Attachthebelt
Using as a Hand Strap
Remove the strap and loop it around your wrist.
While pressing A, pull Band remove the strap.
.
Pressandhold
●When attaching the hand strap, insert Cuntil it clicks into place.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 7
Getting StartedRecordingPlaybackCopying
Further
Information

Inserting an SD card
When a commercially available SD card is inserted, recordings can still be made to the
card without stopping when the remaining recording time on the built-in memory runs out.
.
1
ClosetheLCDmonitor.
Label
3
InsertanSDcard.
2Openthecover.
*Turnoffthepowerofthisunit
beforeinsertingorremovingacard.
(Base)
■To remove the card
Push the card inward once, then pull it out straight.
.
(Base)
NOTE
Operations are confirmed on the following SD cards.
Manufacturer Panasonic, TOSHIBA, SanDisk, ATP
Video Class 4 or higher compatible SDHC card (4 GB to 32 GB)
Still Image SD card (256 MB to 2 GB), SDHC card (4 GB to 32 GB)
●Using cards other than those specified above may result in recording failure
or data loss.
8For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

■To use an SD card
Recording and playback can be
performed on a card when “REC
MEDIA FOR VIDEO” or “REC MEDIA
FOR IMAGE” of media settings is set
to “SD CARD”.
①Display the menu.
.
Touch
②Select “MEDIA SETTINGS” and
touch .
.
?
VIDEO
DISPLAY SETTINGS
CLOCK ADJUST
BASIC SETTINGS
CONNECTION SETTINGS
MEDIA SETTINGS
SET QUIT
③Select “REC MEDIA FOR
VIDEO” or “REC MEDIA FOR
IMAGE”, and touch .
.
?
MEDIA SETTINGS
REC MEDIA FOR VIDEO
REC MEDIA FOR IMAGE
FORMAT BUILT-IN MEM.
FORMAT SD CARD
ERASE ALL DATA
SET QUIT
④Select “SD CARD” and touch .
.
?
MEDIA SETTINGS
BUILT-IN MEMORY
SET QUIT
5&%#4&
■To use SD cards that have
been used on other devices
Format (initialize) the card using
“FORMAT SD CARD” from media
settings.
All data on the card will be deleted
when it is formatted. Copy all files
on the card to a PC before
formatting.
①Touch to display the menu.
②Select “MEDIA SETTINGS” with
the slider and touch .
③Select “FORMAT SD CARD”
and touch .
.
?
MEDIA SETTINGS
REC MEDIA FOR VIDEO
REC MEDIA FOR IMAGE
FORMAT BUILT-IN MEM.
FORMAT SD CARD
ERASE ALL DATA
SET QUIT
④Select “FILE” and touch .
.
?
FORMAT SD CARD
FILE
FILE + MANAGEMENT NO
SET QUIT
⑤Select “YES” and touch .
⑥After formatting, touch .
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 9
Getting StartedRecordingPlaybackCopying
Further
Information

Clock Setting
1Open the LCD monitor.
.
AV
●The unit turns on. When the LCD
monitor is closed, the unit turns off.
2Select “YES” and touch when
“SET DATE/TIME!” is displayed.
.
MENU
OK
SET DATE/TIME!
YES
NO
SET
Slider
OperationButtons
①Select
② Touch
●Slide along the slider to select, then
touch the operation buttons to set.
3Set the date and time.
.
10 00 AM20091
JAN
CLOCK SETTING
DATE TIME
SET QUIT
Cursor
●Use the slider to adjust the year,
month, day, hour and minute.
●Touch the operation buttons “&” /
“'” to move the cursor.
4After setting the date and time,
touch .
5Select the region where you live
and touch .
●The city name and time difference is
displayed.
.
GMT
JAN.1.2009 10:00 AM
CLOCK/AREA SETTING
SAVE QUIT
NOTE
●Touch the slider and buttons
around the screen with your
fingers.
●The slider and buttons do not
function if you touch them with
your fingernails or with gloves
on.
●The displays on the screen do
not work even if you touch them.
●“SET DATE/TIME!” is displayed
when you turn on this unit after it
has not been used for a
prolonged period.
Charge this unit for more than 24
hours before setting the clock.
( P.6)
10 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

