JVC LT-43HW95U User manual

LED TV
Operating Instructions
456
7 8 9
0
OK
EPG LIST
23
INFOINFO
AUDIO
SOURCE
QMENU
LT-43HW95U LT-49HW95U
Downloaded from www.vandenborre.be

Downloaded from www.vandenborre.be

Warnings
This appliance is intended for domestic household use only and should not be used for any other
purpose or on any other application, such as for non-domestic use or use in a commercial
environment.
This apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
The ventilation should not be impeded by covering the ventilation openings with items, such as
newspapers, table-cloths, curtains, etc.
This apparatus is not suitable for use in a tropical climate.
Ventilation
Allow at least a 10 cm gap all around the product.
To protect the environment, use local recycling facilities for battery disposal.
Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
Attention should be drawn to the environmental aspects of battery disposal. Don’t throw used
batteries in dustbin. Please contact your retailer in order to protect the environment.
Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
License Information
[European Union]
Dear Customer,
This apparatus is in conformance with the valid European directives and
standards regarding electromagnetic compatibility and electrical safety.
European representative of the manufacturer is:
Darty Holdings SAS © 14 route d’Aulnay 93140 Bondy, France
DVB and the DVB logo are trademarks of the DVB project.
Manufactured under license from Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo
States and other countries.
are trademarks or registered trademarks or HDMI Licensing Administrator, Inc. in the United
Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories.
1
Downloaded from www.vandenborre.be

EN Contents
Warnings…………………………………………………………….………..…..……..1
Safety Instructions.…………....………………………………....……………....... 7
Assembling the stand.…………………………………………....……………....... 9
Cable Installation…………................................................................................13
Using the remote control……………………………………………………...........14
Battery replacement……………………………..………...................................14
Getting Started…………………………...………………………..……..………....14
Installing Batteries in the Remote Control………………………………..…........14
Remote Control…………………………..……………………………………....…15
Turning on and off the TV.................................................................................17
Programme Selection.......................................................................................18
Basic Operation..................................................................................................17
First Time Setup...............................................................................................17
Volume adjustment...........................................................................................18
Changing the input source………………………………………………………….18
Menu Operation...................................................................................................19
How to Navigate Menus....................................................................................19
Configuring the Channel menu.........................................................................20
Configuring the Picture menu...........................................................................24
Configuring the Sound menu............................................................................25
Configuring the Option menu………………………………………………………29
Configuring the Lock menu………………………………………………..……… 33
Programme Guide............................................................................................34
Channel List / Favorite List..............................................................................35
Applications......................................................................................................40
Q.MENU.........………………………………………………………………………..35
Media Playback................................................................................................ 36
Teletext………………………………………………………………………………....41
Troubleshooting Guide………………………………………………………….......42
Using the teletext feature…………………........................................................41
Troubleshooting…………….…………………………………………………........42
Main Unit Control…………………………….…………………..……..……………. 11
Front Panel…..……………….…………………………………………….……...11
Back v iew con trol an d sock ets. .…… ……… ……… ….… ………. ...… ……...….12.
Connection and setup…………………...…………….........................................13
Network Function Operation Instruction………………………………....……....26
Configuring the Timer menu………………………………………………..…..… 34
Home Page..........................................................................................................36
2
Maintenance……………………………………………………………………....…46
Product fiche...…………………………………………………..…………...............47
Downloaded from www.vandenborre.be

Warnings
DEAR CUSTOMER:
Before operating, please read all these safety and operating instructions completely and
then retain this manual for future reference.
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product.
REGULATORY INFORMATION
This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communication. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
a. Relocate the receiving antenna.
b. Increase the separation between the equipment and receiver.
c. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
d. Consult the dealer or experienced radio/TV technician for help.
CAUTION
※Do not attempt to modify this product in any way without written authorization from
supplier. Unauthorized modification could void the user's authority to operate this
product.
※Figures and illustrations in this User Manual are provided for reference only and
may differ from actual product appearance. Product design and specifications may be
changed without notice.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the products enclosure that may be of sufficient magnitude to constitute
a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
3
Downloaded from www.vandenborre.be

