SERVICE MANUAL
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED No.52114B
2003/8
COLOR TELEVISION
52114B20038AV-27FA44/BSA
AV-32FA44/BYA
AV-32FA44/BZA
Supplementary
OUTLINE
HOW TO IDENTIFY MODELS
The following items for the AV-27FA44/BSA, AV-32FA44/BYA, AV-32FA44/BZA model were changed partly
from AV-27FA44/ASA, AV-32FA44/AYA, AV-32FA44/AZA model.
Therefore, this service manual describes only the items which differ from those of the AV-27FA44/ASA, AV-
32FA44/AYA, AV-32FA44/AZA model service manual.
For details other than those described in this manual, please refer to the AV-27FA44/ASA, AV-32FA44/AYA,
AV-32FA44/AZA model service manual (No.52114, 2003/7).
Since some parts are changed for the reason of cost, we have issued the SERVICE MANUAL for AV-27FA44/
BSA, AV-32FA44/BYA, AV-32FA44/BZA.
“BSA”, “BYA” and “BZA” are added to the serial No. after at the Rating label.
MODEL
SERIAL No.
AV-27FA44
AV-32FA44
BSA
BYA
BZA
Indicated
BASIC CHASSIS
GJ3

1-2 (No.52114B)
DIFFERENCE LIST
USING P.W. BOARD (Page 3-3)
P.W.B ASS'Y Name AV-27FA44/ASA AV-27FA44/BSA DESCRIPTION
MAIN P.W.B SGJ-1508A-M2 SGJ-1524A-M2 Non compatible
CRT SOCKET P.W.B SGJ-3502A-M2 SGJ-3507A-M2 Non compatible
AV SELECTOR P.W.B SGJ-5502A-M2 SGJ-5505A-M2 Non compatible
FRONT CONTROL P.W.B SGJ-6501A-M2 SGJ-6504A-M2 Non compatible
LED & POWER SW PB SGJ-7502A-M2 SGJ-7503A-M2 Non compatible
P.W.B ASS'Y Name AV-32FA44/AYA AV-32FA44/BYA DESCRIPTION
MAIN P.W.B SGJ-1506A-M2 SGJ-1528A-M2 Non compatible
DAF P.W.B SGJ-2503A-M2 SGJ-2505A-M2 Non compatible
CRT SOCKET P.W.B SGJ-3504A-M2 SGJ-3510A-M2 Non compatible
AV SELECTOR P.W.B SGJ-5502A-M2 SGJ-5505A-M2 Non compatible
FRONT CONTROL P.W.B SGJ-6502A-M2 SGJ-6504A-M2 Non compatible
LED & POWER SW PB SGJ-7502A-M2 SGJ-7503A-M2 Non compatible
P.W.B ASS'Y Name AV-32FA44/AZA AV-32FA44/BZA DESCRIPTION
MAIN P.W.B SGJ-1510A-M2 SGJ-1526A-M2 Non compatible
DAF P.W.B SGJ-2502A-M2 SGJ-2504A-M2 Non compatible
CRT SOCKET P.W.B SGJ-3503A-M2 SGJ-3508A-M2 Non compatible
AV SELECTOR P.W.B SGJ-5502A-M2 SGJ-5505A-M2 Non compatible
FRONT CONTROL P.W.B SGJ-6502A-M2 SGJ-6504A-M2 Non compatible
LED & POWER SW PB SGJ-7502A-M2 SGJ-7503A-M2 Non compatible

(No.52114B)1-3
PRINTED WIRING BOARD PARTS LIST [AV-27FA44/BSA]
MAIN P.W. BOARD ASS'Y (SGJ-1524A-M2)
 Ref No. Part No. Part Name Description Local
IC101 M52342SP IC
IC201 TM8812CSDNG4RR3 IC(MCU)
IC421 LA78041 IC
IC502 CXA1875AM-X IC
IC621 AN5277 IC
IC702 AT24C04W-32FA44 IC (SERVICE)
IC703 S-80840CNY-T IC
IC704 AN78L05-T IC
IC851 AN7812F IC
IC852 L7809CP IC
IC853 L7805CP IC
 IC911 STR-G9626-F3 IC
 IC921 SE135N IC
Q001 UN2212-X DIGI TRANSISTOR
Q101 2SC5083/L-P/-T TRANSISTOR
Q131 2SA1530A/QR/-X SI TRANSISTOR
Q161 2SC3928A/QR/-X SI TRANSISTOR
Q211 2SC3928A/QR/-X SI TRANSISTOR
Q232 2SC3928A/QR/-X SI TRANSISTOR
Q233 2SC3928A/QR/-X SI TRANSISTOR
Q352 2SC3928A/QR/-X SI TRANSISTOR
Q353 2SC3928A/QR/-X SI TRANSISTOR
Q431 UN2212-X DIGI TRANSISTOR
Q501 2SC4212/Z1/ TRANSISTOR
 Q511 2SD2645-YD TRANSISTOR H OUT
Q531 2SC2785/JH/-T SI TRANSISTOR
Q532 2SA1530A/QR/-X SI TRANSISTOR
Q541 2SA1530A/QR/-X SI TRANSISTOR
Q542 2SA1530A/QR/-X SI TRANSISTOR
Q543 2SD1267A/QP/ POW TRANSISTOR
Q622 2SC3928A/QR/-X SI TRANSISTOR
Q623 UN2212-X DIGI TRANSISTOR
Q624 2SA1530A/QR/-X SI TRANSISTOR
Q701 2SA1530A/QR/-X SI TRANSISTOR
Q951 2SD1383K/AB/-X TRANSISTOR
Q971 2SA1208/ST/Z1-T TRANSISTOR
D305 1SS133-T2 DIODE
D306 1SS133-T2 DIODE
D307 1SS133-T2 DIODE
D308 1SS133-T2 DIODE
D309 1SS133-T2 DIODE
D310 1SS133-T2 DIODE
D352 MTZJ9.1C-T2 Z DIODE
D353 1SS133-T2 DIODE
D354 MTZJ3.3A-T2 Z DIODE
D421 1N4003-T2 SI DIODE
D422 MTZJ75-T2 Z DIODE
D432 1SS133-T2 DIODE
D501 RH3G-F1 SI DIODE
D502 RU3AM-LFC4 SI DIODE
D507 RGP10J-04TS-T3 SI DIODE
D521 RH1S-T3 SI DIODE
D523 RGP10J-04TS-T3 SI DIODE
D525 1SS81-T5 SI DIODE
D526 1SS81-T5 SI DIODE
D527 1SR124-400A-T2 SI DIODE
D529 MTZJ9.1C-T2 Z DIODE
 D531 MA4068N/Z1/-T2 Z DIODE
D535 1SS133-T2 DIODE
D537 1SR35-400A-T2 SI DIODE
D601 MTZJ9.1C-T2 Z DIODE
D602 MTZJ9.1C-T2 Z DIODE
D603 MTZJ9.1C-T2 Z DIODE
D621 1SS133-T2 DIODE
D622 1SS133-T2 DIODE
D630 1SS133-T2 DIODE
D633 1SS133-T2 DIODE
D700 MTZJ5.6B-T2 Z DIODE
D701 1SS133-T2 DIODE
D703 MTZJ5.6B-T2 Z DIODE
D704 MTZJ5.6B-T2 Z DIODE
D705 1SS133-T2 DIODE
D706 MTZJ5.6B-T2 Z DIODE
D707 MTZJ5.6B-T2 Z DIODE
D708 MTZJ5.6B-T2 Z DIODE
D709 MTZJ5.6B-T2 Z DIODE
D723 MTZJ5.6B-T2 Z DIODE
D810 MTZJ5.6B-T2 Z DIODE
 D901 GSIB460 BRIDGE DIODE
D910 MA700A-T2 SB DIODE
D911 RGP10J-04TS-T3 SI DIODE
D912 RGP10J-04TS-T3 SI DIODE
D913 1SS133-T2 DIODE
D914 1SS133-T2 DIODE
D915 SARS01-T2 SI DIODE
D917 MTZJ30A-T2 Z DIODE
D918 MTZJ5.1C-T2 Z DIODE
D920 1SS133-T2 DIODE
D931 RU4AM-LFT2 SI DIODE
D933 RU3YX-LFC4 SI DIODE
D935 RU3YX-LFC4 SI DIODE
D937 RU3YX-LFC4 SI DIODE
D941 MTZJ33A-T2 Z DIODE
D945 MTZJ9.1B-T2 Z DIODE
D952 1SS133-T2 DIODE
D953 1SS133-T2 DIODE
D954 1N4002G-T2 FR DIODE
D955 1N4002G-T2 FR DIODE
D956 1N4002G-T2 FR DIODE
D957 1N4002G-T2 FR DIODE
D972 MTZJ15C-T2 Z DIODE
D973 1SS133-T2 DIODE
C001 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C003 QETN1HM-106Z E CAPACITOR 10uF 50V M
C004 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C006 QETN1EM-476Z E CAPACITOR 47uF 25V M
C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C104 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C105 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C106 QETN1EM-476Z E CAPACITOR 47uF 25V M
C107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C113 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C114 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C116 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C117 QETN1EM-476Z E CAPACITOR 47uF 25V M
C118 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C119 NDC31HJ-681X C CAPACITOR 680pF 50V J
C120 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C124 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C161 QETN1HM-106Z E CAPACITOR 10uF 50V M
C163 NDC31HJ-470X C CAPACITOR 47pF 50V J
C164 NDC31HJ-470X C CAPACITOR 47pF 50V J
C165 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C166 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C202 QETN1HM-105Z E CAPACITOR 1uF 50V M
C203 NCB31HK-152X C CAPACITOR 1500pF 50V K
C211 QENC1CM-106Z BP E CAPACITOR 10uF 16V M
C212 NDC31HJ-100X C CAPACITOR 10pF 50V J
C221 QETN1HM-106Z E CAPACITOR 10uF 50V M
C222 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C223 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C233 NDC31HJ-680X C CAPACITOR 68pF 50V J
C237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C241 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C242 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C243 QETN1CM-107Z E CAPACITOR 100uF 16V M
C244 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C281 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C282 QETN1CM-107Z E CAPACITOR 100uF 16V M
C283 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C284 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C285 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C286 QETN1HM-106Z E CAPACITOR 10uF 50V M
C287 QETN1CM-107Z E CAPACITOR 100uF 16V M
C288 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C302 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C352 QETN1CM-476Z E CAPACITOR 47uF 16V M
C354 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C391 QETN1CM-107Z E CAPACITOR 100uF 16V M
C392 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C422 QFN32AK-102Z M CAPACITOR 1000pF 100V K
C424 QETN1VM-107Z E CAPACITOR 100uF 35V M
C425 QETN1VM-477Z E CAPACITOR 470uF 35V M
C427 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C428 QETM1EM-228 E CAPACITOR 2200uF 25V M
C431 QFLC2AK-563Z M CAPACITOR 0.056uF 100V K
C432 QETN1EM-476Z E CAPACITOR 47uF 25V M
C433 QETN1EM-476Z E CAPACITOR 47uF 25V M
C435 NCB21HK-183X C CAPACITOR 0.018uF 50V K
C440 QCS32HJ-100Z C CAPACITOR 10pF 500V J
C501 QCB32HK-151Z C CAPACITOR 150pF 500V K
C502 QCB32HK-331Z C CAPACITOR 330pF 500V K
C503 QEHR2CM-105Z E CAPACITOR 1uF 160V M
C504 QEZ0203-107 E CAPACITOR 100uF 160V M
C505 QENC2AM-225Z BP E CAPACITOR 2.2uF 100V M
 Ref No. Part No. Part Name Description Local

