No.52086

AV-28BH8ENS / AV-28BH8ENB

AV-28BH8EPS / AV-28BH8EPB

AV-28BH8EES / AV-28BH8EEB

AV-28BH88EN

Sep. 2002

AV-28BH8ENS / AV-28BH8ENB

AV-28BH8EPS / AV-28BH8EPB

AV-28BH8EES / AV-28BH8EEB

AV-28BH88EN

■OUTLINE

CONTENTS

!MAIN DIFFERENCE LIST ････････････････････････････････

････････････････････････････････････････････････････････････････

･･･････････････････････････････････････････････････････

･･････････････････････････････････････････････

･･･････････････････････ 2

!PARTS LIST ････････････････････････････････

････････････････････････････････････････････････････････････････

･･････････････････････････････････

････

･･ 3

SERVICE MANUAL

COLOUR TELEVISION

The following item for the AV-28BH8 series models were changed partly from AV28BH7 series

models.

Therefore, this service manual describes only the parts list of the AV28BH7 series models.

For details other than those described in this manual, please refer to the AV28BH7 series model

service manual (No.51967, Apr. 2002).

Since the black mute for PR(channel) was changed (AV-28BH8 series) and the 3D PANORAMA was

added (AV-28BH88EN), we have issued this service manual.

No. 52086

V-28BH8ENS / AV-28BH8ENB

V-28BH8EPS / AV-28BH8EPB

V-28BH8EES / AV-28BH8EEB

V-28BH88EN

MAIN DIFFERENCE LIST

Parts No.

!Parts name

AV-28BH8ENS

AV-28BH8EPS

AV-28BH8EES

AV-28BH88EN

AV-28BH8ENB

AV-28BH8EPB

AV-28BH8EEB

!MAIN PWB

VE-20106737 [ENS]

VE-20106734 [EPS]

VE-20106738 [EES]

VE-20105619

VE-20106737 [ENB]

VE-20106734 [EPB]

VE-20106738 [EEB]

!BUTTON ON/OFF VE-20083491 ←VE-20069016

!FRONT PANEL (LENS) VE-20069218 VE-20096162 VE-20069218

!FRONT CABINET VE-20082289 ←VE-20069020

!FUNCTION BUTTON VE-20083502 ←VE-20069014

!FRONT AV DOOR VE-20086219 ←VE-20069213

!BACK COVER VE-20084616 ←VE-20069018

!BACK DOOR VE-20087523 ←VE-20040684

LOGO JVC VE-40009154 ←VE-40009152

!LABEL

(RATING / SERIAL)

VE-20109955 [ENS]

VE-20107839 [ENS (for Italy)]

VE-20107846 [EPS]

VE-20110102 [EES]

VE-20107830 [EES (for Poland)]

VE-20103714

VE-20109962 [ENB]

VE-20107843 [EPB]

VE-20110867 [EEB]

VE-20107826 [EEB (for Poland)]

!WARNING LABEL VE-50020786 [EES only] ×VE-50020786 [EEB only]

CARTON BOX

VE-50031251 [ENS]

VE-50030576 [ENS (for Italy)]

VE-50030581 [EPS]

VE-50031341 [EES]

VE-50030521 [EES (for Poland)]

VE-50028963

VE-50031318 [ENB]

VE-50030579 [EPB]

VE-50031617 [EEB]

VE-50030519 [EEB (for Poland)]

!INST BOOK

VE-50030573 [ENS]

VE-50030578 [EPS]

VE-50030518 [EES]

VE-50028965

VE-50030573 [ENB]

VE-50030578 [EPB]

VE-50030518 [EEB]

No. 52086

V-28BH8ENS / AV-28BH8ENB

V-28BH8EPS / AV-28BH8EPB

V-28BH8EES / AV-28BH8EEB

V-28BH88EN

PARTS LIST

CONTENTS

!USING P.W. BOARD & REMOTE CONTROL UNIT ･･････････････････････････････････････････････････････ 3

!EXPLODED VIEW PARTS LIST ･･･････････････････････････････････････････････････････････････････････････ 4

!EXPLODED VIEW ･････････････････････････････････････････････････････････････････････････････････････････ 5

!PRINTED WIRING BOARD PARTS LIST

"MAIN P.W . BOARD ASS'Y･･････････････････････････････････････････････････････････････････････････････････････ 6

"MULTISOUND P.W. BOARD ASS’Y (Common to all models) ･･･････････････････････････････････････････････････････10

"FEATURE BOX P.W. BOARD ASS’Y (Common to all models) ･･････････････････････････････････････････････････････ 11

"CRT SOCKET P.W. BOARD ASS'Y (Common to all models)････････････････････････････････････････････････････････13

"FRONT CONTROL P.W. BOARD ASS’Y (Common to all models) ･･･････････････････････････････････････････････････ 14

"FRONT AV & HEADPHONE P.W. BOARD ASS’Y (Common to all models)････････････････････････････････････････････14

"MAIN P.W . BOARD ASS'Y･････････････････････････････････････････････････････････････････････････････････････ 15

"MAIN P.W . BOARD ASS'Y･････････････････････････････････････････････････････････････････････････････････････ 19

"MAIN P.W . BOARD ASS'Y･････････････････････････････････････････････････････････････････････････････････････ 23

!PACKING / PACKING PARTS LIST ･･････････････････････････････････････････････････････････････････････27

USING P.W. BOARD & REMOTE CONTROL UNIT

Model

PWB ASS'Y

AV-28BH8ENS

AV-28BH8ENB

AV-28BH8EPS

AV-28BH8EPB

AV-28BH8EES

AV-28BH8EEB AV-28BH88EN

MAIN PWB VE-20106737 VE-20106734 VE-20106738 VE-20105619

MULTISOUND PWB VE-20103705

FEATURE BOX PWB VE-20055386

CRT SOCKET PWB VE-20086313

FRONT CONTROL PWB VE-20082481

FRONT AV & HEADPHONE

PWB VE-20083091

REMOTE CONTROL UNIT VE-30015781

(RM-C85)

[ AV-28BH8EES / AV-28BH8EEB ]

[ AV-28BH8ENS / AV-28BH8ENB ]

[ AV-28BH8EPS / AV-28BH8EPB ]

[ AV-28BH88EN ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

V-28BH8EPS / AV-28BH8EPB

V-28BH8EES / AV-28BH8EEB

V-28BH88EN

EXPLODED VIEW PARTS LIST

!Ref.No. Part No. Part Name Description

!V01 VE-30002754 PICTURE TUBE

!L01 VE-30002728 DEG.COIL & EARTH

!TR202 VE-30016922 FBT (within MAIN PWB)

!1 VE-20083491 BUTTON ON/OFF

2 VE-35004544 SPRING

!3 VE-20069218 FRONT PANEL (LENS) [AV-28BH8ENS,EPS,EES]

!3 VE-20096162 FRONT PANEL (LENS) [AV-28BH88EN]

!4 VE-20082289 FRONT CABINET

!5 VE-20083502 FUNCTION BUTTON

!6 VE-20086219 FRONT AV DOOR

!7 VE-20003605 PIN (FRONT AV DOOR) (X2)

!8 VE-40000026 EJECTOR

!9 VE-20078776 LENS LED

!10 VE-20004339 LENS PRE-AMP

11 VE-30001946 SPEAKER (57x160mm) (X2)

12 VE-30001947 TWEETER (CLOSED) (X2)

!13 VE-20081578 BASE

!14 VE-20069012 CHASSIS FRAME

!15 VE-20084616 BACK COVER

!16 VE-20087523 BACK DOOR

17 VE-35004572 SCREW (X8)

18 VE-35000211 SCREW (X4)

19 VE-40009154 LOGO JVC

!20 VE-30002174 MAIN SWITCH(ON/OFF)

!21 VE-20109955 LABEL [AV-28BH8ENS]

!21 VE-20107839 LABEL [AV-28BH8ENS(for Italy)]

!21 VE-20107846 LABEL [AV-28BH8EPS]

!21 VE-20110102 LABEL [AV-28BH8EES]

!21 VE-20107830 LABEL [AV-28BH8EES(for Poland)]

!21 VE-20103714 LABEL [AV-28BH88EN]

!-- VE-30002385 POWER CORD

!-- VE-30002368 AC CABLE

!-- VE-50020786 WARNING LABEL [AV-28BH8EES only]

!Ref.No. Part No. Part Name Description

!V01 VE-30002754 PICTURE TUBE

!L01 VE-30002728 DEG.COIL & EARTH

!TR202 VE-30016922 FBT (within MAIN PWB)

!1 VE-20069016 BUTTON ON/OFF

2 VE-35004544 SPRING

!3 VE-20069218 FRONT PANEL (LENS) [AV-28BH8ENB,EPB,EEB]

!4 VE-20069020 FRONT CABINET

!5 VE-20069014 FUNCTION BUTTON

!6 VE-20069213 FRONT AV DOOR

!7 VE-20003605 PIN (FRONT AV DOOR) (X2)

!8 VE-40000026 EJECTOR

!9 VE-20078776 LENS LED

!10 VE-20004339 LENS PRE-AMP

11 VE-30001946 SPEAKER (57x160mm) (X2)

12 VE-30001947 TWEETER (CLOSED) (X2)

!13 VE-20081578 BASE

!14 VE-20069012 CHASSIS FRAME

!15 VE-20069018 BACK COVER

!16 VE-20040684 BACK DOOR

17 VE-35004572 SCREW (X8)

18 VE-35000211 SCREW (X4)

19 VE-40009152 LOGO JVC

!20 VE-30002174 MAIN SWITCH(ON/OFF)

!21 VE-20109962 LABEL [AV-28BH8ENB]

!21 VE-20107843 LABEL [AV-28BH8EPB]

!21 VE-20110867 LABEL [AV-28BH8EEB]

!21 VE-20107826 LABEL [AV-28BH8EEB(for Poland)]

!-- VE-30002385 POWER CORD

!-- VE-30002368 AC CABLE

!-- VE-50020786 WARNING LABEL [AV-28BH8EEB only]

[ SILVER model : AV-28BH8ENS, AV-28BH8EPS, AV-28BH8EES, AV-28BH88EN ]

[ BLACK model : AV-28BH8ENB, AV-28BH8EPB, AV-28BH8EEB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

