JVC KW-V40BT User manual

LVT2522-001A (A)© 2013 JVC KENWOOD Corporation
Please read all instructions carefully before operation to obtain the
best possible performance from the unit.
MONITOR WITH DVD RECEIVER
INSTRUCTION MANUAL
KW-V40BT/KW-V20BT/KW-V10
ENGLISH
KW-VEntryA.indb1KW-VEntryA.indb1 2013/10/319:392013/10/319:39

2
CONTENTSCONTENTS
BEFORE USE...................................................2
How to reset your unit.................................................... 3
How to forcibly eject a disc........................................... 3
INITIAL SETTINGS .........................................4
BASICS ...........................................................5
Component names and functions............................. 5
Common operations....................................................... 6
Common screen operations......................................... 7
Selecting the playback source..................................... 8
DISCS .............................................................9
USB...............................................................13
iPod/iPhone ................................................14
Pandora® .....................................................18
TUNER..........................................................20
OTHER EXTERNAL COMPONENTS .............22
Using external audio/video players—AV-IN ........22
Using external audio players—Front AUX
(only for KW-V20BT/KW-V10).....................................22
Using a rear view camera ............................................23
Using an external monitor— Rear Source
(only for KW-V40BT) ......................................................24
BLUETOOTH
(Only for KW-V40BT/KW-V20BT) .....................25
SETTINGS.....................................................33
Sound adjustment .........................................................33
Adjustment for video playback.................................34
Changing display design.............................................36
Customizing the system settings .............................37
Setting menu items.......................................................39
REMOTE CONTROLLER ...............................42
CONNECTION/INSTALLATION ...................44
REFERENCES................................................48
Maintenance....................................................................48
More information...........................................................48
Error message list...........................................................52
Troubleshooting.............................................................53
Specifications...................................................................55
How to read this manual:
• Illustrations of KW-V40BT are mainly used for explanation. The displays and panels shown in this manual
are examples used to provide clear explanations of the operations. For this reason, they may be different
from the actual displays or panels.
• This manual mainly explains operations using the buttons on the monitor panel and touch panel. For
operations using the remote controller (RM-RK256: supplied only for KW-V40BT), see page 42.
• < > indicates the various screens/menus/operations/settings that appear on the touch panel.
• [ ] indicates the buttons on the touch panel.
• Indication language: English indications are used for the purpose of explanation. You can select the
indication language from the <Settings> menu. (Page41)
BEFORE USEBEFORE USE
VWARNINGS: (To prevent accidents and
damage)
• DO NOT install any unit or wire any cable in a
location where;
– it may obstruct the steering wheel and gearshift
lever operations.
– it may obstruct the operation of safety devices
such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
If you need to operate the unit while driving, be
sure to look around carefully.
• The driver must not watch the monitor while
driving.
KW-VEntryA.indb2KW-VEntryA.indb2 2013/10/319:392013/10/319:39

ENGLISH 3
The marking of products using lasers
The label is attached to the chassis/case and says
that the component uses laser beams that have
been classified as Class 1. It means that the unit is
utilizing laser beams that are of a weaker class. There
is no danger of hazardous radiation outside the unit.
VCautions on the monitor:
• The monitor built into this unit has been
produced with high precision, but it may have
some ineffective dots. This is inevitable and is not
considered defective.
• Do not expose the monitor to direct sunlight.
• Do not operate the touch panel using a ball-point
pen or similar tool with a sharp tip.
Touch the buttons on the touch panel with your
finger directly (if you are wearing a glove, take it
off).
• When the temperature is very cold or very hot...
– Chemical changes occur inside, causing
malfunction.
– Pictures may not appear clearly or may move
slowly. Pictures may not be synchronized with
the sound or picture quality may decline in such
environments.
For safety...
• Do not raise the volume level too much, as this
will make driving dangerous by blocking outside
sounds, and may cause hearing loss.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or
cold weather, wait until the temperature in the car
becomes normal before operating the unit.
RHow to reset your unit
KW-V20BT
KW-V10
KW-V40BT
• Your preset adjustments will also be erased
(except the registered Bluetooth devices).
RHow to forcibly eject a disc
Press and hold Mon the monitor panel for 10
seconds.
KW-V40BT KW-V20BT/KW-V10
(Hold)(Hold)
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit. (See above.)
BEFORE USEBEFORE USE
KW-VEntryA.indb3KW-VEntryA.indb3 2013/10/319:392013/10/319:39

