JVC KD-DV5301 User manual

ENGLISH
DVD/CD RECEIVER
KD-DV5302/KD-DV5301
For installation and connections, refer to the separate manual.
INSTRUCTIONS
GET0442-003A
[EU]
For canceling the display demonstration, see page 5.
Cover_KD-DV5302_003A_f.indd 1 12/14/06 6:32:26 PM

ENGLISH
2
How to forcibly eject a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
How to use functions mode
If you press M MODE, the unit goes into functions
mode, then the number buttons and 5/∞ buttons
work as different function buttons.
Thank you for purchasing a J C product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LAS R PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: isible and/or invisible class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
How to reset your unit
• Your preset adjustments will also be erased.
[Within 5 seconds...]
[European Union only]
EN02-05_DV5302_003A_f.indd 2EN02-05_DV5302_003A_f.indd 2 1/8/07 12:28:41 PM1/8/07 12:28:41 PM

ENGLISH
3
WARNINGS:
To prevent a idents and damage
• DO NOT install any unit in lo ations where;
– it may obstru t the steering wheel and
gearshift lever operations.
– it may obstru t the operation of safety
devi es su h as air bags.
– it may obstru t visibility.
• DO NOT operate the unit while driving.
• If you need to operate the unit while
driving, be sure to look ahead arefully.
• The driver must not wat h the monitor
while driving.
If the parking brake is not engaged,
“DRIVER MUST NOT WATCH THE MONITOR
WHILE DRIVING.” appears on the monitor,
and no playba k pi ture will be shown.
– This warning appears only when the
parking brake wire is onne ted to the
parking brake system built in the ar
(refer to the Installation/Conne tion
Manual).
This product incorporates copyright protection
technology that is protected by U.S. patents and
other intellectual property rights. Use of this
copyright protection technology must be authorized
by Macrovision, and is intended for home and
other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
CONTENTS
INTRODUCTIONS
Playable disc type .................................... 4
Preparation ............................................ 5
OPERATIONS
Basic operations
• Control panel ..................................... 6
• Remote controller (RM-RK241) ............ 7
Listening to the radio ............................... 10
Searching for FM RDS programmes
—PTY Search ....................................... 11
Disc operations ........................................ 13
EXTERNAL DEVICES
Listening to the CD changer ...................... 21
Listening to the DAB tuner ........................ 22
Listening to the iPod / D. player ................. 23
Listening to the other external
components ......................................... 24
SETTINGS
Selecting a preset sound mode .................. 25
General settings — PSM .......................... 26
Disc setup menu ....................................... 29
REFERENCES
Maintenance ........................................... 31
More about this unit ................................ 32
Troubleshooting ...................................... 37
Specifications .......................................... 40
EN02-05_DV5302_003A_2.indd 3EN02-05_DV5302_003A_2.indd 3 11/11/06 10:06:27 AM11/11/06 10:06:27 AM

ENGLISH
4
Playable disc type
Disc type Recording format, file type, etc Playable
DVD DVD-Video (Region Code numbers include “2”) *1
DVD-Audio/DVD-ROM
DVD Recordable/Rewritable
(DVD-R *2/-RW, +R/+RW *3)
DVD-Video
DivX Video
MP G-1/MP G-2 Video
MP3/WMA/WAV
JP G/MP G4
DVD-VR, +VR
DVD-RA All
Dual Disc DVD side
Non-DVD side
CD/VCD Audio CD (CD-DA)/DTS-CD *4
VCD (Video CD)
CD-Text
CD-ROM/CD-I (CD-I Ready)
CD Recordable/Rewritable
(CD-R/-RW)
• Compliant to ISO 9660 level 1,
level 2, Romeo, Joliet
CD-DA
DivX Video, VCD (Video CD)
MP G-1/MP G-2 Video
MP3/WMA/WAV
JP G/MP G4
*1 If you insert a DVD Video disc of an incorrect Region Code, “REGION CODE ERROR!” appears on the monitor
*2 DVD-R recorded in multi-border format is also playable (except for dual layer discs)
*3 It is possible to play back finalized +R/+RW (Video format only) discs However, the use of +R double layer disc on
this unit is not recommended
*4 To reproduce DTS sound, use the DIGITAL OUT terminal (see also pages 30 and 35)
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product
may not be recommended.
Caution on volume setting
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc to
avoid damaging the speakers by the sudden increase of
the output level.
EN02-05_DV5302_003A_f.indd 4EN02-05_DV5302_003A_f.indd 4 12/11/06 3:37:52 PM12/11/06 3:37:52 PM

