JVC DT-G17E User manual

Version: D
For Customer Use:
Please read the Instruction Manual carefully
and retain this information for future reference.
MULTI FORMAT LCD MONITOR
INSTRUCTIONS
DT-G17E
DT-G21E
DT-G24E
DT-G27E

2
Safety Precautions
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE. NO OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHALL BE PLACED ON THE
APPARATUS.
IMPORTANT SAFEGUARDS
Warning: This is a class A product. In a domestic environment this
product may cause radio interference in which case the
user may be required to take adequate measures.
CAUTION:
To reduce the risk of electric shock. Do
not remove cover (or back). No user
serviceable parts inside. Refer servicing
to qualified service personnel.
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
The exclamation point within an
The lighting flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulared “dangerous voltage”
within the product’s enclosure that may
be of sufficient magnitude to constitute a
risk of electric shock to persons.
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
POWER CONNECTION
The power supply voltage rating of this product is AC 120 V (For U.S.A. and Canada) and AC 220 – 240 V (For
European countries, Asian countries, and United Kingdom).
The power cord attached conforms to the following power supply voltage and countries. Use only the power
cord designated to ensure safety and EMC regulations of each countries.
This plug will fit only into a grounded power outlet. If you are unable to insert the plug into the outlet, contact
your electrician to install the proper outlet. Do not defeat the safety purpose of the grounded plug.
• This product should be operated only with the type of power source indicated on the label. If you are not sure
of the type of power supply of your home, consult your product dealer or local electric power company.
Warning:
• Do not use the same power cord for AC 120 V as for AC 220 – 240 V. Doing so may cause malfunction,
electric shock or fire.
For United Kingdom: AC 220 – 240 VFor European and Asian countries:
AC 220 – 240 V
For U.S.A. and Canada: AC 120 V
Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety.
But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRIC SHOCK OR FIRE.
In order not to defeat the safeguards incorporated into this product, observe the following basic rules for its installation, use, and service.
Please read these “IMPORTANT SAFEGUARDS” carefully before use.
• All the safety and operating instructions should be read before the product is operated.
• The safety and operating instructions should be retained for future reference.
• All warnings on the product and in the operating instructions should be adhered to.
• All operating instructions should be followed.

3
Do not use the product for a long time if the sound is distorted.
•
•
Safety Precautions (cont.)
Under the following conditions,
1. Turn off the power.
2. Unplug this product from the wall outlet.
3. Refer service to qualified service personnel.
a) When the product emits smoke or unusual smell.
b) When the product exhibits a distinct change in perfor-
mance —for example, no picture or no sound.
c) If liquid has been spilled, or objects have fallen on the
product.
d) If the product has been exposed to rain or water.
e) If the product has been dropped or damaged in any
way.
f) When the power supply cord or plug is damaged.
• Make enough room for inserting or removing the power plug.
Place the product as close to an AC outlet as possible. The
main power supply for the product is controlled by inserting or
removing the power plug.
• When you install the product in a place where you cannot
easily insert or remove the power plug from an AC outlet, do
not use the provided power cord holder, and insert or remove
the power cord from the AC inlet on the product.
• When the product is left unattended and unused for a long
period of time, unplug it from the wall outlet and disconnect
the cable system.
• Do not overload wall outlets, extension cords, or conve-
nience receptacles on other equipment as this can result in a
risk of fire or electric shock.
• Use only the accessory cord designed for this product to
prevent shock.
• Do not install this product in the following places:
– in a damp or dusty room
– where the product is exposed to soot or steam, such as near the cooking counter or a humidifier
– near heat sources
– where condensation easily occurs, such as near the window
• Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious injury to a child or adult,
and serious damage to the product.
The product should be mounted according to the manufacturer’s instructions, and should use a mount recommended by the
manufacturer.
• Do not use this product near water.
• Be sure to install the product in the place where proper temperature and humidity are kept.
This product becomes hot during its use. Take enough care when handling the product.
Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous voltages and
other hazards. Refer all service to qualified service personnel.
When the product is left unattended and unused for a long
period of time, unplug it from the wall outlet and disconnect the
cable system.
Do not overload wall outlets, extension cords, or convenience
receptacles on other equipment as this can result in a risk of
fire or electric shock.
• Slots and openings in the cabinet are provided for ventilation. These ensure reliable operation of the product and protect it
from overheating. These openings must not be blocked or covered.
• Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-circuit
the parts, which could result in a fire or electric shock.
• Never spill liquid of any kind on the product.
• Never place anything on the product. (Placing liquids, naked flames, cloths, paper, etc. on the product may cause a fire.)
• Do not apply any strong shock to the LCD panel. (Do not hit any object against it or push it with a sharp-pointed tool.)
• Do not put heavy objects on the product.
• Do not step on or hang on the product.
• Before connecting other products such as VCR’s and personal computers, you should turn off the power of this product for
protection against electric shock.
• Do not use attachments not recommended by the manufacturer as they may be hazardous.
• When replacement parts are required, be sure the service technician has used replacement parts specified by the manufac-
turer or equivalents. Unauthorized substitutions may result in fire, electric shock, or other hazards.
• Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine
that the product is in proper operating condition.