V-28BH8EPS / AV-28BH8EPB

V-28BH8EES / AV-28BH8EEB

V-28BH88EN

EXPLODED VIEW

MAIN PWB

V01

FRONT AV &

HEADPHONE

PWB

FRONT

CONTROL

PWB

TR202

L01

No. 52086

V-28BH8ENS / AV-28BH8ENB

PRINTED WIRING BOARD PARTS LIST

MAIN P.W. BOARD ASS’Y (VE-20106737)

!Symbol No. Part No. Part Name Description

VARIABLE RESISTOR

VR127 VE-30001041 ADJ RES. 1/6W 1K M VER

RESISTOR

R101 VE-30000668 SMD RES. 1/10W 33K J

R102 VE-30007782 MF RES. 1/4W 3.9M F

R103 VE-30000855 MF RES. 1/4W 1M F

R104 VE-30000668 SMD RES. 1/10W 33K J

R105 VE-30000452 CF RES. 1/4W 10R J

R106 VE-30000664 SMD RES. 1/10W 3.3K J

R107 VE-30007019 SMD RES. 1/10W 10K F

R108 VE-30007784 MO RES. 5W 33K J(RADIAL)

!R109 VE-30001270 PTC 9 OHM

R116 VE-30001171 MO RES. 2W 4.7K J

!R117 VE-30001257 MG RES. 1/2W 4.7M J

!R118 VE-30009036 FUSE RES. 1/2W 0.1R J

!R119 VE-30009036 FUSE RES. 1/2W 0.1R J

R120 VE-30000814 SMD RES. 1/10W 820R J

R122 VE-30000469 SMD RES. 1/10W 1K J

R123 VE-30000469 SMD RES. 1/10W 1K J

R124 VE-30000480 SMD RES. 1/10W 100K J

R125 VE-30000927 MF RES. 1/4W 220K J

R126 VE-30000664 SMD RES. 1/10W 3.3K J

R127 VE-30000469 SMD RES. 1/10W 1K J

R128 VE-30000536 CF RES. 1/4W 150K J

R129 VE-30007019 SMD RES. 1/10W 10K F

R130 VE-30000721 SMD RES. 1/10W 4.7K J

R134 VE-30000469 SMD RES. 1/10W 1K J

R135 VE-30007790 SMD RES. 1/10W 4.3K F

R136 VE-30000774 SMD RES. 1/10W 680R J

R137 VE-30007021 SMD RES. 1/10W 1K F

R138 VE-30007786 SMD RES. 1/10W 2.55K F

R139 VE-30000774 SMD RES. 1/10W 680R J

R140 VE-30000459 CF RES. 1/4W 100R J

R141 VE-30000475 SMD RES. 1/10W 10K J

R142 VE-30000475 SMD RES. 1/10W 10K J

R143 VE-30007021 SMD RES. 1/10W 1K F

R144 VE-30007788 SMD RES. 1/10W 2.7K F

R145 VE-30000732 SMD RES. 1/10W 470K J

R146 VE-30000469 SMD RES. 1/10W 1K J

!R148 VE-30014023 FUSE RES. 1/2W 0.1R J VISHAY

R149 VE-30007204 MF RES. 1/2W 1.5M F

!R150 VE-30007783 FUSE RES. 1/4W 2.2R J

!R151 VE-30014023 FUSE RES. 1/2W 0.1R J VISHAY

R152 VE-30000659 SMD RES. 1/10W 330R J

R153 VE-30012649 SMD RES. 1/16W 150R J

R154 VE-30012984 SMD RES. 1/16W 91R J

R155 VE-30000712 CF RES. 1/4W 470R J

R156 VE-30001089 MO RES. 2W 1R J

R157 VE-30000534 SMD RES. 1/10W 15K J

R158 VE-30000475 SMD RES. 1/10W 10K J

R159 VE-30000480 SMD RES. 1/10W 100K J

R160 VE-30006923 SMD RES. 1/10W 4.3K J

R202 VE-30007779 MO RES. 5W 47R J(RADIAL)

