JVC XV-S60BK User manual

STANDBY
STANDBY/ON
PAUSEPLAYSTOP
SKIP
OPEN/CLOSE
387
0
¢4
PROGRESSIVE
DVD/SUPER VCD/VCD/CD
DVD/SUPER VCD/VCD/CD PLAYER
DVD VIDEO PLAYER
XV-S60BK/XV-S62SL
OPEN
/COSE
TV DVD
REPEAT
123
56
89
0+1010
7
4
3D
PHONIC TV/VIDEO CANCEL
SUBTITLEANGLE
TV1 TV2 TV3
TV4 TV5 TV6
TV7 TV8 TV9
TV
-/-- TV0 MUTING
AUDIO VFP
DIGEST
PREVIOUS
NEXT
CLEAR
STROBE
SLOW
+
SLOW
-
TITLE
MENU
CHOICE
ENTER
CH+
SELECT
CH
-
VOL
+
VOL
-
ON SCREEN
+ZOOM
-
RETURN
4
¢
1
¡
5
5
5
∞
7
8
3
TV DVD
STANDBY/ON
REMOTE CONTROL
PROGRESSIVE
SCAN
Introduction 2
Preliminary knowledge 5
Getting started 14
Basic operations 22
Advanced operations 26
MP3 disc playback 43
Initial settings 46
Additional information 53
For Customer Use:
Enter below the Model No. and Serial No.
which are located on the rear, bottom or
side of the cabinet. Retain this information
for future reference.
Model No.
Serial No
LET0184-014B
[US,UW,UB]
INSTRUCTIONS
VIDEO CD
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Warnings, Cautions and Others
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
Caution –– switch!
Disconnect the mains plug to shut the power off completely.
The switch in any position does not disconnect the mains
line. The power can be remote controlled.
CAUTION:
÷ Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper or
cloth, etc., the heat may not be able to get out.)
÷ Do not place any naked flame sources, such as lighted candles, on
the apparatus.
÷ When discarding batteries, environmental problems must be con-
sidered and local rules or laws governing the disposal of these bat-
teries must be followed strictly.
÷ Do not use this apparatus in a bathroom or places with water.
Also do not place any containers filled with water or liquids (such as
cosmetics or medicines, flower vases, potted plants, cups, etc.) on
top of this apparatus.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION:Invisible laser radiation when open and interlock
failed or defeated. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the Unit; leave all servicing to qualified
service personnel.
REPRODUCTION OF LABELS
1CLASSIFICATION LABEL, PLACED ON REAR ENCLOSURE 2WARNING LABEL, PLACED INSIDE THE UNIT
CLASS 1
LASER PRODUCT
CAUTION: Invisible laser
radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE
TO BEAM. (e)
ADVARSEL: Usynlig laser-
str ling ved bning, n r
sikkerhedsafbrydere er ude
af funktion. Undg uds t-
telse for str ling (d)
VARNING: Osynlig laser-
str lning n r denna del r
ppnad och sp rren r
urkopplad. Betrakta ej
str len. (s)
VARO: Avattaessa ja suo-
jalukitus ohitettaessa olet
alttiina n kym tt m lle
lasers teilylle. l katso
s teeseen. (f)
Floor
Spacing 15 cm or more
Stand heigh
5 cm or mor
Wall or obstructions
Front
Caution: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage.
Locate the apparatus as follows:
Front: No obstructions open spacing.
Sides: No obstructions in 3 cm from the sides.
Top: No obstructions in 5 cm from the top.
Back: No obstructions in 15 cm from the back
Bottom: No obstructions, place on the level surface.
XV-S62SL
XV-S60BK
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

1
English
Table of Contents
Introduction
Page 2
Features...............................................................................2
Supplied accessories..........................................................2
About this instruction manual ..........................................3
Notes on handling..............................................................4
Preliminary knowledge
Page 5
Names of parts and controls.............................................5
Front panel................................................................................5
Remote control unit .................................................................6
Display window........................................................................8
Rear panel.................................................................................8
Operational Principles........................................................9
On-screen displays...................................................................9
To prevent the monitor from burning out
[SCREEN SAVER]................................................................11
On-screen guide icons...........................................................12
How to use numeric buttons.................................................12
About discs .......................................................................13
Playable disc types.................................................................13
Disc structure..........................................................................13
Getting started
Page 14
Connections ......................................................................14
Before making any connections ...........................................14
To connect to a conventional TV ..........................................14
To connect to a TV with the component video
input jacks............................................................................15
To connect to an audio amplifier or receiver.......................16
To connect to audio equipment with a digital input...........17
To connect the power cord ...................................................18
Using the remote control unit.........................................18
To install batteries in the remote control unit .....................18
Remote sensor .......................................................................19
To use the remote control unit for TV operation.................20
Basic operations
Page 22
Turning on/off the unit ....................................................22
Inserting and removing discs..........................................22
Basic playback ..................................................................23
To start playback ....................................................................23
To stop playback completely ................................................23
To stop playback temporarily ...............................................23
To advance or reverse playback rapidly while
monitoring...........................................................................24
To locate the beginning of the scene or song .....................24
Resuming playback ..........................................................25
To memorize the interrupted position .................................25
To resume playback...............................................................25
Advanced operations
Page 26
Playing from a specific position on a disc......................26
To locate a desired scene from the DVD menu...................26
To locate a desired scene from the menu of
the Video CD/SVCD with PBC ............................................26
To locate a desired selection using the numeric
buttons.................................................................................27
To locate a desired selection using 4 or ¢ ...................27
To locate a desired scene by specifying the chapter
number [CHAP.SEARCH] ...................................................28
To locate a desired position in the current title or track
[TIME SEARCH]...................................................................28
To locate a desired scene from the display [DIGEST] ........29
Special picture playback ................................................. 30
To advance a still picture frame-by-frame...........................30
To display continuous still pictures [STROBE]....................30
To playback in slow-motion [SLOW]....................................31
To zoom in/out [ZOOM].........................................................31
Changing the playback order ......................................... 32
To playback in the desired order [PROGRAM] ....................32
To playback in random order [RANDOM]...........................33
Repeat playback............................................................... 33
To repeat the current selection or all tracks [REPEAT] .......33
To repeat a desired part [A-B REPEAT] ...............................35
Selecting a scene angle of DVD VIDEO ......................... 36
To select a scene angle from the normal screen
[ANGLE]...............................................................................36
To select a scene angle from the angle list display
[ANGLE]...............................................................................37
Changing the language and sound................................ 37
To select the subtitle language [SUBTITLE] ........................37
To change the audio language or sound [AUDIO]..............39
Miscellaneous functions ................................................. 40
To adjust the picture character [VFP] ...................................40
To simulate surround sound [3D PHONIC]..........................41
To check the disc time [TIME SELECT] ................................42
Changing the brightness of the display window.................42
MP3 disc playback
Page 43
About MP3 disc................................................................ 43
Operations........................................................................ 43
Basic operations.....................................................................43
Specifying the desired Group and Track .............................44
Repeat playback .....................................................................45
Initial settings
Page 46
Selecting preferences...................................................... 46
How to set preferences..........................................................46
Language and display preference ........................................46
Audio and system preference...............................................48
Limiting playback by children ........................................ 50
To set Parental Lock for the first time
[PARENTAL LOCK]..............................................................50
To change the settings [PARENTAL LOCK] .........................51
To temporarily release the Parental Lock
[PARENTAL LOCK]..............................................................52
Additional information
Page 53
AV COMPU LINK remote control system...................... 53
Connection and setup............................................................53
Operation................................................................................54
Care and handling of discs.............................................. 55
Troubleshooting .............................................................. 56
Specifications................................................................... 57
Table of languages and their abbreviations.. Appendix A
Country code list for parental Lock.................Appendix B
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

2
Introduction
Introduction
Features
This unit is a compatible player for DVD VIDEO, Audio
CD, Video CD and SVCD discs.
