MC-8200LU/MC-8600LU CD/DVD LIBRARY
INSTRUCTIONS
CD/DVD LIBRARY
BEDIENUGSANLEITUNG : CD/DVD BIBLIOTHEK
MANUEL D’INSTRUCTIONS : BIBLIOTHEQUE CD/DVD
Printed in Japan
LST0168-001B
© 2004 Victor Company of Japan, Limited
is a registered Trademark owned by Victor Company of Japan, Limited.
is a registered Trademark in Japan, the U.S.A., the U.K. and many other countries.
ENGLISHDEUTSCHFRANÇAIS
CD/DVD
This instruction book is made from 100% recycled paper.
For Customer Use:
Enter below the Model No. and Serial
No. which is located on the rear of the
cabinet. Retain this information for
future reference.
Serial No.
MC-8200LU / MC-8600LU
Model No.
MC-8600LU
MC-8200LU

I
1. Read all of these instructions.
2. Save these instructions for later use.
3. All warnings on the product and in the operating instructions should be adhered to.
4. Unplug this appliance system from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
5. Do not use attachments not recommended by the appliance manufacturer as they may cause hazards.
6. Do not use this appliance near water - f or example, near a bathtub, washbowl, kitchen sink, or laundry
tub, in a wet basement, or near a swimming pool, etc.
7. Do not place this appliance on an unstable cart, stand, or table. The appliance
may fall, causing serious injury to a child or adult, and serious damage to the
appliance.
Use only with a cart or stand recommended by the manufacturer, or sold with the
appliance.
Wall or shelf mounting should follow the manufacturer's instructions, and should
use a mounting kit approved by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
8. Slots and openings in the cabinet and the back or bottom are provided for
ventilation, and to insure reliable operation of the appliance and to protect it from overheating, these
openings must not be blocked or covered.The openings should never be blocked by placing the appliance
on a bed, sofa, rug, or other similar surface. This appliance should never be placed near or over a
radiator or heat register.This appliance should not be placed in a built-in installation such as a bookcase
unless proper ventilation is provided.
9. This appliance should be operated only from the type of power source indicated on the marking label.
If you are not sure of the type of power supplied to your home, consult your dealer or local power
company. For appliance designed to operate from battery power, refer to the operating instructions.
10. This appliance system is equipped with a 3-wire grounding type plug (a plug having a third (grounding)
pin). This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable
to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the grounding plug.
11. For added protection for this product during a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system.This
will prevent damage to the product due to lightning and power-line surges.
12. Do not allow anything to rest on the power cord. Do not locate this appliance where the cord will be
abused by persons walking on it.
13. Follow all warnings and instructions marked on the appliance.
14. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
15. Never push objects of any kind into this appliance through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind
on the appliance.
16. Do not attempt to service this appliance yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
17. Unplug this appliance from the wall outlet and refer servicing to qualified service personnel under the
following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the appliance.
c. If the appliance has been exposed to rain or water.
d. If the appliance does not operate normally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions as improper adjustment of other controls
may result in damage and will often require extensive work by a qualified technician to restore the
appliance to normal operation.
e. If the appliance has been dropped or the cabinet has been damaged.
f. When the appliance exhibits a distinct change in performance – this indicates a need for service.
18. When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer that have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
19. Upon completion of any service or repairs to this appliance, ask the service technician to perform
routine safety checks to determine that the appliance is in safe operating condition.
S3125A
These are general IMPORTANT SAFEGUARDS and certain items may not apply to all appliances.
IMPORTANT SAFEGUARDS 82 04.10.29, 2:51 PM1

