JVC KS-F345 User manual

GET0112-001A
[EE]
INSTRUCTIONS
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
KS-F345
CASSETTE RECEIVER
РЕСИВЕР С ПРОИГРЫВАТЕЛЕМ КОМПАКТ-ДИСКОВ
ENGLISH
РУCCKИЙ
For installation and
connections, refer to
the separate manual.
Указания по
установке и
выполнению
соединений
приводятся в
отдельной
инструкции.
В соответствии с Законом Российской Федерации “О за ите прав
потребителей” срок службы (годности) данного товара “по истечении
которого он может представлять опасность для жизни, здоровья
потребителя, причинять вред его иму еству или окружаю ей среде”
составляет семь (7) лет со дня производства. Этот срок является
временем, в течение которого потребитель данного товара может
безопасно им пользоваться при условии соблюдения инструкции по
эксплуатации данного товара, проводя необходимое обслуживание,
включаю ее замену расходных материалов и/или соответствую ее
ремонтное обеспечение в специализированном сервисном центре.
Дополнительные косметические материалы к данному товару,
поставляемые вместе с ним, могут храниться в течение двух (2) лет со дня
его производства.
Срок службы (годности), кроме срока хранения дополнительных
косметических материалов, упомянутых в предыду их двух пунктах, не
затрагивает никаких других прав потребителя, в частности, гарантийного
свидетельства JVC, которое он может получить в соответствии с законом
о правах потребителя или других законов, связанных с ним.
SSM
SCMMO
S.BASS
SEL
AM
EX
FM
DISP
Cover001AKS-F345[EE]f.p65 11/14/02, 3:44 PM3

2
ENGLISH
CONTENTS
Thank you for purchasing a JVC product. Please read all instructions carefully before operation,
to ensure your complete understanding and to obtain the best possible performance from the unit.
BEFORE USE
* For safety....
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
* Temperature inside the car....
If you have parked the car for a long time in hot or
cold weather, wait until the temperature in the car
becomes normal before operating the unit.
How to reset your unit ............................... 2
LOCATION OF THE BUTTONS ............ 3
Control panel ............................................. 3
BASIC OPERATIONS ....................... 4
Turning on the power ................................ 4
Setting the clock ........................................ 5
RADIO OPERATIONS ...................... 6
Listening to the radio ................................. 6
Storing stations in memory ....................... 7
Tuning in to a preset station ...................... 8
TAPE OPERATIONS ........................ 9
Listening to a cassette .............................. 9
How to reset your unit
While holding SEL (select), press (standby/on/attenuator) for more than 2 seconds.
This will reset the built-in microcomputer.
Note:
Your preset adjustments—such as preset channels or sound adjustments—will also be erased.
SOUND ADJUSTMENTS ................... 10
Adjusting the sound .................................. 10
Turning on/off the super bass function ...... 10
Selecting preset sound modes .................. 11
Storing your own sound adjustments ........ 11
DETACHING THE CONTROL PANEL ...... 12
TROUBLESHOOTING ...................... 13
MAINTENANCE ............................. 14
SPECIFICATIONS ........................... 15
(standby/on/attenuator)
SEL (select)
SSM
SCMMO
S.BASS
SEL
AM
EX
FM
DISP
EN02-03KS-F345[EE]f.p65 11/14/02, 3:44 PM2

3
ENGLISH
LOCATION OF THE BUTTONS
Control panel
1(standby/on/attenuator) button
2S.BASS (super bass) button
30(eject) button
4Display window
5Cassette compartment
61/¡(PROG:program) buttons
7AM button
8EX (extra) button
9FM button
p/buttons
• Also functions as SSM buttons when pressed
together.
q+/– buttons
wDISP (display) button
eSEL (select) button
rNumber buttons
tMO (monaural) button
ySCM (sound control memory) button
u(control panel release) button
Display window
iFM band indicators
(FM1, FM2, FM3)
oAM band indicator
;S.BASS (super bass) indicator
aMain display
sSound mode indicators
(BEAT, SOFT, POP)
dTuner reception indicators
MO (monaural), ST (stereo)
SSM
SCMMO
S.BASS
SEL
AM
EX
FM
DISP
p
wq y
4 6 7 9
e r t u
8
125
i;a
os
d
3
Display window
EN02-03KS-F345[EE]f.p65 11/14/02, 3:44 PM3

4
ENGLISH
BASIC OPERATIONS
Turning on the power
1 Turn on the power.
Notes on One-Touch Operation:
• When you select a source in step 2 below, the
power automatically comes on. You do not
have to press this button to turn on the power.
• If the cassette is already in the cassette
compartment, tape play starts automatically.
However, it is not recommended to leave the
cassette in the compartment when turning off
the power. It may damage the tape head and
the cassette.
2 Select the source.
To operate the tuner (FM or AM),
see pages 6 – 8.
To operate the EX button,
see page 8.
To play a tape,
see page 9.
3 Adjust the volume.
4 Adjust the sound as you want.
(See pages 10 and 11.)
To drop the volume in a moment
Press briefly while listening to any
source. “AT T ”starts flashing on the display, and
the volume level will drop in a moment.
To resume the previous volume level, press the
button briefly again.
To turn off the power
Press and hold for more than one
second.
“SEE YOU”appears, then the unit turns off.
Volume level appears.
To increase the volume
To decrease the volume
AM
EX
FM
SSM
SCMMO
S.BASS
SEL
AM
EX
FM
DISP
13 2
EN04-05KS-F345[EE]f.p65 11/14/02, 3:44 PM4