7 Progressive Scan system (NTSC only)
Supports the Progressive scan system for NTSC
system, as well as the conventional (current) Interlace
scan system.
* To enjoy the progressive video picture, you must
connect the unit to a television or monitor that
supports the progressive video input.
7 Strobe function
The unit can display nine continuous still pictures on
the TV screen.
7 Digest function
You can select the desired selection to be played from
the opening scenes displayed on the TV screen.
7 Angle function*
You can select a desired angle from multiple camera
angles recorded on the DVD VIDEO disc.
7 Zoom function
You can view scenes close-up.
7 VFP function
You can adjust the picture character according to the
type of programming, picture tone or personal
preferences.
7 Parental lock*
You can restrict the playback of DVD VIDEO discs with
scenes which you do not want children to see, such as
adult or violent films.
7 High quality digital sound
You can enjoy high quality sound with Linear-PCM.
7 Surround function*
The unit accommodates the Dolby Digital, DTS
surround and MPEG multichannel systems.
(These surround signals are output only from the
DIGITAL OUT jacks.)
7 3D PHONIC function
You can enjoy Virtual surround sound with your
2-channel (stereo) system.
7 MP3 disc playback
This unit can playback CD discs recorded by the MP3
format (we refer to those discs as MP3 discs in this
manual).
7 CD-R/CD-RW playback
You can playback a CD-R or CD-RW disc recorded with
the Audio CD or MP3 format.
7 Multi-language subtitles and sound
You can select a subtitle or sound language from
those recorded on the DVD VIDEO/SVCD disc.
7 Operation from the on-screen display
User-friendly on-screen displays allow you to operate
the unit easily.
Functions with (*) mark only work on a DVD VIDEO disc
that is compatible with each function.
Supplied accessories
 Audio/video cable (x 1)
 S-video cable (x 1)
 Remote Control Unit (x 1)
 R6P(SUM-3)/AA(15F) batteries (x 2)
 Instruction manual (x 1)
 AC power cord (x 1)
 AC power plug (x 1)
(except Hong Kong)
Picture functions
Audio functions
Other functions
OPEN
/CLOSE
TV DVD
REPEAT 3D
PHONIC TV/VIDEO
CANCEL
SUBTITLE
ANGLE
TV1 TV2 TV3
TV4 TV5 TV6
TV7 TV9
TV
-/-- TV0
VFP
AUDIO
PROGRESSIVE
SCAN
DIGEST
PREVIOUS
CLEAR
STROBE
SLOW
+
SLOW
-
TITLE
CHOICE
CH
+
SELECT
CH
-
VOL
+
VOL
-
ON SCREEN
+
ZOOM
-
RETURN
TV DVD
STANDBY/ON
TV8
NEXT
MENU
RM-SXVM50J REMOTE CONTROL
123
56
89
0+10
10
7
4
ENTER
4
¢
1
¡
5
5
5
∞
7
8
3
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Introduction
3
Introduction
About this instruction manual
 This instruction manual is written in the following manner.
 This unit can playback CD-R/RW discs recorded by the MP3 format (we refer to those discs as MP3 discs in this
manual).
 Regarding operations for MP3 discs, see MP3 disc playback on and after page 43. The other sections of this manual
basically do not refer to MP3 disc playback.
You can play tracks on an Audio CD, Video CD or SVCD
disc in random order by using the Random function.
÷While stopped
1Press ON SCREEN.
The on-screen display appears on the TV screen.
(for Audio CD) (for Video CD/SVCD)
2Use CURSOR 5/∞ to move
3Press ENTER.
The unit starts random playback.
The “RANDOM” indicator appears in the display
window on the front panel. After playing all tracks
of the discs, random playback ends.
• The same track will not be played back more than once
during random play.
• To quit random playback in the middle
Press 7. The unit stops playback and quits the
random playback mode.
To playback in random order
[RANDOM]
These symbols
indicate the types
of discs which the
operation can be
used for.
The number
indicates the
following procedural
step(s) in which the
button(s) is(are)
used.
You may also use the
corresponding
buttons on the front
panel of the unit if
available.
The names of buttons
on the remote control
unit (or on the front
panel of the unit) are
all given in uppercase
letters.
The number
indicates the
procedural step.
Other convenient
procedures, etc.
The color of [RANDOM] changes.
• During Audio CD playback, pressing ENTER when points
[RANDOM] quits random mode and continues playback in
the normal order.
to [RANDOM].