E2
IMPORTANT
The wires in this mains lead are coloured in accordance with
the following code:
GREEN - and - YELLOW: EARTH
BLUE: NEUTRAL
BROWN: LIVE
As the colours of the wires in the mains lead of this apparatus
may not correspond with the coloured markings identifying
the terminals in your plug. proceed as follows.The wire which
is coloured GREEN-AND-YELLOW must be connected to the
terminal in the plug which is marked with the letter E or the
safety earth symbol or coloured GREEN or GREEN-AND
YELLOW. The wire which is coloured BLUE must be con-
nected to the terminal which is marked with the letter N or
which is coloured BLACK.The wire which is coloured BROWN
must be connected to the terminal which is marked with the
letter L or coloured RED.
For Europe
IMPORTANT FOR LASER PRODUCT
1. CLASS 1 LASER PRODUCT
2. DANGER :Invisible laser radiation when open and interlock
failed or defeated. Avoid direct exposure to beam.
3. CAUTION :Do not open the top cover.There are no user serv-
iceable parts inside the unit: leave all servicing to qualified
service personnel.
CAUTION
Use of controls or adjustments or performance of proce-
dures other than those specified herein may result in
hazardous radiation exposure.
Note
Place a cover on the terminal when not in use.
Static may cause a malfunction or failure of the unit.
WARNING–THIS APPARATUS
MUST BE EARTHED
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
REPRODUCTION OF LABELS
CLASSIFICATION LABEL, PLACED ON
REAR ENCLOSURE.
CLASS 1
LASER PRODUCT
For North America
Information for USA
NOTE:This equipment has been tested and found to comply
with the limits for a Class A digital device,pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable pro-
tection against harmful interference when the equip-
ment is operated in a commercial environment.
This equipment generates,uses,and can radiate radio
frequency energy and,if not installed and used in ac-
cordance with the instruction manual,may cause harmful
interference to radio communications.Operation of this
equipment in a residential area is likely to cause harm-
ful interference in which case the user will be required
to correct the interference at his own expense.
Modifications not expressly approved by the manu-
facturer could void the user's authority to operated
the equipment under FCC rules.
Information for Canada
This Class [A] digital apparatus complies with Canadian
ICES-003.
Informations pour le Canada
Cet appareil numérique de la classe [A] est conforme á la
norme NMB-003 du Canada.
Warning
This is a Class A product. In a domestic en-
vironment this product may cause radio in-
terference in which case the user may be
required to take adequate measures.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM2

E3
ENGLISH
Thank you for purchasing the JVC MC-8200LU/8600LU CD/DVD Library
•Capacity
Up to 600*1 optical discs*1 (12 cm discs) can be accom-
modated.
•Double-sided disc compatibility
Double-sided discs may also be accommodated, by
adding an optional carrier*4.
*1 MC-8600U (200 discs with the MC-8200U).
*2 Media compatible with the library varies depending on the installed drive types. For details, refer to the instruction
manuals of the relevant drives.
*3 For the compatible optional drives, see Specifications on page E34.
*4 MC-CF10U: Optional Carrier
*5 The data transfer rate is dependent on the installed drives. For details, refer to the instruction manual for the
optional drives.
Special Features
The MC-8200LU/8600LU CD/DVD Library is a highly reliable and durable disc changer equipped with large capacity and
high access speed to cope with the ever-changing needs of the rapidly developing information network age.This model is
suitable for business as well as home use.
CAUTION
The magazines and trays used with the MC-1000U/2000U series CD-ROM Library (MC-M15U) and MC-7000U series
DVD-RAM (MC-M25U) are not compatible with those used with the MC-8000U/LU series CD/DVD Library. Do not
interchange the magazines and trays between these models, as this will damage the equipment.
•Six drive bay slots
Six drive bay slots are provided so up to 6 drives*3 can
be installed.
•High-speed interface
The LVD SCSI interface is adopted to enable a maxi-
mum external cable length of 10 meters as well as to
increase the data transfer rate*5.
The following table shows the items provided in the package. Always check thoroughly that all the items are present when
unpacking.
CAUTION
This equipment is supplied with an internal mechanism lock and protective materials.The lock should be opened
and the protective materials removed before use.
Be sure to perform the unlocking and removal operations in accordance with the corresponding information in
this manual. (APage E11,E12,E13)
PACKAGED ITEMS
Item Qty MC-8200LU MC-8600LU
Main unit 1OO
Door opening/closing keys 2OO
Main unit power cord (2.5 m) 2OO
Casters 4–O
Instructions (this manual) 1OO
Caster attaching procedure 1–O
CAUTION
If a media that is not compatible with any of the installed drives is used in the library, malfunctions will result. To
prevent this happening, be sure to check the instruction manuals of the optional drives in order to confirm that
the media to be accommodated is compatible with the drive.
CAUTION
When using 6 of the MC-R434U units together, be sure that the room temperature is between 5 °C and 30 °C.
CAUTION
This product does not include drives. Optional drives should be purchased and installed before using the prod-
uct. After installing, adding or replacing drives, be sure to execute the automatic drive detection mode as de-
scribed on page E24. Malfunctions may occur if this procedure is not performed.
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM3