R203 VE-30000631 SMD RES. 1/10W 2.7K J

R205 VE-30017136 MO RES. 1W 0.56R J

R206 VE-30001080 MO RES. 2W 100R J

R210 VE-30000583 CF RES. 1/4W 220R J

R211 VE-30000721 SMD RES. 1/10W 4.7K J

R212 VE-30000593 SMD RES. 1/10W 2.2K J

R213 VE-30000593 SMD RES. 1/10W 2.2K J

R214 VE-30000593 SMD RES. 1/10W 2.2K J

R215 VE-30000721 SMD RES. 1/10W 4.7K J

R216 VE-30000631 SMD RES. 1/10W 2.7K J

R217 VE-30000593 SMD RES. 1/10W 2.2K J

R218 VE-30000480 SMD RES. 1/10W 100K J

R220 VE-30000590 CF RES. 1/4W 2.2K J

R225 VE-30001086 MO RES. 2W 10K J

R226 VE-30001168 MO RES. 2W 470RJ

R227 VE-30000469 SMD RES. 1/10W 1K J

R228 VE-30000475 SMD RES. 1/10W 10K J

R229 VE-30000727 SMD RES. 1/10W 47K J

R230 VE-30000902 MF RES. 1/4W 1.8K F

!R231 VE-30001229 FUSE RES. 1W 2.2R J

R232 VE-30001027 MF RES. 1/4W 82K J

!R233 VE-30001244 FUSE RES. 1/2W 0.47R J

!R234 VE-30009036 FUSE RES. 1/2W 0.1R J

R235 VE-30000668 SMD RES. 1/10W 33K J

R236 VE-30000718 CF RES. 1/4W 4.7K J

!Symbol No. Part No. Part Name Description

RESISTOR

!R237 VE-30001244 FUSE RES. 1/2W 0.47R J

R238 VE-30000729 CF RES. 1/4W 470K J

!R239 VE-30001215 FUSE RES. 1W 1R J

R240 VE-30000469 SMD RES. 1/10W 1K J

R241 VE-30000818 SMD RES. 1/10W 8.2K J

R242 VE-30000784 CF RES. 1/4W 680K J

R245 VE-30000466 CF RES. 1/4W 1K J

R246 VE-30001027 MF RES. 1/4W 82K J

R250 VE-30000477 CF RES. 1/4W 100K J

R251 VE-30000477 CF RES. 1/4W 100K J

R252 VE-30007789 SMD RES. 1/10W 27K F

R254 VE-30000636 SMD RES. 1/10W 27K J

R255 VE-30001134 MO RES. 2W 2.2R J

R256 VE-30001100 MO RES. 1W 150R J

R257 VE-30001173 MO RES. 1W 0.47R J

R260 VE-30000778 SMD RES. 1/10W 6.8K J

R261 VE-30000778 SMD RES. 1/10W 6.8K J

!R262 VE-30001237 FUSE RES. 1/2W 3.3R J

R264 VE-30001077 MO RES. 2W 10R J

R270 VE-30000541 CF RES. 1/4W 1.5M J

R271 VE-30000744 CF RES. 1/4W 560R J

R272 VE-30000475 SMD RES. 1/10W 10K J

R280 VE-30000727 SMD RES. 1/10W 47K J

R281 VE-30000480 SMD RES. 1/10W 100K J

R318 VE-30000469 SMD RES. 1/10W 1K J

R322 VE-30000594 CF RES. 1/4W 22K J

R323 VE-30000459 CF RES. 1/4W 100R J

R324 VE-30000464 SMD RES. 1/10W 100R J

R327 VE-30000464 SMD RES. 1/10W 100R J

R360 VE-30000659 SMD RES. 1/10W 330R J

R361 VE-30000659 SMD RES. 1/10W 330R J

R362 VE-30000659 SMD RES. 1/10W 330R J

R363 VE-30000659 SMD RES. 1/10W 330R J

R364 VE-30000659 SMD RES. 1/10W 330R J

R365 VE-30000659 SMD RES. 1/10W 330R J

R366 VE-30000659 SMD RES. 1/10W 330R J

R367 VE-30000659 SMD RES. 1/10W 330R J

R368 VE-30000659 SMD RES. 1/10W 330R J

R369 VE-30000659 SMD RES. 1/10W 330R J

R370 VE-30000659 SMD RES. 1/10W 330R J

R371 VE-30000659 SMD RES. 1/10W 330R J

R372 VE-30000659 SMD RES. 1/10W 330R J

R373 VE-30000659 SMD RES. 1/10W 330R J

R374 VE-30000659 SMD RES. 1/10W 330R J

R375 VE-30000659 SMD RES. 1/10W 330R J

R376 VE-30000659 SMD RES. 1/10W 330R J

R378 VE-30000659 SMD RES. 1/10W 330R J

R379 VE-30000659 SMD RES. 1/10W 330R J

R380 VE-30000659 SMD RES. 1/10W 330R J

R381 VE-30000659 SMD RES. 1/10W 330R J

R382 VE-30000659 SMD RES. 1/10W 330R J

R383 VE-30000659 SMD RES. 1/10W 330R J

R384 VE-30000659 SMD RES. 1/10W 330R J

R385 VE-30000659 SMD RES. 1/10W 330R J

R397 VE-30000659 SMD RES. 1/10W 330R J

R398 VE-30000659 SMD RES. 1/10W 330R J

R411 VE-30000747 SMD RES. 1/10W 560R J

R412 VE-30000721 SMD RES. 1/10W 4.7K J

R413 VE-30000475 SMD RES. 1/10W 10K J

R414 VE-30000469 SMD RES. 1/10W 1K J

R415 VE-30000517 SMD RES. 1/10W 15R J

R416 VE-30000717 SMD RES. 1/10W 470R J

R421 VE-30000563 SMD RES. 1/10W 1.8K J

R422 VE-30000464 SMD RES. 1/10W 100R J

R424 VE-30007021 SMD RES. 1/10W 1K F

R425 VE-30000797 SMD RES. 1/10W 75R J

R428 VE-30000475 SMD RES. 1/10W 10K J

R429 VE-30000475 SMD RES. 1/10W 10K J

R440 VE-30000534 SMD RES. 1/10W 15K J

R441 VE-30000818 SMD RES. 1/10W 8.2K J

R445 VE-30000814 SMD RES. 1/10W 820R J

R475 VE-30000524 SMD RES. 1/10W 150R J

R480 VE-30000718 CF RES. 1/4W 4.7K J

R490 VE-30000466 CF RES. 1/4W 1K J

R492 VE-30000503 SMD RES. 1/10W 12K J

R506 VE-30012695 SMD RES. 1/16W 470R J

R509 VE-30000797 SMD RES. 1/10W 75R J

R510 VE-30007021 SMD RES. 1/10W 1K F

R511 VE-30000464 SMD RES. 1/10W 100R J

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

!Symbol No. Part No. Part Name Description

RESISTOR

R512 VE-30000464 SMD RES. 1/10W 100R J

R513 VE-30000457 SMD RES. 1/10W 10R J

R518 VE-30000735 SMD RES. 1/10W 4.7R J

R801 VE-30000718 CF RES. 1/4W 4.7K J

R802 VE-30000718 CF RES. 1/4W 4.7K J

R803 VE-30000628 CF RES. 1/4W 2.7K J

R804 VE-30000475 SMD RES. 1/10W 10K J

R805 VE-30000534 SMD RES. 1/10W 15K J

R806 VE-30000531 CF RES. 1/4W 15K J

R807 VE-30000567 SMD RES. 1/10W 18K J

R808 VE-30000734 CF RES. 1/4W 4.7R J

R809 VE-30000717 SMD RES. 1/10W 470R J

R810 VE-30000564 CF RES. 1/4W 18K J

R811 VE-30000717 SMD RES. 1/10W 470R J

R812 VE-30000734 CF RES. 1/4W 4.7R J

R813 VE-30000475 SMD RES. 1/10W 10K J

R819 VE-30000734 CF RES. 1/4W 4.7R J

R820 VE-30000734 CF RES. 1/4W 4.7R J

R900 VE-30012641 SMD RES. 1/16W 10K J

R901 VE-30012641 SMD RES. 1/16W 10K J

R902 VE-30012641 SMD RES. 1/16W 10K J

R903 VE-30000718 CF RES. 1/4W 4.7K J

R904 VE-30000718 CF RES. 1/4W 4.7K J

R905 VE-30000723 CF RES. 1/4W 47K J

R906 VE-30012696 SMD RES. 1/16W 47K J

R907 VE-30012679 SMD RES. 1/16W 3.9K J

R908 VE-30012679 SMD RES. 1/16W 3.9K J

R909 VE-30000531 CF RES. 1/4W 15K J

R910 VE-30000531 CF RES. 1/4W 15K J

R911 VE-30012641 SMD RES. 1/16W 10K J

R912 VE-30000471 CF RES. 1/4W 10K J

R913 VE-30012641 SMD RES. 1/16W 10K J

R914 VE-30000471 CF RES. 1/4W 10K J

R915 VE-30000471 CF RES. 1/4W 10K J

R916 VE-30012695 SMD RES. 1/16W 470R J

R917 VE-30012987 SMD RES. 1/16W 56R J

R918 VE-30012692 SMD RES. 1/16W 4.7K J

R919 VE-30012657 SMD RES. 1/16W 1K J

R920 VE-30012657 SMD RES. 1/16W 1K J

R921 VE-30012657 SMD RES. 1/16W 1K J

R922 VE-30012657 SMD RES. 1/16W 1K J

R923 VE-30012657 SMD RES. 1/16W 1K J

R924 VE-30012696 SMD RES. 1/16W 47K J

R925 VE-30012696 SMD RES. 1/16W 47K J

R926 VE-30012696 SMD RES. 1/16W 47K J

R927 VE-30012696 SMD RES. 1/16W 47K J

R928 VE-30012510 SMD RES. 1/16W 100R J

R929 VE-30012510 SMD RES. 1/16W 100R J

R930 VE-30012641 SMD RES. 1/16W 10K J

R931 VE-30012641 SMD RES. 1/16W 10K J

R932 VE-30012641 SMD RES. 1/16W 10K J

R933 VE-30000718 CF RES. 1/4W 4.7K J

R934 VE-30012692 SMD RES. 1/16W 4.7K J

R935 VE-30012662 SMD RES. 1/16W 2.7K J

R936 VE-30000718 CF RES. 1/4W 4.7K J

R937 VE-30000459 CF RES. 1/4W 100R J

R938 VE-30012509 SMD RES. 1/16W 100K J

R939 VE-30012692 SMD RES. 1/16W 4.7K J

R940 VE-30000500 CF RES. 1/4W 12K J

R941 VE-30000588 SMD RES. 1/10W 220R J

R942 VE-30000588 SMD RES. 1/10W 220R J

R943 VE-30000471 CF RES. 1/4W 10K J

R944 VE-30012641 SMD RES. 1/16W 10K J

R945 VE-30000471 CF RES. 1/4W 10K J

R946 VE-30012657 SMD RES. 1/16W 1K J

R950 VE-30012657 SMD RES. 1/16W 1K J

R951 VE-30012657 SMD RES. 1/16W 1K J

R952 VE-30012657 SMD RES. 1/16W 1K J

R953 VE-30000466 CF RES. 1/4W 1K J

R955 VE-30012657 SMD RES. 1/16W 1K J

R956 VE-30012510 SMD RES. 1/16W 100R J

R957 VE-30012655 SMD RES. 1/16W 180R J

R958 VE-30014022 SMD RES. 1/16W 47R J

R959 VE-30000466 CF RES. 1/4W 1K J

R960 VE-30000471 CF RES. 1/4W 10K J

R961 VE-30000718 CF RES. 1/4W 4.7K J

R964 VE-30012641 SMD RES. 1/16W 10K J

R965 VE-30012657 SMD RES. 1/16W 1K J

R966 VE-30012641 SMD RES. 1/16W 10K J

R967 VE-30012650 SMD RES. 1/16W 15K J

R968 VE-30000692 SMD RES. 1/10W 3.9K J

!Symbol No. Part No. Part Name Description

CAPACITOR

C100 VE-30000098 MKT CAP. 3.3NF 63V J

C101 VE-30000371 EL CAP. 22UF 50V M

C102 VE-30000294 SMD CAP. 100NF 50V K

C103 VE-30000294 SMD CAP. 100NF 50V K

C104 VE-30012323 MKT CAP. 1NF 100V J WIMA FKI2

C105 VE-30000284 SMD CAP. 1NF 50V K R

C106 VE-30000332 SMD CAP. 4.7NF 50V K

C107 VE-30000263 SMD CAP. 56PF 50V J CH

C108 VE-30000123 PP CAP. 33NF 630V K

C109 VE-30000159 MKP CAP. 4.7NF 1.6KV J

C110 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C111 VE-30000131 MKP CAP. 100NF 250V J

!C112 VE-30000094 MKT CAP. 220NF AC275V M

C114 VE-30000353 EL CAP. 100UF 25V M

!C115 VE-30007858 MKT CAP. 470NF AC275V M (P=22.5

!C118 VE-30007755 MKT CAP. 680NF AC275V M X2

C119 VE-30007754 MKP CAP. 1UF 400V

C120 VE-30007753 MKP CAP. 1NF 1KV

C121 VE-30013690 EL CAP. 220UF 450V M 105°C

!C122 VE-30000447 CER CAP. 4.7NF 4KV M E

C124 VE-30000315 SMD CAP. 220NF 25V Z

C125 VE-30000315 SMD CAP. 220NF 25V Z

C130 VE-30007708 CER CAP. 1NF 1KV K (PULSE)

C131 VE-30006909 EL CAP. 100UF M 250V

C132 VE-30007750 EL CAP. 470UF 35V (H/R 1150MA)

C133 VE-30000409 EL CAP. 470UF 25V M

C134 VE-30007750 EL CAP. 470UF 35V (H/R 1150MA)

C135 VE-30007748 EL CAP. 1000UF 35V M

C136 VE-30007748 EL CAP. 1000UF 35V M

C137 VE-30000284 SMD CAP. 1NF 50V K R

C138 VE-30000224 SMD CAP. 220PF 50V J

C139 VE-30000284 SMD CAP. 1NF 50V K R

C140 VE-30000360 EL CAP. 1000UF 25V M

C141 VE-30000352 EL CAP. 100UF 16V M

C142 VE-30000294 SMD CAP. 100NF 50V K

C143 VE-30000294 SMD CAP. 100NF 50V K

C144 VE-30000352 EL CAP. 100UF 16V M

C145 VE-30000309 SMD CAP. 2.2NF 50V K R

C146 VE-30000359 EL CAP. 1000UF 16V M

C147 VE-30000359 EL CAP. 1000UF 16V M

C148 VE-30000294 SMD CAP. 100NF 50V K

C149 VE-30000294 SMD CAP. 100NF 50V K

C150 VE-30000352 EL CAP. 100UF 16V M

C151 VE-30000284 SMD CAP. 1NF 50V K R

C160 VE-30007081 EL CAP. 4.7UF 50V M (NPL)

C161 VE-30007308 CER CAP. 220PF 1KV K (PULSE)

C162 VE-30007308 CER CAP. 220PF 1KV K (PULSE)

C163 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C165 VE-30016654 SMD CAP. 100NF 16V K R

C166 VE-30000355 EL CAP. 100UF 50V M

C167 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C168 VE-30000294 SMD CAP. 100NF 50V K

C170 VE-30000352 EL CAP. 100UF 16V M

C171 VE-30000352 EL CAP. 100UF 16V M

C172 VE-30016654 SMD CAP. 100NF 16V K R

C173 VE-30000315 SMD CAP. 220NF 25V Z

C201 VE-30000400 EL CAP. 47UF 50V M

C202 VE-30000106 MKT CAP. 47NF 100V J

C203 VE-30000099 MKT CAP. 33NF 63V J

C204 VE-30000345 EL CAP. 10UF 50V M

C206 VE-30000315 SMD CAP. 220NF 25V Z

C207 VE-30000362 EL CAP. 1UF 50V M

C208 VE-30000415 EL CAP. 4.7UF 250V M

C209 VE-30000224 SMD CAP. 220PF 50V J

C210 VE-30000149 MKP CAP. 2.7NF 2KV %3.5

C211 VE-30000179 MKP CAP. 9.1NF 1600V %3.5

C212 VE-30000137 MKP CAP. 15NF 630V J

C213 VE-30007215 MKP CAP. 1.2UF 250V J

C214 VE-30000415 EL CAP. 4.7UF 250V M

C215 VE-30000167 MKP CAP. 560NF 250V J

C216 VE-30000406 EL CAP. 47UF 250V M (HR)