5
ENGLISH
Setting the clock
1 Press and hold SEL (select) for more
than 2 seconds.
“CLOCK H”or “CLOCK M”appears on the
display.
2 Set the hour.
1Select “CLOCK H”(hour) if not shown on
the display.
2Adjust the hour.
3 Set the minute.
1Select “CLOCK M”(minute).
2Adjust the minute.
4 Finish the setting.
To check the current clock time or change the
display mode
Press DISP (display) repeatedly.
Each time you press the button,
the display mode changes as
follows:
• During tuner operation:
•During tape operation:
DISP
ClockFrequency
Clock
Play mode (tape direction)
CLOCK MCLOCK H
CLOCK MCLOCK H
SEL
SEL
SSM
SCMMO
S.BASS
AM
EX
FM
DISP
SEL
EN04-05KS-F345[EE]f.p65 11/14/02, 3:44 PM5

6
ENGLISH
RADIO OPERATIONS
Listening to the radio
You can use either automatic searching or
manual searching to tune in to a particular
station.
Note:
When a cassette is in the cassette compartment, you
cannot select the tuner. Be sure to eject the cassette
from the cassette compartment to listen to the radio.
Searching a station automatically:
Auto search
1 Select the band (FM1 – 3, AM).
Note:
This receiver has three FM bands (FM1, FM2,
FM3).
• FM1/FM2: 87.5 MHz to 108.0 MHz
• FM3: 65.0 MHz to 74.0 MHz
2 Start searching a station.
When a station is received, searching stops.
To stop searching before a station is
received, press the same button you have
pressed for searching.
Searching a station manually:
Manual search
1 Select the band (FM1 – 3, AM).
Note:
This receiver has three FM bands (FM1, FM2,
FM3).
• FM1/FM2: 87.5 MHz to 108.0 MHz
• FM3: 65.0 MHz to 74.0 MHz
To search stations of higher
frequencies
To search stations of lower
frequencies
Selected band appears.
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
AM
FM
AM
FM1 FM2 FM3
AM
FM
AM
FM1 FM2 FM3
SSM
SCMMO
S.BASS
SEL
AM
EX
FM
DISP
EN06-08KS-F345[EE]f.p65 11/14/02, 3:45 PM6

7
ENGLISH
2 Press and hold or until “M”
(manual) starts flashing on the
display.
3 Tune in to a station you want while
“M”(manual) is flashing.
• If you release your finger from the button,
the manual mode will automatically turns
off after 5 seconds.
• If you hold down the button, the frequency
keeps changing in 50 kHz intervals
(87.5 MHz – 108.0 MHz), or in 30 KHz
intervals (65.0 MHz – 74.0 MHz) for FM,
and 9 kHz intervals for AM—MW/LW until
you release the button.
When an FM stereo broadcast is hard to
receive:
Press MO (monaural), while
listening to an FM stereo
broadcast.
Each time you press the button,
the MO indicator lights up and
goes off alternately.
When the MO indicator is lit on the display, the
sound you hear becomes monaural but the
reception will be improved.
To tune in to stations of lower
frequencies
To tune in to stations of higher
frequencies
MO
Storing stations in memory
You can use one of the following two methods to
store broadcasting stations in memory.
• Automatic preset of FM stations: SSM (Strong-
station Sequential Memory)
• Manual preset of both FM and AM stations
FM station automatic preset: SSM
You can preset 6 local FM stations in each FM
band (FM1, FM2, and FM3).
1 Select the FM band (FM1 –3) you
want to store FM stations into.
2 Press and hold both buttons for
more than 2 seconds.
Local FM stations with the strongest signals are
searched and stored automatically in the band
number you have selected (FM1, FM2, or FM3).
These stations are preset in the number
buttons—No.1 (lowest frequency) to No.6
(highest frequency).
When automatic preset is over, the station stored
in number button 1 will be automatically tuned in.
“- -SSM- -” appears, then disappears when
automatic preset is over.
SSM
FM
FM1 FM2 FM3
EN06-08KS-F345[EE]f.p65 11/14/02, 3:45 PM7