4
Maintenance
Unplug this product from the wall outlet before cleaning.
LCD panel
Cabinet
Ventilation openings
Operating Precautions
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit
from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be
placed on the apparatus.
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these
batteries must be followed strictly.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)
15)
16)
17)
The LCD panel and backlight have life expectancy. Due to the basic characteristics of the LCD panel, an afterimage or uneven display
may occur. It is recommended that you change images occasionally, activate the power saving function, or often turn off the power to
reduce the load on the LCD panel. Continuous operations of the LCD panel may accelerate the deterioration.
To avoid irreparable change in appearance of the screen such
as uneven color, discoloration, scratches, be careful about the
following:
Wipe stains off the LCD panel with a soft cloth. If the screen gets
heavily stained, wipe it with a soft cloth soaked in water-diluted
neutral detergent and wrung well, then wipe with a soft dry cloth.
To avoid the deterioration or damages of the cabinet such as its
paint’s peeling away, be careful about the following:
Wipe stains off the cabinet with a soft cloth. If the cabinet gets
heavily stained, wipe it with a soft cloth soaked in water-diluted
neutral detergent and wrung well, then wipe with a soft dry cloth.
Use a vacuum cleaner to get rid of the dust around the intakes (all
the openings). If a vacuum cleaner is not available, use a cloth and
wipe it off. Leaving the dust around the intakes may prevent proper
temperature control and cause damage to the product.
Do not wipe the cabinet using solvent such as alcohol, thinner,
or benzine.
Do not expose the cabinet to any volatile substance such as
insecticides.
Do not allow any rubber or plastic in contact for a long time.
Do not wipe the cabinet forcefully.
Do not paste or stick anything using any glues or adhesive
tapes.
Do not write anything on the screen.
Do not strike the screen with a hard object.
Avoid condensation on the screen.
Do not wipe the screen with any liquid such as water. In
addition, wiping the screen with water-diluted neutral
detergent or solvent such as alcohol, thinner, or benzine
may affect the anti-reflection treatment of the screen.
Do not wipe the screen forcefully.

5
Table of Contents
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFEGUARDS 2
Operating Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Index of Parts and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Rear panel 7
Front panel 8
Showing Input Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
On the Information Display 9
On the Status Display 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
The operation procedure 10
Menu Transition Diagram 10
Main Menu 11
External Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using the UMD control 20
Using the GPI control 20
Using the Webserver IP control 21
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
General 24
LCD panel 24
Input/output terminals 24
Dimensions 25
Available signals 26

Caution:
Be careful not to pinch your fingers in the gap between the monitor and the stand.
When lifting up the stand, lay the monitor on a cloth with the LCD panel facing down to prevent the LCD panel being damaged.
Be careful not to pinch your fingers in the moving parts.
The Max tilt angle is down 7° and up 9°, please make sure the setup location is stable, to prevent the monitor falling down.
Place the monitor on a mat to avoid scratching the table surface.
Step1: Install the Back Plate onto the Bottom Plate by supplied 5 scews.
Step2: Install the Back plate onto the monitor by 4 screws.
The Max tilt angle is down 3° and up 8°, please make sure the setup location is stable.
6
Installation
Do not rest your arm on the monitor or lean against the monitor.
Do not touch the LCD panel when installing the monitor.
Be sure to install the monitor securely to prevent the monitor from falling over, which may cause damage to the monitor or injury.
The monitor package provides a desktop stand to be installed.
Step1: Fix the supplied rack ears onto left and right side of the DT-G17E monitor, by supplied 4 screws.
Step2: Install the monitor onto the standard 19-inch rack. Occupy 7U height.
Using the monitor on the stand
The DT-G17E provides a pair of rack ears to be installed on standard 19” racks.
Using the monitor on 19” rack (Only DT-G17E)
3°8°
Back Plate
Bottom Plate

7
Rear panel
Index of Parts and Functions
•
•
•
•
•
1
1
2
3
4
5
7
8
11
9
6
12
10
RGB
RGB
REMOTE terminal
Terminal for controlling the monitor by an external control. (
Page 20.)
E. AUDIO 3G/HD/SD SDI (IN 1, IN 2) terminals (BNC)
Input / Output terminals for the HD/SD SDI signals.
The terminals accept also EMBEDDED AUDIO signals including
up to 16 audio channels with a sampling frequency of 48 kHz.
RGB-IN (mini D-sub 15pin)
Input terminal for analog RGB signal. ( Page 27.)
HDMI terminal
Input / Output terminal for HDMI signals. Will not display or
output HDCP protected contects. ( page 27.)
Y / Pb / Pr (IN) terminals (BNC)
Input terminals for Component signal.
USB
stick, and insert to this USB socket, and operate Menu system
( Page 16.)
CVBS terminals (BNC)
Input / Output terminals for the composite signals.
AUDIO (IN) terminals (RCA)
Left and Right channels input terminals for the analog audio
signals.
Set signal source as ANALOG (CVBS, RGB, YPbPr) ,the analog
audio can be monitored as audio meters or output via Speaker /
Headphone.
Battery Plate
Install V-mount or Gold mount battery plates to power the monitor
by V-mount batteries. (Gold mount plates for option)
DC-IN terminal
Main (Back up) power input, connect with DC11V-17V 4-pin XLR
power adapter. (Pin 1: Negative, Pin 4: Positive)
AC-IN terminal
Connect the provided AC power cord to an AC outlet, with 250V
fuse.
AC Switcher
Note for connections
User a cord whose plugs correctly match the terminals on this
monitor and the equipment.
noise.
When unplugging a cord, be sure to grasp its plug and pull it
out.
DO NOT connect the power cord until all connections are
2
3
4
5
6
7
8
9
10
11
12

