JVC UX-G70 User manual

MICRO COMPONENT SYSTEM
UX-G70
—Consists of CA-UXG70 and SP-UXG70
INSTRUCTIONS
GVT0181-001B
[J,C]
SUPER VIDEO
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bot-
tom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
Cover[J].fm Page 1 Friday, March 17, 2006 10:36 AM
Downloaded From Disc-Player.com JVC Manuals

G-1
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution, d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le coffret
de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à l’humidité.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2.
CAUTION: Do not open the top cover. There are no user
serviceable parts inside the unit; leave all servicing to qualified
service personnel.
3.
CAUTION: Visible and/or invisible class 1 M laser radiation when
open. Do not view directly with optical instruments.
IMPORTANT POUR PRODUIT LASER
1. PRODUIT LASER CLASSE 1
2.
ATTENTION : N’ouvrez pas le couvercle supérieur. Il n’y a
aucune pièce réparable par l’utilisateur à l’intérieur de l’appareil;
confiez toute réparation à un personnel qualifié.
3.
ATTENTION : Rayonnement laser visible et/ou invisible de
classe 1 M une fois ouvert. Ne pas regarder directement avec
des instruments optiques.
CAUTION — (standby) button!
Disconnect the mains plug to shut the power off completely.
When installing the apparatus, ensure that the plug is easily
accessible. The button in any position does not disconnect
the mains line.
• When the unit is on standby, the STANDBY lamp lights in red.
• When the unit is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
Attention –– Commutateur (attente)!
Déconnecter la fiche de secteur pour couper complètement le
courant. Le commutateur ne coupe jamais complètement
la ligne de secteur, quelle que soit sa position.
•Quand l’appareil est en mode d’attente, le témoin STANDBY est
allume en rouge.
•Quand l’appareil est sous tension, le témoin STANDBY s’éteint.
Le courant peut être télécommandé.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to section 820-40 of the NEC which provides
guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as
practical.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
[European Union only]
[Union européenne seulement]
For U.S.A.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
CAUTION
Changes or modifications not approved by JVC could void the
user’s authority to operate the equipment.
ATTENTION
Des changements ou modifications non approuv é s par JVC
pourront invalider l’autorit
é de l’utilisateur à op é rer cet
appareil.
Declaration of Conformity:
Trade Name: JVC
Model Number: UX-G70
Responsible Party: JVC American Corp.
Address: 1700 Valley Road, Wayne New Jersey 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired operation.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS
B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL
APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,”
ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE
BRUITS RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMIRIQUES DE CLASSE B PRESCRITES DANS
LA NORME SUR LE MATERIEL BROUILLEUR; “APPAREILS
NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES
COMMUNICATIONS.
Safty[J].fm Page 1 Friday, March 17, 2006 10:36 AM
Downloaded From Disc-Player.com JVC Manuals

1
Precautions
Installation
•Install the System in a location with adequate ventilation to
prevent internal heat buildup in the System.
•Install in a place which is level, dry and neither too hot nor
too cold—between 5°C and 35°C (41°F and 95°F).
• Leave sufficient distance between the System and the TV.
•Keep the speakers away from the TV to avoid interference
with the TV.
Power sources
•When unplugging the System from the wall outlet, always
pull on the plug, not the AC power cord.
Moisture condensation
Moisture may condense on the lenses inside the System in
the following cases:
• After starting to heat the room
• In a damp room
• If the System is brought directly from a cold to a warm
place.
Should this occur, the System may malfunction. In this case,
leave the System turned on for a few hours until the moisture
evaporates, unplug the AC power cord, then plug it in again.
Internal heat
• Make sure there is good ventilation around the unit. Poor
ventilation could overheat and damage the unit.
Others
• Should any metallic object or liquid fall into the System,
unplug the AC power cord and consult your dealer before
operating any further.
•If you are not going to operate the System for an extended
period of time, unplug the AC power cord from the wall
outlet.
If anything goes wrong, unplug the AC power cord and
consult your dealer.
Contents
Connections ..............................................................3
Display Indicators....................................................6
Daily Operations—Playback ..................................7
Daily Operations—Sound & Other Adjustments .....12
Adjusting the Volume ....................................................... 12
Adjusting the Sound.......................................................... 12
Creating 3-dimentional Sound Field—3D Phonic ............ 13
Presetting Automatic DVD Video Sound Increase Level......13
Adjusting the Audio Input Level ...................................... 13
Adjusting the Audio Output Level.................................... 13
Changing the Display Brightness...................................... 14
Changing the Scanning Mode ........................................... 14
Changing the Picture Tone................................................ 14
Setting the Clock............................................................... 15
Turning Off the Power Automatically .............................. 15
Unique DVD/VCD Operations .............................16
Selecting the Audio Track................................................. 16
Selecting the Subtitle Language........................................ 17
Selecting the View Angle ................................................. 17
Selecting the Browsable Still Pictures .............................. 17
Playing Back Bonus Group............................................... 17
Making Dialogues Clear—Clear Voice ............................ 18
Special Effect Playback .................................................... 18
Advanced Disc Operations....................................19
Programming the Playing Order—Program Play ............. 19
Playing at Random—Random Play .................................. 20
Playing Repeatedly ........................................................... 21
Prohibiting Disc Ejection—Child Lock............................ 21
On-screen Disc Operations ............................................... 22
Operations on the Control Screen ..................................... 26
Timer Operations...................................................28
Setup Menu Operations ........................................30
Additional Information .........................................32
Learning More about This System.................................... 32
Troubleshooting ................................................................ 35
Operating JVC’s TVs Using the Remote Control............. 37
Specifications .................................................................... 38
Parts Index ............................................................39
DO NOT install the System in a location near
heat sources, or in a place subject to direct
sunlight, excessive dust or vibration.
DO NOT handle the AC power cord with wet
hands.
DO NOT block the ventilation openings or
holes. If they are blocked by a newspaper or
cloth, etc., the heat may not be able to get out.
DO NOT disassemble the System since there
are no user serviceable parts inside.
Introduction
UX-G70[J].book Page 1 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

