SERVICE MANUAL
COPYRIGHT © 2004 Victor Company of Japan, Limited No.YA214
2004/9
LCD FLAT TELEVISION
YA21420049
LT-32X575/T
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-25
BASIC CHASSIS
FL

1-2 (No.YA214)
SPECIFICATION
Design & specifications are subject to change without notice.
Items Contents
Dimensions ( W ×H ×D ) 83.4cm ×63.2 cm ×30 cm [Included stand]
83.4cm ×56.8 cm ×10.8 cm [TV only]
Mass 23 kg [Included stand]
19.8kg [TV only]
Power Input AC110V , 60Hz
Power Consumption 195W (Max)
TV RF System CCIR (M)
Color System NTSC
Sound System BTSC (Multi Channel Sound)
Teletext System Closed caption (T1-T4 / CC1-CC4)
TV Receiving Channels
and Frequency
VHF Low
VHF High
UHF
CATV
02ch to 06ch : 54MHz to 88MHz
07ch to 13ch : 174MHz to 216MHz
14ch to 69ch : 470MHz to 806MHz
54MHz to 804MHz
Low Band : 02 to 06, A-8 by 02 to 06&01
High Band : 07 to 13 by 07 to 13
Mid Band : A to I by 14 to 22
Super Band : J to W by 23 to 36
Hyper Band : W+1 to W+28 by 37 to 64
Ultra Band : W+29 to W+84 by 65 to 94, 100 to 125
Sub Mid Band : A4 to A1 by 96 to 99
TV / CATV Total Channel 181 Channels
[Reception of channel A-5 (“95” of the TV set’s on-screen CABLE channel) is
recommended for your TV set.]
Intermediate Frequency Video IF
Sound IF
45.75 MHz
41.25 MHz (4.5MHz)
Color Sub Carrier 3.58 MHz
LCD panel 32V-inch wide aspect (16:9)
Screen Size Diagonal : 80cm (H:69.7cm ×V : 39.2cm)
Display Pixels Horizontal : 1280 dots ×Vertical : 768 dots (W-XGA)
Audio Power Output 10W + 10W
Speaker 6.6cm, round type ×2 (Oblique corn)
Antenna terminal (VHF/UHF) F-type connector, 75Ωunbalanced, coaxial
Video / Audio input
[INPUT-1/2/3]
Component Video
[INPUT-1]
1125i / 750p
525p / 525i
S-Video
[INPUT-1/2]
Video
Audio
RCA pin jack ×3
Y : 1V (p-p) (Sync signal: 0.35V(p-p), 3-value sync.), 75 Ω
Pb/Pr : ±0.35V(p-p), 75 Ω
Y : 1V (p-p), Positive (Negative sync provided), 75 Ω
Cb/Cr : 0.7V(p-p), 75 Ω
Mini-DIN 4 pin ×2
Y: 1V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286V (p-p) (Burst signal), 75 Ω
1V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack ×3
500mV (rms), High impedance, RCA pin jack ×6
Digital input Video
Audio
HDMI connector ×1
(Digital-input terminal is not compatible with picture signals of computer signal)
Digital: HDMI connector ×1
Anarog: 500mV(rms) (-4dBs), high impedance, RCA pin jack ×2
Audio output 500mV (rms), Low impedance, RCA pin jack ×2
Headphone 3.5mm stereo mini jack ×1
Remote Control Unit RM-C1257G (AA/R6 / UM-3 battery ×2)

(No.YA214)1-3
SECTION 1
PRECAUTION
1.1 SAFETY PRECAUTIONS
(1) The design of this product contains special hardware,
many circuits and components specially for safety
purposes. For continued protection, no changes should be
made to the original design unless authorized in writing by
the manufacturer. Replacement parts must be identical to
those used in the original circuits. Service should be
performed by qualified personnel only.
(2) Alterations of the design or circuitry of the products should
not be made. Any design alterations or additions will void
the manufacturer's warranty and will further relieve the
manufacturer of responsibility for personal injury or
property damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These
characteristics are often not evident from visual inspection
nor can the protection afforded by them necessarily be
obtained by using replacement components rated for
higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in
the parts list of Service manual. Electrical components
having such features are identified by shading on the
schematics and by ( ) on the parts list in Service
manual. The use of a substitute replacement which does
not have the same safety characteristics as the
recommended replacement part shown in the parts list of
Service manual may cause shock, fire, or other hazards.
(4) Don't short between the LIVE side ground and
ISOLATED (NEUTRAL) side ground or EARTH side
ground when repairing.
Some model's power circuit is partly different in the GND.
The difference of the GND is shown by the LIVE : ( ) side
GND, the ISOLATED (NEUTRAL) : ( ) side GND and
EARTH : ( ) side GND.
Don't short between the LIVE side GND and ISOLATED
(NEUTRAL) side GND or EARTH side GND and never
measure the LIVE side GND and ISOLATED (NEUTRAL)
side GND or EARTH side GND at the same time with a
measuring apparatus (oscilloscope etc.). If above note will
not be kept, a fuse or any parts will be broken.
(5) When service is required, observe the original lead dress.
Extra precaution should be given to assure correct lead
dress in the high voltage circuit area. Where a short circuit
has occurred, those components that indicate evidence of
overheating should be replaced. Always use the
manufacturer's replacement components.
(6) Isolation Check (Safety for Electrical Shock Hazard)
After re-assembling the product, always perform an
isolation check on the exposed metal parts of the cabinet
(antenna terminals, video/audio input and output terminals,
Control knobs, metal cabinet, screw heads, earphone jack,
control shafts, etc.) to be sure the product is safe to operate
without danger of electrical shock.
a) Dielectric Strength Test
The isolation between the AC primary circuit and all metal
parts exposed to the user, particularly any exposed metal
part having a return path to the chassis should withstand a
voltage of 3000V AC (r.m.s.) for a period of one second. (.
. . . Withstand a voltage of 1100V AC (r.m.s.) to an
appliance rated up to 120V, and 3000V AC (r.m.s.) to an
appliance rated 200V or more, for a period of one second.)
This method of test requires a test equipment not generally
found in the service trade.
b) Leakage Current Check
Plug the AC line cord directly into the AC outlet (do not use
a line isolation transformer during this check.). Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal part of the cabinet, particularly
any exposed metal part having a return path to the chassis,
to a known good earth ground (water pipe, etc.). Any
leakage current must not exceed 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.2mA AC
(r.m.s.).
Alternate Check Method
Plug the AC line cord directly into the AC outlet (do not
use a line isolation transformer during this check.). Use
an AC voltmeter having 1000Ωper volt or more
sensitivity in the following manner. Connect a 1500Ω
10W resistor paralleled by a 0.15µF AC-type capacitor
between an exposed metal part and a known good earth
ground (water pipe, etc.). Measure the AC voltage
across the resistor with the AC voltmeter. Move the
resistor connection to each exposed metal part,
particularly any exposed metal part having a return path
to the chassis, and measure the AC voltage across the
resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Any voltage measured must
not exceed 0.75V AC (r.m.s.). This corresponds to
0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.3V AC
(r.m.s.). This corresponds to 0.2mA AC (r.m.s.).
AC VOLTMETER
(HAVING 1000 /V,
OR MORE SENSITIVITY)
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
1500 10W
0.15 F AC-TYPE
GOOD EARTH GROUND