OPEN
/CLOSE TV DVD
TV DVD
STANDBY/ON
REPEAT
123
56
89
0+1010
7
4
3D
PHONIC TV/VIDEO CANCEL
SUBTITLEANGLE
TV1 TV2 TV3
TV4 TV5 TV6
TV7 TV8 TV9
TV
-/-- TV0 MUTING
AUDIO VFP
PROGRESSIVE
SCAN
DIGEST
PREVIOUS
NEXT
CLEAR
STROBE
SLOW
+
SLOW
-
TITLE
MENU
CHOICE
ENTER
RM-SXVM50J REMOTE CONTROL
CH+
SELECT
CH
-
VOL
+
VOL
-
ON SCREEN
ZOOM +
RETURN
4
¢
1
¡
5
5
5
∞
7
8
3
1
23
TRACK 1 3 : 54TIME
MIN SEC EACH
REMAIN
RANDOM
PROGRAM
TIME SEARCH
A-B REPEAT
REPEAT
TIME SELECT
PRESS ENTER =EXECUTE
1
9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
17 18 19 20 21 22 23 24
TRACK 1 3 : 54TIME
MIN SEC EACH
REMAIN
RANDOM
PROGRAM
TIME SEARCH
A-B REPEAT
REPEAT
TIME SELECT
PRESS ENTER =EXECUTE
1
9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
17 18 19 20 21 22 23 24
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Introduction
4
Introduction
Notes on handling
Important cautions
Installation of the unit
 Select a place which is level, dry and neither too hot
nor too cold (between 5
o
Cand35
o
C).
 Leave sufficient distance between the unit and the TV.
 Do not use the player in a place subject to vibrations.
Power cord
 Do not handle the power cord with wet hands!
 A small amount of power (2.5 W) is always consumed
while the power cord is connected to the wall outlet.
 When unplugging the player from the wall outlet,
always pull the plug, not the power cord.
To prevent malfunction of the unit
 There are no user-serviceable parts inside. If anything
goes wrong, unplug the power cord and consult your
dealer.
 Do not insert any metallic object into the unit.
 Do not use any non-standard shape disc available on
the market, because it may damage the unit.
 Do not use a disc with tape, seals, or paste on it,
because damage to the unit may result.
Note about copyright laws
 Please check the copyright laws in your country before
recording from DVD VIDEO, Audio CD, Video CD, SVCD
and MP3 discs. Recording of copyrighted material may
infringe copyright laws.
Note about the copyguard system
 The DVD VIDEO disc is protected by the copyguard
system. When you connect the unit to your VCR
directly, the copyguard system activates and the
picture may not be played back correctly.
Safety precautions
Avoid moisture, water and dust
Do not place the unit in moist or dusty places.
Avoid high temperatures
Do not expose the unit to direct sunlight or place it near
a heating device.
When you are away
When away on travel or otherwise for an extended
period of time, remove the plug from the wall outlet.
Do not insert foreign objects into the unit
Do not insert wires, hairpins, coins, etc. into the unit.
Do not block the vents
Blocking the vents may damage the unit.
Care of the cabinet
When cleaning the unit, use a soft cloth and follow the
relevant instructions on the use of chemically-coated
cloths. Do not use benzene, thinner or other organic
solvents and disinfectants. These may cause
deformation or discoloring.
If water gets inside the unit
Turn off the power switch and remove the plug from the
wall outlet, then call the store where you made your
purchase. Using the unit in this state may cause a fire or
electrical shock.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this
copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and
other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
Confidential Unpublished Works.
©
1992-1997 Dolby Laboratories, Inc. All rights reserved.
Manufactured under license from Digital Theater Systems, Inc. US Pat. No. 5,451,942 and other world-wide patents
issued and pending. DTS, DTS Digital Surround, are trademarks of Digital Theater Systems, Inc.
©
1996 Digital Theater Systems, Inc. All Rights Reserved.
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

5
Preliminary
knowledge
Preliminary knowledge
Names of parts and controls
Refer to the corresponding pages indicated in () for details.
Front panel
1 STANDBY indicator (22)
Lights in red when the power cord is connected and
the unit is on standby. When the unit is turned on,
the STANDBY indicator goes off.
2 STANDBY/ON button (22)
Turns the unit on or off (standby).
3 Remote sensor (19)
Receives signals from the remote control unit.
4 Disc tray (22)
Used to load a disc.
5 0 (OPEN/CLOSE) button (22)
Used to open and close the disc tray.
6 PROGRESSIVE indicator (15)
Lights up when the Progressive scan mode is active.
It lights in green during playback of a film-source DVD
VIDEO disc when PROGRESSIVE MODE in
PREFERENCE 1 is set to SMART, FILM or AUTO.
In other conditions when the Progressive scan mode is
active, it lights in red.
7 Display window (8)
Indicates the current status of the unit.
8 4 / ¢ (SKIP) buttons (24, 43)
Used to skip a chapter, title or track. Also, used for
the page selection of a menu screen (for Video CD/
SVCD).
Holding down
4
or ¢ during playback reverses or
advances playback rapidly (except MP3 disc).
9 7 (STOP) button (23, 43)
Stops playback.
0 3 (PLAY) button (23, 43)
Starts playback. Also, used as a SELECT button for
PBC of Video CDs/SVCDs.
- 8 (PAUSE) button (23, 43)
Pauses playback. Also, used to display nine
continuous still pictures (STROBE function).
STANDBY
STANDBY/ON
PROGRESSIVE
DVD/SUPER VCD/VCD/CD
PAUSEPLAYSTOP
SKIP
OPEN/CLOSE
387
0
¢4
DVD/SUPER VCD/VCD/CD PLAYER
1STANDBY indicator 3Remote sensor 50(OPEN/CLOSE) button
2STANDBY/ON
button
4Disc tray
7Display window
6PROGRESSIVE indicator
-8(PAUSE) button
03(PLAY) button
97(STOP) button
84/¢(SKIP) buttons
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Preliminary knowledge
6
Preliminary
knowledge
Remote control unit
1 OPEN/CLOSE button (22)
Opens and closes the disc tray.
2 REPEAT button (33, 45)
Selects the repeat mode.
3 3D PHONIC button (41)
Produces a simulated surround effect.
4 Numeric buttons (12, 20)
When the TV - DVD switch is set to DVD, these buttons
are used to specify a title, chapter, track number, as
well as used to enter a time for the Time search
function.
When the TV - DVD switch is set to TV, these buttons
are used to select a TV channel as well as mute the TV
audio.
5 ANGLE button (36, 37, 42)
Changes camera angles during playback of a DVD
VIDEO disc containing multiple camera angles.
Also used to change the brightness of the display
window.
6 SUBTITLE button (37)
Used to display the subtitle selection display on the
TV screen, as well as used to turn the subtitle on or
off (for DVD VIDEO/SVCD).