■To reset the clock
Set the clock with “CLOCK ADJUST”
from the menu.
①Display the menu.
.
To u c h
②Select “CLOCK ADJUST” and
touch .
.
?
VIDEO
DISPLAY SETTINGS
CLOCK ADJUST
BASIC SETTINGS
CONNECTION SETTINGS
MEDIA SETTINGS
SET QUIT
③Select “CLOCK SETTING” and
touch .
.
?
CLOCK ADJUST
CLOCK SETTING
AREA SETTING
SET FOR DAYLIGHT SAVING TIME
SET QUIT
●The subsequent setting operations
are the same as steps 3 - 5 on the
previous page.
■To change the display
language
The language on the display can be
changed.
①Display the menu.
.
Touch
②Select “DISPLAY SETTINGS”
and touch .
.
?
VIDEO
DISPLAY SETTINGS
CLOCK ADJUST
BASIC SETTINGS
CONNECTION SETTINGS
SET QUIT
AUTO SWITCH REC MEDIA
③Select “LANGUAGE” and touch
.
.
?
DISPLAY SETTINGS
LANGUAGE
DATE DISPLAY STYLE
MONITOR BRIGHTNESS
LCD BACKLIGHT
SET QUIT
④Select the desired language and
touch .
⑤Touch .
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 11
Getting StartedRecordingPlaybackCopying
Further
Information

Video Recording
You can record without worrying about the setting details by using the auto mode.
Before recording an important scene, it is recommended to conduct a trial
recording.
.
AV
Touch
Press
Press
2Select
videomode.
3
CheckiftherecordingmodeisAuto. 
 IfthemodeisManual,
touchthebuttontoswitch. 
Themodechangesbetween
autoandmanualwitheverytouch.
•
•
4
Startrecording.
Pressagaintostop.
•
(Wideangle) (Telephoto)
Zooming
1Openthe
lenscover.
■Indications during video recording
.
RemainingRecordingTime
VideoQuality
：Record-Standby
SceneCounter
：RecordinginProgress
RecordingMedia
BatteryIndicator
NOTE
●The estimated recording time of the supplied battery pack is approximately
50 minutes. ( P.22)
Recording
12 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Reducing Camera Shake (Video Recording)
When the image stabilizer is set, camera shake during recording can be effectively reduced.
.
Touch
(White)：Imagestabilizer①
(Green)：Imagestabilizer②
(White)：OFF
Thesettingswitcheswitheverytouch.
A：Reduces camera shake.
B：
Reduces camera shake at wide angle effectively. It is also effective for recording while walking.
NOTE
●It is recommended to set the image stabilizer to off when shooting a subject
of little movement with the unit on a tripod.
●Complete stabilization may not be possible if camera shake is excessive.
Still Image Recording
.
AV
Pressfully
Presshalfway
Press
Lightsupduringstill
imagerecording
1
Selectstill
imagemode.
3
Takeastillimage.
2
Setthefocusonthesubject.
Lightsupingreen
whenfocused
■Indications during still image recording
.
832
Remaining Number of Shots
Image Quality
Recording in Progress
Shutter Speed
Focus
Image Size
Battery Indicator
Recording Media
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 13
Getting StartedRecordingPlaybackCopying
Further
Information

Playing Back/Deleting Files on this Unit
Select and play back the recorded videos or still images from an index screen (thumbnail display).
The contents of the media selected in media settings ( P.9) are displayed on the index screen.
.