ENGLISH
5INTRODUCTIONS
Preparation
Cancel the display demonstration and set the clock
• See also page 27.
~ Turn on the power.
Ÿ Enter the PSM settings.
! ] ⁄ Cancel the display demonstrations
Select “DEMO,” then “DEMO OFF.”
Set the clock
Select “CLOCK H” (hou ), then adjust the hou .
Select “CLOCK M” (minute), then adjust the minute.
Select “24H/12H,” then “24H” (hou ) o “12H” (hou ).
@ Finish the procedure.
When the powe is tu ned off: Check the cu ent clock time
When the powe is tu ned on: Change the display info mation
Indication language:
In this manual, English indications a e used fo pu poses of explanation. You can select the indication language
on the monito on the “LANGUAGE” setting (see page 29).
EN02-05_DV5302_003A_f.indd 5EN02-05_DV5302_003A_f.indd 5 12/20/06 12:06:50 PM12/20/06 12:06:50 PM

ENGLISH
6
Basic operations — Control panel
• FM/AM/DAB: Select the bands.
• DISC: Start playback.
Select the source.
FM/AM = DAB * = DISC * = CD-CH */IP D */
D.PLAYER * (or EXT IN) = LINE IN = (back to
the beginning)
Display window
• DISC: Select title/folder.
• IP D/D.PLAYER: Enter the main menu/
Pause or stop playback/Confirm selection.
• DAB: Select service.
Eject disc.
Detach the
panel.
• Adjust the sound mode.
• Enter the PSM settings [Hold].
Enter functions mode.
Press M MODE, then one of the follo ing buttons
( ithin 5 seconds)...
EQ : Select the sound mode.
M : Turn on/off monaural reception.
SSM : Automatic station presetting [Hold].
RPT : Select repeat play.
RND : Select random play.
5/∞ : Skip 10 chapters/tracks.
• FM/AM/DAB: Select preset station/
service.
• DISC: Select chapter/title/folder/
track/disc (for CD changer).
• Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
Change the display
information.
• Activate/deactivate TA Standby Reception.
• Enter RDS programme search [Hold].
• FM/AM/DAB: Search for station/
ensemble.
• DISC: Select chapter/track.
• IP D/D.PLAYER: Select track.
Volume control [Turn]
Loading slot
* You cannot select these sources if they are not ready or not connected.
EN06-13_DV5302_003A_f.indd 6EN06-13_DV5302_003A_f.indd 6 12/13/06 4:10:28 PM12/13/06 4:10:28 PM

ENGLISH
7OPERATIONS
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
This unit is equipped ith the steering heel
remote control function.
• See the Installation/Connection Manual (separate
volume) for connection.
Display window
Basic operations — Remote controller (RM-RK241)
Installing the lithium coin battery
(CR2025)
Continued on the next page
Track information
indicators
Tuner reception indicators
Main display
(Time, menu, playback information)
Loudness indicator
Playback source
indicators
Equalizer
indicator
Sound mode indicators
Playback mode/item indicators
(Random/Repeat)
Track indicator
Source display/Preset No./Track No./Folder
No./Disc No./Chapter No./Channel No.
Remote sensor
RDS indicators
EN06-13_DV5302_003A_2.indd 7EN06-13_DV5302_003A_2.indd 7 11/11/06 10:07:05 AM11/11/06 10:07:05 AM