1-4 (No.52114B)
C507 QEM61HK-475Z E CAPACITOR 4.7uF 50V K
C508 QEM61HK-475Z E CAPACITOR 4.7uF 50V K
 C510 QFZ0200-482 MPP CAPACITOR 4800pF 1.5kV H
 C513 QFZ0196-113 MPP CAPACITOR 0.011uF 1.5kV H
C514 QFP32GJ-183 PP CAPACITOR 0.018uF 400V J
C515 QFZ0197-404 MPP CAPACITOR 0.4uF 250V J
C516 QCB32HK-561Z C CAPACITOR 560pF 500V K
C521 QETN2EM-106Z E CAPACITOR 10uF 250V M
C523 QEHR1VM-477Z E CAPACITOR 470uF 35V M
C525 QETN1VM-107Z E CAPACITOR 100uF 35V M
C526 QFV21HJ-824Z MF CAPACITOR 0.82uF 50V J
C527 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C531 QCB32HK-471Z C CAPACITOR 470pF 500V K
C533 QETN1HM-106Z E CAPACITOR 10uF 50V M
C561 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C562 QETN1HM-106Z E CAPACITOR 10uF 50V M
C601 QETN1EM-476Z E CAPACITOR 47uF 25V M
C602 QETN1EM-476Z E CAPACITOR 47uF 25V M
C603 QETN1EM-476Z E CAPACITOR 47uF 25V M
C609 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C610 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C611 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C621 NCB31HK-102X C CAPACITOR 1000pF 50V K
C622 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C623 NCB31HK-102X C CAPACITOR 1000pF 50V K
C624 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C625 QETN1VM-107Z E CAPACITOR 100uF 35V M
C626 QETN1VM-108Z E CAPACITOR 1000uF 35V M
C627 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C628 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C629 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C633 QETN1CM-477Z E CAPACITOR 470uF 16V M
C636 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C637 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C638 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C639 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C641 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C700 NCB31HK-102X C CAPACITOR 1000pF 50V K
C701 QETN1HM-106Z E CAPACITOR 10uF 50V M
C702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C703 QETN1HM-106Z E CAPACITOR 10uF 50V M
C704 QETN1CM-107Z E CAPACITOR 100uF 16V M
C705 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C706 QETN1HM-105Z E CAPACITOR 1uF 50V M
C708 NDC31HJ-220X C CAPACITOR 22pF 50V J
C709 NDC31HJ-220X C CAPACITOR 22pF 50V J
C711 QETN1CM-107Z E CAPACITOR 100uF 16V M
C712 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C716 QETN1HM-106Z E CAPACITOR 10uF 50V M
C728 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C807 QETN1AM-477Z E CAPACITOR 470uF 10V M
C813 NCB31HK-102X C CAPACITOR 1000pF 50V K
C815 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C851 QETN1EM-107Z E CAPACITOR 100uF 25V M
C852 QETN1CM-107Z E CAPACITOR 100uF 16V M
C853 QETN1EM-227Z E CAPACITOR 220uF 25V M
C854 QETN1CM-227Z E CAPACITOR 220uF 16V M
C856 QEHR1CM-227Z E CAPACITOR 220uF 16V M
C857 QETN1CM-477Z E CAPACITOR 470uF 16V M
 C901 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
 C902 QFZ9072-473 MM CAPACITOR 0.047uF AC250V K
 C903 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
 C904 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
 C905 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
 C906 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C907 QEZ0644-567 E CAPACITOR 560uF 200V K
 C908 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C912 QCZ0340-222 C CAPACITOR 2200pF 2kV K
C913 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C914 QETN1HM-107Z E CAPACITOR 100uF 50V M
C916 NDC31HJ-331X C CAPACITOR 330pF 50V J
C917 NCB31HK-182X C CAPACITOR 1800pF 50V K
C918 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C919 QFP32GJ-103 PP CAPACITOR 0.01uF 400V J
C931 QEZ0203-227 E CAPACITOR 220uF 160V M
C932 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C933 QETN1EM-228Z E CAPACITOR 2200uF 25V M
C934 NDC31HJ-221X C CAPACITOR 220pF 50V J
C935 QETN1VM-108Z E CAPACITOR 1000uF 35V M
C937 QCZ0340-102 C CAPACITOR 1000pF 2kV K
C938 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C939 QCB32HK-152Z C CAPACITOR 1500pF 500V K
C941 QCB32HK-102Z C CAPACITOR 1000pF 500V K
C942 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C943 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C951 QETN1EM-477Z E CAPACITOR 470uF 25V M
C952 QETN1CM-227Z E CAPACITOR 220uF 16V M
C971 QETN1CM-107Z E CAPACITOR 100uF 16V M
C972 QETN1EM-476Z E CAPACITOR 47uF 25V M
 Ref No. Part No. Part Name Description Local
C973 QETN1HM-106Z E CAPACITOR 10uF 50V M
 C997 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C998 QCZ9074-103 C CAPACITOR 0.01uF AC250V M
 C999 QCZ9074-103 C CAPACITOR 0.01uF AC250V M
R002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R003 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R004 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R005 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R008 NRSA63J-820X MG RESISTOR 82 Ω 1/16W J
R009 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R101 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R102 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R103 QRE121J-101Y C RESISTOR 100 Ω 1/2W J
R104 NRSA63J-180X MG RESISTOR 18
Ω 1/16W J
R105 NRSA63J-270X MG RESISTOR 27
Ω 1/16W J
R111 NRSA63J-394X MG RESISTOR 390k Ω 1/16W J
R112 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R113 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R115 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R116 NRSA63J-680X MG RESISTOR 68 Ω 1/16W J
R117 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R118 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R131 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R132 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R133 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R134 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R135 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R161 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R162 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R163 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R164 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R165 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R166 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R167 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R168 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R169 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R171 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R201 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R212 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R215 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R216 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R217 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R222 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R227 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R231 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R237 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R238 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R241 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R243 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R281 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R282 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R283 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R286 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R287 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R288 NRSA02J-471X MG RESISTOR 470
Ω 1/10W J
R289 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R290 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R292 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R293 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R301 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R302 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R303 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R304 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R305 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R306 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R318 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R319 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R352 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R354 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R355 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R356 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R358 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R359 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R360 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R421 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R423 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R424 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R426 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R427 QRT029J-1R5 MF RESISTOR 1.5
Ω 2W J
R429 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R430 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R431 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R432 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R433 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R434 QRL029J-181 OMF RESISTOR 180
Ω 2W J
R435 QRE121J-102Y C RESISTOR 1k
Ω 1/2W J
R441 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R447 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
 Ref No. Part No. Part Name Description Local

(No.52114B)1-5
R449 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R501 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R502 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R503 QRE121J-103Y C RESISTOR 10k Ω 1/2W J
R504 QRL039J-222 OMF RESISTOR 2.2k Ω 3W J
R505 QRL039J-182 OMF RESISTOR 1.8k Ω 3W J
R511 QRE121J-220Y C RESISTOR 22 Ω 1/2W J
R512 QRE121J-681Y C RESISTOR 680
Ω 1/2W J
R513 QRL039J-273 OMF RESISTOR 27k
Ω 3W J
R516 QRZ0221-2R0 OMF RESISTOR 2 Ω 7W K
R524 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R526 QRE121J-272Y C RESISTOR 2.7k Ω 1/2W J
R527 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R528 QRE121J-154Y C RESISTOR 150k Ω 1/2W J
R529 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
 R531 QRZ0230-391X UNF C RESISTOR 390 Ω
R532 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R533 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R534 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
 R535 NRSA63D-272X MG RESISTOR 2.7k Ω 1/16W D
 R537 NRSA63D-752X MG RESISTOR 7.5k Ω 1/16W D
R538 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R541 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R543 QRE121J-122Y C RESISTOR 1.2k
Ω 1/2W J
R544 QRE121J-392Y C RESISTOR 3.9k Ω 1/2W J
R545 QRE121J-822Y C RESISTOR 8.2k Ω 1/2W J
R546 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R547 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R548 QRE121J-152Y C RESISTOR 1.5k Ω 1/2W J
R553 QRL039J-390 OMF RESISTOR 39 Ω 3W J
 R554 QRK126J-150X UNF C RESISTOR 15 Ω 1/2W J
R555 QRT029J-3R3 MF RESISTOR 3.3 Ω 2W J
R561 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R562 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R601 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R602 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R603 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R610 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R611 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R612 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R621 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R622 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R623 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R624 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R626 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R627 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R628 QRK126J-102X UNF C RESISTOR 1k Ω 1/2W J
R629 QRK126J-102X UNF C RESISTOR 1k Ω 1/2W J
R631 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R632 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R633 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R637 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R638 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R639 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R640 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R641 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R644 QRZ0230-2R2X UNF C RESISTOR 2.2 Ω
R645 QRZ0230-2R2X UNF C RESISTOR 2.2 Ω
R647 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R651 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R652 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R653 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R657 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R700 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R701 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R702 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R704 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R705 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R706 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R707 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R708 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R709 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R715 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R718 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R721 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R728 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R729 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R731 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R732 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R733 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R734 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R739 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R740 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R764 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R765 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R766 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R767 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R769 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R772 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R811 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R812 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R816 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R821 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R822 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R827 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R857 QRL029J-820 OMF RESISTOR 82 Ω 2W J
R901 QRF074K-1R2 UNF WW RESISTOR 1.2
Ω 7W K
R909 QRG01GJ-470 OMF RESISTOR 47
Ω 1W J
R911 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R912 QRT029J-R18 MF RESISTOR 0.18 Ω 2W J
R913 QRT029J-R15 MF RESISTOR 0.15 Ω 2W J
 R914 QRK126J-681X UNF C RESISTOR 680 Ω 1/2W J
 R915 QRK129J-6R8 UNF C RESISTOR 6.8 Ω 1/2W J
 R917 QRK126J-332X UNF C RESISTOR 3.3k Ω 1/2W J
R918 QRE121J-222Y C RESISTOR 2.2k
Ω 1/2W J
R919 QRE121J-684Y C RESISTOR 680k Ω 1/2W J
R924 QRE121J-222Y C RESISTOR 2.2k Ω 1/2W J
R930 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R939 QRT039J-1R5 MF RESISTOR 1.5 Ω 3W J
R940 QRE121J-181Y C RESISTOR 180 Ω 1/2W J
R941 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R950 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R951 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R952 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R953 QRE121J-820Y C RESISTOR 82 Ω 1/2W J
R972 NRSA63D-122X MG RESISTOR 1.2k Ω 1/16W D
R973 NRVA02D-332X CMF RESISTOR 3.3k Ω 1/10W D
R975 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R977 QRE121J-473Y C RESISTOR 47k Ω 1/2W J
R978 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
 R998 QRZ9041-275 C RESISTOR 2.7M Ω 1/2W K
R999 QRE121J-121Y C RESISTOR 120 Ω 1/2W J
L001 QQL244K-560Z COIL 56uH K
L101 QQLZ014-R22 COIL 0.22uH 100mA L
L113 QQL244K-4R7Z COIL 4.7uH K
L131 QQL244K-150Z COIL 15uH K
L161 QQL244K-220Z COIL 22uH K
L232 QQL244K-560Z COIL 56uH K
L241 QQL244K-220Z COIL 22uH K
L391 QQL244K-220Z COIL 22uH K
L511 QQR1165-001 LINEARITY COIL
L512 QQLZ036-821 COIL 820uH K
L521 QQLZ026-760 COIL 76uH ± 7%
L701 QQL244K-220Z COIL 22uH K
L702 QQL244K-220Z COIL 22uH K
L703 QQL244K-220Z COIL 22uH K
L704 QQL244K-220Z COIL 22uH K
L705 QQL244K-220Z COIL 22uH K
L931 QQL26AK-470Z COIL 47uH K
L933 QQL26AK-470Z COIL 47uH K
L937 QQL26AK-470Z COIL 47uH K
L940 QQR0582-001Z FERRITE BEADS
T111 QQR0907-001 IFT
T501 QQR1414-001 DRIVE TRANSF
 T921 QQS0237-001 SW TRANSF
 T951 QQT0355-001 POWER TRANSF
CF001 QAX0349-001 C TRAP 47.25MHz
CF131 QAX0639-001Z C TRAP 4.500MHz
CF161 QAX0642-001Z C FILTER 4.500MHz
CN001 QGB1505J1-35 CONNECTOR B-B (1-35)
CN004 QGA2501C5-07Z CONNECTOR W-B (1-7)
CN005 QGA2501C5-06Z CONNECTOR W-B (1-6)
CN007 QGA2501C5-06Z CONNECTOR W-B (1-6)
CN00C QGA2501F1-06 CONNECTOR W-B (1-6)
CN0E1 CE41507-001P LV CONNECTOR
CN0E3 CE41507-001P LV CONNECTOR
CN0HV QGZ5004C1-06 CONNECTOR (1-6)
CN0S1 QGA2501C5-05Z CONNECTOR W-B (1-5)
CN0SS QGA2501C5-04Z CONNECTOR W-B (1-4)
 CP932 ICP-N70-T IC PROTECTOR 2.5A
 CP933 ICP-N70-T IC PROTECTOR 2.5A
 CP936 ICP-N70-T IC PROTECTOR 2.5A
 F901 QMF51N1-5R0-J5 FUSE 5A AC125V
 F905 QMFZ049-5R0Z-E FUSE 5A 125V
FC901 CEMG002-001Z FUSE CLIP
FC902 CEMG002-001Z FUSE CLIP
 FR525 QRZ9017-4R7 FUSI RESISTOR 4.7 Ω 1/4W J
 FR527 QRZ9011-470 FUSI RESISTOR 47 Ω 1/2W J
HS001 LC32313-001A HEAT SINK/AL-F/
HS002 LC31678-002A HEAT SINK/AL-F/
HS003 LC32111-002A HEAT SINK/AL-F/
HS004 CEHE015-001WU HEAT SINK
HS005 CM42862-00G-H HEAT SINK ASSY
HS007 CEHT11B-002QS HEAT SINK
J601 QNN0349-002 PIN JACK COMP IN
J810 QNS0001-001 3.5 JACK AV COMPULINK III
 Ref No. Part No. Part Name Description Local

