DT-V1910CG MULTI-FORMAT MONITOR
OPERATING INSTRUCTIONS

(No.52097)
DT-V1910CG/U
2
FCC INFORMATION (U.S.A. only) CAUTION: Changes or modification not approved by JVC could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
SCREEN BURN ●It is not recommended to keep a certain still image
displayed on screen for a long time as well as displaying extremely bright images on screen. This may cause a burning (sticking) phenomenon on the screen of cathode-ray tube. This problem does not occur as far as displaying normal video playback motion images.
PRECAUTIONS ●Use only the power source specified on the unit.
(120 V/230 V AC, 50 Hz/60 Hz)
●Keep flammable material, water, and metal objects away
from the unit – especially the interior of the unit.
●This unit incorporates high voltage circuitry.
For your own safety and that of your equipment, do not attempt to modify or disassemble this monitor. There are no user-serviceable parts inside.
●Video or audio signals cannot be input to this monitor
without optional input cards.
●In these instructions, all explanations (except where noted)
refer to the DT-V1910CG with input cards installed.
HANDLING ●Avoid shocks or vibrations. These may damage the unit and
cause it to malfunction.
●Do not block the ventilation slots. ●Do not expose this unit to high temperatures.
Extended exposure to direct sunlight or a heater could deform the cabinet or cause the performance of internal components to deteriorate.
●Do not place the unit near appliances generating strong
electric or magnetic fields. There can generate picture noise and instability.
●Keep the monitor clean by wiping the cabinet and CRT
screen with a piece of soft cloth. Do not apply thinner or benzine. These chemicals can damage the finish and erase printed letters. When the unit is excessively dirty, use a diluted neutral cleanser, then wipe away the cleanser with a dry cloth.
DEGAUSS ●Do not use a magnet eraser to degauss the monitor’s
cathode ray tube from the outside. Doing so may distort its aperture grill and cause a malfunction.
In order to prevent any fatal accidents caused by misoperation or mishandling the monitor, be fully aware of all the following precautions.
WARNINGS To prevent fire or shock hazard, do not expose this monitor to rain or moisture. Dangerous high voltages are present inside the unit. Do not remove the back cover of the cabinet. When servicing the monitor, consult qualified service personnel. Never try to service it yourself. WARNING : THIS APPARATUS
MUST BE EARTHED.
This monitor is equipped with a 3-blade grounding-type plug to satisfy FCC rule. If you are unable to insert the plug into the outlet, contact your electrician.
Improper operations, in particular alternation of high voltage or changing the type of tube may result in x-ray emission of considerable dose. A unit altered in such a way no longer meets the standards of certification, and must therefore no longer be operated.
Notice (U.S.A. only) This product utilizes both a Cathode Ray Tube (CRT) and other components that contain lead. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information please contact your local authorities, or the Electronics Industries Alliance: <http://www.eiae.org.>
SAFETY PRECAUTIONS
3
SAFETY PRECAUTIONS ........................................................................2 CONTROLS AND FEATURES ................................................................ 4 CONTROLS AND FEATURES (INPUT CARD: OPTIONAL) ..................................................................7 PREPARATION .......................................................................................9 BASIC MENU OPERATIONS (MAIN MENU, SETUP MENU) ............................................................ 11 HOW TO USE “MAIN MENU”...............................................................13 HOW TO USE “SETUP MENU” ............................................................ 16 HOW TO USE EXTERNAL CONTROL ................................................. 21 TROUBLESHOOTING...........................................................................23
SELF-CHECK INDICATIONS .............................................................. 25
SPECIFICATIONS ................................................................................. 26
CONTENTS
Fuse
POWER CONNECTION The power supply voltage rating of this product is AC 120 V (For U.S.A. and Canada only) and AC 230 V (For European countries or United Kingdom), the power cord attached conforms to the following power supply voltage and countries. Use only the power cord designated to ensure Safety and EMC regulations of each countries. Power cord Power supply voltage : AC 120 V AC 230 V AC 230 V Countries : U.S.A. and Canada European countries United Kingdom Warning: ●
Do not use the same Power Cord for AC 120 V as for AC 230 V. Doing so may cause malfunction, electric shock or fire.
Note for the United Kingdom power cord only The plug on the United Kingdom power cord has a built-in fuse. When replacing the fuse, be sure to use only a correctly rated approved type, re-fit the fuse cover. (Consult your dealer or qualified service personnel.)
How to replace the fuse Open the fuse compartment with the blade screw driver, and replace the fuse. (* An example is shown in the illustration.)

(No.52097)
DT-V1910CG/E
ENGLISH
1
INSTRUCTIONS
MULTI-FORMAT MONITOR
DT-V1910CG
Thank you for purchasing this JVC Multi-Format Monitor. Before using it, read and follow all instructions carefully to take full advantage of the monitor’s capabilities.
For Customer Use: Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future reference.
Serial No. :Model No. :
DT-V1910CG
SAFETY PRECAUTIONS ........................................................................2 CONTROLS AND FEATURES ................................................................ 4 CONTROLS AND FEATURES
(INPUT CARD: OPTIONAL) ..................................................................7
PREPARATION .......................................................................................9 BASIC MENU OPERATIONS
(MAIN MENU, SETUP MENU) ............................................................ 11
HOW TO USE “MAIN MENU”...............................................................13 HOW TO USE “SETUP MENU” ............................................................ 16 HOW TO USE EXTERNAL CONTROL ................................................. 21 TROUBLESHOOTING...........................................................................23
SELF-CHECK INDICATIONS .............................................................. 25
SPECIFICATIONS ................................................................................. 26
CONTENTS
DT-V1910CG MULTI-FORMAT MONITOR
VICTOR COMPANY OF JAPAN, LIMITED
©
2003 VICTOR COMPANY OF JAPAN, LIMITED
Printed in Japan 0103-MA-UN-VP

(No.52097)
DT-V1910CG/E
2
SCREEN BURN ●It is not recommended to keep a certain still image
displayed on screen for a long time as well as displaying extremely bright images on screen. This may cause a burning (sticking) phenomenon on the screen of cathode-ray tube. This problem does not occur as far as displaying normal video playback motion images.
PRECAUTIONS ●Use only the power source specified on the unit.
(120 V/230 V AC, 50 Hz/60 Hz)
●Keep flammable material, water, and metal objects away
from the unit – especially the interior of the unit.
●This unit incorporates high voltage circuitry.
For your own safety and that of your equipment, do not attempt to modify or disassemble this monitor. There are no user-serviceable parts inside.
●Video or audio signals cannot be input to this monitor
without optional input cards.
●In these instructions, all explanations (except where noted)
refer to the DT-V1910CG with input cards installed.
HANDLING ●Avoid shocks or vibrations. These may damage the unit and
cause it to malfunction.
●Do not block the ventilation slots. ●Do not expose this unit to high temperatures.
Extended exposure to direct sunlight or a heater could deform the cabinet or cause the performance of internal components to deteriorate.
●Do not place the unit near appliances generating strong
electric or magnetic fields. There can generate picture noise and instability.
●Keep the monitor clean by wiping the cabinet and CRT
screen with a piece of soft cloth. Do not apply thinner or benzine. These chemicals can damage the finish and erase printed letters. When the unit is excessively dirty, use a diluted neutral cleanser, then wipe away the cleanser with a dry cloth.
DEGAUSS ●Do not use a magnet eraser to degauss the monitor’s
cathode ray tube from the outside. Doing so may distort its aperture grill and cause a malfunction.
In order to prevent any fatal accidents caused by misoperation or mishandling the monitor, be fully aware of all the following precautions.
WARNINGS To prevent fire or shock hazard, do not expose this monitor to rain or moisture. Dangerous high voltages are present inside the unit. Do not remove the back cover of the cabinet. When servicing the monitor, consult qualified service personnel. Never try to service it yourself. WARNING : THIS APPARATUS
MUST BE EARTHED.
Improper operations, in particular alternation of high voltage or changing the type of tube may result in x-ray emission of considerable dose. A unit altered in such a way no longer meets the standards of certification, and must therefore no longer be operated. This monitor is equipped with a 3-blade grounding-type plug to satisfy FCC rule. If you are unable to insert the plug into the outlet, contact your electrician.
FCC NOTICE (U.S.A. only) CAUTION:
Changes or modifications not approved by
JVC could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
SAFETY PRECAUTIONS
ENGLISH
3
Fuse
EMC Supplement (Europe only)
This equipment is in conformity with the provisions and protection requirements of the corresponding European Directives. This equipment is designed for professional video appliances and can be used in the following environments:
●Controlled EMC environment (for example purpose built broadcasting or recording studio), and the rural outdoors environ-
ment (far away from railways, transmitters, overhead power lines, etc.)
In order to keep the best performance and furthermore for electromagnetic compatibility we recommend to use cables not exceeding the following length:
Cable Length Power cord (attached cable) 2.0 m Video signal cable (coaxial cable) 2.0 m Y/C signal cable (shielded cable) 3.0 m Audio signal cable (shielded cable) 1.0 m D-sub 9-pin cable (shielded cable) 1.5 m D-sub 15-pin cable (shielded cable) 1.0 m
The inrush current of this apparatus is 20.1 ampere. Caution When in case that the strong electromagnetic waves or magnetism is near the audio cable or the signal cable, the sound or the picture will contain noise. In such case, please keep the cable away from the sources of the disturbance. POWER CONNECTION The power supply voltage rating of this product is AC 120 V (For U.S.A. and Canada only) and AC 230 V (For European countries or United Kingdom), the power cord attached conforms to the following power supply voltage and countries. Use only the power cord designated to ensure Safety and EMC regulations of each countries. Power cord Power supply voltage : AC 120 V AC 230 V AC 230 V Countries : U.S.A. and Canada European countries United Kingdom Warning: ●
Do not use the same Power Cord for AC 120 V as for AC 230 V. Doing so may cause malfunction, electric shock or fire.
Note for the United Kingdom power cord only The plug on the United Kingdom power cord has a built-in fuse. When replacing the fuse, be sure to use only a correctly rated approved type, re-fit the fuse cover. (Consult your dealer or qualified service personnel.)
How to replace the fuse Open the fuse compartment with the blade screw driver, and replace the fuse. (* An example is shown in the illustration.)