ENGLISH
8
Warning:
To prevent accidents and damage
• Do not install any battery other than CR2025 or
its equivalent.
• Do not leave the remote controller in a place
(such as dashboards) exposed to direct sunli ht
for a lon time; otherwise, it may explode.
• Store the battery in a place where children
cannot reach.
• Do not rechar e, short, disassemble, heat the
battery, or dispose of it in a fire.
• Do not leave the battery with other metallic
materials.
• Do not poke the battery with tweezers or similar
tools.
• Wrap the battery with tape and insulate when
throwin away or savin it.
EXTRA MONITOR
1 Monitor control buttons
• Used for a JVC monitor—KV-MR9010,
KV-MH6510, KV-M706, or KV-M705.
DVD/RECEIVER
2 • Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
3 Selects the source.
4 Selects the FM/AM/DAB bands.
5 Not applicable for this unit.
6 Not applicable for this unit.
7 Adjusts the volume level.
• 2nd VOL: Not applicable for this unit.
8 *1 • DVD-Video/DivX: Shows disc menu.
• VCD: Starts PBC playback.
9 *1 Enters disc setup menu.
p SHIFT button
q 7 (stop), 3 (play), 8 (pause)
• 3 (play) also function as ZOOM button when
pressed with SHIFT button (see pa e 17).
• Not applicable for CD chan er/iPod/D. player
operations.
w For advanced disc operations:
•
5 / ∞ :
DVD-Video: Selects the titles.
DivX/MPEG Video/MP3/WMA/WAV: Selects
the folders if included.
•
4 / ¢ :
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed
and held.
•
1 / ¡ : Reverse search/forward
search. *2
For FM/AM t ner operations:
• 5 / ∞ : Chan es the preset stations.
• 4 / ¢ :
– Searches for stations automatically if
pressed briefly.
– Searches for stations manually if pressed
and held.
EN06-13_DV5302_003A_3.indd 8EN06-13_DV5302_003A_3.indd 8 11/24/06 9:28:10 AM11/24/06 9:28:10 AM

ENGLISH
9OPERATIONS
For DAB tuner operations:
• 5 / ∞ : Changes the preset services.
• 4 / ¢ :
– Changes the service if pressed briefly.
– Searches for ensembles if pressed and held.
For Apple iPod/JVC D. player operations:
•
∞ : Pauses/stops or resumes playback.
5 : Enters the main menu.
Now 5/∞/4 / ¢ work as the
menu selecting buttons.) *3
• 4 / ¢ in menu selecting mode):
– Selects an item if pressed briefly. Then,
press ∞ to confirm the selection.)
– Skips 10 items at a time if pressed and held.
• 4 / ¢ :
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed
and held.
e Shows the on-screen bar.
• Also functions as DIRECT button when pressed
with SHIFT button. *4
r *1 • DVD-Video/DivX: Shows disc menu.
• VCD: Starts PBC playback.
t *1 • Makes selection/settings.
• @ / # : DivX: Searches for index during play.
• DISC +/–: Changes discs when the source is
“CD-CH.”
y *1 RETURN button
u • DVD-Video: Selects audio language ),
subtitles )*1, angle )*5.
• DivX: Selects audio language ),
subtitles ).
• VCD: Selects audio channel ).
How to select a number
How to select a preset station/service
*1 Functions as number buttons when pressed with
SHIFT button.
– FM/AM/DAB: Selects preset stations/services.
– DIS : Selects chapter/title/folder/track
after entering search mode by
pressing SHIFT and DIRE T.
*2 Not applicable for D changer operations.
*3 5 : Returns to the previous menu.
∞ : onfirms the selection.
*4 You can directly select title/chapter/folder/track using
the number buttons (see pages 15 and 16).
*5 Functions as SURROUND button when pressed with
SHIFT button (not applicable for this unit).
An input screen appears...
EN06-13_DV5302_003A_f.indd 9EN06-13_DV5302_003A_f.indd 9 12/20/06 12:07:17 PM12/20/06 12:07:17 PM

