SERVICE MANUAL
No. 86683
March 2002
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD.
(The specifications shown pertain specifically to the model GR-DVL320, DVL520, DVL820, DVL1020)
DIGITAL VIDEO CAMERA
SPECIFICATIONS
Regarding service information other than these sections, refer to the GR-DVL765EG service manual (No. 86670).
Also, be sure to note important safety precautions provided in the service manual.
GR-DVL820A/EA/SH,
DVL1020A/EA/SH
Camcorder
General
Power supply : DC 11.0 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.5 W (GR-DVL1020/DVL820)
Approx. 4.3 W (GR-DVL520/DVL320)
LCD monitor on, viewfinder off : Approx. 5.7 W (GR-DVL1020/DVL820)
Approx. 5.3 W (GR-DVL520/DVL320)
Video light : Approx. 2.8 W (GR-DVL1020/DVL820)
Approx. 3.5 W (GR-DVL520/DVL320)
Dimensions (W x H x D) : 79 mm x 89 mm x 184 mm (GR-DVL1020/DVL820)
79 mm x 89 mm x 167 mm (GR-DVL520/DVL320)
(with the LCD monitor closed and the viewfinder pushed down)
Weight : Approx. 580 g (GR-DVL1020)
Approx. 570 g (GR-DVL820)
Approx. 560 g (GR-DVL520)
Approx. 550 g (GR-DVL320)
Operating temperature : 0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Pickup : 1/3.8" CCD (GR-DVL1020/DVL820)
1/4" CCD (GR-DVL520/DVL320)
Lens : F 1.8, f = 3.8 mm to 38 mm, 10:1 power zoom lens (GR-DVL1020/DVL820)
F 1.8, f = 3.6 mm to 36 mm, 10:1 power zoom lens(GR-DVL520/DVL320)
Filter diameter : ø37 mm
LCD monitor : 3.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL1020)
2.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL820/DVL520/DVL320)
Viewfinder : Electronic viewfinder with 0.44" colour LCD (GR-DVL1020)
Electronic viewfinder with 0.24" black/white LCD (GR-DVL820/DVL520/DVL320)
Speaker : Monaural
Digital Video Camera
Format : DV format (SD mode)
Signal format : PAL standard
Recording/Playback format : Video: Digital component recording
: Audio: PCM digital recording, 32 kHz 4-channel (12-bit), 48 kHz 2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette) LP: 120 min.
Digital Still Camera Function (GR-DVL1020/DVL820/DVL520 only)
Storage media : SD Memory Card/MultiMediaCard
Compression system : Still image : JPEG (compatible)
Moving image* : MPEG4 (compatible)
File size : 3 modes (1280 X 960 pixels*, 1024 x 768 pixels,
640 x 480 pixels)
Picture quality : 2 modes (FINE/STANDARD)
Approximate number of
storable images :墌pg. 27.
* GR-DVL1020/DVL820 only.
Connectors
S-Video
Output : Y:1 V (p-p), 75 Ω, analogue
C:0.29 V (p-p), 75 Ω, analogue
Input (GR-DVL1020/DVL820 only) : Y:0.8 V (p-p) – 1.2 V (p-p), 75 Ω, analogue
C:0.2 V (p-p) – 0.4 V (p-p), 75 Ω, analogue
AV
Video output : 1 V (p-p), 75 Ω, analogue
Video input (GR-DVL1020/DVL820 only) : 0.8 V (p-p) – 1.2 V (p-p), 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
Audio input (GR-DVL1020/DVL820 only) : 300 mV (rms), 50 kΩ, analogue, stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input : 4-pin, IEEE 1394 compliant
USB (GR-DVL1020/DVL820/DVL520 only) : 5-pin
PC (GR-DVL320 only) : ø2.5 mm, 3-pole
EDIT (GR-DVL1020/DVL820/DVL520 only) : ø3.5 mm, 2-pole
JLIP (GR-DVL320 only) : ø3.5 mm, 4-pole
AC Adapter
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V , 1 A
Specifications shown are for SP mode unless otherwise indicated. E & O.E.
Design and specifications subject to change without notice.

1
The following table indicate main different points between models GR-DVL765EG-X, GR-DVL820A, GR-DVL820A-S,
GR-DVL820EA, GR-DVL820SH, GR-DVL1020A, GR-DVL1020EA and GR-DVL1020SH.
The following table indicate different parts number between models GR-DVL765EG-X, GR-DVL820A, GR-DVL820A-S,
GR-DV820EA, GR-DVL820SH, GR-DVL1020A, GR-DVL1020EA and GR-DVL1020SH.
PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.
MODEL GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
ITEM
LCD MONITOR 2.5” 3.5”
VIEW FINDER B/W COLOR
DV TERMINAL OUTPUT ONLY IN/OUT
TOTAL ZOOM RATIO 500X 700X 700X 700X
!REF. MODEL GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO. ITEM
FINAL ASSEMBLY <M2>
101 UPPER CASE ASSY LY20774-005B
*
LY20774-005C
* *
LY20797-004C
101A TOP COVER LY20775-001A LY20776-001A
101E COVER(SD) LY32375-001A
*
LY32375-001B
* * * * * *
101J EARTH SHEET/BRAKET(EARTH) LY43540-001A
*
LY32886-001A
***
LY32887-001A
101M SPECIAL SCREW,X2 LY30018-084A LY30018-038A
120 STICKER(SIDE) LY43566-005A LY43566-003A
122 SPACER(A) —
*
LY30029-0Y5A
***
—
*
LY30029-0Y5A
*
140 LOWER CASE ASSY LY20769-004D LY20769-003E
140B COVER(DC) LY32364-001A
*
LY32364-001B
* * * * * *
144 PLATE(ADJUST) LY43256-001A
*
LY43256-001B
* * * * * *
252 SPACER(A) — — LY30029-0Z7A
!REF. MODEL GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO. ITEM
ELECTRONIC VIEWFINDER ASSEMBLY <M4>
300 C.VF ASSY —————LY20838-003A
301 EYE CUP/EYE PIECE ASSY LY32349-001A PTY20712-001
302 CASE A(VF)/TOP CASE SUB ASSY LY20766-001A PTY20712-011
303 BOTTOM CASE —————PTY20712-021
304 CAP(VF) LY32351-001A PTY20712-022
305 VF HINGE ASSY/HINGE ASSY LY20824-001B PTY20838-031
306 LCD MODULE/LCD ASSY QLD0193-001 PTY20712-041
307 FPC QAL0380-002 QAL0287-001
308 SPECIAL SCREW,X4 —————LY30018-063A
309 SPECIAL SCREW,X3 LY30018-0F1A LY30018-055A
310 SPECIAL SCREW,X2 —————LY30018-035A
311 SCREW —————PTY20712-051
321 CASE B(VF) LY20767-001A ———
322 SPECIAL SCREW LY30019-037A ———
323 LEVER(VF) LY43231-001A ———
324 LENS ASSY LY32472-001A ———
324A LENS(A) LY43356-001A ———
324B LENS(B) LY43357-001A ———
325 SPRING(VF) LY43404-001A ———
331 SHEET LY43236-001A ———
332 SHEET2(POLA) LY43246-001A ———
333 HOLDER LCD(VF) LY32347-001A ———
334 SHEET(CUSION) LY43245-001A ———
335 SHEET1(POLA) LY43234-001A ———
336 SHEET(VF) LY43232-001A ———
337 SHEET(DIFF) LY43235-001A ———
338 HOLDER(LED) LY43238-001A ———
339 GUIDE(VF),X2 LY43239-001A ———
340 SPECIAL SCREW,X4 LY30018-060A ———
341 SPACER(A) LY30029-0U6A ———
343 BRACKET(VF) —————LY43827-001A
!REF. MODEL GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO. ITEM
Notes : Mark is same as left. Mark — is not used. Mark * reference model was also changed.
TABLE OF CONTENTS
DIFFERENT TABLE ................................................................................................................................................................................................... 1 to 2
4. CHARTS AND DIAGRAMS (4-1 to 4-6)
4.1 MAIN CIRCUIT BOARD [GR-DVL1020EA/SH]....................................................................................................................................................... 4-1
5. PARTS LIST (5-1 to 5-17)
5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ................................................................................................................................................... 5-1
5.2 FINAL ASSEMBLY <M2> ........................................................................................................................................................................................ 5-3
5.3 ELECTRONIC VIEWFINDER ASSEMBLY <M4> [GR-DVL1020A/EA/SH] ............................................................................................................. 5-6
5.4 MONITOR ASSEMBLY <M5> [GR-DVL820A/A-S/EA/SH] ..................................................................................................................................... 5-7
5.4 MONITOR ASSEMBLY <M5> [GR-DVL1020A/EA/SH] .......................................................................................................................................... 5-8
5.5 ELECTRICAL PARTS LIST ..................................................................................................................................................................................... 5-9
MAIN BOARD ASSEMBLY <01> ............................................................................................................................................................................ 5-9
1 PACKING CASE LY32567-021A LY32567-017A LY32567-008A LY32567-019A
3 POLY BAG LY30023-008A
*
LY30023-022A
* * * * * *
7 SHEET(AGREMENT) LYT0934-001A ———
8 SHEET(E.UE) LYT0889-010A —————BT-56001-2 —
13 SHEET(CON.PLUG) — LYT0609-001A — — LYT0609-001A — —
14 SER.NET CARD — — — BT-56002-2 — — BT-56002-2 —
! 26 POWER CORD QMPL120-190-JR QMPS110-190-JR QMPH020-190-JR QMPL120-190-JR QMPH020-190-JR QMPL120-190-JR
! 29 CONVERSION PLUG — PEMC1012-02 PEMC1012 — QAM0001-001 PEMC1012-02 — QAM0001-001
34 CD ROM ASSY LY32210-023A LY32210-038A
36 CAP(HOOD)ASSY/CAP(M)ASSY LY43294-002A
*
LY43322-002A
* * * * * *
38 WARRANTY CARD BT-54013-2 — — BT-56001-2 — — BT-56001-2 —
39 ADAPTOR PLUG QAM0302-001 ———————
40 CORE FILTER QQR0919-002
*
—
*
—
*
—
*
—
*
—
*
—
*
—