(No.52097)
DT-V1910CG
4
CONTROLS AND FEATURES
FRONT VIEW <Front Panel>
Tally lamp Lights when the tally control signal is ON. • Set the MAKE/TRIGGER terminal’s tally control in the
REMOTE (external control) terminal setup menu.
The lamp color can be set to red or green. • To set the color, use TALLY SELECT in the “FUNCTION
SETTING” setup menu or MAKE/TRIGGER in the REMOTE (external control) terminal setup menu.
For details, refer to Page 17 and 21.
PHASE adjustment knob Adjusts picture hue. • Turn the knob to the left to make the picture redder, and
turn it to the right to make the picture greener.
CHROMA adjustment knob Adjusts picture color density. • Turn the knob to the left to make the picture color
lighter, and turn it to the right to make the picture color deeper.
BRIGHT adjustment knob Adjusts picture brightness. • Turn the knob to the left to make the picture darker, and
turn it to the right to make the picture brighter.
CONTRAST adjustment knob Adjusts picture contrast. • Turn the knob to the left to make the picture contrast
lower, and turn it to the right to make the picture contrast higher.
VOLUME buttons Adjusts the speaker volume. • Pressing this button displays the VOLUME level bar on
the screen. Pressing the button again allows you to adjust speaker volume.
1
10
2 3 4 5 6
9
11
VOLUME
SLOT 1
AB
DEGAUSS
MENU SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF
SLOT 2
CD
SLOT 3 POWER
EF
INPUT SELECT
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF
SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT
2 3 4 5 8 11 12 13 14
1096 6 15 16 17
18 19 20
1
MUTING
7
8 7
!
!
MUTING button Pressing this button mutes the output sound. • To cancel “MUTING ON” (no sound), press MUTING
button again, or press the VOLUME “–” or “+” buttons.
NOTE: When a menu or setting item (such as MAIN MENU, SETUP MENU, sub-menu, or VOLUME bar) is displayed on the screen, this button functions as a control button for the menu screen. In this case, it will not mute the sound when pressed. EMBEDDED AUDIO channel switch button Press this button while the VOLUME bar is displayed on the screen to change the input sound channel. • When the button is pressed, the next highest
channel is selected.
• When the button is pressed, the next lowest channel
is selected.
NOTES: Switchable channels correspond with the group selected in the “E.AUDIO GROUP” of the “FUNCTION SETTING” setup menu. * Valid when an input card compliant with EMBEDDED AUDIO is
installed.
Menu select buttons Selects menu screen items or set-up menu screen. MENU button Displays, adjusts or closes a menu screen. DEGAUSS button/lamp Press the DEGAUSS button. The button lights and degaussing is performed automatically. • When the degaussing is completed, the light goes off.
5
13 12 UNDER SCAN button/lamp
Press the UNDER SCAN button. The button lights and the screen is reduced (under-scan) and the whole screen is displayed. • When the UNDER SCAN button is pressed while lit, the
light goes off and the screen returns to normal size (over-scan).
• Use this function to check the whole screen. NOTE: This function is invalid with the RGB-input screen. PULSE CROSS button/lamp When you press the PULSE CROSS button, the button lights and the picture moves horizontally and vertically. The synchronized signal is dis- played and the screen automatically brightens to make it easier to confirm the synchronized sections. • When the PULSE CROSS button is pressed while lit,
the light goes off and the normal screen is restored.
NOTE: This function is invalid with the RGB-input screen. COLOR OFF button/lamp When you press the COLOR OFF button, the button lights and the screen becomes mono- chrome. Only the brightness signal is displayed. • When the COLOR OFF button is pressed while lit, the
light goes off and the normal screen is restored.
• Use this function to confirm the noise in the brightness
signal or to confirm the white balance.
NOTE: This function is invalid with the RGB-input screen. SCREENS CHECK button/lamp Press the SCREENS CHECK button. The button lights and the screen changes in the following order: Normal screen[Red screen[Green screen
Blue screen
• Press the SCREENS CHECK button when the blue
screen is displayed. The light goes off and the normal screen is restored.
• Use this function to confirm or adjust CHROMA or
PHASE.
NOTE: This function is invalid with the RGB-input screen. ASPECT button/lamp When the ASPECT button is pressed while the screen ratio is 4:3, the button lights and the screen ratio changes to 16:9. • When the ASPECT button is pressed while lit, the light
goes off and the normal screen is restored.
NOTE: This function is invalid with the RGB-input screen.
14 15 16
17 18
[
AREA MARKER button/lamp This button turns the AREA MARKER function ON/OFF. • AREA MARKER function includes MARKER, ZOOM,
and SAFETY AREA functions. Refer to “AREA MARKER” on page 14 for more information.
• When AREA MARKER is set to ON, the button lights. NOTES: • Functions do not operate when they are set to OFF in the
“AREA MARKER”.
• Initial setting of each function in the “AREA MARKER” Menu is
OFF. Before you can use the AREA MARKER function, you must change the “AREA MARKER” Menu settings first. Refer to “AREA MARKER” on page 14 for details.
• This button does not operate when RGB is input. • The ZOOM function does not operate in the under-scan mode. INPUT SELECT button Selects an input signal from one of the input cards installed in the monitor’s card slots (SLOT1 – SLOT3). Select SLOT1: press A or B Select SLOT2: press C or D Select SLOT3: press E or F
Refer to the input card instructions on pages 7 and 8 for details on the correspondence between the input terminals and the INPUT SELECT buttons.
• The INPUT SELECT button corresponding to the
current input signal lights.
• When the input is switched, the new input status is
displayed on the screen for about 3 seconds.
• To display the current input status again, press the
illuminated INPUT SELECT.
About status display Displays information on the current input selection and the monitor settings. INPUT C ................ Selected input VIDEO ................... Input card status (*1) NTSC .................... Signal format (*2) HIGH ..................... Setting of “COLOR TEMP.” (*3) EXT SYNC ............ External synchronization (*4) *1 Notes • “NO SLOT” is displayed when there is no input card inserted in
the slot corresponding to the selected input.
• “COMP.” or “RGB” is displayed when a component or RGB
signal (input from COMPONENT/RGB INPUT CARD) is selected.
• “VIDEO(Y/C)” is displayed when S-video is input from VIDEO
2(INPUT SELECT B/D/F).
*2 Notes • “NO SYNC” is displayed when no video signal is input. • When “SYNC SELECT” is set as “EXT” (external), “NO SYNC”
is displayed even when a video signal is input and a synchro- nized signal is not input. Refer to “SYNC SELECT” on page 17 for more information.
*3 Note Refer to “COLOR TEMP.” on page 18 for details on “COLOR TEMP” settings. *4 Note When “SYNC SELECT” is set to “INT.” (internal synchronization), no message is displayed. Refer to “SYNC SELECT” on page 17 for more information.