1-6 (No.52114B)
CRT SOCKET P.W. BOARD ASS'Y (SGJ3507A-M2)
K401 QQR0621-002Z FERRITE BEADS
K912 QQR0582-001Z FERRITE BEADS
K916 QQR0582-001Z FERRITE BEADS
K917 QQR0582-001Z FERRITE BEADS
K918 QQR0582-001Z FERRITE BEADS
K920 QQR1139-001 FERRITE BEADS
K931 QQR0582-001Z FERRITE BEADS
K932 QQR0582-001Z FERRITE BEADS
K933 QQR0582-001Z FERRITE BEADS
K935 QQR0582-001Z FERRITE BEADS
K937 QQR0582-001Z FERRITE BEADS
LC601 QQR1199-001 EMI FILTER
LC602 QQR1199-001 EMI FILTER
LC603 QQR1199-001 EMI FILTER
 LF901 QQR1159-001 LINE FILTER
 LF902 QQR0527-004 LINE FILTER
 PC921 PC123Y22 PHOTO COUPLER
 RY951 QSK0085-001 RELAY
S421 QSL4A13-C02 LEVER SWITCH V.CENTER
SF101 QAX0723-001 SAW FILTER
 TH901 QAD0132-3R0 P THERMISTOR 3 Ω
 TU001 QAU0305-001 TUNER
 VA901 ERZV10V621CS ZNR
X701 QAX0767-001Z CRYSTAL 8MHz
 Ref No. Part No. Part Name Description Local
Q3103 KTA1267/YG/-T TRANSISTOR
Q3105 KTC3199/YG/-T TRANSISTOR
Q3106 KTA1267/YG/-T TRANSISTOR
Q3107 2SA2005/DE/ POW TRANSISTOR
Q3108 2SC5511/DE/ POW TRANSISTOR
Q3109 KTC3199/YG/-T TRANSISTOR
Q3151 KTC3199/YG/-T TRANSISTOR
Q3152 KTA1267/YG/-T TRANSISTOR
Q3301 2SC5083/L-P/-T TRANSISTOR
Q3302 2SC5083/L-P/-T TRANSISTOR
Q3303 2SC5083/L-P/-T TRANSISTOR
Q3304 2SC5147/CDE/F43 POW TRANSISTOR
Q3305 2SC5147/CDE/F43 POW TRANSISTOR
Q3306 2SC5147/CDE/F43 POW TRANSISTOR
Q3351 KTA1267/YG/-T TRANSISTOR
D3101 1SS133-T2 DIODE
D3105 RH1S-T3 SI DIODE
D3106 RH1S-T3 SI DIODE
D3301 1SS133-T2 DIODE
D3302 1SS133-T2 DIODE
D3303 1SS133-T2 DIODE
D3304 1SS82-T2 SI DIODE
D3305 1SS82-T2 SI DIODE
D3306 1SS82-T2 SI DIODE
D3311 MTZJ3.6B-T2 Z DIODE
D3312 1SS133-T2 DIODE
D3313 MTZJ4.3A-T2 Z DIODE
D3314 1SS133-T2 DIODE
D3331 1SS133-T2 DIODE
D3351 1SS133-T2 DIODE
D3352 1SS133-T2 DIODE
D3353 1SS133-T2 DIODE
D3354 1SS133-T2 DIODE
C3101 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3109 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3110 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3111 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3113 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3114 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3115 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3117 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3118 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C3119 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3120 QETN1AM-337Z E CAPACITOR 330uF 10V M
C3121 QCS32HJ-151Z C CAPACITOR 150pF 500V J
C3122 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C3125 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C3151 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C3152 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C3301 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3302 NDC31HJ-391X C CAPACITOR 390pF 50V J
C3303 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3321 QETN2EM-105Z E CAPACITOR 1uF 250V M
C3322 QETN2EM-105Z E CAPACITOR 1uF 250V M
C3323 QETN1CM-107Z E CAPACITOR 100uF 16V M
 Ref No. Part No. Part Name Description Local
C3351 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3363 QCZ0324-102 C CAPACITOR 1000pF 3kV P
R3108 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3111 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R3114 QRZ0230-100X UNF C RESISTOR 10 Ω
R3115 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3116 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R3117 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3119 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
 R3122 QRZ9021-561 FUSI RESISTOR 560 Ω 1W J
R3123 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R3124 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R3125 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3126 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R3127 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R3128 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R3129 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3130 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R3131 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R3132 QRL029J-391 OMF RESISTOR 390 Ω 2W J
R3134 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3135 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3136 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R3139 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R3142 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R3143 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R3145 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3146 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3151 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R3152 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R3153 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R3154 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R3301 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R3302 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R3303 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R3304 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R3305 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R3306 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R3307 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3308 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3309 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3310 QRL029J-153 OMF RESISTOR 15k Ω 2W J
R3311 QRL029J-153 OMF RESISTOR 15k Ω 2W J
R3312 QRL029J-153 OMF RESISTOR 15k Ω 2W J
R3313 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R3314 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R3315 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R3316 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3317 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3318 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3325 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3326 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3327 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3331 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3332 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R3333 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3334 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R3335 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R3336 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3337 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3338 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3351 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3352 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3353 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3354 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
L3301 QQL244K-180Z COIL 18uH K
L3302 QQL244K-180Z COIL 18uH K
L3303 QQL244K-180Z COIL 18uH K
L3304 QQL244K-470Z COIL 47uH K
L3305 QQL244K-470Z COIL 47uH K
L3306 QQL244K-470Z COIL 47uH K
CN3004 QJB003-073226 SIN ID C-B WIRE
CN3005 WJA0029-001A E-S ID WIRE
CN300V QGA2501C5-03Z CONNECTOR W-B (1-3)
CN30E2 QUB130-38A6AS SIN TWIST WIRE
CN30E4 QUB130-38A6AS SIN TWIST WIRE
 FR3122 QRZ9021-561 FUSI RESISTOR 560 Ω 1W J
HS3010 CEHP00N-001QS HEAT SINK
HS3011 CEHP00N-001QS HEAT SINK
HS3012 CEHP00N-001QS HEAT SINK
HS3013 CEHP00N-001QS HEAT SINK
HS3014 CEHP00N-001QS HEAT SINK
K3102 QQR1114-001Z FERRITE BEADS
K3103 QQR1114-001Z FERRITE BEADS
K3104 QQR1114-001Z FERRITE BEADS
K3105 QQR1114-001Z FERRITE BEADS
 Ref No. Part No. Part Name Description Local

(No.52114B)1-7
AV SELECTOR P.W. BOARD ASS'Y (SGJ-5505A-M2)
 SK3001 QNZ0536-001 CRT SOCKET
 Ref No. Part No. Part Name Description Local
IC5001 CXA2134Q-X IC
IC5151 NJM2150AD IC
IC5201 TC90A49AP IC
IC5501 TA1218AN IC
Q5001 2SA1530A/QR/-X SI TRANSISTOR
Q5002 2SA1530A/QR/-X SI TRANSISTOR
Q5211 2SC3928A/QR/-X SI TRANSISTOR
Q5212 2SC3928A/QR/-X SI TRANSISTOR
Q5251 2SC3928A/QR/-X SI TRANSISTOR
Q5252 2SA1530A/QR/-X SI TRANSISTOR
Q5253 2SA1530A/QR/-X SI TRANSISTOR
Q5261 2SA1530A/QR/-X SI TRANSISTOR
Q5262 2SC3928A/QR/-X SI TRANSISTOR
Q5263 2SA1530A/QR/-X SI TRANSISTOR
Q5384 DTC323TK-X DIGI TRANSISTOR
Q5385 DTC323TK-X DIGI TRANSISTOR
Q5386 DTC323TK-X DIGI TRANSISTOR
Q5387 DTC323TK-X DIGI TRANSISTOR
Q5501 2SA1530A/QR/-X SI TRANSISTOR
D5391 MTZJ9.1C-T2 Z DIODE
D5392 MTZJ9.1C-T2 Z DIODE
D5501 MTZJ9.1C-T2 Z DIODE
D5502 MTZJ9.1C-T2 Z DIODE
D5503 MTZJ9.1C-T2 Z DIODE
D5505 MTZJ9.1C-T2 Z DIODE
D5507 MTZJ9.1C-T2 Z DIODE
D5508 MTZJ9.1C-T2 Z DIODE
D5509 MTZJ9.1C-T2 Z DIODE
D5510 MTZJ9.1C-T2 Z DIODE
D5511 MTZJ9.1C-T2 Z DIODE
D5512 MTZJ9.1C-T2 Z DIODE
D5513 MTZJ9.1C-T2 Z DIODE
C5001 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5002 NCB31HK-562X C CAPACITOR 5600pF 50V K
C5003 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C5004 QETN1HM-105Z E CAPACITOR 1uF 50V M
C5005 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C5006 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5007 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C5008 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5009 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5010 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C5011 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5012 NCB31HK-272X C CAPACITOR 2700pF 50V K
C5013 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C5014 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5015 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5016 QETN1HM-105Z E CAPACITOR 1uF 50V M
C5017 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C5018 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C5019 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C5020 NCB31HK-472X C CAPACITOR 4700pF 50V K
C5021 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5022 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5023 NCB31HK-472X C CAPACITOR 4700pF 50V K
C5024 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C5025 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5026 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C5031 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5151 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C5152 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C5153 NCB31HK-222X C CAPACITOR 2200pF 50V K
C5154 NCB31HK-222X C CAPACITOR 2200pF 50V K
C5155 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C5156 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C5157 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5158 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5159 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5160 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5203 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5204 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5205 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5206 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5211 QENC1CM-106Z BP E CAPACITOR 10uF 16V M
C5212 NDC31HJ-101X C CAPACITOR 100pF 50V J
C5213 NDC31HJ-470X C CAPACITOR 47pF 50V J
C5214 NDC31HJ-181X C CAPACITOR 180pF 50V J
 Ref No. Part No. Part Name Description Local
C5215 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C5226 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5231 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5232 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5233 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5234 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5235 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5236 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5238 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5239 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5240 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5241 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5242 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5243 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5246 NDC31HJ-181X C CAPACITOR 180pF 50V J
C5247 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5251 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5252 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5253 NDC31HJ-820X C CAPACITOR 82pF 50V J
C5255 NDC31HJ-470X C CAPACITOR 47pF 50V J
C5263 NDC31HJ-470X C CAPACITOR 47pF 50V J
C5391 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C5392 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C5501 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5502 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5503 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5504 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5506 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5508 QETN1HM-106Z E CAPACITOR 10uF 50V M
C5509 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5520 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5521 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5531 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5532 QETN1EM-476Z E CAPACITOR 47uF 25V M
C5533 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5534 QENC1CM-106Z BP E CAPACITOR 10uF 16V M
R5001 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R5002 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R5003 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R5004 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R5005 NRSA63F-623X MG RESISTOR 62k Ω 1/16W F
R5007 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R5008 NRSA63J-302X MG RESISTOR 3k Ω 1/16W J
R5010 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R5011 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5012 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5031 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R5032 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R5033 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R5034 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R5151 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R5152 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R5153 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R5154 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R5156 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5158 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5159 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5210 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5211 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R5212 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5213 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5214 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R5215 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R5216 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R5217 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R5240 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5241 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R5242 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R5243 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R5251 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R5253 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R5254 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R5255 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R5258 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R5259 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5261 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R5262 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5263 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R5265 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5269 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R5270 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5384 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R5385 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R5386 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R5387 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R5391 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5392 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
 Ref No. Part No. Part Name Description Local