2
Playable Disc Types
In addition to the above discs, this System can playback
audio data recorded on CD-Extra.
• The following discs cannot be played back:
DVD-RAM, CD-I (CD-I Ready), CD-ROM, Photo CD,
CD-G (CD-Graphics), and DVD/CD Text.
Playing back these discs will generate noise and damage
the speakers.
•In this manual, “file” and “track” are interchangeably used
for MP3/WMA/JPEG operations.
•It is possible to playback finalized +R/+RW (DVD format
only) discs. “DVD” lights on the front display panel when
a +R/+RW disc is loaded.
Note on Region Code
DVD players and DVDs have their own Region Code
numbers. This System can playback only DVDs with Region
Code numbers including “1.”
Audio formats
The System can playback the following digital audio
formats.
•
LPCM
(Linear PCM), DIGITAL (Dolby Digital),
DTS (Digital Theater Systems),
MLP
(Meridian Lossless
Packing)
When playing a multi-channel encoded DVDs, the System
properly converts these multi-channel signals into 2
channels, and emits the downmixed sound from the
speakers.
•
To enjoy the powerful sound of these multi-channel
encoded DVDs,
connect a proper decoder or an amplifier
with a proper built-in decoder to the DVD OPTICAL
DIGITAL OUT terminal on the rear.
How to Read This Manual
• Button and control operations are explained in the table
below.
• Some related tips and notes are explained later in the
sections “Learning More about This System” and
“Troubleshooting,” but not in the same section
explaining the operations ( indicates that the
content has some information).
“DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation registered in the US, Japan and other
countries.
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore, the
use of the Non-DVD side of a DualDisc in this product is not
recommended.
•CD-R/-RW: Recorded in the Audio CD, Video CD and
SVCD formats. MP3, WMA and JPEG files written in
accordance with the “ISO 9660” format can also be
played.
• DVD-R/-RW, +R/+RW: Recorded in the DVD Video
format. MP3, WMA and JPEG files written in the UDF
bridge format can also be played.
• DVD-RW/-ROM: Recorded in the DVD Video
Recording (VR) format.
EX.:
DIGITAL VIDEO
SUPER VIDEO
COMPACT
DIGITAL AUDIO
IMPORTANT: Before playing a disc, make sure of
the following...
•Turn on the TV and select an appropriate input mode on
the TV to view the pictures or on-screen displays.
•For disc playback, you can change the initial setting to
your preference. See “Setup Menu Operations” on
page 30.
If “ ” appears on the TV screen when you press a
button, the disc cannot perform the operation you have
tried to do.
Indicates that you press the button
briefly.
Indicates that you press the button
briefly and
repeatedly
until an option you want is
selected.
Indicates that you press one of the buttons.
Indicates that you
press and hold
the button
for a specified period.
Indicates that you turn the control toward the
specified direction(s).
Indicates that this operation is only possible
using the remote control.
Indicates that this operation is only possible
using the main unit.
INFO
2 sec.
Remote
ONLY
Main Unit
ONLY
UX-G70[J].book Page 2 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

3
Connections
• Connect VIDEO OUT directly to the video input of your
TV. Connecting VIDEO OUT to a TV via a VCR may
interfere with your viewing when playing back a copy-
protected disc. Connecting VIDEO OUT to an integrated
TV/VCR system may also interfere with your viewing.
Do not connect the AC power cord until all other
connections have been made.
Supplied accessories
Check to be sure that you have all the following items.
• FM antenna (x1)
• AM loop antenna (x1)
• Composite video cord (x1)
• Core filter* (x1)
• Remote control (x1)
• Batteries (x2)
If any item is missing, consult your dealer immediately.
Front panel
Pull down the cover until you hear a clicking sound.
From the portable audio device: See page 5.
From the PC: See page 11.
From the headphones: See page 7.
¤To a wall outlet
Plug in the AC power cord only after all connections
are complete.
⁄From the digital input of digital audio component
See page 5.
~From the powered subwoofer
See page 4.
!From the input of TV/monitor
See page 4.
ŸFrom AM/FM antenna
See page 4.
@From the speakers
See page 5.
From the video game: See page 11.
*Attaching the core filter to the USB cable to reduce interference
Wind firmly the USB cable twice.
•Keep close between the plug connected to the
System and the core filter.
• Do not damage the USB cable by applying
excessive force when winding.
Close the core
filter until you
hear a clicking
sound.
Stopper
At the front panel
Rear panel
UX-G70[J].book Page 3 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

4
~
Powered subwoofer
The subwoofer connected can reproduce the bass sounds
recorded in front left and right channels, but cannot
reproduce the LFE signals in DVD multi-channel discs.
•Before plugging the unit to the main supply, make sure that
the powered subwoofer is turned off.
Ÿ
AM/FM antenna
To assemble the AM loop antenna
To connect AM/FM antenna
For better AM/FM reception
• Disconnect the supplied FM antenna, and connect to an
outdoor FM antenna using a 75
Ω wire with coaxial type
connector (IEC or DIN45325).
!
TV/monitor
Connect only component cord at one time.
•To select progressive scanning mode (see page 14), use
COMPONENT jacks.
•After connecting a TV, select the proper video signal mode
according to the connection method. See “Changing the
Scanning Mode” on page 14.
SUB -
WOOFER
OUT
From the powered
subwoofer
(not supplied)
Extend it so that you can obtain the best
reception.
FM antenna (supplied)
AM loop antenna
(supplied)
AM loop antenna (supplied)
Keep it connected.
FM outdoor antenna
(not supplied)
Vinyl-covered wire
(not supplied)
Extend it horizontally.
Green
Blue
Red
Component video cord
(not supplied)
S-video cord (not supplied)
Composite video cord (supplied)
UX-G70[J].book Page 4 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