2
MONITOR ASSEMBLY <M5>
500 MONITOR ASSY LYH20246-043B LYH20246-042B
501 MONITOR COVER ASSY LY20863-001B LY20864-001C
501F EARTH MON LY43784-001A LY43785-001A
501G WINDOW(M.MEGA) LY32704-001A LY32704-002A
501H PLATE LY32706-001B LY32707-001B
502 MONITOR CASE ASSY LY20874-001A LY20598-002A
504 HOLDER LY20674-001A LY20568-001A
506 BACK LIGHT QLL0121-001 QLL0123-001
507 LCD MODULE QLD0154-001 QLD0203-001
511 SPACER(A) —
*
LY30029-0Y4A
***
———
512 SPACER(A) —————LY30029-0Y6A
!REF. MODEL GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO. ITEM
MAIN BOARD ASSEMBLY <01>
PW MAIN BOARD ASSY YB10391QC YB10391PD-01 YB10391QD-03
!REF. MODEL GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO. ITEM
MONITOR BOARD ASSEMBLY <02>
PW MONITOR BOARD ASSY YB10360PG-02 YB10360PJ
IC7101 IC(DIGITAL) TC7SH32FU ——
Q7101 TRANSISTOR 2SA1774/QR/-X ——
Q7102 TRANSISTOR 2SC4617/QR/-X ——
R7110 MG RESISTOR NRSA63J-562X ——
R7111 MG RESISTOR NRSA63J-0R0X ——
R7113 MG RESISTOR NRSA63J-0R0X ——
R7114 MG RESISTOR NRSA63J-271X ——
R7116 MG RESISTOR NRSA63J-102X ——
R7604 MG RESISTOR —————NRSA63J-0R0X
R7612 CMF RESISTOR NRVA63D-223X NRSA63D-682X
R7624 CMF RESISTOR —————NRVA63D-223X
R7625 CMF RESISTOR —————NRVA63D-223X
R7626 CMF RESISTOR —————NRVA63D-183X
R7627 CMF RESISTOR —————NRVA63D-334X
R7634 MG RESISTOR —————NRSA63J-0R0X
R7635 MG RESISTOR —————NRSA63J-0R0X
R7636 MG RESISTOR NRSA63J-101X NRSA63J-221X NRSA63J-101X
R7637 MG RESISTOR NRSA63J-101X NRSA63J-221X NRSA63J-101X
R7638 MG RESISTOR NRSA63J-101X NRSA63J-221X NRSA63J-101X
R7640 MG RESISTOR —————NRSA63J-0R0X
R7643 MG RESISTOR —————NRSA63J-0R0X
R7644 MG RESISTOR —————NRSA63J-0R0X
R7645 MG RESISTOR —————NRSA63J-0R0X
R7646 MG RESISTOR —————NRSA63J-0R0X
C7101 CAPACITOR NDC31HJ-221X ———
C7102 CAPACITOR NCF31CZ-104X ———
C7636 CAPACITOR —————NCF31CZ-104X
C7638 CAPACITOR —————NCB21AK-225X
C7639 T CAPACITOR —————NBE21AM-106X
L7605 COIL NQL365K-100X ——
L7606 COIL —————NQL365K-100X
OT2 SPACER —LY43869-001A
!REF. MODEL GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO. ITEM
DSC BOARD ASSEMBLY <10>
PW DSC BOARD ASSY YB20931F-01 YB20931D-01
IC8003 IC(MICRO C ROM) MBV160TE90PTA29 MBV160TE90PTA41
IC8007 IC MM1385EN ———
IC8301 IC —————ISP1181ADGG
Q8001 DIGI TRANSISTOR DTA114EE ———
R8020 MG RESISTOR NRSA6AJ-0R0W ———
R8027 MG RESISTOR NRSA6AJ-152W ———
R8028 MG RESISTOR NRS181J-270X ———
R8029 MG RESISTOR NRS181J-270X ———
R8030 MG RESISTOR NRSA6AJ-105W NRSA6AJ-0R0W
R8031 MG RESISTOR NRSA6AJ-105W NRSA6AJ-0R0W
R8036 MG RESISTOR NRSA6AJ-105W ———
R8056 MG RESISTOR —————NRSA6AJ-0R0W
R8074 MG RESISTOR —————NRSA6AJ-473W
R8302 MG RESISTOR —————NRS181J-220X
R8303 MG RESISTOR —————NRS181J-220X
R8305 MG RESISTOR —————NRSA6AJ-105W
R8306 MG RESISTOR —————NRSA6AJ-103W
R8307 MG RESISTOR —————NRSA6AJ-103W
R8308 MG RESISTOR —————NRSA6AJ-103W
R8309 MG RESISTOR —————NRSA6AJ-103W
R8311 MG RESISTOR —————NRSA6AJ-0R0W
C8027 CAPACITOR NCB30JK-105X ———
C8028 CAPACITOR NCBA1AK-104W ———
C8029 T CAPACITOR NBE20JM-106X ———
C8301 T CAPACITOR —————NBE20JM-106X
C8305 CAPACITOR —————NCBA1AK-104W
C8306 CAPACITOR —————NCBA1AK-104W
C8307 CAPACITOR —————NCBA1AK-104W
C8310 CAPACITOR —————NCBA1AK-104W
C8311 CAPACITOR —————NCBA1AK-104W
L8301 FERRITE BEAD —————NQR0129-002X
X8002 C OSCILLATOR NAX0398-001X ———
X8301 RESONATOR —————NAX0522-001X
!REF. MODEL GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH
NO. ITEM
Notes : Mark is same as left. Mark —is not used. Mark * reference model was also changed.

Printed in Japan
VICTOR COMPANY OF JAPAN, LIMITED
VIDEO DIVISION S40894

SCHEMATIC DIAGRAMS
No. 86683SCH
March 2002
This schematic diagrams is printed on 100% recycled paper.
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD.
(The specifications shown pertain specifically to the model GR-DVL320, DVL520, DVL820, DVL1020)
DIGITAL VIDEO CAMERA
SPECIFICATIONS
Regarding service information other than these sections, refer to the GR-DVL765EG service manual (No. 86670).
Also, be sure to note important safety precautions provided in the service manual.
GR-DVL820A/EA/SH,
DVL1020A/EA/SH
CD-ROM No.SML200204
Camcorder
General
Power supply : DC 11.0 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.5 W (GR-DVL1020/DVL820)
Approx. 4.3 W (GR-DVL520/DVL320)
LCD monitor on, viewfinder off : Approx. 5.7 W (GR-DVL1020/DVL820)
Approx. 5.3 W (GR-DVL520/DVL320)
Video light : Approx. 2.8 W (GR-DVL1020/DVL820)
Approx. 3.5 W (GR-DVL520/DVL320)
Dimensions (W x H x D) : 79 mm x 89 mm x 184 mm (GR-DVL1020/DVL820)
79 mm x 89 mm x 167 mm (GR-DVL520/DVL320)
(with the LCD monitor closed and the viewfinder pushed down)
Weight : Approx. 580 g (GR-DVL1020)
Approx. 570 g (GR-DVL820)
Approx. 560 g (GR-DVL520)
Approx. 550 g (GR-DVL320)
Operating temperature : 0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Pickup : 1/3.8" CCD (GR-DVL1020/DVL820)
1/4" CCD (GR-DVL520/DVL320)
Lens : F 1.8, f = 3.8 mm to 38 mm, 10:1 power zoom lens (GR-DVL1020/DVL820)
F 1.8, f = 3.6 mm to 36 mm, 10:1 power zoom lens(GR-DVL520/DVL320)
Filter diameter : ø37 mm
LCD monitor : 3.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL1020)
2.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL820/DVL520/DVL320)
Viewfinder : Electronic viewfinder with 0.44" colour LCD (GR-DVL1020)
Electronic viewfinder with 0.24" black/white LCD (GR-DVL820/DVL520/DVL320)
Speaker : Monaural
Digital Video Camera
Format : DV format (SD mode)
Signal format : PAL standard
Recording/Playback format : Video: Digital component recording
: Audio: PCM digital recording, 32 kHz 4-channel (12-bit), 48 kHz 2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette) LP: 120 min.
Digital Still Camera Function (GR-DVL1020/DVL820/DVL520 only)
Storage media : SD Memory Card/MultiMediaCard
Compression system : Still image : JPEG (compatible)
Moving image* : MPEG4 (compatible)
File size : 3 modes (1280 X 960 pixels*, 1024 x 768 pixels,
640 x 480 pixels)
Picture quality : 2 modes (FINE/STANDARD)
Approximate number of
storable images :墌pg. 27.
* GR-DVL1020/DVL820 only.
Connectors
S-Video
Output : Y:1 V (p-p), 75 Ω, analogue
C:0.29 V (p-p), 75 Ω, analogue
Input (GR-DVL1020/DVL820 only) : Y:0.8 V (p-p) – 1.2 V (p-p), 75 Ω, analogue
C:0.2 V (p-p) – 0.4 V (p-p), 75 Ω, analogue
AV
Video output : 1 V (p-p), 75 Ω, analogue
Video input (GR-DVL1020/DVL820 only) : 0.8 V (p-p) – 1.2 V (p-p), 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
Audio input (GR-DVL1020/DVL820 only) : 300 mV (rms), 50 kΩ, analogue, stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input : 4-pin, IEEE 1394 compliant
USB (GR-DVL1020/DVL820/DVL520 only) : 5-pin
PC (GR-DVL320 only) : ø2.5 mm, 3-pole
EDIT (GR-DVL1020/DVL820/DVL520 only) : ø3.5 mm, 2-pole
JLIP (GR-DVL320 only) : ø3.5 mm, 4-pole
AC Adapter
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V , 1 A
Specifications shown are for SP mode unless otherwise indicated. E & O.E.
Design and specifications subject to change without notice.