1-8 (No.52114B)
FRONT CONTROL P.W. BOARD ASS'Y (SGJ-6504A-M2)
LED & POWER SW P.W. BOARD ASS'Y (SGJ-7503A-M2)
R5393 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R5394 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R5395 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5396 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5501 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5502 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5503 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5504 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R5505 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R5507 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5508 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R5509 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5510 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5511 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5512 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R5513 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R5514 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5515 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5516 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5517 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5519 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R5520 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R5521 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R5522 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R5523 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R5524 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5526 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5527 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R5532 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R5533 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R5541 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5542 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5543 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5544 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R5545 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R5546 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5558 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5559 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5560 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5561 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5564 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5565 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L5202 QQL244K-150Z COIL 15uH K
L5211 QQL244K-4R7Z COIL 4.7uH K
L5241 QQL244K-4R7Z COIL 4.7uH K
L5243 QQL244K-4R7Z COIL 4.7uH K
L5244 QQL244K-4R7Z COIL 4.7uH K
L5261 QQL244K-150Z COIL 15uH K
CN5001 QGB1505K1-35 CONNECTOR B-B (1-35)
CN5006 QGA2501C5-05Z CONNECTOR W-B (1-5)
J5501 QNZ0454-001 AV JACK S/V/L/R IN
J5502 QNN0349-001 PIN JACK V/L/R IN
J5503 QNN0348-001 PIN JACK L/R OUT
 Ref No. Part No. Part Name Description Local
C6401 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6402 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C6403 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
R6401 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R6402 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R6403 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R6702 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6703 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6704 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R6705 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R6706 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
CN6006 QJB003-054010 SIN ID C-B WIRE
CN6007 QJB003-064426 SIN ID C-B WIRE
CN600B QJB003-050806 SIN ID C-B WIRE
J6401 QNN0281-003 PIN JACK V IN
J6402 QNN0281-002 PIN JACK L IN
J6403 QNN0282-001 PIN JACK R IN
LC6401 QQR1199-001 EMI FILTER
S6702 QSW0619-003Z TACT SWITCH MENU
S6703 QSW0619-003Z TACT SWITCH CH-
S6704 QSW0619-003Z TACT SWITCH CH+
S6705 QSW0619-003Z TACT SWITCH VOL-
S6706 QSW0619-003Z TACT SWITCH VOL+
 Ref No. Part No. Part Name Description Local
 Ref No. Part No. Part Name Description Local
IC7701 GP1UM281QK IR DETECT UNIT 38kHz
Q7702 UN2112-X TRANSISTOR
D7701 LG22440 LED POWER
C7701 QETN1EM-476Z E CAPACITOR 47uF 25V M
R7708 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R7709 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R7710 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7711 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
CN700B QGA2501C5-05Z CONNECTOR W-B (1-5)
S7701 QSW0847-001 TACT SWITCH POWER

(No.52114B)1-9
PRINTED WIRING BOARD PARTS LIST [AV-32FA44/BYA]
MAIN P.W. BOARD ASS'Y (SGJ-1528A-M2)
 Ref No. Part No. Part Name Description Local
IC101 M52342SP IC
IC201 TM8812CSDNG4RR3 IC(MCU)
IC421 LA78041 IC
IC502 CXA1875AM-X IC
IC621 AN5277 IC
IC702 S524A40X41-DCB0 IC (SERVICE)
IC703 S-80840CNY-T IC
IC704 AN78L05-T IC
IC851 AN7812F IC
IC852 L7809CP IC
IC853 L7805CP IC
 IC911 STR-G9626-F3 IC
 IC921 SE135N IC
Q001 UN2212-X DIGI TRANSISTOR
Q101 2SC5083/L-P/-T TRANSISTOR
Q131 2SA1530A/QR/-X SI TRANSISTOR
Q161 2SC3928A/QR/-X SI TRANSISTOR
Q211 2SC3928A/QR/-X SI TRANSISTOR
Q232 2SC3928A/QR/-X SI TRANSISTOR
Q233 2SC3928A/QR/-X SI TRANSISTOR
Q352 2SC3928A/QR/-X SI TRANSISTOR
Q353 2SC3928A/QR/-X SI TRANSISTOR
Q431 UN2212-X DIGI TRANSISTOR
Q501 2SC4212/Z1/ TRANSISTOR
 Q511 2SD2645-YD TRANSISTOR H OUT
Q531 2SC2785/JH/-T SI TRANSISTOR
Q532 2SA1530A/QR/-X SI TRANSISTOR
Q541 2SA1530A/QR/-X SI TRANSISTOR
Q542 2SA1530A/QR/-X SI TRANSISTOR
Q543 2SD1267A/QP/ POW TRANSISTOR
Q622 2SC3928A/QR/-X SI TRANSISTOR
Q623 UN2212-X DIGI TRANSISTOR
Q624 2SA1530A/QR/-X SI TRANSISTOR
Q701 2SA1530A/QR/-X SI TRANSISTOR
Q951 2SD1383K/AB/-X TRANSISTOR
Q971 2SA1208/ST/Z1-T TRANSISTOR
D305 1SS133-T2 DIODE
D306 1SS133-T2 DIODE
D307 1SS133-T2 DIODE
D308 1SS133-T2 DIODE
D309 1SS133-T2 DIODE
D310 1SS133-T2 DIODE
D352 MTZJ9.1C-T2 Z DIODE
D353 1SS133-T2 DIODE
D354 MTZJ3.3A-T2 Z DIODE
D421 1N4003-T2 SI DIODE
D422 MTZJ75-T2 Z DIODE
D432 1SS133-T2 DIODE
D501 RH3G-F1 SI DIODE
D502 RU3AM-LFC4 SI DIODE
D507 RGP10J-04TS-T3 SI DIODE
D521 RH1S-T3 SI DIODE
D523 RGP10J-04TS-T3 SI DIODE
D525 1SS81-T5 SI DIODE
D526 1SS81-T5 SI DIODE
D527 1SR124-400A-T2 SI DIODE
D529 MTZJ9.1C-T2 Z DIODE
 D531 MA4068N/Z1/-T2 Z DIODE
D535 1SS133-T2 DIODE
D537 1SR35-400A-T2 SI DIODE
D601 MTZJ9.1C-T2 Z DIODE
D602 MTZJ9.1C-T2 Z DIODE
D603 MTZJ9.1C-T2 Z DIODE
D621 1SS133-T2 DIODE
D622 1SS133-T2 DIODE
D630 1SS133-T2 DIODE
D633 1SS133-T2 DIODE
D700 MTZJ5.6B-T2 Z DIODE
D701 1SS133-T2 DIODE
D703 MTZJ5.6B-T2 Z DIODE
D704 MTZJ5.6B-T2 Z DIODE
D705 1SS133-T2 DIODE
D706 MTZJ5.6B-T2 Z DIODE
D707 MTZJ5.6B-T2 Z DIODE
D708 MTZJ5.6B-T2 Z DIODE
D709 MTZJ5.6B-T2 Z DIODE
D723 MTZJ5.6B-T2 Z DIODE
D810 MTZJ5.6B-T2 Z DIODE
 D901 GSIB460 BRIDGE DIODE
D910 MA700A-T2 SB DIODE
D911 RGP10J-04TS-T3 SI DIODE
D912 RGP10J-04TS-T3 SI DIODE
D913 1SS133-T2 DIODE
D914 1SS133-T2 DIODE
D915 SARS01-T2 SI DIODE
D917 MTZJ30A-T2 Z DIODE
D918 MTZJ5.1C-T2 Z DIODE
D920 1SS133-T2 DIODE
D931 RU4AM-LFT2 SI DIODE
D933 RU3YX-LFC4 SI DIODE
D935 RU3YX-LFC4 SI DIODE
D937 RU3YX-LFC4 SI DIODE
D941 MTZJ33A-T2 Z DIODE
D945 MTZJ9.1B-T2 Z DIODE
D952 1SS133-T2 DIODE
D953 1SS133-T2 DIODE
D954 1N4002G-T2 FR DIODE
D955 1N4002G-T2 FR DIODE
D956 1N4002G-T2 FR DIODE
D957 1N4002G-T2 FR DIODE
D972 MTZJ15C-T2 Z DIODE
D973 1SS133-T2 DIODE
C001 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C003 QETN1HM-106Z E CAPACITOR 10uF 50V M
C004 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C006 QETN1EM-476Z E CAPACITOR 47uF 25V M
C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C104 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C105 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C106 QETN1EM-476Z E CAPACITOR 47uF 25V M
C107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C113 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C114 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C116 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C117 QETN1EM-476Z E CAPACITOR 47uF 25V M
C118 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C119 NDC31HJ-681X C CAPACITOR 680pF 50V J
C120 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C124 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C161 QETN1HM-106Z E CAPACITOR 10uF 50V M
C163 NDC31HJ-470X C CAPACITOR 47pF 50V J
C164 NDC31HJ-470X C CAPACITOR 47pF 50V J
C165 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C166 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C202 QETN1HM-105Z E CAPACITOR 1uF 50V M
C203 NCB31HK-152X C CAPACITOR 1500pF 50V K
C211 QENC1CM-106Z BP E CAPACITOR 10uF 16V M
C212 NDC31HJ-100X C CAPACITOR 10pF 50V J
C221 QETN1HM-106Z E CAPACITOR 10uF 50V M
C222 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C223 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C233 NDC31HJ-680X C CAPACITOR 68pF 50V J
C237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C241 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C242 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C243 QETN1CM-107Z E CAPACITOR 100uF 16V M
C244 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C281 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C282 QETN1CM-107Z E CAPACITOR 100uF 16V M
C283 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C284 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C285 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C286 QETN1HM-106Z E CAPACITOR 10uF 50V M
C287 QETN1CM-107Z E CAPACITOR 100uF 16V M
C288 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C302 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C352 QETN1CM-476Z E CAPACITOR 47uF 16V M
C354 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C391 QETN1CM-107Z E CAPACITOR 100uF 16V M
C392 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C422 QFN32AK-102Z M CAPACITOR 1000pF 100V K
C424 QETN1VM-107Z E CAPACITOR 100uF 35V M
C425 QETN1VM-477Z E CAPACITOR 470uF 35V M
C427 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C428 QETM1EM-228 E CAPACITOR 2200uF 25V M
C431 QFLC2AK-563Z M CAPACITOR 0.056uF 100V K
C432 QETN1EM-476Z E CAPACITOR 47uF 25V M
C433 QETN1EM-476Z E CAPACITOR 47uF 25V M
C435 NCB21HK-183X C CAPACITOR 0.018uF 50V K
C440 QCS32HJ-100Z C CAPACITOR 10pF 500V J
C501 QCB32HK-151Z C CAPACITOR 150pF 500V K
C502 QCB32HK-331Z C CAPACITOR 330pF 500V K
C503 QEHR2CM-105Z E CAPACITOR 1uF 160V M
C504 QEZ0203-107 E CAPACITOR 100uF 160V M
C505 QENC2AM-225Z BP E CAPACITOR 2.2uF 100V M
 Ref No. Part No. Part Name Description Local