C222 VE-30000431 CER CAP. 100PF 1KV M

C223 VE-30000351 EL CAP. 10UF 350V M

C225 VE-30000359 EL CAP. 1000UF 16V M

C226 VE-30000356 EL CAP. 100UF 63V M

C228 VE-30000360 EL CAP. 1000UF 25V M

C232 VE-30000225 CER CAP. 220PF 50V J SL

C240 VE-30000354 EL CAP. 100UF 35V M

C250 VE-30000304 SMD CAP. 1.8NF 50V K R

C251 VE-30000359 EL CAP. 1000UF 16V M

C252 VE-30000289 SMD CAP. 10NF 50V K R

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

!Symbol No. Part No. Part Name Description

CAPACITOR

C253 VE-30000294 SMD CAP. 100NF 50V K

C254 VE-30000360 EL CAP. 1000UF 25V M

C255 VE-30000294 SMD CAP. 100NF 50V K

C256 VE-30000078 MKT CAP. 1UF 100V M

C257 VE-30000304 SMD CAP. 1.8NF 50V K R

C258 VE-30000322 SMD CAP. 3.3NF 50V K

C305 VE-30000294 SMD CAP. 100NF 50V K

C313 VE-30000189 SMD CAP. 100PF 50V J

C321 VE-30000352 EL CAP. 100UF 16V M

C322 VE-30000352 EL CAP. 100UF 16V M

C324 VE-30000294 SMD CAP. 100NF 50V K

C333 VE-30000294 SMD CAP. 100NF 50V K

C402 VE-30000345 EL CAP. 10UF 50V M

C403 VE-30000384 EL CAP. 2.2UF 50V M

C404 VE-30000284 SMD CAP. 1NF 50V K R

C405 VE-30000284 SMD CAP. 1NF 50V K R

C406 VE-30000224 SMD CAP. 220PF 50V J

C407 VE-30000312 SMD CAP. 22NF 50V K

C408 VE-30000371 EL CAP. 22UF 50V M

C409 VE-30000294 SMD CAP. 100NF 50V K

C410 VE-30000294 SMD CAP. 100NF 50V K

C411 VE-30000109 MKT CAP. 470NF 63V J

C412 VE-30000384 EL CAP. 2.2UF 50V M

C413 VE-30000294 SMD CAP. 100NF 50V K

C414 VE-30000294 SMD CAP. 100NF 50V K

C417 VE-30000294 SMD CAP. 100NF 50V K

C418 VE-30000294 SMD CAP. 100NF 50V K

C419 VE-30000294 SMD CAP. 100NF 50V K

C427 VE-30000294 SMD CAP. 100NF 50V K

C428 VE-30000294 SMD CAP. 100NF 50V K

C440 VE-30000400 EL CAP. 47UF 50V M

C441 VE-30000220 SMD CAP. 22PF 50V J

C442 VE-30000294 SMD CAP. 100NF 50V K

C443 VE-30013411 SMD CAP. 180PF 50V J

C450 VE-30000345 EL CAP. 10UF 50V M

C451 VE-30000294 SMD CAP. 100NF 50V K

C453 VE-30000355 EL CAP. 100UF 50V M

C454 VE-30000294 SMD CAP. 100NF 50V K

C455 VE-30000345 EL CAP. 10UF 50V M

C456 VE-30000352 EL CAP. 100UF 16V M

C457 VE-30000294 SMD CAP. 100NF 50V K

C468 VE-30000294 SMD CAP. 100NF 50V K

C478 VE-30000294 SMD CAP. 100NF 50V K

C492 VE-30000294 SMD CAP. 100NF 50V K

C497 VE-30000294 SMD CAP. 100NF 50V K

C498 VE-30000294 SMD CAP. 100NF 50V K

C499 VE-30000362 EL CAP. 1UF 50V M

C500 VE-30000352 EL CAP. 100UF 16V M

C505 VE-30000294 SMD CAP. 100NF 50V K

C506 VE-30000345 EL CAP. 10UF 50V M

C509 VE-30000186 SMD CAP. 10PF 50V D COG

C510 VE-30000186 SMD CAP. 10PF 50V D COG

C511 VE-30000341 SMD CAP. 68NF 50V K

C610 VE-30000074 MKT CAP. 100NF 63V J

C801 VE-30000362 EL CAP. 1UF 50V M

C802 VE-30000362 EL CAP. 1UF 50V M

C804 VE-30000409 EL CAP. 470UF 25V M

C805 VE-30000294 SMD CAP. 100NF 50V K

C806 VE-30000409 EL CAP. 470UF 25V M

C807 VE-30000294 SMD CAP. 100NF 50V K

C808 VE-30000074 MKT CAP. 100NF 63V J

C809 VE-30000074 MKT CAP. 100NF 63V J

C819 VE-30000309 SMD CAP. 2.2NF 50V K R

C820 VE-30000309 SMD CAP. 2.2NF 50V K R

C821 VE-30000309 SMD CAP. 2.2NF 50V K R

C822 VE-30000309 SMD CAP. 2.2NF 50V K R

C823 VE-30000345 EL CAP. 10UF 50V M

C900 VE-30000371 EL CAP. 22UF 50V M

C901 VE-30016654 SMD CAP. 100NF 16V K R

C902 VE-30016654 SMD CAP. 100NF 16V K R

C903 VE-30016654 SMD CAP. 100NF 16V K R

C904 VE-30000074 MKT CAP. 100NF 63V J

C905 VE-30000371 EL CAP. 22UF 50V M

C906 VE-30016654 SMD CAP. 100NF 16V K R

C907 VE-30000074 MKT CAP. 100NF 63V J

C908 VE-30016654 SMD CAP. 100NF 16V K R

C909 VE-30016654 SMD CAP. 100NF 16V K R

C910 VE-30016654 SMD CAP. 100NF 16V K R

C911 VE-30000352 EL CAP. 100UF 16V M

C912 VE-30012569 SMD CAP. 33PF 50V J

C913 VE-30012569 SMD CAP. 33PF 50V J

C914 VE-30000371 EL CAP. 22UF 50V M

C915 VE-30016654 SMD CAP. 100NF 16V K R

!Symbol No. Part No. Part Name Description

CAPACITOR

C916 VE-30016654 SMD CAP. 100NF 16V K R

C917 VE-30016654 SMD CAP. 100NF 16V K R

C918 VE-30016654 SMD CAP. 100NF 16V K R

C919 VE-30000375 EL CAP. 220UF 16V M

C920 VE-30000384 EL CAP. 2.2UF 50V M

C921 VE-30016654 SMD CAP. 100NF 16V K R

C926 VE-30016654 SMD CAP. 100NF 16V K R

C927 VE-30016654 SMD CAP. 100NF 16V K R

C930 VE-30000345 EL CAP. 10UF 50V M

C931 VE-30000243 CER CAP. 330PF 50V J CH

C932 VE-30016654 SMD CAP. 100NF 16V K R

C933 VE-30000294 SMD CAP. 100NF 50V K

TRANSFORMER

!TR101 VE-30016819 SMPS TRF

TR201 VE-30006743 HORIZONTAL DRIVER TRF

!TR202 VE-30016922 FBT TRF

COIL

L101 VE-30006712 FERRITE BEAD

L102 VE-30007775 PFC COIL 1MH 1KHZ 2A

L106 VE-30006712 FERRITE BEAD

L107 VE-30001960 FERIT BAR

L108 VE-30001960 FERIT BAR

L109 VE-30001960 FERIT BAR

L201 VE-30007771 FIXED COIL 100UH

L202 VE-30007757 INJECTION COIL 6MH AK28

L203 VE-30007770 FILTER COIL 1MH AK28

L204 VE-30012271 LINEARTY COIL 4.3UH VOGT

L205 VE-30007756 BRIDGE COIL 150UH 32KHZ AK28

L206 VE-30006712 FERRITE BEAD

L207 VE-30006712 FERRITE BEAD

L304 VE-30001992 FIXED COIL 10UH Q65 K-A

L401 VE-30001986 FIXED COIL 3.3UH Q65 K

L403 VE-30001979 FIXED COIL 1UH Q45 M-A

L405 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L420 VE-30001996 FIXED COIL 22UH Q40 K

L421 VE-30001992 FIXED COIL 10UH Q65 K-A

L422 VE-30001994 FIXED COIL 22UH J AXIAL

L423 VE-30001994 FIXED COIL 22UH J AXIAL

L425 VE-30001971 FERRITE BEAT

L427 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L428 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L429 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L430 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L801 VE-30002170 FTZ/RAD COIL