4
INITIAL SETTINGSINITIAL SETTINGS
Initial setup
When you power on the unit for the first time or
reset the unit, the initial setting screen appears.
• You can also change the settings on the
<Settings> screen. (Page39)
1
<Language>
(Page41)
Select the text language
used for on-screen
information.
• Set <GUI Language>
to display the operation
buttons and menu items
in the selected language
([Local]: initially
selected) or English
([English]).
<AV Input>
(Page40)
Select an external
component connected
to the AV-IN1 terminal to
play.
<Camera Input>
(Page40)
Select [On] when
connecting the rear view
camera.
<Display Design>
(Page40)
Select the background
and the colors of the text,
touch panel buttons and
the monitor panel buttons.
<Demonstration>
(Page40)
Activate or deactivate the
display demonstration.
2Finish the procedure.
The <HOME> screen is displayed.
• [AV Off] is selected initially. Select the
playback source. (Page8)
Clock settings
1Display the <HOME> screen.
On the monitor panel:
KW-V40BT KW-V20BT/KW-V10
On the source control screen:
2Display the <Settings> screen.
3Display the <Time Set> screen.
4Set the clock time.
1Select the time display format.
2Adjust the hour.
3Adjust the minute.
5Finish the procedure.
KW-VEntryA.indb4KW-VEntryA.indb4 2013/10/319:392013/10/319:39

ENGLISH 5
BASICSBASICS
Component names and functions
KW-V40BT
1Screen (touch panel)
2Monitor panel*
3Remote sensor
4VOLUME –/+ button
Adjusts the audio volume. (Page 6)
5ATT button
Attenuates the sound. (Page 6)
6HOME/ button
• Displays the <HOME> screen. (Press)
(Page 7)
• Turns off the power. (Hold) (Page 6)
• Turns on the power. (Press) (Page 6)
7/ button
• Displays the phone control screen. (Press)
(Page 28)
• Activates the voice dialing. (Hold) (Page 30)
8DISP/DISP OFF button
• Switches the screen between the current
source and Apps. (Press)
• Turns off the screen. (Hold) (Page 6)
• Turns on the screen. (Hold) (Page 6)
9M(Eject) button
• Displays the <Open/Tilt> screen. (Press)
(Page 6)
• Ejects the disc forcibly. (Hold) (Page 3)
pReset button
Resets the unit. (Page 3)
KW-V20BT/KW-V10
KW-V20BT KW-V10
1Reset button
Resets the unit. (Page 3)
2M(Eject) button
• Ejects the disc. (Press) (Page 9)
• Ejects the disc forcibly. (Hold) (Page 3)
3Loading slot
4HOME/ button
• Displays the <HOME> screen. (Press)
(Page 7)
• Turns off the power. (Hold) (Page 6)
• Turns on the power. (Press) (Page 6)
5For KW-V20BT: / button
• Displays the phone control screen. (Press)
(Page 28)
• Activates the voice dialing. (Hold) (Page 30)
For KW-V10: FNC button
Displays the source control screen. (Page 7)
6VOLUME/ATT knob
• Attenuates the sound. (Press) (Page 6)
• Adjusts the audio volume. (Turn) (Page 6)
7DISP/DISP OFF button
• Switches the screen between the current
source and Apps. (Press)
• Turns off the screen. (Hold) (Page 6)
• Turns on the screen. (Hold) (Page 6)
8AUX input jack
9Monitor panel*
pScreen (touch panel)
* You can change the color of the buttons on the monitor panel.
(Page 36)
VCaution on the volume setting:
Digital devices produce very little noise
compared with other sources. Lower the
volume before playing these digital sources
to avoid damaging the speakers by sudden
increase of the output level.
KW-VEntryA.indb5KW-VEntryA.indb5 2013/10/319:392013/10/319:39

6
BASICSBASICS
Common operations
RTurning on the power
KW-V40BT KW-V20BT/KW-V10
RTurning off the power
KW-V40BT KW-V20BT/KW-V10
(Hold)
(Hold)
RAdjusting the volume
To adjust the volume (00 to 35)
KW-V40BT
Press + to increase, and press – to decrease.
• Holding the button increases/decreases the
volume continuously.
KW-V20BT/KW-V10
Turn to the right to increase, and turn to the left to
decrease.
To attenuate the sound
KW-V40BT KW-V20BT/KW-V10
The ATT indicator lights up.
To cancel the attenuation: Press the same button
again.
RTurning off the screen
On the monitor panel:
KW-V40BT KW-V20BT/KW-V10
(Hold) (Hold)
On the <Home> screen:
To turn on the screen: Press and hold DISP on the
monitor panel, or touch the display.
RTurning on/off the AV source
You can activate the AV function by selecting a
source on the <HOME> screen.
To turn off the AV source:
RMonitor panel operations — <Open/
Tilt> (only for KW-V40BT)
[ Open] Opens the monitor panel.
[ Eject] Ejects the disc.
[ Close] Closes the monitor panel.
• Do not place your finger
behind the monitor panel.
[Tilt +] [ Tilt –] Tilts the monitor panel.
KW-VEntryA.indb6KW-VEntryA.indb6 2013/10/319:392013/10/319:39