Speaker:
For SDI/HDMI embedded audio and analog audio monitoring.
The speaker will not work if earphone is plugged in.
Rotary knobs：
VOLUME: Adjust the sound volume from 0-100.
When the menu is inactivated, revolve “VOLUME” to adjust
the sound volume.
CHROMA: Adjusts the picture chroma from -50 to +50.
BRIGHT: Adjusts the picture brightness from -50 to +50.
CONTRAST: Adjusts the picture contrast from -50 to +50.
Directly press BRIGHT/CONTRAST/SATURATION knobs, the
parameters will recover to default value 0.
Direction Keys:
Includes Up, Down, Left, Right 4 direction keys for Menu
operation. ( page 10.)
Menu Key:
Press to switch on Menu system and operate by direction
keys.
WFM Key:
Press to display Waveform scope.
Continue to press WFM within 5 seconds, it will open
Waveform Sub-Menu for Waveform type selection.
INFO Key
Press to turn on or turn off all the on screen overlay
informations, includes video scopes, audio meters,
markers etc.
Press INFO can quit Menu system at any time.
FUNCTION Keys
Provide F1 / F2 / F3 / F4 / F5 / F6 function keys to assign
monitor functions and switch on/off quickly. ( page 11.)
INPUT SELECTION keys
Select input sources directly:
- SDI 1: the 3G/HD/SD-SDI IN-1 terminal input.
- SDI 2: the 3G/HD/SD-SDI IN-2 terminal input.
- HDMI: the HDMI terminal input.
- Y/Pb/Pr: the Component Y/Pb/Pr terminals input.
- RGB: the RGB terminal input.
- VIDEO: the Composite terminal input.
The key light will indicate the current input source.
POWER key
Press to switch on or swich o the monitor.
The standby power consumption is less than 0.5W, comply
with ErP rules. To complete cut o power, please switch o
the AC input switcher or disconnect DC cable or battery.
PHONE jack
3.5mm earphone socket, for SDI/HDMI embedded audio and
analog audio monitoring.
USB LUT
1. Plug in USB stick to upload 3DLUT cube les, and connect
color sensor probes when calibrating the monitor. ( page
17.)
2. Plug in USB stick with ARM rmware les, and operate
Menu system to upgrade ARM rmware. ( page 16.)
8
Index of Parts and Functionos (cont.)
Front panel
21 3
4
5
10
8911 67
Tally lamp
This lamp is controlled by the tally function of the
Make contact terminal. ( External Control on Page 18.)
You can select the color of the tally lamp from "Green",
"Red", or "Yellow".
VOLUME CHROMA BRIGHT CONRAST
MENU
WFM F1 F2 F3 SDI1 SDI2 HDMI YPbPr VGA VIDEO
POWER PHONE USB
LUT
F6F5F4INFO
VOLUME CHROMA BRIGHT CONRAST
MENU
WFM F1 F2 F3 SDI1 SDI2 HDMI YPbPr RGB VIDEO
POWER PHONE USB
LUT
F6F5F4INFO
1
2
3
4
5
6
7
8
9
10
11
Waveform
Y
Cb
Cr
R
G
B
Off

9
On the Information Display
Showing Input Signals
On the Status Display
-09
-20
-48
123 4 5 6 7 8 91011121314 1516
L -20DB 01CH R -22DB 01CH
CAMERA 1
TC：00:15:13:07
Main Menu
Exit&Status
Color Temp
Func�on Key
GPI
UMD
Marker
Audio
Vector
Waveform
Display
System
OSD
Key Inhibit
＞
＞
＞
＞
＞
＞
＞
＞
＞
＞
＞
＞
Color Measurement
Auto Calibra�on
＞
＞
RGB
＞
＞
＞
Status
HDMI XXX
User Profile XX
Color Temp XXXX
Scan Mode XXX
Freeze Frame XXX
Odd/Even Frame XXX
F1 XXX
F2 XXX
F3 XXX
F4 XXX
F5 XXX
F6 XXX
Monitor IP XX.XX.XX.XX
Net Mask XX.XX.XX.XX
Gateway XX.XX.XX.XX
Port XXX
System Version XXX
1
2
3
4
5
6
7
8
9
Time code (SDI)
Under SDI input, the monitor can display Time code
information (LTC, VITC1&2). If no Time code info is
detected, it will display “TC UNLOCKED”.
UMD
Display TSL 3.1/4.0 UMD or User input Source ID.
( page 12.)
AFD (SDI)
Under SDI input, the monitor can display AFD information.
If no AFD information embedded in the SDI source, it will
display “AFD: UNLOCKED”.
Audio VU/PPM meters
Display meters of SDI/HDMI embedded audio or analog
audio. The audio meter display channels, on screen
positions, markers and background colors are adjustable.
( page 14.)
Histogram
Parallel display R/G/B/Y histogram for SDI and HDMI video.
( page 15.)
Vector scope
Display vector scope with 100% and 75% markers for SDI and
HDMI video. The vector scope pattern display positions,
colors, background are adjustable. ( page 15.)
Waveform
Display waveform scopes for SDI and HDMI video with
markers. The display waveform can be selected from Y/Cb/Cr/
R/G/B types, and single line display mode selectable. The
waveform display positions, colors, background are adjust-
able. ( page 15.)
All the above OSD information display support assign
to F1-F6 keys and turn off or turn off the display. ( page
11.)
Press “MENU” button, the main menu will pop up from the left
top of the screen, and display the current working status,
including:
Input video format
If no video detected in current input source, it will display
“No Signal”.
User Profile
The monitor can restore 3 user preference settings and
display the current user prole info.
Color Temp
Display the current set color temperature value.
Scan Mode
Display the current scan mode.
Freeze Frame
Display the current status of Freeze Frame: ON/OFF.
Odd/Even Frame
Display the current status of Odd/Even Frame: ON/OFF.
Will display gray and not available if the current input
signal doesn’t support Odd/Even mode.
F1/F2/F3/F4/F5/F6
Display the current functions that assigned to F1-F6 function
keys.
Monitor IP
Display the IP address, Net Mask, Gateway and Port of the
monitor, for Webserver IP remote control function
System Version
Display the current rmware version.
1
1
2
3
4
5
6
7
8
9
2
3
4
5
6
7
1
2
3
4 5 6 7

