JVC KD-G126 User manual

ENGLISH
INDONESIA
CD RECEIVER KD-G126/KD-G125
ALAT PENERIMA CD KD-G126/KD-G125
For canceling the display demonstration, see page 5.
Untuk membatalkan tampilan demonstrasi, lihat halaman 5.
For installation and connections, refer to the separate manual.
Untuk instalasi dan penyambungan, lihat buku pedoman terpisah.
INSTRUCTIONS
BUKU PETUNJUK
GET0331-004A
[UN]
KD-G126
KD-G125
KD-G125
KD-G126
Cover_KD-G125_126[UN]f.indd 2Cover_KD-G125_126[UN]f.indd 2 10/4/05 11:52:30 AM10/4/05 11:52:30 AM

ENGLISH
2
How to reset your unit
• Your preset adjustments will also be erased.
• If a disc is loaded, it will eject. Be careful not to
drop the disc.
How to forcibly eject a disc
• If this does not work, reset your unit.
• Be careful not to drop the disc when it ejects.
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to
obtain the best possible performance from the unit.
IMPORTANT FOR LASER PRO UCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
How to use the M MO E button
If you press M MODE, the unit goes into
functions mode, then the number buttons work
as different function buttons.
Ex.: When number button 2 works as
MO (monaural) button.
To use these buttons for their original
functions again after pressing M MODE, wait
for 5 seconds without pressing any of these
buttons until the functions mode is cleared or
press M MODE again.
Time countdown indicator
Warning:
If you need to operate the unit while driving,
be sure to look ahead carefully or you may be
involved in a traffic accident.
Caution on volume setting:
Discs produce very little noise compared
with other sources. Lower the volume
before playing a disc to avoid damaging
the speakers by the sudden increase of the
output level.
EN02-05_KD-G125_126[UN]f.indd 2EN02-05_KD-G125_126[UN]f.indd 2 10/4/05 11:54:41 AM10/4/05 11:54:41 AM

ENGLISH
3
CONTENTS
Control panel — K -G126 and K -G125 ........ 4
Getting started ................................. 5
Basic operations .................................................... 5
Radio operations .............................. 6
isc operations ................................. 7
Playing a disc in the unit ....................................... 7
Sound adjustments ........................... 8
General settings — PSM ................... 9
Maintenance .................................... 10
More about this unit ......................... 11
Troubleshooting ............................... 12
Specifications ................................... 13
For safety...
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• top the car before performing any
complicated operations.
Temperature inside the car...
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in
the car becomes normal before operating the
unit.
How to read this manual
• Button operations are mainly explained with
the illustrations in the table below.
• is used to indicate an indicator is
displayed for the corresponding operation.
• ome related tips and notes are explained in
“More about this unit” (see pages 11 and 12).
Press briefly.
Press repeatedly.
Press either
one.
Press and hold until your
desired response begins.
Press and hold both
buttons at the same time.
How to detach/attach the control
panel
Detaching...
Attaching...
EN02-05_KD-G125_126[UN]f.indd 3EN02-05_KD-G125_126[UN]f.indd 3 10/4/05 11:54:46 AM10/4/05 11:54:46 AM

ENGLISH
4
Control panel — KD-G126 and KD-G125
1 (standby/on/attenuator) button
2 OURCE button
3 BAND button
4 Loading slot
5 Display window
6 0 (eject) button
7 EQ (equalizer) button
8 ¢/4 buttons
9 Control dial
p EL (select) button
q DI P (display) button
w MO (monaural) button
e M ( trong-station equential Memory)
button
r Number buttons
t RPT (repeat) button
y RND (random) button
u M MODE button
i (control panel release) button
isplay window
o DI C indicator
; RND (disc random) indicator
a RPT (repeat) indicator
s . BA (super bass) indicator
d EQ (equalizer) indicator
f ound mode (C-EQ: custom equalizer)
indicators—JAZZ, CLA IC, HIP HOP,
POP , ROCK, U ER
g ource display
Volume level indicator
Time countdown indicator
h Main display
j Tuner reception indicators— T (stereo),
MO (monaural)
Parts identification
isplay window
EN02-05_KD-G125_126[UN]f.indd 4EN02-05_KD-G125_126[UN]f.indd 4 10/4/05 11:54:47 AM10/4/05 11:54:47 AM