ENGLISH
10
When an FM stereo broadcast is
hard to receive
1
2
Reception improves, but stereo effect will be lost.
• MO indicator lights up.
FM station automatic presetting —
SSM (Strong-station Sequential
Memory)
You can preset six stations for each band.
1
2
Listening to the radio
Change the display information (for non-RDS station)
~ Select “FM/AM.
Ÿ Select the bands.
! Search for a station to listen—Auto Search.
Manual Search: old either one of the buttons until “M” flashes on the display, then press it repeatedly.
Select preset station.
3
Local FM stations with the strongest signals are
searched and stored automatically in the FM band.
Manual presetting
Ex.: Storing FM station of 92.5 M z into preset number
4 of the FM1 band.
1
2
3
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
EN06-13_DV5302_003A_2.indd 10EN06-13_DV5302_003A_2.indd 10 11/13/06 7:21:42 PM11/13/06 7:21:42 PM

ENGLISH
11OPERATIONS
Storing your favorite programme
types
You can store your favorite PTY codes into the number
buttons.
1 Select a PTY code (see right column).
2 Select a preset number.
3 Repeat steps 1 and 2 for storing other
PTY codes.
4
Searching for FM RDS programme — PTY Search
Change the display information
Preset PTY codes in the number buttons (1 to 6):
PTY codes (available with the control dial):
NEWS, AFFAIRS, INFO, SPORT, EDUCATE, DRAMA,
CULTURE, SCIENCE, VARIED, POP M (music), ROCK M
(music), EASY M (music), LIG T M (music), CLASSICS,
OT ER M (music), WEAT ER, FINANCE, C ILDREN,
SOCIAL, RELIGION, P ONE IN, TRAVEL, LEISURE, JAZZ,
COUNTRY, NATION M (music), OLDIES, FOLK M (music),
DOCUMENT
~ Activate PTY Search.
Ÿ Select one of the PTY codes (programme types).
See the following for details.
! Start searching.
If there is a station broadcasting a programme of the same PTY code as you have selected, that station is tuned
in.
EN06-13_DV5302_003A_2.indd 11EN06-13_DV5302_003A_2.indd 11 11/13/06 7:10:14 PM11/13/06 7:10:14 PM

ENGLISH
12
Activating/deactivating TA/PTY Standby Reception
TA Standby Reception Indicator PTY Standby Reception Indicator
Press to activate. See page 27.
The unit temporarily ill s itch to Traffic
Announcement (TA), if available, from any
source other than AM.
The volume changes to the preset TA
volume level if the current level is lo er
than the preset level (see page 27).
Lights up The unit temporarily ill s itch to your
favorite PTY programme from any source
other than AM.
Lights up
Not yet activated. Tune in to another
station providing the RDS signals.
Flashes Not yet activated. Tune in to another
station providing the RDS signals.
Flashes
Press to deactivate. Goes off Select “OFF” for the PTY code (see page 27)
to deactivate.
Goes off
• When a DAB tuner is connected, TA/PTY Standby Reception also searches for services. (See also pages 22 and 27.)
When driving in an area here FM reception is not
sufficient enough, this unit automatically tunes in to
another FM RDS station of the same net ork, possibly
broadcasting the same programme ith stronger
signals (see the illustration on the right).
When shipped from the factory, Net ork-Tracking
Reception is activated.
To change the Network-Tracking Reception
setting, see “AF-REG” on page 27.
• When the DAB tuner is connected, refer to “Tracing
the same programme—Alternative Frequency
Reception” on page 22.
Tracing the same programme—Network-Tracking Reception
Programme A broadcasting on different frequency
areas (01 – 05)
Automatic station selection—Programme Search
Usually hen you press the number buttons, the preset station is tuned in.
If the signals from the FM RDS preset station are not sufficient for good reception, this unit, using the AF data, tunes
in to another frequency broadcasting the same programme as the original preset station is broadcasting.
• The unit takes some time to tune in to another station using programme search.
• See also page 27.
EN06-13_DV5302_003A_2.indd 12EN06-13_DV5302_003A_2.indd 12 11/11/06 10:07:09 AM11/11/06 10:07:09 AM