5
⁄
Digital audio component
• Set “DIGITAL AUDIO OUTPUT” in the “AUDIO” menu
correctly according to the connected digital audio
equipment (see page 31). If
the setting is incorrect, loud
noise may be generated causing damage to the speakers.
•Digital audio signals are output from this System only when
“DVD/CD” is selected as the source.
@
Speakers
• When connecting the speaker cords, match the polarity of
the speaker terminals: red color to (+) and black color to (–).
• By using QP Link (Quick Portable Link), you can easily
start playing back a portable audio device on this unit when
connecting it to the LINE IN jack. See page 10 for details.
• Connect an audio component to the LINE OUT jack if the
component is not equipped with a digital input terminal.
•If an external device is not equipped with a stereo mini plug
audio output, use a plug adaptor to convert the stereo mini
plug to the corresponding plug of the audio output.
Preparing the remote control
• Dispose of batteries in the proper manner, according to
federal, state, and local regulations.
When using the remote control
Point the top of the remote control toward the remote sensor
as directly as possible. If you operate it from a diagonal
position, the operating range (approx. 5 m/16-
2
/
5
inch) may
be shorter.
•DO NOT connect more than one speaker to
each terminal.
• DO NOT push or pull the speakers as this
will damage the foot spacers at the bottom
of the speakers.
Protective cap
CAUTION:
From right
speaker
From left
speaker
Red
Black
Press and hold
Release
Insert
When connecting a portable audio device (LINE)
DO NOT recharge, short, disassemble, heat
the battery or dispose of it in a fire.
Stereo mini plug
(not supplied)
At the front panel
Portable audio device
(Digital Audio Player, etc.)
Portable audio device with
the audio input
(Digital Audio Player, etc.)
To the audio output
To the audio input
R6(SUM-3)/AA(15F)
UX-G70[J].book Page 5 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

6
Display Indicators
The indications on the display tell you a lot of things while you are operating the System.
Before operating the System, be familiar with when and how the indicator illuminates on the display.
1 Disc tray indicators
• 1–5: Disc tray number indicators.
– Flashing while the disc tray is open.
• (disc tray indicator):
– Lights when the disc is detected.
– Flashing while playing back a disc or the disc tray is
open.
– Disappears when there is no disc in the tray.
•:Lights to indicate the current selected disc.
2 QP Link (Quick Portable Link) indicator
• Lights when QP Link is activated.
3 Audio file format indicators
• MP3: lights when an MP3 track is detected.
• WMA: lights when a WMA track is detected.
4 PG/PL indicators
• PG: lights when a DVD-VR formatted disc is called up.
• PL: lights when a playlist recorded on a DVD-VR
formatted disc is called up.
5 FM reception indicators
• MONO: lights while receiving an FM stereo station in
monaural.
• ST (stereo): lights while an FM stereo station with
sufficient signal strength is tuned in.
6 USB indicator
• Lights when “USB” is selected as the source.
7 AHB PRO indicator
• Lights when Active Hyper Bass Pro is activated.
8 S.TURBO (Sound Turbo) indicator
• Lights when Sound Turbo II is activated.
9 A.STBY (Auto Standby) indicator
• Lights when Auto Standby is activated.
• Flashes for about 3 minutes before Auto Standby turns
the System off.
p SLEEP indicator
• Lights when the Sleep Timer is activated.
q Playback mode indicators
• PRGM: lights when Program Play is activated.
• RANDOM: lights when Random Play is activated.
•
(repeat)1 DISC A-B ALL GROUP :
–:lights when One Track/Chapter/Step Repeat is
activated.
–:lights when Group Repeat is activated.
–:lights when One Disc Repeat is activated.
–:lights when All Disc Repeat is activated.
–:lights when A-B Repeat is activated.
w Main display
• While listening to radio: Band (or preset number) and
station frequency appear.
• While selecting “LINE”: “LINE” appears.
• While selecting “USB”: “USB AUDIO” appears.
• While selecting “GAME”: “G1 SPORT,” “G2 RPG,”
“G3 ACT,” “G4 NIGHT” or “G5 MANUAL” appears
(depending on the setting).
• While playing a disc: current status appears.
e 3D PHONIC indicator
• Lights when 3D Phonic is activated.
r (Clear Voice) indicator
• Lights when Clear Voice is activated.
t PRGR. (Progressive) indicator
• Lights when the progressive scanning mode is selected.
y B.S.P. (Browsable Still Picture) indicator
•Lights when Browsable Still Pictures are detected while
playing a DVD Audio disc.
u BONUS indicator
• Lights when a DVD Audio disc with a bonus group is
detected
.
i Daily Timer indicators
•1/2/3: lights when a Daily Timer (1, 2, or 3) is on standby;
flashes while working or being set.
•:lights when Daily Timer is on standby or is being set.
MONO
MP3
PL
PG
WMA
PRGR.
3D PHONIC B.S.P. BONUS
ST
TA
NEWS INFO
AHB PRO
A.STBY
123
S.TURBO SLEEP
PRGM
QP Link
USB
REC
REC
1
RANDOM
GROUP
DISC ALL A–B
124
3567 p
89
ewrtyqui
1
GROUP
1 DISC
DISC ALL
A–B
UX-G70[J].book Page 6 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