8
ENGLISH
Manual preset
You can preset up to 6 stations in each band
(FM1, FM2, FM3, and AM) manually into the
number buttons (1 – 6).
• You can also preset an FM or AM station (such
as your favorite station or traffic announcement
station) into the EX (extra) button, and recall it
by one-touch operation even if the unit is
turned off.
Ex.: Storing FM station of 88.3 MHz into the
preset number 1 of the FM1 band.
1 Select the band (FM1 –3, AM) you
want to store stations into (in this
example, FM1).
2 Tune in to a station (in this example,
of 88.3 MHz).
3 Press and hold the number button
(in this example, 1) for more than
2 seconds.
You can also preset an FM
or AM station into the
EX button by pressing and
holding the EX button in this
step.
• “P0” flashes on the display,
showing that the station
has been preset.
4 Repeat the above procedure to store
other stations.
Notes:
• A previously preset station is erased when a new
station is stored in the same preset number.
• Preset stations are erased when the power supply to
the memory circuit is interrupted (for example,
during battery replacement). If this occurs, preset
the stations again.
Tuning in to a preset station
You can easily tune in to a preset station.
Remember that you must store stations first. If
you have not stored them yet, see “Storing
stations in memory” on pages 7 and 8.
To tune in the stations stored in the
number buttons
1 Select the band (FM1 –3, AM).
2 Select the number (1 –6) for the
preset station you want.
To tune in the favorite station stored in
the EX button
The unit automatically turns on
(if it has been off).
Your favorite station is tuned
in—except when the tape is
playing.
• If you press the button again, the
last received station will be
tuned in.
AM
FM
AM
FM1 FM2 FM3
“P1” flashes for a few seconds.
To tune in to stations of lower
frequencies
To tune in to stations of higher
frequencies
AM
FM
AM
FM1 FM2 FM3
EX
EX
EN06-08KS-F345[EE]f.p65 11/14/02, 3:45 PM8

9
ENGLISH
TAPE OPERATIONS
Listening to a cassette
You can play back type I(normal) tapes.
1 Turn on the power.
Note on One-Touch Operation:
If a cassette is already in the cassette
compartment, tape play starts automatically.
However, it is not recommended to leave the
cassette in the compartment when turning off the
power. It may damage the tape head and the
cassette.
2 Insert a cassette into the cassette
compartment.
When one side of the tape
reaches its end during play,
the other side of the tape
automatically starts playing.
(Auto Reverse)
3 Select the tape direction.
Press both buttons at the
same time. Each time you
press both buttons, the tape
direction changes
alternately—forward
() and reverse
().
To stop play and eject the cassette
Press 0.
Tape play stops, the cassette automatically
ejects from the cassette compartment. The
source changes to the previously selected one.
• You cannot change the source if the cassette is
still in the cassette compartment.
To change the source, you must eject the
cassette first.
• You can also eject the cassette by pressing 0
while the unit is turned off.
To fast wind a tape
Press in ¡or 1.
The tape will be wound in the direction of the
arrows (¡or 1).
To restart playback, lightly press the other
button which is not pressed in (1or ¡).
Tape direction
SSM
SCMMO
S.BASS
SEL
AM
EX
FM
DISP
EN09-09KS-F345[EE]f.p65 11/14/02, 3:45 PM9

10
ENGLISH
SOUND ADJUSTMENTS
Adjusting the sound
You can adjust the sound characteristics to your
preference.
1 Select the item you want to adjust.
Each time you press the
button, the adjustable items
change as follows:
Indication To do: Range
BAS Adjust the bass. –6 (min.)
|
+6 (max.)
TRE Adjust the treble. –6 (min.)
|
+6 (max.)
FAD* Adjust the front R6 (Rear only)
and rear speaker |
balance. F6 (Front only)
BAL Adjust the left L6 (Left only)
and right speaker |
balance. R6 (Right only)
VOL Adjust the volume. 00 (min.)
|
50 (max.)
*If you are using a two-speaker system, set the fader
level to “00.”
2 Adjust the level.
Note:
Normally, the + and – buttons work as the volume
control buttons. So you do not have to select “VOL”
to adjust the volume level.
Turning on/off the super bass
function
The super bass function allows you to maintain
the richness and fullness of the bass sound
regardless of how low you set the volume.
Each time you press S.BASS,
the function turns on and off
alternately.
To decrease the level
To increase the level
VOL
(volume)
BAS
(bass)
TRE
(treble)
FAD
(fader)
BAL
(balance)
S.BASS
Ex.: When you select “TRE” (treble)
SEL
EN10-11KS-F345[EE]f.p65 11/14/02, 3:45 PM10

11
ENGLISH
Selecting preset sound modes
You can select a preset sound adjustment
suitable to the music genre.
Select the sound mode you want.
Each time you press the button,
the sound mode changes as
follows:
Indication For: Preset values
BAS TRE S.BASS
SCM OFF (Flat sound) 00 00 OFF
BEAT Rock or +2 00 ON
disco music
SOFT Quiet +1 –3 OFF
background
music
POP Light music +4 +1 OFF
Notes:
• You can adjust each sound mode to your preference,
and store it in memory.
If you want to adjust and store your original sound
mode, see “Storing your own sound adjustments”
below.
• To adjust the bass and treble reinforcement levels or
to turn on/off the super bass function, see page 10.
Storing your own sound
adjustments
You can adjust the sound modes (BEAT, SOFT,
POP) to your preference and store your own
adjustments in memory.
• There is a time limit in doing the following
procedure. If the setting is canceled before you
finish, start from step 1 again.
SCM
SCM OFF (SOFT) (POP)
(BEAT)
Ex.: When you select “BEAT”
1 Call up the sound mode you want to
adjust.
• See on the left column for
details.
2 To adjust the bass or treble level.
1Select “BAS” (bass) or “TRE” (treble).
2Adjust the level.
To turn on or off the super bass function.
• See page 10 for details.
3 Repeat step 2 to adjust the other
items.
4 Press and hold SCM until the sound
mode you have selected in step 1
flashes on the display.
Your adjustment made for the
selected sound mode is stored
in memory.
5 Repeat the same procedure to store
other sound modes.
To reset to the factory settings, repeat the
same procedure and reassign the preset values
listed in the table on the left column.
SCM
S.BASS
SCM
SEL
EN10-11KS-F345[EE]f.p65 11/14/02, 3:45 PM11