L802 VE-30002170 FTZ/RAD COIL

L900 VE-30001992 FIXED COIL 10UH Q65 K-A

L901 VE-30001992 FIXED COIL 10UH Q65 K-A

L902 VE-30001992 FIXED COIL 10UH Q65 K-A

L903 VE-30001992 FIXED COIL 10UH Q65 K-A

L904 VE-30001987 FIXED COIL 4.7UH Q70 K-A

DIODE

D101 VE-30001285 DIODE

D102 VE-30001291 DIODE

D103 VE-30007768 DIODE

D104 VE-30007768 DIODE

D105 VE-30007768 DIODE

D106 VE-30007758 BRIDGE DIODE

D108 VE-30001318 DIODE

D109 VE-30009699 ZENER DIODE

D110 VE-30001301 DIODE

D111 VE-30001299 DIODE

D112 VE-30001302 DIODE

D113 VE-30001302 DIODE

D114 VE-30001302 DIODE

D115 VE-30001285 DIODE

D116 VE-30007760 ZENER DIODE

D117 VE-30001285 DIODE

D118 VE-30007760 ZENER DIODE

D119 VE-30001284 DIODE

D120 VE-30001291 DIODE

D121 VE-30001318 DIODE

D122 VE-30001318 DIODE

D123 VE-30001285 DIODE

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

!Symbol No. Part No. Part Name Description

DIODE

D126 VE-30001284 DIODE

D127 VE-30001284 DIODE

D128 VE-30001284 DIODE

D201 VE-30001291 DIODE

D202 VE-30001285 DIODE

D203 VE-30007760 ZENER DIODE

D205 VE-30007763 ZENER DIODE

D206 VE-30007678 DIODE

D207 VE-30007768 DIODE

D208 VE-30001291 DIODE

D209 VE-30001291 DIODE

D210 VE-30001299 DIODE

D211 VE-30001299 DIODE

D212 VE-30001291 DIODE

D213 VE-30001291 DIODE

D214 VE-30007763 ZENER DIODE

D215 VE-30007762 ZENER DIODE

D216 VE-30001285 DIODE

D218 VE-30001291 DIODE

D219 VE-30001291 DIODE

D220 VE-30001284 DIODE

D221 VE-30001284 DIODE

D222 VE-30001284 DIODE

D223 VE-30001285 DIODE

D224 VE-30001285 DIODE

D225 VE-30001318 DIODE

D226 VE-30007760 ZENER DIODE

D227 VE-30001373 ZENER DIODE

D403 VE-30001285 DIODE

D900 VE-30012412 ZENER DIODE

TRANSISTOR

Q101 VE-30007801 TR

Q103 VE-30007802 TR

Q104 VE-30007798 TR

Q105 VE-30007798 TR

Q106 VE-30007802 TR

Q107 VE-30007798 TR

Q108 VE-30007798 TR

Q109 VE-30001457 TR

Q110 VE-30001457 TR

Q112 VE-30001454 TR

Q113 VE-30001428 TR

Q201 VE-30007802 TR

Q202 VE-30016686 TR

Q203 VE-30001458 TR

Q204 VE-30001458 TR

Q205 VE-30007799 TR

Q206 VE-30001457 TR

Q207 VE-30001457 TR

Q208 VE-30001455 TR

Q403 VE-30001457 TR

Q408 VE-30007800 TR

Q415 VE-30001457 TR

Q801 VE-30001457 TR

Q802 VE-30001457 TR

Q900 VE-30001458 TR

Q901 VE-30001457 TR

Q902 VE-30001457 TR

Q903 VE-30001457 TR

Q904 VE-30001457 TR

Q905 VE-30001457 TR

Q906 VE-30001457 TR

Q907 VE-30001457 TR

Q908 VE-30001457 TR

Q909 VE-30001458 TR

Q910 VE-30001457 TR

Q911 VE-30001457 TR

IC101 VE-30007442 IC

!IC102 VE-30015087 IC

IC103 VE-30001506 IC

IC104 VE-30007444 IC

IC105 VE-30001500 IC

IC106 VE-30001668 IC

IC201 VE-30007793 IC

!Symbol No. Part No. Part Name Description

IC202 VE-30001506 IC

IC302 VE-20105601 IC (MEMORY)

IC304 VE-20098889 PR.IC. (MICOM)

IC401 VE-30001495 IC

IC802 VE-30007794 IC

IC900 VE-30013571 IC

OTHERS

!F101 VE-30001732 FUSE 3.15A 250V 5*20

!F102 VE-30009037 FUSE 6.3A 250V 5mm

!F103 VE-30009037 FUSE 6.3A 250V 5mm

!L103 VE-30006744 LINE FILTER 16MH

!L104 VE-30006744 LINE FILTER 16MH

RL2 VE-30002183 RELAY

S133 VE-30000575 SMD RES. 1/10W 2K J

T401 VE-30001724 SER FILTER

TU401 VE-30009637 TUNER

VL401 VE-30002037 ADJ COIL

X900 VE-30006662 XTAL

Z401 VE-30001706 SAW FILTER

Z403 VE-30001692 SAW FILTER

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

MULTISOUND P.W. BOARD ASS’Y

(VE-20103705 : Common to all models)