7 DIGEST button (29)
Displays beginning scenes of each title, chapter or
track on the TV screen (for DVD VIDEO/Video CD/
SVCD).
PROGRESSIVE
SCAN
OPEN
/CLOSE TV DVD
TV DVD
STANDBY/ON
REPEAT
123
56
89
0+1010
7
4
3D
PHONIC TV/VIDEO CANCEL
SUBTITLEANGLE
TV1 TV2 TV3
TV4 TV5 TV6
TV7 TV8 TV9
TV
-/-- TV0 MUTING
AUDIO VFP
DIGEST
PREVIOUS
NEXT
CLEAR
STROBE
SLOW
+
SLOW
-
TITLE
MENU
CHOICE
ENTER
RM-SXVM50J REMOTE CONTROL
CH+
SELECT
CH
-
VOL
+
VOL
-
ON SCREEN
ZOOM
-
+
RETURN
4
¢
1
¡
5
5
5
∞
7
8
3
1OPEN/CLOSE button
2REPEAT button
33D PHONIC button
4Numeric buttons
5ANGLE button
6SUBTITLE button
7DIGEST button
84/PREVIOUS button
97/CLEAR button
01/SLOW– button
-TITLE button
=CURSOR(5Up, ∞Down)
- CH(+/–) buttons
~CHOICE button
!Infrared signal-emitting
window
@TV STANDBY/ON button
%RETURN button
#TV - DVD switch
$DVD STANDBY/ON button
^TV/VIDEO - CANCEL
button
&
VFP - PROGRESSIVE SCAN button
*AUDIO button
(ZOOM +/– buttons
)¢/NEXT button
_8/STROBE button
¡¡/SLOW
+ button
+3/SELECT button
™MENU button
£ENTER button
¢CURSOR (2Left, 3Right)
- VOL (+/–) buttons
ON SCREEN button
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Preliminary knowledge
7
Preliminary
knowledge
8 4 /PREVIOUS button (24, 27, 43)
Skips back a chapter, title or track. Also used for the
page selection of a menu screen (for DVD VIDEO/Video
CD/SVCD).
Holding down this button during playback reverses
playback rapidly (except MP3 disc).
9 7 /CLEAR button (23, 25, 32, 43)
Stops playback. Also used to clear all the programmed
selection for the program play.
0 1 /SLOW button (24, 31)
Pressing this button during playback reverses playback
rapidly (except MP3 disc).
Pressing this button while a DVD VIDEO disc is paused
reverses playback slowly.
- TITLE button (26)
Displays the title menu of a DVD VIDEO disc on the TV
screen.
= CURSOR ( 5 Up, ° Down) - CH (+/) buttons
When the TV - DVD switch is set to DVD, these buttons
are used to select an item from a menu or on-screen
display, or to change the setting of an on-screen
display item.
In this case, we call them CURSOR
5
/
°
 buttons in
this manual.
When the TV - DVD switch is set to TV, they are used
to select a TV channel.
~ CHOICE button (46)
Brings up the preference on-screen display on the TV
screen.
! Infrared signal-emitting window(19)
Point this window toward the remote sensor on the
front panel when pressing buttons.
@ TV STANDBY/ON button (20)
Turns the TV on or off (standby).
# TV - DVD switch (12, 20, 26)
When setting this switch to TV, the numeric, cursor
and TV/VIDEO - CANCEL buttons are used to control
your TV.
When setting it to DVD, these buttons are used to
control the unit.
$ DVD STANDBY/ON button (22)
Turns the unit on or off (standby).
% RETURN button (27)
Returns to the previous menu (for DVD VIDEO/Video
CD/SVCD).
^ TV/VIDEO - CANCEL button (20, 26)
Switches the TV input mode when the TV - DVD switch
issettoTV.
Cancels the last selection of the program when the
TV - DVD switch is set to DVD.
& VFP - PROGRESSIVE SCAN button (15, 40)
Pressing this button brings up the VFP window in
which you can select or adjust the picture character.
Holding down this button for a few seconds switches
the scan mode between the progressive scan and
interlace scan modes. See How to make the
Progressive scan mode active on page 15 for details.
* AUDIO button (39)
Selects the audio (for DVD VIDEO/Video CD/SVCD).
( ZOOM +/ buttons (31)
Zooms in or out the picture (for DVD VIDEO/Video CD/
SVCD).
) ¢ /NEXT button (24, 27, 43)
Skips forward a chapter, title or track. Also used for
the page selection of a menu screen (for DVD VIDEO/
Video CD/SVCD).
Holding down this button during playback advances
playback rapidly (except MP3 disc).
_ 8 /STROBE button (23, 30, 43)
Pauses playback. Also, used to display nine
continuous still pictures (STROBE function).
Pressing this button while paused advances the still
picture frame-by-frame.
+ 3 /SELECT button (23, 26, 43)
Starts playback. Also used as a SELECT button for
PBC of Video CDs/SVCDs.
¡ Á /SLOW+ button (24, 31)
Pressing this button during playback advances
playback rapidly (except MP3 disc).
Pressing this button while a DVD VIDEO, Video CD or
SVCD disc is paused advances playback slowly.
 MENU button (26)
Displays a DVD menu on the TV screen.
£ ENTER button
Executes the selected item in a menu or on-screen
display.
¢ CURSOR ( 2 Left, 3 Right) - VOL (+/) buttons
When the TV - DVD switch is set to DVD, these
buttons are used to select an item from a menu or
on-screen display, or to change the setting of an
on-screen display item.
In this case, we call them CURSOR
2
/
3
 buttons
in this manual.
When the TV - DVD switch is set to TV, they are used
to change the TV audio volume.
ON SCREEN button
Brings up an appropriate on-screen display for
controlling advanced functions for the current disc on
the TV screen.
3HQJIP 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Preliminary knowledge
8
Preliminary
knowledge
Display window
1 Audio format indicators
Indicates the format of audio currently being played
back.
2 Disc indicator
Indicates the type of the disc set in the tray. When a
DVD VIDEO disc is set, DVD lights up. When a
Video CD disc is set, VCD lights up. When an Audio
CD is set, CD lights up.
3 3 (play)/ 8 (pause) indicators
3
or
8
illuminates during playback or while paused,
respectively.
Neither of them illuminates while stopped.