12
ENGLISH
You can detach the control panel when leaving
the car.
When detaching or attaching the control panel,
be careful not to damage the connectors on the
back of the control panel and on the panel
holder.
Detaching the control panel
Before detaching the control panel, be sure to
turn off the power.
1 Unlock the control panel.
2 Lift and pull the control panel out of
the unit.
3 Put the detached control panel into
the provided case.
Attaching the control panel
1 Insert the left side of the control
panel into the groove on the panel
holder.
2 Press the right side of the control
panel to fix it to the panel holder.
Note on cleaning the connectors:
If you frequently detach the control panel, the
connectors will deteriorate.
To minimize this possibility, periodically wipe the
connectors with a cotton swab or cloth moistened
with alcohol, being careful not to damage the
connectors.
Connectors
DETACHING THE CONTROL PANEL
EN12-12KS-F345[EE]f.p65 11/14/02, 3:46 PM12

13
ENGLISH
TROUBLESHOOTING
What appears to be trouble is not always serious. Check the following points before calling a service
center.
Remedies
Check the cords and
connections.
Adjust it to the optimum level.
Check the cords and
connections.
While holding SEL (select),
press (standby/on/
attenuator) for more than
2 seconds. (The clock setting
and preset stations stored in
memory are erased.)
(See page 2.)
Store stations manually.
Connect the antenna firmly.
Insert the cassette with the
exposed tape facing right.
Clean it with a head cleaning
tape.
Causes
Connections are incorrect.
The volume level is set to the
minimum level.
Connections are incorrect.
The built-in microcomputer
may function incorrectly due
to noise, etc.
Signals are too weak.
The antenna is not connected
firmly.
You have tried to insert a
cassette in the wrong way.
This is not a malfunction.
The tape head is dirty.
Symptoms
• Sound is sometimes
interrupted.
• Sound cannot be heard
from the speakers.
• The unit does not work at
all.
• SSM (Strong-station
Sequential Memory)
automatic preset does not
work.
• Static noise while listening
to the radio.
• A cassette tape cannot be
inserted.
• Cassette tapes become
hot.
• Tape sound is at very low
level and sound quality is
degraded.
General
FM/AM
Tape Playback
EN13-15KS-F345[EE]f.p65 11/14/02, 3:46 PM13

14
ENGLISH
MAINTENANCE
This unit requires very little attention, but you will
be able to extend the life of the unit if you follow
the instructions below.
To clean the head
• Clean the heads after every 10 hours of use
using a wet-type head cleaning tape (available
at an audio store).
When the head becomes dirty, you may realize
the following symptoms:
– Sound quality is reduced.
– Sound level decreases.
– Sound drops out.
• Do not play dirty or dusty tapes.
• Do not touch the highly-polished head with any
metallic or magnetic tools.
To keep the tape clean
• Always store the cassettes in their storage cases
after use.
• Do not store cassettes in the following places:
– Subject to direct sunlight
– With high humidity
– At extremely hot temperatures
CAUTION:
• Do not play the cassettes with peeling labels;
otherwise, they can damage the unit.
• Tighten tapes to remove slack since loose tape
may become entangled with the mechanism.
• Do not leave a cassette in the cassette
compartment after use, as the tape may become
slack.
EN13-15KS-F345[EE]f.p65 11/14/02, 3:46 PM14

15
ENGLISH
AUDIO AMPLIFIER SECTION
Maximum Power Output:
Front: 45 W per channel
Rear: 45 W per channel
Continuous Power Output (RMS):
Front: 17 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than
0.8% total harmonic distortion.
Rear: 17 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than
0.8% total harmonic distortion.
Load Impedance: 4 Ω(4 Ωto 8 Ωallowance)
Tone Control Range:
Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-Out Level/Impedance:
1.0 V/20 kΩload (250 nWb/m)
TUNER SECTION
Frequency Range:
FM1/FM2: 87.5 MHz to 108.0 MHz
FM3: 65.0 MHz to 74.0 MHz
AM: (MW) 522 kHz to 1 620 kHz
(LW) 144 kHz to 279 kHz
[FM Tuner]
Usable Sensitivity:
11.3 dBf (1.0 µV/75 Ω)
50 dB Quieting Sensitivity:
16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity (400 kHz):
65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB
Capture Ratio: 2.0 dB
[MW Tuner]
Sensitivity: 20 µV
Selectivity: 35 dB
[LW Tuner]
Sensitivity: 50 µV
CASSETTE DECK SECTION
Wow & Flutter: 0.15% (WRMS)
Fast-Wind Time: 190 sec. (C-60)
Frequency Response: 50 Hz to 14 000 Hz
(Normal tape)
Signal-to-Noise Ratio: 52 dB
Stereo Separation: 40 dB
GENERAL
Power Requirement:
Operating Voltage: DC 14.4 V
(11 V to 16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature: 0°C to +40°C
Dimensions (W ×H ×D):
Installation Size (approx.):
182 mm ×52 mm ×150 mm
Panel Size (approx.):
188 mm ×58 mm ×11 mm
Mass (approx.):
1.3 kg(excluding accessories)
Design and specifications are subject to change
without notice.
SPECIFICATIONS
EN13-15KS-F345[EE]f.p65 11/14/02, 3:46 PM15