1-4 (No.YA214)
1.2 INSTALLATION
1.2.1 HEAT DISSIPATION
If the heat dissipation vent behind this unit is blocked, cooling
efficiency may deteriorate and temperature inside the unit will
rise. The temperature sensor that protects the unit will be
activated when internal temperature exceeds the pre-determined
level and power will be turned off automatically.Therefore,
please make sure pay attention not to block the heat dissipation
vent as well as the ventilation outlet behind the unit and ensure
that there is room for ventilation around it.
1.2.2 INSTALLATION REQUIREMENTS
Ensure that the minimal distance is maintained, as specified
below, between the unit with and the surrounding walls, as well
as the floor etc.Install the unit on stable flooring or stands.Take
precautionary measures to prevent the unit from tipping in order
to protect against accidents and earthquakes.
1.2.3 INSTALLATION REQUIREMENTS
To ensure safety in an emergency such as an earthquake, and
to prevent accidents, ensure that measures are taken to prevent
the TV dropping or falling over.
Use the supplied screws to firmly attach the supplied hooks
(OPTION) to the back of the TV, and use commercially available
cord to fix the TV to rigid components such as walls and columns.
1.2.4 NOTES ON HANDLING
(1) WHEN TAKING UNIT OUT OF A PACKING CASE
When taking the unit out of a packing case, do not grasp
the upper part of the unit. If you take the unit out while
grasping the upper part, the LCD PANEL may be damaged
because of a pressure. Instead of grasping the upper part,
put your hands on the lower backside or sides of the unit.
(2) AS FOR PRESSING OR TOUCHING A SPEAKER
Be careful not to press the opening of the speaker in the
lower part of the unit and around them since the decorative
sheet on the surface of the openings may be deformed.
Ventilation hole
Ventilation hole
150 mm
200 mm
150 mm
200 mm
50 mm
The hook for fall
prevention(option)
Hook
Wall
It fixes in a band.
TV Stand
*Diagram differs from actual appearance.

(No.YA214)1-5
1.3 HANDLING LCD PANEL
1.3.1 PRECAUTIONS FOR TRANSPORTATION
When transporting the unit, pressure exerted on the internal LCD
panel due to improper handling (such as tossing and dropping)
may cause damages even when the unit is carefully packed. To
prevent accidents from occurring during transportation, pay
careful attention before delivery, such as through explaining the
handling instructions to transporters.
Ensure that the following requirements are met during
transportation, as the LCD panel of this unit is made of glass and
therefore fragile:
(1) USE A SPECIAL PACKING CASE FOR THE LCD PANEL
When transporting the LCD panel of the unit, use a special
packing case (packing materials). A special packing case
is used when a LCD panel is supplied as a service spare
part.
(2) ATTACH PROTECTION SHEET TO THE FRONT
Since the front (display part) of the panel is vulnerable,
attach the protection sheet to the front of the LCD panel
before transportation. Protection sheet is used when a LCD
panel is supplied as a service spare part.
(3) AVOID VIBRATIONS AND IMPACTS
The unit may be broken if it is toppled sideways even when
properly packed. Continuous vibration may shift the gap of
the panel, and the unit may not be able to display images
properly. Ensure that the unit is carried by at least 2
persons and pay careful attention not to exert any vibration
or impact on it.
(4) DO NOT PLACE EQUIPMENT HORIZONTALLY
Ensure that it is placed upright and not horizontally during
transportation and storage as the LCD panel is very
vulnerable to lateral impacts and may break. During
transportation, ensure that the unit is loaded along the
traveling direction of the vehicle, and avoid stacking them
on one another. For storage, ensure that they are stacked
in 2 layers or less even when placed upright.
1.3.2 OPTICAL FILTER (ON THE FRONT OF THE LCD PANEL)
(1) Avoid placing the unit under direct sunlight over a
prolonged period of time. This may cause the optical filter
to deteriorate in quality and color.
(2) Clean the filter surface by wiping it softly and lightly with a
soft and lightly fuzz cloth (such as outing flannel).
(3) Do not use solvents such as benzene or thinner to wipe the
filter surface. This may cause the filter to deteriorate in
quality or the coating on the surface to come off. When
cleaning the filter, usually use the neutral detergent diluted
with water. When cleaning the dirty filter, use water-diluted
ethanol.
(4) Since the filter surface is fragile, do not scratch or hit it with
hard materials. Be careful enough not to touch the front
surface, especially when taking the unit out of the packing
case or during transportation.
1.3.3 PRECAUTIONS FOR REPLACEMENT OF EXTERIOR
PARTS
Take note of the following when replacing exterior parts (REAR
COVER, FRONT PANEL, etc.):
(1) Do not exert pressure on the front of the LCD panel (filter
surface). It may cause irregular color.
(2) Pay careful attention not to scratch or stain the front of the
LCD panel (filter surface) with hands.
(3) When replacing exterior parts, the front (LCD panel) should
be placed facing downward. Place a mat, etc. underneath
to avoid causing scratches to the front (filter surface).

1-6 (No.YA214)
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 FEATURES
D.I.S.T. (Digital Image Scaling Technology)
This system uses line interpolation to double the number of
scanning lines and achieve high resolution, flicker-free picture.
SMART CAPTION
Smart caption will appear when you press the MUTING button,
only on channels where the broadcast contains CLOSED
CAPTION information.
SMART SOUND
Decreases high sound levels, giving a regulated sound level.
VIDEO STATUS
Expression of a favorite screen can be chosen by the VIDEO
STATUS function.
[STANDARD ↔DYNAMIC ↔THEATER ↔GAME]
DIGITAL INPUT
Digital-in will display when any picture signal (480i/ 480p,
720p/ 1080i) in Digital-in is displayed.
V-CHIP
Since the V-CHIP is built in, it can choose, view and listen to a
healthy program.
MTS STEREO
The voice multiplex function of the MTS system is built in.
(MTS = Multi channel Television Sound system)
NATURAL CINEMA
Watching the movie or animation, press the Natural Cinema to
adjust the out line of the images to make thin more sharp.
BBE
High definition audio adds natural, clear and extraordinary
sound quality to any program.
VIDEO INPUT LABEL
This function is used to label video input connections for the
onscreen displays.
A.H.S.
Adds a more spacious surround sound. Music gives basic
effect and Movie for more effect.