(No.52097)
DT-V1910CG
6
REAR/SIDE VIEW <Rear Panel>
REMOTE (external control) terminals Terminals for controlling the monitor from an external unit. MAKE/TRIGGER terminal (Upper):
Enables the monitor to be controlled by closing the circuit (point of contact) connected to the terminal.
RS-485IN terminal:
Enables the monitor to be controlled from a personal computer via a serial cable.
RS-485 OUT terminal (Lower):
Enables a cascade control connection. Multiple moni- tors can be controlled by the device connected to the IN terminal.
Input card slots (SLOT 1 — SLOT 3) Optional input cards can be installed in these slots. Input cards are not provided when you purchase the monitor. NOTE: It is not possible to input video or audio signals to the monitor when no input cards are installed. Main power switch Press the switch to turn the main power ON or OFF. When the main power is ON, the power lamp on the front panel lights in yellow and the monitor enters the stand-by mode. • I : ON : OFF
G/Y
OUTIN OUTIN
R/P
R
/B-Y
SLOT1SLOT3
SLOT2
MAINPOWER
OUTIN
VD
OUTIN
HD/C
S
OUTIN OUTIN
AUDIO
OUT
IN
B/P
B
/B-Y
AUDIO
OUT
IN
SWITCHED
OUT
HDSDI 1
HDSDI 2
IN IN
22 23 24
MAKE/TRIGGER
REMOTE
21
RS-485
IN
OUT
25
<Side Panel>
21 22 23
24 25
AC inlet Power input connector. Connect the provided AC power cord to an AC outlet (120 V/230 V AC, 50 Hz/60 Hz). *Attach the provided Power Cord Holder to prevent
accidental disconnection of the AC power cord.
Refer to page 10 for details.
Built-in speaker (monaural) Outputs the selected INPUT audio signal.
CONTROLS AND FEATURES (cont'd)
Power lamp Unlit : The main power is OFF. Orange : The main power is ON, but the monitor’s power
is OFF (in stand-by mode).
Green : The main power is ON, and the monitor’s
power is ON (in normal operation mode).
POWER switch Press the power switch to turn the monitor’s power ON or OFF when the main power is ON. NOTE: When RUSH DELAY TIME is set to SLOW in the set-up menu, it takes approx. 3.2 seconds for the power to actually turn ON after the power switch is pressed.
19 20
7
Component/RGB signal input/output terminals Input (IN) and output (OUT) terminals for component (color difference) or RGB signals. Select component signal: INPUT SELECT A (SLOT1)/C (SLOT2)/E (SLOT3) Select RGB signal : INPUT SELECT B (SLOT1)/D (SLOT2)/F (SLOT3) * The IN and OUT terminals are bridge-connected (auto termination). Synchronized signal input/output terminals Input (IN) and output (OUT) terminals for the vertical, horizontal or complex synchronized signals. • To use these terminals, set “SYNC SELECT” to “EXT”.
Refer to “SYNC SELECT” on page 17 for more information.
Audio input/output terminals Input (IN) and output (OUT) terminals for the analog audio signals. • The IN and OUT terminals are bridge-connected. Connection terminal Attach to the connection terminal of your Multi-Format Monitor.
1
CONTROLS AND FEATURES (INPUT CARD: OPTIONAL)
COMPONENT/RGB INPUT CARD (IF-C01COMG) Compatible signal formats:
NTSC (3.58 MHz), PAL (4.43 MHz), black-and-white (50 Hz/60 Hz)
VIDEO INPUT CARD (IF-C01PNG) Compatible signal formats:
480/60i, 576/50i, 576/50p, 480/60p, 720/ 60p, 1035/60i, 1080/50i, 1080/60i, 1080/ 24psF
Composite signal input/output terminals (VIDEO1, VIDEO2) Input (IN) and output (OUT) terminals for the composite video signals of the NTSC, PAL, and black/white (50/60Hz).
NTSC and PAL are switched in the “COLOR SYSTEM”. Refer to “COLOR SYSTEM” on page 17.
Select VIDEO 1: press INPUT SELECT A (SLOT1)/C (SLOT2)/E (SLOT3) buttons. Select VIDEO 2: press INPUT SELECT B (SLOT1)/D (SLOT2)/F (SLOT3) buttons. * The IN and OUT terminals are bridge-connected (auto termination).
S-video signal input terminal (only for VIDEO 2) Input terminal for the S-video signal. • When an S-video signal is input to this terminal and a video signal is input to VIDEO
2, the S-video signal has priority over the video signal.
Synchronized signal input/output terminals (for both VIDEO 1 and VIDEO 2) Input (IN) and output (OUT) terminals for the complex synchronized signals.
To use these terminals, set “SYNC SELECT” to “EXT”. Refer to “SYNC SELECT” on page 17 for more information.
NOTES: • When an external synchronized signal is input, external synchronization is prioritized
for both VIDEO1 and VIDEO2.
• External synchronization does not function when a video signal (except black burst
signal) is included in the complex synchronized signal.
Audio signal input/output terminals (for both VIDEO 1 and VIDEO 2) Input (IN) and output (OUT) terminals for analog audio signals correspond- ing to VIDEO 1 and VIDEO 2. • The IN and OUT terminals are bridge-connected. Connection terminal Attach to the connection terminal of your Multi-Format Monitor.
1 2 3 4 2 3 4 5
B/P
B
/B-Y
G/Y
OUTIN OUTIN
R/P
R
/B-Y
OUTIN
VD
OUTIN
HD/C
S
OUTIN OUTIN
AUDIO
OUT
IN
1 2 3 4
VIDEO 1
OUT
IN
AUDIO 2 AUDIO 1
OUT
IN
VIDEO 2
OUT
Y/C IN
IN
OUT
IN
EXT.SYNC
1 2 3 4 5

(No.52097)
DT-V1910CG
8
HD SDI INPUT CARD (IF-C12HSDG)
Compliant with EMBEDDED AUDIO
Compatible signal formats: 720/60p,
1080/50i, 1080/60i, 1035/60i, 1080/24psF, EMBEDDED AUDIO
HD SDI signal input/output terminals (HD SDI 1, HD SDI 2) Input (IN) and output (OUT) terminals for the HD SDI signal (HD compo- nent serial digital signal) This card is also compatible with EMBEDDED AUDIO signals with a 48kHz sampling frequency and channel range of 1-8.
The EMBEDDED AUDIO output channel is controlled from this monitor. Refer to “EMBEDDED AUDIO channel switch button” on page 4 for more information.
Select HD SDI1 input : press INPUT SELECT A (SLOT1)/C (SLOT2)/E (SLOT3)
buttons.
Select HD SDI2 input : press INPUT SELECT B (SLOT1)/D (SLOT2)/F (SLOT3)
buttons.
OUT terminal The re-clocked HD SDI1 and/or HD SDI2 input signal is output from the HD SDI1 OUT and/or HD SDI2 OUT terminal. NOTE: • Signals cannot be output from the OUT terminal when the monitor’s power is OFF
or in the stand-by mode.
Connection terminal Attach to the connection terminal of your Multi-Format Monitor.
1 2
CONTROLS AND FEATURES (INPUT CARD: OPTIONAL)
(cont'd)
SDI INPUT CARD (IF-C01SDG)
SWITCHED OUT terminal Output (OUT) terminal for the re-clocked signal. The input signal from SDI1 or SDI2 (selected with the INPUT SELECT buttons) is re-clocked and output from this terminal. NOTES: • Even when the input signal is switched from the SDI Input Card, the SWITCHED
OUT terminal still outputs the SDI 1 or SDI 2 re-clocked signal (whichever you selected last).
• No signal is output from the SWITCHED OUT terminal when the monitor is turned
off or in the stand-by mode.
D1 SDI signal input terminal (SDI1, SDI2) Accepts an SMPTE259M compliant D1 SDI signal (component serial digital signal). Select SDI1 input: press INPUT SELECT A (SLOT1)/C (SLOT2)/E (SLOT3) buttons. Select SDI2 input: press INPUT SELECT B (SLOT1)/D (SLOT2)/F (SLOT3) buttons. NOTE: Not compliant with EMBEDDED AUDIO. Audio signal input/output terminals (for both SDI1 and SDI2) Input (IN) and output (OUT) terminals for the analog audio signals. • The IN and OUT terminals are bridge-connected. Connection terminal Attach to the connection terminal of your Multi-Format Monitor.
1
Compatible signal formats: 480/60i,
576/50i
2 3 4
AUDIO 2 AUDIO 1
OUT
IN
SWITCHED
OUT
SDI 1
SDI 2
IN
IN
1 2 3 4
E.AUDIO
HD SDI 1
IN
OUT
2
1
E.AUDIO
HD SDI 2
IN
OUT
9
PREPARATION
1. Turn off the Multi-Format Monitor’s main
power and unplug the power cable from the AC outlet.
2. Unscrew the screws and remove the slot
cover from the slot (on the rear side of the monitor) in which you are going to install the card.
3. Insert the Input Card’s board (green-
colored) into the slot, fitting the board into the guide rails on the top and bottom of the slot.
4. Push the Input Card in so that its front
panel touches the monitor’s rear panel.
5. Secure the Input Card by replacing the
screws removed in Procedure 2.
INSTALLING THE INPUT
CARD
Optional input cards are necessary to use the functions of this monitor. Before mounting the monitor or connecting other equipment to the monitor, be sure to install the input cards.
SLOT1SLOT3
SLOT2
MAKE/TRIGGER
REMOTE
RS-485
IN
OUT
MAKE/TRIGGER
REMOTE
RS-485
IN
OUT
SLOT1SLOT3
SLOT2
SLOT1SLOT3
SLOT2
MAKE/TRIGGER
REMOTE
RS-485
IN
OUT
ATTACHING THE WIDE
MASK
A wide mask is provided with the monitor. This changes the viewable screen area to the 16:9 aspect ratio. •
The wide mask cannot be attached to the monitor after the monitor is mounted in a rack. Mount the wide mask before installing the monitor in a rack.
1. Prepare the provided wide mask and 4
screws (for attaching).
2. Attach the wide mask to the monitor. 3. Secure the wide mask with the screws (fix
2 screws each to both right and left side).
●When detaching the wide mask, follow this procedure in
reverse.
Slot cover
Fit the board to the guide rails.
Knob
Guide rails
Knob
NOTES: • Do not touch the terminal connected to the monitor or board
pattern.
• Do not remove slot covers from the monitor’s slots if they
are not in use.
Input card (the illustration shown is of the IF-C01PNG)
Caution: Use only the provided screws.
Rear side of the DT-V1910CG Multi-Format Monitor

(No.52097)
DT-V1910CG
10
1. Attach the Power Cord Holder case to the AC inlet on the back of the monitor with 2 screws
(provided).
2. Attach the Power Cord Holder cover to the AC power cord. 3. Connect the AC power cord to the AC inlet, and join the Power Cord Holder cover with the
case.
ATTACHING THE POWER CORD HOLDER •
The provided Power Cord Holder prevents accidental disconnection of the AC power cord from the AC inlet.
•
The Power Cord Holder consists of two parts; a case and cover.
Press the cover until it clicks.
Hold until it clicks.
Caution:
•
A different plug shape will result in the cover being
attached to a different position.
•
Check to make sure the plug doesn't pull out after the
cover is attached.
Note: To disconnect the power cord, click the tab to open the cover.
Caution: Use only the provided screws.
PREPARATION (cont'd)
11
BASIC MENU OPERATIONS (MAIN MENU, SETUP MENU)
ABOUT MENU SCREENS
This monitor features a MAIN MENU (main menu screen) and a SETUP MENU (setup menu screen). The MAIN MENU contains the functions normally used, and the SETUP MENU contains the settings required for initial setup.
“MAIN MENU”
Items Functions Displays 1 APERTURE CONTROL Compensates the frequency characteristics of the input video signal. *1 2 SLOT CONDITION Displays the status of the input cards installed in each of the input card slots. 3 sub menu POSITION Selects the display position of the sub menu superimposed on the screen. 4 AREA MARKER Controls ON/OFF and other settings of the MARKER, SAFETY MARKER,
and ZOOM functions included in the AREA MARKER function.
*2
5 COLOR MATRIX Selects or adjusts the picture color matrix. *1
About “Displays” *1 : Not displayed when an RGB signal is input.
*2 : Displayed only when the screen ratio is 16:9. Not displayed when an RGB signal is input. When some items are not displayed depending on the input signals, subsequent items will move up. Position of the menu varies depending on the type of signal.
“SETUP MENU”
Items Functions
1 FUNCTION SETTING Selects the control systems for the COLOR SYSTEM, synchronized signal, RUSH DELAY TIME,
tally lamp colors, and MAKE/TRIGGER terminal.
* Checks the amount of time that the monitor has been used. * Sets the AUTO INPUT function ON/OFF. (When an input card compliant with AUTO INPUT is
installed.)
* Selects the audio channel group for the EMBEDDED AUDIO. (When an input card compliant
with EMBEDDED AUDIO is installed.)
2 PICTURE SUB ADJ. Controls the approximate adjustment of the video control level when the video adjustment knob is
adjusted to the center.
* Can also be used to switch the NTSC set-up level, and change the component signal’s input level settings.
3 COLOR TEMP./BAL. Sets or adjusts the color temperature or white balance. 4 SIZE/POSI. ADJ. Adjusts the size or position of the picture. 5 DISTORTION ADJ. Compensates the picture distortion. 6 STATUS DISPLAY Sets the status display ON/OFF.
* Switches the display on and off. Also selects the type of display. (When an input card compliant with AUDIO LEVEL METER
is installed.)
* Switches the AUDIO PLL setting. (When SDI input card compliant with EMBEDDED AUDIO is installed.)
7 CONTROL LOCK Sets the control lock preventing the monitor from misuse. 8 all reset Sets all items in SETUP MENU to factory-preset values.
BUTTONS FOR MENU OPERATIONS
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF
SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT
VOLUME
DEGAUSS
MENU
MENU
MUTING