E4
1. PRECAUTIONS ..................................................................................................................................................... 5
Installation and handling precautions ................................................................................................................. 5
Disc handling precautions .................................................................................................................................. 5
2. NAMES AND FUNCTIONS OF PARTS................................................................................................................. 6
2-1.Front panel, right side panel, rear panel........................................................................................................... 6
2-2. Interior ............................................................................................................................................................. 7
2-3. Magazine numbers, tray numbers, disc numbers ............................................................................................ 8
2-4. Internal SCSI cable ......................................................................................................................................... 9
3. SETUP ................................................................................................................................................................... 10
3-1. Attaching the casters ..................................................................................................................................... 10
3-2. Opening the transport lock ............................................................................................................................ 11
3-3. Removing the transport protective materials ................................................................................................. 12
3-4. Removing the optional carrier transport lock screw ...................................................................................... 13
3-5. Installing drives and settings SCSI-ID No., etc. ............................................................................................. 13
3-6. Connecting the power cord and cables ......................................................................................................... 14
4. CONTROL PANEL OPERATIONS AND LCD DISPLAY ....................................................................................... 15
4-1. Normal display ............................................................................................................................................... 15
4-2. Menu display ................................................................................................................................................. 15
4-3. Event display ................................................................................................................................................. 16
4-4. Display and operation sequence ................................................................................................................... 17
5. DOOR OPENING/CLOSING ................................................................................................................................. 18
6. MAIL SLOT ............................................................................................................................................................ 19
6-1. Disc loading ................................................................................................................................................... 19
6-2. Import/export operation ................................................................................................................................. 20
7. DRIVE UNITS ........................................................................................................................................................ 22
7-1. Removing the panel....................................................................................................................................... 22
7-2. Installing the drive units ................................................................................................................................. 22
7-3. Setting the SCSI-ID Numbers, etc. ................................................................................................................ 23
7-4. Connecting the cables ................................................................................................................................... 23
7-5. Installing the panels ...................................................................................................................................... 24
7-6. Automatic drive detection mode .................................................................................................................... 24
7-7. Drive type display .......................................................................................................................................... 25
8. SETTING THE SCSI-ID NUMBERS OF THE MAIN UNIT ..................................................................................... 26
8-1. Display for checking the SCSI ID numbers ................................................................................................... 26
9. MAGAZINES .......................................................................................................................................................... 27
9-1. Ejecting/loading the magazines ..................................................................................................................... 27
9-2. Loading/replacing the discs ........................................................................................................................... 28
9-3. Automatic disc checking function .................................................................................................................. 29
10 ERROR CODES ................................................................................................................................................... 30
10-1. Error code explanation ................................................................................................................................ 30
10-2. Error code list .............................................................................................................................................. 31
10-3. How to cancel the Errors “20”, “21” and “64” ............................................................................................... 31
10-4. Error history display .................................................................................................................................... 32
10-5. Troubleshooting ........................................................................................................................................... 32
11. ACCESS COUNTS .............................................................................................................................................. 33
SPECIFICATIONS ..................................................................................................................................................... 34
CONTENTS
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM4

E5
ENGLISH
1. PRECAUTIONS
 Installation and handling precautions
(1) Opening the transport lock
•Make sure that the transport lock is released and all trans-
port protective materials are removed before turning on the
power. Failure to do so will result in equipment malfunction.
(2) Location of installation
•Do not install the equipment near a source of vibration such
as motor, engine or loudspeaker. They may adversely af-
fect the equipment performance.
•Do not install the equipment in a place that is exposed to
radiation, X-rays or corrosive gases.This may cause a mal-
function or failure of the equipment.
•If the equipment is to have a fixed installation, we advise
you to give sufficient allowance for space so that extension
and replacement of optional units and other operations such
as replacement and maintenance can be easily performed.
For details, please consult your dealer or nearest JVC-au-
thorized service agent.
•This equipment must be installed on a level surface that is
subject to minimal vibration
(3) Condensation
•If the equipment which has been left in a cold room for a
long period of time and is moved to a warm room or if the
temperature of the room suddenly increases, condensation
may occur on a mobile part, optical pickup or a disc inside
the equipment with a disabling effect. If this occurs, do not
use the equipment for a few hours before starting it again.
(4) Interference with reception of other devices
•When this equipment is used near a radio receiver such as
a radio, television or BS tuner, reception of radio waves on
these these devices may experience interference.
(5) Use in a strong radio wave environment
The equipment may not function properly if it is used in a
strong radio wave environment, for example near an illegal
radio station or a broadcasting station. If this happens, please
consult your dealer or nearest JVC-authorized service agent.
(6) Compatible media
Media compatible with the MC-8200U/8600U varies depend-
ing on the drive in which it is accommodated. For details,
refer to the instruction manual of the relevant drive.
 Disc handling precautions
A disc is made of plastic material which can be easily dam-
aged. If the discs are damaged or become dirty, it may lead to
malfunction such as incorrect data readout.To prevent this han-
dle the discs with care so that they will stay free of damage,
stain, dust/dirt adhesion, warping, etc.
(1) Do not touch the reflective surface (data surface) of a
disc directly with your hand. Be sure to use special
care when handling double-sided discs.
(2) Use commercially available cleaning kits such as a CD
cleaner to remove dust and/or dirt from the disc sur-
face.
•Gently wipe-clean the disc surface without scratching it.
(Make sure to wipe from the centre of the disc towards the
outer edge. Never use a circular motion.)
(3) Do not use chemicals for disc cleaning.
•Never use any solvents other than those included in the
cleaning kits.
•Never use analogue record cleaning fluid, benzene, alcohol
or anti-static agent.
(4) Do not damage the label surface
•Damage to the label surface also affects the data surface
immediately underneath it.
•Do not attach pieces of paper or adhesive tape to either
side of the disc.
•When you need to write on the label surface, please use a
permanent ink felt-tip pen.
Writing implements with hard tips such as ball-point pens
and pencils should not be used as they will damage the
surface.
(5) Periodical cleaning of the discs is recommended.
•Periodical disc cleaning may be required depending on the
equipment installation environment and disc handling
method.
(7) Installation environment
•This equipment has been designed with consideration for
dust protection, but its structure is not dust-proof. There-
fore, if it is used in an environment where cigarette smoke
and/or dust are present, the lens of the drive or a disc will
become dirty and stop functioning correctly. Using the equip-
ment in these conditions should be avoided. If, however, you
have to use it in a dusty environment, make sure to carry
out ‘maintenance & regular inspection’ at an earlier interval.
•If the equipment is used outside of the suitable temperature
and humidity range, the drive life may become greatly short-
ened. Please make sure to use the equipment in an appro-
priate environment.
(8) Backup
•JVC cannot accept responsibility for any loss of data and/or
any other direct and indirect damage caused by the use or
malfunctioning of this equipment. We therefore strongly ad-
vise that all important data should be fully backed up in case
of unexpected loss.
•When this equipment is used with a system which runs con-
tinually for 24 hours or which cannot be turned off at all, we
recommend a redundancy design such as [a] back-up sys-
tem on the system.
(9) Never take the equipment apart.
•Fire and electric shock may result. Do not try to take apart
or modify this equipment or the drive units inside.
(10) Cleaning
•Do not use solvents (paint thinner, benzene, etc.), cleaning
products containing abrasives, anti-static agent, cloth soaked
in detergent and silicon cloth. They can cause discolora-
tion.
•Wipe-clean using a well-squeezed cloth which has been
soaked in a neutral detergent.
(11) Do not place anything on the top panel.
•Do not place any objects on or step onto the top panel of
this equipment as a malfunction or accident may result.
* Always from the centre to outer edge
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM5