(No.YA214)1-7
2.2 TECHNICAL INFORMATION
2.2.1 LCD PANEL
This unit uses the flat type panel LCD (Liquid Crystal Display) panel that occupies as little space as possible, instead of the
conventional CRT (Cathode Ray Tube), as a display unit.
Since the unit has the two polarizing filter that are at right angles to each other, the unit adopts "normally black" mode, where light
does not pass through the polarizing filter and the screen is black when no voltage is applied to the liquid crystals.
2.2.1.1 SPECIFICATIONS
The following table shows the specifications of this unit.
2.2.1.2 PIXEL FAULT
There are three pixel faults - bright fault , dark fault and flicker fault - that are respectively defined as follows.
(1) BRIGHT FAULT
In this pixel fault, a cell that should not light originally is lighting on and off.
For checking this pixel fault, input ALL BLACK SCREEN and find out the cell that is lighting on and off.
(2) DARK FAULT
In this pixel fault, a cell that should light originally is not lighting or lighting with the brightness twice as brighter as originally lighting.
For checking this pixel fault, input 100% of each R/G/B colour and find out the cell that is not lighting.
(3) FLICKER FAULT
In the pixel fault, a cell that should light originally or not light originally is flashing on and off.
For checking this pixel fault, input ALL BLACK SCREEN signal or 100% of each RGB colour and find out the cell that is flashing on
and off.
Item Specifications Remarks
Maximum dimensions ( W ×H ×D ) 780mm ×450mm ×51mm
Weight 9.2kg
Effective screen size Diagonal: 800mm (H: 697mm ×V : 392mm) 32V type
Aspect ratio 16 : 9
Drive device / system a-Si-TFT, active matrix system
Resolution Horizontally 1366 ×Vertically 768 ×RGB <W-XGA> 3147264 dots in total
Pixel pitch (pixel size) Horizontally:0.51057mm, Vertically:0.510575mm
Displayed color 16777216 colors 256 colors for R, G, and B
Brightness 500cd/m2
Contrast ratio 800 : 1
Response time 15ms
View angle Horizontally: 170°, Vertically: 170°
Surface polarizer Anti-Glare type, Low reflective coat
Color filter Vertical stripe
Backlight Cold cathode fluorescent lamp ×16
Power supply voltage in LCD 5V
Power supply voltage in inverter 12V
Panel interface system LVDS (Low Voltage Differential Signaling)

1-8 (No.YA214)
2.2.2 MAIN CPU PIN FUNCTION [IC7601 : DIGITAL SIGNAL PWB ASS'Y]
Pin Pin name I/O Function Pin Pin name I/O Function
1 VHOLD1 I Data slice for main screen closed caption 51 NC O Not used
2 HFLT1 I/O LPF for main screen closed caption video input 52 NC O Not used
3 NC O Not used 53 NC O Not used
4 NC O Not used 54 NC O Not used
5 DIGR0 O R [0] for OSD 55 NC O Not used
6 TB1in I AC power for timer clock 56 NC O Not used
7 REMO I Remote control 57 NC O Not used
8 BYTE I Data bus width select [L = 16bit (fixed)] 58 NC O Not used
9 CNVss I CPU programming mode select [Normal = L] 59 NC O Not used
10 DIGG0 O G [0] for OSD 60 NC O Not used
11 DIGB0 O B [0] for OSD 61 NC O Not used
12 RESET I Reset for main CPU [Reset = L] 62 HSYNC I H. sync for OSD
13 Xout O System clock osillation (crystal) : 16MHz 63 NC O Not used
14 Vss - GND 64 VSYNC I V. sync for OSD
15 Xin I System clock osillation (crystal) : 16MHz 65 NC O Not used
16 VccI I 3.3V stand-by power supply 66 NC O Not used
17 OSC1 I Clock for OSD 67 NC O Not used
18 OSC2 O Not used : Clock for OSD 68 NC O Not used
19 INT1 I AV COMPULINK control 69 NC O Not used
20 INT0 I
Request for sub(chassis) CPU communication (serial data) 70 NC O Not used
21 OUT1 O Ys (blanking) for OSD 71 NC O Not used
22 OUT2 O YM (transparence) for OSD 72 NC O Not used
23 NC O Not used 73 NC O Not used
24 NC O Not used 74 NC O Not used
25 NC O Not used 75 NC O Not used
26 NC O Not used 76 NC O Not used
27 CTA2/RTS2 O Not used : Digital tuner control 77 NC O Not used
28 CLK2 O Not used : Digital tuner control 78 NC O Not used
29 RxD2 I Not used : Digital tuner control 79 NC O Not used
30 TxD2 O Not used : Digital tuner control 80 NC O Not used
31 SDA2 I/O Not used 81 NC O Not used
32 DIGR1 O R [1] for OSD 82 NC O Not used
33 DIGG1 O G [1] for OSD 83 NC O Not used
34 DIGB1 O B [1] for OSD 84 WAKE O Reset for sub(chassis) CPU
35 TxD0 I Data receive (serial) for external programming 85 CARD_DET I Not used : Card detection for ATSC digital tuner
36 RxD0 O Data transmission (serial) for external programming 86
POWER_SW I Not used : Power switch (mechanical) detection
37 CLK0 I Clock for external programming 87 NC I/O Data for Inter IC (serial) bus control : memory
38 RTS0 O Busy for external programming [Operation = H] 88 NC O Clock for Inter IC (serial) bus control : memory
39 P5.7 I Not used 89 DIGR2 O R [2] for OSD
40 P5.6 O Not used 90 DIGG2 O G [2] for OSD
41 HOLD I CPU programming mode select [Normal = H] 91 DIGB2 O B [2] for OSD
42 P5.4 O Not used 92 NC O Not used
43 P5.3 O Not used 93 KEY2 I
Key scan data for front control button (MENU/CH+/CH-) KEY2
44 P5.2 O Not used 94 KEY1 I Key scan data for front control button (VOL+/VOL-) KEY1
45 P5.1 O Not used 95 VHOLD2 I Data slice for sub screen closed caption
46 WR O CPU programming mode select [Normal = L] 96 HLF2 I/O LPF for sub screen closed caption video input
47 P4.7 O
Data transmission for sub(chassis) CPU communication (serial) 97 CVIN2 I Video(Y) for sub screen closed caption
48 P4.6 I
Data receive for sub(chassis) CPU communication (serial) 98 TVSETB I Test terminal [L Fixed]
49 P4.5 I Clock for sub(chassis) CPU communication (serial) 99 VCCE I 5V stand-by power supply
50 P4.4 O Not used 100 CVIN1 I Video(Y) for main screen closed caption

