JVC GR-FXM39EK User manual

No. 86719
2003/02
COMPACT VHS CAMCORDER
Regarding service information other than these sections, refer to the service manual No. 86712 (GR-SXM49EX).
Also, be sure to note important safety precautions provided in the service manual.
GR-FXM39EK,GR-FXM39EX,GR-FXM39EY,GR-FXM39EZ,
GR-FXM393EX,GR-FXM393EY,GR-FXM393EZ
SERVICE MANUAL
SPECIFICATION
Camcorder
General
Connectors
AC Adapter
Format :S-VHS(GR-SXM49/SX25 only)/
VHS PAL standard
Power source :DC 11 V (Using AC Adapter)
DC 6 V (Using battery pack)
Power consumption
Viewfinder on :4.2 W (GR-SXM49/FXM393/FXM39 only)
4.0 W (GR-SX25/FX15 only)
LCD monitor* on :4.7 W (GR-SXM49/FXM393/FXM39 only)
Video light** :3.0W
* Applicable models only.
** GR-SXM49/FXM393/SX25 only.
Signal system :PAL-type
Video recording system
Luminance :FMrecording
Colour :Converted sub-carrier direct recording
Conforms to VHS standard
Cassette : /cassette
Tape speed
SP :23.39 mm/sec.
LP :11.70 mm/sec.
Recording time (max.)
SP :60minutes
LP :120minutes (with EC-60 cassette)
Operating
temperature :0°Cto 40°C
Operating humidity :35% to 80%
Storage temperature :-20°Cto 50°C
Weight :Approx. 840 g (GR-SXM49/FXM393/FXM39 only)
Approx. 760 g (GR-SX25 only)
Approx. 750 g (GR-FX15 only)
Dimensions (W x H x D) :113mm x 117 mm x 199 mm
(GR-SXM49/FXM393/FXM39 only)
108 mm x 117 mm x 199 mm (GR-SX25/FX15 only)
(with the LCD monitor* closed and with the
viewfinder fully tilted downward)
* Applicable models only.
Pickup :1/6"format CCD
Lens :F1.6, f = 2.7 mm to 43.2 mm,
16:1 power zoom lens with auto iris and
macro control, filter diameter 40.5 mm
Viewfinder :Electronic viewfinder with 0.5"
black/white CRT White balance
White balance
adjustment
:Auto/Manual adjustment
Speaker
(Applicable models only)
:Monaural
LCD monitor
(Applicable models only)
:2.5"diagonally measured, LCD panel/
TFT active matrix system
Video
: 1 V (p-p), 75 unbalanced, analogue output
(via Video output connector)
Audio
: 300 mV (rms), 1 k , analogue output
(via Audio output connector)
S-Video
(GR-SXM49/SX25 only)
: Y:1V(p-p), 75 , analogue output
C:0.30V(p-p),75 , analogue output
Power requirement
: AC 110 V - 240 V ~, 50 Hz/60 Hz
Output
: DC 11 V , 1 A
Optional Accessories
• Battery Packs BN-V12U, BN-V20U, BN-V400U
• Compact S-VHS ( ) Cassettes SE-C45/30
• Compact VHS ( ) Cassettes EC-60/45/30
• Active Carrying Bag CB-V7U
• Cassette Adapter C-P7U
Some accessories are not available in some areas. Please consult your
nearest JVC dealer for details on accessories and their availability.
(The specifications shown pertain specifically to the model GR-SXM49, FXM393, FXM39, SX25, FX15)
GR-FXM39EK,GR-FXM39EX,GR-FXM39EY,GR-FXM39EZ,GR-FXM393EX,GR-FXM393EY,GR-FXM393EZ M3A622,M3A623

TABLE OF CONTENTS
DIFFERENT TABLE .................................................................................................................................................................................... 1 to 2
PARTS LIST
1. PACKING AND ACCESSORY ASSEMBLY <M1> .................................................................................................................................... 3-1
1
Notes : Mark is same as left.
Mark — is not used.
