SERVICE MANUAL
COPYRIGHT © 2004 Victor of Japan, Limited No.YA031
2004/6
LCD FLAT TELEVISION
LT-17E31 BUG/BJG
LT-17E31 SUG/SJG
LT-17E75 BJG
LT-17E75 SJG
TABLE OF CONTENTS
1. PRECAUTIONS .......................................................................................................................................... 1-3
2. SPECIFIC SERVICE INSTRUCTIONS .......................................................................................................... 1-5
3. DISASSEMBLY ........................................................................................................................................... 1-6
4. ADJUSTMENT .......................................................................................................................................... 1-22
5. TROUBLE SHOOTING .............................................................................................................................. 1-23

1-2 (No. YA031)
SPECIFICATION
NOTE: Design & specifications are subject to change without notice.
Dimentions (W x H x D) 46.5cm x 32.5cm x 7.8cm (TV only)
46.5cm x 36.3cm x 19.0cm
Mass 6.1kg (TV only)
7.3kg
TV RF System B, G, I, D, K, L
Colour System TV Mode PAL / SECAM
Video Mode PAL / SECAM / NTSC3.58 / NTSC4.43
Stereo System A2(B/G, D/K), NICAM (B/G, I, D/K, L)
Teletext System FLOP(Fastext), TOP, WST(World Standard System)
Receiving Frequency E2 ~ E12, E21 ~ E69 E21 ~ E69
S1 ~ S41, X, Y, Z, Z+1, Z+2
ITALY A-H, H+1, H+2
F2 ~ F10, F21 ~ F69
R1 ~ R12, R21 ~ R69
IR A ~ J A ~ J
French cable TV 116MHz ~ 172MHz
220MHz ~ 469MHz
Aerial Input Terminal 75Ωunbalanced
Power Input TV : 12V DC, AC adapter : AC100V ~ AC240V, 50Hz/60Hz
Power Consumption 60W, Standby : 6W
Display area Visible size: 43.5cm (Diagonal) / 37.0cm x 22.5cm (H x V)
Display pixels 1280 x 768 (W-XGA)
Speakers 5.4cm, Round type x 2
Audio Output 3W + 3W
Video / Audio Inputs EXT-1 terminal Euroconnector (21pin SCART)
(1/2/3) Composite video, RGB, Audio L, R
EXT-2 terminal Euroconnector (21pin SCART)
Composite video, S-VIDEO, RGB, Audio L, R
EXT-3 terminal RCA connectors x3, S-VIDEO connector x1
Composite video, S-VIDEO, Audio L, R
Video / Audio Outputs EXT-1 terminal Euroconnector (21pin SCART)
Composite video, Audio L, R (TV broadcast outputs)
Audio RCA connectors x3
Audio L, R, Subwoofer
PC Input Analog RGB : D-SUB(15pin) x1, PC AUDIO IN x1
Headphone 3.5mm stereo mini jack x 1
Remote Control Unit DA-5000100084 DA-5000100085 DA-5000100084
(AA/R06/UM-3 battery x 2) (AA/R06/UM-3 battery x 2) (AA/R06/UM-3 battery x 2)
AC adapter HP-OL060D03
Items
Contents
LT-17E31 BUG LT-17E31 BJG LT-17E75 BJG
LT-17E31 SUG LT-17E31 SJG LT-17E75 SJG