(No.YA214)1-9
2.2.3 SUB (CHASSIS) CPU PIN FUNCTION [IC7001 : DIGITAL SIGNAL PWB ASS'Y]
Pin Pin name I/O Function Pin Pin name I/O Function
1 LB_PRO O Not used 51 BS_TXD O
Not used : Data transmission for digital tuner communication
2 P_MU O Picture muting [Muting = H] 52 BS_RXD I Not used : Data receive for digital tuner communication
3 JP_CSB O Not used (NC) 53 NC O Not used (NC)
4 A_MU O Audio muting [Muting = H] 54 VREF+ I 3.3V power supply
5 M_MU O Audio muting (for AUDIO OUT) [Muting = H] 55 PDP_TX O
Data transmission for SUB (DRIVE) CPU communication
6 PC_SEL O Not used : RGB(PC) INPUT select 56 PDP_RX I Data receive for SUB (DRIVE) CPU communication
7 ON_TIMER O POWER INDICATOR (LED) brightness [LOW = L] 57 SDA0 I/O Data for Inter IC (serial) bus : EEP-ROM (IC7002)
8 ILA0 O Not used : LCD back light lighting 58 SCL0 O Clock for Inter IC (serial) bus : EEP-ROM (IC7002)
9 ILA1 O Not used : LCD panel overshoot refresh timing 59 SDA_DVI I/O
Not used : Data for Inter IC (serial) bus for panel communication
10 ILA2 O Not used 60 SCL_DVI O Not used : Clock for Inter IC (serial) bus for panel communication
11 POW_LED O POWER LED lighting [ON = H] 61 AVSS - GND
12 WORD O Not used 62 DIGII_PHOT I Photo sensor for DIGITAL-IN illegal copy protection
13 MI_CK I Clock for SUB (OSD) CPU communication 63 AGC I Not used
14 MI_TX I Data receive for SUB (OSD) CPU communication 64 EXT_YS1 I Not used
15 MI_RX O Data transmission for SUB (OSD) CPU communication 65 EXT_YS2 I Not used
16 MI_REQ O
Data request for SUB (OSD) CPU communication [Request = L] 66 VDD I 3.3V power supply
17 VDD I 3.3V power supply 67 DIGI_PRO O for DIGITAL-IN (HDMI)
18 FOSC O Not used (NC) 68 GCR_RST O Not used (NC)
19 VSS - GND 69 GR_ON O Not used (NC)
20 X1 I Not used : Low speed oscillatior 70 SYNC_SEL O Not used : Sync select for digital tuner
21 X0 O Not used : Low speed oscillatior 71 NC O Not used (NC)
22 VDD I 3.3V power supply 72 NC O Not used (NC)
23 OSC1 I System clock osillation (crystal) : 16MHz 73 SBD5 I/O
Not used : Data for writing on board (connect CN01P : for Frash ROM type)
24 OSC0 O System clock osillation (crystal) : 16MHz 74 SBT5 I Not used : Clock for writing on board (connect CN01P : for Frash ROM type)
25 MODE I Single chip mode 75 NMI I 3.3V power supply
26 BS1.5CTL O Not used : Digital tuner power / reset control 76 COMP I AV COMPULINK lll control
27 A92RES O
Reset for IC1001(3D YC SEP / COLOR DEMODULAT) [Reset = H] 77 REMO I Remote control
28 BS_RST O Not used: Reset for Digital tuner power / reset control 78 VSYNC I V. sync pulse
29 LIP_RST O Not used: Reset for Sound delay (Lip sync) 79 WAKE I Reset for sub(chassis) CPU
30 SOFT_OFF O Not used 80
POWERGOOD I Power error detection [NG = H]
31 VMUTE I No use : Picture muting request from digital tuner 81 NC O Not used (NC)
32 VOUTENB O No use : Video cutoff for digital tuner 82 RST I Reset for MAIN CPU [Reset = L]
33 MDR_CON I No use : System cable connection monitor for PDP 83 VDD I 3.3V power supply
34 AVDD I 3.3V power supply 84 SCL3A O Clock for Inter IC (serial) bus control
35 BS_POW O Not used : Digital tuner power control 85 SDA3A I/O Data for Inter IC (serial) bus control
36
DsyncSW2 O Sync select for DIGITAL-IN [Cotrolled with 99-pin] 86 SCL3B O Clock for Inter IC (serial) bus control
37 LB_POW O Not used : Power control for low bias line 87 SDA3B I/O Data for Inter IC (serial) bus control
38 NC O Not used (NC) 88
DIGI_SYNCSEL O Not used
39 HOTPLUG I
Not used : Video communiation monitor for receiver unit (PDP) 89 DIGI_LRSW O For DIGITAL-IN (HDMI)
40 MECA_SW I Mechanical monitor for POWER switch [Push = L] 90 DIGI_INT I Reset for HDMI process [Reset = ]
41 MAIN_POW O Main power control [ON = L] 91 DVI_RST O Not used : Reset for DVI format conversion
42 MSP_RST O AUDIO OUT output mode select [VARIABLE = L] 92 VSS - GND
43 VREF- I Not used 93 SCL5055 O
Clock for Inter IC (serial) bus : JCC5055 (DIST process)
44 AFT2 I Not used : AFT voltage for sub tuner 94 VFORMATSEL O Not used : Digital tuner clock control
45 AFT1 I AFT voltage for VHF/UHF tuner 95 SDA5055 I/O Data for Inter IC (serial) bus : JCC5055 (DIST process)
46 KEY2 I Key scan data for front switch (MENU/CH+/CH-) 96
OSD_MODE_SEL O Not used : OSD mode select
47 KEY1 I Key scan data for front switch (VOL+/VOL-) 97 NC O Not used (NC)
48 NC O Not used (NC) 98 15K/OTH O Main video select [Fixed H]
49 NC O Not used (NC) 99 DsyncSW1 O Sync select for DIGITAL-IN [Cotrolled with 36-pin]
50 AC_IN I AC power pulse for timer clock 100 57 BUSY I Busy monitor for JCC5057 (New DIST process)

