JVC KD-DV9406 User manual

For canceling the display demonstration, see page 7.
For installation and connections, refer to the separate manual.
INSTRUCTIONS
GET0541-005A
[A]
KD-DV9406/KD-DV9405
DVD/CD RECEIVER
Cover_KD-DV9406_005A_1.indd 1Cover_KD-DV9406_005A_1.indd 1 22/4/08 4:12:39 PM22/4/08 4:12:39 PM

2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
[European Union only]
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• top the car before performing any complicated
operations.
Temperature insi e the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
Caution:
If the temperature inside the car is below 0°C, the
movement of animation and text scroll will be halted
on the display to prevent the display from being
blurred. appears on the display.
When the temperature increases, and the operating
temperature is resumed, these functions will start
working again.
EN02-09_KD-DV9406_005A_1.indd 2EN02-09_KD-DV9406_005A_1.indd 2 22/4/08 4:11:49 PM22/4/08 4:11:49 PM

3
How to reset your unit
• Your preset adjustments will also be erased (except the
registered Bluetooth device, see pages 26 and 27).
How to forcibly eject a isc
“Please Eject” appears on the display.
• Be care ul not to drop the disc when it ejects.
• I this does not work, reset your unit.
Caution on volume setting:
Digital devices (CD/U B) produce very little noise
compared with other sources. Lower the volume before
playing these digital sources to avoid damaging the
speakers by sudden increase of the output level.
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product
may not be recommended.
WARNINGS:
(To prevent acci ents an amage)
• DO NOT install any unit or wire any cable in
a location where;
– it may obstruct the steering wheel an
gearshift lever operations.
– it may obstruct the operation of safety
evices such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while riving.
• If you nee to operate the unit while
riving, be sure to look aroun carefully.
• The river must not watch the monitor
while riving.
If the parking brake is not engage ,
“DRIVER MUST NOT WATCH THE MONITOR
WHILE DRIVING.” appears on the monitor,
an no playback picture will be shown.
– This warning appears only when the
parking brake lea is connecte to the
parking brake system built in the car
(refer to the Installation/Connection
Manual).
In ication language:
In this manual, English indications are used
for purposes of explanation. You can select
the indication language on the monitor on the
“LANGUAGE” setting (see page 44).
• You can also select the indication language on
the display while playing a CD Text, MP3, WMA,
AAC, or WAV file. ee “Language” on page 40 for
setting.
EN02-09_KD-DV9406_005A_1.indd 3EN02-09_KD-DV9406_005A_1.indd 3 22/4/08 4:11:50 PM22/4/08 4:11:50 PM

4
Detaching the control panel
Attaching the control panel
Opening an closing the control
panel
Avoid touching the connectors.
How to use the M MODE an SEL
buttons
If you use M MODE or EL (select), the display and some
controls (such as the number buttons,
4 /¢ buttons, 5/∞ buttons, and the
control dial) enter the corresponding control mode.
Ex.: When you press number button 1 after pressing
M MODE, to operate the FM tuner.
To use these controls for original functions, press
M MODE again.
• However, pressing EL makes the unit enters a
different mode.
• Waiting for about 15 seconds without pressing any of
these buttons will automatically cancels the control.
Open...
Close...
Works as time countdown indicator.
EN02-09_KD-DV9406_005A_1.indd 4EN02-09_KD-DV9406_005A_1.indd 4 22/4/08 4:11:51 PM22/4/08 4:11:51 PM