ENGLISH
5
Basic settings
• ee also “General settings — P M” on page 9.
1
2
1 Canceling the display
demonstrations
elect “DEMO,” then “DEMO OFF.”
2 Setting the clock
elect “CLOCK H” (hour), then adjust
the hour.
elect “CLOCK M” (minute), then
adjust the minute.
3 inish the procedure.
To check the current clock
time while the power is
turned off
To check the other
information while listening
to the radio/a disc
Frequency/Elapsed playing time
Ô Clock
Getting started
Basic operations
~ Turn on the power.
Ÿ
* You cannot select “DIS ” as the
playback source if there is no disc in the
loading slot.
! or M/AM tuner
⁄ Adjust the volume.
.
Adjust the sound as you want. (See
page 8.)
To drop the volume in a
moment (ATT)
To restore the sound, press
it again.
To turn off the power
Volume level appears.
Volume level indicator
EN02-05_KD-G125_126[UN]f.indd 5EN02-05_KD-G125_126[UN]f.indd 5 10/4/05 11:54:47 AM10/4/05 11:54:47 AM

ENGLISH
6
Radio operations
~
Ÿ
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
Selected band appears.
! Start searching for a station.
When a station is received,
searching stops.
To stop searching, press the
same button again.
To tune in to a station manually
In step ! above...
1
2 Select the desired station frequencies.
When an FM stereo broadcast is hard to
receive
Reception improves, but stereo effect will be
lost.
To restore the stereo effect, repeat the same
procedure “MONO OFF appears and the MO
indicator goes off.
Storing stations in memory
You can preset six stations for each band.
FM station automatic presetting —
SSM (Strong-station Sequential
Memory)
1 Select the FM band (FM1 – FM3) you
ant to store into.
2
3
“SSM flashes, then disappears when
automatic presetting is over.
Local FM stations with the strongest signals are
searched and stored automatically in the FM
band.
Lights up when monaural mode is activated.
EN06-09_KD-G125_126[UN]f.indd 6EN06-09_KD-G125_126[UN]f.indd 6 10/4/05 11:55:21 AM10/4/05 11:55:21 AM

ENGLISH
7
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset
number 4 of the FM1 band.
1
2
3
Listening to a preset station
1
2 Select the preset station (1 – 6) you
ant.
Disc operations
laying a disc in the unit
All tracks will be played repeatedly until you
change the source or eject the disc.
To stop play and eject the
disc
To fast-forward or reverse
the track
To go to the next or
previous tracks
To locate a particular track directly
To select a number from 01 – 06:
To select a number from 07 – 12:
rohibiting disc ejection
You can lock a disc in the loading slot.
To cancel the prohibition, repeat the same
procedure.
Preset number flashes for a while.
EN06-09_KD-G125_126[UN]f.indd 7EN06-09_KD-G125_126[UN]f.indd 7 10/4/05 11:55:27 AM10/4/05 11:55:27 AM