7
Daily Operations
—Playback
1
Turn on the power.
The STANDBY lamp on the main unit goes off.
• Without pressing AUDIO, the System turns on
by pressing one of the source buttons.
•The System turns on and changes the source to LINE
by starting playback on an external device when
QP Link is activated. (See page 10 for details.)
2 Select the source.
Playback automatically starts if the selected source is
ready.
• If you press LINE, start playback on the external
component.
• If you press GAME, turn on the video game
connected to the System.
3
Adjust the volume.
4
Operate the target source as explained
later.
To turn off (standby) the unit
You can reduce power consumption by pressing DISPLAY
to turn the display off while on standby.
• When the display is turned off, QP Link does not work.
2
1
VOLUME
TV VOLUME
3
4
DVD/CD USB
FM/AM LINE
GAME
1
GROUP/TITLE SKIP
FM/PLAY MODE
4,¢
1,¡
8
7
SHIFT
,, ,
2
ENTER/SET
MENU/PL
RETURN
TOP MENU/PG
QP LINK
MONO
MP3
PL
PG
WMA
PRGR.
3D PHONIC B.S.P. BONUS
ST
TA
NEWS INFO
AHB PRO
A.STBY
123
S.TURBO SLEEP
PRGM
QP Link
USB
REC
REC
1
RANDOM
GROUP
DISC ALL A–B
3
Number
buttons
Disc tray
selecting
buttons
Remote control
In this manual, operations using the remote control are
mainly explained; however, you can use the buttons
and controls on the main unit if they have the same (or
similar) name and marks.
The STANDBY lamp on the main unit
lights in red.
•Asmall amount of power is always
consumed even while on standby.
For private listening
Connect a pair of headphones to the PHONES jack on the
main unit. The sound will no longer come out of the
speakers. Be sure to turn down the volume before
connecting or putting on the headphones.
• Disconnecting the headphones will activate the
speakers again.
DO NOT turn off (standby) the System with
the volume set to an extremely high level;
otherwise, the sudden blast of sound can
damage your hearing, speakers and/or
headphones when you turn on the System or
start playback.
UX-G70[J].book Page 7 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

8
Listening to the Radio
To select the band (FM or AM)
To tune in to a station
While FM or AM is selected...
Frequency starts changing on the display.
When a station (frequency) with sufficient signal strength is
tuned in, the frequency stops changing.
• When you repeatedly press the button, the frequency
changes step by step.
To stop searching manually,
press either button.
If the FM station has poor reception
The MONO indicator lights on the display. Reception will
improve though stereo effect is lost—Monaural reception.
To restore the stereo effect,
press the button again (the
MONO indicator disappears).
To preset the stations
You can preset 30 FM and 15 AM stations.
1
Tune in to a station you want to preset.
•You can also store the monaural reception mode for FM
preset stations if selected.
2
Activate the preset number entry mode.
•Finish the following process while the indication on the
display is flashing.
3
Select a preset number for the station you store.
• You can also use the ¡ or 1 button.
4
Store the station.
To tune in to a preset station
1
Select the band (FM or AM).
2
Select the preset number for the station you stored.
• You can also use the ¡ or 1 button.
Remote control: Main unit:
Remote control: Main unit:
INFO
GROUP/TITLE SKIP
2sec. 2sec.
DOWN UP
Remote
ONLY
FM/PLAY MODE
PAG E
Remote
ONLY
MONO
MP3
PL
PG
WMA
PRGR.
3D PHONIC B.S.P. BONUS
ST
TA
NEWS INFO
AHB PRO
A.STBY
123
S.TURBO SLEEP
PRGM
QP Link
USB
REC
REC
1
RANDOM
GROUP
DISC ALL A–B
ENTER/SET
Examples:
To select preset number 5, press
5.
To select preset number 10, press
10.
To select preset number 15, press
10, 1, then 5.
To select preset number 30, press
10, 3, then 0.
Examples:
To select preset number 5, press
5.
To select preset number 10, press
10.
To select preset number 15, press
10, 1, then 5.
To select preset number 30, press
10, 3, then 0.
DISC 1
A.STANDBY
SLEEP VFP
LINE OUT LEVEL ZOOM
SCAN MODE
1
4
7
10
2
5
8
3
6
9
10
ANGLE
0
DISC 2 DISC 3
DISC 4 DISC 5
ENTER/SET
MONO
MP3
PL
PG
WMA
PRGR.
3D PHONIC B.S.P. BONUS
ST
TA
NEWS INFO
AHB PRO
A.STBY
123
S.TURBO SLEEP
PRGM
QP Link
USB
REC
REC
1
RANDOM
GROUP
DISC ALL A–B
Remote
ONLY
TUNER FM
TUNER AM
DISC 1
A.STANDBY
SLEEP VFP
LINE OUT LEVEL ZOOM
SCAN MODE
1
4
7
10
2
5
8
3
6
9
10
ANGLE
0
DISC 2 DISC 3
DISC 4 DISC 5
UX-G70[J].book Page 8 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