5
CONTENTS
INTRODUCTIONS
Playable disc type ........................................................................................................................... 6
Preparation ..................................................................................................................................... 7
OPERATIONS
Basic operations .............................................................................................................................. 8
• Using the control panel ............................................................................................................................ 8
• Using the remote controller (RM-RK252) ................................................................................................. 9
Listening to the radio ...................................................................................................................... 12
Disc operations ................................................................................................................................ 14
• Operations using the control panel .......................................................................................................... 15
• Operations using the remote controller (RM-RK252) ............................................................................... 18
Listening to the U B device ............................................................................................................. 24
Dual Zone operations ...................................................................................................................... 25
Listening to the Bluetooth® devices ................................................................................................ 26
• Using the Bluetooth cellular phone ......................................................................................................... 28
• Using the Bluetooth audio player ............................................................................................................ 31
EXTERNAL DEVICES
Listening to the CD changer ............................................................................................................ 32
Listening to the iPod ....................................................................................................................... 33
Listening to the other external components ................................................................................... 35
SETTINGS
electing a preset sound mode ....................................................................................................... 36
General settings — P M ................................................................................................................ 39
Disc setup menu .............................................................................................................................. 44
Bluetooth settings .......................................................................................................................... 46
Title assignment ............................................................................................................................. 47
REFERENCES
Maintenance ................................................................................................................................... 48
More about this unit ....................................................................................................................... 49
Troubleshooting .............................................................................................................................. 57
pecifications .................................................................................................................................. 62
EN02-09_KD-DV9406_005A_1.indd 5EN02-09_KD-DV9406_005A_1.indd 5 22/4/08 4:11:52 PM22/4/08 4:11:52 PM

6
Disc type Recor ing format, file type, etc Playable
DVD DVD Video (Region Code: 4) *1
DVD Audio
DVD-ROM
DVD Recor able/Rewritable
(DVD-R/-RW *2, +R/+RW *3)
• DVD Video: UDF bridge
• DVD-VR
• DivX/MPEG-1/MPEG-2/MP3/
WMA/WAV: I O 9660 level 1,
level 2, Joliet
DVD Video
DVD-VR
DivX/MPEG1/MPEG2
MP3/WMA/AAC *4/WAV
JPEG/MPEG4
DVD+VR
DVD-RAM
Dual Disc DVD side
Non-DVD side
CD/VCD Audio CD/CD Text (CD-DA)/DT -CD *5
VCD (Video CD)
VCD ( uper Video CD)
CD-ROM
CD-I (CD-I Ready)
CD Recor able/Rewritable
(CD-R/-RW)
• I O 9660 level 1, level 2, Joliet
CD-DA
DivX/MPEG1/MPEG2
MP3/WMA/AAC *4/WAV
JPEG/MPEG4
*1 I you insert a DVD Video disc o an incorrect Region Code, “REGION CODE ERROR” appears on the monitor.
*2 DVD-R recorded in multi-border ormat is also playable (except or dual layer discs). DVD-RW dual layer discs are not
playable.
*3 It is possible to play back inalized +R/+RW (Video ormat only) discs. +RW double layer discs are not playable.
*4 This unit can play back AAC iles encoded using iTunes. This unit cannot play back AAC iles purchased rom iTunes
Store.
*5 To reproduce DTS sound, use the DIGITAL OUT terminal (see also pages 45 and 55).
Playable disc type
EN02-09_KD-DV9406_005A_1.indd 6EN02-09_KD-DV9406_005A_1.indd 6 22/4/08 4:11:52 PM22/4/08 4:11:52 PM

7INTRODUCTIONS
Preparation
Cancel the isplay emonstration an set the clock
• ee also pages 39 and 40.
1Turn on the power.
2Enter the PSM settings.
3Cancel the isplay emonstrations
elect “Demo,” then “Off.”
Set the clock
elect “Clock Hr” (hour), then adjust the hour.
elect “Clock Min” (minute), then adjust the minute.
elect “24H/12H,” then “24Hours” or “12Hours.”
4Finish the proce ure.
Changing the isplay information an pattern
• When the power is turned off: Check the current clock time
Ex.: When tuner is selected as the source
ource operation display
• To assign a title to a station, see page 47.
Audio level meter display
(see “LevelMeter” on page 39)
EN02-09_KD-DV9406_005A_1.indd 7EN02-09_KD-DV9406_005A_1.indd 7 22/4/08 4:11:53 PM22/4/08 4:11:53 PM