(No.52097)
DT-V1910CG
12
DISPLAYING THE MENU
SCREENS
To display MAIN MENU
Press the MENU button on the front panel.
To display SETUP MENU
Press the button while pressing the button on the front
panel.
NOTES: • To exit the MENU, press the MENU button several times. • The MENU automatically exits about 30 seconds after the last Menu
operation.
• To go back the previous MENU, press MENU. MENU OPERATION
PROCEDURE
Example: Adjusting the “BRIGHT” value to “+10”. 1.Press the button while button is pressed.
“SETUP MENU” is displayed on the screen.
2. Select “PICTURE SUB ADJ.” by pressing the
button, then press the button. “PICTURE SUB ADJ.” menu is displayed on the screen.
3. Select “BRIGHT” by pressing the button .
4. Press the and/or buttons as many times
as required to obtain the brightness desired.
Example: Setting brightness to “+10”.
5. Delete the “SETUP MENU” by pressing the
MENU button several times.
<SETUP MENU> FUNCTION SETTING PICTURE SUB ADJ. COLOR TEMP/BAL. SIZE/POSI.ADJ. DISTORTION ADJ. STATUS DISPLAY CONTROL LOCK :ON all reset EXIT:
MENU
ENTER:+ SELECT:
<PICTURE SUB ADJ.> CONTRAST : 00 BRIGHT : 00 CHROMA : 00 PHASE : 00 NTSC SETUP : 00 COMPO.LEVEL :SMPTE sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
<PICTURE SUB ADJ.> CONTRAST : 00 BRIGHT :+10 CHROMA : 00 PHASE : 00 NTSC SETUP : 00 COMPO.LEVEL :SMPTE sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
CONTRAST : 00 - - + +
[UPPER]
[LOWER]
CONTRAST : 00 - - + +
About “ sub-menu” Only displays selected items. (sub-menu display) Allows you to adjust and set items while looking at the actual screen. NOTE: • This function is available only when “ sub-menu” is displayed in the
MENU.
Example: Setting an item in the “PICTURE SUB ADJ.”
with the sub-menu.
1. Press the button while button is pressed.
“SETUP MENU” is displayed on the screen.
2. Select “PICTURE SUB ADJ.” by pressing the
button, then press the button.
3. Select “sub-menu” by pressing the button
several times, then press the button.
The adjustment bar is displayed at the bottom or top of the screen.
4. Select the desired setup item by pressing the
and buttons (several times).
5. Press the and/or buttons as many times
as required to obtain the desired setting.
To delete the sub-menu display:
Press the MENU button on the front panel. • The previous MENU display is restored.
To change the position of the sub-menu display
1. Display the “MAIN MENU” by pressing the MENU button. 2. Select “sub menu POSITION” by pressing the button
several times.
3. Set “UPPER” or “LOWER” by pressing the and
buttons.
BASIC MENU OPERATIONS (MAIN MENU, SETUP MENU) (cont'd)
About “reset” Restores all MENU settings (currently displayed) to factory-preset values. Select “reset” using the / buttons, then press the button. NOTE: • This function is only available when “reset” is displayed in the
MENU.
13
HOW TO USE “MAIN MENU”
“MAIN MENU” SCREENS
<MAIN MENU> APERTURE CONTROL SLOT CONDITION sub menu POSITION :LOWER AREA MARKER. COLOR MATRIX EXIT:
MENU
ENTER:+ SELECT:
<APERTURE CONTROL> LEVEL : 00 CONTROL FREQ. :HIGH sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
<SLOT CONDITION> INPUT A : VIDEO-1 INPUT B : VIDEO-2 INPUT C : COMPO. INPUT D : RGB INPUT E : NO SLOT INPUT F : NO SLOT EXIT:MENU
<COLOR MATRIX> SELECT :ITU601 EXIT:MENU ADJUST:- + SELECT:
<AREA MARKER> MARKER SELECT :LINE ZOOM :ON ASPECT SELECT : 4:3 SAFETY AREA : 85 R-MARKER SELECT :LINE R-ZOOM :OFF R-ASPECT SELECT : 13:9 R-SAFETY AREA : 85 EXIT:MENU ADJUST:- + SELECT:
Some items are not displayed depending on the picture input signal. (

See page 11.)
Setting Items
MAIN MENU
Adjusts with
and buttons. 
See page 12 for
more information on “sub-menu” and
“reset”.
Press .
 See page 14.
* To go back the previous MENU,
press MENU.

(No.52097)
DT-V1910CG
14
HOW TO USE “MAIN MENU” (cont'd)
AREA MARKER:
Controls ON/OFF and other settings of the MARKER, SAFETY MARKER, and ZOOM functions included in the AREA MARKER function. Press the button to
display the setting menu illustrated on the right.
NOTES: • For the 4:3 screen ratio, only
SAFETY MARKER and R-SAFETY MARKER are displayed.
• To set up non-“R-” items, press the AREA MARKER button on the
front panel. An external control system should not be operated at this time.
• To set up “R-” items, set the AREA MARKER function to ON via
external control.
• Use the MAKE/TRIGGER terminal for external control of AREA
MARKER function. Please note that this will only work when the AREA MARKER button on the front panel has been pressed (the AREA MARKER lamp will be illuminated). For details, refer to “How to use the MAKE/TRIGGER terminal” on page 21.
MARKER SELECT/R-MARKER SELECT
It displays the area of the aspect ratio that has been set in the ASPECT SELECT/R-ASPECT SELECT, superimposed on the current screen.
OFF : MARKER does not function. LINE : Displays the area with an outline. S.HALF : The area outside the specified screen ratio is
displayed as a 50% transparency.
HALF+L: The area of the specified screen ratio is indicated
by an outline, and the area outside of that is displayed as a 50% transparency.
S. BLK : The area outside the specified screen ratio is
black. Only the portion of the picture within the designated area is displayed.
BLK.+L : The area of the specified screen ratio is indicated
by an outline, and the area outside of that becomes black so that only the area inside the line is displayed.
ZOOM/R-ZOOM
Zooms the center of the marked area.
OFF: Does not zoom. ON : Zooms.
NOTES: • Does not function when under-scan is operated. • To adjust the zoom picture size, refer to “ZOOM V. SIZE” and
“ZOOM H. SIZE” on page 19.
ASPECT SELECT/R-ASPECT SELECT
Selects the screen aspect ratio.
• 4:3/13:9/14:9
<AREA MARKER> MARKER SELECT :LINE ZOOM :ON ASPECT SELECT : 4:3 SAFETY AREA :85 R-MARKER SELECT :LINE R-ZOOM :OFF R-ASPECT SELECT : 13:9 R-SAFETY AREA :85 EXIT:
MENU
ENTER:+ SELECT:
APERTURE CONTROL
Compensates the frequency characteristics of the input video signal. Press the button to
display the setting menu illustrated on the right.
LEVEL
Adjusts the compensate value. The higher the number is, the larger the compensate value gets.
• 00 ~ +10
CONTROL FREQ.
Adjusts the frequency compensation.
HIGH: Compensates the high frequencies. LOW : Compensates the low frequencies. OFF : Deactivates the aperture compensation.
<SLOT CONDITION> INPUT A : VIDEO-1 INPUT B : VIDEO-2 INPUT C : COMPO. INPUT D : RGB INPUT E : NO SLOT INPUT F : NO SLOT EXIT:
MENU
ITEM CONTENTS AND ADJUSTMENT RANGE/SETTINGS
<APERTURE CONTROL> LEVEL : 00 CONTROL FREQ. :HIGH sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
INPUT A/INPUT B : Status of SLOT1 INPUT C/INPUT D : Status of SLOT2 INPUT E/INPUT F : Status of SLOT3 VIDEO-1/VIDEO-2 : With VIDEO input card is installed. COMP./RGB : With Component/RGB input card is
installed.
SDI1/SDI2 : With SDI input card is installed. HD SDI1/HD SDI2 : With HD SDI input card is installed.
NOTES:
• If an input card is compatible with EMBEDDED AUDIO, an asterisk
(*) is displayed its name. (Example: HD SDI*)
• If an input card is compatible with both EMBEDDED AUDIO and
AUDO LEVEL METER, two asterisks (**) are displayed after its name. (Example: HD SDI**)
• The “--” indication may appear. This means that no signal is input
to the corresponding INPUT, either because no input card is installed or because the input card only has a single input line.
sub menu POSITION
Selects the display position of the sub menu superim- posed on the screen.
For details, refer to “To change the position of the sub-menu display” on page 12.
SLOT CONDITION
Displays the status of the input cards installed in each of the input card slots. Press the button to
display the setting menu illustrated on the right.
4:3 14:9 13:9
15
SAFETY AREA/R-SAFETY AREA
Displays dotted lines to indicate the areas corre- sponding to 80%, 88%, or 90% of the screen size (the aspect ratio setting in “ASPECT SELECT/R- ASPECT SELECT”).
OFF: SAFETY AREA does not function. 90%: Marked area is 90% of the 16:9 screen ratio. 88%: Marked area is 88% of the 16:9 screen ratio. 80%: Marked area is 80% of the 16:9 screen ratio.
NOTES:
• When a picture of 4:3 aspect ratio is input, SAFETY AREA for 4:3
screen is displayed.
• To display SAFETY AREA for 16:9 screen ratio when a picture of
16:9 aspect ratio is input, set “MARKER SELECT/R-MARKER SELECT” to OFF. (In this case, setting of ASPECT SELECT is invalid.)
Input Signal Format Standard Manual
setting setting
(MANUAL)
NTSC, PAL, 480/60i, ITU601
480/60p, 576/50i, 575/50p ITU709 720/60p, 1080/50i, 1080/60i, ITU709 1035/60i, 1080/24psF
<COLOR MATRIX> SELECT :MANUAL R-Y PHASE : 90 R/B GAIN :0.86 G-Y PHASE : 244 G/B GAIN :0.36 sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
COLOR MATRIX
Selects or adjusts the standard of the color demodulation (color rendering). Press the button to
display the setting menu illustrated on the right.
The menu screen when MANUAL is selected.
●The standard setting is set to “ITU601” or “ITU709”
depending on the input signal format. The factory preset of MANUAL is ITU709
R-Y PHASE 90
ITU601 R/B GAIN 0.79
G-Y PHASE 244 G/B GAIN 0.45 R-Y PHASE 90
ITU709 R/B GAIN 0.86
G-Y PHASE 244 G/B GAIN 0.30
SELECT
Selects the picture matrix standard.
ITU601 or ITU709 : Standard setting MANUAL : Manual setting
NOTE : The following items are displayed when MANUAL is selected. When ITU601 or ITU709 is selected, they are not displayed.
R-Y PHASE
Sets the R-Y phase.
• 90/92/94/112
R/B GAIN
Sets the R/B gain.
• 0.86/0.56/0.68/0.79
G-Y PHASE
Sets the G-Y phase.
• 244/253/236/240
G/B GAIN
Sets the G/B gain.
• 0.30/0.34/0.40/0.45