ENGLISH
8
Sound adjustments
You can select a preset sound mode suitable to
the music genre (C-EQ: custom equalizer).
Indication (For)
BAS TRE S.BS
(bass) (treble)
(super
bass)
USER (Flat sound) 00 00 OFF
ROCK
(Rock or disco music) +03 +01 ON
CLASSIC
(Classical music) +01 –02 OFF
POPS (Light music) +04 +01 OFF
HIP HOP
(Funk or rap music) +02 00 ON
JAZZ (Jazz music) +02 +03 OFF
Indication, [Range]
BAS*2 (bass), [–06 to +06]
Adjust the bass.
TRE*2 (treble), [–06 to +06]
Adjust the treble.
FAD*3 (fader), [R06 to F06]
Adjust the front and rear speaker balance.
BAL*4 (balance), [L06 to R06]
Adjust the left and right speaker balance.
S.BS*2 (super bass), [S.BS ON or S.BS OFF],
[01 to 05]
*5
Maintain the richness and fullness of the bass
sound regardless of how low you set the volume.
SUB. W
(subwoofer), [00 to 08]
Adjust the subwoofer output level when a
subwoofer is connected.
VOL (volume), [00 to 30 or 50*6]
Adjust the volume.
*2 When you adjust the bass, treble, or
super bass the adjustment you have made is
stored for the currently selected sound mode
(C-EQ) including “ SER.”
*3 If you are using a two-speaker system, set the
fader level to “00.”
*4 This adjustment cannot affect the subwoofer
output.
*5 Range adjustment for super bass is adjustable
only when it is set to “S.BS ON.”
*6 Depending on the amplifier gain control
setting. (See page 9 for details.)
reset values
Adjusting the sound
You can adjust the sound characteristics to your
preference.
*1 Displayed only when “L/O MODE” is set to
“WOOFER” (see page 9).
Selecting the playback modes
You can use only one of the following playback
modes at a time.
1
2 Select your desired playback mode.
7 Repeat play
Mode lays repeatedly
TRK RPT : The current track.
RPT OFF : Cancels.
7 Random play
Mode lays at random
DISC RND : All tracks of the current disc.
RND OFF : Cancels.
EN06-09_KD-G125_126[UN]f.indd 8EN06-09_KD-G125_126[UN]f.indd 8 10/4/05 11:55:28 AM10/4/05 11:55:28 AM

ENGLISH
9
3 Adjust the PSM item selected.
4 Repeat steps 2 and 3 to adjust other
PSM items if necessary.
5 Finish the procedure.
You can change PSM (Preferred Setting Mode)
items listed in the table that follows.
1
2 Select a PSM item.
Indications Selectable settings, [reference page]
DEMO
Display
demonstration
DEMO ON : [Initial]; Display demonstration will be activated automatically
if no operation is done for about 20 seconds, [5].
DEMO OFF : Cancels.
CLOCK H
Hour adjustment
1 – 12, [5]
[Initial: 1 (1:00)]
CLOCK M
Minute adjustment
00 – 59, [5]
[Initial: 00 (1:00)]
L/O MODE
Line output mode
When connecting an amplifier or a subwoofer, set this correctly.
REAR : [Initial]; Select if the REAR LINE OUT terminals are used for
connecting the speakers through an external amplifier.
WOOFER : Select if the REAR LINE OUT terminals are used for
connecting a subwoofer.
AMP GAIN
Amplifier gain
control
You can change the maximum volume level of this unit.
LOW PWR : VOL 00 – VOL 30 (Select this if the maximum power of the
speaker is less than 50 W to avoid damaging the speaker.)
HIGH PWR : [Initial]; VOL 00 – VOL 50
General settings — PSM
EN06-09_KD-G125_126[UN]f.indd 9EN06-09_KD-G125_126[UN]f.indd 9 10/4/05 11:55:29 AM10/4/05 11:55:29 AM

ENGLISH
10
Warped disc
Sticker Sticker residue
Disc Stick-on label
Do not use the following discs:
Maintenance
How to clean the connectors
Frequent detachment will deteriorate the
connectors.To minimize this possibility,
periodically wipe the connectors with a cotton
swab or cloth moistened with alcohol, being
careful not to damage the connectors.
Moisture condensation
Moisture may condense on the lens inside the
CD player in the following cases:
After starting the heater in the car.
If it becomes very humid inside the car.
Should this occur, the CD player may
malfunction.In this case, eject the disc and leave
the unit turned on for a few hours until the
moisture evaporates.
How to handle discs
When removing a disc from
its case, press down the center
holder of the case and lift the disc
out, holding it by the edges.
Always hold the disc by the
edges. Do not touch its recording surface.
When storing a disc into its case, gently insert
the disc around the center holder (with the
printed surface facing up).
Make sure to store discs into the cases after
use.
To play new discs
New discs may have some rough
spots around the inner and outer
edges. If such a disc is used, this
unit may reject the disc.
To remove these rough spots, rub the edges
with a pencil or ball-point pen, etc.
To keep discs clean
A dirty disc may not play correctly.
If a disc does become dirty, wipe it
with a soft cloth in a straight line
from center to edge.
Do not use any solvent (for example,
conventional record cleaner, spray, thinner,
benzine, etc.) to clean discs.
Center holder
Connector
EN10-13_KD-G125_126[UN]f.indd 10EN10-13_KD-G125_126[UN]f.indd 10 10/4/05 11:55:55 AM10/4/05 11:55:55 AM