1-10 (No.YA214)
SECTION 3
DISASSEMBLY
3.1 SYSTEM SETTEING
When the DIGITAL SIGNAL PWB is replaced or the DIGITAL
INPUT is not normal, SYSTEM SETTING in the following
procedure.
(1) Set to 0 minutes using the [SLEEP TIMER] key.
(2) Press the [VIDEO STATUS] key and [DISPLAY] key
simultaneously, then enter the SERVICE MODE.
(3) When the Main Menu is displayed, press [2] key to enter
the self check mode.
(4) Turn off the power by pressing the [POWER] key on the
remote control unit.
3.2 DISASSEMBLY PROCEDURE
NOTE:
• Make sure that the power cord is disconnected from the
outlet.
• Pay special attention not to break or damage the parts.
• When removing each board, remove the connectors as
required. Taking notes of the connecting points (connector
numbers) makes service procedure manageable.
• Make sure that there is no bent or stain on the connectors
before inserting, and firmly insert the connectors.
MAIN MENU SCREEN
SELF CHECK MODE SCREEN
LOB OK FAN OK
LOB OK FAN OK
SYNC M:OK S:OK HD:NG
SYNC M:OK S:OK HD:NG
TIM OK
TIM OK
MSM OK DIGI 0000
MSM OK DIGI 0000
MEM OK AVSW OK
MEM OK AVSW OK
YC OK AIO OK
YC OK AIO OK
TUN OK GCR NG 1
TUN OK GCR NG 1
IP OK RGB OK 8
IP OK RGB OK 8
DVI OK HDMI OK
DVI OK HDMI OK
SERVICE MENU
SERVICE MENU
1.ADJUST
1.ADJUST
2.SELF_CHK
2.SELF_CHK
3.I2C STOP
3.I2C STOP
CAUTION AT DISASSEMBLY
• Pay extra attention in the following matter when turning the
power on with the REAR COVER removed.
(1) Prior to disassembly, unplug the power cord from the AC
outlet without fail. (Turn the power "off".)
(2) Make sure that the RECEIVER PWB: IC3102 is
completely covered with black masking tape. (Fig.1)
(3) Make sure to remove the masking of RECEIVER
PWB: IC3102 when attaching the REAR COVER.
(4) Do not turn the power on until the REAR COVER is
attached properly, after the masking is removed.
Fig.1
RECEIVER PWB
IC3101
IC3102
SOLDER SIDE
Masking tape

(No.YA214)1-11
3.2.1 REMOVING THE STAND
(1) Remove the 2 screws [A], Then remove the STAND
COVER.
(2) Remove the 4 screws [B], Then remove the STAND.
3.2.2 REMOVING THE REAR COVER
• Remove the STAND.
(1) Remove the JACK COVER (L/R).
(2) Remove the 7 screws [C], 4 screws [D], and 1 screws [E] .
(3) Remove the REAR COVER.
CAUTION:
• Prior to starting the work, be sure to read the following
written instructions on the CAUTION LABEL attached to the
REAR COVER.
3.2.3 REMOVING THE POWER PWB / REGULATOR PWB
• Remove the STAND.
• Remove the REAR COVER.
(1) Remove the 5 screws [F], Then remove the FAN
BRACKET.
(2) Remove the 1 screw [G], Then remove the POWER CORD
HOLDER.
(3) Remove the POWER CORD from the POWER PWB.
(4) Remove the REGULATOR PWB.
(5) Remove the 5 screw [H], Then remove the POWER PWB.
3.2.4 REMOVING THE ANALOG SYGNAL PWB
• Remove the STAND.
• Remove the REAR COVER.
• Remove the FAN BRACKET.
(1) Remove the 6 screws [J] Then remove the TERMINAL
BASE.
(2) Remove the 6 screws [K] Then remove the ANALOG
SYGNAL PWB.
3.2.5 REMOVING THE FRONT CONTROL PWB CONTROL /
FRONT SENSOR PWB
• Remove the STAND.
• Remove the REAR COVER.
(1) Remove the 2 screws [L], Then remove the CONTROL
KNOB ASSY.
(2) Remove the 2 screws [M], Then remove the FRONT
CONTROL PWB.
(3) Remove the FRONT SENSOR PWB.
3.2.6 REMOVING THE RECEIVER PWB / CONNECTOR
PWB
• Remove the STAND.
• Remove the REAR COVER.
(1) Remove the 4 screws [O] Then remove the RECEIVER
PWB.
(2) Remove the 4 screws [P] Then remove the RECEIVER
PWB BRACKET.
(3) Remove the 2 screws [Q] Then remove the CONNECTOR
PWB.
3.2.7 REMOVING THE DIGITAL SIGNAL PWB
• Remove the STAND.
• Remove the REAR COVER.
(1) Remove the 3 screws [R] and 1 screw [S], Then remove
the TUNER BASE.
(2) Remove the 5 screws [T], Then remove the DIGITAL
SIGNAL PWB.
CAUTION:
Make sure to perform the "SYSTEM SETTING" on page 1-10,
when DIGITAL SIGNAL PWB is replaced.
3.2.8 REMOVING THE SPEAKER
• Remove the STAND.
• Remove the REAR COVER.
(1) Remove the 5 screws [a], Then remove the SPEAKER
BOX.
(2) Remove the 4 screws [b], Then remove the SPEAKER (L /R).
(3) Remove the 4 screws [c], Then remove the DUCT(L/R).
NOTE:
Since the speaker is attached in a certain direction, attach the
speaker in the same correct direction as it has been attached.
3.2.9 REMOVING THE LCD PANEL UNIT
• Remove the STAND.
• Remove the REAR COVER.
(1) Remove the 6 screws [d] and 4 screws [e].
(2) Remove the LCD PANEL UNIT.
(3) Remove the 7 screws [f]. Then, remove the MAIN BASE.
(4) Remove the 2 screws [g]. Then, remove the TOP FRAME.
(5) Remove the 2 screws [h]. Then, remove the BOTTOM
FRAME.

1-12 (No.YA214)
Fig.2
a
C
C
C
D
D
E
D
F
R
T
T
T
S
K
K
K
K
Q
P
O
G
L
M
K
Ha
A
B
JACK COVER
JACK COVER
STAND COVER
STAND
FAN BRACKET
RECEIVER PWB
POWER CORD
POWER CORD
HOLDER
REAR COVER
REGULATOR PWB
POWER PWB
INSULATOR
TERMINAL BASE
ANALOG SIGNAL PWB
CONTROL KNOB ASSY
FRONT SENSOR PWB
FRONT CONTROL PWB
FRONT
DIGITAL SIGNAL PWB
RECEIVER PWB
BRACKET
CONNECTOR PWB
TUNER BASE

(No.YA214)1-13
Fig.3
BOTTOM FRAME
TOP FRAME
MAIN BASE
FRONT
a
g
g
d
SPEAKER BOX
LCD PANEL UNIT
f
f
e
d
h
h
e
FRONT PANEL
b
DUCT
DUCT SHEET
b
DUCT
DUCT SHEET
c
SPEAKER
c
SPEAKER