1-10 (No.52114B)
C507 QEZ0195-475Z BP E CAPACITOR 4.7uF 50V M
 C510 QFZ0200-382 MPP CAPACITOR 3800pF 1.5kV H
 C513 QFZ0198-133 MPP CAPACITOR 0.013uF 1.5kV H
C514 QFP32GJ-223 PP CAPACITOR 0.022uF 400V J
C515 QFZ0197-474 MPP CAPACITOR 0.47uF 250V J
C516 QCB32HK-561Z C CAPACITOR 560pF 500V K
C521 QETN2EM-106Z E CAPACITOR 10uF 250V M
C523 QEHR1VM-108Z E CAPACITOR 1000uF 35V M
C525 QETN1VM-107Z E CAPACITOR 100uF 35V M
C526 QFV21HJ-824Z MF CAPACITOR 0.82uF 50V J
C527 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C533 QETN1HM-106Z E CAPACITOR 10uF 50V M
C561 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C562 QETN1HM-106Z E CAPACITOR 10uF 50V M
C601 QETN1EM-476Z E CAPACITOR 47uF 25V M
C602 QETN1EM-476Z E CAPACITOR 47uF 25V M
C603 QETN1EM-476Z E CAPACITOR 47uF 25V M
C609 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C610 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C611 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C621 NCB31HK-102X C CAPACITOR 1000pF 50V K
C622 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C623 NCB31HK-102X C CAPACITOR 1000pF 50V K
C624 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C625 QETN1VM-107Z E CAPACITOR 100uF 35V M
C626 QETN1VM-108Z E CAPACITOR 1000uF 35V M
C627 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C628 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C629 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C633 QETN1CM-477Z E CAPACITOR 470uF 16V M
C636 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C637 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C638 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C639 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C641 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C700 NCB31HK-102X C CAPACITOR 1000pF 50V K
C701 QETN1HM-106Z E CAPACITOR 10uF 50V M
C702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C703 QETN1HM-106Z E CAPACITOR 10uF 50V M
C704 QETN1CM-107Z E CAPACITOR 100uF 16V M
C705 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C706 QETN1HM-105Z E CAPACITOR 1uF 50V M
C708 NDC31HJ-220X C CAPACITOR 22pF 50V J
C709 NDC31HJ-220X C CAPACITOR 22pF 50V J
C711 QETN1CM-107Z E CAPACITOR 100uF 16V M
C712 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C716 QETN1HM-106Z E CAPACITOR 10uF 50V M
C728 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C807 QETN1AM-477Z E CAPACITOR 470uF 10V M
C813 NCB31HK-102X C CAPACITOR 1000pF 50V K
C815 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C851 QETN1EM-107Z E CAPACITOR 100uF 25V M
C852 QETN1CM-107Z E CAPACITOR 100uF 16V M
C853 QETN1EM-227Z E CAPACITOR 220uF 25V M
C854 QETN1CM-227Z E CAPACITOR 220uF 16V M
C856 QETN1CM-227Z E CAPACITOR 220uF 16V M
C857 QETN1CM-477Z E CAPACITOR 470uF 16V M
 C901 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
 C902 QFZ9072-473 MM CAPACITOR 0.047uF AC250V K
 C903 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
 C904 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
 C905 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
 C906 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C907 QEZ0644-567 E CAPACITOR 560uF 200V K
 C908 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C912 QCZ0340-222 C CAPACITOR 2200pF 2kV K
C913 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C914 QETN1HM-107Z E CAPACITOR 100uF 50V M
C916 NDC31HJ-331X C CAPACITOR 330pF 50V J
C917 NCB31HK-182X C CAPACITOR 1800pF 50V K
C918 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C919 QFP32GJ-103 PP CAPACITOR 0.01uF 400V J
C931 QEZ0203-227 E CAPACITOR 220uF 160V M
C932 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C933 QETN1EM-228Z E CAPACITOR 2200uF 25V M
C934 NDC31HJ-221X C CAPACITOR 220pF 50V J
C935 QETN1VM-108Z E CAPACITOR 1000uF 35V M
C937 QCZ0340-102 C CAPACITOR 1000pF 2kV K
C938 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C939 QCB32HK-152Z C CAPACITOR 1500pF 500V K
C941 QCB32HK-102Z C CAPACITOR 1000pF 500V K
C942 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C943 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C951 QETN1EM-477Z E CAPACITOR 470uF 25V M
C952 QETN1CM-227Z E CAPACITOR 220uF 16V M
C971 QETN1CM-107Z E CAPACITOR 100uF 16V M
C972 QETN1EM-476Z E CAPACITOR 47uF 25V M
C973 QETN1HM-106Z E CAPACITOR 10uF 50V M
 C997 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 Ref No. Part No. Part Name Description Local
 C998 QCZ9074-103 C CAPACITOR 0.01uF AC250V M
 C999 QCZ9074-103 C CAPACITOR 0.01uF AC250V M
R002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R003 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R004 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R005 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R008 NRSA63J-820X MG RESISTOR 82
Ω 1/16W J
R009 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R101 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R102 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R103 QRE121J-101Y C RESISTOR 100 Ω 1/2W J
R104 NRSA63J-180X MG RESISTOR 18 Ω 1/16W J
R105 NRSA63J-270X MG RESISTOR 27 Ω 1/16W J
R111 NRSA63J-394X MG RESISTOR 390k
Ω 1/16W J
R112 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R113 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R115 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R116 NRSA63J-680X MG RESISTOR 68 Ω 1/16W J
R117 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R118 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R131 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R132 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R133 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R134 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R135 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R161 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R162 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R163 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R164 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R165 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R166 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R167 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R168 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R169 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R171 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R201 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R212 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R215 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R216 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R217 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R222 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R227 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R231 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R237 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R238 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R241 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R243 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R281 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R282 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R283 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R286 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R287 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R288 NRSA02J-471X MG RESISTOR 470 Ω 1/10W J
R289 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R290 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R292 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R293 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R301 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R302 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R303 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R304 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R305 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R306 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R318 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R319 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R352 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R354 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R355 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R356 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R358 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R359 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R360 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R421 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R423 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R424 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R426 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R427 QRT029J-1R2 MF RESISTOR 1.2
Ω 2W J
R428 QRE121J-120Y C RESISTOR 12 Ω 1/2W J
R429 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R430 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R431 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R432 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R433 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R434 QRL029J-221 OMF RESISTOR 220 Ω 2W J
R435 QRE121J-102Y C RESISTOR 1k
Ω 1/2W J
R441 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R447 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R449 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
 Ref No. Part No. Part Name Description Local

(No.52114B)1-11
R501 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R502 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R503 QRE121J-103Y C RESISTOR 10k Ω 1/2W J
R504 QRL039J-152 OMF RESISTOR 1.5k Ω 3W J
R505 QRL039J-152 OMF RESISTOR 1.5k Ω 3W J
R506 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R508 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R509 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R511 QRE121J-220Y C RESISTOR 22
Ω 1/2W J
R512 QRE121J-681Y C RESISTOR 680 Ω 1/2W J
R513 QRL039J-273 OMF RESISTOR 27k Ω 3W J
R515 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R516 QRZ0221-2R0 OMF RESISTOR 2 Ω 7W K
R524 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R526 QRE121J-272Y C RESISTOR 2.7k
Ω 1/2W J
R527 QRE121J-124Y C RESISTOR 120k
Ω 1/2W J
R528 QRE121J-154Y C RESISTOR 150k Ω 1/2W J
R529 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
 R531 QRZ0230-391X UNF C RESISTOR 390 Ω
R532 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R533 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R534 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
 R535 NRVA02D-242X CMF RESISTOR 2.4k Ω 1/10W D
 R537 NRVA02D-752X CMF RESISTOR 7.5k Ω 1/10W D
R538 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R541 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R543 QRE121J-122Y C RESISTOR 1.2k Ω 1/2W J
R544 QRE121J-392Y C RESISTOR 3.9k Ω 1/2W J
R545 QRE121J-822Y C RESISTOR 8.2k Ω 1/2W J
R546 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R547 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R548 QRE121J-152Y C RESISTOR 1.5k Ω 1/2W J
R553 QRL039J-330 OMF RESISTOR 33 Ω 3W J
 R554 QRK126J-150X UNF C RESISTOR 15 Ω 1/2W J
R555 QRT029J-2R2 MF RESISTOR 2.2 Ω 2W J
R561 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R562 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R581 QRE121J-100Y C RESISTOR 10 Ω 1/2W J
R582 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R583 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R584 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R585 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R586 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R587 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R588 QRE121J-100Y C RESISTOR 10 Ω 1/2W J
R589 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R590 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
 R591 QRJ149J-220 UNF C RESISTOR 22 Ω 1/4W J
R592 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R593 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R594 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R595 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R601 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R602 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R603 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R610 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R611 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R612 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R621 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R622 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R623 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R624 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R626 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R627 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R628 QRK126J-102X UNF C RESISTOR 1k
Ω 1/2W J
R629 QRK126J-102X UNF C RESISTOR 1k Ω 1/2W J
R631 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R632 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R633 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R637 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R638 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R639 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R640 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R641 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R644 QRZ0230-2R2X UNF C RESISTOR 2.2
Ω
R645 QRZ0230-2R2X UNF C RESISTOR 2.2 Ω
R647 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R651 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R652 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R653 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R657 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R700 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R701 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R702 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R704 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R705 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R706 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R707 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R708 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R709 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R715 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R718 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R721 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R728 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R729 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R731 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R732 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R733 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R734 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R739 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R740 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R764 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R765 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R766 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R767 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R769 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R772 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R811 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R812 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R816 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R821 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R822 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R827 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R857 QRL029J-820 OMF RESISTOR 82 Ω 2W J
R901 QRF074K-1R2 UNF WW RESISTOR 1.2 Ω 7W K
R909 QRG01GJ-470 OMF RESISTOR 47 Ω 1W J
R911 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R912 QRT029J-R18 MF RESISTOR 0.18 Ω 2W J
R913 QRT029J-R15 MF RESISTOR 0.15 Ω 2W J
 R914 QRK126J-681X UNF C RESISTOR 680 Ω 1/2W J
 R915 QRK129J-6R8 UNF C RESISTOR 6.8 Ω 1/2W J
 R917 QRK126J-332X UNF C RESISTOR 3.3k Ω 1/2W J
R918 QRE121J-222Y C RESISTOR 2.2k Ω 1/2W J
R919 QRE121J-684Y C RESISTOR 680k Ω 1/2W J
R924 QRE121J-222Y C RESISTOR 2.2k Ω 1/2W J
R930 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R939 QRT039J-1R5 MF RESISTOR 1.5 Ω 3W J
R940 QRE121J-181Y C RESISTOR 180 Ω 1/2W J
R941 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R950 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R951 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R952 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R953 QRE121J-820Y C RESISTOR 82 Ω 1/2W J
R972 NRVA02D-102X CMF RESISTOR 1k Ω 1/10W D
R973 NRVA02D-332X CMF RESISTOR 3.3k Ω 1/10W D
R975 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R977 QRE121J-473Y C RESISTOR 47k Ω 1/2W J
R978 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
 R998 QRZ9041-275 C RESISTOR 2.7M Ω 1/2W K
R999 QRE121J-121Y C RESISTOR 120 Ω 1/2W J
L001 QQL244K-560Z COIL 56uH K
L101 QQLZ014-R22 COIL 0.22uH 100mA L
L113 QQL244K-4R7Z COIL 4.7uH K
L131 QQL244K-150Z COIL 15uH K
L161 QQL244K-220Z COIL 22uH K
L232 QQL244K-560Z COIL 56uH K
L241 QQL244K-220Z COIL 22uH K
L391 QQL244K-220Z COIL 22uH K
L511 QQR1027-003 LINEARITY COIL
L512 QQLZ036-821 COIL 820uH K
L521 QQLZ026-830 COIL 83uH
± 7%
L701 QQL244K-220Z COIL 22uH K
L702 QQL244K-220Z COIL 22uH K
L703 QQL244K-220Z COIL 22uH K
L704 QQL244K-220Z COIL 22uH K
L705 QQL244K-220Z COIL 22uH K
L931 QQL26AK-470Z COIL 47uH K
L933 QQL26AK-470Z COIL 47uH K
L937 QQL26AK-470Z COIL 47uH K
L940 QQR0582-001Z FERRITE BEADS
T111 QQR0907-001 IFT
T501 QQR1414-001 DRIVE TRANSF
 T921 QQS0237-001 SW TRANSF
 T951 QQT0355-001 POWER TRANSF
CF001 QAX0349-001 C TRAP 47.25MHz
CF131 QAX0639-001Z C TRAP 4.500MHz
CF161 QAX0642-001Z C FILTER 4.500MHz
CN001 QGB1505J1-35 CONNECTOR B-B (1-35)
CN004 QGA2501C5-07Z CONNECTOR W-B (1-7)
CN005 QGA2501C5-06Z CONNECTOR W-B (1-6)
CN007 QGA2501C5-06Z CONNECTOR W-B (1-6)
CN00C QGA2501F1-06 CONNECTOR W-B (1-6)
CN00Q QGA2501C5-03Z CONNECTOR W-B (1-3)
CN0E1 CE41507-001P LV CONNECTOR
CN0E3 CE41507-001P LV CONNECTOR
CN0HV QGZ5004C1-06 CONNECTOR (1-6)
 Ref No. Part No. Part Name Description Local

