JVC LT-40C880 User manual

• Do not connect the TV to the mains supply until you have completed all the connections.
• Always disconnect the TV from the mains socket when not in use for a long period of time.
• The button on the remote control is only used for switching the TV into standby, it does not disconnect the TV from the mains power.
To completely disconnect the mains power, please remove the mains plug from the mains socket.
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object,
or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of the TV at any time because
the screen could crack.
Please inspect your TV for damage after unpacking. If you do notice any damage please consult your dealer.
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to any local regulations.
TV
TV Stand Neck
TV Stand Base
Remote Control/
AAA Batteries x2
Screws x 8
Instruction Manual
Quick Start Guide
Unpacking
1
1. Connect one end of the RF coaxial cable
to the aerial socket on the wall and the
other end of the cable to the ANT socket
on the back of your TV.
2. Plug the TV into a mains socket and
switch on at the mains.
3. In standby mode, press the button on
the remote control to turn the TV on. The
LED indicator will flash for a few seconds
then the TV will switch on.
Connecting the Aerial and Turning on the TV
4
Installing the Stand
3
1. Slide open the battery compartment on the back of the remote control.
Operating Your Remote Control
2
Thank you for purchasing your new JVC TV.
Your new TV incorporates the latest technology to enhance your viewing
experience. We would suggest that you allow about 20 mins for initial setup.
Please follow this guide for a successful rst time installation.
The latest eco-friendly power-saving technology will switch o the TV if
it is left on and idle for 4 hours. Please refer to “Auto Standby” under the
“Time Settings”section of the instruction manual for more detail.
Quick Start Guide
40" LED Smart 4K HDR TV
LT-40C880
2. Insert two AAA size batteries. Make sure to match the (+) and ( - )
ends of the batteries with the (+) and ( - ) ends indicated in the battery
compartment.
3. Slide the battery compartment cover back into place. Make sure it clicks
into place.
Optional
If you want to connect to the internet via a wired connection then
connect your ethernet cable to the LAN socket.
HDMI3 HDMI2 (ARC)
LAN
ANT.
VGA
Optic.OUT
SPDIF
RF coaxial cable
(not included)
Fitting the Stand to the TV
3. Ensure the TV is switched o and not connected to the mains power supply.
4. Lay the TV down on a at surface ideally on the edge of a table so the base of the
TV slightly overhangs the edge of the table, with the back side facing up. Please
make sure a soft cushioned material (such as a dry bath towel or thick piece of
foam) is placed beneath the screen.
5. Slide the stand under the lip, the neck will t snugly over the screw holes. Then
screw the stand to the TV using the 4 screws supplied.
Fitting the Stand Neck and Base Together
1. Fit the neck onto the base.
2. Using 4 of the supplied screws, screw the neck to the base.
Slide under
the lip
HDMI3 HDMI2 (ARC)
LAN
ANT.
VGA
Optic.OUT
SPDIF
Table
Cushioned
material
Protective
Bag
JVC 40' LED Smart 4K HDR TV LT-40C880 Quick Start.indd 1 04/04/2018 09:16

Well done, your new TV is now ready to use. You will nd that there are many exciting features available. To get to know all these features, please take
some time to read the instruction manual provided with your TV.
(QSG-LT-40C880-180404V1)
Need More Help!
If you need more help setting up your TV then please call:
UK: 0344 561 1234
Ireland: 1890 818 575
Lines are open 24/7
1. The first time you turn the TV on, it will go straight into the First Time Installation menu. Please
ensure the aerial is plugged in. Press the buttons to highlight your language then press OK.
Getting Started
Connecting to the Internet - Wired, Wireless or using the WPS button
5
6
All of the setting on 'First time installations' menu are pre set for the majority of customers in the UK, if
you wish you can change the setting by selecting each setting and pressing the
buttons.
If you View TV Through a Set Top Box
If you have attached a Set top box such as Sky/Virgin or BT via a HDMI cable select Digital Aerial to NO.
This will mean your TV will not try to tune any channels in. To view your set top box press
the SOURCE button and select the HDMI socket you have attached your set top box to.
2. Confirm these settings by pressing OK.
3. Press the buttons to highlight
Home Mode then press OK.
4. To access all the features of your
Smart TV you must be connected to
the internet. If you do not wish to
set up your network connection you
can skip this section by selecting NO,
however we recommend you set up
your network connection now.
5. Select Yes and Press OK.
To access all the features of your Smart TV you must be connected to the internet. If you do not wish
to set up your network connection you can skip this section by pressing , however we recommend
you set up your network connection now.
WIRED Connection
•If you have connected your ethernet cable to the LAN socket on the back of your TV press the
buttons to select WIRED DEVICE. When Network says CONNECTED press OK.
WIRELESS Connection
You can connect using a wireless
connection via your router.
1. Press the buttons to select WIRELESS DEVICE. Wait a few seconds and a list of all wireless
networks will be displayed.
2. Press the buttons to select your wireless network then press OK.
3. You now need to enter your password, a keyboard
will appear. Press the buttons to select a
letter/number/symbol and press OK to enter each
one. Once you have typed your password highlight
OK and press OK. The network will now show
Connected.
4. Press the OK button to continue.
WPS Connection
Rather than having to enter your Wireless password, you can select the WPS option. This will allow you
to connect to your router without a password once the WPS button is pressed on your router.
1. Select WIRELESS DEVICE, when you see list of wireless networks press the BACK button.
2. Press the button to select 'Press WPS on your wifi router' then press OK. Now press the WPS
button on your router and your TV will connect to your router, without the use of a password.
Tuning in Your TV
7
Choose Region (UK only)
During tuning, your TV may have received signals from more than one transmitter. If this has occurred the Choose Region screen will be displayed. This will
enable you to select the correct regional transmission for the local news service that you require.
1. Press the button to highlight Primary region, then press the buttons to select your
Primary Region e.g. England.
2. Press the button to highlight Secondary region, then press the buttons to select your
Secondary Region e.g. London.
3. Press the button to highlight Tertiary region, then press the buttons to select your
Tertiary Region e.g. Greater London.
• To make sure you activate Freeview Play select YES and press OK.
4. Press the button to highlight Save then press OK.
5. The Scan statistics screen will appear, showing you the amount of TV and radio stations that
have been tuned in. Press OK to exit this screen.
6. The Edit Channel list will appear, press the EXIT button to remove this. Your TV is now fully
tuned in and ready to use.
To enjoy Freeview Play your TV must be connected to the internet.
Your TV will now start automatic channel scan. It will tune in all available TV channels.
Make sure your TV is as close to your router as possible, within
5m and its recommended its in the same room as the TV.