Warnings
IMPORTANT WARNINGS AND CAUTIONS!
Electrical energy can perform many useful functions, but it can also cause
personal injuries and property damage if improperly handled. This product has
been engineered and manufactured with the highest priority on safety. BUT
IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE
HAZARD. In order to prevent potential danger, please observe the following
instructions when installing, operating and cleaning the product.
1. Attachments---Only use attachments/accessories specified by the manufacturer. Do
not use attachments not recommended by the manufacturer. Use of improper
attachments can result in accidents.
2. Water--- To reduce the risk of fire or electric shock, do not expose this apparatus to rain
or moisture. The apparatus shall not be exposed to dripping or splashing and that
objects filled with liquids, such as vases, shall not be placed on apparatus.
3. Fire or explosion---Do not use or store flammable or combustible materials near the
unit. Doing so may result in fire or explosion. Do not place any naked flame sources,
such as lit candles, cigarettes or incense sticks on top of the TV set.
Warning: To prevent the spread of fire, keep candles or other open flames away from
this product at all times.
4. Ventilation---When you install your TV, maintain a distance of at least 4 inches
between the TV and other objects (walls, cabinet sides, etc.) to ensure proper
ventilation. Failing to maintain proper ventilation may result in a fire or a problem with
the product caused by an increase in its internal temperature.
5. This equipment is a Class Ⅱor double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical earth.
6. Power source---This product is intended to be supplied by a listed power supply
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company.
7. Overloading---Do not overload wall outlets, extension cables, or convenience
receptacles on other equipment as this can result in a risk of fire or electric shock.
8. Voltage---Before installing this TV set, make sure your outlet voltage corresponds to
the voltage stated on the appliance rating label.
9. Power plug --- Do not defeat the safety purpose of the polarized or grounding-type
plug. Most appliances recommend they be placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that appliance and has no additional outlets or
branch circuits.
To prevent possible hearing damage, do not listen at high volume levels for
long periods
4
Downloaded from www.vandenborre.be

Warnings
10. The MAINS plug of the apparatus is used as the disconnect device, the disconnect
device shall remain readily operable.
11. Wall mounting---When mounting the product on a wall, be sure to install the product
according to the method recommended by the manufacturer. This is a safety feature.
12. Stand--- Do not place the product on an unstable trolley, stand, tripod or table. Placing
the product on an unstable base can cause the product to fall, resulting in serious
personal injuries as well as damage to the product.
Always place the TV on furniture that can safely support the TV. Make sure the ends of
the TV do not overhang the edge of the supporting furniture.
13. Entering of objects and liquids---Never insert an object into the product through
vents or openings. High voltage flows in the product, and inserting an object can cause
electric shock and/or short internal parts. For the same reason, do not spill water or
liquid on the product.
14. Damage requiring service--- This unit should only be serviced by an authorized and
properly trained technician. Opening the cover or other attempts by the user to service
this unit may result in serious injury or death from electrical shock, and may increase
the risk of fire.
15. Replacement parts---In case the product needs replacement parts, make sure that the
service person uses replacement parts specified by the manufacturer, or those with the
same characteristics and performance as the original parts. Use of unauthorized parts
can result in fire, electric shock and/or other danger.
16. Safety checks---Upon completion of service or repair work, request the service
technician to perform safety checks to ensure that the product is in proper operating
condition.
17. Children ---Do not allow young children to play with the plastic bag that came with the
television when you unpacked it. Failure to do so can result in suffocation, causing
injury.
18. Batteries---The batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
19. Antenna ---Install the antenna away from high-voltage power lines and communication
cables and make sure it is installed securely. If the antenna touches a power line,
contact with the antenna could result in fire, electric shock or serious injury.
20. Panel protection--- The panel used in this product is made of glass. Therefore, it can
break when the product is dropped or impacted upon by other objects. Be careful not to
be injured by broken glass pieces in case the panel breaks.
21. Operating Temperature: 5℃to 35℃Operating Humidity: ≤80%
Storage Temperature: -15℃to 45℃Storage Humidity: ≤90%
5
Downloaded from www.vandenborre.be

Warnings
WARNING
Never place a television set in an unstable location. A television set may fall, causing
serious personal injury or death. Many injuries, particularly to children, can be
avoided by taking simple precautions such as:
Using cabinets or stands recommended by the manufacturer of the television set.
Only using furniture that can safely support the television set.
Ensuring the television set is not overhanging the edge of the supporting furniture.
Not placing the television set on tall furniture (for example, cupboards or bookcases)
without anchoring both the furniture and the television set to a suitable support.
Not placing the television set on cloth or other materials that may be located between
the television set and supporting furniture.
Educating children about the dangers of climbing on furniture or reach the television
set or its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.
6
Downloaded from www.vandenborre.be

Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
7. Do not block any ventilation openings.
Ventilation should not be impeded by
covering the ventilation openings with
items such as newspapers, table-cloths,
curtains etc.
5. Do not use this apparatus near water. 8. Do not install near any heat source such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
6. Clean only with a dry cloth. Unplug this
product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol
cleaners.
9. Do not defeat the safety purpose of the
polarized or grounding type plug. A
polarized plug has two blades with one
wider than other. A grounding type plug
has two blades and a third grounding
prong. The wide blade or the third prong is
provided for your safety. When the
provided plug does not fit into your outlet,
consult an electrician for replacement of
the obsolete outlet.
7
Downloaded from www.vandenborre.be

Safety Instructions
10. Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
13. For added protection for this product
during a lightning storm, or when it is left
unattended and unused for long periods
of time, unplug it from the wall outlet and
disconnect the cable system.
11. Educate children about the dangers of
climbing on furniture to reach TV
controls.
14. Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
12. When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over. Sudden
stops, excessive force and uneven floor
surfaces can cause the product to fall
from the trolley.
NOTE:
※Disposal of this product must be carried out in accordance to the regulations of your local
authority. Do not dispose of this product with general household waste disposal.
※Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue,
green or red. Please note that this does not affect the performance of your product.
※Avoid touching the screen or holding your finger(s) against it for long periods of time.
Doing so may produce some temporary distortion effect on the screen.
※It is not recommended to keep a certain still image displayed on the screen for a long time
as well as displaying extremely bright images on screen, reduce the ‘brightness’ and
‘contrast’ when displaying still images.
8
Downloaded from www.vandenborre.be

Assembling the stand
Stand Installation
NOTE:
Assure the AC cord is not connected to an AC outlet.
Before beginning this process, make sure that you have a clean, safe, and cushioned
space to work at to avoid any damage to the unit.
Do not touch or press the TV screen, the glass might break under pressure.
1. Carefully place the TV screen face-down on a clean, cushioned surface.
2. Insert and secure the stands (R and L) with 2 screws (supplied) each side as shown.
3. be sure to follow the above instructions. Insufficient tightening or incorrect installation
of the stand will not support your TV correctly, and could result in damage or injury from
tip-over.



9
Downloaded from www.vandenborre.be

Wall Mounting the TV
cables, gas and water pipes in the wall. In case of any doubt, please contact a qualified
installer.
Contact the store where you purchased the product for information on where to
purchase the VESA kit.
Assembling the stand
Mount the TV according to the instructions supplied with the kit. Beware of electrical
The TV can be mounted on a wall using a 300mm x300mm VESA kit sold separately.
10
Downloaded from www.vandenborre.be

Main Unit Control
POWER / MENU Button:
CHANNEL buttons: /
(CURSOR buttons: ▲/▼
in menu mode)
VOLUME buttons: +/-
(CURSOR buttons: ▶/◀
in menu mode)
Opens and closes the menu.
Turns on and off the TV.
Control Key
NOTE: Keypad may change model to model.
Front Panel
Remote sensor
Power Indicator
11
Downloaded from www.vandenborre.be

Main Unit Control
2
134
5
6
7
8
9
7
No. Name Description
1 LAN Local area network (LAN) port. Connect a LAN
cable to this port to connect to the Network.
2
HDMI1/2/3
HDMI (High-Definition Multimedia Interface) input.
3 SCART SCART connector.
4 ANT1/2 Connection of the external antenna.
5
COAXIAL Connect to an external digital audio device.
6 Earphones/headphones jack.
7 USB2.0
USB port. Connector a USB Storage device for
multimedia file playback.
8
AV IN
AV audio/video signal input.
9 COMMON INTERFACE COMMON INTERFACE slot.
NOTE: Input / Output connectivity options may change from model to model.
Back view controls and sockets
12
Downloaded from www.vandenborre.be