EN, RU 1202KKSMDTJEIN
Having TROUBLE with operation?
Please reset your unit
Refer to page of How to reset your unit
Затруднения при эксплуатации?
Пожалуйста, перезагрузите Ваше
устройство
Для получения инфор ации о перезагрузке Вашего
устройства обратитесь на соответствующую страницу
J
V
C
© 2002 VICTOR COMPANY OF JAPAN, LIMITED
Cover001AKS-F345[EE]f.p65 11/14/02, 3:44 PM2

1
53 mm
184 mm
KS-F345
Installation/Connection Manual
Руководство по установке/подключению
ENGLISH
• This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems.
INSTALLATION (IN-DASH MOUNTING)
• The following illustration shows a typical installation. However, you should make adjustments corresponding
to your specific car. If you have any questions or require information regarding installation kits, consult your
JVC IN-CAR ENTERTAINMENT dealer or a company supplying kits.
1202KKSMDTJEIN
EN, RU
1 Before mounting: Press (control panel release button) to detach the control panel if already
attached.
* When shipped from the factory, the control panel is packed in the hard case.
2 Remove the trim plate.
3 Remove the sleeve after disengaging the sleeve locks.
1Stand the unit.
Note: When you stand the unit, be careful not to damage the fuse on the rear.
2Insert the 2 handles between the unit and the sleeve, as illustrated, to disengage the sleeve locks.
3Remove the sleeve.
Note: Be sure to keep the handles for future use after installing the unit.
4 Install the sleeve into the dashboard.
* After the sleeve is correctly installed into the dashboard, bend the appropriate tabs to hold the sleeve
firmly in place, as illustrated.
5 Fix the mounting bolt to the rear of the unit’s body and place the rubber cushion over the end of the bolt.
6 Do the required electrical connections.
7 Slide the unit into the sleeve until it is locked.
8 Attach the trim plate.
9 Attach the control panel.
GET0112-002A
[EE]
J
V
C
1 Перед установкой: Нажмите кнопку (кнопка освобождения панели управления) для
отсоединения панели управления, если она уже прикреплена.
* При отправке с завода панель управления упакована в твердую коробку.
2 Удалите декоративная панель.
3 Удалите муфту после освобождения запоров муфт .
1Установите устройство.
Примечание: Устанавливайте устройство таким образом, чтоб не повредить
предохранитель, расположенн й сзади.
2Вставьте два р чага между устройством и муфтой, как показано на рисунке, для
освобождения запоров муфт .
3Удалите муфту.
Примечание: После установки устройства сохраните р чаги для использования в будущем.
4 Установите муфту в приборную панель.
* После установки муфт в приборную панель согните соответствующие зубц для фиксации
муфт , как показано на рисунке.
5 Затяните Крепежн й болт на задней части корпуса устройства и наденьте резинов й чехол на
конец болта.
6 В полните необходим е подключения контактов, как показано на оборотной стороне этой
инструкции.
7 Задвиньте устройство в муфту до упора.
8 Установите накладку.
9 Прикрепите панель управления.
РУССКИЙ
• Это устройство разработано для эксплуатации на 12 В постоянного напряжения с минусом на массе.
УСТАН ВКА (УСТАН ВКА В ПРИБ РНУЮ ПАНЕЛЬ)
• На следующих иллюстрациях показана типовая установка. Тем не менее, В должн сделать
поправки в соответствии с типом Вашего автомобиля. Если у Вас есть какие-либо вопрос ,
касающиеся установки, обратитесь к Вашему дилеру JVC IN-CAR ENTERTAINMENT или в компанию,
поставляющую соответствующие принадлежности.
3
12
Handle
Р чаг
Fuse
Предохранитель
Slot
Отверстие
Lock Plate
Фиксирующая панель
Sleeve
Муфта
9
8
Trim plate
Декоративная панель
See “ELECTRICAL CONNECTIONS.”
Смотрите “ЭЛЕКТРИЧЕСКИЕ
ПОДКЛЮЧЕНИЯ”.
6
7
Sleeve
Муфта
Mounting bolt
Крепежн й болт
5
4
Control panel
Панель управления
Dashboard
Приборная панель
Trim plate
Декоративная панель
Rubber cushion
Резинов й чехол
Control panel
Панель управления
*
4
InstalKS-F345[EE]002Af.p65 11/15/02, 12:55 PM1