ENGLISH 7
BASICSBASICS
Common screen operations
RCommon screen descriptions
You can display other screens any time to change
the source, show the information, or change the
settings, etc.
Source control screen
Performs source playback operations.
• The operation buttons vary depending on the
selected source.
1
2
3
4
Common operation buttons:
1Displays the screen of the App from the
connected iPod touch/iPhone.*1(Page 17)
2Displays the phone control screen.*2 *3
(Page 28)
3Displays the sound adjustment screen.
(Page 33)
4Displays the <HOME> screen. (See the right
column.)
• Pressing HOME on the monitor panel also
displays the <HOME> screen.
Gesture control on the source control screen:
You can also control playback by moving your finger
on the touch panel as follows (for some sources, the
gesture control is not available).
• Sliding the finger towards up/down: Functions
same as pressing [ ]/[ ].
• Sliding the finger towards left/right: Functions
same as pressing [S]/[T].
• Moving your finger clockwise or counter-
clockwise: increases/decreases the volume.
<HOME> screen
Displays the source control screen/settings screen
and changes the picture source.
56 78
123
4
Common operating buttons:
1Changes the playback source. (Page 8)
2Displays the phone control screen.*2
(Page 28)
3Displays the <Settings> screen. (See below.)
4Returns to the previous screen.
5Displays the source control screen. (See the far
left column.)
6Displays the picture from the rear view camera.
(Page 23)
7Displays the screen of the App from connected
iPod touch/iPhone.*1(Page 17)
8Turns off the screen. (Page 6)
<Settings> screen
Changes the detailed settings. (Page 39)
34
1
2
Common operating buttons:
1Selects the menu category.
2Changes the page.
3Returns to the previous screen.
4Displays the current source control screen.
*1Appears when <Input> in <Navigation Input> is set to
[iPhone]. (Page 17)
*2 Only for KW-V40BT/KW-V20BT.
*3 The icon varies depending on the connection status of the Bluetooth
device. (Page 25)
KW-VEntryA.indb7KW-VEntryA.indb7 2013/10/319:392013/10/319:39

8
BASICSBASICS
RTouch screen operations
1
3
2
4
1Displays the video control menu while playing a
video.
2Displays the source control screen while playing
a video.
• The operation buttons disappear when the
screen is touched or when no operation is
done for about 10 seconds.
3Goes to the previous chapter/track.*
4Goes to the next chapter/track.*
* Not available for video from an external component. Dragging your
finger to the left or right functions in the same way as touching.
Selecting the playback source
KW-V40BT
KW-V20BT
KW-V10
[TUNER] Switches to the radio broadcast.
(Page 20)
[DISC] Plays a disc. (Page 9)
[USB] Plays files on a USB device.
(Page 13)
[iPod] Plays an iPod/iPhone. (Page 14)
[Bluetooth]*1
Plays a Bluetooth audio player.
(Page 32)
[Pandora] Switches to the Pandora broadcast.
(Page 18)
[AV-IN]*2 Switches to an external component
connected to the AV-IN1 terminal
on the rear panel. (Page 22)
[Apps]*3 Switches to the App screen from
the connected iPod touch/iPhone.
(Page 16)
[Front AUX]*4 Switches to an external component
connected to AUX input terminal
on the monitor panel. (Page 22)
[AV Off] Turns off the AV source.
(Page 6)
*1 Only for KW-V40BT/KW-V20BT.
*2 Appears only when <AV Input> is set to [AV-IN].
(Page40)
*3 Appears only when <AV Input> is set to [iPod]. (Page40)
*4 Only for KW-V20BT/KW-V10.
KW-VEntryA.indb8KW-VEntryA.indb8 2013/10/319:392013/10/319:39