10
The Operation Procedure
Menu Transition Diagram
"Exit &Status" only displays the current info, and cannot be set/changed.
Exit&Status HDMI
User Profile
Color Temp
Scan Mode
Freeze Frame
Odd/Even Frame
F2
F1
F3
F4
F5
F6
Monitor IP
Net Mask
Gateway
Port
System Version
Exit
Contrast
Brightness
Chroma
Sharpness
Phase
Backlight
Aspect Ratio
Scan Mode
Zoom Mode
Scaling Position
Flip Mode
Freeze Frame
Color Range
Color Temp
Function Key
Exit
Gamma
Color Temp
Red Gain
Green Gain
Blue Gain
Red Bias
Green Bias
Blue Bias
Exit
F1
F2
F3
F4
F5
F6
GPI
Exit
GPI Control
1Pin
2Pin
3Pin
4Pin
5Pin
6Pin
Source ID
Parity
Baud Rate
Display Type
Size
Color
RS485 Address
Position
Exit
UMD
Marker
Exit
Marker
Marker Select
Safety Area
Fit Marker
Center Marker
Marker Color
Audio
Exit
Audio Bar
Bar Frame
Bar Position
Bar Blending
Select Channel
Left Channel
Audio Alarm
Rright Channel
Exit
Odd/Even Frame
Reacall Profile
Save Profile
Source Scan
Exit
Size
Auto Adjust
Horizontal Pos.
Vertical Pos.
Phase
Logo
Green Mode
Idle Duration
Update Driver
Update Kernel
Update ARM
Exit
Waveform
Audio Bar
Vector
Zebra
Focus Assist
Time Code
Histogram
False Color
AFD
H/V Delay
R/G/B/Mono
Color Bar
Marker
Low Latency Mode
UMD
Vector
Waveform
Display
System
Color Measure
Auto Calibration
OSD
RGB
Key Inhibit
Exit
Waveform
WFM Type
WFM Position
WFM Blending
Exit
Log Mode
1DLut Exit
Probe Select
Start Calibration
Color Space
Import
Reset
WFM Color
WFM Single Line
WFM Line Count
Exit
OSD Language
OSD Blending
OSD Duration
Key Led Brightness
Tally-R Brightness
Tally-G Brightness
Tally-Y Brightness
Soft-Tally Position
Soft-Tally Blinking
Exit
Vector
Vector Position
Vector Blending
Vector Color
Histogram
Histogram Blending
Exit
Key Inhibit
Marker Outside
Press the “MENU” button to display the Main Menu.
Press “ ” and “ ” to select submenu, the selected submenu highlights in yellow; Press “ ”
to apply and enter into the selected submenu item.
Press “ ” and “ ” to select the item to be set from the submenu; Press “ ”, the selected
item and its parameters will be highlighted in yellow.
Press “ ” and “ ” to adjust the selected item; Press “ ” or “MENU” to apply and save the
settings.
Press “ ” to quit submenu; Press “ ” again to quit the Main Menu.
Press “INFO” can quit Menu system at any time.
Note
The items in gray means not available
to set up.
If there is no operation in a period of
time, the menu will automatically save
settings and quit. The menu quit time
can be set from OSD submenu.
If Key Inhibit is turned on, except the
Key Inhibit submenu, all other items
are not available to operate. Please
turn o the key inhibit to enable the
Menu operation.
2
3
4
5
6
1

Main Menu
Picture Function
Setting for the picture quality.
Item
Exit
Contrast
Brightness
Chroma
Sharpness
Phase
Backlight
Aspect Ratio
Scan Mode
Zoom Mode
Color Range HDMI Color Range setting
Scaling Position
Flip Mode
Freeze Frame
To do
Return to Main Menu
Adjusts the contrast of the display.
Adjusts the brightness of the display.
Adjusts the saturation of the display.
Adjusts the sharpness of the display.
Adjusts the phase of the display.
Adjusts the backlight of the display.
Aspect Ratio setting
Scan Mode setting
Zoom Mode setting
Scaling Position setting
Flip Mode setting
Display setting
On: Displayed, O: Not displayed
Setting value
-50 to +50
-50 to +50
-50 to +50
-50 to +50
-50 to +50
0 to 100
16:9, 4:3, Auto
Normal, Native
On, O
O, 16-235, 0-255
O, Zoom1, Zoom2
Center, Top Left, Top Right,
Bottom Left, Bottom Right
Item
Exit
Gamma
Color Temp
Red Gain
Green Gain
Blue Gain
Red Bias
Green Bias
Blue Bias
To do
Return to Main Menu
Select the Gamma correction value.
Select the color temperature Mode.
Adjusts the Red Gain
Adjusts the Green Gain
Adjusts the Blue Gain
Adjusts the Red Bias
Adjusts the Green Bias
Adjusts the Blue Bias
Setting value
2.2 (equivalent to 2.2)
1.8 (equivalent to 1.8)
2.4 (equivalent to 2.4)
2.6 (equivalent to 2.6)
3200k, 5600K, 6500K, 9300K
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
Item
Exit
F1
F2
F3
F4
F5
F6
Setting value
To do
Return to Main Menu
Assign functions to the function
keys F1 - F6 on the front key board
For example: Set F3 to “R/G/B/Mono” under “Function key” submenu. User can press F3 on the front panel to adjust the parameters of
“R/G/B/Mono”, and the “R/G/B/Mono” will change and follow the sequence: Blue Only →Red Only →Green Only →Mono →
Color Temperature
Adjusts the R/G/B Gain and Bias, and Gamma Preset
Function Key
Set short-cut functions for F1-F6
11
Time Code
Color Temp
Flip Mode
Freeze Frame
Scan Mode
Aspect Ratio,
WFM Single Line
Focus Assist
Low Latency Mode
Odd/Even Frame
Max Backlight
Audio Alarm
UMD
Color Bar
Marker
R/G/B/Mono
H/V Delay
AFD
False Color
Histogram
Audio Bar
Zebra
Vector
ABCDEF
ABCDEF
ABCDEF
ABCDEF
O(normal)
H Flip V Flip H/V Flip