(No. YA031) 1-3
1.1 SAFETY PRECAUTIONS
(1) The design of this product contains special hardware,
many circuits and components specially for safety
purposes. For continued protection, no changes should
be made to the original design unless authorized in writing
by the manufacturer. Replacement parts must be identical
to those used in the original circuits. Service should be
performed by qualified personnel only.
(2) Alterations of the design or circuitry of the products should
not be made. Any design alterations or additions will void
the manufacturer's warranty and will further relieve the
manufacturer of responsibility for personal injury or
property damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These
characteristics are often not evident from visual inspection
nor can the protection afforded by them necessarily be
obtained by using replacement components rated for
higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in
the parts list of Service manual. Electrical components
having such features are identified by shading on the
schematics and by () on the parts list in Service
manual. The use of a substitute replacement which does
not have the same safety characteristics as the
recommended replacement part shown in the parts list
of Service manual may cause shock, fire, or other hazards.
(4) Don't short between the LIVE side ground and ISOLATED
(NEUTRAL) side ground or EARTH side ground when
repairing.
Some model's power circuit is partly different in the GND.
The difference of the GND is shown by the LIVE : ( ) side
GND, the ISOLATED (NEUTRAL) : ( ) side GND and
EARTH : ( ) side GND. Don't short between the LIVE
side GND and ISOLATED (NEUTRAL) side GND or EARTH
side GND and never measure the LIVE side GND and
ISOLATED (NEUTRAL) side GND or EARTH side GND at
the same time with a measuring apparatus (oscilloscope
etc.).
If above note will not be kept, a fuse or any parts will be
broken.
(5) If any repair has been made to the chassis, it is
recommended that the B1 setting should be checked or
adjusted (See ADJUSTMENT OF B1 POWER SUPPLY).
(6) The high voltage applied to the picture tube must conform
with that specified in Service manual. Excessive high
voltage can cause an increase in X-Ray emission, arcing
and possible component damage, therefore operation
under excessive high voltage conditions should be kept
to a minimum, or should be prevented. If severe arcing
occurs, remove the AC power immediately and determine
the cause by visual inspection (incorrect installation,
cracked or melted high voltage harness, poor soldering,
etc.). To maintain the proper minimum level of soft X-Ray
emission, components in the high voltage circuitry
including the picture tube must be the exact replacements
or alternatives approved by the manufacturer of the
complete product.
(7) Do not check high voltage by drawing an arc. Use a high
voltage meter or a high voltage probe with a VTVM.
Discharge the picture tube before attempting meter
connection, by connecting a clip lead to the ground frame
and connecting the other end of the lead through a 10kΩ
2W resistor to the anode button.
(8) When service is required, observe the original lead dress.
Extra precaution should be given to assure correct lead
dress in the high voltage circuit area. Where a short circuit
has occurred, those components that indicate evidence
of overheating should be replaced. Always use the
manufacturer's replacement components.
(9) Isolation Check
(Safety for Electrical Shock Hazard)
After re-assembling the product, always perform an
isolation check on the exposed metal parts of the cabinet
(antenna terminals, video/audio input and output
terminals, Control knobs, metal cabinet, screw heads,
earphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.
a) Dielectric Strength Test
The isolation between the AC primary circuit and all metal
parts exposed to the user, particularly any exposed metal
part having a return path to the chassis should withstand
a voltage of 3000V AC (r.m.s.) for a period of one second.
(. . . . Withstand a voltage of 1100V AC (r.m.s.) to an
appliance rated up to 120V, and 3000V AC (r.m.s.) to an
appliance rated 200V or more, for a period of one second.)
This method of test requires a test equipment not generally
found in the service trade.
b) Leakage Current Check
Plug the AC line cord directly into the AC outlet (do not use
a line isolation transformer during this check.). Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal part of the cabinet, particularly
any exposed metal part having a return path to the chassis,
to a known good earth ground (water pipe, etc.). Any
leakage current must not exceed 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.2mA AC
(r.m.s.).
Alternate Check Method
Plug the AC line cord directly into the AC outlet (do not
use a line isolation transformer during this check.).
Use an AC voltmeter having 1000 ohms per volt or
more sensitivity in the following manner. Connect a
1500Ω10W resistor paralleled by a 0.15µF AC-type
capacitor between an exposed metal part and a known
good earth ground (water pipe, etc.). Measure the AC
voltage across the resistor with the AC voltmeter. Move
the resistor connection to each exposed metal part,
particularly any exposed metal part having a return path
to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Any voltage measured
must not exceed 0.75V AC (r.m.s.). This corresponds
to 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.3V AC
(r.m.s.). This corresponds to 0.2mA AC (r.m.s.).
AC VOLTMETER
(HAVING 1000Ω/V,
OR MORE SENSITIVITY)
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
1500Ω10W
0.15µF AC-TYPE
GOOD EARTH GROUND
SECTION 1
PRECAUTION