ENGLISH 9
DISCSDISCS
Playing a disc
• If a disc does not have a disc menu, all tracks on
it will be played repeatedly until you change the
source or eject the disc.
• For playable disc types/file types, see page 49.
RInserting a disc
Insert a disc with the label side facing up.
• For KW-V40BT: To open the monitor panel, see
page 6.
KW-V40BT KW-V20BT/KW-V10
The source changes to “DISC” and playback starts.
• The DISC IN ( ) indicator lights up while a
disc is inserted.
• If “ ” appears on the screen, the unit cannot
accept the operation you have tried to do.
– In some cases, without showing “ ,”
operations will not be accepted.
• When playing back a multi-channel
encoded disc, the multi-channel signals are
downmixed to stereo.
REjecting a disc
KW-V40BT
KW-V20BT/KW-V10
• When removing a disc, pull it horizontally.
• You can eject a disc when playing another AV
source.
• If the ejected disc is not removed within
15 seconds, the disc is automatically inserted
again into the loading slot to protect it from dust.
• If the disc cannot be ejected, see page 3.
Playback operations
• When the operation buttons
are not displayed on the screen,
touch the area shown on the
illustration.
– For KW-V10: You can also
display/hide the operation
buttons by pressing FNC on
the monitor panel.
– To change settings for video
playback, see page 34.
RIndications and buttons on the source
control screen
For DVD/DVD-VR/VCD/DivX/MPEG1/MPEG2/JPEG
12 3 6
7
5
8
4
Playback information
1Media type
2Audio format
3Playback mode (Page12)
4Playing time
5Playback status (I: play/W: pause/o: stop)
6DISC IN indicator
7Video format/video playback mode—VIDEO/VR-
PRG (program)/VR-PLAY (playlist)/ DivX/MPEG/
PBC
8Current playback item information
• DVD Video: Title no./Chapter no.
• DVD-VR: Program no. (or Playlist no.)/Chapter
no.
• DivX/MPEG1/MPEG2: Folder no./Track no.
• JPEG: Folder no./File no.
• VCD: Track no.
KW-VEntryA.indb9KW-VEntryA.indb9 2013/10/319:392013/10/319:39

10
DISCSDISCS
Operation buttons
[o]*1 Stops playback.
[ ]*2 Displays the folder/track list. (See
the far right column.)
[]
[ ]*3
Selects playback mode.
(Page12)
[I/W]Starts/pauses playback.
[S] [T]*4• Selects a chapter/track. (Press)
• Reverse/forward search.*5 (Hold)
[] [ ]*4*6
Selects title (DVD)/program or
playlist (DVD-VR)/folder (DivX/
MPEG1/MPEG2/JPEG).
[Mode]*6 Changes the settings for disc
playback on the <Mode> screen.
(Page12)
[HOME] Displays the <HOME> screen.
*1
Appears only for DVD/DVD-VR/VCD.
*2 Does not appear for DVD/DVD-VR/VCD.
*3 Does not appear for DVD/DVD-VR/JPEG.
*4The icon displayed between the buttons varies depending on the
type of disc or file.
*5Search speed varies depending on the type of disc or file.
*6 Does not appear for VCD.
For CD/MP3/WMA/WAV
12 3 65
8
9
4 7
Playback information
1Media type
2Audio format
3Playback mode (Page12)
4Playing time
5Playback status (I: play/W: pause/o: stop)
6DISC IN indicator
7Track/file information
• Touching the information bar scrolls the text if
not all of the text is shown.
8Current playback item information
• MP3/WMA/WAV: Folder no./Track no.
• CD: Track no.
9Jacket picture (Shown while playing if the file has
tag data that includes the jacket picture)
Operation buttons
[ ]*1 Displays the folder/track list. (See
the right column.)
[ ] [ ] Selects playback mode.
(Page12)
[I/W]Starts/pauses playback.
[S] [T]• Selects a track. (Press)
• Reverse/forward search.*2(Hold)
[ ] [ ]*1 Selects a folder.
[Mode]*1 Changes the settings for disc
playback on the <Mode> screen.
(Page12)
[HOME] Displays the <HOME> screen.
*1Does not appear for CD.
*2 Search speed varies depending on the type of disc or file.
RSelecting a folder/track on the list
1
2Select the folder (1), then the item in the
selected folder (2).
• Repeat the procedure until you select the
desired track.
• If you want to play all tracks in the folder,
press [I] on the right of the desired folder.
• You can change the page to display more
items by pressing [J]/[K].
• Press [Root] to return to the root folder.
• Press [] to return to the upper layer.
KW-VEntryA.indb10KW-VEntryA.indb10 2013/10/319:392013/10/319:39