The following table indicate main different points between models GR-SXM49EX, GR-FXM39EK, GR-FXM39EX, GR-FXM39EY,
GR-FXM39EZ, GR-FXM393EX, GR-FXM393EY and GR-FXM393EZ.
The following table indicate different parts number between models GR-SXM49EX,GR-FXM39EK,GR-FXM39EX,GR-FXM39EY,
GR-FXM39EZ,GR-FXM393EX,GR-FXM393EY and GR-FXM393EZ.
PACKING AND ACCESSORY ASSEMBLY <M1>
MODEL GR-SXM49EX GR-FXM39EK GR-FXM39EX GR-FXM39EY GR-FXM39EZ GR-FXM393EX GR-FXM393EY GR-FXM393EZ
ITEM
TAPE FORMAT S-VHS-C VHS-C
S CABLE Used Not Used
S OUTPUT Used Not Used
DC LIGHT Used Not Used Used
BODY COLOR SILVER MOLD BLACK
1PACKING CASE LY33071-001B LY33071-003B
4POLY BAG QPA02003506 QPA02003506P QPA02003506
!5INST BOOK (ENGLISH) — LYT1061-001B ——————
!5INST BOOK (GERMAN) LYT1060-002C — LYT1060-002C —LYT1060-002C —
!5INST BOOK (FRENCH) LYT1060-003C — LYT1060-003C — — LYT1060-003C — —
!5INST BOOK (DUTCH) LYT1060-004C — LYT1060-004C — — LYT1060-004C — —
!5INST BOOK (SPANISH) LYT1060-005C — LYT1060-005C — — LYT1060-005C — —
!5INST BOOK (ITALIAN) LYT1060-006C — LYT1060-006C — — LYT1060-006C — —
!5INST BOOK (DANISH) — — — LYT1060-007B — — LYT1060-007B —
!5INST BOOK (FINNISH) — — — LYT1060-008B — — LYT1060-008B —
!5INST BOOK (SWEDISH) — — — LYT1060-009B — — LYT1060-009B —
!5INST BOOK (NORWEGIAN) — — — LYT1060-010B — — LYT1060-010B —
!5INST BOOK (RUSSIAN) ————LYT1060-011B — — LYT1060-011B
!5INST BOOK (CZECH) ————LYT1060-012B — — LYT1060-012B
!5INST BOOK (POLISH) ————LYT1060-013B — — LYT1060-013B
!5INST BOOK (HUNGARIAN) ————LYT1060-014B — — LYT1060-014B
6Q.CARD(JUK) — LYT0194-001B ——————
7GUARANTY CARD — BT-54008-4 ——————
8WARRANTY CARD BT-54013-5 — BT-54013-5
9POLY BAG QPA02003506 QPA02003506P QPA02003506
!14 AC ADAPTER LY20955-001C LY 2 0956-001B
!14 AC ADAPTER LY20956-001B ——————
16 S CABLE QAM0004-003 ———————
17 POWER CORD
QMPL120-190-JR QMPP110-190-JR QMPL120-190-JR
!REF. MODEL GR-SXM49EX GR-FXM39EK GR-FXM39EX GR-FXM39EY GR-FXM39EZ GR-FXM393EX GR-FXM393EY GR-FXM393EZ
NO. ITEM

2
MAIN BOARD ASSEMBLY <01>
PW1 MAIN BOARD ASSY YB10400EA1-02 YB10400EH1-03 YB10400EC1-03
IC4002 IC(DIGITAL) MSM548331TA ———————
IC4701 IC — MM1512XN-X
IC4702 IC BA7665FS-X ———————
Q3505 DIGI TRANSISTOR DTC144EE-X ———————
Q4001 DIGI TRANSISTOR DTC144EE-X ———————
Q6306 MOS FET 2SK3577-X ————2SK3577-X
D4001 SI DIODE DAN222-X ———————
C4024 C CAPACITOR NCF31EZ-104X ———————
C4025 C CAPACITOR NCB31CK-104X ———————