ENGLISH
13OPERATIONS
Disc operations
Before performing any operations...
Turn on the monitor to watch the playback picture. If you turn on the monitor, you can also control playback of other
discs by referring to the monitor screen. (See pages 17 – 0.)
The disc type is automatically detected, and playback starts automatically (for DVD: automatic start depends on its
internal program).
If the current disc does not have any disc menu, all tracks will be played repeatedly until you change the source or
eject the disc.
If “ ” appears on the monitor when pressing a button, the unit cannot accept the operation you have tried to
do.
• In some cases, without showing “ ,” operations will not be accepted.
Insert the disc.
Playback starts automatically.
Change the display information
Start playback if necessary.
Prohibiting disc ejection
To cancel the prohibition, repeat the
same procedure.
*1 If the file does not have Tag information or
“TAG DISP” is set to “TAG OFF” (see page
28 , folder name and file name appear.
TAG indicator will not light up.
*2 “NO NAME” appears for an audio CD.
EN06-13_DV5302_003A_2.indd 13EN06-13_DV5302_003A_2.indd 13 11/13/06 7:10:36 PM11/13/06 7:10:36 PM

ENGLISH
14
Operations using the control panel
Pressing (or holding) the following buttons allows you to...
Disc type
(Number buttons) *3
Press: Select chapter
Hold: Reverse/fast forward
chapter *1
Select title During stop: Locate title
During play/pause: Locate
chapter
Press: Select track
Hold: Reverse/fast forward track *2
Select folder Locate particular folder directly
Press: Select track
Hold: Reverse/fast forward track *1—Locate particular track directly (PBC not in use)
Press: Select track
Hold: Reverse/fast forward track *1
Select folder Locate particular folder directly
Press: Select track
Hold: Reverse/fast forward track *1—Locate particular track directly
*1 Search speed changes to on the monitor.
*2 Search speed changes on the monitor.
*3 Press to select number 1 to 6; hold to select number 7 to 12.
After pressing , press the following buttons to...
Disc type
Skip 10 chapters (during
play or pause)
CHP RPT: Repeat current
chapter
TIT RPT: Repeat current title
—
Skip 10 tracks (within the
same folder)
TRK RPT: Repeat current track
FLDR RPT: Repeat current folder —
Skip 10 tracks (PBC not in
use)
TRK RPT: Repeat current track
(PBC not in use)
DISC RND: Randomly play all
tracks (PBC not in use)
Skip 10 tracks (within the
same folder)
TRK RPT: Repeat current track
FLDR RPT: Repeat current folder
FLDR RND: Randomly play all
tracks of current
folder, then tracks of
next folders
DISC RND: Randomly play all
tracks
Skip 10 tracks TRK RPT: Repeat current track DISC RND: Randomly play all
tracks
• To cancel repeat play or random play, select “RPT OFF” or “RND OFF.”
EN14-21_DV5302_003A_2.indd 14EN14-21_DV5302_003A_2.indd 14 11/11/06 10:07:24 AM11/11/06 10:07:24 AM