ENGLISH
11
More about this unit
Inserting a disc
When a disc is inserted upside down, the disc
automatically ejects.
Do not insert 8 cm discs (single CD) and
unusual shape discs (heart, flower, etc.) into
the loading slot.
Playing a CD-R or CD-RW
Use only “finalized” CD-Rs or CD-RWs.
This unit can play back multi-session discs;
however, unclosed sessions will be skipped
while playing.
Some CD-Rs or CD-RWs may not play
back on this unit because of their disc
characteristics, and for the following causes:
– Discs are dirty or scratched.
– Moisture condensation occurs on the lens
inside the unit.
– The pickup lens inside the unit is dirty.
– CD-R/CD-RW on which the files are
written with “Packet Write” method.
– There are improper recording conditions
(missing data, etc.) or media conditions
(stain, scratch, warp, etc.).
CD-RWs may require a longer readout time
since the reflectance of CD-RWs is lower than
that of regular CDs.
Do not use the following CD-Rs or CD-RWs:
– Discs with stickers, labels, or protective seal
stuck to the surface.
– Discs on which labels can be directly
printed by an ink jet printer.
Using these discs under high temperatures
or high humidity may cause malfunctions or
damages to the unit.
Changing the source
If you change the source, playback also stops
(without ejecting the disc).
Next time you select “DISC” for the playback
source, disc play starts from where it has been
stopped previously.
Basic operations
Turning on the power
By pressing SOURCE on the unit, you can
also turn on the power. If the source is ready,
playback also starts.
Turning off the power
If you turn off the power while listening to a
disc, disc play will start from where playback
has been stopped previously, next time you
turn on the power.
electing the sources
When no disc is loaded in the unit, “DISC”
cannot be selected.
Tuner operations
toring stations in memory
During SSM search...
– All previously stored stations are erased and
stations are stored newly.
–
Received stations are preset in No. 1 (lowest
frequency) to No. 6 (highest frequency).
– When SSM is over, the station stored in
No. 1 will be automatically tuned in.
When storing a station manually, a previously
preset station is erased when a new station is
stored in the same preset number.
Disc operations
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does
not comply with the “Compact Disc Digital
Audio” standard. Therefore, the use of Non-
DVD side of a DualDisc on this product may
not be recommended.
General
This unit has been designed to reproduce
CDs, and CD-Rs (Recordable)/CD-RWs
(Rewritable) in audio CD (CD-DA) format.
When a disc has been loaded, selecting
“DISC” for the playback source starts disc
play. To be continued...
EN10-13_KD-G125_126[UN]f.indd 11EN10-13_KD-G125_126[UN]f.indd 11 10/4/05 11:55:59 AM10/4/05 11:55:59 AM

ENGLISH
12
ymptoms Remedies/Causes
General
Sound cannot be heard from the
speakers.
Adjust the volume to the optimum level.
Check the cords and connections.
This unit does not work at all. Reset the unit (see page 2).
FM/AM
SSM automatic presetting does not
work.
Store stations manually.
Static noise while listening to the
radio.
Connect the antenna firmly.
Disc playback
Disc automatically ejects. Insert the disc correctly.
CD-R/CD-RW cannot be played
back.
Tracks on the CD-R/CD-RW cannot
be skipped.
Insert a finalized CD-R/CD-RW.
Finalize the CD-R/CD-RW with the component
which you used for recording.
Disc can be neither played back nor
ejected.
Unlock the disc (see page 7).
Eject the disc forcibly (see page 2).
Disc sound is sometimes interrupted. Stop playback while driving on rough roads.
Change the disc.
Check the cords and connections.
“NO DISC” appears on the display. Insert a playable disc into the loading slot.
Troubleshooting
What appears to be trouble is not always serious. Check the following points before calling a service
center.
Ejecting a disc
If the ejected disc is not removed within
15 seconds, the disc is automatically inserted
again into the loading slot to protect it from
dust. (Disc will not play this time.)
General settings—P M
If you change the “AMP GAIN” setting from
“HIGH PWR” to “LOW PWR” while the
volume level is set higher than “VOL 30,” the
unit automatically changes the volume level to
“VOL 30.”
EN10-13_KD-G125_126[UN]f.indd 12EN10-13_KD-G125_126[UN]f.indd 12 10/4/05 11:56:00 AM10/4/05 11:56:00 AM