!Symbol No. Part No. Part Name Description

RESISTOR

R501 VE-30000475 SMD RES. 1/10W 10K J

R502 VE-30000475 SMD RES. 1/10W 10K J

R503 VE-30000459 CF RES. 1/4W 100R J

R504 VE-30000459 CF RES. 1/4W 100R J

R505 VE-30000464 SMD RES. 1/10W 100R J

R506 VE-30000721 SMD RES. 1/10W 4.7K J

R507 VE-30000626 SMD RES. 1/10W 270R J

R508 VE-30000464 SMD RES. 1/10W 100R J

R509 VE-30000464 SMD RES. 1/10W 100R J

R510 VE-30000464 SMD RES. 1/10W 100R J

R511 VE-30000464 SMD RES. 1/10W 100R J

R512 VE-30000469 SMD RES. 1/10W 1K J

R513 VE-30000466 CF RES. 1/4W 1K J

R516 VE-30000469 SMD RES. 1/10W 1K J

R517 VE-30000469 SMD RES. 1/10W 1K J

R518 VE-30000469 SMD RES. 1/10W 1K J

R519 VE-30000469 SMD RES. 1/10W 1K J

R520 VE-30000469 SMD RES. 1/10W 1K J

R521 VE-30000469 SMD RES. 1/10W 1K J

R522 VE-30000469 SMD RES. 1/10W 1K J

R523 VE-30000469 SMD RES. 1/10W 1K J

R524 VE-30000797 SMD RES. 1/10W 75R J

R525 VE-30000797 SMD RES. 1/10W 75R J

R529 VE-30000797 SMD RES. 1/10W 75R J

R532 VE-30000459 CF RES. 1/4W 100R J

R533 VE-30000459 CF RES. 1/4W 100R J

!R535 VE-30001207 FUSE RES. 1/4W 10R J

R536 VE-30000797 SMD RES. 1/10W 75R J

R538 VE-30000457 SMD RES. 1/10W 10R J

R539 VE-30000452 CF RES. 1/4W 10R J

R540 VE-30000457 SMD RES. 1/10W 10R J

R541 VE-30000717 SMD RES. 1/10W 470R J

R542 VE-30000475 SMD RES. 1/10W 10K J

R543 VE-30000721 SMD RES. 1/10W 4.7K J

R544 VE-30000717 SMD RES. 1/10W 470R J

R545 VE-30000475 SMD RES. 1/10W 10K J

R546 VE-30000712 CF RES. 1/4W 470R J

R547 VE-30000475 SMD RES. 1/10W 10K J

R548 VE-30000717 SMD RES. 1/10W 470R J

R549 VE-30000475 SMD RES. 1/10W 10K J

R550 VE-30000721 SMD RES. 1/10W 4.7K J

R551 VE-30000721 SMD RES. 1/10W 4.7K J

R552 VE-30000452 CF RES. 1/4W 10R J

R553 VE-30000721 SMD RES. 1/10W 4.7K J

R555 VE-30000797 SMD RES. 1/10W 75R J

R556 VE-30000792 CF RES. 1/4W 75R J

R557 VE-30000792 CF RES. 1/4W 75R J

R558 VE-30000792 CF RES. 1/4W 75R J

R559 VE-30000457 SMD RES. 1/10W 10R J

R560 VE-30000717 SMD RES. 1/10W 470R J

R561 VE-30000475 SMD RES. 1/10W 10K J

R562 VE-30000721 SMD RES. 1/10W 4.7K J

R563 VE-30000792 CF RES. 1/4W 75R J

R572 VE-30000721 SMD RES. 1/10W 4.7K J

R573 VE-30000721 SMD RES. 1/10W 4.7K J

R574 VE-30000721 SMD RES. 1/10W 4.7K J

R575 VE-30000721 SMD RES. 1/10W 4.7K J

R576 VE-30000797 SMD RES. 1/10W 75R J

R577 VE-30000480 SMD RES. 1/10W 100K J

R578 VE-30000480 SMD RES. 1/10W 100K J

R579 VE-30000797 SMD RES. 1/10W 75R J

R580 VE-30000588 SMD RES. 1/10W 220R J

R581 VE-30000588 SMD RES. 1/10W 220R J

R582 VE-30000583 CF RES. 1/4W 220R J

R583 VE-30000503 SMD RES. 1/10W 12K J

R584 VE-30000636 SMD RES. 1/10W 27K J

R585 VE-30000503 SMD RES. 1/10W 12K J

R586 VE-30000636 SMD RES. 1/10W 27K J

R587 VE-30000469 SMD RES. 1/10W 1K J

R588 VE-30000469 SMD RES. 1/10W 1K J

R589 VE-30000457 SMD RES. 1/10W 10R J

R590 VE-30000469 SMD RES. 1/10W 1K J

R591 VE-30000457 SMD RES. 1/10W 10R J

R592 VE-30000464 SMD RES. 1/10W 100R J

R593 VE-30000469 SMD RES. 1/10W 1K J

R594 VE-30000469 SMD RES. 1/10W 1K J

R595 VE-30000457 SMD RES. 1/10W 10R J

R596 VE-30000717 SMD RES. 1/10W 470R J

R597 VE-30000475 SMD RES. 1/10W 10K J

R598 VE-30000721 SMD RES. 1/10W 4.7K J

R599 VE-30000797 SMD RES. 1/10W 75R J

R600 VE-30000475 SMD RES. 1/10W 10K J

!R613 VE-30001231 FUSE RES. 1/4W 27R J

R614 VE-30000797 SMD RES. 1/10W 75R J

!Symbol No. Part No. Part Name Description

CAPACITOR

C501 VE-30000407 EL CAP. 470UF 16V M

C502 VE-30000294 SMD CAP. 100NF 50V K

C504 VE-30000352 EL CAP. 100UF 16V M

C505 VE-30000407 EL CAP. 470UF 16V M

C507 VE-30000284 SMD CAP. 1NF 50V K R

C508 VE-30000284 SMD CAP. 1NF 50V K R

C509 VE-30000252 SMD CAP. 47PF 50V J

C510 VE-30000252 SMD CAP. 47PF 50V J

C511 VE-30000332 SMD CAP. 4.7NF 50V K

C512 VE-30000332 SMD CAP. 4.7NF 50V K

C513 VE-30000332 SMD CAP. 4.7NF 50V K

C514 VE-30000332 SMD CAP. 4.7NF 50V K

C516 VE-30000371 EL CAP. 22UF 50V M

C517 VE-30000294 SMD CAP. 100NF 50V K

C521 VE-30000371 EL CAP. 22UF 50V M

C522 VE-30000109 MKT CAP. 470NF 63V J

C523 VE-30000109 MKT CAP. 470NF 63V J

C524 VE-30000109 MKT CAP. 470NF 63V J

C525 VE-30000109 MKT CAP. 470NF 63V J

C526 VE-30000265 SMD CAP. 560PF 50V J

C527 VE-30000109 MKT CAP. 470NF 63V J

C528 VE-30000109 MKT CAP. 470NF 63V J

C529 VE-30000294 SMD CAP. 100NF 50V K

C530 VE-30000393 EL CAP. 3.3UF 50V M

C531 VE-30000345 EL CAP. 10UF 50V M

C532 VE-30000345 EL CAP. 10UF 50V M

C533 VE-30000345 EL CAP. 10UF 50V M

C534 VE-30000284 SMD CAP. 1NF 50V K R

C535 VE-30000284 SMD CAP. 1NF 50V K R

C536 VE-30000216 SMD CAP. 1.8PF 50V J CH

C537 VE-30000216 SMD CAP. 1.8PF 50V J CH

C538 VE-30000284 SMD CAP. 1NF 50V K R

C539 VE-30000284 SMD CAP. 1NF 50V K R

C540 VE-30000284 SMD CAP. 1NF 50V K R

C541 VE-30000284 SMD CAP. 1NF 50V K R

C542 VE-30000263 SMD CAP. 56PF 50V J CH

C543 VE-30000294 SMD CAP. 100NF 50V K

C544 VE-30000294 SMD CAP. 100NF 50V K

C545 VE-30000284 SMD CAP. 1NF 50V K R

C546 VE-30000284 SMD CAP. 1NF 50V K R

C547 VE-30000284 SMD CAP. 1NF 50V K R

C548 VE-30000284 SMD CAP. 1NF 50V K R

C549 VE-30000294 SMD CAP. 100NF 50V K

C550 VE-30000294 SMD CAP. 100NF 50V K

C551 VE-30000407 EL CAP. 470UF 16V M

C552 VE-30000407 EL CAP. 470UF 16V M

C553 VE-30000204 SMD CAP. 150PF 50V J N750

C554 VE-30000204 SMD CAP. 150PF 50V J N750

C556 VE-30000352 EL CAP. 100UF 16V M

C557 VE-30000332 SMD CAP. 4.7NF 50V K

C558 VE-30000332 SMD CAP. 4.7NF 50V K

C560 VE-30000074 MKT CAP. 100NF 63V J

C561 VE-30000247 SMD CAP. 39PF 50V J

C562 VE-30000247 SMD CAP. 39PF 50V J

C563 VE-30000294 SMD CAP. 100NF 50V K

C564 VE-30000332 SMD CAP. 4.7NF 50V K

C565 VE-30000332 SMD CAP. 4.7NF 50V K

C566 VE-30000109 MKT CAP. 470NF 63V J

C567 VE-30000109 MKT CAP. 470NF 63V J

C569 VE-30000109 MKT CAP. 470NF 63V J

C576 VE-30000109 MKT CAP. 470NF 63V J

C582 VE-30000092 MKT CAP. 220NF 63V J

C583 VE-30000204 SMD CAP. 150PF 50V J N750

C584 VE-30000204 SMD CAP. 150PF 50V J N750

C585 VE-30000092 MKT CAP. 220NF 63V J

C586 VE-30000092 MKT CAP. 220NF 63V J

C587 VE-30000092 MKT CAP. 220NF 63V J

C590 VE-30000332 SMD CAP. 4.7NF 50V K

C591 VE-30000332 SMD CAP. 4.7NF 50V K

C592 VE-30000092 MKT CAP. 220NF 63V J

C612 VE-30000204 SMD CAP. 150PF 50V J N750

C614 VE-30000294 SMD CAP. 100NF 50V K

C615 VE-30000284 SMD CAP. 1NF 50V K R

C616 VE-30000294 SMD CAP. 100NF 50V K

C617 VE-30000294 SMD CAP. 100NF 50V K

C618 VE-30000294 SMD CAP. 100NF 50V K

C619 VE-30000294 SMD CAP. 100NF 50V K

C620 VE-30000092 MKT CAP. 220NF 63V J

C623 VE-30000371 EL CAP. 22UF 50V M

C624 VE-30000371 EL CAP. 22UF 50V M

C626 VE-30000371 EL CAP. 22UF 50V M

C627 VE-30000371 EL CAP. 22UF 50V M

C628 VE-30000371 EL CAP. 22UF 50V M

C629 VE-30000371 EL CAP. 22UF 50V M

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

!Symbol No. Part No. Part Name Description

CAPACITOR

C630 VE-30000294 SMD CAP. 100NF 50V K

C631 VE-30000237 SMD CAP. 33PF 50V J

C632 VE-30000237 SMD CAP. 33PF 50V J

C633 VE-30000237 SMD CAP. 33PF 50V J

C634 VE-30000237 SMD CAP. 33PF 50V J

C635 VE-30000232 SMD CAP. 270PF 50V J

C636 VE-30000256 SMD CAP. 470PF 50V J

C637 VE-30000237 SMD CAP. 33PF 50V J

C638 VE-30000289 SMD CAP. 10NF 50V K R

C640 VE-30000332 SMD CAP. 4.7NF 50V K

C641 VE-30000332 SMD CAP. 4.7NF 50V K

C643 VE-30000294 SMD CAP. 100NF 50V K

C644 VE-30000294 SMD CAP. 100NF 50V K

COIL

L501 VE-30001996 FIXED COIL 22UH Q40 K

L502 VE-30001996 FIXED COIL 22UH Q40 K

L503 VE-30001996 FIXED COIL 22UH Q40 K

L504 VE-30001996 FIXED COIL 22UH Q40 K

L505 VE-30001996 FIXED COIL 22UH Q40 K

L506 VE-30001996 FIXED COIL 22UH Q40 K

L507 VE-30001996 FIXED COIL 22UH Q40 K

L508 VE-30001996 FIXED COIL 22UH Q40 K

L509 VE-30001996 FIXED COIL 22UH Q40 K

L510 VE-30001996 FIXED COIL 22UH Q40 K

L513 VE-30001996 FIXED COIL 22UH Q40 K

L514 VE-30001996 FIXED COIL 22UH Q40 K

L515 VE-30001996 FIXED COIL 22UH Q40 K

L516 VE-30001996 FIXED COIL 22UH Q40 K

L517 VE-30001996 FIXED COIL 22UH Q40 K

L520 VE-30013413 FERRITE BEAD

L521 VE-30013413 FERRITE BEAD

L522 VE-30013413 FERRITE BEAD

L523 VE-30013413 FERRITE BEAD

L524 VE-30013413 FERRITE BEAD

L525 VE-30013413 FERRITE BEAD

L526 VE-30013413 FERRITE BEAD

L527 VE-30013413 FERRITE BEAD

L533 VE-30013413 FERRITE BEAD

L534 VE-30013413 FERRITE BEAD

L535 VE-30013413 FERRITE BEAD

L536 VE-30010964 FERRITE BEAT

L537 VE-30010964 FERRITE BEAT

DIODE

D501 VE-30001369 ZENER DIODE

D502 VE-30001284 DIODE

D504 VE-30001285 DIODE

D505 VE-30001285 DIODE

TRANSISTOR

Q501 VE-30001458 TR

Q502 VE-30001457 TR

Q503 VE-30001457 TR

Q504 VE-30001457 TR

Q505 VE-30001457 TR

Q506 VE-30001457 TR

Q507 VE-30001457 TR

Q508 VE-30001457 TR

Q509 VE-30001457 TR

Q510 VE-30001457 TR

Q511 VE-30001457 TR

Q512 VE-30001457 TR

Q513 VE-30001457 TR

Q514 VE-30001457 TR

Q515 VE-30001457 TR

IC501 VE-30009354 IC

IC502 VE-30001619 IC

IC504 VE-30001349 ZENER DIODE

OTHERS

X501 VE-30001756 XTAL

FEATURE BOX P.W. BOARD ASS’Y

(VE-20055386 : Common to all models)