ENGLISH 11
DISCSDISCS
RVideo menu operations
You can display the video menu screen during video
playback.
• Available items on the screen differ depending on
the types of the loaded disc and playback files.
• The operation buttons disappear when the screen
is touched or when no operation is done for about
10 seconds.
*
*
*
[Zoom] Displays the picture size selecting
screen. (Page35)
[Aspect] Selects the aspect ratio. (Page35)
[Adjust] Displays the picture adjustment
screen. (Page34)
[ ]* Selects the audio type.
• For DVD-VR: Selects the audio
channel (ST: stereo, L: left, R: right).
[ ]* Selects the subtitle type.
[ ]* Selects the view angle.
[Menu]* Displays the disc menu (DVD)/
playlist (DVD-VR).
[Top Menu]* Displays the disc menu (DVD)/
original program (DVD-VR).
[ ]* Displays the menu/playlist/original
program/scene selecting screen.
• [J] [K] [H] [I]: Selects an item.
– For DivX: [H] [I] skips back or
forward by about 5 minutes.
• [Enter]: Confirms the selection.
• [Return]: Returns to the previous
screen.
• [ ]: Displays the menu screen of
the top layer when several menu
screens exist on the disc.
– For DivX: Exits from the scene
selecting screen.
[ ]* Switches to the direct disc menu
mode. Touch the target item to
select.
• To exit from the menu selecting
screen, press [ ].
* Does not appear for MPEG1/MPEG2.
• Touching any position other than operation
buttons displays the source control screen.
For VCD
1
2
[Zoom] Displays the picture size selecting
screen. (Page35)
[Aspect] Selects the aspect ratio. (Page35)
[Adjust] Displays the picture adjustment
screen. (Page34)
[ ] Selects the audio channel (ST: stereo,
L: left, R: right).
[Return] Displays the previous screen or menu.
[Menu] Displays the disc menu.
[ ] Displays/hides the direct selecting
buttons. (See below.)
• To select a track directly, press [ ] to display
the direct selecting buttons, then...
– When you enter a wrong number, press [Direct/
CLR] to delete the last entry.
• To deactivate the PBC function, stop playback,
then use the direct selecting buttons to select a
track number.
KW-VEntryA.indb11KW-VEntryA.indb11 2013/10/319:392013/10/319:39

12
DISCSDISCS
RSelecting playback mode
[ ] Selects Repeat playback mode.
[ ] Selects Random playback mode.
• For DVD/DVD-VR: Repeat play is available.
For VCD (without PBC)/CD/DivX/MPEG1/MPEG2/
MP3/WMA/WAV: Repeat and Random play are
available.
– You cannot activate the repeat mode and the
random mode at the same time.
• Each time you press the button, the playback
mode changes. (The corresponding indicator
lights up.)
– Available items differ depending on the types of
loaded disc and playback file.
PROGRAM Repeats current program (not
available for Playlist playback).
CHAPTER Repeats current chapter.
TITLE Repeats current title.
SONGS Repeats current track.
FOLDER Repeats all tracks of the
current folder.
FOLDER Randomly plays all tracks of
the current folder, then tracks
of the next folders.
ALL Randomly plays all tracks.
To cancel Repeat/Random playback: Press the
button repeatedly until the indicator disappears.
Settings for disc playback
• The items shown on the <Mode> screen are
different depending on the discs/files played back.
RSetting items
<Menu
Language>
Select the initial disc menu language.
(Initial: English) (Page51)
<Audio
Language>
Select the initial audio language.
(Initial: English) (Page51)
<Subtitle> Select the initial subtitle language
or turn subtitles off (Off). (Initial:
English) (Page51)
<Down Mix> When playing back a multi-channel
disc, this setting affects the signals
reproduced through the front and/
or rear speakers and AV-OUT/Audio
output*1.
• Dolby Surround: Select this to
enjoy multi-channel surround
sound by connecting an amplifier
compatible with Dolby Surround.
• Stereo (initial): Normally select
this.
<D. Range
Compres.>
You can change the dynamic range
while playing Dolby Digital software.
• Off: Select this to enjoy a powerful
sound at a low volume level with
its full dynamic range.
• On (initial): Select this to reduce
the dynamic range a little.
• Dialog: Select this to reproduce
movie dialog more clearly.
<Monitor
Type>
Select the monitor type to watch a
wide screen picture on the external
monitor.
16:9
(Initial) 4:3 LB 4:3 PS
<File
Type>*2
Select the playback file type when a
disc contains different types of files.
• Audio: Plays back audio files.
• Still Picture: Plays back JPEG files.
• Video: Plays back DivX/MPEG1/
MPEG2 files.
• Audio&Video (initial): Plays back
audio files and DivX/MPEG1/
MPEG2 files.
*1Only for KW-V40BT.
*2For playable file types, see page 49.
If the disc contains no files of the selected type, the existing files are
played in the following priority: audio, video, then still picture.
KW-VEntryA.indb12KW-VEntryA.indb12 2013/10/319:392013/10/319:39