1-12 (No.52114B)
DAF P.W. BOARD ASS'Y (SGJ-2505A-M2)
CRT SOCKET P.W. BOARD ASS'Y (SGJ-3510A-M2)
CN0S1 QGA2501C5-05Z CONNECTOR W-B (1-5)
CN0SS QGA2501C5-04Z CONNECTOR W-B (1-4)
 CP932 ICP-N70-T IC PROTECTOR 2.5A
 CP933 ICP-N70-T IC PROTECTOR 2.5A
 CP936 ICP-N70-T IC PROTECTOR 2.5A
 F901 QMF51N1-5R0-J5 FUSE 5A AC125V
 F905 QMFZ049-5R0Z-E FUSE 5A 125V
FC901 CEMG002-001Z FUSE CLIP
FC902 CEMG002-001Z FUSE CLIP
 FR525 QRZ9017-4R7 FUSI RESISTOR 4.7 Ω 1/4W J
 FR527 QRZ9011-470 FUSI RESISTOR 47 Ω 1/2W J
HS001 LC32313-001A HEAT SINK/AL-F/
HS002 LC31678-002A HEAT SINK/AL-F/
HS003 LC32111-002A HEAT SINK/AL-F/
HS004 CEHE015-001WU HEAT SINK
HS005 CM42862-00G-H HEAT SINK ASSY
HS007 CEHT11B-002QS HEAT SINK
J601 QNN0349-002 PIN JACK COMP IN
J810 QNS0001-001 3.5 JACK AV COMPULINK III
K401 QQR0621-002Z FERRITE BEADS
K912 QQR0582-001Z FERRITE BEADS
K916 QQR0582-001Z FERRITE BEADS
K917 QQR0582-001Z FERRITE BEADS
K918 QQR0582-001Z FERRITE BEADS
K920 QQR1139-001 FERRITE BEADS
K931 QQR0582-001Z FERRITE BEADS
K932 QQR0582-001Z FERRITE BEADS
K933 QQR0582-001Z FERRITE BEADS
K935 QQR0582-001Z FERRITE BEADS
K937 QQR0582-001Z FERRITE BEADS
LC601 QQR1199-001 EMI FILTER
LC602 QQR1199-001 EMI FILTER
LC603 QQR1199-001 EMI FILTER
 LF901 QQR1159-001 LINE FILTER
 LF902 QQR0527-004 LINE FILTER
 PC921 PC123Y22 PHOTO COUPLER
 RY951 QSK0085-001 RELAY
S421 QSL4A13-C02 LEVER SWITCH V.CENTER
SF101 QAX0723-001 SAW FILTER
 TH901 QAD0132-3R0 P THERMISTOR 3 Ω
 TU001 QAU0305-001 TUNER
 VA901 ERZV10V621CS ZNR
X701 QAX0767-001Z CRYSTAL 8MHz
 Ref No. Part No. Part Name Description Local
C2701 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
R2701 QRG01GJ-220 OMF RESISTOR 22 Ω 1W J
R2702 QRE121J-123Y C RESISTOR 12k Ω 1/2W J
R2703 QRZ0056-103Z COMP RESISTOR 10k Ω 1/2W K
L2701 QQLZ028-272 COIL 2.7mH
T2701 QQR1153-001 DAF TRANSF
CN200Q WJA0026-001A E-S ID WIRE
CN2DAF CE41507-001P LV CONNECTOR
 Ref No. Part No. Part Name Description Local
Q3103 KTA1267/YG/-T TRANSISTOR
Q3105 KTC3199/YG/-T TRANSISTOR
Q3106 KTA1267/YG/-T TRANSISTOR
Q3107 2SA2005/DE/ POW TRANSISTOR
Q3108 2SC5511/DE/ POW TRANSISTOR
Q3109 KTC3199/YG/-T TRANSISTOR
Q3151 KTC3199/YG/-T TRANSISTOR
Q3152 KTA1267/YG/-T TRANSISTOR
Q3301 2SC5083/L-P/-T TRANSISTOR
Q3302 2SC5083/L-P/-T TRANSISTOR
Q3303 2SC5083/L-P/-T TRANSISTOR
Q3304 2SC5147/CDE/F43 POW TRANSISTOR
Q3305 2SC5147/CDE/F43 POW TRANSISTOR
Q3306 2SC5147/CDE/F43 POW TRANSISTOR
D3101 1SS133-T2 DIODE
D3105 RH1S-T3 SI DIODE
D3106 RH1S-T3 SI DIODE
D3301 1SS133-T2 DIODE
 Ref No. Part No. Part Name Description Local
D3302 1SS133-T2 DIODE
D3303 1SS133-T2 DIODE
D3304 1SS82-T2 SI DIODE
D3305 1SS82-T2 SI DIODE
D3306 1SS82-T2 SI DIODE
D3311 MTZJ3.6B-T2 Z DIODE
D3312 1SS133-T2 DIODE
D3313 MTZJ4.3A-T2 Z DIODE
D3314 1SS133-T2 DIODE
D3331 1SS133-T2 DIODE
D3351 1SS133-T2 DIODE
D3352 1SS133-T2 DIODE
D3353 1SS133-T2 DIODE
D3354 1SS133-T2 DIODE
C3101 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3109 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3110 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3111 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3113 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3114 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3115 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3117 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3118 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C3119 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3120 QETN1AM-337Z E CAPACITOR 330uF 10V M
C3121 QCS32HJ-151Z C CAPACITOR 150pF 500V J
C3122 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C3125 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C3151 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C3152 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C3301 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3302 NDC31HJ-391X C CAPACITOR 390pF 50V J
C3303 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3321 QETN2EM-105Z E CAPACITOR 1uF 250V M
C3322 QETN2EM-105Z E CAPACITOR 1uF 250V M
C3323 QETN1CM-477Z E CAPACITOR 470uF 16V M
C3351 QETN1CM-337Z E CAPACITOR 330uF 16V M
C3363 QCZ0324-102 C CAPACITOR 1000pF 3kV P
R3108 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3111 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R3114 QRZ0230-100X UNF C RESISTOR 10 Ω
R3115 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3116 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3117 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3119 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
 R3122 QRZ9021-561 FUSI RESISTOR 560 Ω 1W J
R3123 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R3124 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R3125 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3126 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R3127 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R3128 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R3129 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3130 NRSA63J-390X MG RESISTOR 39
Ω 1/16W J
R3131 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R3132 QRL029J-391 OMF RESISTOR 390
Ω 2W J
R3134 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3135 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3136 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3139 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R3142 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R3143 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R3145 NRSA63J-5R6X MG RESISTOR 5.6
Ω 1/16W J
R3146 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3151 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R3152 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R3153 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R3154 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R3301 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R3302 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R3303 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R3304 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R3305 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R3306 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R3307 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3308 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R3309 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3310 QRL029J-153 OMF RESISTOR 15k
Ω 2W J
R3311 QRL029J-153 OMF RESISTOR 15k Ω 2W J
R3312 QRL029J-153 OMF RESISTOR 15k
Ω 2W J
R3313 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R3314 QRL029J-183 OMF RESISTOR 18k
Ω 2W J
R3315 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R3316 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3317 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3318 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3325 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
 Ref No. Part No. Part Name Description Local

(No.52114B)1-13
AV SELECTOR P.W. BOARD ASS'Y (SGJ-5505A-M2)
REFER TO PARTS LIST IN PAGE 3-7 FOR THIS P.W. BOARD.
FRONT CONTROL P.W. BOARD ASS'Y (SGJ-6504A-M2)
REFER TO PARTS LIST IN PAGE 3-8 FOR THIS P.W. BOARD.
LED & POWER SW P.W. BOARD ASS'Y (SGJ-7503A-M2)
REFER TO PARTS LIST IN PAGE 3-8FOR THIS P.W. BOARD.
R3326 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3327 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3331 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3332 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3333 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3334 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R3335 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R3336 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3337 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3338 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3351 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3352 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3353 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3354 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R3355 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
L3301 QQL244K-180Z COIL 18uH K
L3302 QQL244K-180Z COIL 18uH K
L3303 QQL244K-180Z COIL 18uH K
L3304 QQL244K-470Z COIL 47uH K
L3305 QQL244K-470Z COIL 47uH K
L3306 QQL244K-470Z COIL 47uH K
CN3004 QJB003-074022 SIN ID C-B WIRE
CN3005 WJA0029-002A E-S ID WIRE
CN300V QGA2501C5-03Z CONNECTOR W-B (1-3)
CN30E2 QUB130-46A6AS SIN TWIST WIRE
CN30E4 QUB130-46A6AS SIN TWIST WIRE
 FR3122 QRZ9021-561 FUSI RESISTOR 560 Ω 1W J
HS3010 CEHP00N-001QS HEAT SINK
HS3011 CEHP00N-001QS HEAT SINK
HS3012 CEHP00N-001QS HEAT SINK
HS3013 CEHP00N-001QS HEAT SINK
HS3014 CEHP00N-001QS HEAT SINK
K3102 QQR1114-001Z FERRITE BEADS
K3103 QQR1114-001Z FERRITE BEADS
K3104 QQR1114-001Z FERRITE BEADS
K3105 QQR1114-001Z FERRITE BEADS
 SK3001 QNZ0634-001 CRT SOCKET
 Ref No. Part No. Part Name Description Local

1-14 (No.52114B)
PRINTED WIRING BOARD PARTS LIST [AV-32FA44/BZA]
MAIN P.W. BOARD ASS'Y (SGJ-1526A-M2)
 Ref No. Part No. Part Name Description Local
IC101 M52342SP IC
IC201 TM8812CSDNG4RR3 IC(MCU)
IC421 LA78041 IC
IC502 CXA1875AM-X IC
IC621 AN5277 IC
IC702 S524A40X41-DCB0 IC (SERVICE)
IC703 S-80840CNY-T IC
IC704 AN78L05-T IC
IC851 L7812CP IC
IC852 L7809CP IC
IC853 L7805CP IC
 IC911 STR-G9626-F3 IC
 IC921 SE135N IC
Q001 UN2212-X DIGI TRANSISTOR
Q101 2SC5083/L-P/-T TRANSISTOR
Q131 2SA1530A/QR/-X SI TRANSISTOR
Q161 2SC3928A/QR/-X SI TRANSISTOR
Q211 2SC3928A/QR/-X SI TRANSISTOR
Q232 2SC3928A/QR/-X SI TRANSISTOR
Q233 2SC3928A/QR/-X SI TRANSISTOR
Q352 2SC3928A/QR/-X SI TRANSISTOR
Q353 2SC3928A/QR/-X SI TRANSISTOR
Q431 UN2212-X DIGI TRANSISTOR
Q501 2SC4212/Z1/ TRANSISTOR
 Q511 2SD2645-YD TRANSISTOR H OUT
Q531 2SC2785/JH/-T SI TRANSISTOR
Q532 2SA1530A/QR/-X SI TRANSISTOR
Q541 2SA1530A/QR/-X SI TRANSISTOR
Q542 2SA1530A/QR/-X SI TRANSISTOR
Q543 2SD1267A/QP/ POW TRANSISTOR
Q622 2SC3928A/QR/-X SI TRANSISTOR
Q623 UN2212-X DIGI TRANSISTOR
Q624 2SA1530A/QR/-X SI TRANSISTOR
Q701 2SA1530A/QR/-X SI TRANSISTOR
Q951 2SD1383K/AB/-X TRANSISTOR
Q971 2SA1208/ST/Z1-T TRANSISTOR
D305 1SS133-T2 DIODE
D306 1SS133-T2 DIODE
D307 1SS133-T2 DIODE
D308 1SS133-T2 DIODE
D309 1SS133-T2 DIODE
D310 1SS133-T2 DIODE
D352 MTZJ9.1C-T2 Z DIODE
D353 1SS133-T2 DIODE
D354 MTZJ3.3A-T2 Z DIODE
D421 1N4003-T2 SI DIODE
D422 MTZJ75-T2 Z DIODE
D432 1SS133-T2 DIODE
D501 RH3G-F1 SI DIODE
D502 RU3AM-LFC4 SI DIODE
D507 RGP10J-04TS-T3 SI DIODE
D521 RH1S-T3 SI DIODE
D523 RGP10J-04TS-T3 SI DIODE
D525 1SS81-T5 SI DIODE
D526 1SS81-T5 SI DIODE
D527 1SR124-400A-T2 SI DIODE
D529 MTZJ9.1C-T2 Z DIODE
 D531 MA4068N/Z1/-T2 Z DIODE
D535 1SS133-T2 DIODE
D537 1SR35-400A-T2 SI DIODE
D601 MTZJ9.1C-T2 Z DIODE
D602 MTZJ9.1C-T2 Z DIODE
D603 MTZJ9.1C-T2 Z DIODE
D621 1SS133-T2 DIODE
D622 1SS133-T2 DIODE
D630 1SS133-T2 DIODE
D633 1SS133-T2 DIODE
D700 MTZJ5.6B-T2 Z DIODE
D701 1SS133-T2 DIODE
D703 MTZJ5.6B-T2 Z DIODE
D704 MTZJ5.6B-T2 Z DIODE
D705 1SS133-T2 DIODE
D706 MTZJ5.6B-T2 Z DIODE
D707 MTZJ5.6B-T2 Z DIODE
D708 MTZJ5.6B-T2 Z DIODE
D709 MTZJ5.6B-T2 Z DIODE
D723 MTZJ5.6B-T2 Z DIODE
D810 MTZJ5.6B-T2 Z DIODE
 D901 GSIB460 BRIDGE DIODE
D910 MA700A-T2 SB DIODE
D911 RGP10J-04TS-T3 SI DIODE
D912 RGP10J-04TS-T3 SI DIODE
D913 1SS133-T2 DIODE
D914 1SS133-T2 DIODE
D915 SARS01-T2 SI DIODE
D917 MTZJ30A-T2 Z DIODE
D918 MTZJ5.1C-T2 Z DIODE
D920 1SS133-T2 DIODE
D931 RU4AM-LFT2 SI DIODE
D933 RU3YX-LFC4 SI DIODE
D935 RU3YX-LFC4 SI DIODE
D937 RU3YX-LFC4 SI DIODE
D941 MTZJ33A-T2 Z DIODE
D945 MTZJ9.1B-T2 Z DIODE
D952 1SS133-T2 DIODE
D953 1SS133-T2 DIODE
D954 1N4002G-T2 FR DIODE
D955 1N4002G-T2 FR DIODE
D956 1N4002G-T2 FR DIODE
D957 1N4002G-T2 FR DIODE
D972 MTZJ15C-T2 Z DIODE
D973 1SS133-T2 DIODE
C001 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C003 QETN1HM-106Z E CAPACITOR 10uF 50V M
C004 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C006 QETN1EM-476Z E CAPACITOR 47uF 25V M
C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C104 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C105 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C106 QETN1EM-476Z E CAPACITOR 47uF 25V M
C107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C113 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C114 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C116 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C117 QETN1EM-476Z E CAPACITOR 47uF 25V M
C118 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C119 NDC31HJ-681X C CAPACITOR 680pF 50V J
C120 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C124 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C161 QETN1HM-106Z E CAPACITOR 10uF 50V M
C163 NDC31HJ-470X C CAPACITOR 47pF 50V J
C164 NDC31HJ-470X C CAPACITOR 47pF 50V J
C165 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C166 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C202 QETN1HM-105Z E CAPACITOR 1uF 50V M
C203 NCB31HK-152X C CAPACITOR 1500pF 50V K
C211 QENC1CM-106Z BP E CAPACITOR 10uF 16V M
C212 NDC31HJ-100X C CAPACITOR 10pF 50V J
C221 QETN1HM-106Z E CAPACITOR 10uF 50V M
C222 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C223 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C233 NDC31HJ-680X C CAPACITOR 68pF 50V J
C237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C241 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C242 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C243 QETN1CM-107Z E CAPACITOR 100uF 16V M
C244 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C281 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C282 QETN1CM-107Z E CAPACITOR 100uF 16V M
C283 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C284 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C285 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C286 QETN1HM-106Z E CAPACITOR 10uF 50V M
C287 QETN1CM-107Z E CAPACITOR 100uF 16V M
C288 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C302 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C352 QETN1CM-476Z E CAPACITOR 47uF 16V M
C354 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C391 QETN1CM-107Z E CAPACITOR 100uF 16V M
C392 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C422 QFN32AK-102Z M CAPACITOR 1000pF 100V K
C424 QETN1VM-107Z E CAPACITOR 100uF 35V M
C425 QETN1VM-477Z E CAPACITOR 470uF 35V M
C427 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C428 QETM1EM-228 E CAPACITOR 2200uF 25V M
C431 QFLC2AK-563Z M CAPACITOR 0.056uF 100V K
C432 QETN1EM-476Z E CAPACITOR 47uF 25V M
C433 QETN1EM-476Z E CAPACITOR 47uF 25V M
C435 NCB21HK-183X C CAPACITOR 0.018uF 50V K
C440 QCS32HJ-100Z C CAPACITOR 10pF 500V J
C501 QCB32HK-151Z C CAPACITOR 150pF 500V K
C502 QCB32HK-331Z C CAPACITOR 330pF 500V K
C503 QEHR2CM-105Z E CAPACITOR 1uF 160V M
C504 QEZ0203-107 E CAPACITOR 100uF 160V M
C505 QENC2AM-225Z BP E CAPACITOR 2.2uF 100V M
 Ref No. Part No. Part Name Description Local