E6
2. NAMES AND FUNCTIONS OF PARTS
1POWER switch ................... Turns the main unit power on/off. " | ":ON. "  ":OFF.
2POWER Indicator ............... Lights up when the POWER switch is turned on. Blinks in case of error during operation.
3LCD Display Panel ............. Shows information using alphanumeric characters.
4MODE key .......................... Used for LCD display page selection and other operations.
5SELECT key ....................... Used for switching displayed information and other operations.
6LOAD/EJECT key ............... Opens or closes the mail slot.
7ENTER key ......................... Used for LCD page selection and other operations.
810-key ................................. Used for selecting tray Nos. and changer SCSI ID Nos. for import/export operations.
9Mail slot .............................. Used for disc insertion/ejection
0Key cylinder ....................... After completing the door opening mode, insert a key and turn it counterclockwise to open
the door.
!Rear panel .......................... Opened and closed when installing or replacing drive units.
@SCSI connector ................. One SCSI connector port system is provided as standard.
#RS-232C connector ........... 9-pin D-sub connector (plug) for use in maintenance.
$AC inlet (main unit) ........... Insert the provided power cord and plug the other end of the power cord to a 120 V-240 V, 50
Hz/60 Hz AC power outlet.
%Side panel .......................... To be removed in servicing.
2-1. Front panel, right side panel, rear panel
MC-8200LU (MC-8600LU)
Front panel Right side panel Rear panel
9
0
1
POWER MODE SELECT LOAD/EJECT
MAIL SLOT
1 2 3 4 5 6 7 8 9 0 E
348 7
62
5
Control panel : the control panel consist of the keys 2- 8
and the LCD display screen.
%
!
$
#
@
SCSI-C
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM6

E7
ENGLISH
2-2. Interior
Names and Functions of Parts
9Mail slot .............................. Used for disc insertion/ejection.
&Mail slot transport lock ..... Locks the mail slot during transport.
*Magazines .......................... Each magazine contains 50 trays accommodating up to 50 discs.
(Drive bays .......................... Accommodation for up to 6 drive units is compatible with this product. The bays are num-
bered 1, 2, 3,4 5 and 6 from the bottom.
)Carrier ................................ Tr ansports the trays (discs) between the magazines and the mail slot, drives or printer.
⁄Carrier transport lock ....... Locks the carrier during transport.
¤
Optional carrier transport lock .... To be locked before transport when the MC-CF10U Optional Carrier is installed.
‹
Transport lock screw storage hole ... Attach the transport lock screw provided with the MC-CF10U Optional Carrier to this hole.
(for optional carrier)
›Center panel ...................... To be removed only for maintenance, etc. Do not normally remove this panel, as it provides
hazard protection to the parts inside.
●The system for transporting the trays (discs) between the magazines and the mail slot or drives or printer using
the carrier is generically referred to as the "changer".
Right side panel (when the door is removed.)
*
*
9
⁄
&
*
(
)
›
‹
¤
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM7