(No.52097)
DT-V1910CG
16
HOW TO USE “SETUP MENU”
“SETUP MENU” SCREENS
<SETUP MENU> FUNCTION SETTING PICTURE SUB ADJ. COLOR TEMP./BAL. SIZE/POSI.ADJ. DISTORTION ADJ. STATUS DISPLAY CONTROL LOCK :ON all reset EXIT:MENU ENTER:+ SELECT:
<FUNCTION SETTING> COLOR SYSTEM :AUTO AUTO INPUT :ON SYNC SELECT :INT. RUSH DELAY TIME :STD. TALLY SELECT :GREEN REMOTE SYSTEM :MAKE E.AUDIO GROUP :1G HOUR METER X100 :000 EXIT:MENU ADJUST:- + SELECT: <PICTURE SUB ADJ.> CONTRAST : 00 BRIGHT : 00 CHROMA : 00 PHASE : 00 NTSC SETUP : 00 COMPO.LEVEL : SMPTE sub menu reset EXIT:MENU ADJUST:- + SELECT:
<COLOR TEMP./BAL.> COLOR TEMP. : HIGH BLUE DRIVE : 000 RED DRIVE : 000 GREEN CUTOFF : 000 BLUE CUTOFF : 000 RED CUTOFF : 000 sub menu reset EXIT:MENU ADJUST:- + SELECT: <SIZE/POSI. ADJ.> H.SIZE : 00 H.POSITION : 00 V.SIZE : 00 V.POSITION : 00 ZOOM H.SIZE : 00 ZOOM V.SIZE : 00 sub menu reset EXIT:MENU ADJUST:- + SELECT: <DISTORTION ADJ.> PINCUSHION : 00 PIN.BALANCE : 00 PARALLELOGRAM : 00 TRAPEZOID : 00 ROTATION : 00 sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
<STATUS DISPLAY> STATUS DISPLAY :ON LEVEL METER ch :31 24
BAR TYPE :3COLORS REFERENCE LEVEL :-20dB OVER LEVEL :-4dB BAR BRIGHTNESS :HIGH EXIT:MENU ADJUST:- + SELECT:
Setting Items
Adjusts with
and buttons. 
See page 12 for
more information on “sub-menu” and
“reset”.
Press .

See page 20.
SETUP MENU
* To go back the previous MENU,
press MENU.
17
ITEM CONTENTS AND ADJUSTMENT RANGE/SETTINGS FUNCTION SETTING
Selects the control systems for the COLOR SYSTEM, synchronized signal, RUSH DELAY TIME, tally lamp colors, and MAKE/TRIGGER terminal. • Checks the amount of time that the monitor has been
used.
• Sets the AUTO INPUT function ON/OFF. (When an input
card compliant with AUTO INPUT is installed.)
• Selects the audio channel group for the EMBEDDED
AUDIO. (When an input card compliant with EMBEDDED AUDIO is installed.)
Press the button to
display the setting menu illustrated on the right.
COLOR SYSTEM
Selects the color system when using the video input card.
AUTO : Changes NTSC and PAL automatically. NTSC : Keeps the color system NTSC. PAL : Keeps the color system PAL.
NOTE: Normally select AUTO. However, if the input signal is unstable, select NTSC or PAL.
AUTO INPUT
When HD SDI signal and D1 SDI signal need to be switched to input accordingly by one signal cable, AUTO INPUT automatically detects whether a signal is being input to Input A (HD SDI input card) or Input C (SDI input card) and switches INPUT accordingly.
ON : AUTO INPUT is ON. OFF : AUTO INPUT does not function.
NOTES: • Functions only when input card compatible with AUTO INPUT is
used.
• “INPUT SELECT ERROR” is displayed for approx. 3 seconds
when different signal cables are connected to each INPUT A and INPUT C and signals are input to the each of them.
Preparation for the AUTO INPUT function (See below illustration) 1. Insert HD SDI input card to SLOT1, and SDI input card to
SLOT2 (both cards need to be compatible with AUTO INPUT), then connect the signal cable.
2. Input HD SDI signal or D1 SDI signal to HD SDI input
card.
SYNC SELECT
Synchronized signal selection.
INT. : The input video signal is synchronized with the
built-in sync signal.
EXT. : The input video signal is synchronized with an
external signal from an external sync terminal.
RUSH DELAY TIME
Sets the time when the power supply to the monitor’s circuits (excluding the micro computers) starts after the power switch is pressed.
STD. : The power supply starts approx.
1 second after the power switch is pressed.
SLOW : The power supply starts approx.
3.2 seconds after the power switch is pressed.
NOTE: If you are going to turn several Multi-Format Monitors on at the same time, it is recommended to apply SLOW to some of the monitors to control rush current.
TALLY SELECT
Selects the color of the tally lamp (when lit) on the upper front panel.
GREEN : The tally lamp lights in green. RED : The tally lamp lights in red.
REMOTE SYSTEM
Selects the control system for the MAKE/TRIGGER terminals. Refer to “How to use the MAKE/TRIGGER terminal” on page 21.
• MAKE (make contact)/ TRIGGER (trigger contact)
E.AUDIO GROUP
Selects the audio channel group for EMBEDDED AUDIO. It is displayed when an input card compliant with EMBEDDED AUDIO is installed.
• 1G/2G/1-2G
1G : 2G : 1-2G :
NOTE: The auto setting mixes and outputs all 8 signal channels. Sets the output level automatically by detecting the number of channels receiving the signal. * About sound output level
Sound output level is set to a standard output level for all channels when several sound channels are output at the same time. The more channels are selected, the lower each channel’s level will be. (Each channel's level becomes half for 1– 2 channel, 1/4 for 1– 4 channel.)
HOUR METER X100h
Displays the total usage time of the monitor in hundred-hour units.
• 000 ~ 655
NOTES:
• When the timer passes 655, it returns to 000. • The timer does not count the usage time under one hour.
<FUNCTION SETTING> COLOR SYSTEM :AUTO AUTO INPUT :ON SYNC SELECT :INT. RUSH DELAY TIME :STD. TALLY SELECT :GREEN REMOTE SYSTEM :MAKE E.AUDIO GROUP :1G HOUR METER X100h :000 EXIT:
MENU
ADJUST:- + SELECT:
1ch 2ch 3ch 4ch 1-2ch 3-4ch 1-4ch
5ch 6ch 7ch 8ch 5-6ch 7-8ch 5-8ch
AUTO 5-8ch 1-4ch 7-8ch 5-6ch 3-4ch
1ch 2ch 3ch 4ch 5ch 6ch 7ch 8ch 1-2ch
IN
OUT
E.AUDIO
HD SDI 1
IN1 IN2
SWITCHED
OUT
E.AUDIO
SDI
SLOT2
SLOT1
D1 SDI input card compatible with AUTO INPUT
HD SDI input card compatible with AUTO INPUT