4 Title/track/chapter indicators
One or more appropriate indicators illuminate
according to the disc inserted.
5 Repeat mode indicators
The appropriate indicator illuminates according to the
current repeat mode.
6 PROGRAM/RANDOM indicators
The appropriate indicator illuminates while the unit
is in the Program or Random playback mode.
7 Multi-information window
Displays the current title/track/chapter number(s),
time and status information.
Rear panel
1 DIGITAL OUT jack(s) (OPTICAL/COAXIAL) (17)
Outputs digital audio signals. You must select the
signal type correctly according to the external device
connected to via the Preference display. Both the
OPTICAL and COAXIAL connectors are provided.
2 VIDEO OUT - VIDEO jack (14)
Outputs a composite video signal.
3 VIDEO OUT - COMPONENT jacks (Y/P
B
/P
R
)(15)
Output component video signals.
These jacks can output the Progressive scan signals as
well as the conventional Interlace scan signals.
See How to make the Progressive scan mode active
on page 15 for details.
4 Region code label (13)
Indicates the region code of the unit.
5 AUDIO OUT jacks (RIGHT/LEFT) (14, 15)
Outputs stereo analog audio signals.
6 VIDEO OUT - S-VIDEO jack (14)
Outputs an S-video signal.
7 VIDEO OUT SELECT switch (NTSC/PAL) (15)
Selects NTSC or PAL to match the color
system of your TV. Note that the unit power must
be off (on standby) when you change the switch
position. Otherwise, the changed setting will not be
effective.
8 AV COMPU LINK jacks (53)
Connects with other JVC equipment supporting
the AV Compulink function to facilitate integrated
operations.
9 AC IN connector (18)
Connects to the wall outlet using the suppplied AC
power cord.
VCDVD
TITLE TRACK CHAP A
-
B1
PROGRAM
RANDOM
8
3
2Disc indicator
33(play)/8(pause)
indicators
4Title/track/
chapter indicators
5Repeat mode indicators
7Multi-information window
6
PROGRAM/RANDOM indicators
LPCM
MPEG
DOLBY
DIGITAL
DTS
1Audio format indicators
1DIGITAL OUT jack(s) (OPTICAL/COAXIAL)
3VIDEO OUT - COMPONENT jacks (Y/PB/PR)
5AUDIO OUT jacks (RIGHT/LEFT)
8AV COMPU LINK jacks
9AC IN connector
2VIDEO OUT - VIDEO jack
6 VIDEO OUT - S-VIDEO jack
VIDEO OUT
AC IN
AUDIO OUTDIGITAL OUT
VIDEO
RIGHT COMPONENT
S-VIDEO
YP
BPR
PCM / STREAM
COAXIALOPTICAL
AV COMPU LINK
LEFT
4Region code label
7VIDEO OUT SELECT switch (NTSC/PAL)
NTSC PAL
VIDEO OUT
SELECT
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Preliminary knowledge
9
Preliminary
knowledge
Operational Principles
You can set preferences and perform advanced playback
functions via various on-screen displays, including the
Opening, Preference, Parental lock and Control displays.
Basic operations of on-screen displays
 You can move using the CURSOR 5 / ° / 2 / 3 buttons
to select items you want to work with.
 With an item like you can change the setting
by using the CURSOR 2 / 3 buttons when is on
the item.
 - type item works when you place on the
item and press ENTER.
 In the message box, the operation to be performed is
displayed according to the item pointed by .
 Numbers are entered using the numeric buttons.
 Some functions become effective by pressing ENTER
after specifying necessary entries.
Opening display
An opening display appears automatically (without
pressing any buttons) in some conditions.
The display shown on the right appears when the unit
turns on with no disc inserted.
One of the displays shown on the right appears when a
disc is set and stopped. For a disc that does not contain
any picture (such as an Audio CD), the opening display
does not disappear after starting playback.
On-screen displays
1 / 3
REPEAT
(for Video CD/SVCD)
(for DVD VIDEO)
OPEN
/CLOSE
TV DVD
REPEAT
123
56
89
0+1010
7
4
3D
PHONIC TV/VIDEO CANCEL
SUBTITLEANGLE
TV1 TV2 TV3
TV4 TV5 TV6
TV7 TV8 TV9
TV
-/-- TV0 MUTING
AUDIO VFP
DIGEST
PREVIOUS
NEXT
CLEAR
STROBE
SLOW
+
SLOW
-
TITLE
MENU
CHOICE
ENTER
CH+
SELECT
CH
-
VOL
+
VOL
-
ON SCREEN
+ZOOM
-
RETURN
4
¢
1
¡
5
5
5
∞
7
8
3
TV DVD
STANDBY/ON
REMOTE CONTROL
PROGRESSIVE
SCAN
ENTER
Numeric
buttons
CURSOR
5/∞/2/3
(for Audio CD)
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Preliminary knowledge
10
Preliminary
knowledge
PREFERENCE (1, 2) displays (see page 46)
You can set preferences via these displays.
 To bring up the PREFERENCE 1/PREFERENCE 2
display
1
When a DVD VIDEO disc is set and stopped or no
disc is inserted, press CHOICE.
2
To select the display, move to the desired tab
using the CURSOR 2 / 3 buttons.
PARENTAL LOCK display (see page 50)
You can set the parental lock from this display.
 To bring up the PARENTAL LOCK display
When no disc is inserted or a DVD VIDEO disc is
stopped, press ENTER while holding down 7 .
DVD VIDEO CONTROL display
You can select and set various functions for DVD VIDEO
playback from this display.
This display is avairable only during DVD VIDEO
playback.
 To bring up the DVD VIDEO CONTROL display
During DVD VIDEO playback, press ON SCREEN.
CD CONTROL display
You can select and set various functions for Audio CD
playback from this display.
 To bring up the CD CONTROL display
Whenever an Audio CD is inserted, press ON SCREEN.