12
UMD
Source ID and UMD setting
Item
Exit
Position
Size
Color
Display Type
Baud Rate
Parity
Source ID
To do
Return to Main Menu
Address setting *1
Display position setting
Size setting
Color setting
Choose Display Type *2
Baud Rate setting
Parity setting
Setting of “Source ID” *3
Setting value
Top, Bottom
Normal, Mid-Large, Large
Red, White, Black, Blue, Green, Yellow
Source ID, UMD
38400, 9600, 19200
Even, None
X X X X X X X X
1 to 126RS485 Address
*1 Address setting
(1) The RS485 address setting is for UMD device connection.
(2) Support TSL UMD Protocol V3.1 and V4.0, provided by Television System Ltd.
(3) Set the UMD address, Baud Rate, Parity correct, to display UMD letters and Tally.
*2 Choose Display Type
(1) Select “UMD” to display Source info and Tally info from external control devices of TSL protocol,
(2) Select “Source ID” to display a user input xed source info, and Tally info by GPI input.
*3 Source ID setting
(1) Support 8 letters to input.
(2) Press “MENU” to select each letter space, and press “ ” and “ ” to select letters from:
(3) Press “MENU” to conrm current letter and move to next space.
UMD letters and Tally1/Tally2 from external control devices
of TSL 3.1/4.0 protocol
Space 0~9 A~Z a~z &()*+,-./:<>_
CAMERA1
Tally1
UMD
Tally2
CAMERA1
Tally1
Source ID
Tally2
Source ID letters by manually input,
Tally1/Tally2 input via GPI pin assignment.
Item
Exit
GPI Control *1
1 Pin
2 Pin
3 Pin
4 Pin
5 Pin
6 Pin
Setting valueTo do
Return to Main Menu
Enable GPI control
Assign functions to the GPI
terminals
ON, OFF
GPI
Setting functions for external control
Red Tally, Green Tally, Yellow Tally, Video, HDMI, SDI1, SDI2, Focus Assist,
Low Latency Mode, Odd/Even Frame , Max Backlight,Audio Alarm, UMD,
Color Bar, Marker, R/G/B/Mono, H/V Delay, AFD, False Color, Histogram,
Audio Bar, Vector,Zebra, Time Code, Color Temp, Flip Mode, Freeze Frame
Scan Mode, Aspect Ratio
*1 GPI Control
The monitor can be operated through external GPI control unit when GPI Control is turned ON. ( page 20.)

13
Item
Exit
Safety Area
Fit Marker *1
Marker Color
Marker Outside
To do
Return to Main Menu
Turn the marker display on / o
Adjust the ratio of marker
Safety area setting
Set safety area to t marker ratio or not
Turn the center cross mark on / o
Marker color setting
Marker outside color setting
Setting value
O, 4:3, 13:9, 14:9, 15:9, 16:9, 1.85:1, 2.35:1
O, 80%, 85%, 90%, 93%, 95%
O, On
White, Red, Green, Blue, Black, Gray
O, Gray, Black
Marker
Marker Select
O, On
Center Marker O, On
Marker
Settings for marker functions
Safety Area
Marker select Center Marker Marker Outside Marker: 4:3
Safety Area: 85%
Center Marker: On
Marker: 4:3
Safety Area: 85%
Fit Marker: On
*1 Fit Marker
Turn o the Fit Marker, the safety area size percentage is based on screen size.
Turn on the Fit Marker, the safety area size percentage is based on Marker ratio.

Item
Exit
To do
Return to Main Menu
Turn on / turn o the audio bar display
Turn on / turn o the
audio bar frame and marks.
Setting value
Audio Setting
Setting for the audio meters and channel selection
On, O
On, O
Bar Frame
Bar Position
Bar Blending
Audio Alarm*1
Select Channel*2
Left Channel
Right Channel*3
Change on screen display position of the audio bar. Top Right, Bottom Left,
Bottom Right, Top Left
Low, O, High
O, On
SDI input: Channel 1-2, 1-8, 1-16
For HDMI and ANALOG input,
only display Channel 1-2.
SDI：Channel 1-16
Adjust the audio bar pattern background transparency.
*1 Audio Alarm
Switch on “Audio Alarm”, the audio bars will display audio alarm info:
No audio detected - display “UNLOCKED”.
Audio detected but volume is low - display “MUTE”
*2 Select Channel
Under SDI input, Channel 1-2, 1-8, 1-16 display mode can be selected.
Under HDMI input or Analog input, only Channel 1-2 can be selected.
*3 Left Channel / Right Channel
When selected display channel is “Channel 1-2”, the left and right channel output can be selected from Channel 1-2;
When selected display channel is “Channel 1-8”, the left and right channel output can be selected from Channel 1-8;
When selected display channel is “Channel 1-16”, the left and right channel output can be selected from Channel 1-16;
In the audio bar, the left channel information will be in green, and the right channel information will be in red.
Turn on / turn o the audio alarm
information
Select the audio left and right channel to be
de-embed and output via speaker or headphone.
-09
-20
-48
123 4 5 6 7 8 910111213141516
L -32DB 01CH R -13DB 02CH
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
L -32DB 01CH R -13DB 02CH
Left Channel:5 Green Right Channel:11 Red
Select audio channel
quantities to display
Audio Bar
-09
-20
-48
123 4 5 6 7 8
L -04DB R -06DB
Red
Yellow
Green
Bar Frame : On
123 4 5 6 7 8
Bar Frame : O
Audio alarm : On Audio alarm : O
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
-09
-20
-48
123 4 5 6 7 8
L -04DB R -06DB
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
-09
-20
-48
123 4 5 6 7 8
L -04DB R -06DB
-09
-20
-48
123 4 5 6 7 8 910111213141516
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
-09
-20
-48
123 4 5 6 7 8
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
M
U
T
E
12
14
L -04DB R -06DB