E8
Names and Functions of Parts
2-3. Magazine numbers, tray numbers, disc numbers
The internal layout of the magazine and the numbers assigned to the magazines, trays and discs are as shown below.
Magazine number ...... This is the number assigned to each of the 4 or 12 sets of magazines. The error message dis-
played when a magazine is inserted incompletely refers to the magazine number. (See page E27)
Note, magazine number assignments are different from previous models (MC-1000, MC-2000 and
MC-7000 Series).
Tray number............... This is the 2-digit number assigned to each of the 50 trays in each magazine.The combination of a
tray number and magazine number corresponds to a disc number. For example, disc number 120
can also be represented as the disc in tray number 20 of magazine number 3. In this way, the disc
can be located in the 20th slot from the bottom of magazine 3.
Disc number .............. This is the 3-digit number assigned serially to every disc in all magazines and trays, starting from
disc number 1 in tray 01 of magazine 1 up to disc number 200 or 600. The error messages usually
refer to the disc numbers. (See page E30)
MC-8200LU
MC-8600LU
200
151
050
001
100
051
150
101
Disc No.
3
50
41
40
31
30
21
20
11
10
01
Magazine No. : 3
Tray No. : 20
Disc No. : 120
Tray No.
7
6
5
4
3
8
9
10
11
12
2
1
3 4
2
1
Magazine No.
350
301
400
351
450
401
500
451
550
501
600
551
300
251
250
201
200
151
150
101
100
051
050
001
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM8

E9
ENGLISH
2-4. Internal SCSI cable
The SCSI connections inside the main unit (the Changer) are explained below:
The SCSI board, drive units and an SE (single-ended)/LVC (Low Voltage Differential) conversion board are daisy-chain
connected by an internal SCSI cable. The length of the internal SCSI cable should be about 1.0 meter.
●Connectors that are not used should be capped in order to prevent short-circuiting.
●The physical extremity of the internal SCSI cable of the changer is terminated.
Names and Functions of Parts
Interior
Drive 4
Drive 3
Drive 2
Drive 1
Library SCSI board
Drive 6
Drive 5
Terminator
Internal SCSI (LVD) cable
68-pin external SCSI connector
To host computer (SE/LVD)
SE-LVD conversion board
Terminator
Internal SCSI (SE) cable
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM9

E10
3. SETUP
The standard setup procedure is as shown below. Set up the equipment according to the procedure shown for each model.
3-1. Attaching the casters
The MC-8600LU comes standard with designated casters.
Three or more persons should attach these casters by following the procedure below.
Please also refer to the caster attaching procedure manual which is provided with the equipment.
1. After unpacking the equipment, take out the 4 casters
from inside the bottom cushioning material.
2. Hold each caster with the wheel side down, and insert it
into a caster socket on the bottom panel while sliding
the lock pin as shown below.
3. The caster is attached completely when the lock pin
reaches and engages with the hole on the caster socket.
•Make sure that the pin does not come out even when
the caster is pulled strongly.
Caster sockets
Lock pin
Bar
Wheel lock lever
*Be sure to lock the wheel
during the attaching operation.
Wheel
Start
MC-8200LU MC-8600LU
Open the transport lock
Removing the transport protective materials
Turn the power switch on.
Completion Proceed to the host computer setup
Attach the casters
Install the drive units
Load discs in the magazines
*1
*1
A large number of discs can be loaded quickly(bulk load).
*2
Please have your dealer or nearest JVC service center perform this task.
P.E10
P.E11
P.E22
Mount the optional carrier *2
P.E12
Connect the power cord and cables P.E14
Set the SCSI-ID numbers, etc. P.E23
Execute the automatic drive detection mode. P.E24
P.E19, E27
WARNING
Insert the casters until they are locked com-
pletely. Should an incompletely attached
caster comes out, the equipment may fall over
and could cause an injury and damage to the
equipment.
CAUTION:
The casters provided together with
the MC-8600LU are exclusively for
preventing the equipment from fall-
ing over and for changing its instal-
lation place and not for transpor-
tation.
Transporting the MC-8600LU on
these casters on an uneven sur-
face over a long distance may
cause them to be damaged.
MC-8200LU_8600LU INST(E) 04.10.29, 2:07 PM10