R1081
R1082
R1083
C1621
TG3
R1002
R1007
R1010
R1011
R1012
R1018
R1022
R1023
R1024
R1027
R1029
R1030
R1031
R1032
R1036
R1037
R1044 R1045
R1046
R1047
R1051
R1052
R1053
R1055
R1058
R1066
R1072
R1078
R1079
R1080
C1004
C1007
C1013
C1015
C1017
C1023
C1026
C1038
R3075
L1002
Q1001
Q1003
D1001
IC1005
RA1008
RA1009
RA1010
IC
1
IC1007
IC1003
X1001
IC1001
R1402
R1403
R1404
R1406
R1409
R1410
R1411
R1412
R1413
R1414
R1415
R1416
R1417
R1421R1422
C1401
C1404
C1406
C1407
C1409
C1412
C1413
C1414
C1415
Q1401
RA1401
R1610
R1611
R1622
C
C
C
R4308
R3008
R3009 R3010
R3011
R3016
R3017
R3018
R3020
R3027
R3029
R3030
R3031
R3036
R3037 R3044
R1425
R1426
R3033
C3014
C3022
C3023
C3024
C3028
C3029 C3034
C3037
C3045 C3046
C3064
C3054
C3007
L3004
L3006
C3001
C3008
RA3004
RA3005
IC3007
D3001
IC3001
TL1420
TL3006
R3071
R3070
R4311
Q3002
Q3001
C1416
C3070
R1061
C4313
C3060
C4312
C4317
C3059
RA430RA4302RA4303
TL1001 TL1002TL1003
TL1004 TL1005
TL1007
TL1009TL1027 TL1029TL1030 TL1031TL1032TL1033 TL1034
TL1035
TL1401TL1402
TL1403
TL1404
TL1405
TL1406
TL1407
TL1408
TL1409
TL1410
TL1411
TL1414
TL1601
TL16
0
TL1612TL1613TL1617
TL3001
TL3005
C4311
CN112
C4310
RA4304
R
R3069
R3744
C3069
C
3
C3
7
L3012
L3732
IC3731
IC3005
L3014
IC1009
TL1036
TL1038
TL3002
TL3004
TL3501
R3057
R1001
R1003
R1004
R1005
R1006
R1009
R1014
R1015
R1016
R1019
R1020R1021
R1026
R1028
R1038
R1039
R1048
R1049 R1050
R1054
R1056
R1057
R1060 R1071
R1076
R1077
C1009
C1010
C1011 C1014
C1016 C1019 C1027
C1028
C1029 C1030
C1034
C1036
C1037
C1020
C1021
C1031
Q1002
Q1005
Q1006 Q1007
Q1008
Q1009
IC1008
IC1004
R1401
R1405
R1407
R1408
R1423
C1402
C1403
C1405
C1410 C1411
L1401
C1408
Q1402 Q1403
X1401
IC1401
R1625 R1626
C1642 C1632
R3002
R3003
R3004
R3005 R3006
R3007
R3013 R3014
R3015
R3019
R3032 R3034
R3040 R3041 R3042 R3043
R3045 R3046
R3047R3048
R3051
R3059
R3049
R4321
R3050
C3011 C3012
C3013
C3015 C3016
C3017
C3020 C3021
C3025
C3027
C3030
C3031
C3032 C3033
C3035
C3036
C3038
C3039
C3040 C3041
C3042C3043
C3044
C3047
C3049
C3050
C3051 C3052
C3053
C3055
C3057
C3058
C3061
C1003
C3006
C3026
C3003
C3004
C3048
L3001
L3002
L3003
L3005
L3015
L3007
L3008
L3009 C3005
C3056
D3004
IC3004
RA3001 RA3002
RA3003
X3001X3002
D3002
D3003
R3072
R3073 R3074 R3025
R3026
C1039
R1008
C3009
C3067
C4318
C3066
R4305
TL4309
TL4310 TL4311
TL4312 TL4313
TL4314 TL4315
R3066 R3067
CN105
RA4305
R3068
R3742 R3743
C3068
C3743
C3740 C3741
IC3002
Q1004
D1002
30 15
16
1
1
3
5
4
1
8
4
5
14 23
118
14 23
1
3
5
4
4
5
1
8
4
6
3
1
10
11
20 11
110
15 34
14
85
41
58
3
4
5
SECTION 4
CHARTS AND DIAGRAM
4.1 MAIN CIRCUIT BOARD
[GR-DVL1020EA/SH]
FOIL SIDE(B)
4-1

4-2
C1606
2
1
TG4
C4216
2
3
Q2102
Q2103
IC1006
R1601
R1602
R1616
R1619
R1620
R1621
2
R1624
R1628
R1629
R1635R1637
R1643
R1630 R1631
C1601
C1607
C1618
C1619
C1620
C1622
C1623
C1624
C1625
C1626
C1627
C1628
C1641
C1602
C1603
IC1602
IC1601
R2006
R2007R2008
R2009
R2014
R2015
R2016
R2018
R2023
R2024
R2025
R2104
R2105
R2107
R2108
R2111
R2112
R2114
R2117
R2503
R2513
R2203
R2501
R2502
R2504
C2006
C2007
C2017
C2021
C2026
C2110
C2115
C2116
C2119
C2121
C2124
C2501
C2502
C2503
C2003
C2105
C2106
C2111
C2112
C2128
C2512
C2513
C2514
C2515
C2004
C2005
C2024
C2107
C2108
C2012
C2015
C2025
Q2001
IC2001
L2002
R2128
R2125
R3701
R3702
R4204
R4205
R4320
C3702
C3704
R4301
R4301
R4304
R2011
R4312
R4314
R2013
R4315
R4317 C4207 C4208
C4212
C4213
C4214
C4309
C4314
R4203
R4303 R4309
L4301 L4302L4305
C4202
C4210
C4204
A4301
T
L1602
TL1603
TL1604
TL1611 TL1614
TL4201
TL4202
R4302
C4203
C4206
L4303
R3704
L4304
C4201
IC4301
RA4306
X4301
R3705
R3721
R3722
R3745
R3747
R3748
R3803
R3805
R3807
R3806
R3808
C3742
C3744
C3745
C3747
C3805
C3810
C3812
C3813
C3815
C3816
C3818
C3819
C3811
C3746
C3802
L3802
7
32 TL3801
TL3802
TL4318
TL4319
C4217 C4220 R4201
R4306 R4307
Q2101
R1603
R1604
R1612
R1613
R1614 R1615 R1617 R1618
R1636
R1605 R1609
C1605
C1633
C1614
Q1601
D1602
D1603
D1604
R2004R2005
R2017
R2019 R2020
R2028
R2103
R2106
R2109
R2110
R2113 R2115
R2116R2118
R2119
R2120 R2121 R2122
R2123
R2124
R2505 R2506
R2507 R2508
R2509 R2510 R2511
R2512
R2029
C2013 C2014
C2016
C2020 C2027
C2028
C2109
C2117
C2118
C2120 C2122
C2123
C2125
C2126
C2506
C2507
C2018 C2019
C2113 C2114
C2127
C2504 C2505
C2510 C2511
C2516 C2517
C2008
C2009 C2010
C2103
C2104
L2001
C2001
C2002
C2011
C2509
Q2002
Q2501
IC2501
R2126
R2129
R3723 R3724
C3703 C3705
Q3701
RA4201RA4202
R4310 R4313
R4316
C4218
C4205
C4215
C4304
C4307
C3803
C4315
C3804
C4302 C4303
C4211
C4301
C4306
IC4201
C4308
TL4304 TL4305
TL4306 TL4308
TL4316
TL4317
C2508
R2001
L2501
C4316
C4209
L4201
RA4307RA4308
CN102
C4305
IC4202
IC4302
R2010
R2012
R2127
C4219
IC4303
R3746
R3801 R3802
R3804
R3809
C3806 C3807 C3808
C3814 C3817
C3820
C3809
C3801
L3801
L3803
Q3703 Q3704
Q3735
IC3802
IC3801
L3804
3
1
1
20
1 3
5 4
1
48
16
33
64
49
17
32
1
48
16
33
64
49
17
32
124
18
169
121 2536
2437 1348
1 3
1 3
5 4
1 3
5 4
A
B
C
D
12
0 1 MAIN PWB
YB10391-01-01