1-14 (No.YA214)
3.3 MEMORY IC REPLACEMENT
• This model uses the memory IC.
• This memory IC stores data for proper operation of the video and drive circuits.
• When replacing, be sure to use an IC containing this (initial value) data.
3.3.1 MEMORY IC REPLACEMENT PROCEDURE
1. Power off
Switch off the power and disconnect the power plug from the AC outlet.
2. Replace the memory IC
Be sure to use the memory IC written with the initial setting values.
3. Power on
Connect the power plug to the AC outlet and switch on the power.
4. Receiving channel setting
Refer to the OPERATING INSTRUCTIONS and set the receive channels (Channels Preset) as described.
5. User setting
Check the user setting items according to the given in page later. Where these do not agree, refer to the OPERATING
INSTRUCTIONS and set the items as described.
6. SERVICE MODE setting
Verify what to set in the SERVICE MODE, and set whatever is necessary (Fig.1). Refer to the SERVICE ADJUSTMENT for setting.
3.3.2 SERVICE MODE SETTING
SERVICE MODE SCREEN
Fig.1
SETTING ITEM
MAIN MENU SCREEN
ADJUSTMENT MODE SCREEN
S001 PREPARE 000
S001 PREPARE 000
NTSC3 1409 DYN H
NTSC3 1409 DYN H
SERVICE MENU
SERVICE MENU
1.ADJUST
1.ADJUST
2.SELF_CHK
2.SELF_CHK
3.I2C STOP
3.I2C STOP
Setting items Settings Item No.
Video sytetem setting Adjust S001 to S039
Audio sytetem setting Adjust T001 to T010
Panel control sytetem setting Fixed P001 to P010
Drive sytetem setting Fixed D001 to D187
Main cpu system setting Fixed Z001 to Z010

(No.YA214)1-15
3.3.3 SETTINGS OF FACTORY SHIPMENT
3.3.3.1 BUTTON OPERATION 3.3.3.2 REMOTE CONTROL DIRECT OPERATION
3.3.3.3 REMOTE CONTROL MENU OPERATION
1. PICTURE ADJUST
Customers can adjust the picture setting of menu screen as their
own like but the picture standard value during factory shipment is as
below.
< NTSC MODE >
< HD MODE >
2. SOUND ADJUST
3. CLOCK / TIMERS
4. INITIAL SETUP
Setting item Setting position
POWER Off
CHANNEL CABLE-02
VOLUME 10
Setting item Setting position
INPUT TV
CHANNEL CABLE-02
VOLUME 10
MUTING OFF
DISPLAY OFF
ASPECT NTSC PANORAMA
HD FULL
SLEEP TIMER OFF
THEATER PRO OFF
VIDEO STATUS DYNAMIC
SOUND
EFFECT
A.H.S OFF
BBE ON
SMART SOUND OFF
A.H.B OFF
Setting item DYNAMIC STANDARD GAME THEATER
PICTURE 00 00 00 00
BRIGHT 00 00 00 00
COLOR [phone]
TINT 00 00 00 00
DETAIL +05 00 00 00
ENERGY SAVER MODE +30 +20 00 00
COLOR TEMPERATURE HIGH LOW HIGH HIGH
DIG. NOISE CLEAR OFF OFF OFF OFF
NATURAL CINEMA AUTO AUTO AUTO AUTO
COLOR MANAGEMENT ON ON ON ON
DYNAMIC GAMMA ON ON ON ON
Setting item
DYNAMIC STANDARD GAME THEATER
PICTURE 00 00 00 00
BRIGHT 00 00 00 00
COLOR +05 00 -10 00
TINT 00 00 00 00
DETAIL +05 00 00 00
ENERGY SAVER MODE +30 +20 00 00
COLOR TEMPERATURE HIGH LOW HIGH HIGH
DIG. NOISE CLEAR OFF OFF OFF OFF
NATURAL CINEMA AUTO AUTO AUTO AUTO
COLOR MANAGEMENT ON ON ON ON
DYNAMIC GAMMA ON ON ON ON
Setting item Setting position
BASS 00
TREBLE 00
BALANCE 00
MTS STEREO
Setting item Setting position
SET CLOCK OFF
ON / OFF TIMER OFF
Setting item Setting position
DIGITAL-IN
SIZE 1
DIGITAL-AUDIO DIGITAL
NOISE MUTING ON
FRONT PANEL LOCK OFF
V1 SMART INPUT OFF
VIDEO INPUT LABEL All blank
POSITION ADJUSTMENT Center
POWER INDICATOR OFF
LANGUAGE ENG.
CLOSED CAPTION OFF
AUTO SHUT OFF OFF
XDS ID OFF
V-CHIP OFF
AUTO DEMO OFF

1-16 (No.YA214)
3.4 REPLACEMENT OF CHIP COMPONENT
3.4.1 CAUTIONS
(1) Avoid heating for more than 3 seconds.
(2) Do not rub the electrodes and the resist parts of the pattern.
(3) When removing a chip part, melt the solder adequately.
(4) Do not reuse a chip part after removing it.
3.4.2 SOLDERING IRON
(1) Use a high insulation soldering iron with a thin pointed end of it.
(2) A 30w soldering iron is recommended for easily removing parts.
3.4.3 REPLACEMENT STEPS
1. How to remove Chip parts
[Resistors, capacitors, etc.]
(1) As shown in the figure, push the part with tweezers and
alternately melt the solder at each end.
(2) Shift with the tweezers and remove the chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply extra solder to each lead.
(2) As shown in the figure, push the part with tweezers and
alternately melt the solder at each lead. Shift and remove
the chip part.
NOTE :
After removing the part, remove remaining solder from the
pattern.
2. How to install Chip parts
[Resistors, capacitors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder. Then heat and melt the solder at both ends of the
chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder.
(3) First solder lead Aas indicated in the figure.
(4) Then solder leads Band C.
SOLDER SOLDER
A
B
C
A
B
C