ENGLISH
13
CD PLAYER ECTION
Type: Compact disc player
Signal Detection System: Non-contact optical
pickup (semiconductor laser)
Number of channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Range: 96 dB
Signal-to-Noise Ratio: 98 dB
Wow and Flutter: Less than measurable limit
GENERAL
Power Requirement:
Operating Voltage:
DC 14.4 V (11 V to 16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature:
0°C to +40°C
Dimensions (W × H × D):
Installation Size (approx.):
182 mm × 52 mm × 150 mm
Panel Size (approx.):
188 mm × 58 mm × 11 mm
Mass (approx.):
1.2 kg (excluding accessories)
Design and specifications are subject to change
without notice.
Specifications
AUDIO AMPLIFIER ECTION
Maximum Power Output:
Front: 50 W per channel
Rear: 50 W per channel
Continuous Power Output (RMS):
Front: 19 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Rear: 19 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range:
Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Frequency Response: 40 Hz to 20 000 Hz
Signal to Noise Ratio: 70 dB
Line-Out Level/Impedance:
2.0 V/20 kΩ load (full scale)
Output Impedance: 1 kΩ
Subwoofer-Out Level/Impedance:
2.0 V/20 kΩ load (full scale)
TUNER ECTION
Frequency Range:
FM: 87.5 MHz to 108.0 MHz
AM: 531 kHz to 1 602 kHz
[FM Tuner]
Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω)
50 dB Quieting Sensitivity:
16.3 dBf (1.8 μV/75 Ω)
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 35 dB
Capture Ratio: 1.5 dB
[AM Tuner]
Sensitivity: 20 μV
Selectivity: 35 dB
EN10-13_KD-G125_126[UN]f.indd 13EN10-13_KD-G125_126[UN]f.indd 13 10/4/05 11:56:00 AM10/4/05 11:56:00 AM

INDONESIA
2
Bagaimana mereset unit anda
• Penyetelan-penyetelan pengaturan awal anda
akan terhapus juga.
• Jika sebuah disk sudah dimuat, akan
dikeluarkan. Hati-hati untuk tidak
menjatuhkan disk tersebut.
Bagaimana secara paksa
mengeluarkan sebuah disk
• Jika ini tidak bekerja, coba mengeset kembali
(reset) alat penerima anda.
• Hati-hati untuk tidak menjatuhkan disk
tersebut ketika dikeluarkan.
Terima kasih telah membeli produk JVC.
Harap membaca seluruh petunjuk dengan teliti sebelum mengoperasikan, untuk memastikan anda
memahami secara keseluruhan dan mendapatkan performansi terbaik dari unit ini.
PENTING UNTUK PRODUK-PRODUK ASER
1. PR DUK LASER KELAS 1
2. PERHATIAN: Jangan membuka penutup atas. Tidak ada bagian yang dapat diperbaiki oleh
pengguna di dalam unit tersebut; biarkanlah semua bagian yang diperbaiki untuk memenuhi
syarat perbaikan teknis.
3. PERHATIAN: Radiasi laser yang terlihat dan tidak terlihat ketika membuka dan salah sambung
atau gagal. Hindari sorotan pencahayaan yang langsung.
4. REPR DUKSI DARI LABEL: LABEL PERHATIAN, TEMPATKAN DI LUAR UNIT
TERSEBUT.
Bagaimana menggunakan tombol
M MODE
Jika anda menekan M M DE, alat penerima
masuk ke dalam mode fungsi-fungsi, kemudian
tombol-tombol nomor bekerja sebagai tombol-
tombol yang berbeda fungsi.
Contoh: Ketika tombol nomor 2 bekerja
sebagai tombol M (mono).
Untuk menggunakan tombol-tombol ini
untuk fungsi aslinya setelah menekan M
MODE, tunggu 5 detik tanpa menekan tombol
apa pun sampai mode fungsi kosong atau tekan
lagi M M DE.
Peringatan:
Jika anda perlu mengoperasikan unit tersebut
sementara mengemudi, pastikan untuk
melihat ke atas dengan hati-hati atau anda
mungkin terlibat suatu kecelakaan lalu lintas.
Perhatian pada pengaturan volume:
Disk-disk menghasilkan sangat kecil noise
(derau) dibandingkan dengan sumber yang
lain. Kecilkan volume sebelum disk untuk
menghindari kerusakan speaker-speaker
dengan penambahan mendadak dari level
keluaran.
Indikator hitung mundur waktu
IN02-05_KD-G125_126[UN]f.indd 2IN02-05_KD-G125_126[UN]f.indd 2 10/11/05 5:02:21 PM10/11/05 5:02:21 PM