4-3
COMPONENT PARTS LOCATION GUIDE <MAIN/YB10391-01-01> (1/2)
REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION
CAPACITOR
C1003 B C 3A
C1004 B C 3A
C1006 A C 5A
C1007 B C 5B
C1009 B C 4A
C1010 B C 3A
C1011 B C 4A
C1013 B C 4A
C1014 B C 4A
C1015 B C 4A
C1016 B C 4A
C1017 B C 4A
C1019 B C 4A
C1020 B C 3A
C1021 B C 4A
C1023 B C 3B
C1026 B C 4B
C1027 B C 4A
C1028 B C 3A
C1029 B C 4A
C1030 B C 4A
C1031 B C 5B
C1034 B C 4A
C1036 B C 4A
C1037 B C 4A
C1038 B C 4A
C1039 B C 4A
C1401 B C 4B
C1402 B C 4B
C1403 B C 4B
C1404 B C 4B
C1405 B C 4B
C1406 B C 4B
C1407 B C 4B
C1408 B C 4B
C1409 B C 4B
C1410 B C 4B
C1411 B C 4B
C1412 B C 4B
C1413 B C 4B
C1414 B C 4B
C1415 B C 4B
C1416 B C 4B
C1601 B C 2C
C1602 B C 2D
C1603 B C 2D
C1605 B C 2C
C1606 B C 2C
C1607 B C 3D
C1614 B C 3C
C1618 B C 3C
C1619 B C 3C
C1620 B C 3C
C1621 B C 3C
C1622 B C 3D
C1623 B C 3D
C1624 B C 3D
C1625 B C 2C
C1626 B C 2C
C1627 B C 2C
C1628 B C 2D
C1632 B C 3D
C1633 B C 2C
C1641 B C 2C
C1642 B C 3D
C2001 B C 2C
C2002 B C 1B
C2003 B C 1D
C2004 B C 1C
C2005 B C 1C
C2006 B C 2C
C2007 B C 2C
C2008 B C 2C
C2009 B C 2C
C2010 B C 2C
C2011 B C 2C
C2012 B C 1C
C2013 B C 1D
C2014 B C 1D
C2015 B C 1D
C2016 B C 2C
C2017 B C 2C
C2018 B C 1C
C2019 B C 1C
C2020 B C 2C
C2021 B C 2C
C2024 B C 1C
C2025 B C 1C
C2026 B C 2C
C2027 B C 2D
C2028 B C 1D
C2103 B C 1D
C2104 B C 1C
C2105 B C 1C
C2106 B C 1C
C2107 B C 1C
C2108 B C 1C
C2109 B C 1C
C2110 B C 1C
C2111 B C 1C
C2112 B C 1C
C2113 B C 1C
C2114 B C 1C
C2115 B C 1D
C2116 B C 1C
C2117 B C 1D
C2118 B C 1C
C2119 B C 1D
C2120 B C 1C
C2121 B C 1D
C2122 B C 1C
C2123 B C 1D
C2124 B C 1C
C2125 B C 1D
C2126 B C 1C
C2127 B C 1D
C2128 B C 1C
C2201 A C 1C
C2202 A C 1C
C2501 B C 2B
C2502 B C 2B
C2503 B C 2C
C2504 B C 1C
C2505 B C 1C
C2506 B C 1C
C2507 B C 1C
C2508 B C 1B
C2509 B C 1B
C2510 B C 1C
C2511 B C 1C
C2512 B C 1B
C2513 B C 1B
C2514 B C 2C
C2515 B C 2C
C2516 B C 2C
C2517 B C 2C
C3001 B C 3D
C3003 B C 5B
C3004 B C 4B
C3005 B C 4D
C3006 B C 3D
C3007 B C 5B
C3008 B C 4C
C3009 B C 4D
C3011 B C 5C
C3012 B C 4C
C3013 B C 4C
C3014 B C 3C
C3015 B C 4C
C3016 B C 4C
C3017 B C 4C
C3020 B C 4C
C3021 B C 5C
C3022 B C 4C
C3023 B C 4C
C3024 B C 4D
C3025 B C 4B
C3026 B C 5C
C3027 B C 5C
C3028 B C 5C
C3029 B C 5C
C3030 B C 4C
C3031 B C 4C
C3032 B C 4C
C3033 B C 4C
C3034 B C 4C
C3035 B C 4C
C3036 B C 4C
C3037 B C 4C
C3038 B C 5B
C3039 B C 4B
C3040 B C 4B
C3041 B C 5B
C3042 B C 5C
C3043 B C 5C
C3044 B C 5C
C3045 B C 5C
C3046 B C 5C
C3047 B C 5C
C3048 B C 5D
C3049 B C 5C
C3050 B C 5C
C3051 B C 3C
C3052 B C 3D
C3053 B C 3C
C3054 B C 3C
C3055 B C 5C
C3056 B C 3C
C3057 B C 4C
C3058 B C 4C
C3059 B C 3C
C3060 B C 3C
C3061 B C 3C
C3064 B C 4C
C3066 B C 3C
C3067 B C 4C
C3068 B C 3C
C3069 B C 3C
C3070 B C 3C
C3501 A C 3C
C3502 A C 3C
C3503 A C 2D
C3504 A C 2C
C3505 A C 2C
C3506 A C 2C
C3507 A C 2C
C3508 A C 2C
C3509 A C 2C
C3510 A C 2C
C3511 A C 3C
C3512 A C 3C
C3513 A C 3C
C3514 A C 3C
C3515 A C 3C
C3516 A C 3C
C3517 A C 3C
C3518 A C 3C
C3519 A C 3C
C3520 A C 3C
C3521 A C 2C
C3522 A C 2C
C3523 A C 2C
C3524 A C 2C
C3525 A C 2C
C3526 A C 2C
C3527 A C 3C
C3528 A C 3C
C3701 A C 3C
C3702 B C 2C
C3703 B C 2C
C3704 B C 2C
C3705 B C 2C
C3706 A C 3B
C3707 A C 3B
C3708 A C 3B
C3709 A C 3B
C3712 A C 3C
C3713 A C 3B
C3714 A C 3B
C3715 A C 2B
C3731 A C 2B
C3732 A C 2B
C3733 A C 2B
C3734 A C 2B
C3735 A C 2B
C3736 A C 2B
C3737 A C 2B
C3738 A C 2B
C3739 A C 2B
C3740 B C 3B
C3741 B C 3B
C3742 B C 3B
C3743 B C 3B
C3744 B C 3B
C3745 B C 3B
C3746 B C 3B
C3747 B C 3B
C3801 B C 2B
C3802 B C 2B
C3803 B C 2B
C3804 B C 2B
C3805 B C 2B
C3806 B C 2C
C3807 B C 2C
C3808 B C 2C
C3809 B C 2C
C3810 B C 2B
C3811 B C 2B
C3812 B C 2B
C3813 B C 2C
C3814 B C 2B
C3815 B C 2B
C3816 B C 2B
C3817 B C 2B
C3818 B C 2B
C3819 B C 2B
C3820 B C 3C
C4201 B C 2A
C4202 B C 2A
C4203 B C 2A
C4204 B C 2A
C4205 B C 2A
C4206 B C 2B
C4207 B C 2B
C4208 B C 2B
C4209 B C 2B
C4210 B C 2B
C4211 B C 2A
C4212 B C 2A
C4213 B C 2A
C4214 B C 2A
C4215 B C 2A
C4216 B C 2A
C4217 B C 2A
C4218 B C 2A
C4219 B C 2A
C4220 B C 2A
C4301 B C 3A
C4302 B C 3A
C4303 B C 3A
C4304 B C 3A
C4305 B C 2A
C4306 B C 3A
C4307 B C 2A
C4308 B C 2A
C4309 B C 2A
C4310 B C 3A
C4311 B C 3B
C4312 B C 3B
C4313 B C 3B
C4314 B C 3A
C4315 B C 3A
C4316 B C 2B
C4317 B C 3B
C4318 B C 3B
C4803 A C 1C
C4804 A C 1C
C4806 A C 1C
C4807 A C 1C
C4808 A C 1C
C4809 A C 1C
C4810 A C 1C
C4811 A C 1C
C4812 A C 1C
C4813 A C 1C
C4814 A C 2C
C4815 A C 1C
C4819 A C 2C
C4820 A C 1C
C4822 A C 1C
C4823 A C 2C
C4851 A C 2B
C4852 A C 2B
C4853 A C 2B
C4854 A C 2B
C4855 A C 2B
C4858 A C 1C
C4859 A C 1C
C4860 A C 1C
C4861 A C 1C
C4862 A C 1C
C4863 A C 1C
C4864 A C 1B
C4865 A C 1B
C4866 A C 1B
C5001 A C 2A
C5002 A C 2A
C5003 A C 2A
C5004 A C 2A
C5005 A C 2A
C5006 A C 2A
C5007 A C 2A
C5008 A C 2A
C5009 A C 2A
C5010 A C 2A
C5011 A C 2A
C5012 A C 3A
C5013 A C 3A
C5014 A C 3A
C5015 A C 2B
C5016 A C 2B
C5017 A C 2B
C5018 A C 2B
C5019 A C 2B
C5020 A C 2B
C5021 A C 2B
C5022 A C 2B
C5023 A C 2A
C5024 A C 2A
C5025 A C 2A
C5026 A C 2A
C5027 A C 2A
C5028 A C 2A
C6001 A C 3B
C6004 A C 4B
C6005 A C 4B
C6101 A C 4C
C6102 A C 5D
C6103 A C 4C
C6105 A C 4D
C6106 A C 4B
C6107 A C 4A
C6108 A C 4A
C6109 A C 4A
C6110 A C 3A
C6111 A C 3A
C6112 A C 3A
C6113 A C 3A
C6114 A C 3A
C6115 A C 3A
C6116 A C 3A
C6117 A C 3A
C6118 A C 3A
C6119 A C 3A
C6120 A C 3A
C6121 A C 3B
C6122 A C 3B
C6123 A C 3B
C6124 A C 3B
C6125 A C 3B
C6126 A C 3B
C6127 A C 3B
C6128 A C 3B
C6129 A C 3B
C6130 A C 4B
C6131 A C 5B
C6132 A C 5C
C6134 A C 4B
C6201 A C 5C
C6202 A C 4B
C6203 A C 4B
C6204 A C 4B
C6205 A C 4B
C6206 A C 4C
C6207 A C 4B
C6208 A C 4B
C6209 A C 4C
C6210 A C 3C
C6211 A C 3C
C6212 A C 3B
C6213 A C 4B
C6214 A C 5B
C6215 A C 5B
C6216 A C 5B
C6217 A C 4B
C6218 A C 4B
C6219 A C 4B
C6220 A C 5C
C6221 A C 5C
C6222 A C 5C
C6224 A C 4A
C6225 A C 4A
C6226 A C 4A
C6227 A C 5B
C6228 A C 4B
C6230 A C 4A
C6231 A C 1C
C6701 A C 4C
C6703 A C 3C
C6704 A C 3C
CONNECTOR
CN101 A C 3D
CN102 B C 1C
CN103 A C 5B
CN104 A C 5C
CN105 B C 5B
CN106 A C 1C
CN107 A C 2B
CN108 A C 1B
CN109 A C 5C
CN110 A C 2D
CN111 A C 4A
CN112 B C 4D
CN113 A C 1C
DIODE
D1001 B C 5B
D1002 B C 5B
D1602 B C 2C
D1603 B C 2C
D1604 B C 3D
D3001 B C 4D
D3002 B C 4C
D3003 B C 4C
D3004 B C 3D
D3701 A C 2B
D5001 A C 2A
D6002 A C 4B
D6201 A C 4C
D6202 A C 4C
D6203 A C 4C
D6204 A C 4B
D6205 A C 4B
D6206 A C 5C
D6207 A C 4A
D6208 A C 5B
D6701 A C 3C
D6702 A C 4C
FUSE
F6101 A C 5C
IC
IC1001 B C 4A
IC1002 A C 4A
IC1003 B C 5B
IC1004 B C 3A
IC1005 B C 4A
IC1006 B C 3C
IC1007 B C 5B
IC1008 B C 4B
IC1009 B C 4A
IC1401 B C 4B
IC1601 B C 2C
IC1602 B C 3C
IC2001 B C 1C
IC2501 B C 2C
IC3001 B C 4C
IC3002 B C 3C
IC3004 B C 3C
IC3005 B C 4C
IC3007 B C 3C
IC3501 A C 2C
IC3502 A C 3C
IC3701 A C 3B
IC3731 B C 3B
IC3801 B C 2B
IC3802 B C 3C
IC4201 B C 2A
IC4202 B C 2A
IC4301 B C 3B
IC4302 B C 3A
IC4303 B C 2A
IC4802 A C 1C
IC4803 A C 1C
IC4804 A C 2C
IC4807 A C 2C
IC4851 A C 1C
IC5001 A C 2A
IC5002 A C 2A
IC5003 A C 2A
IC6001 A C 3B
IC6101 A C 3A
COIL
L1002 B C 4A
L1401 B C 4B
L2001 B C 1B
L2002 B C 1D
L2101 A C 1C
L2102 A C 1C
L2103 A C 1C
L2501 B C 1B
L3001 B C 3D
L3002 B C 5B
L3003 B C 4B
L3004 B C 4D
L3005 B C 5B
L3006 B C 4C
L3007 B C 4D
L3008 B C 4C
L3009 B C 4C
L3012 B C 4D
L3014 B C 3C
L3015 B C 3C
L3501 A C 3C
L3502 A C 3C
L3503 A C 2B
L3504 A C 2C
L3505 A C 2C
L3701 A C 3C
L3731 A C 2B
L3732 B C 3B
L3801 B C 2B
L3802 B C 2B
L3803 B C 2B
L3804 B C 2B
L4201 B C 2A
L4301 B C 3A
L4302 B C 2A
L4303 B C 2A
L4304 B C 2B
L4305 B C 3A
L4802 A C 1C
L4851 A C 2B
L4852 A C 2B
L4853 A C 1C
L5001 A C 2A
L5002 A C 2A
L5003 A C 2A
L5004 A C 2B
L5005 A C 2B
L5006 A C 2B
L5007 A C 3B
L6101 A C 5C
L6102 A C 4C
L6201 A C 4C
L6202 A C 4C
L6203 A C 4C
L6204 A C 3C
L6205 A C 4B
L6206 A C 4B
L6207 A C 4B
L6208 A C 5B
L6701 A C 4C
TRANSISTOR
Q1001 B C 5B
Q1002 B C 5B
Q1003 B C 4A
Q1004 B C 5B
Q1005 B C 4A
Q1006 B C 4A
Q1007 B C 4A
Q1008 B C 4A
Q1009 B C 4A
Q1401 B C 4B
Q1402 B C 4B
Q1403 B C 4B
Q1601 B C 2C
Q2001 B C 2D
Q2002 B C 1C
Q2101 B C 1D
Q2102 B C 1C
Q2103 B C 1C
Q2501 B C 2C
Q3001 B C 3D
Q3002 B C 3C
Q3701 B C 2C
Q3702 A C 3B
Q3703 B C 2C
Q3704 B C 3C
Q3705 A C 2B
Q3731 A C 2B
Q3732 A C 2B