(No.52114B)1-15
C507 QEZ0195-475Z BP E CAPACITOR 4.7uF 50V M
 C510 QFZ0200-422 MPP CAPACITOR 4200pF 1.5kV H
 C513 QFZ0200-822 MPP CAPACITOR 8200pF 1.5kV H
C514 QFP32GJ-273 PP CAPACITOR 0.027uF 400V J
C515 QFZ0197-304 MPP CAPACITOR 0.3uF 250V J
C516 QCB32HK-561Z C CAPACITOR 560pF 500V K
C521 QETN2EM-106Z E CAPACITOR 10uF 250V M
C523 QEHR1VM-108Z E CAPACITOR 1000uF 35V M
C525 QETN1VM-107Z E CAPACITOR 100uF 35V M
C526 QFV21HJ-824Z MF CAPACITOR 0.82uF 50V J
C527 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C533 QETN1HM-106Z E CAPACITOR 10uF 50V M
C561 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C562 QETN1HM-106Z E CAPACITOR 10uF 50V M
C601 QETN1EM-476Z E CAPACITOR 47uF 25V M
C602 QETN1EM-476Z E CAPACITOR 47uF 25V M
C603 QETN1EM-476Z E CAPACITOR 47uF 25V M
C609 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C610 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C611 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C621 NCB31HK-102X C CAPACITOR 1000pF 50V K
C622 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C623 NCB31HK-102X C CAPACITOR 1000pF 50V K
C624 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C625 QETN1VM-107Z E CAPACITOR 100uF 35V M
C626 QETN1VM-108Z E CAPACITOR 1000uF 35V M
C627 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C628 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C629 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C633 QETN1CM-477Z E CAPACITOR 470uF 16V M
C636 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C637 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C638 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C639 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C641 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C700 NCB31HK-102X C CAPACITOR 1000pF 50V K
C701 QETN1HM-106Z E CAPACITOR 10uF 50V M
C702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C703 QETN1HM-106Z E CAPACITOR 10uF 50V M
C704 QETN1CM-107Z E CAPACITOR 100uF 16V M
C705 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C706 QETN1HM-105Z E CAPACITOR 1uF 50V M
C708 NDC31HJ-220X C CAPACITOR 22pF 50V J
C709 NDC31HJ-220X C CAPACITOR 22pF 50V J
C711 QETN1CM-107Z E CAPACITOR 100uF 16V M
C712 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C716 QETN1HM-106Z E CAPACITOR 10uF 50V M
C728 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C807 QETN1AM-477Z E CAPACITOR 470uF 10V M
C813 NCB31HK-102X C CAPACITOR 1000pF 50V K
C815 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C851 QETN1EM-107Z E CAPACITOR 100uF 25V M
C852 QETN1CM-107Z E CAPACITOR 100uF 16V M
C853 QETN1EM-227Z E CAPACITOR 220uF 25V M
C854 QETN1CM-227Z E CAPACITOR 220uF 16V M
C856 QETN1CM-227Z E CAPACITOR 220uF 16V M
C857 QETN1CM-477Z E CAPACITOR 470uF 16V M
 C901 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
 C902 QFZ9072-473 MM CAPACITOR 0.047uF AC250V K
 C903 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
 C904 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
 C905 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
 C906 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C907 QEZ0644-567 E CAPACITOR 560uF 200V K
 C908 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C912 QCZ0340-222 C CAPACITOR 2200pF 2kV K
C913 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C914 QETN1HM-107Z E CAPACITOR 100uF 50V M
C916 NDC31HJ-331X C CAPACITOR 330pF 50V J
C917 NCB31HK-182X C CAPACITOR 1800pF 50V K
C918 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C919 QFP32GJ-103 PP CAPACITOR 0.01uF 400V J
C931 QEZ0203-227 E CAPACITOR 220uF 160V M
C932 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C933 QETN1EM-228Z E CAPACITOR 2200uF 25V M
C934 NDC31HJ-221X C CAPACITOR 220pF 50V J
C935 QETN1VM-108Z E CAPACITOR 1000uF 35V M
C937 QCZ0340-102 C CAPACITOR 1000pF 2kV K
C938 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C939 QCB32HK-152Z C CAPACITOR 1500pF 500V K
C941 QCB32HK-102Z C CAPACITOR 1000pF 500V K
C942 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C943 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C951 QETN1EM-477Z E CAPACITOR 470uF 25V M
C952 QETN1CM-227Z E CAPACITOR 220uF 16V M
C971 QETN1CM-107Z E CAPACITOR 100uF 16V M
C972 QETN1EM-476Z E CAPACITOR 47uF 25V M
C973 QETN1HM-106Z E CAPACITOR 10uF 50V M
 C997 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 Ref No. Part No. Part Name Description Local
 C998 QCZ9074-103 C CAPACITOR 0.01uF AC250V M
 C999 QCZ9074-103 C CAPACITOR 0.01uF AC250V M
R002 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R003 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R004 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R005 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R008 NRSA63J-820X MG RESISTOR 82
Ω 1/16W J
R009 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R101 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R102 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R103 QRE121J-101Y C RESISTOR 100 Ω 1/2W J
R104 NRSA63J-180X MG RESISTOR 18 Ω 1/16W J
R105 NRSA63J-270X MG RESISTOR 27 Ω 1/16W J
R111 NRSA63J-394X MG RESISTOR 390k
Ω 1/16W J
R112 NRSA63J-334X MG RESISTOR 330k
Ω 1/16W J
R113 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R115 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R116 NRSA63J-680X MG RESISTOR 68 Ω 1/16W J
R117 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R118 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R131 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R132 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R133 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R134 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R135 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R161 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R162 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R163 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R164 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R165 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R166 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R167 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R168 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R169 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R171 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R201 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R212 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R215 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R216 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R217 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R222 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R227 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R231 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R237 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R238 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R241 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R243 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R281 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R282 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R283 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R286 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R287 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R288 NRSA02J-471X MG RESISTOR 470 Ω 1/10W J
R289 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R290 NRSA02J-561X MG RESISTOR 560
Ω 1/10W J
R292 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R293 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R301 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R302 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R303 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R304 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R305 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R306 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R318 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R319 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R352 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R354 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R355 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R356 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R358 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R359 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R360 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R421 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R423 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R424 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R426 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R427 QRT029J-1R2 MF RESISTOR 1.2
Ω 2W J
R428 QRE121J-120Y C RESISTOR 12 Ω 1/2W J
R429 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R430 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R431 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R432 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R433 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R434 QRL029J-221 OMF RESISTOR 220 Ω 2W J
R435 QRE121J-821Y C RESISTOR 820
Ω 1/2W J
R441 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R447 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R449 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
 Ref No. Part No. Part Name Description Local

1-16 (No.52114B)
R456 QRE121J-821Y C RESISTOR 820 Ω 1/2W J
R501 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R502 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R503 QRE121J-103Y C RESISTOR 10k Ω 1/2W J
R504 QRL039J-152 OMF RESISTOR 1.5k Ω 3W J
R505 QRL039J-152 OMF RESISTOR 1.5k Ω 3W J
R506 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R508 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R509 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R511 QRE121J-220Y C RESISTOR 22 Ω 1/2W J
R512 QRE121J-681Y C RESISTOR 680 Ω 1/2W J
R513 QRL039J-273 OMF RESISTOR 27k Ω 3W J
R515 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R516 QRZ0221-2R0 OMF RESISTOR 2 Ω 7W K
R524 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R526 QRE121J-272Y C RESISTOR 2.7k
Ω 1/2W J
R527 QRE121J-184Y C RESISTOR 180k Ω 1/2W J
R528 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R529 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
 R531 QRZ0230-391X UNF C RESISTOR 390 Ω
R532 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R533 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R534 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
 R535 NRVA02D-242X CMF RESISTOR 2.4k Ω 1/10W D
 R537 NRVA02D-752X CMF RESISTOR 7.5k Ω 1/10W D
R538 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R541 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R543 QRE121J-122Y C RESISTOR 1.2k Ω 1/2W J
R544 QRE121J-392Y C RESISTOR 3.9k Ω 1/2W J
R545 QRE121J-153Y C RESISTOR 15k Ω 1/2W J
R546 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R547 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R548 QRE121J-152Y C RESISTOR 1.5k Ω 1/2W J
R553 QRL039J-330 OMF RESISTOR 33 Ω 3W J
 R554 QRK126J-150X UNF C RESISTOR 15 Ω 1/2W J
R555 QRT029J-2R2 MF RESISTOR 2.2 Ω 2W J
R561 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R562 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R581 QRE121J-100Y C RESISTOR 10 Ω 1/2W J
R582 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R583 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R584 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R585 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R586 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R587 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R588 QRE121J-100Y C RESISTOR 10 Ω 1/2W J
R589 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R590 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
 R591 QRJ149J-220 UNF C RESISTOR 22 Ω 1/4W J
R592 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R593 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R594 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R595 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R601 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R602 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R603 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R610 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R611 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R612 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R621 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R622 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R623 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R624 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R626 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R627 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R628 QRK126J-102X UNF C RESISTOR 1k Ω 1/2W J
R629 QRK126J-102X UNF C RESISTOR 1k
Ω 1/2W J
R631 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R632 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R633 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R637 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R638 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R639 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R640 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R641 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R644 QRZ0230-2R2X UNF C RESISTOR 2.2
Ω
R645 QRZ0230-2R2X UNF C RESISTOR 2.2 Ω
R647 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R651 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R652 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R653 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R657 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R700 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R701 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R702 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R704 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R705 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R706 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R707 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R708 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R709 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R715 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R718 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R721 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R728 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R729 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R731 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R732 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R733 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R734 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R739 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R740 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R764 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R765 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R766 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R767 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R769 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R772 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R811 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R812 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R816 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R821 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R822 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R827 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R857 QRL029J-820 OMF RESISTOR 82 Ω 2W J
R901 QRF074K-1R2 UNF WW RESISTOR 1.2 Ω 7W K
R909 QRG01GJ-470 OMF RESISTOR 47 Ω 1W J
R911 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R912 QRT029J-R18 MF RESISTOR 0.18 Ω 2W J
R913 QRT029J-R15 MF RESISTOR 0.15 Ω 2W J
 R914 QRK126J-681X UNF C RESISTOR 680 Ω 1/2W J
 R915 QRK129J-6R8 UNF C RESISTOR 6.8 Ω 1/2W J
 R917 QRK126J-332X UNF C RESISTOR 3.3k Ω 1/2W J
R918 QRE121J-222Y C RESISTOR 2.2k Ω 1/2W J
R919 QRE121J-684Y C RESISTOR 680k Ω 1/2W J
R924 QRE121J-222Y C RESISTOR 2.2k Ω 1/2W J
R930 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R939 QRT039J-1R5 MF RESISTOR 1.5 Ω 3W J
R940 QRE121J-181Y C RESISTOR 180 Ω 1/2W J
R941 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R950 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R951 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R952 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R953 QRE121J-820Y C RESISTOR 82 Ω 1/2W J
R972 NRVA02D-102X CMF RESISTOR 1k Ω 1/10W D
R973 NRVA02D-332X CMF RESISTOR 3.3k Ω 1/10W D
R975 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R977 QRE121J-473Y C RESISTOR 47k Ω 1/2W J
R978 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
 R998 QRZ9041-275 C RESISTOR 2.7M Ω 1/2W K
R999 QRE121J-121Y C RESISTOR 120 Ω 1/2W J
L001 QQL244K-560Z COIL 56uH K
L101 QQLZ014-R22 COIL 0.22uH 100mA L
L113 QQL244K-4R7Z COIL 4.7uH K
L131 QQL244K-150Z COIL 15uH K
L161 QQL244K-220Z COIL 22uH K
L232 QQL244K-560Z COIL 56uH K
L241 QQL244K-220Z COIL 22uH K
L391 QQL244K-220Z COIL 22uH K
L511 QQR1409-002 LINEARITY COIL
L512 QQLZ028-501 COIL 500uH
L521 QQR1333-001 CHOKE COIL
L701 QQL244K-220Z COIL 22uH K
L702 QQL244K-220Z COIL 22uH K
L703 QQL244K-220Z COIL 22uH K
L704 QQL244K-220Z COIL 22uH K
L705 QQL244K-220Z COIL 22uH K
L931 QQL26AK-470Z COIL 47uH K
L933 QQL26AK-470Z COIL 47uH K
L937 QQL26AK-470Z COIL 47uH K
L940 QQR0582-001Z FERRITE BEADS
T111 QQR0907-001 IFT
T501 QQR1414-001 DRIVE TRANSF
 T921 QQS0237-001 SW TRANSF
 T951 QQT0355-001 POWER TRANSF
CF001 QAX0349-001 C TRAP 47.25MHz
CF131 QAX0639-001Z C TRAP 4.500MHz
CF161 QAX0642-001Z C FILTER 4.500MHz
CN001 QGB1505J1-35 CONNECTOR B-B (1-35)
CN004 QGA2501C5-07Z CONNECTOR W-B (1-7)
CN005 QGA2501C5-06Z CONNECTOR W-B (1-6)
CN007 QGA2501C5-06Z CONNECTOR W-B (1-6)
CN00C QGA2501F1-06 CONNECTOR W-B (1-6)
CN00Q QGA2501C5-03Z CONNECTOR W-B (1-3)
CN0E1 CE41507-001P LV CONNECTOR
CN0E3 CE41507-001P LV CONNECTOR
 Ref No. Part No. Part Name Description Local