PREFERENCE2PREFERENCE1
MENU LANGUAGE
ENGLISH
AUDIO LANGUAGE
ENGLISH
OFF
SUBTITLE
ON SCREEN LANGUAGE
ENGLISH
ON SCREEN GUIDE
ON
MONITOR TYPE
PRESS KEY
PROGRESSIVE MODE
AUTO
(PREFERENCE 1)
4:3 LB
PREFERENCE2PREFERENCE1
DIGITAL AUDIO OUTPUT
STREAM/PCM
DOWN MIX
Lo / Ro
COMPRESSION
AUTO STANDBY
ON
OFF
SCREEN SAVER
MODE 1
AV COMPULINK MODE
PRESS KEY
DVD1
(PREFERENCE 2)
PARENTAL LOCK
Country Code MY
Set Level NONE
PASSWORD – – – –
EXIT
NEW PASSWORD? • • • PRESS 0~9 KEY
St. End
010Mb
TITLE
TIME
3
CHAPTER
3
1 : 34 : 58
PRESS ENTER EXECUTE CHAP.SEARCH
TIME SEARCH
A-B REPEAT
REPEAT
1 / 3
AUDIO
SUBTITLE
2 / 3
ANGLE
1 / 3
TITLE REPEAT
TITLE
TIME
3
CHAPTER
3
1 : 34 : 58
St. End
010Mb
Current relative
position of the
title
(St: start,End: end)
Current
title
number
Current
chapter
number
Elapsed time from
the beginning
of the current title
Transmission rate
TRACK 3 : 54TIME1 MIN SEC EACH
REMAIN
RANDOM
PROGRAM
TIME SEARCH
A-B REPEAT
REPEAT
TIME SELECT
PRESS ENTER =EXECUTE
REPEAT ALL
1
9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
17 18 19 20 21 22 23 24
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Preliminary knowledge
11
Preliminary
knowledge
VCD CONTROL display (for Video CD/
SVCD)
When a Video CD or SVCD disc is stopped, a display
similar to the CD CONTROL display appears.
During Video CD playback, the display shown on the
right appears. During SVCD playback, the display shown
on the right-bottom appears.
 To bring up the VCD CONTROL display
Press ON SCREEN when a Video CD or SVCD is
inserted. The appropriate display appears according
to the unit's status.
MP3 CONTROL display (See page 43)
The display shown on the right appears when an MP3
disc is set. You can select the desired Group or track to
be played back.
A television monitor screen may be burned out if a static
picture is displayed for a long time. To prevent this, the
unit automatically activates the screen saver function if a
static picture, such as an on-screen display or menu, is
displayed for over 5 minutes.
 Pressing any buttons on the unit or the remote control
unit will release the screen saver function and return to
the previous display.
 You can select one of several screen saver modes
available (see page 50).
 The screen saver function is not activated during
Audio CD/MP3 disc playback or after stopping Audio
CD/MP3 disc playback.
TRACK
TIME
3 4 : 58
PBC CALL
TIME SEARCH
A-B REPEAT
REPEAT
AUDIO
ST
PRESS ENTER EXECUTE
St. End
010Mb
REPEAT ALL
TRACK
TIME
3
4 : 58
St. End
010Mb
Current relative
position of the
track
(St: start, End: end) Current track
number
Elapsed time from
the beginning of
the current track
Transmission rate
(for Video CD)
MP3 CONTROL
GROUP: /
TRK.
TIME
03
4 : 58
PBC CALL
TIME SEARCH
A-B REPEAT
REPEAT
AUDIO
ST1
PRESS ENTER EXECUTE
St. End
010Mb
1 / 4
(for SVCD)
SUBTITLE
To prevent the monitor from burning out [SCREEN SAVER]
DVD/Super VCD/Video CD/CD PLAYER
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Preliminary knowledge
12
Preliminary
knowledge
On-screen guide icons
During DVD VIDEO playback, you may see icons displayed over the picture. These have
the following meanings.
: Displayed at the beginning of a scene recorded from multiple angles. (See page 36.)
: Displayed at the beginning of a scene recorded with multiple audio languages.
(See page 39.)
: Displayed at the beginning of a scene recorded with multiple subtitle languages.
(See page 37.)
You can set the unit not to display on-screen icons above via the preference settings
described on page 47.
About invalid operation icon
When you press a button, if the unit does not accept its operation, appears on your
television screen. Operations are occasionally unacceptable even if is not displayed.
Note that some operations may not be accepted. For example, some discs may not allow
rapid advance/reverse or slow-motion playback.
How to use numeric buttons
The function of the numeric buttons differs depending on the setting of the TV - DVD
switch. When setting it to TV, the buttons are used to select a TV channel (see page 20).
When setting it to DVD, the buttons are used to select a track/title or enter a disc time or
chapter number.
To select a track/title number
 To select a number between 1 and 10
Press the corresponding button for the number.
 To select a number higher than 10
Use the +10 button.
Examples:
To select 13 +10 o 3
To select 34 +10 o +10 o +10 o 4
To select 40 +10 o +10 o +10 o 10
To enter a time or chapter number
The method for entering a time for Time search or chapter number for Chapter search is
different from above. See the corresponding sections in this manual for the details.
* There is another method for selecting a track or group of an MP3 disc. See the
appropriate section.
To select a TV channel
Press the corresponding numeric buttons. See page 20 and 21 for details.
123
56
89
0+1010
7
4
SUBTITLEANGLE
TV1 TV2 TV3
TV4 TV5 TV6
TV7 TV8 TV9
TV
-/-- TV0 MUTING
AUDIO VFP
TV DVD
TV DVD
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Preliminary knowledge
13
Preliminary
knowledge
About discs
Playable and non-playable disc types are as follows:
Playable discs
The DVD VIDEO Logo is a trademark.
 CD-R and CD-RW discs recorded with the Audio CD or MP3 format can be played back, though some may not be played
back because of the disc characteristics or recording condition.
 DVD VIDEO players and DVD VIDEO discs have their own Region Code numbers. This unit can playback DVD VIDEO
discs whose Region Code numbers include the units Region Code, which is indicated on the region code symbol on
the rear panel.
Example of playable DVD discs when the unit's Region Code is 2:
The unit can playback a disc recorded with either the NTSC or PAL format and output a video signal with the format set
by the NTSC - PAL selector on the rear panel (i.e. you can enjoy an NTSC disc with the PAL television by simply set the
selector to PAL, or vice versa).
When playing back a PAL disc, the Progressive scan mode is never active even if you set the Progressive scan mode
to active (see page 15).
Non-playable discs
DVD-ROM, DVD-RAM, DVD AUDIO, DVD-R, DVD-RW, CD-ROM, PHOTO CD, CD-EXTRA, CD-G, CD-TEXT
 Playing back discs listed as Non-playable discs above may generate noise and damage speakers.
 This unit can play back audio recorded in CD-G, CD-EXTRA and CD-TEXT discs.