E11
ENGLISH
3-2. Opening the transport lock
Setup
1. Open the door by inserting the key and turning it
counterclockwise (90°) to unlock the door.
2. Open the transport lock of the mail slot.
•Using a philps screwdriver, continue to turn the lock
counterclockwise until the lock is completely disen-
gaged and moves outwards.
3. Open the transport lock of the carrier.
•Continue to turn the screw counterclockwise to loosen
it until the metal device retaining it is disengaged and
moves outwards.
Proceed to the operation in the next page without clos-
ing the door.
Lock pin
Door opening/closing
key cylinder
Unlocked
Locked
Note:
When using the MC-CF10U Optional Carrier, read "3-4.
Removing the optional carrier transport lock screw"
on page E13 before continuing on.
•In the case of re-transporting, lock the transport lock as follows:
1) Remove all the discs and turn off the power.
2) Turn on the power while pressing the “1” of the 10-key pad and enter the PACKING mode.
3) Turn off the power as soon as the “END” display appears on the LCD screen.
4) Fix the transport lock as described in 2 and 3 above.
5) When using the MC-CF10U Optional Carrier, read "3-4. Removing the optional carrier transport lock screw" on
page E13 before continuing on.
6) Re-attach the protective transport materials. (aSee page E12.)
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM11

E12
Setup
3-3. Removing the transport protective materials
After opening the transport lock, proceed to the following steps without closing the door.
1. Remove magazine No. 1.
(aSee “9-1. Ejecting/loading the magazines” on page E27.)
2. Pull out the protective material forwards.
3. Load magazine No. 1.
(aSee “9-1. Ejecting/loading the magazines” on page E27.)
4. Repeat the same operation for each of the remaining magazines.
TOP
TOP
Protective material
3 4
2
•In the case of re-transporting, it is necessary to remove all the discs and re-attach the protective transport materials
using the reverse procedure to the above. When this operation is required, please consult your dealer or nearest JVC-
authorized service agent.
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM12

E13
ENGLISH
3-4. Removing the optional carrier transport lock screw
Setup
When the MC-CF10U is installed, its special transport lock should be removed in addition to its being unlocked as
detailed in "3-2. Opening the transport lock" on page E11. Use the following procedure when unlocking the optional
carrier transport lock.
1. Remove the transport lock
screw (for optional carrier).
2. Insert the removed screw into the desigated storage hole for
the transport lock screw.
•If the system is transported with the MC-CF10U Optional Carrier installed, refer to "3-2. Opening the transport lock",
execute the packing mode and clamp the above-mentioned transport lock screw.
3-5. Installing drives and settings SCSI-ID No., etc.
1. Installing drives
Install the drives (aSee "7. DRIVE UNITS" on page E22).
2. Initial setting of SCSI-ID No., etc.
The default setting of the SCSI-ID No. of the MC-8200LU/8600LU is "0".
Set the SCSI-ID No. according to your system.
•To change the SCSI-ID No. of the MC-8200LU/8600LU aRead "8. SETTING THE SCSI-ID NUMBERS OF THE MAIN
UNIT" on page E26.
• To set the SCSI-ID Nos. and termination of drives aRead the instruction manuals of the installed drives.
•As the MC-8200LU/8600LU should be turned on to allow its SCSI-ID No. to be set, read "3-6. Connecting the power
cord and cables" on page E14 and connect the power cord before proceeding.
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM13

E14
3-6. Connecting the power cord and cables
Setup
CAUTION
Turn OFF the power of all equipment before starting connections.
Connecting the equipment while power is ON may lead to a malfunction.
sThe length of the internal SCSI cable is about 1.0 meter.
sCheck the total length of the internal and external SCSI cables. A malfunction may occur if the lengths described below
are exceeded.
1) For use with an LVD: The maximum length of the external cable is 10 meters.
2) For use with an SE (Narrow): The maximum length of the external cable is as follows.
•SCSI-2, 20 Mbytes/s sync: 1.5 meter (Max. 2 drives)
•SCSI-2, 10 Mbytes/s sync: 1.5 meter
•SCSI-2, 5 Mbytes/s async: 4.5 meter
sUse an Ultra 160-compatible cable as the external cable. A malfunction may occur if any other cable is used.
sThe host bus adapter in the controller computer should be LVD compatible.
To AC IN
To SCSI-C
To the host adapter
of computer
To AC outlet
Always use the power cord provided by JVC. The library system has been designed to conform to
“Insulation category Class 1”. In order to assure safety at all times, be sure to ground the system
before use. If other types of power cords other than the specified cord are used, they may overheat and
burn or cause a fire.
WARNING
sRecommended SCSI host adapters and SCSI cables
• WINDOWS server
SCSI host adapter: ASC-29160 by ADAPTEC Co., Ltd.
SCSI cable: ACK-LVD-3M-U320 (3 m) by ADAPTEC Co., Ltd.
• SUN work station
SCSI host adapter: PCI SCSI-2U3WL by Antares Microsystems Co., Ltd.
SCSI cable: ACK-68V-68HD-LVD (2 m) by ADAPTEC Co., Ltd.
Please consult your local JVC service center if a cable of a length other than the above mentioned or one that has been
supplied by another manufacturer has been fitted.
Operation with a recommended host adapter is not guaranteed for a host computer in all cases. An adequate pre-
operation examination is essential before starting an operation.
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM14

