SERVICE MANUAL

2005/12

DVD PLAYER

YD056B200512

XV-N320BEK2,XV-N320BER2,XV-N320BEU2,

XV-N320BEY2,XV-N320BEZ2,XV-N322SEK2,

XV-N322SER2,XV-N322SEU2,XV-N322SEY2,

XV-N322SEZ2

TABLE OF CONTENTS

1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

XV-N320BEK2C,XV-N320BEU2C,XV-N320BEY2C,XV-N320BEZ2C,XV-N320BER2C

XV-N322SEK2C,XV-N322SEU2C,XV-N322SEY2C,XV-N322SEZ2C,XV-N322SER2C

VIDEO

OPEN/

LIST

SET UP

CLEAR

SLOW

DISPLAY ON SCREEN

ENTER

STANDBY/ON

VFP

I/P

CANCEL RETURN

SOUND

EFFECT

TITLE/

GROUP DIMMER

AUDIO

SUBTITLEANGLE

SLIDE EFFECT

ZOOM

123

456

789

THUMBNAIL/

TOP

NEXTPREVIOUS SELECT

Area Suffix

EK ------------------------ U.K.

EU -------- Western Europe

EY -------- Northern Europe

EZ --------- Eastern Europe

ER ---- Russian Federation

This model is a model to which Pick up of "XV-N320B,XV-N322S"that has already

been put on the market and "Circumference circuit of pick up" are changed.

Please see page 1-3 for details.

1-2 (No.YD056B)

SPECIFICATION

• Manufactured under license from DolbyLaboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

• “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use

of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses

only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

• “CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS

PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE

SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE “STANDARD

DEFINITION” OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS MODEL 525p

AND 625p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.”

XV-N320BEK2,XV-N320BER2,XV-N320BEU2,XV-N320BEY2,XV-N320BEZ2,XV-N322SEK2,XV-N322SER2,XV-N322SEU2,XV-N322SEY2,XV-N322SEZ2

General

Readable discs DVD VIDEO, DVD-R (Video format), DVD-RW (Video format), SVCD, Video CD, Audio CD (CD-DA),

CD-R/RW (CD-DA, SVCD, Video CD, MP3 format, JPEG)

Video format PAL, 625i/625p selectable

Other

Power requirements AC 230 V~, 50 Hz

Power consumption 11.0 W (POWER ON), 1.0 W (STANDBY mode)

Mass 1.5 kg

Dimensions (W ×H ×D) 435mm ×44mm ×201.5 mm

Video outputs

VIDEO OUT (pin jack) 1.0 Vp-p (75 Ω)

RGB Output 700mVp-p (75 Ω)

COMPONENT (pin jacks) Y Output: 1.0 Vp-p (75 Ω)

Pb/Pr Output: 0.7Vp-p (75 Ω)

Horizontal resolution 500 lines or more

Audio outputs

ANALOG OUT (pin jack) 2.0 Vrms (10 kΩ)

DIGITAL OUT (COAXIAL) 0.5 Vp-p (75 Ωtermination)

Audio characteristics

Frequency response CD (sampling frequency 44.1 kHz):2 Hz to 20 kHz

DVD (sampling frequency 48 kHz):2 Hz to 22 kHz

(4 Hz to 20 kHz for DTS and Dolby Digital bitstream signals)

DVD (sampling frequency 96 kHz):2 Hz to 44 kHz

Wow and flutter Unmeasurable (less than +- 0.002%)

Total harmonic distortion less than 0.009%

(No.YD056B)1-3

This model is a model to which Pick up of "XV-N320B,XV-N322S" that has already been put

on the market and "Circumference circuit of pick up" are changed.

< When the label in figure is pasted in the main body >

The circumference circuit of pick up and pick up is different from the model to whom the label is not

pasted by the same model name, and use this manual, please.

Please already refer to the issued service manual when the label is not pasted.

The already published service manual

* ISSUE No.YD056 2005/3 XV-N320B, XV-N322S for EK,EU,EY,EZ,ER

Outside of rear panelInside of rear panel

Used only service dealer

Please refer to service manual of an applicable model MK2.

GN30080-001A

0786

inside

The position of the label might be somewhat different.

For this service manual