9
Playing Back a Disc
Before operating a disc, be familiar how a disc is recorded.
• DVD Video/DVD-VR comprises of “ Titles ” which
includes “
Chapters
,” DVD Audio/MP3/WMA/JPEG
comprises of “
Groups
” which includes “
Tracks
,” JPEG
comprises of “
Groups
” which includes “
Files
,” and CD/
SVCD/VCD comprises of only “
Tracks
.”
•For playback of MP3/WMA/JPEG, see also page 26.
To insert a disc
You can insert a disc while playing another source.
•When using an 8 cm (3-
3
/
16
inch) disc, place it on the inner
circle of the disc tray.
To close the disc tray,
press the upper part of the same
button. The tray closes and playback starts.
• When current selected disc tray is open, you can use
DVD/CD 3 to close the disc tray and start playback
(depending on how the disc is programmed internally).
•
While one of the trays is open, the tray closes automatically
by pressing down EJECT for the next tray, then the next tray
comes out.
• While playing DVD/SVCD/VCD/MP3/WMA:
This
System can store the stop point, and when you start
playback again by pressing DVD/CD 3 (even while on
standby), it starts from the position where you have
stopped—Resume Play. (“RESUME” appears on the
display when you stop playback.)
To stop completely while Resume is activated, press 7
twice. (To cancel Resume, see “RESUME” on page 31.)
• When operating the System, the on-screen guide icon
(see the following table) appears on the TV.
To select a disc
To select a title/group
While playing a disc...
•You can select a title/group directly by pressing a number
button after pressing GROUP/TITLE (except for DVD-VR
disc).
• Group name appears for MP3/WMA playback.
To select a chapter/track
• For VCD/SVCD, cancel PBC (see the next page).
While playing a disc...
To start: To pause: To stop:
To release, press
DVD/CD 3 .
INFO
DVD/CD
On-screen guide icons
• During DVD Video playback, the following icons may
appear on the TV:
At the beginning of a scene containing
multi-angle views.
At the beginning of a scene containing
multi-audio sounds.
At the beginning of a scene containing
multi-subtitles.
• The following icons will be also shown on the TV to
indicate your current operation.
, , , , ,
• To deactivate the on-screen guide icons, see “ON
SCREEN GUIDE” on page 31.
Remote Control:
Main Unit:
• First time you press 4 , you
will go back to the beginning of
the current chapter/track.
1
4
2
5
3
DISC 1 DISC 2 DISC 3
DISC 4 DISC 5
(while holding...)
Playback
starts.
Playback starts.
Remote
ONLY
GROUP/TITLE SKIP
(while holding...)
GROUP/TITLE SKIP
UX-G70[J].book Page 9 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

10
To locate a particular portion
While playing a disc...
•Search speed changes as illustrated above except for MP3/
WMA discs. For MP3/WMA discs, search speed and the
indications on the TV are different.
• No sound comes out if searching is carried out while
showing the moving picture.
To return to normal playback, press DVD/CD 3 .
To locate an item directly
You can select a title/chapter/track directly and start
playback.
• For DVD Video, you can select
a title before starting
playback
, while you can select
a chapter after starting
playback
.
To playback using the disc menu
7 For DVD Video/DVD Audio:
1
Show the disc menu.
2
Select an item on the disc menu.
•With some discs, you can also select items by entering the
number using the number buttons.
7 For SVCD/VCD with PBC:
While playing a disc with PBC, “PBC” appears on the
display.
When disc menu appears on the TV, select an item on the
menu. Playback of the selected item starts.
To cancel PBC,
press 7 , then select a track. Playback starts
with the selected track.
To reactivate PBC,
press 7 (twice if Resume is turned
“ON”), then press DVD/CD 3 .
Playing Back a Portable Audio Device
By using QP Link (Quick Portable Link), you can easily start
playing back a portable audio device connected to the LINE
IN jack (see page 5).
•Make sure to set the volume of your portable audio device
loud enough so that the System can detect the sound signal.
To activate QP Link
When QP Link is activated, connecting a portable device to
the LINE IN jack and starting playback performs the
following:
Examples:
To select number 5, press 5.
To select number 10, press 10.
To select number 15, press 10,
1, then 5.
To select number 30, press 10,
3, then 0.
Remote
ONLY
SLOW
+
–
x2 x5 x10 x20 x60
x2 x5 x10 x20 x60
Remote
ONLY
DISC 1
A.STANDBY
SLEEP VFP
LINE OUT LEVEL ZOOM
SCAN MODE
1
4
7
10
2
5
8
3
6
9
10
ANGLE
0
DISC 2 DISC 3
DISC 4 DISC 5
Remote
ONLY
TOP MENU/PG MENU/PL
RETURN
TV CH
ENTER/SET
TV CH
Examples:
To select number 5, press 5.
To select number 10, press 10.
To select number 15, press 10,
1, then 5.
To select number 30, press 10,
3, then 0.
To move to the next or previous page of the current
menu:
To return to the previous menu:
DISC 1
A.STANDBY
SLEEP VFP
LINE OUT LEVEL ZOOM
SCAN MODE
1
4
7
10
2
5
8
3
6
9
10
ANGLE
0
DISC 2 DISC 3
DISC 4 DISC 5
GROUP/TITLE SKIP
Moves to the next page.
Moves to the previous page.
TOP MENU/PG
RETURN
(while holding...)
INFO
Remote
ONLY
QP LINK
CLOCK/TIMER
QPLINK ON
QPLINK OFF
(while holding...)
UX-G70[J].book Page 10 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