4-4
REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION
Q3733 A C 2B
Q3734 A C 2B
Q3735 B C 3B
Q4801 A C 1C
Q4802 A C 2C
Q4803 A C 2C
Q4804 A C 2C
Q4805 A C 2C
Q4806 A C 2C
Q4851 A C 2C
Q6001 A C 3B
Q6002 A C 3B
Q6004 A C 4B
Q6201 A C 4C
Q6202 A C 4B
Q6203 A C 4C
Q6204 A C 4C
Q6205 A C 3C
Q6206 A C 3C
Q6207 A C 3B
Q6208 A C 4B
Q6210 A C 4B
Q6211 A C 5C
Q6212 A C 4A
Q6213 A C 4A
Q6214 A C 4A
Q6215 A C 4A
Q6216 A C 4A
Q6217 A C 4B
Q6701 A C 4C
RESISTOR
R101 A C 5B
R102 A C 5B
R1001 B C 5B
R1002 B C 4A
R1003 B C 4A
R1004 B C 3A
R1005 B C 4A
R1006 B C 5A
R1007 B C 4A
R1008 B C 3A
R1009 B C 4A
R1010 B C 3A
R1011 B C 4A
R1012 B C 4A
R1014 B C 4A
R1015 B C 4A
R1016 B C 5B
R1017 A C 5C
R1018 B C 5B
R1019 B C 4A
R1020 B C 4B
R1021 B C 4B
R1022 B C 4B
R1023 B C 3A
R1024 B C 3A
R1026 B C 5B
R1027 B C 3A
R1028 B C 4A
R1029 B C 4A
R1030 B C 4A
R1031 B C 3A
R1032 B C 3A
R1036 B C 4A
R1037 B C 4A
R1038 B C 3A
R1039 B C 4B
R1044 B C 4A
R1045 B C 4A
R1046 B C 3A
R1047 B C 4A
R1048 B C 3A
R1049 B C 4A
R1050 B C 4A
R1051 B C 5B
R1052 B C 5B
R1053 B C 5B
R1054 B C 5B
R1055 B C 5B
R1056 B C 5B
R1057 B C 4A
R1058 B C 4A
R1060 B C 4A
R1061 B C 3B
R1066 B C 5B
R1071 B C 4A
R1072 B C 4B
R1076 B C 4A
R1077 B C 4A
R1078 B C 4A
R1079 B C 4A
R1080 B C 4A
R1081 B C 4A
R1082 B C 4A
R1083 B C 4A
R1401 B C 4B
R1402 B C 4B
R1403 B C 4B
R1404 B C 4B
R1405 B C 4B
R1406 B C 4B
R1407 B C 5B
R1408 B C 4B
R1409 B C 4B
R1410 B C 4C
R1411 B C 4B
R1412 B C 4B
R1413 B C 4B
R1414 B C 4B
R1415 B C 4B
R1416 B C 4B
R1417 B C 5B
R1421 B C 4B
R1422 B C 4B
R1423 B C 4C
R1425 B C 4B
R1426 B C 4B
R1601 B C 2D
R1602 B C 2D
R1603 B C 2C
R1604 B C 2D
R1605 B C 2C
R1609 B C 3C
R1610 B C 3D
R1611 B C 3D
R1612 B C 3C
R1613 B C 3C
R1614 B C 2C
R1615 B C 2C
R1616 B C 3D
R1617 B C 2C
R1618 B C 2C
R1619 B C 2C
R1620 B C 2C
R1621 B C 2D
R1622 B C 3C
R1624 B C 2C
R1625 B C 4C
R1626 B C 4C
R1628 B C 2C
R1629 B C 2D
R1630 B C 3D
R1631 B C 3D
R1635 B C 2C
R1636 B C 2C
R1637 B C 2C
R1643 B C 2C
R2001 B C 1D
R2004 B C 1D
R2005 B C 1D
R2006 B C 2C
R2007 B C 2D
R2008 B C 2D
R2009 B C 2C
R2010 B C 2C
R2011 B C 2C
R2012 B C 2C
R2013 B C 2C
R2014 B C 2D
R2015 B C 2D
R2016 B C 2D
R2017 B C 1C
R2018 B C 2C
R2019 B C 1D
R2020 B C 1D
R2023 B C 2C
R2024 B C 2C
R2025 B C 2C
R2028 B C 1C
R2029 B C 1D
R2103 B C 1C
R2104 B C 1C
R2105 B C 1C
R2106 B C 1C
R2107 B C 1C
R2108 B C 1C
R2109 B C 1C
R2110 B C 1C
R2111 B C 1D
R2112 B C 1C
R2113 B C 1D
R2114 B C 1C
R2115 B C 1D
R2116 B C 1C
R2117 B C 1D
R2118 B C 1C
R2119 B C 1D
R2120 B C 1C
R2121 B C 1D
R2122 B C 1C
R2123 B C 1D
R2124 B C 1C
R2125 B C 1D
R2126 B C 1C
R2127 B C 1D
R2128 B C 1C
R2129 B C 1C
R2201 A C 1C
R2202 A C 1C
R2203 B C 1C
R2501 B C 1B
R2502 B C 1B
R2503 B C 1B
R2504 B C 1B
R2505 B C 1B
R2506 B C 1B
R2507 B C 1B
R2508 B C 1B
R2509 B C 2C
R2510 B C 2C
R2511 B C 2C
R2512 B C 2C
R2513 B C 2C
R3002 B C 4C
R3003 B C 3C
R3004 B C 4C
R3005 B C 4C
R3006 B C 4C
R3007 B C 4C
R3008 B C 4D
R3009 B C 4C
R3010 B C 4D
R3011 B C 4D
R3013 B C 5C
R3014 B C 5C
R3015 B C 5C
R3016 B C 5C
R3017 B C 5C
R3018 B C 5C
R3019 B C 5C
R3020 B C 5C
R3025 B C 3D
R3026 B C 3D
R3027 B C 4C
R3029 B C 4C
R3030 B C 4C
R3031 B C 4C
R3032 B C 4C
R3033 B C 4C
R3034 B C 4C
R3036 B C 5C
R3037 B C 5D
R3040 B C 3C
R3041 B C 3C
R3042 B C 3C
R3043 B C 3D
R3044 B C 3D
R3045 B C 3C
R3046 B C 3C
R3047 B C 4C
R3048 B C 4C
R3049 B C 3C
R3050 B C 3C
R3051 B C 4C
R3057 B C 4C
R3059 B C 4B
R3066 B C 4C
R3067 B C 4C
R3068 B C 3C
R3069 B C 3C
R3070 B C 3C
R3071 B C 4C
R3072 B C 3C
R3073 B C 3C
R3074 B C 3C
R3075 B C 3C
R3501 A C 2C
R3502 A C 2C
R3503 A C 2C
R3504 A C 2C
R3505 A C 2C
R3506 A C 2C
R3507 A C 2C
R3508 A C 3C
R3509 A C 2C
R3510 A C 2C
R3511 A C 3C
R3512 A C 3C
R3521 A C 3C
R3522 A C 2C
R3701 B C 2B
R3702 B C 2C
R3703 A C 3B
R3704 B C 2C
R3705 B C 2C
R3706 A C 3B
R3707 A C 3B
R3708 A C 3C
R3709 A C 3B
R3710 A C 3B
R3711 A C 3B
R3712 A C 3B
R3713 A C 3B
R3714 A C 3B
R3715 A C 3B
R3721 B C 2C
R3722 B C 2C
R3723 B C 2C
R3724 B C 3C
R3725 A C 2B
R3726 A C 2B
R3727 A C 2B
R3728 A C 2B
R3730 A C 2B
R3731 A C 2B
R3732 A C 2B
R3733 A C 2B
R3734 A C 2B
R3735 A C 2B
R3736 A C 2B
R3737 A C 2B
R3738 A C 2B
R3739 A C 2B
R3740 A C 2B
R3741 A C 2B
R3742 B C 3B
R3743 B C 3B
R3744 B C 3B
R3745 B C 3B
R3746 B C 3B
R3747 B C 3B
R3748 B C 3B
R3801 B C 2C
R3802 B C 2C
R3803 B C 2B
R3804 B C 2B
R3805 B C 2B
R3806 B C 2B
R3807 B C 3B
R3808 B C 3B
R3809 B C 3C
R4201 B C 2B
R4203 B C 2A
R4204 B C 2A
R4205 B C 2A
R4301 B C 2B
R4302 B C 3A
R4303 B C 3B
R4304 B C 3B
R4305 B C 3A
R4306 B C 3B
R4307 B C 3B
R4308 B C 3B
R4309 B C 3B
R4310 B C 3B
R4311 B C 3B
R4312 B C 3B
R4313 B C 3B
R4314 B C 3B
R4315 B C 3B
R4316 B C 2B
R4317 B C 2B
R4320 B C 3A
R4321 B C 3A
R4322 A C 3A
R4323 A C 3B
R4804 A C 2C
R4805 A C 1C
R4806 A C 1C
R4807 A C 1C
R4808 A C 1C
R4809 A C 1C
R4810 A C 1C
R4811 A C 1C
R4812 A C 1C
R4813 A C 1C
R4814 A C 1C
R4815 A C 1C
R4816 A C 1C
R4817 A C 2C
R4818 A C 2C
R4819 A C 1C
R4820 A C 1C
R4821 A C 1C
R4822 A C 2C
R4823 A C 2C
R4824 A C 1C
R4825 A C 2C
R4826 A C 2C
R4827 A C 1C
R4828 A C 2C
R4829 A C 1C
R4830 A C 2C
R4831 A C 2C
R4833 A C 2C
R4836 A C 2C
R4837 A C 2C
R4839 A C 2C
R4840 A C 2C
R4841 A C 2C
R4842 A C 2C
R4843 A C 2C
R4844 A C 2C
R4845 A C 2C
R4846 A C 2C
R4847 A C 2C
R4849 A C 2C
R4850 A C 2C
R4852 A C 1B
R4854 A C 1C
R4855 A C 1C
R4856 A C 1C
R4857 A C 1C
R4858 A C 2C
R4859 A C 2C
R4860 A C 2C
R4862 A C 1B
R4863 A C 1B
R4864 A C 1B
R4865 A C 1B
R4866 A C 1B
R4867 A C 1B
R4868 A C 1B
R4870 A C 2C
R4871 A C 1B
R4872 A C 2C
R4874 A C 1B
R5001 A C 2A
R5002 A C 3A
R5003 A C 3A
R5004 A C 3A
R5005 A C 3A
R5006 A C 2A
R5009 A C 2A
R5010 A C 3A
R5017 A C 2A
R5020 A C 3A
R6001 A C 3B
R6002 A C 3B
R6003 A C 3B
R6004 A C 3B
R6005 A C 3B
R6009 A C 4A
R6010 A C 4B
R6011 A C 4B
R6012 A C 4B
R6013 A C 4B
R6101 A C 4A
R6102 A C 4A
R6103 A C 4A
R6106 A C 3A
R6107 A C 3A
R6108 A C 3A
R6113 A C 3A
R6114 A C 3B
R6115 A C 3B
R6116 A C 3A
R6117 A C 3B
R6118 A C 3B
R6124 A C 4B
R6201 A C 4B
R6202 A C 4B
R6203 A C 4B
R6204 A C 4B
R6205 A C 4B
R6206 A C 4B
R6207 A C 4B
R6208 A C 4B
R6209 A C 4B
R6210 A C 3C
R6211 A C 3C
R6212 A C 3C
R6213 A C 3C
R6214 A C 3C
R6215 A C 3C
R6216 A C 3C
R6217 A C 4B
R6218 A C 4B
R6219 A C 5B
R6220 A C 5B
R6221 A C 5B
R6222 A C 5B
R6223 A C 5B
R6224 A C 4B
R6225 A C 4B
R6226 A C 4B
R6227 A C 4A
R6228 A C 4A
R6229 A C 4A
R6230 A C 4A
R6231 A C 4A
R6232 A C 4A
R6233 A C 4A
R6234 A C 4A
R6235 A C 4A
R6236 A C 4A
R6237 A C 4A
R6238 A C 4A
R6239 A C 4A
R6240 A C 4A
R6241 A C 4A
R6242 A C 4A
R6243 A C 4A
R6244 A C 4B
R6245 A C 4B
R6246 A C 4B
R6247 A C 4A
R6701 A C 3C
R6702 A C 3C
R6703 A C 3C
R6704 A C 5B
R6705 A C 5B
RA1008 B C 4B
RA1009 B C 4A
RA1010 B C 5B
RA1401 B C 4B
RA3001 B C 4C
RA3002 B C 4C
RA3003 B C 4C
RA3004 B C 5C
RA3005 B C 5C
RA4201 B C 2A
RA4202 B C 2A
RA4301 B C 3A
RA4302 B C 3A
RA4303 B C 3A
RA4304 B C 3A
RA4305 B C 3B
RA4306 B C 3B
RA4307 B C 2B
RA4308 B C 2B
OTHER
TL1001 B C 5A
TL1002 B C 4A
TL1003 B C 4A
TL1004 B C 4A
TL1005 B C 4A
TL1007 B C 4A
TL1009 B C 4A
TL1027 B C 4A
TL1029 B C 4A
TL1030 B C 4A
TL1031 B C 4A
TL1032 B C 4A
TL1033 B C 4A
TL1034 B C 4A
TL1035 B C 4A
TL1036 B C 4A
TL1038 B C 4A
TL1401 B C 4B
TL1402 B C 4B
TL1403 B C 4B
TL1404 B C 4B
TL1405 B C 4B
TL1406 B C 4B
TL1407 B C 4B
TL1408 B C 5B
TL1409 B C 4B
TL1410 B C 5B
TL1411 B C 5B
TL1412 A C 3B
TL1413 A C 3B
TL1414 B C 4B
TL1415 A C 4B
TL1416 A C 4B
TL1417 A C 4B
TL1418 A C 4B
TL1419 A C 4B
TL1420 B C 5B
TL1601 B C 3D
TL1602 B C 3C
TL1603 B C 3C
TL1604 B C 2C
TL1605 A C 3D
TL1606 A C 2D
TL1607 A C 3D
TL1608 A C 3D
TL1609 A C 2D
TL1610 A C 2D
TL1611 B C 3C
TL1612 B C 3D
TL1613 B C 3D
TL1614 B C 2C
TL1617 B C 3D
TL1618 A C 3D
TL1619 A C 3D
TL1620 A C 3D
TL1621 A C 3D
TL1622 A C 3D
TL3001 B C 4C
TL3002 B C 4C
TL3004 B C 4C
TL3005 B C 4D
TL3006 B C 5C
TL3501 B C 4B
TL3801 B C 3B
TL3802 B C 3B
TL4201 B C 2B
TL4202 B C 2A
TL4304 B C 2B
TL4305 B C 2B
TL4306 B C 2B
TL4308 B C 2B
TL4309 B C 3B
TL4310 B C 3B
TL4311 B C 3B
TL4312 B C 3A
TL4313 B C 3A
TL4314 B C 3B
TL4315 B C 3B
TL4316 B C 3B
TL4317 B C 2B
TL4318 B C 2B
TL4319 B C 2B
TL4801 A C 1C
TL5001 A C 3A
TL5002 A C 3A
TL5004 A C 3A
X1001 B C 4B
X1002 A C 4A
X1401 B C 4B
X3001 B C 4C
X3002 B C 4C
X4301 B C 2B
COMPONENT PARTS LOCATION GUIDE <MAIN/YB10391-01-01> (2/2)