INDONESIA
3
DAFTAR ISI
Panel kontrol — KD-G126 dan KD-G125 ........ 4
Memulai .......................................... 5
Pengoperasian-pengoperasian dasar .................... 5
Pengoperasian–pengoperasian
radio .............................................. 6
Pengoperasian-pengoperasian disk ... 7
Memainkan disk di dalam unit .............................. 7
Penyetelan suara-suara .................... 8
Pengaturan-pengaturan umum
— PSM .......................................... 9
Perawatan ....................................... 10
ebih lagi tentang alat penerima
ini .................................................. 11
Pemecahan Masalah ......................... 12
Spesifikasi-spesifikasi ....................... 13
Untuk keselamatan...
• Jangan menaikkan level volume terlalu tinggi
karena akan menghalangi suara dari luar, dan
membahayakan perjalanan anda.
• Hentikan mobil sebelum melakukan
pengoperasian yang rumit.
Suhu dalam mobil...
Jika anda telah memarkir mobil terlalu lama
dalam cuaca yang panas atau dingin, tunggu
hingga suhu dalam mobil menjadi normal
kembali sebelum mengoperasikan unit ini.
Bagaimana membaca manual ini
• preasi tombol secara umum dijelaskan
dengan ilustrasi dalam tabel di bawah ini.
• digunakan untuk menunjukkan
indikator yang ditampilkan untuk
pengoperasian yang bersangkutan.
• Beberapa saran dan catatan yang berkaitan
dijelaskan dalam “Lebih lagi tentang alat
penerima ini” (lihat halaman 11 dan 12).
Tekan dengan singkat.
Tekan secara berulang.
Tekan salah
satu.
Tekan dan tahan sampai
respon yang anda
harapkan dimulai.
Tekan dan tahan kedua
tombol pada waktu
bersamaan.
Cara melepas/memasang panel kontrol
Melepas...
Memasang…
IN02-05_KD-G125_126[UN]f.indd 3IN02-05_KD-G125_126[UN]f.indd 3 10/11/05 4:38:36 PM10/11/05 4:38:36 PM

INDONESIA
4
Panel kontrol — KD-G126 dan KD-G125
1 Tombol (standby/hidup/pelemah)
2 Tombol S URCE
3 Tombol BAND
4 Celah pemuatan
5 Jendela tampilan
6 Tombol 0 (keluar)
7 Tombol EQ (equalizer)
8 Tombol-tombol ¢/4
9 Tombol kontrol
p Tombol SEL (pilih)
q Tombol-tombol DISP (tampilan)
w Tombol M (mono)
e Tombol SSM (Memori Urutan Stasiun-
Kuat)
r Tombol-tombol nomor
t Tombol RPT (ulang)
y Tombol RND (acak)
u Tombol M M DE
i Tombol (pelepas panel kontrol)
Jendela tampilan
o Indikator DISC
; Indikator RND (disk acak)
a Indikator RPT (ulang)
s indikator S. BASS (super bass)
d Indikator EQ (equalizer)
f Indikator-indikator mode suara (C-EQ:
kostum equalizer)—JAZZ, CLASSIC,
HIP H P, P PS, R CK, USER
g Tampilan sumber
Indikator level volume
Indikator hitung mundur waktu
h Tampilan utama
j Indikator-indikator penerima tuner—ST
(stereo), M (mono)
Pengenalan bagian-bagian
Jendela tampilan
IN02-05_KD-G125_126[UN]f.indd 4IN02-05_KD-G125_126[UN]f.indd 4 10/11/05 4:38:37 PM10/11/05 4:38:37 PM