ENGLISH 13
USBUSB
Connecting a USB device
You can connect a USB mass storage class device
such as a USB memory, Digital Audio Player etc. to
the unit.
• For details about connecting USB devices, see
page 47.
• You cannot connect a computer or portable HDD
to the USB input terminal.
• For playable file types and notes on using USB
devices, see page 50.
When a USB device is connected...
The source changes to “USB” and playback starts.
• All tracks in the USB device will be played
repeatedly until you change the source.
Playback operations
• When the operation buttons
are not displayed on the screen,
touch the area shown on the
illustration.
– For KW-V10: You can also
display/hide the operation
buttons by pressing FNC on
the monitor panel.
– To change settings for video
playback, see page 34.
RIndications and buttons on the source
control screen
12 4
7
8
6
3 5
Playback information
1Audio format
2Playback mode (See the right column.)
3Playing time
4Playback status (I: play/W: pause/o: stop)
5Track/file information (for MP3/WMA/WAV)
• Touching the information bar scrolls the text if
not all of the text is shown.
6Video format—MPEG/JPEG
7Current playback item information
• MPEG1/MPEG2/MP3/WMA/WAV: Folder no./
Track no.
• JPEG: Folder no./File no.
8Jacket picture (Shown while playing if the file has
tag data that includes the jacket picture)
Operation buttons
[ ] Displays the folder/track list.
(Page14)
[ ] Selects repeat playback mode.*1 *2
• SONGS: Repeats the current
track.
• FOLDER: Repeats all tracks in
the current folder.
[ ] Selects random playback mode.*1 *2
• FOLDER: Randomly plays all
tracks in the folder.
• ALL: Randomly plays all tracks.
[ ] Switches between the internal and
external memory source of the
connected device (such as mobile
phone).
[I/W]Starts/pauses playback.
[S] [T]*3• Selects a track. (Press)
• Reverse/forward search.*4(Hold)
[ ] [ ] Selects a folder.
[Mode] Changes the settings for <File
Type> /<Monitor Type> on the
<Mode> screen. (Page14)
[HOME] Displays the <HOME> screen.
*1
To cancel random or repeat mode, press the button repeatedly until
the indicator disappears.
*2 You cannot activate the repeat mode and the random mode at the
same time.
*3The icon displayed between the buttons varies depending on the file
type.
*4Search speed varies depending on the file type.
KW-VEntryA.indb13KW-VEntryA.indb13 2013/10/319:392013/10/319:39

14
USBUSB
R<Mode> settings
Setting <File Type>
[Audio] Plays back audio files.
[Still Picture] Plays back JPEG files.
[Video] Plays back MPEG1/MPEG2 files.
[Audio&Video]
(Initial)
Plays back audio files and
MPEG1/MPEG2 files.
• For playable files, see page 50. If the USB device
contains no files of the selected type, the existing
files are played in the following priority: audio,
video, then still picture.
Setting <Monitor Type>
Select the monitor type to watch a wide screen
picture on the external monitor.
[16:9] (Initial) [4:3 LB] [4:3 PS]
RSelecting a folder/track on the list
1
2Select the folder (1), then the item in the
selected folder (2).
• Repeat the procedure until you select the
desired track.
• If you want to play all tracks in the folder,
press [I] on the right of the desired folder.
• You can change the page to display more
items by pressing [J]/[K].
• Press [Root] to return to the root folder.
• Press [] to return to the upper layer.
iPod/iPhoneiPod/iPhone
• To use iPod touch/iPhone Apps, see page 16.
• To listen to Pandora, see page 18.
Preparation
RConnecting iPod/iPhone
• For details about connecting iPod/iPhone, see
page 47.
• For playable iPod/iPhone types, see page 50.
Connect your iPod/iPhone using the appropriate
cable according to your purpose.
• To listen to music: USB 2.0 cable (accessory of the
iPod/iPhone)
• To watch video and listen to music: USB Audio
and Video cable for iPod/iPhone—KS-U59
(optional accessory)
– You cannot connect iPod nano (7th Generation)/
iPod touch (5th Generation)/iPhone 5 with
KS-U59.
RSelecting preference settings for iPod/
iPhone playback
When the source is “iPod”...
1
2
<Audiobooks> Select the speed of audio
books.
<Artwork> Shows/hides the iPod artwork.
KW-VEntryA.indb14KW-VEntryA.indb14 2013/10/319:392013/10/319:39

ENGLISH 15
iPod/iPhoneiPod/iPhone
RSetting <AV Input> for iPod/iPhone
playback
Select an appropriate input setting for <AV Input>
according to the connection method of the iPod/
iPhone.
• For KW-V40BT: Make sure that “AV Off” is selected
as the rear source. (Page24)
1Turn off the AV source.
On the <HOME> screen:
2 Display the <Input> setting screen.
3
[AV-IN] Select this when the iPod/iPhone is
connected using the USB 2.0 cable
(accessory of the iPod/iPhone).
[iPod] Select this when the iPod/iPhone is
connected using KS-U59 (optional
accessory).
Playback operations
• When the operation buttons
are not displayed on the screen,
touch the area shown on the
illustration.
– For KW-V10: You can also
display/hide the operation
buttons by pressing FNC on
the monitor panel.
– To change settings for video
playback, see page 34.
RIndications and buttons on the source
control screen
1 3
5
6
2 4
Playback information
1Playback mode (Page16)
2Playing time
3Playback status (I: play/W: pause)
4Song/video information
• Touching the information bar scrolls the text if
not all of the text is shown.
5Track no./Total track number
6Artwork (Shown if the song contains Artwork)
• To change the Artwork display, see page 14.
KW-VEntryA.indb15KW-VEntryA.indb15 2013/10/319:392013/10/319:39