2
• When installing the unit without using the sleeve
•При установке устройства без использования муфты
In a Toyota for example, first remove the car radio and install the unit in its place.
В автомобилях “Toyota”, например, сначала удалите автомобильную магнитолу, затем установите на ее место
это устройство.
Removing the unit
• Before removing the unit, release the rear section.
1 Remove the control panel.
2 Remove the trim plate.
3 Insert the 2 handles into the slots, as shown. Then, while gently pulling the handles away from each
other, slide out the unit. (Be sure to keep the handles after installing it.)
Note : When installing the unit on the mounting bracket, make sure to use the 6 mm-long screws. If longer
screws are used, they could damage the unit.
Примечание : При установке устройства на крепежн й кронштейн, используйте только винт длиной 6 мм.
При использовании более длинн х винтов можно повредить устройство.
• When using the optional stay
•При использовании дополнительной стойки
Handles
Р чаги
Washer (ø5)
Шайба (њ5)
Lock nut (M5)
Фиксирующая гайка (M5)
Mounting bolt (M5 x 20 mm)
Крепежн й болт (M5 x 20 мм)
Rubber cushion
Резинов й чехол
Parts list for installation and connection
The following parts are provided with this unit.
After checking them, please set them correctly.
Hard case/Control panel
Жесткий футляр/панель управления
Sleeve
Муфта
Trim plate
Декоративная панель
Power cord
Кабель питания
321
Control panel
Панель управления
Trim plate
Декоративная панель Handle
Р чаг
Bracket*
Кронштейн*
Bracket*
Кронштейн*
* Not included with this unit.
* Не входят в комплект.
Flat type screws (M5 x 6 mm)*
Крепежн е винт (M5 x 6 мм)*
Pocket
Карман
Flat type screws (M5 x 6 mm)*
Крепежн е винт (M5 x 6 мм)*
Sleeve
Муфта
Screw (option)
Винт (дополнительно)
Lock nut
Фиксирующая
гайка
Stay (option)
Стойка
(дополнительно)
Mounting bolt
Крепежн й болт
Fire wall
Стена
Washer
Шайба
Dashboard
Приборная панель
Удаление устройства
• Перед удалением устройства освободите заднюю часть.
1 Удалите панель управления.
2 Удалите декоративную панель.
3 Вставьте 2 р чаги в отверстия, как показано на иллюстрации. Затем, плавно раздвигая р чаги в
сторон , в ньте устройство. (После установки сохраните рычаги.)
Список деталей для установки и подключения
Следующие детали поставлен в комплекте с устройством.
После проверки комплектации, пожалуйста, установите их правильно.
InstalKS-F345[EE]002Af.p65 11/15/02, 12:55 PM2