ENGLISH
15OPERATIONS
To search for chapter/title directly
1 Select chapter/title search.
+
2 Enter the desired number.
+
3
: Stop play
: Pause (Frame by frame playback if
pressed during pause.)
: Start play
: everse/forward track search *4
: Press: Select track
Hold: everse/fast-forward track
search *5
: Select folder
: • eturn/advance the scenes by
about 5 minutes (Index search).
• Select chapter.
: DivX: Select subtitles language
: DivX: Select audio language
To search for track (within the same folder)/
folder directly
1 Select track/folder search.
+
2 Enter the desired number.
+
3
Operations using the remote controller—RM-RK241
: Stop play
: Pause (Frame by frame playback if pressed during
pause.)
: Start play
: everse/forward chapter search *1
• Slow motion *2 during pause. No sound can be heard.
: Press: Select chapter (during play or pause)
Hold: everse/fast-forward chapter search *3
: Select title
: Select audio language
: Select subtitle language
: Select view angle
Continued on the next page
Using menu driven features...
1 /
2 Select an item you want to
start play.
3
*1, 2, 3, 4, 5 : See page 16.
EN14-21_DV5302_003A_3.indd 15EN14-21_DV5302_003A_3.indd 15 11/17/06 3:06:26 PM11/17/06 3:06:26 PM

ENGLISH
16
To search for track ( ithin the
same folder)/folder directly
1 Select track/folder search.
+
2 Enter the desired number.
+
3
Canceling the PBC playback...
1
2 +
3 Enter the desired number.
+
4
• To resume PBC, press / .
: Stop play
: Pause (Frame by frame playback if
pressed during pause.)
: Start play
: Reverse/forward track search *1
• Forward slow motion *2 during
pause. No sound can be heard.
(Reverse slow motion does not
work.)
: Press: Select track
Hold: Reverse/fast forward track
search *3
: Select audio channel
(ST: stereo, L: left, R: Right)
: Stop play
: Pause
: Start play
: Reverse/forward track search *1
: Press: Select tracks
Hold: Reverse/fast forward track
search *3
: Select folder
: Stop play
: Pause
: Start play
: Reverse/forward track search *1
: Press: Select tracks
Hold: Reverse/fast forward track
search *3
*1 Search speed changes to on the monitor if pressed repeatedly.
*2 Slo motion speed changes to on the monitor if pressed
repeatedly.
*3 Search speed changes to on the monitor.
*4 Search speed changes on the monitor if pressed repeatedly.
*5 Search speed changes on the monitor.
To search for track directly
1 Select track search.
+
2 Enter the desired number.
+
3
EN14-21_DV5302_003A_2.indd 16EN14-21_DV5302_003A_2.indd 16 11/11/06 10:07:28 AM11/11/06 10:07:28 AM

ENGLISH
17OPERATIONS
Operations using the on-screen bar (DVD/Div /MPEG Video/VCD)
These operations are possible on the monitor using the remote controller.
~ Sho the on-screen bar (see page 18).
(twice)
Ÿ Select an item.
! Make a selection.
If pop up menu appears...
• To cancel pop up menu, press .
• For entering time/numbers, see the following.
⁄ Remove the on-screen bar.
Enlarging the view—Zoom in (DVD/Div /MPEG Video/VCD)
During moving picture playback...
1 While holding , press repeatedly.
2 Move the enlarged portion.
• To cancel zoom, select “ZOOM OFF.”
Entering time/numbers
Press to change the number, then press to move to the next entry.
• Each time you press , the number increases/decreases by one value.
• After entering the numbers, press .
• It is not required to enter the zero and tailing zeros (the last two digits in the example below).
Ex.: Time search
DVD: _:_ _:_ _ (Ex.: 1:02:00)
Press once, then twice to go to the third entry, twice, then press ENTER.
EN14-21_DV5302_003A_2.indd 17EN14-21_DV5302_003A_2.indd 17 11/11/06 10:07:29 AM11/11/06 10:07:29 AM