Connection and setup
Cable Installation
Before the installation and use, please read carefully the relevant content in “Warning
and Safety instructions”.
Take out the TV from the wrapping package and put it in a drafty and flat place.
NOTE:
When unplugging the power cable or signal cable, please hold the plug (the insulated
part); do not draw the body of the cable.
•LAN: Use a network cable to connect the interface and the broadband network
interface.
•HDMI1/2/3: (High-Definition Multimedia Interface) it provides an uncompressed digital
connection that carries both video and audio data by way of an integrated mini-plug
cable.
NOTE:
While connecting the HDMI, please aim at carefully, do not insert overexerted, for
fear the pin might be broken.
•SCART: Connect the TV set with an external device using the SCART socket.
•ANT: Connect the antenna to TV via coaxial cable on ANT jack of the back panel.
•COAXIAL: Send the TV's audio signal to external audio equipment via the Digital
Audio Output port.
•HEAD PHONE ( ): Connect a 3.5mm headphone for personal audio.
•USB2.0: Connect a USB Storage device and multimedia file playback.
•AV IN: The output AV terminal of DVD can be connected with the AV input port of the
TV through AV cable.
NOTE:
If AV works as mini terminal, please choose to use a one-to-three audio & video
cable.
•COMMON INTERFACE: Please insert CI card into the CI slot according to the arrow
on the CI card.
NOTE:
The range of power input for the TV is 100-240V~ 50/60Hz; do not connect the TV
power input port with the power cable out of the above range.
Please hold the insulated part of the plug when you are unplugging the power cable,
do not touch directly the metallic part of the cable.
Before connecting to an external device, please firstly make sure that the TV set and
the external device have been turned off. When connecting, please make reference to
the interface name and the interface color to connect the signal cable.
The unit has a built-in wireless network card, and can directly receive network
signals from wireless router through WIFI antenna.
When you plug or unplug the power cable, you must make sure that the TV, computer
or other equipment have been already shut down.
HDMI 1 (supports ARC function)
ARC: (Audio Return Channel) Adopted in TV output of digital audio, can be connected
to the device supporting ARC, transmit the TV sound to the device.
13
Downloaded from www.vandenborre.be

Getting Started
Using the Remote Control
When using the remote control, aim it at remote sensor on the television. If there is an
object between the remote control and the remote sensor on the unit, the unit may not
operate.
•Point the remote control at the REMOTE SENSOR located on the television.
•When using this television in a very brightly lit area, the infrared REMOTE CONTROL
SENSOR may not work properly.
•The recommended effective distance for using the remote control is about 7 metres.
Installing Batteries in the Remote Control
1. Open the cover at the back of the 2. Install two AAA size batteries. Make sure to
remote control. match the “+” and “-” ends of the batteries
with the diagram inside the compartment.
3. Replace the cover.
Battery Replacement
You will need to install the batteries into the remote control to make it operate following
the instruction below.
When the batteries become weak, the operating distance of the remote control will be
greatly reduced and you will need to replace the batteries.
Notes on Using Batteries:
The use of the wrong type of batteries may cause chemical leakage and/or explosion.
Please note the following:
•Always ensure that the batteries are inserted with the + and - terminals in the correct
direction as shown in the battery compartment.
•Different types of batteries have different characteristics. Do not mix different types.
•Do not mix old and new batteries. Mixing old and new batteries will shorten battery life
and/or cause chemical leakage.
• Replace batteries as soon as they do not work.
•Chemicals which leak from batteries may cause skin irritation. If any chemical matter
seeps out of the batteries, wipe it up immediately with a dry cloth.
• The batteries may have a shorter life expectancy due to storage conditions. Remove
the batteries whenever you anticipate that the remote control will not be used for an
extended period.
•The batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
CAUTION:
•It may result in an explosion if batteries are replaced incorrectly.
•Only replace batteries with the same or equivalent type.
14
Downloaded from www.vandenborre.be

Remote Control
The buttons of the original remote control are as following:
27
QMENU
AUDIO
EPG LIST
INFOINFO
1.
: Power, Press to enter or exit the standby
mode.
2.
: Press to mute or restore sound.
3. II: Pause (in Media/PVR mode).
Press to start time shift function (in DTV
mode).
4.
: Stop the playback (in Media /PVR mode).
: Hold the teletext page on display, press
again to release.
5. : Start playback (in media mode).
6.
: Press button to start recording (In DTV
mode).
7.
: Skip to the beginning of the previous. (in
media mode).
i
: Go to the index page.
8. : Skip to the beginning of the next. (in
media mode).
?
: Reveal the hidden information of some
teletext pages.
9.
: Reverse playback rapidly. (in media
mode).
: Enter subtitle mode or subpage.
10. : Advance playback rapidly. (in media
mode).
: Cancel the teletext but not to exit
teletext, press again to exit.
11. AUDIO(∞I/II): Press to select the NICAM
modes in Analog TV mode.
Press to select desired audio language in
Digital TV Mode.
12.
: Enter the Teletext, and press this button
again to exit.
13. INFO: display the current program
information on the screen.
14. :Return to the previous menu.
: Delete button.
15. NUMBER BUTTONS: Choose channels or
password importation.
16. MENU(
): Press to enter the menu screen
for various optional adjustable settings.
15
Downloaded from www.vandenborre.be