CN110
TG2
C3504
C3516
C3517C3520C3524
C3506
C3502
S-CASE-L3
C6120
L2101
L2103
R2202
C2201
R35
1
R3714
R3715
R4323
C
C3707
C3709
C3706
L3503
IC3701
R4827
R4836
R4808R4809 R4810
R4814
R4819
R4829
R4837
R4841
R4850
R4852
R4856 R4857
R4862R4863
R4859
R4874
R4843
R4846
R4871
C4806
C4812
C4820
C4822
C4808
C4815
L4802
Q4851
IC4802
IC4803
IC4851
R6001
R6116
C6118
C6119
C6121
C6122
C6123 C6124
C6125C6126
TL1606
TL1609
TL1610
TL4801
R4825
R4839
R4840
R4844
R4849
CN113
CN108
C4803
C4864
R5002
R5003
R5017
C5002
C5005 C5006
C5007
C5011
C5012
C5013
C5014
C5001
L5001
L5002
L5003
L5004
L5006
C5009
C5025
D5001
IC5001
R3730
R3732
R3733
R3734
R3735
R3737
R3739
R3740
R3741
C3714
C3731
C3733
C3735
C3737
C3738
Q3731
Q3732
Q3734
TL5001
TL5002
TL5004
C3526 R3501 R3502
R3503
R3504 R3505 R3506 R3507
R3508
R3509 C3505C3507C3508C3509C3510
C3511 C3513 C3514 C3515
C3518 C3519 C3521 C3523
C3512
C3522 C3525
L3501
L3502
L3504L3505
C3501
C3503
IC3501
R3521
R3522
S-CASE
S-CASE-L1 S-CASE-L2
C3527
L2102
R2201
C2202
R3510
R3703 R3706
R3707 R3711
R3712
R3713
R4322
C3715
Q3702
D3701
R4828
R4804
R4805
R4806
R4807
R4811
R4812 R4813
R4815R4816
R4817 R4818
R4820
R4821
R4822 R4823
R4824
R4831
R4833
R4845
R4855
R4858
R4864 R4865 R4866 R4867
R4870
R4872
R4842
R4854
R4868
C5023
C5026 C5027
R4847
R4860
C4804
C4807
C4809
C4810 C4811
C4813
C4814
C4823
C4852
C4858 C4859 C4860 C4861 C4862
C4865
C4866
C5024
C4819
C4855
L4851
L4852
L4853
C4853
C4854
Q4801
IC4804
R6004 R6005
R6114 R6115
C6231
Q6001 IC6001
R4826
C3708
R4830
C4863
Q4802
Q4803
Q4804
Q4805
Q4806 IC4807 CN107
CN106
C4851
R5001
R5004 R5005
R5006 R5010
R5020
R5009
C5010
C5015 C5018
C5004
C5019 C5022
L5005
L5007
C5008
C5016 C5017 C5020
C5021
C5003 C5028
IC5003
IC5002
R3710
R3725
R3726 R3727
R3728
R3731
R3736 R3738
C3732 C3734
C3736
C3739
L3731
Q3705
Q3733
123
1
38
19
20
17
8
1
5
4
8
1
5
4
1 33
14 85
14 85
116
4833
6417 4932
18
8
9
1
16
191
3 1
4 5
8 1
5 4
36
1
25
12
24
13
37
48
50
51
1
2
4
3
48 33
15
A
B
C
D
12
0 1 MAIN PWB
YB10391-01-01
4-5
COMPONENT SIDE(A)