 
8+&'12.#;$#%- 8+&'12.#;$#%-
② Touch
①Select
② Touch
① Select
Press
Press
3Playbackafile.
1Selecttheplaybackmode.
Volumeadjustmentduring
videoplayback
Turnup
thevolume
Turndown
thevolume
2
Selectvideoorstillimagemode.
Todeleteunwantedfiles■

Touchtostop.
•
SelectYESwhenthe
confirmationmessage
appearsandtouch.
•
Mediabeingplayedback
■To capture a still image during playback
Pause the playback and press the SNAPSHOT button.
■Usable operation buttons during playback
Display During video playback During still image playback
/ Playback/pause Start/pause slideshow
Stop (returns to thumbnail display) Stop (returns to thumbnail display)
Advances to the next video Advances to the next still image
Returns to the beginning of the scene Returns to the previous still image
!Forward search -
"Reverse search -
$Forward slow-motion -
%Reverse slow-motion -
Playback
14 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Playing Back on TV
1Connect to a TV.
* Refer also to the instruction manual of the TV.
●Press the Power button for more than 2 seconds to turn off this unit.
.
AV
AV
Yellow
White
Red
ToAVTerminal
VideoInput
VideoInput
AudioInput(L)
AudioInput(R)
TV
AVCable
(Provided)
2Connect the AC adapter. ( P.6)
●This unit powers on automatically when the AC adapter is connected.
3Select the TV input switch.
4Play back a file. ( P.14)
■To play back with date/time display
Set “DISPLAY ON TV” in the connection settings menu to “ON”.
Alternatively, set “ON-SCREEN DISPLAY” in the playback menu to “DISPLAY ALL”
or “DISPLAY DATE ONLY”.
■When images look unnatural on the TV
Images do not appear on the TV
properly.
●Disconnect the cable and connect again.
●Restart this unit by turning off and on.
Images are projected vertically
on the TV.
Set “VIDEO OUTPUT” in the connection settings
menu to “4:3”.
Images are projected
horizontally on the TV.
Adjust the TV's screen accordingly.
NOTE
●Please contact the TV manufacturer on questions or problems with setting
the TV to the correct mode.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 15
Getting StartedRecordingPlaybackCopying
Further
Information

Copying Files
You can create discs or copy the files on this unit by connecting it to various devices.
●Copying files by connecting to a DVD writer is not supported.
Device ...
Referen
ce Page
Dubbing Files by
Connecting to a DVD
Recorder or VCR
DVD Recorder
.
333
P.17
VCR
.
3- - P.17
Copying to PC
.
-3*3P.18
* For details on how to create a disc using a computer, refer to the Detailed User
Guide.
Copying
16 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Dubbing Files by Connecting to a DVD
Recorder or VCR
You can dub videos in standard quality by connecting to a DVD recorder or VCR.
Refer also to the instruction manual of the TV, DVD recorder, VCR, etc.
1Connect to a VCR/DVD recorder.
●Press the Power button for more than 2 seconds to turn off this unit.
.
AV
AV
ToDCTerminal
ACAdapterToACOutlet
(110Vto240V)
VCR/DVDRecorder
Yellow
White
Red
ToAVTerminal
VideoInput
VideoInput
AudioInput(L)
AudioInput(R)
AVCable
(Provided)
●This unit powers on automatically when the AC adapter is connected.
2Select the playback mode.
.
AV
Press
3Prepare to record.
Preparation on TV and VCR/DVD recorder
●Switch to a compatible external input.
●Insert compatible blank DVD or VHS to dub.
Preparation on this unit
●Set “VIDEO OUTPUT” in the connection
settings menu to the aspect ratio (“4:3” or “16:9”) of the connecting TV.
●To include the date during dubbing, set “DISPLAY ON TV” in the connection
settings menu to “ON”. Alternatively, set “ON-SCREEN DISPLAY” in the playback
menu to “DISPLAY DATE ONLY”.
4Start recording.
●Start playback on this unit ( P.14) and press the record button on the recorder.
●After playback is complete, stop the recording.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 17
Getting StartedRecordingPlaybackCopying
Further
Information