!Symbol No. Part No. Part Name Description

RESISTOR

R001 VE-30000659 SMD RES. 1/10W 330R J

R002 VE-30000464 SMD RES. 1/10W 100R J

R003 VE-30000688 SMD RES. 1/10W 390R J

R004 VE-30006462 SMD RES. 1/10W 22R J

R005 VE-30000653 SMD RES. 1/10W 33R J

R006 VE-30000588 SMD RES. 1/10W 220R J

R007 VE-30000469 SMD RES. 1/10W 1K J

R008 VE-30000659 SMD RES. 1/10W 330R J

R009 VE-30000659 SMD RES. 1/10W 330R J

R010 VE-30000659 SMD RES. 1/10W 330R J

R011 VE-30000659 SMD RES. 1/10W 330R J

R012 VE-30000659 SMD RES. 1/10W 330R J

R013 VE-30000659 SMD RES. 1/10W 330R J

R014 VE-30000659 SMD RES. 1/10W 330R J

R015 VE-30000659 SMD RES. 1/10W 330R J

R016 VE-30000659 SMD RES. 1/10W 330R J

R017 VE-30000659 SMD RES. 1/10W 330R J

R018 VE-30000659 SMD RES. 1/10W 330R J

R021 VE-30000659 SMD RES. 1/10W 330R J

R024 VE-30000797 SMD RES. 1/10W 75R J

R026 VE-30000797 SMD RES. 1/10W 75R J

R028 VE-30000797 SMD RES. 1/10W 75R J

R030 VE-30000797 SMD RES. 1/10W 75R J

R031 VE-30000833 SMD RES. 1/10W 91R J

R032 VE-30000524 SMD RES. 1/10W 150R J

R033 VE-30000475 SMD RES. 1/10W 10K J

R034 VE-30000469 SMD RES. 1/10W 1K J

R047 VE-30000797 SMD RES. 1/10W 75R J

R048 VE-30006462 SMD RES. 1/10W 22R J

R050 VE-30000597 SMD RES. 1/10W 22K J

R053 VE-30000797 SMD RES. 1/10W 75R J

R054 VE-30000797 SMD RES. 1/10W 75R J

R055 VE-30000797 SMD RES. 1/10W 75R J

R056 VE-30000797 SMD RES. 1/10W 75R J

R057 VE-30000797 SMD RES. 1/10W 75R J

R058 VE-30000797 SMD RES. 1/10W 75R J

R059 VE-30000797 SMD RES. 1/10W 75R J

R074 VE-30000721 SMD RES. 1/10W 4.7K J

R075 VE-30000721 SMD RES. 1/10W 4.7K J

R076 VE-30000721 SMD RES. 1/10W 4.7K J

R079 VE-30000464 SMD RES. 1/10W 100R J

R080 VE-30000688 SMD RES. 1/10W 390R J

R081 VE-30006462 SMD RES. 1/10W 22R J

R082 VE-30000797 SMD RES. 1/10W 75R J

R083 VE-30000588 SMD RES. 1/10W 220R J

R084 VE-30000469 SMD RES. 1/10W 1K J

R085 VE-30000464 SMD RES. 1/10W 100R J

R086 VE-30000688 SMD RES. 1/10W 390R J

R087 VE-30006462 SMD RES. 1/10W 22R J

R088 VE-30000797 SMD RES. 1/10W 75R J

R089 VE-30000588 SMD RES. 1/10W 220R J

R090 VE-30000469 SMD RES. 1/10W 1K J

R091 VE-30000464 SMD RES. 1/10W 100R J

R092 VE-30000688 SMD RES. 1/10W 390R J

R093 VE-30006462 SMD RES. 1/10W 22R J

R094 VE-30000797 SMD RES. 1/10W 75R J

R095 VE-30000588 SMD RES. 1/10W 220R J

R096 VE-30000469 SMD RES. 1/10W 1K J

R098 VE-30000597 SMD RES. 1/10W 22K J

R099 VE-30000626 SMD RES. 1/10W 270R J

R100 VE-30000475 SMD RES. 1/10W 10K J

R101 VE-30000593 SMD RES. 1/10W 2.2K J

R105 VE-30000475 SMD RES. 1/10W 10K J

R106 VE-30000664 SMD RES. 1/10W 3.3K J

R107 VE-30000475 SMD RES. 1/10W 10K J

R108 VE-30000475 SMD RES. 1/10W 10K J

R110 VE-30000534 SMD RES. 1/10W 15K J

R111 VE-30000534 SMD RES. 1/10W 15K J

R112 VE-30000593 SMD RES. 1/10W 2.2K J

R117 VE-30000475 SMD RES. 1/10W 10K J

R119 VE-30000475 SMD RES. 1/10W 10K J

R120 VE-30000469 SMD RES. 1/10W 1K J

R121 VE-30006462 SMD RES. 1/10W 22R J

R122 VE-30000588 SMD RES. 1/10W 220R J

R125 VE-30000659 SMD RES. 1/10W 330R J

R126 VE-30000659 SMD RES. 1/10W 330R J

R127 VE-30000659 SMD RES. 1/10W 330R J

R128 VE-30000659 SMD RES. 1/10W 330R J

R129 VE-30000659 SMD RES. 1/10W 330R J

R130 VE-30000659 SMD RES. 1/10W 330R J

R131 VE-30000659 SMD RES. 1/10W 330R J

R132 VE-30000659 SMD RES. 1/10W 330R J

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

!Symbol No. Part No. Part Name Description

RESISTOR

R133 VE-30000659 SMD RES. 1/10W 330R J

R134 VE-30000659 SMD RES. 1/10W 330R J

R135 VE-30000659 SMD RES. 1/10W 330R J

R136 VE-30000659 SMD RES. 1/10W 330R J

R137 VE-30000659 SMD RES. 1/10W 330R J

R138 VE-30000659 SMD RES. 1/10W 330R J

R140 VE-30000797 SMD RES. 1/10W 75R J

R141 VE-30000659 SMD RES. 1/10W 330R J

R142 VE-30000659 SMD RES. 1/10W 330R J

R143 VE-30000659 SMD RES. 1/10W 330R J

R144 VE-30000659 SMD RES. 1/10W 330R J

R145 VE-30000659 SMD RES. 1/10W 330R J

R149 VE-30000534 SMD RES. 1/10W 15K J

R150 VE-30000797 SMD RES. 1/10W 75R J

R151 VE-30000797 SMD RES. 1/10W 75R J

R152 VE-30000797 SMD RES. 1/10W 75R J

R153 VE-30000797 SMD RES. 1/10W 75R J

R154 VE-30000797 SMD RES. 1/10W 75R J

R155 VE-30000464 SMD RES. 1/10W 100R J

R156 VE-30000464 SMD RES. 1/10W 100R J

R157 VE-30000464 SMD RES. 1/10W 100R J

R158 VE-30000464 SMD RES. 1/10W 100R J

R159 VE-30000464 SMD RES. 1/10W 100R J

R161 VE-30000464 SMD RES. 1/10W 100R J

R162 VE-30000464 SMD RES. 1/10W 100R J

R163 VE-30000464 SMD RES. 1/10W 100R J

R164 VE-30000464 SMD RES. 1/10W 100R J

R165 VE-30000721 SMD RES. 1/10W 4.7K J

CAPACITOR

C001 VE-30000309 SMD CAP. 2.2NF 50V K R

C002 VE-30000294 SMD CAP. 100NF 50V K

C003 VE-30000334 SMD CAP. 47NF 50V K

C004 VE-30000309 SMD CAP. 2.2NF 50V K R

C005 VE-30000186 SMD CAP. 10PF 50V D COG

C006 VE-30000186 SMD CAP. 10PF 50V D COG

C007 VE-30000232 SMD CAP. 270PF 50V J

C008 VE-30000265 SMD CAP. 560PF 50V J

C009 VE-30000309 SMD CAP. 2.2NF 50V K R

C010 VE-30000232 SMD CAP. 270PF 50V J

C011 VE-30000265 SMD CAP. 560PF 50V J

C012 VE-30000309 SMD CAP. 2.2NF 50V K R

C013 VE-30000232 SMD CAP. 270PF 50V J

C014 VE-30000265 SMD CAP. 560PF 50V J

C015 VE-30000309 SMD CAP. 2.2NF 50V K R

C016 VE-30000232 SMD CAP. 270PF 50V J

C017 VE-30000265 SMD CAP. 560PF 50V J

C018 VE-30000309 SMD CAP. 2.2NF 50V K R

C019 VE-30000309 SMD CAP. 2.2NF 50V K R

C020 VE-30000294 SMD CAP. 100NF 50V K

C021 VE-30000345 EL CAP. 10UF 50V M

C022 VE-30000345 EL CAP. 10UF 50V M

C024 VE-30000345 EL CAP. 10UF 50V M

C026 VE-30000345 EL CAP. 10UF 50V M

C027 VE-30000345 EL CAP. 10UF 50V M

C028 VE-30000345 EL CAP. 10UF 50V M

C029 VE-30000242 SMD CAP. 330PF 50V J

C030 VE-30010560 SMD CAP. 220NF 25V K R

C031 VE-30000242 SMD CAP. 330PF 50V J

C032 VE-30010560 SMD CAP. 220NF 25V K R

C033 VE-30000242 SMD CAP. 330PF 50V J

C034 VE-30010560 SMD CAP. 220NF 25V K R

C035 VE-30000109 MKT CAP. 470NF 63V J

C036 VE-30000345 EL CAP. 10UF 50V M

C037 VE-30000345 EL CAP. 10UF 50V M

C038 VE-30000289 SMD CAP. 10NF 50V K R

C039 VE-30000371 EL CAP. 22UF 50V M

C040 VE-30000392 EL CAP. 0.33UF 50V M

C041 VE-30000371 EL CAP. 22UF 50V M

C042 VE-30000392 EL CAP. 0.33UF 50V M

C043 VE-30000392 EL CAP. 0.33UF 50V M

C045 VE-30000294 SMD CAP. 100NF 50V K

C046 VE-30000294 SMD CAP. 100NF 50V K

C047 VE-30000294 SMD CAP. 100NF 50V K

C048 VE-30000232 SMD CAP. 270PF 50V J

C049 VE-30000265 SMD CAP. 560PF 50V J

C050 VE-30000309 SMD CAP. 2.2NF 50V K R

C051 VE-30000232 SMD CAP. 270PF 50V J

C052 VE-30000265 SMD CAP. 560PF 50V J

C053 VE-30000309 SMD CAP. 2.2NF 50V K R

!Symbol No. Part No. Part Name Description

CAPACITOR

C054 VE-30000228 SMD CAP. 27PF 50V J CH

C055 VE-30000228 SMD CAP. 27PF 50V J CH

C056 VE-30000232 SMD CAP. 270PF 50V J

C057 VE-30000265 SMD CAP. 560PF 50V J

C058 VE-30000309 SMD CAP. 2.2NF 50V K R

C059 VE-30000284 SMD CAP. 1NF 50V K R

C060 VE-30000289 SMD CAP. 10NF 50V K R

C061 VE-30000294 SMD CAP. 100NF 50V K

C062 VE-30000294 SMD CAP. 100NF 50V K

C063 VE-30000289 SMD CAP. 10NF 50V K R

C064 VE-30000289 SMD CAP. 10NF 50V K R

C065 VE-30000289 SMD CAP. 10NF 50V K R

C066 VE-30000289 SMD CAP. 10NF 50V K R

C067 VE-30000289 SMD CAP. 10NF 50V K R

C068 VE-30000294 SMD CAP. 100NF 50V K