TG1
C6106
C6107
C6108
C6109
C6213
L6701
IC1002
Q6208Q6210
R3511
R3708
R6222
C3528
R6247
L3701
CN111
R
6001 R6002
R6003
R6010R6011
R6103
R6106
R6201
R6202
R6203
R6204
R6205
R6207
R6208
R6209
R6217
R6219 R6220
R6221 R6223
R6224 R6225
R6226
R6227
R6229
R6232
R6234
R6237
R6240
R6241
R6245
R6246
R6704
R6705
R6009
C6001
C6130
C6134
C6203
C6208
C6216
C6225
C6101C6103
C6105
C6212
C6215
C6218C6219
C6226
C6230
C6703
C6202
C6210
C6228
L6204
Q6206
Q6216
Q6202
Q6213
Q6212
Q6217
Q6205
D6207
D6002
F6101
D6204D6205
L6206L6207
R6701
TL1412TL1413
TL1415
TL1416
TL1417
TL1418TL1419
TL1605 TL1607
TL1608
TL1618
TL1619
TL1620
TL1621
TL1622
CN101
R3709
R3521
-C E-L2
C6004
C6205
C1006
L6205
Q6002
Q6201
Q6203
Q6207
X1002
Q6211
R101 R102
R3512 C3701
C3712 C3713
IC3502
R6004 R6005
R6012 R6013
R6101 R6102
R6107 R6108 R6113
R6118
R6124
R6206
R6210 R6211 R6212
R6213R6214
R6215 R6216
R6218
R6228 R6230
R6231
R6233 R6235 R6236
R6238
R6239
R6242
R6243
R6244
R6702 R6703
R6117
C6005
C6110 C6111 C6112 C6113 C6114 C6115 C6116 C6117
C6127 C6129
C6131
C6132
C6204
C6211
C6224
C6704 C6128
C6201
C6206
C6209
C6214 C6217
C6220
C6701
C6207
C6221
C6222
C6227
C6102
Q6001
Q6214
Q6215
Q6204
Q6701
Q6004
IC6001
IC6101
L6201 L6202
L6203
D6201
D6202
D6203
D6701
D6702
L6101
L6102
L6208
D6206
D6208
R1017
C3708
CN103
CN109
CN104
1
100
4
5
1
8
1
2
4
3
116
48 33
1764 3249
1 3
5 4
1 40
115
16
111
3
4
5
4-6
E. & O. E. No. 86683
(Sanwa)-M2D229/249
GR-DVL820A/A-S/EA/SH, DVL1020A/EA/SH

Printed in Japan
VICTOR COMPANY OF JAPAN, LIMITED
VIDEO DIVISION S40894

5-1
SECTION 5
PARTS LIST
SAFETY PRECAUTION
Parts identified by the symbol are critical for safety. Replace only with specified part numbers.
5.1 PACKING AND ACCESSORY ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
1
LABEL
(SERIAL)
7
13
14
6
4
15
5
2
31
34
33
18
30 32
19
21
20
25
24
36
38
3
37
FINAL ASSY
<M2>
41 17 16
26
29

5-2
#REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- -----------------------------------------------------
MODEL MARK
GR-DVL820A A
GR-DVL820A-S B
GR-DVL820EA C
GR-DVL820SH D
GR-DVL1020A E
GR-DVL1020EA F
GR-DVL1020SH G
******************************
PACKING AND ACCESSORY ASSEMBLY <M1>
1 LY32567-021A PACKING CASE,A,B,C
LY32567-008A PACKING CASE,E,F
LY32567-017A PACKING CASE,D
LY32567-019A PACKING CASE,G
2 LY32568-001A CUSHION
3 LY30023-022A POLY BAG
4 QPA02003506 POLY BAG
! 5 LYT0963-001A INST.BOOK(EN),A,B,C,E,F
! LYT0963-002A INST.BOOK(CH),A,B,E
! LYT0963-003A INST.BOOK(RU),A,B,E
! LYT0963-004A INST.BOOK(AR),A,B,E
! LYT0963-005A INST.BOOK(GE),A,B,E
! LYT0963-006A INST.BOOK(FR),A,B,E
! LYT0964-001A INST.BOOK(EN),D,G
! LYT0964-002A INST.BOOK(CH),D,G
! LYT0964-003A INST.BOOK(RU),D,G
6 LYT0912-001A INST.BOOK(SOFT.EN),A,B,C,D
LYT0912-002A INST.BOOK(SOFT.GE),A,B
LYT0912-003A INST.BOOK(SOFT.FR),A,B
LYT0912-011A INST.BOOK(SOFT.CH),A,B,D
LYT0912-012A INST.BOOK(SOFT.RU),A,B,D
LYT0931-001A INST.BOOK(SOFT.EN),E,F,G
LYT0931-002A INST.BOOK(SOFT.GE),E
LYT0931-003A INST.BOOK(SOFT.FR),E
LYT0931-011A INST.BOOK(SOFT.CH),E,G
LYT0931-012A INST.BOOK(SOFT.RU),E,G
7 LYT0934-001A SHEET(AGREMENT),A,B,C,D
13 LYT0609-001A SHEET(CON.PLUG),A,B,E
14 BT-56002-2 SER.NET CARD,C,F
15 QPA01703005 POLY BAG
16 QAM0212-001 CABLE ASSY,AUDIO/VIDEO CABLE
17 QQR0918-002 CORE FILTER
18 PEAC0428-150 CABLE ASSY,EDITING CABLE
19 QQR0491-002 CORE FILTER
20 QAM0324-001 USB CABLE
21 QQR0491-002 CORE FILTER
! 24 LY20847-001C AC ADAPTER,AP-V12EG
25 QQR0917-002 CORE FILTER
! 26 QMPL120-190-JR POWER CORD,A,D,E,G
! QMPH020-190-JR POWER CORD,C,F
! QMPS110-190-JR POWER CORD,B
! 29 PEMC1012 CONVERSION PLUG,B
! PEMC1012-02 CONVERSION PLUG,A,E
! QAM0001-001 CONVERSION PLUG,D,G
! 30 LY32566-001A BATTERY PACK ASSY,BN-V408U
31 LY20186-001A SHOULDER STRAP
32 LY20750-001A REMOTE CONTROL UNIT,RM-V717U
33 – BATTERY,AAA(R03),X2
34 LY32210-023A CD ROM ASSY,A,B,C,D
LY32210-038A CD ROM ASSY,E,F,G
36 LY43322-002A CAP(M)ASSY
37 QAM0342-002 MEMORY CARD,8MB(SD)
38 BT-56001-2 WARRANTY CARD,C,F
41 QQR0491-002 CORE FILTER
•INSTRUCTIONS
EN ....... ENGLISH
CH ...... CHINESE
RU ....... RUSSIAN
AR ....... ARABIC
GE ...... GERMANY
FR ....... FRENCH

5-3
5.2 FINAL ASSEMBLY <M2>
125H
140T
140U
140T
140
140T
140T
140C
140E
140S
140S
140S
141
142 142 131
140S
140K
140J
140P
140H
k
140R
140R
m
a
a
140G
144
RATING
LABEL
140N
140M
140N
140N
141
140R
140F 143 131
140D
140L
140B
140A
140L
140L
140L
bb
125D
125C
125K
125B
125A
125
126
b
d
d
t
173
125E
OPTICAL BLOCK
SECTION
251
c
c
171
170A
170B
170
172
12
5
125F
125G
125E
12
5
1
1
111
p
g
251C
251C
251E
251F
251G
251A
251D 251C
251J
252
s
251D
251C
251C
251B
r251H
251H
CCD
<04>
166

5-4
153
135
132
132
133
130E
130C
130E
130D
134
130B 130A
130
151
159
101K
101M
101J
101H
101C
101C
101M
101F
101B
101E
101G
101K
101A
162
101L
101L
115
118
119
121
119
114
109
103
122
105
108
107
101D
MECHANISM
<M3>
116 116
101
bb
aa
zcc
wu
t
aa
v
m
bb
y
n
z
g
n
ee
j
k
fdd
o
j
yx
w
p
u
125E
125E
e
h
MONITOR
<M5>
JACK
<06>
JUNCTION
<05>
MAIN
<01>
DSC
<10>
REAR
<07>
MONITOR
<02>
ELECTRONIC
VIEWFINDER
<M4>
102
102
120
118
152
163
152
156
165
156
158
131
130F
130F
130F
158
157
153
153
150
b
e
q
gg
ff
gg
160
160
104
114
104
117
164
110
110
110
110
111
106
106
112
p
dd
h
ff
113
110
f
v
s
r
o
qx
cc
ee
155 154
166

#REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
5-5
******************************
FINAL ASSEMBLY <M2>
101 LY20774-005B UPPER CASE(2.5)ASSY,A
LY20774-005C UPPER CASE(2.5)ASSY,B,C,D
LY20797-004C UPPER CASE(3.5)ASSY,E,F,G
101A LY20775-001A TOP COVER(2.5),A,B,C,D
LY20776-001A TOP COVER(3.5),E,F,G
101B LY32371-003A PLATE(UPPER)
101C LY40664-001A SPACER,X2
101D LY31019-001A BASE
101E LY32375-001B COVER(SD)
101F LY43292-001A SHAFT
101G LY43293-001A SPRING
101H LY43261-001A HOOK(UPPER)
101J LY32886-001A BRAKET(EARTH)2.5,A,B,C,D
LY32887-001A BRAKET(EARTH)3.5,E,F,G
101K LY30018-023A SPECIAL SCREW,X2
101L LY30018-084A SPECIAL SCREW,X2
101M LY30018-084A SPECIAL SCREW,X2,A,B,C,D
LY30018-038A SPECIAL SCREW,X2,E,F,G
102 LY30018-0D6A SPECIAL SCREW,X2
103 LY32373-001A BRACKET(MONITOR)
104 LY30018-066A SPECIAL SCREW,X2
105 LY20777-001A COVER(HINGE)
106 LY30018-047A SPECIAL SCREW,X2
107 LY43263-001A KNOB(SLIDE)
108 LY43263-002A KNOB(SLIDE)
109 QAS0048-001 SPEAKER
110 LY30018-023A SPECIAL SCREW,X5
111 LY30018-047A SPECIAL SCREW
112 QUQ105-4007AA FFC WIRE,MONI CN761-MAIN CN101
113 QUQ105-1011AA FFC WIRE,MONI CN762-DSC CN8002
114 LY30018-084A SPECIAL SCREW,X2
115 LY30018-084A SPECIAL SCREW
116 LY30018-047A SPECIAL SCREW,X2
117 LY30018-047A SPECIAL SCREW
118 LY30018-064A SPECIAL SCREW,X2
119 LY30018-099A SPECIAL SCREW,X2
120 LY43566-003A STICKER(SIDE)
121 LY30018-084A SPECIAL SCREW
122 LY30029-0Y5A SPACER(A),A,B,C,D,F,G
125 LY32382-007A FRONT COVER ASSY
125A LY32383-001A HOOD
125B LY32687-001B RING(MEGA)
125C LY32705-001A HOOD(SCREW)
125D LY30018-084A SPECIAL SCREW
125E LY30018-0A7A SPECIAL SCREW,X4
125F LY32343-001A MICROPHONE
125G LY32388-001A BASE(LIGHT)
125H LY32338-001A DC LIGHT ASSY
125K LY32387-001A HOOD(MEGA)
126 LY43567-002A STICKER(TOP)
130 LY10317-001A REAR UNIT
130A LY32408-001A KNOB(BATT.RELE)
130B LY30001-018A TENSION SPRING
130C LY32409-001A TERMINAL BASE
130D LY43291-001A TERMINAL(R),X2
130E LY43290-001A TERMINAL(L),X3
130F LY30018-084A SPECIAL SCREW,X3
131 LY30018-084A SPECIAL SCREW,X3
132 LY30018-0C9A SPECIAL SCREW,X2
133 LY30018-0C9A SPECIAL SCREW
134 LY41691-001A COVER(JIG)
135 LY30018-037A SPECIAL SCREW
140 LY20769-003E LOWER CASE ASSY
140A LY32363-001A COVER(JACK)
140B LY32364-001B COVER(DC)
140C LY40592-001A CAP(GRIP BELT)
140D LY20770-001A ARM ASSY
140E LY30029-0T9A SPACER(A)
140F LY32365-001A PLATE
140G LY20780-001A GRIP BELT
140H LY10304-001A ZOOM UNIT
140J LY10309-001A CASSETTE COVER
140K LY43254-001B LOCK ASSY
140L LY30018-084A SPECIAL SCREW,X4
140M LY30018-038A SPECIAL SCREW
140N LY30018-038A SPECIAL SCREW,X3
140P LY30018-0D1A SPECIAL SCREW
140R LY30018-084A SPECIAL SCREW,X3
140S LY30018-023A SPECIAL SCREW,X4
140T LY30018-038A SPECIAL SCREW,X4
140U LY43609-001A SPACER(B)
141 LY30018-084A SPECIAL SCREW,X2
142 LY30018-084A SPECIAL SCREW,X2
143 LY30018-0C9A SPECIAL SCREW
144 LY43256-001B PLATE(ADJUST)
150 LY20778-001A BRACKET(MECHA)
151 YQ43893-4 MINI SCREW
152 LY30019-026A SPECIAL SCREW,X2
153 QYSPSPT1730R SCREW,X3
154 LY40698-002A LABEL(HOUSING)
155 LY40699-002A LABEL(PUSH)
156 LY30018-084A SPECIAL SCREW,X2
157 LY30018-066A SPECIAL SCREW
158 LY30018-066A SPECIAL SCREW,X2
159 LY30018-038A SPECIAL SCREW
160 LY30019-038A SPECIAL SCREW,X2
162 YQ43893-4 MINI SCREW
163 WJT0066-001A E-CARD WIRE,MAIN CN113-JUNC.CN571
164 LY30019-038A SPECIAL SCREW
165 LY30029-0V6A SPACER(A)
166 LY30029-0X1A SPACER(A)
170 LY43258-001A BRACKET(OP)ASSY
170A LY42796-001A BUSH
170B LY30016-0N9A SPACER-A
171 LY30018-084A SPECIAL SCREW
172 LY30018-066A SPECIAL SCREW
173 LY30019-029B SPECIAL SCREW
252 LY30029-0Z7A SPACER(A),B,C,D,E,F,G
– OPTICAL BLOCK SECTION –
251 J7C-112A OPTICAL BLOCK ASSY
251A LY31572-001A ZOOM MOTOR
251B LY31571-001A FOCUS MOTOR
251C LY30727-002A SCREW,X5
251D LY30727-001A SCREW,X2
251E LY43384-001A OPTICAL LPF
251F LY43494-001A SHEET
251G LYH30375-003A CCD BASE ASSY
251H QYSPSGU1750Z SCREW,X2
251J LY32721-001A IRIS MOTOR UNIT

5-6
5.3 ELECTRONIC VIEWFINDER ASSEMBLY <M4> [GR-DVL1020A/EA/SH]
308
311
308
310
310
308
308
309 309
309
302
312
300
301
306
307
303
304
314
305
342
343
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
#REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
306 PTY20712-041 LCD ASSY
307 QAL0287-001 FPC
308 LY30018-063A SPECIAL SCREW,X4
309 LY30018-055A SPECIAL SCREW,X3
310 LY30018-035A SPECIAL SCREW,X2
311 PTY20712-051 SCREW
312 LY41701-002A SHEET(CAUTION)1
314 LY43041-002A LABEL(VF)
342 LY43489-001B PLATE(VF)
343 LY43827-001A BRACKET(VF)
******************************
ELECTRONIC VIEWFINDER ASSEMBLY <M4>
300 LY20838-003A C.VF ASSY
301 PTY20712-001 EYE PIECE ASSY
302 PTY20712-011 TOP CASE SUB ASSY
303 PTY20712-021 BOTTOM CASE
304 PTY20712-022 CAP(VF)
305 PTY20838-031 HINGE ASSY

5-7
5.4 MONITOR ASSEMBLY <M5> [GR-DVL820A/A-S/EA/SH]
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
#REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
502A LY42388-001A EARTH MON(2)
504 LY20674-001A HOLDER(2.5)
505 LY31622-001A BRACKET(EARTH)
506 QLL0121-001 BACK LIGHT
507 QLD0154-001 LCD MODULE
508 LY32695-001A MONITOR FPC ASSY
508A LY32574-001A MONITOR FPC ASSY
508B LY32079-001A HINGE ASSY
508C LY32380-001A HINGE COVER(U)
508D LY32381-001A HINGE COVER(L)
508E LY30018-058A SPECIAL SCREW,X2
508F LY30018-023A SPECIAL SCREW
508G LY30029-0Q5A SPACER(A)
509 QYSPSPT1730R SCREW,X2
510 LY30018-0F2A SPECIAL SCREW,X2
511 LY30029-0Y4A SPACER(A)
507
506
504
LCD BL
<03>
510
508C
508E
508
508E
508A
c
508F
508B
508D
508G
c
501
500
501A
501C
501E
501H
501G
501J
501B
501F 501D
501D
a
b
509
505
b
502
a
502A
d
d
511
******************************
MONITOR ASSEMBLY <M5>
500 LYH20246-043B MONITOR ASSY
501 LY20863-001B MONITOR COVER(2.5MEGA)ASSY
501A LY31620-001A KNOB(LOCK 1)
501B LY42180-001A KNOB(LOCK 2)
501C LY30002-044A COMPRESSION SPRING
501D LY30018-084A SPECIAL SCREW,X2
501E LY42883-001A MARK
501F LY43784-001A EARTH MON(2.5)
501G LY32704-001A WINDOW(M.MEGA)
501H LY32706-001B PLATE(M2.5MEGA)
501J QLE0017-001 EL PANEL
502 LY20874-001A MONITOR CASE ASSY

5-8
5.4 MONITOR ASSEMBLY <M5> [GR-DVL1020A/EA/SH]
******************************
MONITOR ASSEMBLY <M5>
500 LYH20246-042B MONITOR ASSY
501 LY20864-001C MONITOR COVER(3.5MEGA)ASSY
501A LY31620-001A KNOB(LOCK 1)
501B LY42180-001A KNOB(LOCK 2)
501C LY30002-044A COMPRESSION SPRING
501D LY30018-084A SPECIAL SCREW,X2
501E LY42883-001A MARK
501F LY43785-001A EARTH MON(3.5)
501G LY32704-002A WINDOW(M.MEGA)
501H LY32707-001B PLATE(M3.5MEGA)
501J QLE0017-001 EL PANEL
502 LY20598-002A MONITOR CASE ASSY
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
#REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
502A LY42388-001A EARTH MON(2)
504 LY20568-001A HOLDER(3.5PWB)
505 LY31622-001A BRACKET(EARTH)
506 QLL0123-001 BACK LIGHT
507 QLD0203-001 LCD MODULE
508 LY32695-001A MONITOR FPC ASSY
508A LY32574-001A MONITOR FPC ASSY
508B LY32079-001A HINGE ASSY
508C LY32380-001A HINGE COVER(U)
508D LY32381-001A HINGE COVER(L)
508E LY30018-058A SPECIAL SCREW,X2
508F LY30018-023A SPECIAL SCREW
508G LY30029-0Q5A SPACER(A)
509 QYSPSPT1730R SCREW,X2
510 LY30018-0F2A SPECIAL SCREW,X2
512 LY30029-0Y6A SPACER(A)
502
507
506
504
LCD BL
<03>
500
a
b505
508C
508E
508
508E
508A
c
508F
508B
508D
508G
c
b
502A
510
501
501A
501C
501E
501H
501G
501J
501B
501F
501D
501D
a
509
d
d
512