1-4 (No. YA031)
1.2 INSTALLATION
1.2.1 HEAT DISSIPATION
If the heat dissipation vent behind this unit is blocked, cooling efficiency may deteriorate and temperature inside the unit will rise.
Therefore, please make sure pay attention not to block the heat dissipation vent as well as the ventilation outlet behind the unit
and ensure that there is room for ventilation around it.
1.2.2 INSTALLATION REQUIREMENTS
Ensure that the minimal distance is maintained, as specified below, between the unit with and the surrounding walls.
Install the unit on stable flooring or stands.
Take precautionary measures to prevent the unit from tipping in order to protect against accidents and earthquakes.
Distance recommendations
Avoid improper installation and never position the unit where good ventilation
is impossible.
When installing this TV, distance recommendations must be maintained
between the set and the wall, as well as inside a tightly enclosed area or
piece of furniture.
Keep to the minimum distance guidelines shown for safe operation.
1.3 PRECAUTIONS
(1) Depending on the around temperature, the brightness leaning occurs. Be careful of the environment in the product
installation place and so on sufficiently.
(2) Don't hinder radiation from the back, the heaven and the side. Please refer to the next page that explains about the
condition of the installation.
The inside becomes hot if hindering radiation and there is fear, which the inner circuit damages.
(3) Install in the place with good ventilation. Use in the condition that around temperature is in the 0~35°C range.
(4) Avoid preservation and use at the high temperature or high humidity place. If you behave like this, leaning sometimes
happens in the screen when the set actives.
(5) Depending on the condition and the environment of display, the slight fleck of the light and leaning of the screen and so on
is sometimes conspicuous. This is the characteristic which is peculiar to liquid crystal display. It is not set trouble.
(6) This monitor has cool cathode pipe as the backlight. The time change and the use time sometimes change brightness
and condition of display.
1.4 THE ATTENTION IN TRANSPORTATION
When transporting a set, if the load handling is bad (throwing, falling and so on) however it is using a solid box, pressure inside
liquid crystal display.
In the case there is fear to break the liquid crystal display while transporting. To prevent from the accident or trouble while
transporting, pay attention to choice of the transportation company sufficiently and also arrange for it in the delivery after the
attention of the load handling is explained to the transportation company.
This set is used glass for composing liquid crystal display. When carrying, pay attention not to add over vibration and impact
sufficiently.
Ensure that it is placed upright and not horizontally during transportation and storage as the LCD panel is very vulnerable to
lateral impacts and may break. During transportation, ensure that the unit is loaded along the traveling direction of the vehicle,
and avoid stacking them on one another. For storage, ensure that they are stacked in 2 layers or less even when placed upright.
200 mm 200 mm
50 mm
150 mm 150 mm