INDONESIA
5
Pengaturan dasar
• Lihat juga “Pengaturan-pengaturan umum
— PSM” pada halaman 9.
1
2
1 Membatalkan tampilan
demonstrasi-demonstrasi
Pilih “DEM ”, kemudian “DEM
FF”.
2 Pengaturan jam
Pilih “CL CK H” (jam), kemudian setel
jam.
Pilih “CL CK M” (menit), kemudian
setel menit.
3 Prosedur selesai.
Untuk mengecek waktu
jam yang berlaku sekarang
sewaktu daya dimatikan
Untuk mengecek
informasi lainnya sewaktu
mendengarkan radio/disc
Frekuensi/Waktu putar yang
sudah lewat Ô Jam
Memulai
Pengoperasian-pengoperasian
dasar
~ Menghidupkan po er.
Ÿ
* nda tidak dapat memilih “DISC”
sebagai sumber putar ulang jika tidak
ada disk di dalam celah pemuatan.
! Untuk radio FM/AM
⁄ Setel volume.
Setel suara sesuai keinginan anda.
(Lihat halaman 8).
Untuk menurunkan volume
dalam sesaat (ATT)
Untuk mengembalikan suara,
tekanlah kembali.
Untuk mematikan power
Level volume muncul.
Indikator level volume
IN02-05_KD-G125_126[UN]f.indd 5IN02-05_KD-G125_126[UN]f.indd 5 10/11/05 4:38:37 PM10/11/05 4:38:37 PM

6
INDONESIA
Pengoperasian–
pengoperasian radio
~
Ÿ
Menyala ketika menerima sebuah siaran
stereo FM dengan kekuatan sinyal yang
cukup.
Jalur yang dipilih muncul.
! Mulai mencari sebuah stasiun.
Ketika sebuah stasiun
diterima, pencarian
berhenti.
Untuk menghentikan
pencarian, tekan tombol
yang sama kembali.
Untuk menyetel ke sebuah stasiun secara
manual
Pada langkah ! di atas...
1
2 Pilih frekuensi-frekuensi stasiun yang
diinginkan.
Ketika sebuah siaran stereo FM sulit diterima
Penerimaan membaik, tetapi efek stereo akan
hilang.
Untuk mengembalikan efek stereo, ulangi
prosedur yang sama, “MONO OFF” muncul
dan indikator MO padam.
Menyimpan stasiun-stasiun dalam
memori
nda dapat preset (mengatur awal) enam
stasiun untuk setiap jalur.
Mempreset (Mengatur awal) secara
otomatis stasiun FM—SSM (Memori
Urutan Stasiun-kuat)
1 Pilih jalur FM (FM1 FM3) yang
anda ingin simpan di dalamnya.
2
3
“SSM” berkedip, kemudian hilang ketika
mempreset (mengatur awal) secara otomatis
selesai.
Stasiun-stasiun FM lokal dengan sinyal-sinyal
terkuat dicari dan disimpan secara otomatis
dalam jalur FM tersebut.
Menyala ketika mode mono diaktifkan.
IN06-09_KD-G125_126[UN]f.indd 6IN06-09_KD-G125_126[UN]f.indd 6 10/11/05 4:39:19 PM10/11/05 4:39:19 PM