3
5
1
2
3
4
2
P
L
O
M
4
*
*
3
15
FED C HGB A
View from the lead side
Вид со сторон контактов
From the car body
На корпусе автомобиля Original wiring
Исходное соединение
If your car is equipped with the ISO connector
Если Ваш автомобиль оборудован разъемами ISO
•Connect the ISO connectors as illustrated.
• Подключите разъем ISO, как показано на иллюстрации.
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious damage
to this unit.
The leads of the power cord and those of the connector from the car body may be different in color.
1 Cut the ISO connector.
2 Connect the colored leads of the power cord to the car battery, speakers and power aerial (if any) in the
following sequence.
1Black: ground
2Yellow: to car battery (constant 12 V)
3Red: to an accessory terminal
4Blue with white stripe: to remote lead of other equipment or power aerial if any (200 mA max.)
5Others: to speakers
3 Connect the aerial cord.
4 Finally connect the wiring harness to the unit.
Connections without using the ISO connectors / Подключение без использования разъемов ISO
Line out (see
diagram )
Линейн й в ход
(см. схему )
Fuse block
Блок
предохранителя
To metallic body or chassis of the car
К металлическому корпусу или шасси автомобиля
To remote lead of other equipment or power aerial if any
К удаленному проводу другого оборудования или антенн
Red
Красн й
Yellow*1
Желт й*1
Modified wiring 2
Модифицированное
соединение 2
Modified wiring 1
Модифицированное
соединение 1
Aerial terminal
Разъем антенн
To aerial
К антенне
Rear ground terminal
Задний разъем заземления
Black
Черн й
Blue with white stripe
Синий с белой полосой
*1 : Before checking the operation of this unit prior to
installation, this lead must be connected, otherwise
power cannot be turned on.
*1 : Перед проверкой работ устройства подключите
этот провод, иначе питание не включится.
White
Бел й
Gray with black stripe
Сер й с черной
полосой
Green
Зелен й
Purple
Пурпурн й
White with black stripe
Бел й с черной
полосой
Green with black stripe
Зелен й с черной
полосой
Purple with black stripe
Пурпурн й с черной
полосой
Left speaker (front)
Лев й громкоговоритель
(передний)
Right speaker (front)
Прав й громкоговоритель
(передний)
Left speaker (rear)
Лев й громкоговоритель
(задний)
Right speaker (rear)
Прав й громкоговоритель
(задний)
Gray
Сер й
15 A fuse
Предохранитель 15A
ISO connector of the supplied power cord
Разъем ISO, полученн й в комплекте
кабеля питания
For some VW/Audi or Opel (Vauxhall) automobile
Для некоторых автомобилей VW/Audi или Opel (Vauxhall)
You may need to modify the wiring of the supplied power cord as illustrated.
•Contact your authorized car dealer before installing this unit.
Вам может потребоваться изменение соединений полученного в комплекте кабеля питания, как показано на иллюстрации.
• Перед установкой устройства обратитесь к Вашему официальному дилеру автомобиля.
Use modified wiring 2if the unit does not
turn on.
Если устройство не включается,
модифи-цируйте кабель по схеме 2.Red/Красн й
Red/Красн й
Red/Красн й Red/Красн й
Yellow/Желт й
Yellow/Желт й
Red/Красн й
Red/Красн й
Yellow/Желт й
Red/Красн й
ISO connector
Разъем ISO
Yellow/Желт й Yellow/Желт й
Red/
Красн й Red/Красн й
Yellow/Желт й
ENGLISH РУССКИЙ
Перед началом подключений: Тщательно проверьте проводку в автомобиле. Неправильное
подключение может привести к серьезному повреждению устройства.
Жил силового кабеля и жил соединителя от кузова автомобиля могут б ть разного цвета.
1 Отрежьте разъем ISO.
2 Подключите цветн е провода кабеля питания к аккумулятору, громкоговорителям и автономной
антенне (если есть) в следующем порядке:
1Черн й: земля
2Желт й: к аккумулятору (постоянн й 12 В)
3Красн й: к вспомогательному разъему
4Синий с белой полосой: к удаленному проводу другого оборудования или антенн (макс. 200 мА).
5Другие: к громкоговорителям
3 Подключите кабель антенн .
4 В последнюю очередь подключите электропроводку к устройству.
To an accessory terminal in the fuse block
К вспомогательному разъему в блоке предохранителя
Ignition switch
Переключатель зажигания
1
ELECTRICAL CONNECTIONS
To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all
electrical connections before installing the unit. If you are not sure how to install this unit correctly, have it
installed by a qualified technician.
Note:
This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems. If your vehicle does not have
this system, a voltage inverter is required, which can be purchased at JVC IN-CAR ENTERTAINMENT dealers.
•Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC IN-CAR
ENTERTAINMENT dealer.
•If noise is a problem...
This unit incorporates a noise filter in the power circuit. However, with some vehicles, clicking or other
unwanted noise may occur. If this happens, connect the unit’s rear ground terminal (see connection diagram)
to the car’s chassis using shorter and thicker cords, such as copper braiding or gauge wire. If noise still
persists, consult your JVC IN-CAR ENTERTAINMENT dealer.
•Maximum input of the speakers should be more than 45 W at the rear and 45 W at the front, with an
impedance of 4 Ωto 8 Ω.
•Be sure to ground this unit to the car’s chassis.
•The heat sink becomes very hot after use. Be careful not to touch it when removing this unit.
ЭЛЕКТРИЧЕСКИЕ П ДКЛЮЧЕНИЯ
Для предотвращения коротких зам каний м рекомендуем Вам отсоединить отрицательн й разъем
аккумулятора и осуществить все подключения перед установкой устройства. Если В не знаете точно,
как следует устанавливать это устройство, обратитесь к квалифицированному специалисту.
Примечание:
Это устройство разработано для эксплуатации на 12 В постоянного напряжения с минусом на массе.
Если Ваш автомобиль не имеет этой систем , требуется инвертор напряжения, котор й может б ть
приобретен у дилера JVC IN-CAR ENTERTAINMENT.
• Заменяйте предохранитель другим предохранителем указанного класса. Если предохранитель
сгорает слишком часто, обратитесь к дилеру JVC IN-CAR ENTERTAINMENT.
• При появлении сильн х помех...
Это устройство оснащено фильтром помех в цепи питания. Однако в некотор х случаях возможно
появление щелчков и других нежелательн х помех. В этом случае подключите задний разъем
заземления этого устройства (см. схему подключения ниже) к шасси автомобиля при помощи более
коротких и толст х проводов. Если помехи не исчезают, обратитесь к дилеру JVC IN-CAR
ENTERTAINMENT.
• Максимальная входная мощность громкоговорителей должна б ть больше 45 Вт сзади и 45 Вт
впереди при полном сопротивлении от 4 Ω до 8 Ω.
•Нe забудьте заземлить устройство на шасси автомобиля.
• Радиатор во время использования сильно нагревается. Старайтесь его не трогать во время удаления
устройства.
Cut the ISO connector
Отрежьте разъем ISO
Heat sink
Радиатор
Not included with this unit.
Не входит в комплект.
*
To a live terminal in the fuse block connecting to the car battery
(bypassing the ignition swich)
К разъему фаз в блоке предохранителя (минуя блок
зажигания)
N
J
I
K
M
L
PO
EF
B
D
H
G
A
C
InstalKS-F345[EE]002Af.p65 11/15/02, 12:55 PM3