16
iPod/iPhoneiPod/iPhone
Operation buttons
[ ] Displays the audio/video file list. (See
below.)
[ ] Selects repeat playback mode.
• SONGS: Functions the same
as “Repeat One.”
• ALL: Functions the same as
“Repeat All.”
[ ] Selects random playback mode.*1
• SONGS: Functions the same as
“Shuffle Songs.”
• ALBUMS: Functions the same
as “Shuffle Albums.”
[I/W]Starts/pauses playback.
[S] [T]• Selects an audio/video file.*2(Press)
• Reverse/forward search. (Hold)
[Mode] Changes the settings for iPod/iPhone
playback on the <Mode> screen.
(Page14)
[HOME] Displays the <HOME> screen.
*1
To cancel random mode, press the button repeatedly until the
indicator disappears.
*2
Resume playback is unavailable for video files.
RSelecting an audio/video file from the
menu
1
2Select the menu ( : audio or :
video) (1), a category (2), then a desired
item (3).
• Select the item in the selected layer until a
desired file starts playing.
• If you want to play all items in the layer, press
[I] on the right of the desired item.
Audio menu:
*
Video menu:
*
• You can change the page to display more
items by pressing [J]/[K].
• Press [Top] to return to the top layer.
• Press [] to return to the upper layer.
• Available categories differ depending on the type
of your iPod/iPhone.
* You can switch to the top of the category by pressing the
corresponding tab: Playlist (), Artist (), Albums () or
Songs ().
Using an iPod touch/iPhone App
You can use an App of the connected iPod touch/
iPhone on this unit.
• You cannot use Apps with iPod touch (5th
Generation)/iPhone 5.
• When you use an iPod touch or iPhone App, see
also page 51 for safety instructions.
• For Apps you can use on this unit, visit
<http://www.jvc.net/cs/car/>.
Preparation
• Connect the iPod touch/iPhone using KS-U59
(optional accessory). (Page47)
• Select [iPod] for <AV Input>. (Page15)
RPlayback operations
1Start App on your iPod touch/iPhone.
2Select “Apps” as the source. (Page8)
• You can operate some functions of the App on the
touch panel.
Audio:
KW-VEntryA.indb16KW-VEntryA.indb16 2013/10/319:392013/10/319:39

ENGLISH 17
iPod/iPhoneiPod/iPhone
Video:
For some applications such as navigation
applications, the operating buttons and information
are not shown. You can perform the operations on
the touch panel, such as scrolling the map.
You can also play back the audio/video using iPod/
iPhone itself instead of the unit.
RDisplaying the App screen while
listening to another source
You can switch to the App screen from the
connected iPod touch/iPhone while listening to
another source.
Displaying the Apps switch button on the source
control screen and <HOME> screen
• For KW-V40BT: Make sure that “AV Off” is selected
as the rear source. (Page24)
• Select [AV] for <Display> on the <HOME> screen
beforehand. (Page7)
1Turn off the AV source. (Page6)
2Display the <Input> setting screen.
3Select [iPhone] for <Input> on the
<Navigation Input> screen.
When <Input> is set to [iPhone], the [Apps] button
is shown on the <HOME> screen, and the
[ ] button is shown on the source control screen.
You can display the App screen by pressing either
button. (See the right column.)
• When <Input> is set to [iPhone], the <AV Input>
setting is automatically changed and fixed to
[iPod].
To deactivate: Select [Off] for <Input>.
To view the App screen
On the <HOME> screen:
On the source control screen:
On the monitor panel:
KW-V40BT KW-V20BT/KW-V10
To exit the App screen
KW-V40BT KW-V20BT/KW-V10
• You can also exit the App screen by pressing [AV]
on the <HOME> screen after pressing HOME on
the monitor panel.
KW-VEntryA.indb17KW-VEntryA.indb17 2013/10/319:392013/10/319:39