7
INDONESIA
Mempreset (Mengatur awal) secara
manual
Contoh: Menyimpan stasiun FM dari
92.5 MHz ke dalam pengaturan
sebelumnya nomor 4 dari jalur FM1.
1
2
3
Mendengarkan sebuah preset
(pengaturan awal) stasiun
1
2 Pilih preset (pengaturan awal) stasiun
(1 6) yang anda inginkan.
Pengoperasian-
pengoperasian disk
Memainkan disk di dalam unit
Semua trek akan diputar secara berulang sampai
anda mengganti sumber atau mengeluarkan disk.
Untuk menghentikan putar
dan mengeluarkan disk
Untuk maju-cepat atau
mundur trek
ergi ke trek-trek sesudah
atau sebelumnya
Untuk menemukan trek tertentu secara
langsung
Untuk memilih sebuah nomor dari 01 – 06:
Untuk memilih sebuah nomor dari 07 – 12:
engeluaran disk dilarang
nda dapat mengunci sebuah disk dalam celah
pemuatan.
Untuk membatalkan larangan, ulangi prosedur
yang sama.
Nomor preset (pengaturan awal) berkedip-kedip sesaat.
IN06-09_KD-G125_126[UN]f.indd 7IN06-09_KD-G125_126[UN]f.indd 7 10/11/05 4:39:22 PM10/11/05 4:39:22 PM

8
INDONESIA
Penyetelan suara-suara
nda dapat memilih sebuah mode preset
(pengaturan awal) yang sesuai untuk jenis musik
(C-EQ: kostum equalizer).
Indikasi (Untuk)
BAS TRE S.BS
(bas) (trebel)
(super
bass)
USER (Suara rata) 00 00 OFF
ROCK
(Musik rock atau disko) +03 +01 ON
CLASSIC
(Musik klasik) +01 –02 OFF
POPS (Musik ringan) +04 +01 OFF
HIP HOP
(Musik funk atau rap) +02 00 ON
JAZZ (Musik jazz) +02 +03 OFF
Indikasi, [Cakupan]
BAS*2 (bas), [–06 ke +06]
Setel bas.
TRE*2 (trebel), [–06 ke +06]
Setel trebel.
FAD*3 (feder (pemudar)), [R06 ke F06]
Setel balance (seimbang) speaker depan dan
belakang.
BAL*4 (balance), [L06 ke R06]
Setel balance (seimbang) speaker kiri dan
kanan.
S.BS*2 (super bass), [S.BS ON atau S.BS OFF],
[01 ke 05]*5
Mempertahankan suara bass yang mantap dan
utuh, tanpa terpengaruh volume yang nda
setel serendah apa pun.
SUB. W (subwoofer), [00 ke 08]
Menyesuaikan tingkat keluaran subwoofer
apabila subwoofer dihubungkan.
VOL (volume), [00 ke 30 atau 50*6]
Setel volume.
*2 Apabila Anda menyetel bass, trebel, atau
super bass, setelan yang Anda buat disimpan
untuk modus suara yang sekarang dipilih
(C-EQ), termasuk “USER .
*3 Jika anda menggunakan sebuah sistem dua-
speaker, atur level feder (pemudar) ke “00 .
*4 Penyesuaian ini tidak mempengaruhi
keluaran subwoofer.
*5 Kisaran penyesuaian untuk super bass hanya
disesuaikan apabila super bass disetel ke
“S.BS ON .
*6 Tergantung pada pengaturan kontrol
penambah penguat. (Lihat halaman 9 untuk
lebih rinci.)
Nilai-nilai preset
(pengaturan awal)
Menyetel Suara
nda dapat menyetel karakteristik-karakteristik
suara untuk kesukaan anda.
*1 Hanya ditampilk
KD-G126 DD1:
Memilih mode-mode putar ulang
nda dapat menggunakan hanya satu dari
mode putar ulang berikut pada saat yang sama.
1
2 Pilih mode putar ulang yang anda
inginkan.
7 Putar berulang
Mode utar secara berulang-ulang
TRK RPT : Trek yang sekarang.
RPT OFF : Batal.
7 Putar acak
Mode utar acak
DISC RND : Semua trek-trek dari disk yang
sekarang.
RND OFF : Batal.
IN06-09_KD-G125_126[UN]f.indd 8IN06-09_KD-G125_126[UN]f.indd 8 10/11/05 4:39:22 PM10/11/05 4:39:22 PM