E15
ENGLISH
[Pattern 1]
[Pattern 2]
Carrier
Drive 1
Idle Mail slot
CR : – – – MS : – – –
D1 : 0 3 6 D2 : 0 7 5
Drive 2
Disc No.
D5 : NC
D3 : NC D4 : NC
D6 : NC
Unconnected
SELECT SELECT
075
Drive 3 Drive 4Drive 5 Drive 6
4. CONTROL PANEL OPERATIONS AND LCD DISPLAY
The switch operation and LCD display system has three operation and display modes as described below.
Normal display ..... This mode includes two patterns, one of which is displayed automatically when the equipment starts
up normally. The disc numbers in the drive units are displayed in real time.
Menu display ........ This mode allows you to start user operations such as SCSI-ID No. checking and setting, internal
history display and door/panel opening.
Event display ........ This mode overrides other modes in case of an event such as initialization after startup, mail slot
operations, setting up the door/panel opening mode or appearance of errors.
Pattern 1 is displayed automatically when the startup has succeeded normally. The display pattern will change every time the
SELECT switch is pressed.
4-2. Menu display
4-1. Normal display
1NORMAL DISPLAY
(aSee "4-1. Normal display" on this page.)
2ERROR DISPLAY
(aSee "10-4. Error history display" on page E32.)
3ID No. DISPLAY
(aSee "8-1. Display for checking the SCSI ID numbers" on page
E26.)
4PANEL OPEN
5DOOR OPEN MODE
(aSee "5. Door Opening/Closing" on page E18.)
6ID No. SET MODE
(aSee "8. Setting the SCSI-ID numbers of the main unit" on page
E26.)
7COUNT DISPLAY
(aSee "11. Access counts" on page E33.)
8IMPORT/EXPORT
(aSee "6-2. Import/export operation" on page E20.)
9DRIVE DISPLAY
(aSee "7-7. Drive type display" on page E25.)
SELECT
SELECT
1.NORMA L D I SPLAY
2.ERROR DISPLAY
2.ERROR DISPLAY
3. ID No.DISPLAY
9.DRIVE DISPLAY
1.NORMAL DISPLAY
Cursor: Currently selected menu
Pressing the MODE key switch during normal display starts the menu display.
Select a menu by pressing the SELECT key and enter the selection by pressing the MODE key again.
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM15

E16
4-3. Event display
1Power on
POWER ON
2During initialization
INITIALIZING
3Error occurrence (aSee “10-2. Error code list” on page E31.)
Displayed
alternately.
DISC=124
CODE =CU 04
ERROR OCCURRED !
4During door opening (aSee “5. Door Opening/Closing” on page E18.)
EXECUT I NG DOOR
OPEN PROCESS
THE DOOR
CAN BE OPENED
5When door is open (aSee “5. Door Opening/Closing” on page E18.)
Door closing
DOOR OR PANEL
IS OPEN
PUSH ENTER KEY
TO RESUME
6During mail slot operation (aSee “6. Mail Slot” on page E19.)
EXPORT DONE
PUSH LOAD KEY
INITIALIZING
FL IP CARR I ER
When the MC-CF10U Optional Carrier is installed
Control Panel Operations and LCD Display
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM16

E17
ENGLISH
Control Panel Operations and LCD Display
4-4. Display and operation sequence
The sequence of display and operation after turning the power on is as shown below.
POWER ON
1. NORMAL DISPLAY
2. ERROR DISPLAY
Power On
INITIALIZING
Pattern 1
Normal display
Pattern 2
SELECT SELECT
MODE
SELECT
ENTER
Error display 1
3. ID No. DISPLAY
SELECT
SELECT
SELECT
SELECT
ENTER
4. PANEL OPEN MODE
ENTER
SCSI-ID display
Error display 2
Error display 8
SELECT
SELECT SELECT
DR1 :
DR2 :
DR6 :
SELECT
SELECT SELECT
SELECT
SELECT
5. DOOR OPEN MODE
SELECT
ENTER
PUSH SELECT
PUSH SELECT
EXECUTING ...
... CAN BE OPENED
SELECT
SELECT
6. ID No. SET MODE
7. COUNT DISPLAY
8. IMPORT/EXPORT
ENTER
ENTER
ENTER
ENTER
SELECT
9. DRIVE DISPLAY
PUSH SELECT
PUSH SELECT
ID No. display
ID No. entry
SELECT
SELECT
SELECT
ENTER
Input ID No.
SELECT
SELECT
SELECT
9. DR6
SELECT
10. FL
SELECT
SELECT
2. CR
1. TOTAL
PUSH SEL. KEY
PUSH SEL. KEY
Input the start
tray No.
Input the end
tray No.
Start accessing
ENTER
ENTER
*1
•If the MODE, SELECT or ENTER key has not been pressed within 10
seconds, the current display will return to “Normal display - Pattern 1”
(except in a situation when an event is displayed or the Import/Export Tray
numbers and SCSI-ID numbers are being input).
*1. When the MC-CF10U Optional
Carrier is installed.
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM17