C4044 C CAPACITOR NCB30JK-105X ———————
C4713 E CAPACITOR NEA70JM-226X ———————
C4714 E CAPACITOR NEA70GM-107X ———————
C4715 C CAPACITOR NCB31EK-103X ———————
C6307 E CAPACITOR NEA71CM-106X ————NEA71CM-106X
R4013 MG RESISTOR NRSA63J-102X ———————
R4014 MG RESISTOR NRSA63J-103X ———————
R4036 MG RESISTOR NRSA63J-101X ———————
R4712 MG RESISTOR NRSA63D-680X ———————
R4713 MG RESISTOR NRSA63D-680X ———————
R6306 MG RESISTOR NRSA63J-0R0X ————NRSA63J-0R0X
R6307 MG RESISTOR NRSA63J-104X ————NRSA63J-104X
R6314 MG RESISTOR NRS12BK-R47W ————NRS12BK-R47W
CN6 CONNECTOR QGA1201C2-02X ————QGA1201C2-02X
J505 S JACK QND0068-001 ———————
!REF. MODEL GR-SXM49EX GR-FXM39EK GR-FXM39EX GR-FXM39EY GR-FXM39EZ GR-FXM393EX GR-FXM393EY GR-FXM393EZ
NO. ITEM
Notes : Mark is same as left.
Mark — is not used.
MONITOR ASSEMBLY <M5>
!500 MONITOR ASSY LY20947-001A LY20947-005A LY 20947-002A
!501 M.COVER ASSY LY33066-001A LY33066-005A LY 33066-002A
501A STICKER(B) LY43982-001A LY43982-005A LY 43982-004A
503 MON.HINGE ASSY LY33005-001B LY33005-001C LY33005-002C
!REF. MODEL GR-SXM49EX GR-FXM39EK GR-FXM39EX GR-FXM39EY GR-FXM39EZ GR-FXM393EX GR-FXM393EY GR-FXM393EZ
NO. ITEM
MECHANISM ASSEMBLY <M3>
400 MECHA(B) ASSY YMA0040A-E YMA0042A-E
406 CASSETTE GUIDE ASSY(RIGHT) YQ44339A-7 — — — — — — —
406A SW.LEVER(RIGHT) YQ32162-1-3 — — — — — — —
406B TORSION SPRING YQ44340-1-4 — — — — — — —
407 SCREW LY42819-001A — — — — — — —
466 ROTARY ENCODER QSW0888-002 QSW0888-001
!REF. MODEL GR-SXM49EX GR-FXM39EK GR-FXM39EX GR-FXM39EY GR-FXM39EZ GR-FXM393EX GR-FXM393EY GR-FXM393EZ
NO. ITEM
FINAL ASSEMBLY <M2>
101 C. COVER(M)ASSY LY20927-002C LY20927-001C LY20927-002C LY20927-003C
101F STICKER(C) LY44007-001A — LY44007-001A
103 COV.(UPPER/M)ASSY LY33068-001C LY 33068-002B
121 LOWER CASE ASSY LY20925-001D LY20925-005E
!135 F.COVER ASSY LY20926-001C LY20926-003D LY 20926-012B
135B RING LY32949-001A LY 32949-007A
135D STICKER(A) LY43983-001A LY43983-002A
!135E CAUTION LABEL LY44141-001A ————LY44141-001A
135G COVER(LIGHT) — LY32965-001A ———
137 DC LIGHT LY33067-001A ————LY33067-001A
138 MIC LY32981-001A LY 32981-002A
157 TOP OPE UNIT LY10392-001C LY10392-002D LY10392-003D
!REF. MODEL GR-SXM49EX GR-FXM39EK GR-FXM39EX GR-FXM39EY GR-FXM39EZ GR-FXM393EX GR-FXM393EY GR-FXM393EZ
NO. ITEM
135
135C
135B
135A
135F
135F
135D
135F
136
g
m
f
139
a
135G
135E
As for the difference in a “FINAL ASSEMBLY <M2>”
drawing, 135G is added.

Printed in Japan