(No.YA214)1-17
SECTION 4
ADJUSTMENT
4.1 ADJUSTMENT PREPARATION
(1) There are 2 ways of adjusting this TV : One is with the
REMOTE CONTROL UNIT and the other is the
conventional method using adjustment parts and
components.
(2) The adjustment using the REMOTE CONTROL UNIT is
made on the basis of the initial setting values. The
setting values which adjust the screen to the optimum
condition can be different from the initial setting
values.
(3) Make sure that connection is correctly made AC to AC
power source.
(4) Turn on the power of the TV and measuring instruments for
warning up for at least 30 minutes before starting
adjustments.
(5) If the receive or input signal is not specified, use the most
appropriate signal for adjustment.
(6) Never touch the parts (such as variable resistors,
transformers and condensers) not shown in the adjustment
items of this service adjustment.
4.2 PRESET SETTING BEFORE ADJUSTMENTS
Unless otherwise specified in the adjustment items, preset the
following functions with the REMOTE CONTROL UNIT.
4.3 MEASURING INSTRUMENT AND FIXTURES
• Oscilloscope
• Signal generator (Pattern generator)
[NTSC / 525i / 525p / 750p / 1125i / DIGITAL]
• TV audio multiplex signal generator
• Remote control unit
4.4 ADJUSTMENT ITEMS
VIDEO CIRCUIT
• 525i A-D OFFSET adjustment
• 1125i BRIGHTNESS adjustment
• 1125i A-D OFFSET adjustment
• SUB SCREEN A-D OFFSET adjustment
• WHITE BALANCE (HIGHLIGHT) adjustment
MTS CIRCUIT
• MTS INPUT LEVEL adjustment
• MTS SEPARATION adjustment
4.5 BASIC OPERATION OF SERVICE MODE
4.5.1 HOW TO ENTER THE SERVICE MODE
(1) Set to 0 minutes using the [SLEEP TIMER] key.
(2) Press the [VIDEO STATUS] key and [DISPLAY] key
simultaneously, then enter the SERVICE MODE mode.
(3) When the MAIN MENU SCREEN is displayed, press [1]
key to enter the adjustment mode.
NOTE:
• Before entering the SERVICE MODE, confirm that the
setting of TV / CATV switch of the REMOTE CONTROL
UNIT is at the "TV" side and the setting of VCR / DVD switch
is at the "VCR" side. If the switches have not been properly
set, you cannot enter the SERVICE MODE.
• When a number key other than the [1] to [3] key is pressed
in the MAIN MENU SCREEN, the other relevant screen may
be displayed.
This is not used in the adjustment procedure. Press the
[MENU] key to return to the MAIN MENU SCREEN.
4.5.2 HOW TO EXIT THE SERVICE MODE
Press the [ BACK ] key to exit the Service mode.
Setting item Settings
VIDEO STATUS STANDARD
BRIGHT / CONTRAST / COLOR / TINT 00
COLOR TEMPERATURE LOW
DIG. NOISE CLEAR OFF
COLOR MANAGEMENT ON
NATURAL CINEMA OFF
TREBLE / BASS / BALANCE 00
BBE OFF
A.H.S OFF
A.H.B OFF
ASPECT FULL
SERVICE MENU
SERVICE MENU
1.ADJUST
1.ADJUST
2.SELF_CHK
2.SELF_CHK
3.I2C STOP
3.I2C STOP
MAIN MENU SCREEN
ADJUSTMENT MODE SCREEN
S001 PREPARE 000
S001 PREPARE 000
NTSC3 1409 DYN H
NTSC3 1409 DYN H

1-18 (No.YA214)
4.5.3 DESCRIPTION OF STATUS DISPLAY
(1) SIGNAL SYSTEM
The signal displayed on the screen is displayed.
(2) SCREEN MODE
State of the SCREEN SIZE or MULTI PICTURE is displayed.
SINGLE SCREEN
MULTI SCREEN
(3) VIDEO STATUS
(4) WHITE BALANCE
(5) SETTING ITEM NAME
Setting item name are displayed. The setting item numbers to
be displayed are listed below.
(6) SETTING ITEM NO.
Setting item numbers are displayed. For the setting item
names to be displayed, refer to "Initial setting value of
adjustment mode".
(7) SETTING VALUE (DATA)
The SETTING VALUE is displayed.
4.5.4 CHANGE AND MEMORY OF SETTING VALUE
SELECTION OF SETTING ITEM
• [CHANNEL (+/-)] key.
For scrolling up / down the setting items.
• [SLEEP TIMER] key.
For switching to next items.
CHANGE OF SETTING VALUE (DATA)
• [VOLUME (+/-)] key.
For scrolling up / down the setting values.
MEMORY OF SETTING VALUE (DATA)
Changed setting value is memorized by pressing [MUTING]
key.
4.5.5 SERVICE MODE SELECT KEY LOCATION
NTSC3 : 525i (Composite / S-video input)
525I : 525i (Component input)
525P : 525p
1125I6 : 1125i
750P : 750p
H525I : HDMI 525i
H525P : HDMI 525p
H125I6 : HDMI 1125i
H750P : HDMI 750p
1409 : FULL
1609 : PANORAMA, HD PANORAMA
1609S : CINEMA, CINEMA ZOOM
FULL : REGULAR
M12 : FREEZE screen
FRZ : TWIN screen
STD : INDEX screen
STD : STANDARD
DYN : DYNAMIC
TH : THEATER
GAME : GAME
H:HIGH
M:LOW
Item No. Setting item
S001 to S039 Video sytetem setting
T001 to T010 Audio sytetem setting
P001 to P010 Panel control sytetem setting
D001 to D187 Drive sytetem setting
Z001 to Z010 Main cpu system setting
SIGNAL SYSTEM SCREEN MODE VIDEO STATUS
SETTING VALUE (DATA)SETTINGITEM No. SETTING ITEM WHITE BALANCE
S001 PREPARE 000
S001 PREPARE 000
NTSC3 1409 DYN H
NTSC3 1409 DYN H
S001... ↔T001... ↔P001... ↔D001... ↔Z001...
S001 →T001 →P001 →D001 →Z001
POWER
VCR/DVD
switch
NUMBER
DISPLAY
TV/CATV
switch
MENU
SLEEP
TIMER
VIDEO
STATUS
MUTING
RM-C1257G
CHANNEL +
CHANNEL -
VOLUME +
VOLUME - BACK