8
Basic operations
Using the control panel
8 • Volume control [Turn].
• elect the source [Press].
TUNER = DISC *1 = USB *1 = CD-CH *1/
iPo *1 (or EXT IN) = BT Au io = LINE IN
= AV IN = (back to the beginning)
9 • elect/adjust the sound mode.
• Enter the P M settings [Hold].
p • TUNER: elect preset station.
• DISC/USB/CD-CH: elect chapter/title/
program/folder/track/disc (for CD changer).
• Bluetooth: Dial preset phone number *2.
q • Enter functions mode.
• Bluetooth: Activate Voice Dialing [Hold].
w Change the display information and pattern.
e • TUNER: elect the bands.
• DISC/USB: tart/pause playback.
• BT Au io: tart/pause playback.
*1 You cannot select these sources i they are not ready
or not connected.
*2 For storing preset phone number, see page 30.
1 • TUNER: elect preset station.
• DISC/USB/CD-CH: elect title/program/
playlist/folder.
• iPo : Enter the main menu/Pause playback/
Confirm selection.
2 • Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
• Bluetooth: witch the conversation media
during a phone call conversation.
3 Display window
4 • Enter/exit Bluetooth menu.
• Display the dialed list [Hold].
5 Flip down the control panel.
• To eject the disc, flip down the control panel
then press 0 on the unit.
6 AV-IN (video) input jack
7 • TUNER: earch for station.
• DISC/USB/CD-CH/iPo : elect chapter/track.
• BT Au io: Reverse skip/forward skip.
EN02-09_KD-DV9406_005A_1.indd 8EN02-09_KD-DV9406_005A_1.indd 8 22/4/08 4:11:53 PM22/4/08 4:11:53 PM

9OPERATIONS
Continued on the next page
Installing the batteries
Insert the batteries into the remote controller by
matching the polarity (+ and –) correctly.
Caution:
Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
If the effectiveness of the remote controller
ecreases, replace both batteries.
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
Using the remote controller (RM-RK252)
R03/LR03/AAA
Remote sensor
IMPORTANT:
If Dual Zone is activated (see page 25), the remote
controller only functions for operating the DVD/CD
player.
1*1 button
• Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
• witches the conversation media during a
phone call conversation.
EN02-09_KD-DV9406_005A_1.indd 9EN02-09_KD-DV9406_005A_1.indd 9 22/4/08 4:11:54 PM22/4/08 4:11:54 PM

10
2 5/∞ buttons
• TUNER: Selects the preset stations.
• DISC:
– DVD-Video: Selects the title.
– DVD-VR: Selects the program/playlist.
– DivX/MP G Video/MP3/WMA/AAC/WAV:
Selects the folders if included.
• USB:
– DivX/MP G Video/MP3/WMA/AAC/WAV:
Selects the folders if included.
• CD-CH: Selects the folders if included.
• BT Audio: Selects the folders if included.
• iPOD:
–
5 : nters the main menu (then 5 / ∞ /
4 / ¢ work as menu
selecting buttons.)
5 : Returns to the previous menu.
∞ : Confirms the selection.
– ∞ : Pauses or resumes playback.
4 / ¢ buttons
• TUNER:
– Searches for stations automatically if pressed
briefly.
– Searches for stations manually if pressed and
held.
• DISC/USB/CD-CH:
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed and
held.
• BT Audio:
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed and
held.
• iPOD:
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed and
held.
In menu selecting mode:
– Selects an item if pressed briefly. (Then, press
∞ to confirm the selection.)
– Skips 10 items at a time if pressed and held.
3 VOL (volume) + / – buttons
• Adjusts the volume level.
2nd VOL (volume) buttons
• Adjust the volume level through the 2nd AUDIO
OUT plug while holding SHIFT button (see
page 25).
4 * 2 ASPECT button
• Not applicable for this unit.
5 * 1 PHONE button
• Answer incoming calls.
• nters “Redial” menu when a Bluetooth phone
is connected [Hold].
6 * 2 SETUP button
• nters disc setup menu (during stop).
7 * 2 TOP M (menu) button
• DVD-Video/DivX: Shows the disc menu.
• DVD-VR: Shows the Original Program screen.
• VCD: Resumes PBC playback.
8 * 2 OSD (on-screen display) button
• Shows the on-screen bar.
9 SHI T button
• Functions with other buttons.
p * 1 DISP (display) button
• Changes the display information.
q 1 / ¡ buttons
• DVD-Video: Slow motion playback (during
pause).
• DVD-VR/VCD: Forward slow motion playback
(during pause).
• DISC/USB: Reverse search/forward search.
EN10-17_KD-DV9406_005A_1.indd 10EN10-17_KD-DV9406_005A_1.indd 10 22/4/08 4:10:27 PM22/4/08 4:10:27 PM