A DVD VIDEO disc is comprised of titles, while an Audio CD, Video CD or SVCD is comprised of tracks. Each title may
be divided into some chapters. For example, if a DVD VIDEO disc contains some movies, each movie may have its own
title number, and each movie may be divided into some chapters. In a DVD VIDEO KARAOKE disc, each song usually has
its own title number and does not have chapters. In general, each title has independent content, while each chapter in the
same title has continuity.
(Example: DVD VIDEO disc)
(Example: Audio CD/Video CD/SVCD)
Playable disc types
DVD VIDEO Video CD SVCD Audio CD
Disc structure
VIDEO CD
ALL 252 4
2
3
13
2
16
5
4
Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2
Title 1 Title 2
Track 1 Track 2 Track 3 Track 4
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

14
Getting started
Getting started
Connections
*In the following description, TV may be substituted with monitor or projector.
*Before using the unit, you have to connect the unit to a TV and/or amplifier.
 Do not connect the AC power cord until all other connections have been made.
 Since different components often have different terminal names, carefully read the instructions supplied with the
component you are going to connect.
You can enjoy playback by simply connecting the unit to a TV. To improve audio sound quality, connect the AUDIO OUT
jacks to your separate audio equipment. (See the following pages.)
Connect the unit to a TV equipped with stereo audio input and video input jacks using the supplied audio/video cables.
 If your TV has a monaural audio input instead of stereo, you need to use an optional audio cable which converts stereo
audio output to monaural.
 If your TV has an S-video input, you can get better picture quality by connecting it with the S-VIDEO output of the unit
using the S-video cable in addition to the (standard) video connection.
The unit is compatible with the PAL and NTSC systems, Set the VIDEO OUT SELECT switch on the rear panel to match the
color system of your TV. Make sure that the color system of a DVD VIDEO/Video CD/SVCD disc labeled on the package
matches your TV.
If you use a multi-system TV, you can play discs recorded on both PAL and NTSC systems by setting the VIDEO OUT
SELECT switch appropriately. However, note that you must change the switch position while the unit power is off (on
standby). Otherwise, the changed setting is not effective.
Before making any connections
To connect to a conventional TV
If theTV has an AV COMPU LINK terminal,
you can use the AV COMPU LINK function.
See “AV COMPU LINK remote control
system” on page 53 for details.
Yellow
Audio/Video cable
(supplied)
White
Red
S-video cable
(supplied)
Red
White Yellow
AV COMPU LINK
VIDEO OUTAUDIO OUTDIGITAL OUT
RIGHT COMPONENT
S-VIDEO
YP
BPR
PCM / STREAM
COAXIALOPTICAL
LEFT
VIDEO
T V
VIDEO
AUDIO
RIGHT
LEFT
S-VIDEO
IN
The unit
NTSC PAL
VIDEO OUT
SELECT
NOTES
 When connecting to a TV using the VIDEO OUT jack, make sure that the PROGRESSIVE indicator on the front panel is not lit. If
it is lit, the VIDEO and S-VIDEO outputs do not feed the correct signals. To turn off the PROGRESSIVE indicator, see How to
make the Progressive scan mode active on page 15.
 Connect VIDEO OUT of the unit directly to the video input of your TV. Connecting VIDEO OUT of the unit to a TV via a VCR may
cause a monitor problem when playing back a copy-protected disc.
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Getting started
15
Getting started
You can enjoy high picture quality by connecting the units COMPONENT VIDEO OUT jacks to the COMPONENT VIDEO IN
jacks of your TV with the video cables.
 Set the NTSC - PAL selector on the rear panel to match the system of your TV.
The unit can playback a disc recorded with either the NTSC or PAL format and output a video signal with the format set
by the NTSC - PAL selector.
However, if you connect the unit to a NTSC/PAL compatible TV, by setting MONITOR TYPE in PREFERENCE 1 to an
appropriate MULTI option, the unit outputs a video signal by the same format recorded on the disc (i.e. if you play an
NTSC disc, the unit output a signal by the NTSC format) regardless of the NTSC - PAL selector.
 The unit supports the progressive scan system for the NTSC video, as well as the conventional interlace scan system.
If your television or monitor supports the progressive video input, you can enjoy a high quality picture by making the
Progressive scan mode active.
Set the scan mode correctly when you connect the unit to an NTSC or NTSC/PAL compatible TV (see next column).
How to make the Progressive scan mode active (for NTSC disc only)
¦ While the NTSC - PAL selector on the rear panel is set to NTSC
Press and hold VFP - PROGRESSIVE SCAN button for a few seconds.
The scan mode switches between the progressive scan and interlace scan modes. When the progressive scan mode is
selected, the PROGRESSIVE indicator on the front panel is lit.
 You should note that not all Progressive TV and High-Definition TV sets are fully compatible with this product and may
cause artifacts to be displayed in the picture. In case of 525 progressive scan picture problems, it is recommended that
you switch the setting to the standard definition output.
 All JVC Progressive TV and High-Definition TV sets have no problem.
To connect to a TV with the component video input jacks
Audio cable
(not supplied)
White
Red
Red White
The unit
Green Red
Blue
Component video cable
(not supplied)
Green Red
Blue
T V
AV COMPU LINK
VIDEO OUTAUDIO OUTDIGITAL OUT
RIGHT COMPONENT
S-VIDEO
YP
BPR
YPBPR
PCM / STREAM
COAXIALOPTICAL
LEFT
VIDEO
IN
VIDEO
AUDIO
RIGHT
LEFT
S-VIDEO
IN
NTSC PAL
VIDEO OUT
SELECT
STANDBY
STANDBY/ON
PAUSEPLAYSTOP
SKIP
OPEN/CLOSE
387
0
¢4
PROGRESSIVE
DVD/SUPER VCD/VCD/CD PLAYER
PROGRESSIVE indicator
DVD/SUPER VCD/VCD/CD
PROGRESSIVE
SCAN
VFP -
PROGRESSIVE
SCAN
OPEN
/CLOSE
TV DVD
REPEAT
123
56
89
0+1010
7
4
3D
PHONIC TV/VIDEO CANCEL
SUBTITLEANGLE
TV1 TV2 TV3
TV4 TV5 TV6
TV7 TV8 TV9
TV
-/-- TV0 MUTING
AUDIO VFP
DIGEST
PREVIOUS
NEXT
CLEAR
STROBE
SLOW
+
SLOW
-
SELECT
+ZOOM
-
RETURN
4
¢
7
8
3
TV DVD
STANDBY/ON
3HQJIP 3DJH  7XHVGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Getting started
16
Getting started
You can enjoy high-quality audio by connecting the unit's audio output to your amplifier or receiver.