11
• While listening to another source...
Changes the source to LINE automatically. (If you change
from LINE to another source, QP link will be canceled.)
• While the System is on standby...
Turns on the System and activates the LINE source
automatically (except when the display is turned off).
While QP Link plays back the device...
Enjoying a video game
By connecting a video game to this System instead of a TV,
you can enjoy the image of the game with your TV and the
dynamic sound with this System.
• Refer also to the manual of your video game and TV.
To connect the video game
To enjoy powerful game sound
You can enjoy the sound effect for the genre or scene of the
game by selecting one of the settings below.
Playing Back from the PC
This System is equipped with a USB AUDIO terminal on the
front panel. You can connect your PC to this terminal and
enjoy sound reproduced through your PC.
When you connect your PC for the first time, follow the
procedure below.
• Remember you cannot send any signal or data to your PC
from this System.
How to install the USB drivers
1
Turn on your PC and start running WindowsR 98 * ,
WindowsR 98SE * , WindowsR Me * , WindowsR 2000 * ,
or WindowsR XP * .
• If the PC has been turned on, quit all the applications
running.
2
Select “USB” as the source.
3
Connect the System to the PC using a USB cable (not
supplied).
• Use “USB series A plug to B plug” cable less than
3 m .
4
The USB drivers are installed automatically.
To playback sound on the PC
Refer to the manuals supplied with the sound reproduction
application installed in the PC.
•Noise and static electricity may stop the sound through the
USB connection. In this case, do the following operations:
– Disconnect and connect the USB cable again
– Restart the music software on your PC
– Turn off and on the System
* MicrosoftR
, WindowsR 98, WindowsR 98SE,
WindowsR Me, WindowsR 2000 and WindowsR XP are
registered trademarks of Microsoft corporation.
Remote control: Main unit:
G1 SPORT For sport game (initial setting).
G2 RPG For RPG.
G3 ACT For action game.
G4 NIGHT For enjoying powerful game sound with
low sound level.
G5 MANUAL You can adjust the bass and treble level
manually with this setting. See “To adjust
the tone” on page 12 for how to adjust it.
MONO
MP3
PL
PG
WMA
PRGR.
3D PHONIC B.S.P. BONUS
ST
TA
NEWS INFO
AHB PRO
A.STBY
123
S.TURBO SLEEP
PRGM
QP Link
USB
REC
REC
1
RANDOM
GROUP
DISC ALL A–B
Bubbles appear
when QP Link
works.
MONO
MP3
PL
PG
WMA
PRGR.
3D PHONIC B.S.P. BONUS
ST
TA
NEWS INFO
AHB PRO
A.STBY
123
S.TURBO SLEEP
PRGM
QP Link
USB
REC
REC
1
RANDOM
GROUP
DISC ALL A–B
Bubbles disappear
when the sound signal
stops or is too weak.
INFO
Yellow
White
Red
Video game
At the front panel
GAME
G1 SPORT
G2 RPG G3 ACT
G4 NIGHT
G5 MANUAL
(initial setting)
IMPORTANT
•Always set volume to “VOL MIN” when connecting or
disconnecting the other equipment.
Remote control: Main unit:
INFO
USB
USB cable
PC
At the front panel
UX-G70[J].book Page 11 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

12
Daily Operations
—Sound & Other Adjustments
Adjusting the Volume
You can adjust the volume level from VOL MIN to level 40
(VOL MAX).
To drop the volume in a moment
Adjusting the Sound
To reinforce the heavy sound
This boosts the low and high frequency sound—Sound
Turbo II.
• When Sound Turbo II is turned on, AHB Pro is
automatically turned on, and cannot be turned off.
(AHB PRO indicator does not light even though the
function is turned on.)
To reinforce the bass sound
While Sound Turbo II is off, the richness and fullness of the
bass sound is clearly maintained regardless of how you set
the volume—Active Hyper Bass Pro.
•When Sound Turbo II is turned on, AHB Pro setting cannot
be changed.
To adjust the tone
You can adjust the bass and treble level from –3 to +3.
To adjust the bass
To adjust the treble
Remote control: Main unit:
VOLUME +,–
SOUND
TURBO
DIMMER
Remote control
Main unit
SOUND TURBO
VOLUME
+,–
A.STANDBY
SLEEP
ENTER/SET
DVD LEVEL
AHB PRO
DISPLAY
CLOCK/TIMER
BASS/TREBLE
VFP
DIMMER
SCAN MODE
SHIFT
FADE
MUTING
,, ,
3D PHONIC
LINE OUT LEVEL
VOLUME
TV VOLUME
VOLUME
To restore the volume,
press again, or
adjust the volume level.
Remote
ONLY
FADE
MUTING
INFO
SOUND
TURBO
TURBO ON
TURBO OFF
Remote
ONLY
AHB PRO
DVD LEVEL
AHB ON
AHB OFF
Remote
ONLY
BASS/
TREBLE
BASS TREBLE
VOLUME
TV VOLUME
Canceled
BASS/
TREBLE
BASS TREBLE
VOLUME
TV VOLUME
Canceled
UX-G70[J].book Page 12 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

13
Creating 3-dimentional Sound Field
—3D Phonic
While playing a disc...
• The selected mode can only be shown on the TV.
Presetting Automatic DVD Video Sound
Increase Level
DVD Video sound is sometimes recorded at a lower level
than other discs and sources. You can set the increase level
for the currently loaded DVD Video, so you do not have to
adjust the volume when you change the source.
• This only functions for DVD Video.
Adjusting the Audio Input Level
If the sound from the component connected to the
LINE IN jack is too loud or is too quiet when changing from
another source to LINE, you can change the audio input level
through the LINE IN jack (without changing the volume
level).
Adjusting the Audio Output Level
If the recorded sound on the device connected to the LINE
OUT jack is too loud or too quiet, you can change the audio
output level through the LINE OUT jack (without changing
the volume level).
ACTION Suitable for action movies and sports
programs.
DRAMA Creates natural and warm sound. Enjoy
movies in a relaxed mood.
THEATER Enjoy sound effects like in a major theater.
NORMAL Original recording level.
MEDIUM Output level is increased (less than “HIGH”).
HIGH Output level is increased (more than
“MEDIUM”). (initial setting)
Remote
ONLY
3D PHONIC ACTION 3D PHONIC DRAMA
3D PHONIC THEATER 3D PHONIC OFF
3D PHONIC
AUDIO/MPX
(while holding...)
Remote
ONLY
AHB PRO
DVD LEVEL
NORMAL MEDIUM
HIGH
(while holding...)
(initial setting)
L.IN LVL1 Select this when the sound is too loud
with “L.IN LVL 2” selected. This setting
is recommended when connecting an
audio device other than a portable audio
device to the LINE IN jack.
L.IN LVL2 Select this when the sound is too loud
with “L.IN LVL 3” selected.
L.IN LVL3 Select this when listening to a portable
audio device (initial setting).
L.OUT LVL1 Select this when recording the sound
with a portable audio device (initial
setting).
L.OUT LVL2 Select this when the recorded sound is
too loud with “L.OUT LVL 1” selected.
Remote
ONLY
ENTER/SET
L.IN LVL1 L.IN LVL2
L.IN LVL3
(initial setting)
2 sec.
Remote
ONLY
LINE OUT LEVEL
10
L.OUT LVL1
L.OUT LVL2
(while holding...)
(initial setting)
UX-G70[J].book Page 13 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