11OPERATIONS
w*1 SOURCE button
• Selects the source.
e 3 (play) / 8 (pause) button
• DISC/USB/BT Audio: Starts/pauses playback.
r (end call) button
• nds the call.
BAND / 7 (stop) buttons
• TUNER: Selects the bands.
• DISC/USB/BT Audio: Stops playback.
t * 2 RETURN button
• VCD: Returns to the PBC menu.
y * 2 MENU button
• DVD-Video/DivX: Shows the disc menu.
• DVD-VR: Shows the Playlist screen.
• VCD: Resumes PBC playback.
u * 2 % / fi buttons
• DVD-Video: Makes selection/settings.
• CD-CH: Changes discs in the magazine.
@ / # buttons
• DVD-Video: Makes selection/settings.
• DivX/MP G Video: Skips back or forward by
about five minutes.
ENT (enter) button
• Confirms selection.
i * 2 DUAL button
• Activates or deactivates Dual Zone.
o SURROUND button
• Not applicable for this unit.
DIRECT button
• DISC/USB: nters direct search mode for
chapter/title/program/playlist/folder/track
while holding SHIFT button (see page 18 for
details).
CLR (clear) button
• DISC/USB/Bluetooth: rases the misentry
while holding SHIFT button.
*1 When Dual Zone is activated, these buttons cannot be
used.
*2 Functions as number buttons/* (asterisk)/# (hash)
while holding HIFT button.
– TUNER: elects the preset stations (1 – 6).
– DI C: Enters chapter/title/program/playlist/folder/
track number after entering search mode by
pressing HIFT and DIRECT (see page 18 for details).
EN10-17_KD-DV9406_005A_1.indd 11EN10-17_KD-DV9406_005A_1.indd 11 22/4/08 4:10:30 PM22/4/08 4:10:30 PM

12
M station automatic presetting
— SSM (Strong-station Sequential
Memory)
You can preset up to six stations for each band.
1 While listening to a station...
2
3
Local FM stations with the strongest signals are
searched and stored automatically in the selected
FM band.
When an M stereo broadcast is
hard to receive
1
2
Reception improves, but stereo effect will be lost.
• lights up on the display.
3 Exit from the setting.
Listening to the radio
1Select “TUNER.”
2Select the bands.
3Search for a station to listen—Auto Search.
Manual Search: Hold either one of the buttons until “Manual Search” lights up on the
display, then press it repeatedly.
• When receiving an FM stereo broadcast with sufficient signal strength, lights up
on the display.
EN10-17_KD-DV9406_005A_1.indd 12EN10-17_KD-DV9406_005A_1.indd 12 22/4/08 4:10:30 PM22/4/08 4:10:30 PM

13OPERATIONS
Manual presetting
x.: Storing FM station of 92.5 MHz into preset number
4 of the FM1 band.
Using the number buttons
1
2
3
Using the Preset Station list
• When is shown on the display, you can move
back to the previous screen by pressing number
button 3.
1 ollow steps 1 and 2 of “Using the number
buttons” above.
• By holding 5 / ∞, the Preset Station List will
also appear (go to step 4).
2
3 Display the Preset Station List.
4 Select the preset number you want to store
into.
• You can move to the lists of the other FM bands
by pressing number button 5 ( ) or
6 ( ) repeatedly.
5 Store the station.
Listening to the preset station on
the Preset Station List
1 Display the Preset Station List, then select
the preset station you want to listen to.
2 Change to the selected station.
Preset number flashes for a while.
EN10-17_KD-DV9406_005A_1.indd 13EN10-17_KD-DV9406_005A_1.indd 13 22/4/08 4:10:31 PM22/4/08 4:10:31 PM