(No.52114B)1-17
DAF P.W. BOARD ASS'Y (SGJ-2504A-M2)
CRT SOCKET P.W. BOARD ASS'Y (SGJ-3508A-M2)
CN0HV QGZ5004C1-06 CONNECTOR (1-6)
CN0S1 QGA2501C5-05Z CONNECTOR W-B (1-5)
CN0SS QGA2501C5-04Z CONNECTOR W-B (1-4)
 CP932 ICP-N70-T IC PROTECTOR 2.5A
 CP933 ICP-N70-T IC PROTECTOR 2.5A
 CP936 ICP-N70-T IC PROTECTOR 2.5A
 F901 QMF51N1-5R0-J5 FUSE 5A AC125V
 F905 QMFZ049-5R0Z-E FUSE 5A 125V
FC901 CEMG002-001Z FUSE CLIP
FC902 CEMG002-001Z FUSE CLIP
 FR525 QRZ9017-4R7 FUSI RESISTOR 4.7 Ω 1/4W J
 FR527 QRZ9011-470 FUSI RESISTOR 47 Ω 1/2W J
HS001 LC32313-001A HEAT SINK/AL-F/
HS002 LC31678-002A HEAT SINK/AL-F/
HS003 LC32111-002A HEAT SINK/AL-F/
HS004 CEHE015-001WU HEAT SINK
HS005 CM42862-00G-H HEAT SINK ASSY
HS007 CEHT11B-002QS HEAT SINK
J601 QNN0349-002 PIN JACK COMP IN
J810 QNS0001-001 3.5 JACK AV COMPULINK III
K401 QQR0621-002Z FERRITE BEADS
K912 QQR0582-001Z FERRITE BEADS
K916 QQR0582-001Z FERRITE BEADS
K917 QQR0582-001Z FERRITE BEADS
K918 QQR0582-001Z FERRITE BEADS
K920 QQR1139-001 FERRITE BEADS
K931 QQR0582-001Z FERRITE BEADS
K932 QQR0582-001Z FERRITE BEADS
K933 QQR0582-001Z FERRITE BEADS
K935 QQR0582-001Z FERRITE BEADS
K937 QQR0582-001Z FERRITE BEADS
LC601 QQR1199-001 EMI FILTER
LC602 QQR1199-001 EMI FILTER
LC603 QQR1199-001 EMI FILTER
 LF901 QQR1159-001 LINE FILTER
 LF902 QQR0527-004 LINE FILTER
 PC921 PC123Y22 PHOTO COUPLER
 RY951 QSK0085-001 RELAY
S421 QSL4A13-C02 LEVER SWITCH V.CENTER
SF101 QAX0723-001 SAW FILTER
 TH901 QAD0132-3R0 P THERMISTOR 3 Ω
 TU001 QAU0305-001 TUNER
 VA901 ERZV10V621CS ZNR
X701 QAX0767-001Z CRYSTAL 8MHz
 Ref No. Part No. Part Name Description Local
C2701 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
R2701 QRG01GJ-220 OMF RESISTOR 22 Ω 1W J
R2702 QRE121J-123Y C RESISTOR 12k Ω 1/2W J
R2703 QRZ0056-103Z COMP RESISTOR 10k
Ω 1/2W K
L2701 QQLZ028-272 COIL 2.7mH
T2701 QQR1153-001 DAF TRANSF
CN200Q WJA0026-001A E-S ID WIRE
CN2DAF CE41507-001P LV CONNECTOR
 Ref No. Part No. Part Name Description Local
Q3103 KTA1267/YG/-T TRANSISTOR
Q3105 KTC3199/YG/-T TRANSISTOR
Q3106 KTA1267/YG/-T TRANSISTOR
Q3107 2SA2005/DE/ POW TRANSISTOR
Q3108 2SC5511/DE/ POW TRANSISTOR
Q3109 KTC3199/YG/-T TRANSISTOR
Q3151 KTC3199/YG/-T TRANSISTOR
Q3152 KTA1267/YG/-T TRANSISTOR
Q3301 2SC5083/L-P/-T TRANSISTOR
Q3302 2SC5083/L-P/-T TRANSISTOR
Q3303 2SC5083/L-P/-T TRANSISTOR
Q3304 2SC5147/CDE/F43 POW TRANSISTOR
Q3305 2SC5147/CDE/F43 POW TRANSISTOR
Q3306 2SC5147/CDE/F43 POW TRANSISTOR
D3101 1SS133-T2 DIODE
D3105 RH1S-T3 SI DIODE
D3106 RH1S-T3 SI DIODE
 Ref No. Part No. Part Name Description Local
D3301 1SS133-T2 DIODE
D3302 1SS133-T2 DIODE
D3303 1SS133-T2 DIODE
D3304 1SS82-T2 SI DIODE
D3305 1SS82-T2 SI DIODE
D3306 1SS82-T2 SI DIODE
D3311 MTZJ3.6B-T2 Z DIODE
D3312 1SS133-T2 DIODE
D3313 MTZJ4.3A-T2 Z DIODE
D3314 1SS133-T2 DIODE
D3331 1SS133-T2 DIODE
D3351 1SS133-T2 DIODE
D3352 1SS133-T2 DIODE
D3353 1SS133-T2 DIODE
D3354 1SS133-T2 DIODE
C3101 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3109 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3110 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3111 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3113 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3114 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3115 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3117 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3118 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C3119 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3120 QETN1AM-337Z E CAPACITOR 330uF 10V M
C3121 QCS32HJ-151Z C CAPACITOR 150pF 500V J
C3122 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C3125 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C3151 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C3152 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C3301 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3302 NDC31HJ-391X C CAPACITOR 390pF 50V J
C3303 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3321 QETN2EM-105Z E CAPACITOR 1uF 250V M
C3322 QETN2EM-105Z E CAPACITOR 1uF 250V M
C3323 QETN1CM-477Z E CAPACITOR 470uF 16V M
C3351 QETN1CM-337Z E CAPACITOR 330uF 16V M
C3363 QCZ0324-102 C CAPACITOR 1000pF 3kV P
R3108 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3111 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R3114 QRZ0230-100X UNF C RESISTOR 10 Ω
R3115 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3116 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3117 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3119 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
 R3122 QRZ9021-561 FUSI RESISTOR 560 Ω 1W J
R3123 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R3124 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R3125 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3126 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R3127 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R3128 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R3129 NRSA63J-5R6X MG RESISTOR 5.6
Ω 1/16W J
R3130 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R3131 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R3132 QRL029J-391 OMF RESISTOR 390 Ω 2W J
R3134 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R3135 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3136 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3139 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R3142 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R3143 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R3145 NRSA63J-5R6X MG RESISTOR 5.6 Ω 1/16W J
R3146 NRSA63J-5R6X MG RESISTOR 5.6
Ω 1/16W J
R3151 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R3152 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R3153 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R3154 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R3301 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R3302 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R3303 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R3304 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R3305 NRSA63J-121X MG RESISTOR 120
Ω 1/16W J
R3306 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R3307 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R3308 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3309 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R3310 QRL029J-153 OMF RESISTOR 15k Ω 2W J
R3311 QRL029J-153 OMF RESISTOR 15k
Ω 2W J
R3312 QRL029J-153 OMF RESISTOR 15k Ω 2W J
R3313 QRL029J-183 OMF RESISTOR 18k
Ω 2W J
R3314 QRL029J-183 OMF RESISTOR 18k Ω 2W J
R3315 QRL029J-183 OMF RESISTOR 18k
Ω 2W J
R3316 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3317 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3318 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
 Ref No. Part No. Part Name Description Local

1-18 (No.52114B)
AV SELECTOR P.W. BOARD ASS'Y (SGJ-5505A-M2)
REFER TO PARTS LIST IN PAGE 3-7 FOR THIS P.W. BOARD.
FRONT CONTROL P.W. BOARD ASS'Y (SGJ-6504A-M2)
REFER TO PARTS LIST IN PAGE 3-8 FOR THIS P.W. BOARD.
LED & POWER SW P.W. BOARD ASS'Y (SGJ-7503A-M2)
REFER TO PARTS LIST IN PAGE 3-8FOR THIS P.W. BOARD.
R3325 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3326 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3327 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3331 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3332 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3333 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3334 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R3335 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R3336 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3337 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3338 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3351 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3352 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3353 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3354 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R3355 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
L3301 QQL244K-180Z COIL 18uH K
L3302 QQL244K-180Z COIL 18uH K
L3303 QQL244K-180Z COIL 18uH K
L3304 QQL244K-470Z COIL 47uH K
L3305 QQL244K-470Z COIL 47uH K
L3306 QQL244K-470Z COIL 47uH K
CN3004 QJB003-074022 SIN ID C-B WIRE
CN3005 WJA0029-002A E-S ID WIRE
CN300V QGA2501C5-03Z CONNECTOR W-B (1-3)
CN30E2 QUB130-46A6AS SIN TWIST WIRE
CN30E4 QUB130-46A6AS SIN TWIST WIRE
 FR3122 QRZ9021-561 FUSI RESISTOR 560 Ω 1W J
HS3010 CEHP00N-001QS HEAT SINK
HS3011 CEHP00N-001QS HEAT SINK
HS3012 CEHP00N-001QS HEAT SINK
HS3013 CEHP00N-001QS HEAT SINK
HS3014 CEHP00N-001QS HEAT SINK
K3102 QQR1114-001Z FERRITE BEADS
K3103 QQR1114-001Z FERRITE BEADS
K3104 QQR1114-001Z FERRITE BEADS
K3105 QQR1114-001Z FERRITE BEADS
 SK3001 QNZ0634-001 CRT SOCKET
 Ref No. Part No. Part Name Description Local

(No.52114B)
AV & MULTIMEDIA COMPANY VIDEO DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
VICTOR COMPANY OF JAPAN, LIMITED
WPC
Printed in Japan

COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED No.52114
2003/6
COLOR TELEVISION
5211420036
AV-27FA44/ASA, AV-27FA44/AZA,
AV-32FA44/AYA, AV-32FA44/AZA,
AV-36FA44/AYA
ASPECT LIGHT
INPUT
SOUND
C.C.
RM-C1251G
V.STATUS
BASIC CHASSIS
GJ2
CD-ROM No.SML200307
SCHEMATIC DIAGRAMS