E18
5. DOOR OPENING/CLOSING
Once the transport locks have been released and the power has been turned on for the first time, the door is locked by an
internal safety lock in addition to the key so that the door cannot be opened with the key alone.
In order to open the door with the key under these conditions, either maintain or turn on the power supply if it has not been
turned on yet, and perform the following operations before inserting and turning the key.
1. In the normal display mode, press the MODE Key.
(The menu display appears.)
•You cannot perform disc transport operations when the above the door open mode is being executed or the door is open.
Door Opening
Door Closing
1. Close the door and turn the door opening/closing key
clockwise to lock.
2. Press the ENTER key switch when the display shown
on the right appears.
*The screen will return to the Normal display after initialization.
The door opening/closing
key cylinder (lock)
PUSH ENTER KEY
TO RESUME
DOOR OR PANE L
IS OPEN
The door is open.
The door is closed.
1.NORMA L D I SP L AY
2.ERROR DISPLAY
5.DOOR OPEN MODE
6. ID No.SET MODE
PUSH SELECT KEY
TO OPEN THE DOOR
PUSH SELECT KEY
TO OPEN THE DOOR
EXECUT I NG DOOR
OPEN PROCESS
THE DOOR
CAN BE OPENED
2. Press the SELECT key 4 times.
("5. DOOR OPEN MODE" appears.)
3. Press the ENTER key.
(Select and enter "5. DOOR OPEN MODE".)
4. Press and hold the SELECT key for more than 5 sec-
onds.
(Wait until the display starts to blink.)
5. Release the SELECT key when the execution display
[EXECUTING DOOR OPEN PROCESS] appears.
*When inserting/ejecting a drive unit, turn off the power after
the completion display [THE DOOR CAN BE OPENED] ap-
pears.
6. Insert the door opening/closing key in the cylinder and
turn it counterclockwise to release the lock and open
the door.
Unlocked
Locked
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM18

E19
ENGLISH
6. MAIL SLOT
CAUTION
Do not load or eject a disc before the mail slot has stopped completely.
It may not only damage the disc but also cause the equipment to malfunction because of excessive force being applied
during opening and closing.
EXPORT DONE
PUSH LOAD KEY
POWER MODE SELECT LOAD/EJECT
MAIL SLOT
6-1. Disc loading
Disc loading/ejection method
When a tray is transported to the mail slot under the con-
trol of the host computer or the import/export operation
(aP. E20), the mail slot opens automatically when trans-
portation has been completed.
1. Place a disc gently on the tray with a label surface fac-
ing upwards.
(To remove a disc from the tray, hold the disc by the
center hole and the outer edge which is accessible near
the notched section on the front side of the tray.)
CAUTION
•Never use a damaged and/or warped disc or a disc with an attached label. It will lead to a malfunction of the equipment.
•If you are going to use a disc from a different drive, please check the drive specifications carefully before using it.
(Some drives may not be able to read the disc.)
(At the same time, the equipment may not be able to read the disc which has been written and deleted in a different drive.)
•Note that some double-sided discs do not provide a distinction between the top and bottom sides. Take special care
when removing/loading these discs from/in the MC-8200LU/8600LU.
•In order to prevent a malfunction or failure, do not place two or more discs on a single tray.
CAUTION
•ADVD-RAM disc may become impossible to write/read
due to dust, fingerprints, scratches, etc. adhering to
the disc surface. Please handle it carefully.
Take special care in handling the DVD-RAM/R discs
because they are extremely vulnerable to scratches
and contamination.
2. Press the LOAD/EJECT key.
(The mail slot closes.)
•Now you can repeat the open/close operations alternately
by pressing the LOAD/EJECT key provided that the mail
slot transportation operation has not started yet.
• While the carrier is in operation, pressing the LOAD/
EJECT key will not start the open/close operations.
Label surface
(With a single-sided disc)
CAUTION
Media compatible with the MC-8200LU/8600LU varies
depending on the installed drive types. For details, refer
to the instruction manuals of the drives.
When using double-sided discs, handle them with spe-
cial care because they do not have a label on the surface.
CAUTION
MC-8200LU_8600LU INST(E) 04.10.29, 2:08 PM19