14
To stop play and eject the disc
• Press SOURC to listen to another playback source.
Prohibiting disc ejection
To cancel the prohibition, repeat the same
procedure.
Disc operations
Before performing any operations...
Turn on the monitor to watch the playback picture. If you turn on the monitor, you can also control playback of other
discs by referring to the monitor screen. (See pages 20 – 23.)
The disc type is automatically detected, and playback starts automatically (for DVD: automatic start depends on its
internal program).
If the current disc does not have any disc menu, all tracks will be played repeatedly until you change the source or
eject the disc.
If “ ” appears on the monitor when pressing a button, the unit cannot accept the operation you have tried to
do.
• In some cases, without showing “ ,” operations will not be accepted.
1Open the control panel.
2
Insert the disc.
Playback starts automatically.
3Start playback if necessary.
EN10-17_KD-DV9406_005A_1.indd 14EN10-17_KD-DV9406_005A_1.indd 14 22/4/08 4:10:32 PM22/4/08 4:10:32 PM

15OPERATIONS
Operations using the control panel
Pressing (or holding) the following buttons allows you to...
Disc type
(Number buttons) *3
[Press] Select chapter
[Hold] Reverse/fast-forward
chapter *1
Select title During stop: Locate title
During play/pause: Locate
chapter
[Press] Select chapter
[Hold] Reverse/fast-forward
chapter *1
Select program number/
playlist number
During stop: Locate program
During play/pause: Locate
chapter
[Press] Select track
[Hold] Reverse/fast-forward track *2
Select folder Locate particular folder directly
[Press] Select track
[Hold] Reverse/fast-forward track *1—Locate particular track directly (PBC not in use)
[Press] Select track
[Hold] Reverse/fast-forward track *1
Select folder Locate particular folder directly
[Press] Select track
[Hold] Reverse/fast-forward track *1—Locate particular track directly
*1 earch speed:
*2 earch speed:
*3 Press to select number 1 to 6; hold to select number 7 to 12.
Continued on the next page
EN10-17_KD-DV9406_005A_1.indd 15EN10-17_KD-DV9406_005A_1.indd 15 22/4/08 4:10:33 PM22/4/08 4:10:33 PM

16
After pressing M MOD , press the following buttons to...
Disc type
Skip 10 chapters (during
play or pause)
Repeat Chapter:
Repeat current chapter
Repeat Title:
Repeat current title
—
Skip 10 chapters (during
play or pause)
Repeat Chapter:
Repeat current chapter
Repeat Program:
Repeat current program (not
available for Playlist Playback)
—
Skip 10 tracks (within the
same folder)
Repeat Track:
Repeat current track
Repeat older:
Repeat current folder
Random older:
Randomly play all tracks of
current folder, then tracks of
next folders
Random All:
Randomly play all tracks
Skip 10 tracks (PBC not in
use)
Repeat Track:
Repeat current track (PBC not in
use)
Random Disc:
Randomly play all tracks (PBC
not in use)
Skip 10 tracks (within the
same folder)
Repeat Track:
Repeat current track
Repeat older:
Repeat current folder
Random older:
Randomly play all tracks of
current folder, then tracks of
next folders
Random All:
Randomly play all tracks
Skip 10 tracks Repeat Track:
Repeat current track
Random All:
Randomly play all tracks
• You can also cancel the playback mode by selecting “Off” or press number button 4 ( ).
EN10-17_KD-DV9406_005A_1.indd 16EN10-17_KD-DV9406_005A_1.indd 16 22/4/08 4:10:34 PM22/4/08 4:10:34 PM

17OPERATIONS
5 Change to the selected item.
A If File List is selected
The list disappears and playback
starts.
B If Folder List is selected
• If the current folder is selected, File List
appears, then repeat steps 4 and 5 A to
start playback.
• If another folder is selected, playback starts
from the 1st file of the selected folder.
Selecting a folder/track on the list
(only for MP3/WMA/AAC/WAV file)
• When is shown on the display, you can move
back to the previous screen by pressing number
button 3.
1
2 Select “LIST.”
3 Select the list type.
4 Select an item.
• You can move to the other lists by pressing
number button 5 ( ) or 6 ( )
repeatedly.
x.: When “File” is selected in step 3
EN10-17_KD-DV9406_005A_1.indd 17EN10-17_KD-DV9406_005A_1.indd 17 22/4/08 4:10:34 PM22/4/08 4:10:34 PM