Remote Control
NOTE:
The colour and shape may vary depending on the model.
The buttons not mentioned here are not used.
17. EXIT( ): Quit the current interface.
18. ▲/▼/◄/►: Press the direction buttons to
select menu options or settings.
19. OK:Select the current item or enter into the
function of the menu of the next level.
20. : Goes to NETFLIX homepage.
21. : Goes to YouTube homepage.
22. +-: Press to adjust the volume level up
or down.
23. SOURCE( ): Select signal source, and
accesses the main scene interface.
24. : Press to select channels in
ascending or descending order.
25. COLOR BUTTONS: Red/ green/ yellow/
blue key navigation link. Use in accordance
with the operation interface instructions.
26. LIST: Press to call up the channel list.
Press again to exit it.
27. EPG: Electronic Program Guide, use in the
DTV mode.
28. QMENU: Press to enter quick menu.
27
QMENU
AUDIO
EPG LIST
INFOINFO
16
Downloaded from www.vandenborre.be

Basic Operation
Turning on and off the TV
■ Turn on the TV
Plug the power cord into a suitable power point, then press the POWER ( ) button,
on the remote control, making sure to aim it at
■ Turn off the TV
Press the button on the remote control to enter standby mode. To power down the
TV completely, unplugs the power cord from the mains socket.
Do not leave your set in standby mode for long periods of time. If you will not use the
TV for a long time, it is recommended to unplug the set from the mains and aerial.
First Time Setup
If this is the first time you run the TV, the Initial Setup Menu will appear in the picture,
and the items of this menu also exist in other menus, so you are able to change the
values after you set them up.
Tips: Make sure that the antenna or cable TV system connection is made.
■Select you desired language
Press the ◄/►buttons to select the language to be used for menus and message
and then press the OK button to go to the next step.
■Select your country
Press the ▲/▼/◄/►buttons to select the country you are living in and then press
the OK button to go to the next step.
Press the ◄button to select “< Back” to go to previous step.
■Select your time zone.
Press the ▲/▼/◄/►buttons to select a time zone and then press the OK button to
go to the next step.
Press the ◄button to select “< Back” to go to previous step.
■Select the antenna type (Air, Cable and Satellite).
Press the ◄/►buttons to select the tuning modes and then press the OK button.
(For more detailed information, please refer to Channel menu →Auto Tuning).
■ Auto Tuning
The TV starts Auto Tuning.
If you press the MENU(
) button in TV searching, the Auto Tuning will skip to DTV
searching as the suggestive picture shows.
NOTE:
If the TV doesn't receive any channels, please check your aerial connection or the
country you selected, and then try an auto search again.
If the TV just receives some of the channels, it means the aerial's reception isn't good
enough and an antenna service is recommended.
the sensor at the front of the TV;
17
Downloaded from www.vandenborre.be

Basic Operation
Programme Selection
■Using the on the panel of TV or on the remote control.
■ Using 0- 9 Digital Buttons.
You can select the channel number by pressing 0 to 9. Example:
To select - channel (e.g. Channel 5): Press 5.
To select -- channel (e.g. Channel 20): Press 2 and 0 in a short time.
Volume Adjustment
■Press the +/-on the panel of TV or + - on the remote control to adjust the volume.
■ If you want to switch the sound OFF, press the
.
■ You can release mute by pressing the or increase the volume.
Changing the Input Source
1. You can select the input source by pressing the SOURCE ( ) button on the remote
control.
2. Press the arrow button to cycle through the input source, and press the OK button to
confirm your choice.
Press P∧to increase channel number.
Press P∨to decrease channel number.
18
Downloaded from www.vandenborre.be