Vector
Setting for Vector scope and Histogram patterns
Item
Exit
Vector Color
To do
Return to Main Menu
Turn on/o the Vector scope pattern
Turn on/o the Histogram pattern
Waveform pattern background transparency selection
Vector scope pattern background transparency selection
Histogram pattern background transparency selection
Vector scope pattern color setting
Item
Exit
WFM Type
WFM Color
WFM Line Count
To do
Return to Main Menu
Turn on/o the Waveform pattern
Turn on/o the Waveform single line mode
Waveform type select
Waveform pattern on screen display position setting
Waveform pattern color setting
Select a line for the single line waveform
Setting value
Setting value
Bottom Right, Center, Top Left
Top Right, Bottom Left
Vector O, On
Vector scope pattern on screen display position settingVector Position *1
Vector Blending
Color, White, Green, False Color
O, Low, High
Histogram O, On
O, Low, HighHistogram Blending
Waveform
Setting for Waveform patterns
Waveform
Y, Cb, Cr, R, G, B
O, On
0 to 1079
Bottom Left, Bottom Right,
Center, Top Left, Top Right
Low, High, O
White, Green, False Color
O, On
WFM Position *1
WFM Blending
WFM Single Line *2
*2: WFM Single Line
Turn on the Waveform single line mode, the monitor will display waveform for 1 line. (Only available under SDI input)
Select a line at WFM Line Count by “ ” and “ ”.
Under WFM single line mode, out of Menu system, directly press “ ” and “ ” can select lines.
*1: Vector Position / WFM Position
Select 4 corners and center display position of Vector scope pattern and Waveform pattern.
The Vector scope and Waveform can be displayed together.
WFM Single Line: OnWFM Single Line: O
100
50
0
15
100
50
0
100
50
0
100
50
0
100
50
0
100
50
0
100
50
0
Y Line:210

*1: Time Code / AFD / H/V delay / Low Latency Mode Available only under SDI input
*2: Low Latency Mode Turn on the Low Latency Mode, the video signal latency will be 1 line, and no video functions are available.
Low Latency Mode is available under SDI 720p50/60, 1080i50/60, 1080p50/60.
Item
Exit
To do
Return to Main Menu
Display
Waveform
Audio Bar
Vector
Zebra
Focus Assist
Time Code *1
Histogram
False Color
AFD *1
H/V Delay *1
Color Bar
Marker
Low Latency Mode *2
UMD
Select Red only, Green only, Blue only or Black/White modeR/G/B/Mono Blue Only, Red Only, Green Only, Mono
Setting value
System
Item
Exit
Odd/Even Frame
Green Mode*2
Idle Duration*3
Update Driver*4
Update Kernel*5
Update ARM*6
To do
Return to Main Menu
Select Odd/Even Frame mode
Loading Factory settings and User presets
Factory: Recover all settings to factory setting
User 1/2/3: Load the User settings 1/2/3
Save current User settings
User 1/2/3: Save the current settings to User 1/2/3
Automatically scan input signal or not when switch on the monitor
Settings to display Switch on logo or not
Display settings when in Energy Save mode
Set an idle time to enter Energy Save mode
Firmware upgrade: Driver
Firmware upgrade: Kernel
Firmware upgrade: ARM
Setting value
Off, Odd Mode, Even Mode
Factory, User1, User2, User3
Source Scan*1
Logo
User1, User2, User3
No, Yes
No, Yes
app, ulmage, rootfs.ubi
Black Backlight, Standby, Gray Backlight
16
USB firmware upgrade
Firmware Upgrating... 37%
Caution ! DO NOT cut off power
during firmware upgrade.
*1 Source Scan
When set to “On”, next time switch on the monitor, the monitor
will automatically scan the available signal source with the
sequence of SDI1→SDI2→HDMI→YPbPr→RGB→Video, and
*2 Green Mode
To comply with ECO save energy regulations, the monitor will
go to Green Mode if there’s no operation during a period of
time. Press any button, the monitor will be back to normal
status.
*3 Idle Duration
Select a time to enter Green Mode if there’s no operation. Set to
*4 / 5 Update Driver / Kernel
monitor, and insert USB stick to the REAR panel USB port of the
monitor. ( page 7)
Enter “Update Driver” - “Yes”, or “Update Kernel” - “Yes”, the monitor will
*6 Update ARM
USB stick to the FRONT panel USB port of the monitor.
and update automatically.
button OFF/ON.
CAUTION