4
L
R
L
R
R
L
R
L
LINE OUT
REAR
*2
INPUT
R
L
EF
B
D
H
G
A
C
*
*
*
*
TROUBLESHOOTING
•The fuse blows.
* Are the red and black leads connected correctly?
•Power cannot be turned on.
* Is the yellow lead connected?
•No sound from the speakers.
* Is the speaker output lead short-circuited?
•Sound is distorted.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
•Unit becomes hot.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
You can connect an amplifier to upgrade your car stereo system.
•Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it can be
controlled through this unit.
•Connect this unit’s line-out terminals to the amplifier’s line-in terminals.
•Disconnect the speakers from this unit, connect them to the amplifier. Leave the speaker leads of
this unit unused. (Cover the terminals of these unused leads with insulating tape, as illustrated
above.)
Connections Adding Other Equipment / Подключение других устройств
Amplifier / Усилитель
Twist the core wires when connecting.
Закрутите конц проводов при соединении.
CAUTION / ПРЕД СТЕРЕЖЕНИЕ:
•To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.
•Для предотвращения короткого зам кания заклейте НЕИСПОЛЬЗУЕМЫЕ конц
изолирующей лентой.
Connecting the leads / Подключение контактов
PRECAUTIONS on power supply and speaker connections:
•DO NOT connect the speaker leads of the power cord to the car battery; otherwise, the unit will be
seriously damaged.
•Connect the black lead (ground), yellow lead (to car battery, constant 12 V), and red lead (to an accessory
terminal) correctly.
•BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in your
car.
–If the speaker wiring in your car is as illustrated in Fig. 1 and Fig. 2 below, DO NOT connect the unit
using that original speaker wiring. If you do, the unit will be seriously damaged.
Redo the speaker wiring so that you can connect the unit to the speakers as illustrated in Fig. 3.
–If the speaker wiring in your car is as illustrated in Fig. 3, you can connect the unit using the original
speaker wiring in your car.
–If you are not sure of the speaker wiring of your car, consult your car dealer.
Signal cord (not supplied with this unit)
Кабель сигнала (не входит в комплект)
Rear speakers
Задние громкоговорители
JVC Amplifier
JVC-усилитель
KS-F345
* Cut the rear speaker leads of the
car’s ISO connector and connect
them to the amplifier.
* Отрежьте провода задних
громкоговорителей разъема ISO и
подсоедините их к усилителю.
Rear speakers
Задние громкоговорители
Front speakers (see diagram )
Передние громкоговорители (см. схему )
To power aerial if any
К питанию антенн , если есть
Y-connector (not supplied with this unit)
Разъем Y (не входит в комплект)
Blue with white stripe
Синий с белой полосой
Remote lead
Провод внешнего устройства
Fig. 2 Fig. 3Fig. 1
*2 : Firmly attach the ground wire to the metallic body or to the chasis of
the car—to the place not coated with paint (if coated with paint,
remove the paint before attaching the wire). Failure to do so may
cause damage to the unit.
*2 : Плотно прикрепите заземляющий провод к металлическому
кузову или шасси автомобиля—в месте, не покр том краской
(если оно покр то краской, удалите краску перед тем, как
прикреплять провод). Нев полнение этого требования может
привести к повреждению данного устройства.
Solder the core wires to connect them securely.
Спаяйте провода для надежного соединения.
ПРЕД СТЕРЕЖЕНИЯ по питанию и подключению громкоговорителей:
•НЕ подключайте провода громкоговорителей к аккумулятору автомобиля, иначе
устройство будет повреждено.
• Правильно подключите черн й провод (земля), желт й провод (в аккумулятор, постоянн й ток
12 В) и красн й провод (в вспомогательн й разъем).
• ПЕРЕД подключением проводов громкоговорителей к кабелю питания громкоговорителя
проверьте схему соединений громкоговорителей в Вашем автомобиле.
–Если проводка громкоговорителей в Вашем автомобиле такая, как показано на
приводимых ниже Fig. 1 и Fig. 2, НЕ подключайте устройство с помощью первоначальной
проводки громкоговорителей.
Если В это сделаете, устройство будет серьезно повреждено. Переделайте проводку
громкоговорителей так, чтоб В могли подключить устройство к громкоговорителям, как это
показано на рис. 3.
–Если проводка громкоговорителей в Вашем автомобиле такая, как показано на Fig. 3, В
можете подключить устройство с помощью первоначальной проводки громкоговорителей в
Вашем автомобиле.
– Если В не знаете соединение громкоговорителей в Вашем автомобиле, обратитесь к Вашему
автомобильному дилеру.
Для обновления автомобильной стереосистем В можете подключить усилитель.
• Подсоедините провод внешнего устройства (синий с белой полосой) к проводу внешнего
устройства другого оборудования так, чтоб им можно б ло управлять с этого устройства.
• Подключите в ходн е клемм данного устройства к входн м клеммам усилителя.
•тсоедините громкоговорители от данного устройства, подключите их к усилителю.
ставьте провода громкоговорителей данного устройства неиспользованными. (Замотайте
клеммы этих неиспользованных проводов изоляционной лентой, как показано выше.)
BЫЯВЛЕНИЕ НЕИСПРАВН СТЕЙ
•Сработал предохранитель.
* Правильно ли подключен черн й и красн й провода?
•Питание не включается.
* Подключен ли желт й провод?
•Звук не выводится через громкоговорители.
* Нет ли короткого зам кания на кабеле в хода громкоговорителей?
•Звук искажен.
* Заземлен ли провод в хода громкоговорителей?
* Заземлен ли разъем “–” правого (R) и левого (L) громкоговорителей?
•Устройство нагревается.
* Заземлен ли провод в хода громкоговорителей?
* Заземлен ли разъем “–” правого (R) и левого (L) громкоговорителей?
L
R+
-
+
-
+
-
+
-
L
R+
-
+
-
+
-
+
-
L
R+
-
+
-
+
-
+
-
InstalKS-F345[EE]002Af.p65 11/15/02, 12:55 PM4