(No.52097)
DT-V1910CG
18
HOW TO USE “SETUP MENU” (cont'd)
CONTRAST
• –20 ~ 00 ~ +20
BRIGHT
• –20 ~ 00 ~ +20
CHROMA
• –20 ~ 00 ~ +20
PHASE
• –20 ~ 00 ~ +20
NTSC SETUP
Sets the set-up level of the input NTSC signal.
00 : Compliant with 0% set-up signal. 7.5 : Compliant with 7.5% set-up signal.
NOTE : NTSC SETUP is displayed only when the video input card is installed and an NTSC signal is input.
COMPO. LEVEL
Sets the set-up level of the input component signal.
SMPTE : Compliant with M2VTR signals. B75 : Compliant with Betacam 7.5% set-up signal. B00 : Compliant with Betacam 0% set-up signal.
NOTE : COMPO. LEVEL is displayed only when a 480/60i, 480/60p, 576/ 50i or 576/50p signal is input.
<COLOR TEMP./BAL.> COLOR TEMP. :HIGH BLUE DRIVE : 000 RED DRIVE : 000 GREEN CUTOFF : 000 BLUE CUTOFF : 000 RED CUTOFF : 000 SUB MENU reset EXIT:
MENU
ADJUST:- + SELECT:
COLOR TEMP./BAL.
Sets or adjusts the color temperature or white balance. Press the button to
display the setting menu illustrated on the right.
• Use the five items indicated with
mark to make fine adjustments
between the monitors.
COLOR TEMP.
Selects the color temperature.
HIGH : Sets the color temperature to 9300. LOW : Sets the color temperature to 6500.
BLUE DRIVE
Adjusts the blue drive level.
• MIN ~ 000 ~ MAX (in 127 grades)
RED DRIVE
Adjusts the red drive level.
• MIN ~ 000 ~ MAX (in 127 grades)
GREEN CUTOFF
Sets the green cut-off point.
• MIN ~ 000 ~ MAX (in 205 grades)
BLUE CUTOFF
Sets the blue cut-off point.
• MIN ~ 000 ~ MAX (in 205 grades)
RED CUTOFF
Sets the red cut-off point.
• MIN ~ 000 ~ MAX (in 205 grades)
<PICTURE SUB ADJ.> CONTRAST : 00 BRIGHT : 00 CHROMA : 00 PHASE : 00 NTSC SETUP : 00 COMPO.LEVEL :SMPTE sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
PICTURE SUB ADJ.
Controls the approximate adjustment of the video control level when the video adjustment knob is adjusted to the center. • Can also be used to switch the NTSC set-up level, and
change the component signal’s input level settings.
Press the button to
display the setting menu illustrated on the right.
NOTE : When the RGB signal is input, only CONTRAST and BRIGHT are displayed. When the PAL signal is input, only CONTRAST, BRIGHT and CHROMA are displayed.
19
<DISTORTION ADJ.> PINCUSHION : 00 PIN.BALANCE : 00 PARALLELOGRAM : 00 TRAPEZOID : 00 ROTATION : 00 sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
DISTORTION ADJ.
Compensates the picture distortion. Press the button to
display the setting menu illustrated on the right.
PINCUSHION
Compensates pincushion picture distortion.
• –20 ~ 00 ~ +20
– : Expands both left and right sides of the picture. +:Squeezes both left and right sides of the picture.
PIN.BALANCE
Adjusts the compensation balance of the pincushion picture distortion.
• –20 ~ 00 ~ +20
– : The picture is expanded on the left side, and squeezed on the
right side.
+ : The picture is squeezed on the left side, and expanded on the
right side.
PARALLELOGRAM
Compensates parallelogram picture distortion.
• –20 ~ 00 ~ +20
– : Moves the upper side of the picture to the right, and the lower
side to the left.
+ : Moves the upper side of the picture to the left, and the lower
side to the right.
TRAPEZOID
Compensates trapezoid picture distortion.
• –20 ~ 00 ~ +20
–:Enlarges the upper side of the picture. +:Reduces the upper side of the picture.
ROTATION
Compensates for picture tilt.
• –31 ~ 00 ~ +31
–:Turns the picture clockwise. + : Turns the picture counterclockwise.
<SIZE/POSI. ADJ.> H.SIZE : 00 H.POSITION : 00 V.SIZE : 00 V.POSITION : 00 ZOOM H.SIZE : 00 ZOOM V.SIZE : 00 sub menu reset EXIT:
MENU
ADJUST:- + SELECT:
H.SIZE
Adjusts the horizontal screen size.
• –20 ~ 00 ~ +20 (*)
–:Reduces the screen size horizontally. +:Enlarges the screen size horizontally.
* Reduced to 00 ~ +20 during the under-scan mode.
H.POSITION
Adjusts the horizontal screen position.
• –20 ~ 00 ~ +20
–:Move the screen to the left. +:Move the screen to the right.
V.SIZE
Adjusts the vertical screen size.
• –20 ~ 00 ~ +20
–:Reduces the screen size vertically. +:Enlarges the screen size vertically.
V.POSITION
Adjusts the vertical screen position.
• – 20 ~ 00 ~ + 20
–:Move the screen up. +:Move the screen down.
ZOOM V. SIZE
• – 20~00
ZOOM H. SIZE
• – 20~+20 NOTE: • ZOOM V. SIZE and ZOOM H. SIZE are displayed only when the
ZOOM function is operated. ZOOM V. SIZE adjusts the screen size vertically, and ZOOM H. SIZE adjusts it horizontally when the ZOOM is operated.
SIZE/POSI. ADJ.
Adjusts the size or position of the picture. Press the button to
display the setting menu illustrated on the right.

(No.52097)
DT-V1910CG
20
<STATUS DISPLAY> STATUS DISPLAY : ON LEVEL METER ch :31•24 BAR TYPE :3COLORS REFERENCE LEVEL : -20dB OVER LEVEL : -4dB BAR BRIGHTNESS : HIGH EXIT:
MENU
ADJUST:- + SELECT:
STATUS DISPLAY
Sets the status display ON or OFF.
ON : The information is displayed. OFF : The information is not displayed.
LEVEL METER ch
Selects the audio channels used in the AUDIO LEVEL METER display.
• OFF/1:2/12:34/31:24/123:456/1-8 NOTES: • Numbers indicate the audio channel. The channel input level
indicated on the left side of “:” is displayed on the left side of the screen, and the channel input level indicated on the right side of “:” is displayed on the right side of the screen.
• AUDIO LEVEL METER is not displayed when this is set to OFF. • When “1-8” is selected, the channel input level for 1,2,3 and 4 is
displayed on the left side of the screen, and the channel input level for 5,6,7 and 8 is displayed on the right side of the screen.
BAR TYPE
Selects the color of the audio level meter.
WHITE-1 : White color display WHITE-2 : White (half transparent) display 3 COLORS : The audio level meter uses three different
colors (red, yellow and green) to indicate variations in input levels.
Red : displayed when the audio input exceeds the
level set in “OVER LEVEL”.
Yellow : displayed when the audio input exceeds the
level set in “REFERENCE LEVEL”.
Green : displayed when the audio input does not
exceed the level set in “REFERENCE LEVEL”.
NOTES: • For WHITE-1 and WHITE-2, the line indication for the standard
input level set in the “REFERENCE LEVEL” is displayed. Input level set in the “OVER LEVEL” is not displayed.
• As for the audio channel bar display with no signal input, white is
displayed for the 3COLORS setting, and gray is displayed for other settings.
REFERENCE LEVEL( )
Sets the standard input level.
• – 20dB/-18dB
CONTROL LOCK CONTROL LOCK
Invalidates most of operations on the front panel (including menu screen operations).
OFF : Enables normal operations. ON : Invalidates all operations except the power switch
and CONTROL LOCK.
NOTES:
• While CONTROL LOCK is set to ON, attempting to perform any
operation except power switch and CONTROL LOCK causes the “Control lock on!” warning to appear on the screen for approx.
3 seconds. (It is possible to operate the power switch and display SETUP MENU.)
• When SETUP MENU is displayed while CONTROL LOCK is set
to ON, the cursor (
4
) is located next to CONTROL LOCK and
cannot be moved.
all reset
Resets all SETUP MENU items to factory-preset values.
1. Select “all reset” by / buttons, then press button.
Confirmation message is displayed.
2. To initialize, press button.
To cancel the initialization, press the MENU button.
STATUS DISPLAY
Sets the status display ON/OFF. * Switches the display on and off. Also selects the type of
display. (When an input card compliant with AUDIO LEVEL METER is installed.)
* Switches the AUDIO PLL setting. (When SDI input card
compliant with EMBEDDED AUDIO is installed.)
Press the button to
display the setting menu illustrated on the right.
NOTE:
Function setting is displayed
when input card compliant with AUDIO LEVEL METER is installed.
1 2 3 4 5 6 7 8
OVER LEVEL ( )
Sets the input level’s lower limit indicated in red for the “3COLORS” display.
• -8dB/-6dB/-4dB/-2dB
BAR BRIGHTNESS ( )
Selects the brightness of the AUDIO LEVEL METER display.
HIGH : Brighter LOW : Darker
AUDIO LEVEL METER display example LEVEL METER ch: 1-8, BAR TYPE: 3COLORS
OVER LEVEL [–8dB/–6dB/–4dB/–2dB]
REFERENCE LEVEL
[–20dB/
–18dB]
Audio channels and OVER/REFERENCE level indication
HOW TO USE “SETUP MENU” (cont'd)
21
HOW TO USE EXTERNAL CONTROL
ABOUT EXTERNAL CONTROL The Multi-Format Monitor has two external control terminals. One is the MAKE/TRIGGER terminal, which allows the monitor to be controlled by the MAKE(make contact) or TRG. (trigger contact) method selected in the function setting. MAKE (make contact system): Controls functions either by short-circuiting (short with GND of 15th terminal) or stable disconnec-
tion (terminal open) of the controlled terminal.
TRG. (trigger system) : Controls the function by instantaneously (one second) short-circuiting (short with GND of 15th
terminal) the controlled terminal. * MAKE or TRIGGER are selected from REMOTE SYSTEM in the setup menu.
The other terminal used for remote control is the RS-485 terminal, and this allows the monitor to be controlled by serial communication. NOTE: Control priority is in the following order; 1MAKE/TRIGGER terminal > 2RS-485 terminal > 3front panel buttons.
When trigger contact is on, the front panel buttons can be operated.
10 9 8
54321
76
1415 13 12 11
*1 : The TRIGGER (trigger contact) system switches each setting by instantaneously (approx. 1 second) short-circuiting (short with GND of 15th terminal) the
controlled terminal.
*2 : TALLY (1st terminal) and EXTERNAL CONTROL (14th terminal) must be controlled with the MAKE (make contact) system even under the TRIGGER (trigger
contact) system.
*3 : Activating each with “R-” or without “R-” setting in the AREA MARKER menu is possible. Refer to “AREA MARKER” on page 14 for details.
Operation
1. Short-circuit EXTERNAL CONTROL (14th terminal) to GND (15th terminal) to activate the external control. 2. Under the MAKE system, controls each function by short-circuiting (short with GND of 15th terminal) or stable disconnection
(terminal open) of the controlled terminal.
3. Under the TRIGGER (trigger contact) system, controls each function by Pulse Control, that is by instantaneously (approx. 1
second) short-circuiting (short with GND of 15th terminal) the controlled terminal.
NOTES: • When using INPUT A (the 2nd pin) through INPUT F (7th terminal), only the terminal in use should be short-circuited, the others must be
disconnected.
• Under the TRIGGER system, multiple terminals cannot be short-circuited to GND (15th terminal). Be sure to short-circuit the single terminal to
GND.
No. Functions to be controlled Disconnection Short-circuiting *1
1 Turns on the tally lamp Off On *2 2 Changes the input to INPUT A Invalid Valid 3 Changes the input to INPUT B Invalid Valid 4 Changes the input to INPUT C Invalid Valid 5 Changes the input to INPUT D Invalid Valid 6 Changes the input to INPUT E Invalid Valid 7 Changes the input to INPUT F Invalid Valid 8 COLOR OFF Off On 9 AREA MARKER Off On
10 ASPECT Off On
11 TALLY SELECT GREEN RED
12 AREA MARKER set-up without “R-” with “R-” *3 13 STATUS DISPLAY ON OFF 14 External Control Invalid Valid *2 15 GND
HOW TO USE THE MAKE/TRIGGER TERMINAL