14
Changing the Display Brightness
You can dim the display window.
* “AUTO DIM” does not work for CD/MP3/WMA.
Changing the Scanning Mode
This System supports progressive scanning.
Select the video signal mode according to the type of your
TV. If you connect a progressive TV through the VIDEO
OUT jacks, you can enjoy a high quality picture from the
built-in DVD player by selecting “PROGRE.”
Changing the Picture Tone
• While showing a playback picture on the TV, you can
select a preset picture tone, or adjust it and store your own
taste.
To select a preset picture tone
1
While playing, display VFP setting screen.
2
Select a preset picture tone.
To remove the screen,
press VFP again while holding
SHIFT, or wait for more than 5 seconds.
To adjust the picture tone
1
Select “USER1” or “USER2.”
• Follow steps 1 and 2 explained above.
2
Select a parameter you want to adjust.
DIMMER ON Dims the display.
AUTO DIM * Removes the display illumination when
starting playback a disc with a video
source.
• The display illuminates when playback
stops.
INTER Select for a conventional TV.
PROGRE Select for a progressive TV.
Select to enjoy a progressive scanned
picture through the Video
Component out terminal.
TV/VIDEO
DIMMER
DIMMER ON
AUTO DIM
DIMMER OFF
(Canceled)
Remote
ONLY
INFO
SCAN MODE
7
PROGRE
INTER
ENTER/SET
(while holding...)
NORMAL Normally select this.
CINEMA Suitable for a movie source.
USER1/USER2 You can adjust parameters and can
store the settings.
GAMMA Adjust if the neutral color is bright
or dark (–3 to +3).
BRIGHTNESS Adjust if the entire picture is bright
or dark (–8 to +8).
CONTRAST Adjust if the far and near positions
are unnatural (–7 to +7).
SATURATION Adjust if the picture is whitish or
blackish (–7 to +7).
TINT Adjust if the human skin color is
unnatural (–7 to +7).
SHARPNESS Adjust if the picture is indistinct
(–8 to +8).
Remote
ONLY
VFP
8
0
NORMAL
GAMMA
BRIGHTNESS
CONTRAST
SATURATION
TINT
SHARPNESS
0
0
0
0
0
(while holding...) On the TV
NORMAL CINEMA
USER2 USER1
ENTER/SET
TV CH
TV CH
UX-G70[J].book Page 14 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

15
3
Adjust the parameter.
4
Repeat steps 2 to 3 to adjust other parameters.
To remove the screen, press VFP again while holding
SHIFT, or wait for more than 5 seconds.
Setting the Clock
Without setting the built-in clock, you cannot use Daily
Timers (see page 28) and Sleep Timer.
•To correct a mis-entry during the process, press CANCEL
or CLOCK/TIMER. You can return to the previous step.
1 Activate the clock setting mode.
•If you have already adjusted the clock before, press the
button repeatedly until the clock setting mode is
selected.
2
Set the time.
•Adjust the hour and press ENTER/SET, then adjust the
minute and press ENTER/SET.
Now the built-in clock starts working.
To check the current clock time during play
Turning Off the Power Automatically
Auto Standby
When Auto Standby is in use, the A.STBY indicator lights
on the display.
When disc play stops, the A.STBY indicator starts flashing.
If no operation is done for about 3 minutes while the
indicator is flashing, the System turns off (on standby)
automatically.
Sleep Timer
You can set the shut-off time so that you can go to bed
without turning it off yourself.
1
Specify the time (in minutes).
2
Wait until the set time disappears.
To check the time remaining until the shut-off time, press
SLEEP while holding SHIFT.
• If you press the button repeatedly, you can change
the shut-off time.
ENTER/SET
TV CH
TV CH
Remote
ONLY
INFO
QP LINK
CLOCK/TIMER
MONO
MP3
PL
PG
WMA
PRGR.
3D PHONIC B.S.P. BONUS
ST
TA
NEWS INFO
AHB PRO
A.STBY
123
S.TURBO SLEEP
PRGM
QP Link
USB
REC
REC
1
RANDOM
GROUP
DISC ALL A–B
ENTER/SET
MONO
MP3
PL
PG
WMA
PRGR.
3D PHONIC B.S.P. BONUS
ST
TA
NEWS INFO
AHB PRO
A.STBY
123
S.TURBO SLEEP
PRGM
QP Link
USB
REC
REC
1
RANDOM
GROUP
DISC ALL A–B
DISPLAY
CANCEL
Source information
(while holding...)
Clock
Disc type
Remote
ONLY
A.STANDBY
6
(while holding...)
Canceled
On
SLEEP
9
10 20 30 60 90 120 150
(while holding...)
Canceled
UX-G70[J].book Page 15 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