18
To search for chapter/title/program/playlist/folder/track directly (DVD/DivX/MPEG Video/VCD/
MP3/ MA/AAC/ AV/CD)
1 While holding SHIFT, press DIRECT repeatedly to select the desired search mode.
DVD-Video VCD
DVD-VR CD
DivX/MPEG Video
MP3/WMA/AAC/WAV
2 While holding SHIFT, press the number buttons (0 – 9) to enter the desired number.
3 Press ENT (enter) to confirm.
Button /
Stop play Stop play
Start play/Pause (if pressed during play) Start play/Pause (if pressed during play)
• Reverse/forward chapter search *1 (No
sound can be heard.)
• Slow motion *2 during pause (No sound can
be heard.)
* DVD-VR: Reverse slow motion does not work.
Reverse/forward track search *4 (No sound can
be heard.)
[Press] Select chapter (during play or pause)
[Hold] Reverse/fast-forward chapter search *3
[Press] Select track (during play or pause)
[Hold] Reverse/fast-forward track search *5
(No sound can be heard.)
• DVD-Video Select title (during play or
pause)
• DVD-VR Select program/playlist (during
play or pause)
Select folder
—
• Skip back or forward the scenes by about
five minutes
• Select chapter
Operations using the remote controller (RM-RK252)
Disc
EN18-25_KD-DV9406_005A_1.indd 18EN18-25_KD-DV9406_005A_1.indd 18 22/4/08 4:12:04 PM22/4/08 4:12:04 PM

19OPERATIONS
Stop play Stop play Stop play
Start play/Pause (if pressed during
play)
Start play/Pause (if pressed during
play)
Start play/Pause (if pressed during
play)
Reverse/forward track search *1
• Forward slow motion *2 during
pause. (No sound can be heard.)
* Reverse slow motion does not work.
Reverse/forward track search *1Reverse/forward track search *1
[Press] Select track (during play or
pause)
[Hold] Reverse/fast-forward track
search *3 (No sound can be
heard.)
[Press] Select track (during play or
pause)
[Hold] Reverse/fast-forward track
search *3
[Press] Select track (during play or
pause)
[Hold] Reverse/fast-forward track
search *3
—
Select folder
—
———
Continued on the next page
• For DivX/MPEG Video/MP3/WMA/AAC/WAV, track is searched within the same folder.
• To erase a misentry, press CLR (clear) while holding SHIFT.
• To return to the previous screen, press RETURN.
*1 Search speed:
*2 Slow motion speed:
*3 Search speed:
*4 Search speed:
*5 Search speed:
EN18-25_KD-DV9406_005A_1.indd 19EN18-25_KD-DV9406_005A_1.indd 19 22/4/08 4:12:06 PM22/4/08 4:12:06 PM

20
Operations using the
on-screen bar
(DVD/DVD-VR/DivX/MPEG Video/VCD)
These operations are possible on the monitor using the
remote controller.
1 Show the on-screen bar (see page 21).
2 Select an item.
3 Make a selection.
If pop-up menu appears...
• To cancel pop-up menu, press RETURN.
• For entering time/numbers, see the following.
Entering time/numbers
Press % / fi to change the number, then press @ / # to
move to the next entry.
• Each time you press % / fi, the number increases/
decreases by one value.
• After entering the numbers, press ENT (enter).
• It is not required to enter the zero and tailing zeros
(the last two digits in the example below).
Ex. Time search
DVD: _ _ _ _ _ (Ex. 1 02 00)
Press % once, then # twice to go to the third entry, %
twice, then press ENT (enter).
To remove the on-screen bar
(twice)
Using menu driven features... (DVD-Video/
DVD-VR)
1 Press TOP M/MENU to enter the menu screen.
2 Press % / fi / @ * / # * to select an item you want
to start play.
3 Press ENT (enter) to confirm.
* Not applicable or DVD-VR.
Canceling the PBC playback... (VCD)
1 During stop, press DIRECT while holding SHIFT.
2 Hold SHIFT, then press the number buttons (0 – 9)
to enter the desired number.
3 Press ENT (enter) to confirm.
• To resume PBC, press TOP M/MENU.
EN18-25_KD-DV9406_005A_1.indd 20EN18-25_KD-DV9406_005A_1.indd 20 22/4/08 4:12:07 PM22/4/08 4:12:07 PM