(No.52097)
DT-V1910CG
22
HOW TO USE THE RS-485 TERMINAL You can control the monitor from the controller (exclusive for this monitor) or your PC via the RS-485 terminal. For details on operating the monitor from the PC, consult the service center. 1. Cable
Prepare a straight cable with a D-sub connector (9-pin, male) and a D-sub connector (9-pin, male)
2. Communications Specifications
Baud Rate : 4800/9600/19200 (factory pre-set; 4800) Data Bits : 8 bits Parity : No parity Stop Bits : 1 Communication Cord : ASCII Cord
3. Commands
Format
Header ID Command ID Command Content Data CR
Header
! Control from the PC to the monitor
? Reference from the PC to the monitor
@ Answer from the monitor to the PC
ID + Command + Data
B Basic command Characters 00, 01 or No data
D Command for adjusting the picture size 00 ~ 08 U, D (U: UP, D: DOWN)
S Command for adjusting the picture quality 00 ~ 05 U, D (U: UP, D: DOWN)
M Command for selecting the menu item 00 ~ 0E 00, 01, 10, 11
F Command for selecting the menu item 00 ~ 10 00, 01, 02, 03, 04, 05
W Command for adjusting the white balance 00 ~ 05 U, D (U: UP, D: DOWN)
C Command for inquiring for the monitor’s status 00 0 ~ 655
Communication Procedures The following is the communication procedures.
1. Starting the communication
Receives the connection command (!XXBCN1Cr) from the PC [Sends the monitor’s status (@XXBOKCr) to the PC
2. Performing the external control
Receives the control command (!XXXXCr) from the PC [Sends the monitor’s status (@XXBOKCr) to the PC * The monitor repeats these receiving and sending if necessary.
3. Terminating the communication
Receives the termination command (!XXBCN0Cr) [Sends the monitor’s status (@XXBOKCr) to the PC * Hand-shake communication is used. This means that after sending a command to the monitor, the PC must receive a status
return from the monitor before sending the next command.
* When the monitor is controlled by a PC via RS-485, a conversion adapter (RS-232p[RS-485) is also required.
4
3
2 1
9 8
5
7
6
Pin No. IN terminal OUT terminal
signal signal
1 5V Power (for
controller exclusively NC
for this monitor)
2TD
+
TD
+
3RD
+
RD
+
4NC NC 5NC NC 6NC NC 7 TD– TD– 8 RD– RD– 9NC NC
* The 5V power supply of the 1st terminal is for the controller
exclusively for this monitor. Do not use it for other devices.
HOW TO USE EXTERNAL CONTROL (cont'd)
23
Problems
No power supply No picture with the power on No sound Wrong color Unnatural picture Shaking picture
Points to be checked
Is the power plug loosened or disconnected? Is the main power turned OFF? Is the signal cable disconnected? Is the power of the connected component ON? Is the signal output from the connected component? Is the input signal selected correctly? Is the input signal adapted to the monitor’s specification? Are any of the self-check indicators (INPUT SELECT A through F buttons) blinking? Is the audio cable disconnected? Is the audio signal output from the connected component? Is the volume output set to minimum? Has the picture adjustment been changed? Has the WHITE BALANCE setting been changed? Are any cables connected to the component/RGB input card? Has the correct signal been input to the component/RGB input card and the correct INPUT been selected on the monitor? Has [CONTRAST] or [BRIGHT] been changed? Is the monitor close to a motor, transformer or any other device generating a strong magnetic field? (a fan, fluorescent light, laser printer, another monitor, etc.)
Measures (Remedy)
Firmly insert the power plug. Turn the main power ON. Connect the signal cable firmly. Turn on the power of the connected component and set it correctly. Select the correct input with the INPUT SELECT buttons. Check that the input signal format corresponds to the installed input card format. Follow the procedures in “SELF-CHECK INDICATIONS”. Connect the audio cable firmly. Set the connected component correctly. Adjust the speaker volume with the VOLUME (volume adjustment) buttons. Set each picture adjustment knob to the standard (centered) position. Or, set each picture adjustment item in [ PICTURE SUB ADJ.] in the <SETUP MENU> screen to Standard (00) (or use the [reset] function). Set each [COLOR TEMP./BAL.] item in the <SETUP MENU> screen to Standard (000) (or use the [reset] function). Connect each signal cable firmly. Select INPUT A/C/E when the component signal is input, or select INPUT B/D/F when the RGB signal is input. Adjust the CONTRAST or BRIGHT picture adjustment knobs. Or, adjust the [CONTRAST] or [BRIGHT] item in [PICTURE SUB ADJ.] in the <SETUP MENU> screen. Move the monitor away from the device until the picture stops shaking. Connect the power plug to another AC outlet away from the former one.
TROUBLESHOOTING
Solutions to common problems related to your monitor are described here. If none of the solutions presented here solve the problem, unplug the monitor and consult a JVC-authorized dealer or service center for assistance.
Reference pages
—
6
7 ~ 8
—
5
7 ~ 8
25
7 ~ 8
—
4
4, 18
18
7 7
4, 18
—

(No.52097)
DT-V1910CG
24
TROUBLESHOOTING (cont'd)
Problems
Irregular color Wrong picture position, wrong picture size Front panel buttons and knobs do not function
Points to be checked
Is the monitor placed or moved close to a speaker or any other device incorporating a magnet? Has the position of the monitor been changed with the power on? Has the picture position, size or distortion been changed? Have the UNDER SCAN or ASPECT button been pressed? Has the CONTROL LOCK function been set to ON? Has the monitor’s setting been changed to enable control from an external unit via the REMOTE terminals?
Measures (Remedy)
Move the device away from the monitor. Press the DEGAUSS button on the front panel to degauss the screen. When degaussing, wait more than 30 minutes for maximum effect. Adjust the picture size (H. SIZE, V. SIZE) or position (H. POSITION, V. POSITION) in the [SIZE/POSI. ADJ.] item in the <SETUP MENU> screen. Adjust the picture distortion (PINCUSHION, PIN. BALANCE, TRAPEZOID and PARALLELOGRAM) in the [DISTORTION ADJ.] item in the <SETUP MENU> screen. It may not be possible to expand the picture due to the selected input mode. In this case, adjustment is impossible. When the UNDER SCAN or ASPECT button is lit, press each button to invalidate each setting. Set the CONTROL LOCK function to OFF. Change the setting of the external control to control the monitor locally.
The following are not malfunctions: ●You may see two horizontal lines on the monitor. They are the
shadows of the “damper lines” that are necessary for composing the monitor. These lines are not a malfunction.
●About CRT tube reflection (when Zoom mode is used.)
The screen might appear as brownish white. This is due to a reflection of part of the image on the CRT caused by certain signal sources, and it is not a malfunction.
●When a bright still image (such as a white cloth) is displayed for a
long period, it may appear to be colored. This is due to the structure of the cathode ray tube and will disappear when another image is displayed.
●You may sometimes experience a mild electric shock when you
touch the picture tube. This phenomenon is due to a normal buildup of static electricity on the CRT and is not harmful.
●The monitor emits a strange sound when the room temperature
changes suddenly. This is only a problem if an abnormality appears on the screen as well.
●If two or more monitors are operated next to each other, their
images may shake or be distorted. This phenomenon is due to mutual interference; it is not a malfunction. Move the monitors away from each other until the interference disappears or turn the power off on any monitor that is not being used.
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT
Reference
pages
4
19
5
20
21, 22
Damper line
When black vertical lines appear on the screen Black vertical lines may appear on the screen if the aperture grill is tilted as a result of being shaken or jolted during shipment. In this case, try tapping the monitor on the side. If this does get rid of the lines, follow the procedure below. 1. Display a white screen, so that the problem area can be seen clearly. 2. Maximize the “CONTRAST” and “BRIGHT” adjustments, then place a bright white rectangle on the area.
3. After a while, the lines should disappear.
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF
SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF
SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF
SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT
25
SELF-CHECK INDICATIONS When the screen goes blank, and one or more of the INPUT SELECT A through F buttons on the front control panel start blinking... This monitor has a self-check function, which allows it to detect malfunctions and alert you. This makes trouble-shooting easier. Whenever a problem occurs, a combination of “self-check indicators” (INPUT SELECT A through F buttons) will blink and the monitor’s power automatically turns off. If this happens, follow the steps below and contact your dealer to resolve the problem.
1. Check which indicators are blinking. 2. Turn off the main power switch on the back of the monitor. 3. Disconnect the Power Cord from the AC outlet. 4. Contact your dealer with the information about which indicators are blinking.
NOTE: ●If you turn on the monitor’s power immediately after turning it off (or after a short-term power failure), the self-check indicators
may blink, and no image may be displayed. When this happens, turn off the power, and wait at least 10 seconds before turning it on again. If the self-check indicators have stopped blinking, you can use the monitor as usual.
SLOT 1
AB
SLOT 2
CD
SLOT 3
EF
INPUT SELECT
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF
SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT

(No.52097)
DT-V1910CG
26
SPECIFICATIONS
Type : Multi-Format Monitor Picture Tube : 19" measured diagonally Effective
Screen Size : Width : 370 mm (14-5/8")
Height : 270 mm (10-5/8") Diagonal : 460 mm (18-1/8")
Scanning
Frequency : H : 15 kHz/27 kHz – 45 kHz
V : 50 Hz – 80 Hz
Video Band : Component : 25 MHz (–3 dB)
Video (Y/C) : 8 MHz (–3 dB)
Horizontal
Resolution : Video (Y/C) : 600 TV lines
1080/60i : 900 TV lines
Input
Terminals : Installing an optional input card in SLOT 1,
2, or 3 is required.
INPUT A/INPUT B: Terminals on the input
card in SLOT 1
INPUT C/INPUT D: Terminals on the input
card in SLOT 2
INPUT E/INPUT F: Terminals on the input
card in SLOT 3
Compliant
Video Signal : NTSC (3.58 MHz)/PAL (4.43 MHz)
(using the IF-C01PNG)
480i/576i/480p/576p/1080i (50 HZ/60 HZ/
24psF)/720p (using the IF-C01COMG)
D1 serial digital (using the IF-C01SDG)
HD serial digital (using the IF-C12HSDG)
[Dimensions]
Unit : mm (inch)
<Front View with the wide mask attached>
440 (17-3/8)
377
(14-7/8")*
285
(11-1/4")*
380.4 (15")
372
(14-3/4")*
206
(8-1/8")*
336 (13-1/4")
95.7
(3-7/8")
5
(1/4") 5
(1/4")
485 (19-1/8")
1.5
(1/16")
496 (19-5/8")
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF
SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK ASPECT AREA
MARKER
UNDER
SCAN PULSE
CROSS COLOR
OFF SLOT2
CD
SLOT3 POWER
EF
INPUTSELECT
375 (14-7/8")
<Front View>

Remote Inputs
: • Point-of-contact connection, 1 line,
D-sub connector (15-pin 3-line)
• Serial connection, 1 line, D-sub connector
(9-pin), compliant to RS-232C
Audio Output : 1 W (monaural) Built-in
Speaker : 8 cm (3-1/8") round x 1
Environmental
Conditions : Operating temperature : 5°C – 35°C
(41°F – 95° F)
Operating humidity : 20% – 80%
(non-condensing)
Power
Requirements
: 120/230 V AC, 50 Hz/60 Hz
Power
Consumption : 1.8A/1.0A (when input card is inserted)
Max. 2.1 A/1.2 A (when input card is inserted)
Dimensions : Width : 440 mm (17-3/8")
Height : 375 mm (14-7/8") Depth : 496 mm (19-5/8")
(not including wide mask and input card)
Weight : 29.4 kg(64.7 lbs)
(not including wide mask and input card)
Accessory : AC power cord
: Power cord holder x 1 (case and cover) : Screws x 2 (Power cord holder) : Wide Mask x 1 : Screws x 4 (Wide Mask)
<Side View>
* Illustrations and pictures used in this manual have been
exaggerated, abbreviated or compounded for explanatory purposes only. The appearance of the actual product may differ slightly.
* Dimensions and weight are approximate. * E. & O.E. Design and specifications subject to change without
notice.
Asterisks(*) are used to indicate
front panel dimensions.
27
Compliant Signal Formats of Each Input Card
Input Signals IF-C01PNG IF-C01COMG IF-C01SDG IF-C12HSDG NTSC (3.58 MHz)
R
———
PAL (4.43 MHz)
R
———
Black-and-White (50 Hz/60 Hz)
R
———
480/60i (525i) —
RR
—
480/60p (525p) —
R
——
576/50i —
RR
—
576/50p —
R
——
720/50 (720p) —
R
——
720/60p (720p) —
R
—
R
1080/50i —
R
—
R
1080/60i (1125i) —
R
—
R
1035/60i (1125i) (*1) —

—

1080/24psF —
R
—
R
EMBEDDED AUDIO — — —
R
R
: Input possible. Pre-set.

: Input possible. Not pre-set.
– : Input impossible
*1 : 1035/60i (1125i) is not pre-set. To input signals of these types, some setup adjustments are required.
NOTE: This monitor is designed to accept AUTO INPUT and AUDIO LEVEL METER (for EMBEDDED AUDIO) input cards that will be for sale in the future.

(No.52097)
DT-V1910CG
28
SPECIFICATIONS (INPUT CARD: OPTIONAL)
IF-C01COMG: COMPONENT/RGB INPUT CARD Type : Component/RGB input card for Multi-Format Monitor Inputs/Outputs : Component (Y, P
B
/B-Y, P
R
/R-Y) or RGB: 1 line, BNC connector x 6
(Y: 1 V (p-p), 75 Ω/P
B
, B-Y, P
R
, R-Y, R, G, B: 0.7 V (p-p), 75 Ω)
Synchronized signal (HD/C
S
, VD) : 1 line, BNC connector x 4 (1.0 V – 4.0 V (p-p), 75 Ω)
* The input (IN) and output (OUT) terminals are bridge-connected. Auto termination. Audio signal: 1 line (monaural), RCA pin x 2 (0.5 V (rms), high impedance) * The input (IN) and output (OUT) terminals are bridge-connected.
Required slots :1 Power consumption : 14 V DC, 0.02 A Weight : 0.5 kg (1.1 lbs.) Dimensions
(W x H x D) : 43 mm x 154.5 mm x 191.9 mm
(1-3/4" x 6-1/8" x 7-5/8")
IF-C01PNG: VIDEO INPUT CARD Type : Video input card for Multi-Format Monitor Inputs/Outputs : VIDEO 1/VIDEO 2: 2 lines, BNC connector x 4 (1 V (p-p), 75 Ω)
Synchronized signal (EXT.SYNC): 1 line, BNC connector x 2 (1.0 V – 4.0 V (p-p), 75 Ω) * The input (IN) and output (OUT) terminals are bridge-connected. Auto termination. Y/C signal : 1 line, input only, mini-DIN 4-pin connector x 1 (Y/C input has a priority to a
VIDEO 2 input) (Y: 1 V (p-p), 75 Ω/C: 0.286 V (NTSC)/0.3 V (PAL), 75 Ω)
Audio signal : 2 lines (monaural), RCA pin x 4 (0.5 V (rms), high impedance) * The input (IN) and output (OUT) terminals are bridge-connected.
Required slots :1 Power consumption : 14 V DC, 0.25 A
7 V DC, 0.15 A
Weight : 0.5 kg (1.1 lbs.) Dimensions (W x H x D) : 43 mm x 154.5 mm x 191.9 mm
(1-3/4" x 6-1/8" x 7-5/8")
IF-C01SDG: SDI INPUT CARD Type : SDI input card for Multi-Format Monitor Inputs/Outputs : Digital input (SDI 1/SDI 2): 2 lines, BNC connector x 2 (0.8 V (p-p), 75 Ω)
Digital output (SWITCHED OUT): 1 line, BNC connector x 1 (0.8 V (p-p), 75 Ω) Audio signal: 2 lines (monaural), RCA pin x 4 (0.5 V (rms), high impedance) * The input (IN) and output (OUT) terminals are bridge-connected.
Format : D1 serial component digital, 525/625 auto switching (compliant to SMPTE259M) Required slots :1 Power consumption : 7 V DC, 0.65 A Weight : 0.5 kg (1.1 lbs.) Dimensions
(W x H x D) : 43 mm x 154.5 mm x 191.9 mm
(1-3/4" x 6-1/8" x 7-5/8")
29
IF-C12HSDG: HD SDI INPUT CARD Type : HD SDI input card for Multi-Format Monitor Inputs/Outputs : Digital input (HD SDI 1/HD SDI 2): 2 lines, BNC connector x 2 (0.8V (p-p), 75 Ω)
(compliant with EMBEDDED AUDIO)
Digital output (HD SDI 1/HD SDI 2): 2 lines, BNC connector X 2 (0.8V (p-p), 75 Ω)
Format : HD serial component digital, BTA S-004B, SMPTE292M (Digital Interface Standard),
SMPTE299M (EMBEDDED AUDIO)
Required slots : 1 Power consumption : 14 V DC, 0.6A
7 V DC, 0.6A
Weight : 0.5 kg (1.1 lbs.) Dimensions
(W x H x D) : 43 mm x 154.5 mm x 191.5 mm
(1-3/4" x 6-1/8" x 7-5/8")
