JVC KD-R604 Guide

1
When using the optional stay
Install the unit at an angle of
less than 30˚.
This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems. If your vehicle does not have this system, a voltage inverter is required, which can be purchased at JVC car audio dealers.
WARNINGS
To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all electrical connections before installing the unit.
•Be sure to ground this unit to the car’s chassis again after installation.
Notes:
•Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio dealer.
•It is recommended to connect speakers with a maximum power of more than 50 W (both at the rear and at the front, with an impedance of 4 Ωto 8 Ω). If the maximum power
is less than 50 W, change “AMP GAIN” setting to prevent the speakers from being damaged (see page 25 of the INSTRUCTIONS).
•To prevent short circuits, cover the terminals of the UNUSED leads with insulating tape.
•The heat sink becomes very hot after use. Be careful not to touch it when removing this unit.
PRECAUTIONS on power supply and speaker connections:
•DO NOT connect the speaker leads of the power cord to the car battery; otherwise, the unit
will be seriously damaged.
•BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in
your car.
F
Handles
A/ B
Hard case/
Control panel
C
Sleeve
E
Power cord
INSTALLATION (IN-DASH MOUNTING)
The following illustration shows a typical installation. If you have any questions or require information regarding installation kits, consult your JVC car audio dealer or a company supplying kits.
•If you are not sure how to install this unit correctly, have it installed by a qualified technician.
Removing the unit
Before removing the unit, release the rear section.
H
Battery
G
Remote
controller
Parts list for installation and connection
The following parts are provided for this unit. If any item is missing, consult your JVC car audio
dealer immediately.
D
Trim plate
Insert the two handles, then pull them as
illustrated so that the unit can be removed.
KD-R604
Installation/Connection Manual
GET0578-002B
[UI]
0409DTSMDTJEIN
EN
© 2009 Victor Company of Japan, Limited
Heat sink
Do the required electrical connections.
Bend the appropriate tabs to hold the
sleeve firmly in place.
Screw (option)
Stay (option)
Fire wall
Dashboard
Note : When installing the unit on the
mounting bracket, make sure to
use the 8 mm-long screws. If longer
screws are used, they could damage
the unit.
Bracket*6
Pocket
Flat head screws (M5 ×8 mm) *6
When installing the unit without
using the sleeve
In a Toyota car for example, first remove the car
radio and install the unit in its place.
Flat head screws
(M5 ×8 mm) *6
Bracket *6
*1When you stand the unit, be careful not to damage the fuse on the rear.
*2Rubber cushion—Not supplied for this unit
*3Mounting bolt (M4 × 5 mm; M5 × 12.5 mm)—Not supplied for this unit
*4Washer (ø5)—Not supplied for this unit
*5Lock nut (M5)—Not supplied for this unit
*6Not supplied for this unit.
Install_KD-R604[UI]ff.indd 1Install_KD-R604[UI]ff.indd 1 4/15/09 3:58:46 PM4/15/09 3:58:46 PM

2
ELECTRICAL CONNECTIONS
TROUBLESHOOTING
•The fuse blows.
*Are the red and black leads connected correctly?
•Power cannot be turned on.
*Is the yellow lead connected?
•No sound from the speakers.
*Is the speaker output lead short-circuited?
•Sound is distorted.
*Is the speaker output lead grounded?
*Are the “–” terminals of L and R speakers
grounded in common?
A
Typical connections
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in color.
1Connect the colored leads of the power cord in the order specified in the illustration below.
2Connect the antenna cord.
3Finally connect the wiring harness to the unit.
Connecting the external amplifier or subwoofer
Rear speakers
Remote lead Y-connector (not supplied for this unit)
Remote lead (blue with white stripe)
To the remote lead of other
equipment or automatic
antenna if any
B
Front speakers
You can connect an amplifier to upgrade your car stereo system.
•Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it can be controlled through this unit.
•Disconnect the speakers from this unit, connect them to the amplifier. Leave the speaker leads of this unit unused.
*1Not supplied for this unit.
*2Before checking the operation of this unit prior to
installation, this lead must be connected, otherwise the
power cannot be turned on.
Signal cord (not supplied for this unit)
JVC Amplifier
JVC Amplifier
Set “L/O MODE” to “REAR” (See page 25 of the
INSTRUCTIONS.)
Set “L/O MODE” to “SUB.W” (See page 25 of the
INSTRUCTIONS.)
Subwoofer
Connecting the external components
When connecting the external components, refer also to the manuals supplied for the components and
adapters.
CAUTION:
Before connecting the external components, make sure that the unit is turned off.
You can connect the following JVC components to the CD changer jack.
JVC component Model name
CD changer (CD-CH) CH-X1500, etc.
You can also connect the following components through the various JVC adapters.
• Connection cords may need to be purchased separately.
Component Adapter Model name
Bluetooth device Bluetooth adapter KS-BTA200
iPod Interface adapter for iPod KS-PD100
Portable audio player with line
output jacks
Line input adapter KS-U57
Portable audio player with 3.5 mm
stereo mini jack
AUX input adapter KS-U58
C
CD changer jack
When connecting two components in series
AKS-BTA200
B*4CD-CH / KS-PD100 /
KS-U57 / KS-U58
*4
iPod is a trademark of Apple Inc., registered in
the U.S. and other countries.
To disconnect the connector
Hold the connector
tightly (1), then pull it
out (2).
•Noise interfere with sounds.
*Is the rear ground terminal connected to the car’s
chassis using shorter and thicker cords?
•This unit becomes hot.
*Is the speaker output lead grounded?
*Are the “–” terminals of L and R speakers
grounded in common?
•This unit does not work at all.
*Have you reset your unit?
or
Remote lead
Rear line out (see diagram ) Rear ground terminal
15 A fuse
Antenna terminal To external components (see diagram )
Black
Red
Yellow *2
Blue with white stripe
Blue
Orange with white stripe
To the metallic body or chassis of the car
To a live terminal in the fuse block connecting to the car battery
(bypassing the ignition switch) (constant 12 V)
To an accessory terminal in the fuse block
To the remote lead of other equipment (200 mA max.)
To the automatic antenna if any (250 mA max.)
To car light control switch
Ignition switch
Fuse block
PurplePurple with black stripeGreenGreen with black stripeGrayGray with black stripeWhiteWhite with black stripe
Right speaker (rear)Left speaker (rear)
Right speaker (front)Left speaker (front)
*3Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint
(if coated with paint, remove the paint before attaching the wire). Failure to do so may cause damage to the unit.
*4To use these components, set the external input setting correctly (see page 25 of the INSTRUCTIONS).
When connecting more than one component (maximum: two), it is recommended that you connect the
components in series as explained below.