*1 Log Mode
The Log Mode is for De-log 3DLUTs and User 3DLUT selection.
Select a preset 3DLUT to convert Camera Log Mode to Rec.709.
The User-Log is to select the user uploaded 3DLUT.
*2 Color Space
Switch to “LCD panel”, the monitor will display LCD native color space, and
enable color calibration by 3rd party 3DLUT calibration software.
Please switch back to “ITU709” when 3rd party calibration nished and
return to normal monitoring.
*3 Upload 3DLUT re-calibrated cube
Upload position: 3DLut.cube
Support 17×17×17 cube, calibration under 6500K and Gamma 2.4.
Konica Minolta CA-310 color meter dan Spectracal CalMAN5 software are
recommanded.
Rename the re-calibrated cube as “3DLut.cube” (attention to the cap
letters), and copy into USB stick root directory.
Insert the USB stick onto monitor USB port on the FRONT panel, select
“Import” - “3DLut.cube” - “YES” to import the new cube.
*4 Overwrite the preset De-log 3DLUTs
Upload position: J-Log1.cube, Log-C.cube, S-Log2.cube,S-Log3.cube,
C-Log.cube, V-Log.cube, RedLogFilm.cube.
Rename the De-log 3DLUT cube as the same le name to the system
(attention to the cap letters), and copy into USB stick root directory.
Insert the USB stick onto monitor USB port on the FRONT panel, select
the corresponding logs to import the new cube.
*5 Upload user 3DLUT and 1DLUT les
User 3DLUT Upload position: User-Log.cube
User 1DLUT Upload position: 1DLutUser1.csv, 1DLutUser2.csv
Rename the User 3DLUT or 1DLUT as the same le name to the system
(attention to the cap letters), and copy into USB stick root directory.
Insert the USB stick onto monitor USB port on the FRONT panel, select
the corresponding upload position to import the new le.
*6 Reset
For any wrong cubes imported that caused wrong display colors, you can
reset the cubes to factory cubes here.
To do
Return to Main Menu
Select a camera log LUT to convert to Rec.709
Select the uploaded User 3DLUT cube
Select 1DLUT color le
Upload 3DLUT re-calibrated cube*3,
Overwrite the preset De-log 3DLUTs *4,
Upload user 3DLUT and 1DLUT les *5
Reset*6
Upload Position
3DLut.cube
J-Log1.cube
Log-C.cube
S-Log2.cube
S-Log3.cube
C-Log.cube
V-Log.cube
RedLogFilm.cube
User-Log.cube
1DLutUser1.csv
1DLutUser2.csv
Re-calibrated 3DLUT cube
JVC J-Log1 De-log 3DLUT cube
ARRI Log-C De-log 3DLUT cube
SONY S-Log2 De-log 3DLUT cube
SONY S-Log3 De-log 3DLUT cube
Canon C-Log.cube De-log 3DLUT cube
Panasonic V-Log De-log 3DLUT cube
Red Log De-log 3DLUT cube
User 3DLUT cube upload
User 1DLUT csv upload
User 1DLUT csv upload
Description
Reset to factory imported 3DLUT cubes
Setting value
J-Log1, Log-C, S-Log2, S-Log3, C-Log, V-Log,
RedLogFilm, User-Log
Default, User1, User2
ITU709, LCD panel
3DLut.cube, J-Log1.cube, Log-C.cube, S-Log2.cube,
S-Log3.cube, C-Log.cube, V-Log.cube, RedLogFilm.cube,
User-Log.cube, 1DLutUser1.csv, 1DLutUser2.csv
3DLut.cube,J-Log1.cube,Log-C.cube,S-Log2.cube,
S-Log3.cube,C-Log.cube,V-Log.cube,RedLogFilm.cube,
User-Log.cube
Item
Exit
Log Mode*1
1DLut
Switch to LCD panel native color space
Color Space*2
Color Measure
Import
3rd party 3DLUT calibration, de-log LUTs, User LUTs upload
17
VOLUME CHROMA BRIGHT CONRAST
MENU
WFM F1 F2 F3 SDI1 SDI2 HDMI YPbPr VGA VIDEO
POWER PHONE USB
LUT
F6F5F4INFO
POWER PHONE USB
LUT
Insert the USB stick onto monitor USB port on the FRONT panel

*2 Start Calibration
The monitor has built in 3DLUT calibration software, and connect the
supported color sensor probe directly to the monitor, the montior can
be calibrated automatically without PC connection.
Steps:
(1) Connect the supported color sensor probe to the FRONT USB port
of the monitor.
(2) Switch on the monitor, Enter: Menu - Auto Calibration - Start
Calibration - YES. The monitor will display:
(3) Follow the instructions to place the color sensor probe to the
indicated position:
(4) Select “YES”, the auto calibration will start. The monitor will
calibration progress in percentage.
*1 X-rite Eye One Pro OEM, Jeti Sepcbos
The monitor support the following probe models:
(
Please donot touch the probe during the calibration process.
18
To do
Return to Main Menu
Select probe that used for the calibration
Start the auto calibration
Setting value
X-rite Eye One Pro OEM, Jeti Specbos*1
No, Yes
Item
Exit
Probe Select
Start Calibration *2
Operations for automatic 3DLUT color calibration
Auto Calibration
Auto Calibration
Progress 30%
Please wait...
Auto Calibration
Progress 100%
Succeed ! Press”INFO” to quit.
X-rite Eye One Pro OEM
Please make sure the monitor is in dark room
and the sensor probe is put in the center
marker and close the screen.
Select Yes to start calibration.
Yes No
Place Sensor Probe here
i1 DISPLAY E0DIS3-DC0EX-rite
Specbos 1211JETI
Brand Model Sensor Probe Connection
FRONT USB port connection
Probe not detected
(1) Re-check and conrm the model type of the color sensor
probe.
(2) Check and make sure the FRONT USB port is well connected.
Calibration failed
(1) Make sure the probe sensor is not covered, and placed to the
indicated position on the screen.
(2) Reconnect the USB port and operate calibration again.
You may terminate the Auto calibration process at any
time by disconnecting probe USB or pressing the front
power button o and on, to restart the monitor.
X-rite Eye One Pro OEM
Please make sure the monitor is in dark room
and the sensor probe is put in the center
marker and close the screen.
Select Yes to start calibration.
Yes No
X-rite Eye One Pro OEM
Probe not detected, process cannot proceed.
X-rite Eye One Pro OEM
Place Sensor Probe here
Failed! Press “INFO” to quit and try again.
Progress 100%