(No. YA031) 1-5
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 DESCRIPTION ABOUT LIQUID CRYSTAL PANEL
2.2.1 STRUCTURE OF LIGUID CRYSTAL PANEL
The Liquid Crystal Panel of this model is TFT Panel. The Print circuit board that consist of TFT array and the print circuit board
adopted stripe shaped image element alignment are used. These two boards are mixed. The Liquid crystal is enclosed between
two boards.
2.1.2 LONG RANGE AFTERIMAGE OF LIQUID CRYSTAL
The small amount of ion material has mixed a liquid crystal panel with the liquid crystal material in the manufacturing process.
If ion material is piled up partially among the poles when the voltage is impressed among the poles, the brightness difference
occurs and becomes a long-range afterimage If same picture is reflected for long time, such a long-range afterimage occurs. If
the long-range afterimage occurs, we recommend that you reflect the single color image or moving picture and so on to restore.
2.1.3 THE DISPLAY REPLYING SPEED OF LIQUID CRYSTAL
Because the speed to display of Liquid crystal panel is slower than the speed of the CRT monitor, some of the moving picture
cannot overtake to the speed to display and the image looks flowing is sometimes displayed. This is not trouble, but efficiency
of Liquid Crystal.
2.1.4 THE EYESIGHT CORNER OF LIQUID CRYSTAL
The liquid crystal panel has the wide eyesight corner for which it is difficult to reverse brightness. The tint changes depending on
the direction to see a screen. This is not trouble, but efficiency of Liquid Crystal.
2.1.5 THE PICTURE ELEMENT FAULT OF LIQUID CRYSTAL
The liquid crystal panel is composed of precise technique but all devices don't always work right.
2.2 ATTENTION ITEMS WHEN REPLACING PARTS
2.2.1 ATTENTION TO EXCHANGE THE LIQUID CRYSTAL PANEL
(1) The stillness electricity sometimes makes damage a liquid crystal panel. In liquid crystal panel exchange, do a measure
of the stillness electricity such as the earth band.
(2) A liquid crystal panel and back-light are made from glass. If you gain an impact to these materials, there is fear to damage.
So in case of treatment, be careful sufficiently.
(3) Fix with the screw after confirming that there is not a float to chassis base when exchanging liquid crystal panel.
After that reflect all the black signals and confirm that brightness leaning doesn't occur near the screw fixation part.
When brightness leaning occurs, slacken a screw in the neighborhood until the brightness leaning is running-out.
(4) Fix the torque that installs a screw below 0.294Nm.
If you install at any more torque, the liquid crystal panel is transformed and sometimes damages.
(5) If you pull out or insert each connector when power is ON, it causes the trouble.
So pull out or insert each connector in the condition to have pulled out a power supply plug.
2.2.2 ATTENTION WHEN EXCHANGING THE FUSE
When exchanging the fuse, please use specified parts. After fuse exchange, confirm that insulater is set to the shield and
insulate surely.

1-6 (No. YA031)
SECTION 3
DISASSEMBLY
3.1 DISASSEMBLY PROCEDURE
CAUTION:
•Disconnect the set and attached devices from the electrical outlet
•To avoid ESD (Electro-Static Discharge), ground yourself by using a wrist grounding strap or by periodically touching
unpainted metal on the set.
3.1.1 REMOVING THE CABLE COVER AND NECK COVER
(1) Remove the CABLE COVER (L) by pulling the snap tabs.
(2) Make similar ways to remove the CABLE COVER (R) and NECK COVER.
Snap tabs
CABLE COVER (R) NECK COVER REAR COVER
CABLE COVER (L)

(No. YA031) 1-7
3.1.2 REMOVING THE DUMMY COVERS (If necessary)
(1) Remove the DUMMY COVERS of TUNER module and AV JACK module by pulling the snap tabs
Snap tab DUMMY COVER TUNER COVER
Snap tab DUMMY COVER
TUNER module AV JACK module

1-8 (No. YA031)
3.1.3 PREPARING TO REMOVE THE MODULE UNITS
(1) Remove the TUNER module cover by pulling snap tab.
(2) Loosen 2 screws [A] of AV JACK module.
3.1.4 REMOVING THE BASE AND THE HANDLE
(1) Remove 4 screws [B] and remove the BASE by pulling BASE.
(2) Remove 4 screws [C] and remove the HANDLE.
A
C
B
TUNER module
HANDLE
Snap tab

(No. YA031) 1-9
3.1.5 REMOVING THE MODULE UNITS
(1) Remove the TUNER module by pulling carefully.
(2) Remove the AV JACK module by pulling carefully.
3.1.6 REMOVING THE REAR COVER
(1) Remove 4 screws [D] and remove the REAR COVER.
NOTE:
For the REAR COVER is attached tightly, it is easy to open from the corner of the REAR COVER.
REAR COVER
TUNER module
AV JACK module
D