 Connect the unit's AUDIO OUT to any line-level inputs (such as AUX, DVD, CD, etc.) of an audio amplifier or receiver.
NOTES
 Connect Y to Y,P
B
toP
B
,P
R
toP
R
 correctly.
 When the component video input jacks of the TV is of the BNC type, use an adapter to convert a pin jack to a BNC jack
(optional).
 When the Progressive scan mode is selected, the VIDEO and S-VIDEO outputs do not feed the correct signals.
 The unit always scans a PAL disc with the Interlaced scan system regardless of the NTSC - PAL selector and the Progressive
scan mode settings.
About SCAN MODE
To display video on the monitor (television) screen, the conventional scanning method is called Interlaced scan.
With this method, only half of the horizontal lines are displayed at a time. So two fields complete a single picture
(frame); i.e., the first field, containing all the odd-numbered lines, is displayed followed by the second field, containing
all the even-numbered lines.
On the other hand, the Progressive scan system scans all horizontal lines at a time, so you can double the number of
pictures compared with the interlaced scan, resulting flicker-free, high-density picture.
To enjoy the progressive scanned video, a monitor (or TV or projector) to be connected to the unit must have the
Progressive inputs.
Depending on the material source format, DVD VIDEO discs can be classified into two types; film source and video
source (Note that some DVD VIDEO discs contain both film source and video source). Film sources are recorded as 24-
frame-per-second information, while (NTSC) video sources are recorded as 30-frame-per-second (60-field-per-second
interlaced) information.
When the unit plays back a film source material, uninterlaced progressive output signals are created using the original
information. When a video source material is played back, the unit interleaves lines between the interlaced lines on
each to create the pseudo uninterlaced picture and outputs as the progressive signal.
To connect to an audio amplifier or receiver
NOTE
 When using the unit with a stereo amplifier or receiver, make the DOWN MIX setting in PREFERENCE 2 to Lo/Ro. (See
page 49.)
Audio cable
(not supplied)
White
Red
The unit
White
Red Amplifier or receiver
AV COMPU LINK
VIDEO OUTAUDIO OUTDIGITAL OUT
RIGHT COMPONENT
S-VIDEO
YP
BPR
PCM / STREAM
COAXIALOPTICAL
LEFT
VIDEO
AUDIO
RIGHT
LEFT
IN
NTSC PAL
VIDEO OUT
SELECT
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Getting started
17
Getting started
You can enhance the sound quality by connecting either of the unit's DIGITAL OUT jacks to the digital input of an
amplifier, MD, etc. by using an optional digital cable (OPTICAL or COAXIAL). The digital audio signal from a disc is
directly transferred. If you connect the unit to a Dolby Digital or DTS decoder or an amplifier with a built-in decoder by
using an optional digital cable, you can enjoy high-quality surround sound.
When you make the digital connection, we recommend also to make the analog connection, because, depending on
discs, no signal may be output from the DIGITAL OUT.
To connect to audio equipment with a digital input
NOTES
 When you connect the unit's DIGITAL OUT to digital audio equipment, before using, make the DIGITAL AUDIO OUTPUT
setting in the PREFERENCE 2 on-screen display correctly according to the connected audio equipment. If the DIGITAL
AUDIO OUTPUT is not set correctly, loud noise may be generated from speakers, causing damage to them. See DIGITAL
AUDIO OUTPUT on page 48.
 With the digital connection, the COMPRESSION settings in the PREFERENCE 2 on-screen display are invalid. Settings for
these items must be made from the decoder.
Digital equipment
Audio cable
(not supplied)
White
Red
The unit
White
Red
Coaxial digital cable
(not supplied)
Optical digital cable
(not supplied)
The OPTICAL jack is protected by the hinged cover.
To connect the optical cable to the jack, press the
cover with the plug and connect it to the jack inside
in the correct direction.
AV COMPU LINK
AUDIO
RIGHT
LEFT
IN
OPTICAL
COAXIAL
DIGITAL
IN
VIDEO OUTAUDIO OUTDIGITAL OUT
RIGHT COMPONENT
S-VIDEO
YP
BPR
PCM / STREAM
COAXIALOPTICAL
LEFT
VIDEO
NTSC PAL
VIDEO OUT
SELECT
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals

Getting started
18
Getting started
When all the audio/video connections have been made, insert the smaller plug of the supplied AC power cord to the
units AC IN connector, then insert the other end to the wall outlet. Make sure that plugs are inserted firmly. The
STANDBY indicator lights and setup is completed.
Warning
 Disconnect the power cord if you are not going to use the unit for a long time.
 Disconnect the power cord before cleaning the unit.
 Disconnect the power cord before moving the unit.
 Do not connect or disconnect the power cord with wet hands.
 Do not pull the power cord when disconnecting it, as this may damage the cord and cause fire, electric shock, or other
accidents.
Caution
 Do not damage, alter, twist, or pull the power cord, as this may cause fire, electric shock, or other accidents.
 To prevent any accidents or damages caused by an unsuitable AC power cord, only use the supplied power cord. If the
cord is damaged, contact a dealer and get the new power cord.
 Do not put anything heavy, or the unit, on the power cord, as this may cause fire, electric shock, or other accidents.
Using the remote control unit
Using the remote control, you can operate not only all the functions of the unit but also basic functions of your TV.
The battery compartment is located on the back of the remote control unit.
1
Press down on the point shown by the arrow at the top of the compartment cover,
and pull up the cover to open the compartment.
2
Place the two accessory R6P (SUM-3)/AA(15F) batteries in the remote control according
to the polarity markings (+ and ) inside the compartment and on the batteries.
3
Place the cover over the compartment, and press down lightly.
 The batteries will last about six months with normal use. If the functions of the remote control become erratic, replace
the batteries. See below for more information.
To connect the power cord
NOTE
 The unit automatically accommodates AC power between 110 V and 240 V. You do not need any setting to match the unit with
your local power voltage.
To install batteries in the remote control unit
6(1*ERRN 3DJH  )ULGD\ -XQH    $0
Downloaded From Disc-Player.com JVC Manuals