*1 Key Inhibit
O: Not inhibited.
Step 1: Only Menu button is available. Enter Menu, and Up/Down/Left/Right arrow buttons can be operated to turn o the Key Inhibit.
Step 2: Menu button, F1 - F6 Function keys, and Input Selection buttons are availble to operate.
Step 3: Menu button and Input Selection buttons are availble to operate.
Under Key Inhibit mode, for any operations to the inhibited buttons, the monitor will display:
19
To do
Return Main Menu
OSD Blending setting
OSD Duration setting
Key Led Brightness
Tally-R Brightness
Tally-G Brightness
Soft-Tally Position
Soft-Tally Blinking
Item
Exit
Key Inhibit *1
To do
Return Main Menu
Key Inhibit setting
Setting value
O, Step1, Step2, Step3
*1 During this period of time, if there's no operation to the menu, the menu will automatically quit.
*1 If RGB signal can’t display correct, select “Auto Adjust”, and press MENU key, the system will automatically adjust the RGB display.
Key Led Brightness setting
Set the brightness of tally when it’s red
Set the brightness of tally when it’s green
Set the position of soft-tally
Set the blinking of soft-tally
Low, Medium, High, O
High, Low, Medium
High, Low, Medium
Tally-Y Brightness Set the brightness of tally when it’s yellow High, Low, Medium
Top, Bottom
On, O
Setting value
English
Low, Medium, High, O
10Sec,15Sec, 30Sec, 60Sec
Item
Exit
OSD Language
OSD Blending
OSD Duration*1
OSD
Adjust the OSD display size, color, duration, and TALLY light/keyboard light settings
Key Inhibit
To lock the keyboard for safety operation
To do
Return Main Menu
Phase Phase setting of RGB signal
Setting valueItem
Exit
Auto Adjust*1 Automatically adjust the RGB signal
0-100
0-100
0-100
0-100
Horizontal Pos. Adjust the horizontal position of RGB
Adjust the vertical position of RGB
Vertical Pos.
RGB
Adjust the display position, size, phase under RGB input.
Size Zoom-in/out the signal, default 50
!
Key Inhibit

About the external control
This monitor has three external control terminals.
<Serial communication>
RS-485 IN RS-485
OUT
RS-485
IN
RS-485
OUT
RS-485
IN
RS-485
OUT
TallyMan
External Control
Using the GPI control
Using the UMD control
Pin No Pin name
1 GPI 1
2 GPI 2
3 GPI 3
4 GPI 4
5 GPI 5
This is a female terminal.
6 GPI 6
7 NC
8 GND
To assign the functions to the pin terminals
1Select “GPI” on the Main Menu.
2Set “GPI control” to “ON”.
3 Select a pin name (“Pin1” – “Pin6”) for which you want to assign a
function, then select the function you want to assign.
Operation of the external control
1 Operate each function by short-circuiting the corresponding pin
terminal to the 8th pin terminal (GND) or opening it.
<Functions controlled by the GPI terminal>
Pin No.IN terminal signal OUT terminal signal
1 TXD + TXD +
2 TXD – TXD –
3 RXD + RXD +
4 NC NC
5 NC NC
6 RXD – RXD –
7 NC NC
8 GND GND
This is a female terminal.
Display
Red Tally
Green Tally
Yellow Tally
Video
HDMI
SDI1
SDI2
Aspect Ratio
Scan Mode
Freeze Frame
Time code
Low Latency Mode Low Latency Mode setting
Max Backlight Max Backlight setting
Focus Assist Focus Assist setting
Zebra
Vector
Audio Bar
Histogram
False Color
AFD
H/V Delay
Marker
Color Bar
UMD
Audio Alarm
Color Temp
R/G/B/Mono
Flip Mode
Odd/Even Frame
Functions to be controlled
Tally light red
Tally light green
Tally light yellow
Switch to Video input display
Switch to HDMI input display
Switch to SDI-1 input display
Switch to SDI-2 input display
Changes the aspect ratio.
Changes the scan mode
Freeze Frame setting
Time code display
Zebra display
Vector display
Audio Bar display
Histogram display
False Color display
AFD display
H/V Delay display
Marker display
Color Bar display
UMD display
Audio Alarm display
Color Temp setting
R/G/B/Mono setting
Flip Mode setting
Odd/Even Mode setting
Open Short
RedO
O
O
Green
Yellow
*1
*1
*1
*1
*2
*3
*4
*5
*5
*5
*5
*5
*5
*5
*5
*5
*5
*5
*5
*5
*5
*5
*6
*7
*8
*9
20
RS-485 terminal (RJ-45):
Controls the monitor with the RS-485 system.
The terminal is to connect with TallyMan system of UMD application.
Make contact terminal (RJ-45):
Controls the monitor by short-circuiting the corresponding pin
terminal to the GND pin terminal, or disconnecting (opening) it.
The terminal is to assign functions for GPI controlling.
Webserver IP remote control (RJ-45):
Controls the monitor by computer webpage.
*1 Short-circuit the pin to switch to the input signal.
*2 For every short-circuit contact, the Aspect ratio will change in the
order of 16:9 →4:3 →Auto.
*3 For every short-circuit contact, the Scan mode will change in the
order of Normal →Native.
*4 For every short-circuit contact, the Color temperature will change in
the order of 6500K →5600K →9300K →3200K.
*5 For every short-circuit contact, the value will change in the order of
On →O.
*6 For every short-circuit contact, the Focus assist will change in the
order of O →Red →Blue.
*7 For every short-circuit contact, the R/G/B/Mono will change in the
order of O →Blue only →Red only →Green only →Mono(B&W).
*8 For every short-circuit contact, the Flip mode will change in the
order of O →H Flip →V Flip →H&V Flip.
*9 For every short-circuit contact, the Odd/Even mode will change in
the order of O →Odd Mode →Even Mode.