ENGLISH
18
Information
Operation
On-screen bar
Ex.: DVD Video
1 Disc type
2 • DVD Video/DTS CD: Audio signal format type
and channel
• VCD: PBC
3 Playback mode *1
DVD Video: T. RPT: Title repeat
C. RPT: Chapter repeat
DivX/MPEG Video: T. RPT: Track repeat
F. RPT: Folder repeat
VCD *2: T. RPT: Track repeat
D. RND: Disc random
T. INT: Track intro *3
4 Playback information
Current title/chapter
Current track
Current folder/track
5 Time indication
Elapsed playing time of the disc
(For DVD Video, elapsed playing
time of the current title.)
DVD Video: Remaining title time
VCD: Remaining disc time
Elapsed playing time of the current
chapter/track
Remaining time of the current
chapter/track
6 Playback status
Play
Forward/reverse search
Forward/reverse slow motion
Pause
Stop
7 Operation icons
Change time indication (see 5)
Time Search (Enter the elapsed playing
time of the current title or of the disc.)
Title Search (by its number)
Chapter Search (by its number)
Track Search (by its number)
Change the audio language or audio
channel
Change the subtitle language
Change the view angle
Repeat play *1
Intro play *3
Random play *1
*1 For repeat play/random play, see also page 14.
*2 While PBC is not in use.
*3 Plays the beginning 15 seconds of...
TRACK INTRO : All tracks of the current disc.
FOLDER INTRO : First tracks of all folders of the
current disc.
EN14-21_DV5302_003A_2.indd 18EN14-21_DV5302_003A_2.indd 18 11/11/06 10:07:30 AM11/11/06 10:07:30 AM

ENGLISH
19OPERATIONS
Control screen
1 Current folder number/total folder number
2 Folder list with the current folder selected
3 Selected playback mode
4 Elapsed playing time of the current track
5 Operation mode icon ( 3, 7, 8, ¡, 1 )
6 Current track number/total number of tracks in the
current folder (total number of tracks on the disc)
7 Track information
8 Track list with the current track selected
To select a playback mode
1 While control screen is displayed...
Playback mode selection screen appears on the
folder list section of the control screen.
2 Select a playback mode.
3 Select an item.
REPEAT/INTRO:
RANDOM:
4 Confirm the selection.
*1 Not selectable for DivX/MPEG Video
*2 Not selectable for CD
Operations using the control screen (Div /MPEG Video/MP3/WMA/WAV/CD)
These operations are possible on the monitor using the remote controller.
~ Sho the control screen.
DivX/MPEG Video: Press during play.
MP3/WMA/WAV/CD: Automatically appear during play.
Ÿ Select “Folder” column or “Track” column (except for CD).
! Select a folder or track.
⁄ Start playback.
DivX/MPEG Video: Press .
MP3/WMA/WAV/CD: Playback starts automatically.
Ex.: MP3/WMA/WAV disc
Continued on the next page
EN14-21_DV5302_003A_2.indd 19EN14-21_DV5302_003A_2.indd 19 11/11/06 10:07:32 AM11/11/06 10:07:32 AM

ENGLISH
20 OPERATIONS
List screen
These operations are possible on the monitor using the remote controller.
Before playing, you can display the folder list/track list to confirm the contents and
start playing a track.
~ Display the folder list hile stop.
Ÿ Select an item from the folder list.
• Track list of the selected folder appears.
• To go back to the folder list, press .
! Select a track to start playing.
• MP3/WMA/WAV: Control screen appears (see page 19).
Operations using the list screen (Div /MPEG Video/MP3/WMA/WAV)
Ex.: Folder list
1 Current folder number/total folder number
2 Current track number/total number of tracks in the
current folder
3 Current page/total number of the pages included
in the list
4 Current folder/track (highlighted bar)
Mode Playback functions
F. RPT (folder repeat): Repeat current folder
T. RPT (track repeat): Repeat current track
F. INT (folder intro): Plays the beginning 15 seconds of first tracks of all folders of the current disc
T. INT (track intro): Plays the beginning 15 seconds of all tracks of the current disc
D. RND (disc random): Randomly play all tracks
F. RND (folder random): Randomly play all tracks of current folder, then tracks of next folders
EN14-21_DV5302_003A_2.indd 20EN14-21_DV5302_003A_2.indd 20 11/11/06 10:07:33 AM11/11/06 10:07:33 AM