18
Pandora®Pandora®
You can stream Pandora from iPod touch/iPhone
via a wired connection or from Android devices
through Bluetooth.
• Install the latest version of the Pandora
application on your iPod touch/iPhone/Android.
• Android devices can only be used with
KW-V40BT/KW-V20BT.
Preparation
Connect the device, then start Pandora application.
For Android
1Pair the Android device through Bluetooth.
(Page25)
2Select “Pandora” as the source.
(Page8)
3Connect the Android device for using
Pandora on the <Bluetooth Setup>
screen. (Page26)
“Connected” appears. Press [OK] to confirm the
operation.
When the connection is established, the
Pandora application is started and “Pandora”
source control screen is displayed.
For iPod touch/iPhone
1Connect the iPod touch/iPhone to the USB
terminal using KS-U59 (optional accessory)
or USB 2.0 cable (accessory of the iPod/
iPhone). (Page
47)
2Start the Pandora application on the
connected iPod touch/iPhone.
The “Pandora” source control screen is
displayed.
• You can also display the “Pandora” source control
screen by connecting the iPod touch/iPhone using
KS-U59 after starting the Pandora application.
Playback operations
You can operate Pandora using the remote
controller. Only playing, pausing, and skipping are
available.
RIndications and buttons on the source
control screen
12
4
3
Playback information
1Station name/playing time
2Playback status (I: play/W: pause)
3Track information
• Touching the information bar scrolls the text if
not all of the text is shown.
4Picture data (Shown if available from current
content and when iPod touch/iPhone is
connected via USB)
Operation buttons
[ ] Displays the <Station List> screen.
[Genre] Displays the <Genre List> screen.
[ ] Registers the current track as a
favorite.
[ ] Thumbs down to the current track
and skips to the next track.
[ ] Adds the current artist to the
<Station List>.
[ ] Adds the current track to the
<Station List>.
[I/W]Starts/pauses playback.
[T]Skips the current track.
• Not available when the Pandora
skip reaches its limit.
[HOME] Displays the <HOME> screen.
KW-VEntryA.indb18KW-VEntryA.indb18 2013/10/319:392013/10/319:39

ENGLISH 19
Pandora®Pandora®
RAdding a station from the <Genre List>
to the <Station list>
The screen shows the genres sent by the connected
device. Select a genre and station to add to the
Station List.
1Display <Genre List> screen.
2Select a genre.
• You can change the page to display more
items by pressing [J]/[K].
3Select a station.
• You can change the page to display more
items by pressing [J]/[K].
The selected station is added to the Station List.
RSelecting a station from the <Station
List>
• You can change the page to display more items by
pressing [J]/[K].
• The indicator appears on the left of the
item when Shuffle is activated (All songs on the
registered stations are played randomly).
• The indicator appears on the right of the item
when the station is shared.
To sort the <Station List>
[By Date] Sorts the list in reverse chronological
order.
[A−Z] Sorts the list in alphabetical order.
Requirements for Pandora®
iPhone or iPod touch
• Install the latest version of the Pandora application
on your iPhone or iPod touch. (Search for
“Pandora” in the Apple iTunes App Store to find
and install the most current version.)
• Connect iPod touch/iPhone to this unit with
KS-U59 (optional accessory) or USB 2.0 cable
(accessory of the iPod/iPhone).
Android™
• Visit Google play and search for Pandora to install.
• Bluetooth must be built in and the following
profiles must be supported.
– SPP (Serial Port Profile)
– A2DP (Advanced Audio Distribution Profile)
NOTE
• Ensure you are logged in to your smartphone
application. If you do not have a Pandora account,
you can create one for free from your smartphone
or at www.pandora.com.
• Pandora is available only in the U.S./Australia/New
Zealand.
• Because Pandora is a third-party service, the
specifications are subject to change without
prior notice. Accordingly, compatibility may
be impaired or some or all of the services may
become unavailable.
• Some functions of Pandora cannot be operated
from this unit.
• For issues using the application, contact Pandora
at [email protected]
• Establish an Internet connection using LTE, 3G,
EDGE, or WiFi.
KW-VEntryA.indb19KW-VEntryA.indb19 2013/10/319:392013/10/319:39

20
TUNERTUNER
Listening to the radio
RIndications and buttons on the source
control screen
12345
6
Tuner reception information
1Band
2Preset no.
3The station frequency currently tuned in
4ST/MO indicator
• The ST indicator lights up when receiving an
FM stereo broadcast with sufficient signal
strength.
5DX/LO indicator
6Preset list
Operation buttons
[P1] – [P6] • Selects a stored station. (Press)
• Stores the current station. (Hold)
[BAND] Selects the band.
[S] [T]Searches for a station.
• Auto search (Press)
• Manual search (Hold)
[] [ ] Selects a stored station.
[Mode] Changes the settings for tuner
reception on the <Mode> screen.
(Pages20–21)
[HOME] Displays the <HOME> screen.
RImproving the FM reception
Activate monaural mode for better reception.
1
2
[On] Activate monaural mode to improve
FM reception, but the stereo effect will
be lost. The MO indicator lights up.
[Off] Restore the stereo effect.
RTuning in FM stations only with strong
signals—LO/DX (Local/Distance-
extreme)
1
2
[Local] Select this to tune in only to stations
with sufficient signal strength. The
LO indicator lights up.
[DX] Deactivate the function. The DX
indicator lights up.
KW-VEntryA.indb20KW-VEntryA.indb20 2013/10/319:392013/10/319:39