(No.YA214)1-19
4.6 INITIAL SETTING VALUES IN THE SERVICE MODE
• Perform fine-tuning based on the "initial values" using the remote control when in the Service mode.
• The "initial values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved
may be different from the default values. But, don't change the values that are not written in "ADJUSTMENT PROCEDURE". They
are fixed values.
4.6.1 VIDEO SYSTEM SETTING 4.6.2 AUDIO SYSTEM SETTING
4.6.3 PANEL CONTOROL SYSTEM SETTING (*Fixed values)
4.6.4 DRIVE SYSTEM SETTING (*Fixed values)
Item No. Item name Variable range Setting value
S001 PREPARE 000 to 031 000
S002 NTSC BL 000 to 015 000
S003 NTSC CNT 000 to 255 036
S004 NT CR OF 000 to 015 006
S005 NT CB OF 000 to 015 006
S006 525i BL 000 to 015 000
S007 525i CNT 000 to 255 044
S008 5i CB OF 000 to 015 000
S009 5i CR OF 000 to 015 000
S010 5i CR GN 000 to 015 006
S011 5i CB GN 000 to 015 006
S012 HD BL 000 to 063 056
S013 HD CB OF 000 to 063 055
S014 HD CR OF 000 to 063 058
S015 RT CONT 000 to 015 007
S016 RT CB OF 000 to 015 005
S017 RT CR OF 000 to 015 007
S018 RT CL GA 000 to 015 012
S019 PC CL MB 000 to 007 000
S020 PC CL LB 000 to 031 000
S021 PC CL MR 000 to 071 000
S022 PC CL LR 000 to 031 000
S023 (Not display) 000 to 255 000
S024 (Not display) 000 to 255 000
S025 (Not display) 000 to 255 000
S026 (Not display) 000 to 255 000
S027 (Not display) 000 to 255 000
S028 (Not display) 000 to 255 000
S029 (Not display) 000 to 255 000
S030 R DRIVE 000 to 255 130
S031 G DRIVE 000 to 255 133
S032 B DRIVE 000 to 255 090
S033 (Not display) 000 to 255 000
S034 (Not display) 000 to 255 000
S035 (Not display) 000 to 255 000
S036 (Not display) 000 to 255 000
S037 (Not display) 000 to 255 000
S038 (Not display) 000 to 255 000
S039 ILA COM +00 to +01 +00
Item No. Item name Variable range Setting value
T001 IN LEVEL 000 to 255 255
T002 LOW SEP 000 to 255 199
T003 HIGH SEP 000 to 255 255
T004 AFC 000 to 255 000
T005 (Not display) 000 to 255 000
T006 ATT V ON 000 to 001 000
T007 ATT U ON 000 to 001 000
T008 ATT C ON 000 to 001 000
T009 (Not display) 000 to 255 000
T010 (Not display) 000 to 255 000
Item No. Item name Variable range Setting value
P001 TM HOR H 00 to FF 00
P002 TM HOR L 00 to FF 00
P003 TM MIN 00 to FF 00
P004 TEMP0 000 to 255 000
P005 (Not display) 000 to 255 000
P006 (Not display) 000 to 255 000
P007 (Not display) 000 to 255 000
P008 (Not display) 000 to 255 000
P009 (Not display) 000 to 255 000
P010 (Not display) 000 to 255 000
Item No. Item name Variable range Setting value
D001 SLV GN 00 to 3F 15
D002 SLVH GN 00 to 3F 13
D003 SLH GN 00 to 3F 15
D004 SLV Pf 00 to 03 01
D005 SLH Pf H 00 to 01 01
D006 SLH Pf L 00 to 03 01
D007 SL EGCON 00 to 3F 08
D008 SL EGONF 00 to 01 01
D009 SL CRGON 00 to 3F 06
D010 SL CRGON 00 to 01 01
D011 SL ON OF 00 to 01 01
D012 SV GN 00 to 3F 18
D013 SVH GN 00 to 3F 1A
D014 SH GN 00 to 3F 1C
D015 SV Pf 00 to 03 00
D016 SV PfH 00 to 01 01

1-20 (No.YA214)
D017 SV PfL 00 to 03 00
D018 SYL CON 00 to 3F 30
D019 SYL CONF 00 to 01 01
D020 SYH CON 00 to 3F 00
D021 SYH CONF 00 to 01 01
D022 SC CON 00 to 3F 1A
D023 SC CNONF 00 to 01 01
D024 SPM BLC 00 to 3F 0A
D025 SPM BLCO 00 to 01 01
D026 SLIM 00 to 3F 20
D027 SLIMONF 00 to 01 01
D028 SCRG 00 to 3F 24
D029 SRGONF 00 to 01 01
D030 S ONF 00 to 01 01
D031 pb GN 00 to 3F 15
D032 pb PfH 00 to 01 01
D033 pb PfL 00 to 03 00
D034 pb CRG 00 to 3F 04
D035 pb CRGON 00 to 01 01
D036 pb ONF 00 to 01 01
D037 pr GN 00 to 3F 15
D038 pr PfH 00 to 01 01
D039 pr PfL 00 to 03 00
D040 pr CRG 00 to 3F 05
D041 pr CRGON 00 to 01 01
D042 pr ONF 00 to 01 01
D043 ENH ONF 00 to 01 01
D044 (Not display) 00 to FF 00
D045 (Not display) 00 to FF 00
D046 (Not display) 00 to FF 00
D047 (Not display) 00 to FF 00
D048 (Not display) 00 to FF 00
D049 (Not display) 00 to FF 00
D050 (Not display) 00 to FF 00
D051 (Not display) 00 to FF 00
D052 (Not display) 00 to FF 00
D053 (Not display) 00 to FF 00
D054 (Not display) 00 to FF 00
D055 (Not display) 00 to FF 00
D056 (Not display) 00 to FF 00
D057 (Not display) 00 to FF 00
D058 (Not display) 00 to FF 00
D059 (Not display) 00 to FF 00
D060 (Not display) 00 to FF 00
D061 (Not display) 00 to FF 00
D062 (Not display) 00 to FF 00
Item No. Item name Variable range Setting value
D063 (Not display) 00 to FF 00
D064 (Not display) 00 to FF 00
D065 (Not display) 00 to FF 00
D066 (Not display) 00 to FF 00
D067 (Not display) 00 to FF 00
D068 (Not display) 00 to FF 00
D069 (Not display) 00 to FF 00
D070 (Not display) 00 to FF 00
D071 (Not display) 00 to FF 00
D072 (Not display) 00 to FF 00
D073 (Not display) 00 to FF 00
D074 (Not display) 00 to FF 00
D075 (Not display) 00 to FF 00
D076 (Not display) 00 to FF 00
D077 (Not display) 00 to FF 00
D078 (Not display) 00 to FF 00
D079 (Not display) 00 to FF 00
D080 (Not display) 00 to FF 00
D081 (Not display) 00 to FF 00
D082 (Not display) 00 to FF 00
D083 (Not display) 00 to FF 00
D084 (Not display) 00 to FF 00
D085 (Not display) 00 to FF 00
D086 (Not display) 00 to FF 00
D087 (Not display) 00 to FF 00
D088 (Not display) 00 to FF 00
D089 (Not display) 00 to FF 00
D090 (Not display) 00 to FF 00
D091 (Not display) 00 to FF 00
D092 (Not display) 00 to FF 00
D093 (Not display) 00 to FF 00
D094 (Not display) 00 to FF 00
D095 (Not display) 00 to FF 00
D096 (Not display) 00 to FF 00
D097 (Not display) 00 to FF 00
D098 (Not display) 00 to FF 00
D099 (Not display) 00 to FF 00
D101 (Not display) 00 to FF 00
D102 (Not display) 00 to FF 00
D103 (Not display) 00 to FF 00
D104 (Not display) 00 to FF 00
D105 (Not display) 00 to FF 00
D106 (Not display) 00 to FF 00
D107 (Not display) 00 to FF 00
D108 (Not display) 00 to FF 00
D109 (Not display) 00 to FF 00
Item No. Item name Variable range Setting value