16
Unique DVD/VCD Operations
Selecting the Audio Track
For DVD Video:
While playing back a chapter containing
audio languages, you can select the language to listen to.
For DVD Audio:
While playing back a track containing
audio channels, you can select the audio channel to listen to.
For DVD-VR and SVCD/VCD:
When playing back a track,
you can select the audio channel to play.
•You can also select the audio track using the on-screen bar
(see page 22).
While playing a DVD Video...
While playing a DVD Audio...
While playing a DVD-VR, or SVCD/VCD...
• SVCD can have 4 audio channels. SVCD usually uses
these 4 channels to record two 2-channel recordings
(ST1/ST2).
ANGLE
ENTER
/SET
SLOW ,
AUDIO/MPX
ZOOM
87
C.VOICE
SUBTITLE
SHIFT
DVD/CD 3
,, ,
PAGE
Remote control
Number
buttons
ST1/ST2/
ST
To listen to normal stereo (2-channel)
playback.
L1/L2/L To listen to the left audio channel.
R1/R2/R To listen to the right audio channel.
Remote
ONLY
INFO
3D PHONIC
AUDIO/MPX
ENGLISH
1/3 3/3
FRENCH
2/3
JAPANESE
ENGLISH
1/3
FRENCH
2/3
JAPANESE
3/3
Ex.:
1
1/3
2
2/3
3
3/3
Ex.:
3D PHONIC
AUDIO/MPX
ST1 ST2 L1
R2 L2 R1
ST L R
SVCD
DVD-VR/VCD
UX-G70[J].book Page 16 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

17
Selecting the Subtitle Language
For DVD Video:
While playing back a chapter containing
subtitles in different languages, you can select the subtitle
language to display on the TV.
For DVD-VR:
While playing, you can turn the subtitles on
or off.
For SVCD:
While playing, you can select the subtitles even
if no subtitles are recorded on the disc.
• You can also select the subtitle language using the on-
screen bar (see page 22).
While playing a DVD Video...
1
2
While playing a DVD-VR...
While playing an SVCD...
Selecting the View Angle
For DVD Video only:
While playing back a chapter
containing multi-view angles, you can view the same scene
from different angles.
• You can also select the multi-view angles using the on-
screen bar (see page 22).
While playing...
Selecting the Browsable Still Pictures
For DVD Audio only:
While playing back a track linked to
browsable still pictures (B.S.P.), you can select the still
picture (turn the page) to be shown on the TV screen.
•If a track is linked to browsable still pictures (B.S.P.), they
are usually shown automatically during playback.
• You can also select the page using the on-screen bar
(see page 22).
Playing Back Bonus Group
For DVD Audio only: Some DVD Audio discs have a
special group called “bonus group” whose contents are not
open to the public.
•To playback a bonus group, you have to enter the specific
“key number” (a kind of password) for the bonus group.
The way of getting the key number depends on the disc.
1
Select the bonus group.
• The bonus group is usually recorded as the last group
(for example, if a disc contains 4 groups including a
bonus group, “group 4” is the bonus group).
•For how to select the group, see “To select a title/group”
on page 9.
Continued on the next page
Remote
ONLY
C. VOICE
SUBTITLE
ENGLISH
1/3
ENGLISH
1/3
1/3 3/3
2/3
FRENCH JAPANESEENGLISH
1/3 2/3
JAPANESE
3/3
ENGLISH FRENCH JAPANESE
TV CH
TV CH
Ex.:
ON OFF
ON OFF
C. VOICE
SUBTITLE
C. VOICE
SUBTITLE
Each time you press
the button (while
holding SHIFT), the
still picture changes
one after another
(if available).
Remote
ONLY
1
1/3
2
2/3
3
3/3
1
1/3
2
2/3
3
3/3
0
ANGLE
Ex.:
(while holding...)
Remote
ONLY
PAG E
FM/PLAY MODE
(while holding...)
Remote
ONLY
UX-G70[J].book Page 17 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals

18
2
Enter the key number.
3
Follow the interactive instructions shown on the
screen.
To cancel the key number entry,
press 7 .
Making Dialogues Clear—Clear Voice
When you playback a disc, you can use this function—Clear
Voice. You can make the singer’s voices or dialogues of the
movie clear.
• This function only works when 3D Phonic is activated.
Special Effect Playback
Pause playback
Frame-by-frame playback
1 While playing...
2 Advance the still picture frame by frame.
To resume normal playback,
press DVD/CD 3 .
Slow-motion playback
1 While playing...
2
Select slow motion speed.
*Only available for DVD Video.
To resume normal playback,
press DVD/CD 3 .
To replay the previous scenes
(One-Touch Replay)
• This function is only used while playing DVD Video/
DVD-VR.
While playing back..
Zoom
• For JPEG, see page 27.
1
While playing back...
• As the number increases, magnification also increases.
2
Move the zoomed-in position.
To cancel Zoom,
press ZOOM (while holding SHIFT)
repeatedly until “ZOOM OFF” appears on the TV.
To pause: To resume normal
playback:
While playing...
Still picture playback starts.
ENTER/SET
0
1
4
7
2
5
8
3
6
9
DISC 1
A.STANDBY
SLEEP VFP SCAN MODE
ANGLE
DISC 2 DISC 3
DISC 4 DISC 5
Remote
ONLY
C. VOICE
SUBTITLE
(while holding...)
(On)
Off
Remote
ONLY
INFO
DVD/CD
Still picture playback starts.
The playback position moves
back about 10 seconds before the
current position (only within the
same title).
SLOW
+
–
1/32 1/16 1/8 1/4 1/2
1/32 1/16 1/8 1/4 1/2
Reverse slow motion*starts.
Forward slow motion starts.
GROUP/TITLE
ZOOM 1 ZOOM 2 ZOOM 3 ZOOM 4
ZOOM 5ZOOM 6 ZOOM OFF
ZOOM
10
(while holding...)
TV CH
TV CH
UX-G70[J].book Page 18 Monday, April 3, 2006 4:46 PM
Downloaded From Disc-Player.com JVC Manuals