Copying to Computer
Verifying System Requirements (Guideline)
Windows PC
You can copy files to a PC using the provided software.
Right-click on “Computer” (or “My Computer”) in the “Start” menu and select
“Properties” to check the following items.
■Windows Vista / Windows 7
.
Windows Vista
Home Basic or Home Premium
(Pre-installed versions only)
Windows 7
Home Premium
(Pre-installed versions only)
Service Pack 2 (Windows Vista only)
Processor:
Intel Core Duo CPU 1.5 GHz or higher
Intel Pentium 4 CPU 1.6 GHz or higher
Intel Pentium M CPU 1.4 GHz or higher
Systemtype: 32-bit / 64-bit
Memory: At least 1 GB (1024 MB)
■Windows XP
.
Windows XP
Home Edition or Professional
(Pre-installed versions only)
Service Pack 3
Processor:
Intel Core Duo CPU 1.5 GHz or higher
Intel Pentium 4 CPU 1.6 GHz or higher
Intel Pentium M CPU 1.4 GHz or higher
Memory: At least 512 MB
NOTE
●If your PC does not meet the above system requirements, the provided
software cannot be used.
●Still images cannot be recorded to discs using the provided software.
●For more information, contact your PC's manufacturer.
●Mac users may use the software provided with the Mac computer
18 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/

Mac Computer
Copy the video and still image files to a computer using the following method.
①Close the LCD monitor and connect to a computer. ( P.20)
②Open the LCD monitor and display the USB menu.
③Select “PLAYBACK ON PC” and touch .
④
Double-click on the "EVERIO_MEM"or "EVERIO_SD"icon on the desktop.
⑤Click on the column display icon.
⑥Copy the files to any folder in the computer (desktop, etc).
.
column display icon Copy the files
●When the folders or files are deleted/moved/renamed in the computer, they
cannot be played back on this unit anymore.
●When removing this unit from the computer, drag & drop the "EVERIO_MEM"
or "EVERIO_SD"icon on the desktop to the trash bin.
Installing the Provided Software
You can display the recorded images in
calendar format and perform simple
editing using the provided software.
1Load the provided CD-ROM into
your PC.
(Windows Vista / Windows 7 only)
①Click “Run INSTALL.EXE” in the
auto play dialog box.
②Click “Continue” on the user
account control screen.
●“Software Setup” appears after a
while.
●If it doesn't appear, double-click
the CD-ROM icon in “My
Computer”.
2Click “Easy Installation”.
.
Read Detailed User Guide
●Follow the on-screen instructions.
NOTE
Viewing the web user guide
●Connect to the internet and click
“Read Detailed User Guide”.
3Click “Finish”.
4Click “Quit”.
●Exits installation of Everio
MediaBrowser and icons are
created on the desktop.
For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/ 19
Getting StartedRecordingPlaybackCopying
Further
Information

Backing Up All Files
Before making backup, make sure that
there is enough free space in the PC's
HDD.
1Connect the USB cable and AC
adapter.
.
USB Cable
(Provided)
AC Adapter To AC Outlet
(110V to 240V)
To USB Terminal
To DC Terminal
To USB Terminal
2Open the LCD monitor.
3Select “BACK UP” and touch .
.
?
75$/'07
%4'#6'&8&
&+4'%6&8&
72.1#&
':214661.+$4#4;
$#%-72
5'6 37+6
●The provided software Everio
MediaBrowser starts up on the PC.
The subsequent operations are to be
performed on the PC.
4Select the volume.
.
2
1
Click
Click
5Start backup.
.
Click
Saving destination (PC)
6
After backup is complete, click “OK”.
If you encounter any problems with
the provided software Everio
MediaBrowser, please consult the
"Pixela User Support Center".
■
To disconnect this unit from the PC
①Click “Safely Remove Hardware”.
.
②Click “Safely Remove USB Mass
Storage Device”.
③(For Windows Vista) Click “OK”.
④Disconnect the USB cable and
close the LCD monitor.
20 For more information, refer to the Detailed User Guide
http://manual.jvc.co.jp/index.html/