1-10 (No. YA031)
3.1.7 REMOVING THE D-SUB COVER AND THE AUDIO COVER
(1) Remove a screw [E] and remove the D-SUB COVER.
(2) Remove a screw [F] and remove the AUDIO COVER.
3.1.8 REMOVING THE MODULE BRACKETS
(1) Remove the 2 screws [G] and remove the MODULE BRACKETS.
G
D-SUB COVER AUDIO COVER
MODULE BRACKETS
EF

(No. YA031) 1-11
3.1.9 REMOVING THE MAIN BOARD SHIELD
(1) Remove 4 screws [H] and remove the 2 nuts [I].
(2) Remove the tape fixing wires.
(3) Remove the MAIN BOARD SHIELD by sliding to downside and lifting.
Holes for slide
Tape
Release the earth wires
I
H

1-12 (No. YA031)
3.1.10 DISCONNECTING THE WIRING CONNECTORS
(1) Disconnect the wiring connectors from P002 and P003 on MAIN PWB.
NOTES:
Confirm the wiring layout of harnesses.
•The AUDIO wires are fixed by hot bond between P002 and P003, after connected.
•The RIGHT SPEAKER wires are turn around into the gap as shown Fig.A.
•The LEFT SPEAKER wires must be put away from the top of the RIGHT SPEAKER and hooked as shown Fig. B.
Fixed by hot bond
SPEAKER (L)
Wire for SPEAKER (L)
Hooks
Fig. BFig. A
SPEAKER (R)
Wire for SPEAKER (R)
P003
P002

(No. YA031) 1-13
3.1.11 REMOVING THE LCD MODULE ASS’Y
(1) Remove 3 screws [J].
(2) Remove the LCD MODULE ASS’Y by release from the 6 latches.
J
Label
Latch (Right)
Latches (Top) x4
Latch (Left)

1-14 (No. YA031)
3.1.12 REMOVING THE SPEAKERS
(1) Disconnect the wires from the P603 on FRONT CONTROL PWB.
(2) Strip off the sponges and lift the SPEAKERS.
P603
Sponges
Wires under sponges SPEAKERS

(No. YA031) 1-15
3.1.13 REMOVING THE FRONT CONTROL PWB AND IR SENSOR PWB
(1) Remove 2 screws [K] and remove the FRONT CONTROL PWB.
(2) Remove a screw [L] and remove the IR SENSOR PWB.
(3) Remove 3 screws [M] and remove the KEY assembly.
K L
M
FRONT CONTROL PWB
wires (8P)IR SENSOR PWBwires (6P)

1-16 (No. YA031)
3.1.14 SUPPLEMENTAL 1
•The below assemblies are welded process.
•If removing these components, it is necessary to replace them.
VESA BRACKET
Welded
REAR COVER
FRONT COVER
Welded
IR LENS
LED WINDOW
Welded
Welded
KEY COVER
KEY
LOGO

(No. YA031) 1-17
3.1.15 SUPPLEMENTAL 2
•SPEAKER assembly.
•Confirm to connect the positive wire to the terminal with RED marker.
Red (+)
Cushion
rubber
SPEAKER SPEAKER wires RED marker
High density rubber
Black ( - )
White (+)
Black ( - )

1-18 (No. YA031)
3.1.16 SUPPLEMENTAL 3
•BASE assembly.
BASE
Rubber foot
HINGE COVER
HINGE
Hot bond
Insert until locking
Latchs
BASE BRACKET
Q
P
•HINGE assembly.

(No. YA031) 1-19
IR SENSOR PWB
MAIN PWB
F
E
TUNER PWB
AV JACK PWB
LK
M
J
H
A
Q
P
B
D
C
G
FRONT COVER
LCD PANEL
FRONT CONTROL PWB
INVERTER
BASE
REAR COVER
MODULE BRACKET
VESA BRACKET
HANDLE
CABLE COVER (L)
NECK COVER
CABLE COVER (R)
HINGE
SPEAKER
SPEAKER

1-20 (No. YA031)
Memory IC Notice
MCU IC Notice
3.2 REPLACEMENT OF MEMORY IC
3.2.1 PROCEDURE FOR REPLACING OF MEMORY IC