C069 VE-30000289 SMD CAP. 10NF 50V K R

C070 VE-30000289 SMD CAP. 10NF 50V K R

C071 VE-30000289 SMD CAP. 10NF 50V K R

C072 VE-30000309 SMD CAP. 2.2NF 50V K R

C073 VE-30000265 SMD CAP. 560PF 50V J

C074 VE-30000345 EL CAP. 10UF 50V M

C075 VE-30000345 EL CAP. 10UF 50V M

C076 VE-30000345 EL CAP. 10UF 50V M

C077 VE-30000345 EL CAP. 10UF 50V M

C078 VE-30000109 MKT CAP. 470NF 63V J

C079 VE-30000109 MKT CAP. 470NF 63V J

C080 VE-30000345 EL CAP. 10UF 50V M

C081 VE-30000345 EL CAP. 10UF 50V M

C082 VE-30000345 EL CAP. 10UF 50V M

C083 VE-30000294 SMD CAP. 100NF 50V K

C084 VE-30000186 SMD CAP. 10PF 50V D COG

C085 VE-30000232 SMD CAP. 270PF 50V J

C086 VE-30000309 SMD CAP. 2.2NF 50V K R

C087 VE-30000265 SMD CAP. 560PF 50V J

C088 VE-30000232 SMD CAP. 270PF 50V J

C089 VE-30000232 SMD CAP. 270PF 50V J

C090 VE-30000265 SMD CAP. 560PF 50V J

C091 VE-30000309 SMD CAP. 2.2NF 50V K R

C092 VE-30000309 SMD CAP. 2.2NF 50V K R

C093 VE-30000265 SMD CAP. 560PF 50V J

C094 VE-30000232 SMD CAP. 270PF 50V J

C095 VE-30000232 SMD CAP. 270PF 50V J

C096 VE-30000265 SMD CAP. 560PF 50V J

C097 VE-30000309 SMD CAP. 2.2NF 50V K R

C098 VE-30000345 EL CAP. 10UF 50V M

C099 VE-30000345 EL CAP. 10UF 50V M

C100 VE-30000393 EL CAP. 3.3UF 50V M

C101 VE-30000392 EL CAP. 0.33UF 50V M

C102 VE-30000345 EL CAP. 10UF 50V M

C103 VE-30000289 SMD CAP. 10NF 50V K R

C104 VE-30000284 SMD CAP. 1NF 50V K R

C105 VE-30000294 SMD CAP. 100NF 50V K

C106 VE-30000294 SMD CAP. 100NF 50V K

C107 VE-30000186 SMD CAP. 10PF 50V D COG

C108 VE-30000345 EL CAP. 10UF 50V M

C109 VE-30000294 SMD CAP. 100NF 50V K

C110 VE-30000186 SMD CAP. 10PF 50V D COG

C111 VE-30000186 SMD CAP. 10PF 50V D COG

C112 VE-30000284 SMD CAP. 1NF 50V K R

C113 VE-30000242 SMD CAP. 330PF 50V J

C25 VE-30000109 MKT CAP. 470NF 63V J

COIL

L001 VE-30001992 FIXED COIL 10UH Q65 K-A

L002 VE-30001992 FIXED COIL 10UH Q65 K-A

L003 VE-30001992 FIXED COIL 10UH Q65 K-A

L004 VE-30001986 FIXED COIL 3.3UH Q65 K

L005 VE-30001986 FIXED COIL 3.3UH Q65 K

L006 VE-30001996 FIXED COIL 22UH Q40 K

L007 VE-30001986 FIXED COIL 3.3UH Q65 K

L008 VE-30001986 FIXED COIL 3.3UH Q65 K

L009 VE-30001986 FIXED COIL 3.3UH Q65 K

L010 VE-30001986 FIXED COIL 3.3UH Q65 K

DIODE

D001 VE-30001284 DIODE

D002 VE-30001284 DIODE

D003 VE-30001284 DIODE

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

!Symbol No. Part No. Part Name Description

TRANSISTOR

Q001 VE-30001454 TR

Q002 VE-30001454 TR

Q003 VE-30001455 TR

Q004 VE-30001454 TR

Q005 VE-30001454 TR

Q006 VE-30001455 TR

Q007 VE-30001454 TR

Q008 VE-30001454 TR

Q009 VE-30001455 TR

Q010 VE-30001454 TR

Q011 VE-30001454 TR

Q012 VE-30001455 TR

Q013 VE-30001454 TR

Q014 VE-30001454 TR

Q015 VE-30001454 TR

IC001 VE-30010350 IC

IC002 VE-30010348 IC

IC003 VE-30007668 IC

IC004 VE-30007739 IC

IC005 VE-30010349 IC

OTHERS

X001 VE-30008778 XTAL

X002 VE-30008782 XTAL

CRT SOCKET P.W. BOARD ASS’Y

(VE-20086313 : Common to all models)

!Symbol No. Part No. Part Name Description

RESISTOR

R901 VE-30000499 SMD RES. 1/10W 1.2K J

R902 VE-30017132 MF RES. 1W 51K F

R903 VE-30000499 SMD RES. 1/10W 1.2K J

R904 VE-30000524 SMD RES. 1/10W 150R J

R905 VE-30001192 MO RES. 1W 680R J

R906 VE-30000499 SMD RES. 1/10W 1.2K J

R907 VE-30017132 MF RES. 1W 51K F

R908 VE-30000499 SMD RES. 1/10W 1.2K J

R909 VE-30000524 SMD RES. 1/10W 150R J

R910 VE-30001192 MO RES. 1W 680R J

R911 VE-30000499 SMD RES. 1/10W 1.2K J

R912 VE-30017132 MF RES. 1W 51K F

R913 VE-30000499 SMD RES. 1/10W 1.2K J

R914 VE-30000524 SMD RES. 1/10W 150R J

R915 VE-30001192 MO RES. 1W 680R J

R916 VE-30001125 MO RES. 2W 2.2K J

R917 VE-30001170 MO RES. 1W 4.7K J

R918 VE-30000788 CF RES. 1/4W 6.8M J

R920 VE-30000535 CF RES. 1/2W 150K J

R922 VE-30000477 CF RES. 1/4W 100K J

R923 VE-30000477 CF RES. 1/4W 100K J

R924 VE-30000477 CF RES. 1/4W 100K J

R925 VE-30007788 SMD RES. 1/10W 2.7K F

R926 VE-30000469 SMD RES. 1/10W 1K J

!R927 VE-30001247 FUSE RES. 1/2W 4.7R J

R929 VE-30000466 CF RES. 1/4W 1K J

R931 VE-30000593 SMD RES. 1/10W 2.2K J

R932 VE-30000471 CF RES. 1/4W 10K J

!R944 VE-30001211 FUSE RES. 1W 1K J

CAPACITOR

C901 VE-30000275 CER CAP. 8PF 50V D CH

C902 VE-30000294 SMD CAP. 100NF 50V K

C903 VE-30000075 MKT CAP. 100NF 250V K (DC)

C904 VE-30000265 SMD CAP. 560PF 50V J

!Symbol No. Part No. Part Name Description

CAPACITOR

C905 VE-30000209 SMD CAP. 18PF 50V J

C906 VE-30000294 SMD CAP. 100NF 50V K

C907 VE-30000075 MKT CAP. 100NF 250V K (DC)

C908 VE-30000265 SMD CAP. 560PF 50V J

C909 VE-30000220 SMD CAP. 22PF 50V J

C910 VE-30000294 SMD CAP. 100NF 50V K

C911 VE-30000075 MKT CAP. 100NF 250V K (DC)

C912 VE-30000265 SMD CAP. 560PF 50V J

C914 VE-30000072 MKT CAP. 10NF 1250V J

C915 VE-30000415 EL CAP. 4.7UF 250V M

C916 VE-30000330 CER CAP. 4.7NF 50V K B

C919 VE-30000352 EL CAP. 100UF 16V M

C920 VE-30000294 SMD CAP. 100NF 50V K

C921 VE-30000359 EL CAP. 1000UF 16V M

C922 VE-30000075 MKT CAP. 100NF 250V K (DC)

C923 VE-30000406 EL CAP. 47UF 250V M (HR)

C931 VE-30000265 SMD CAP. 560PF 50V J

C934 VE-30000294 SMD CAP. 100NF 50V K

C935 VE-30000294 SMD CAP. 100NF 50V K

C936 VE-30000075 MKT CAP. 100NF 250V K (DC)

C938 VE-30000433 CER CAP. 1NF 1KV M B

C949 VE-30000294 SMD CAP. 100NF 50V K

COIL

L904 VE-30001997 FIXED COIL 33UH Q60 J

L921 VE-30001994 FIXED COIL 22UH J AXIAL

DIODE

D902 VE-30001318 DIODE

D907 VE-30001284 DIODE

TRANSISTOR

Q901 VE-30001427 TR

Q902 VE-30001455 TR

IC901 VE-30001551 IC

IC902 VE-30001551 IC

IC903 VE-30001551 IC

OTHERS

!PL904 VE-30001855 CRT SOCKET

SP901 VE-30000428 SPARK GAP 300V

SP903 VE-30000428 SPARK GAP 300V

SP904 VE-30000428 SPARK GAP 300V

SP905 VE-30000428 SPARK GAP 300V

SP906 VE-30000428 SPARK GAP 300V

SP907 VE-30000428 SPARK GAP 300V

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8ENS / AV-28BH8ENB

FRONT CONTROL P.W. BOARD ASS’Y

(VE-20082481 : Common to all models)

!Symbol No. Part No. Part Name Description

RESISTOR

R1 VE-30000689 CF RES. 1/4W 3.9K J

R2 VE-30000526 CF RES. 1/4W 1.5K J

R3 VE-30000770 CF RES. 1/4W 680R J

R4 VE-30000712 CF RES. 1/4W 470R J

R5 VE-30000622 CF RES. 1/4W 270R J

DIODE

D1 VE-30001279 LED RED/GREEN

IC1 VE-30001670 PREAMPLIFIER

OTHERS

SW1 VE-30002181 SWITCH TACT V-

SW2 VE-30002181 SWITCH TACT MENU

SW3 VE-30002181 SWITCH TACT P+

SW4 VE-30002181 SWITCH TACT P-

SW5 VE-30002181 SWITCH TACT V+

FRONT AV & HEADPHONE P.W. BOARD ASS’Y

(VE-20083091 : Common to all models)

!Symbol No. Part No. Part Name Description

RESISTOR

R107 VE-30000594 CF RES. 1/4W 22K J

R108 VE-30000712 CF RES. 1/4W 470R J

R109 VE-30000594 CF RES. 1/4W 22K J

R110 VE-30000712 CF RES. 1/4W 470R J

R113 VE-30000744 CF RES. 1/4W 560R J

R114 VE-30000744 CF RES. 1/4W 560R J

R115 VE-30000712 CF RES. 1/4W 470R J

R116 VE-30000712 CF RES. 1/4W 470R J

CAPACITOR

C103 VE-30000213 CER CAP. 180PF 50V J CH

C104 VE-30000213 CER CAP. 180PF 50V J CH

C106 VE-30000190 CER CAP. 100PF 50V J CH

COIL

L103 VE-30001996 FIXED COIL 22UH Q40 K

L104 VE-30001996 FIXED COIL 22UH Q40 K

OTHERS

CON102 VE-30001893 RCA JACK

CON103 VE-30001891 RCA JACK

CON104 VE-30001892 RCA JACK

CON106 VE-30001900 HEADPHONE JACK

T103 VE-30001962 FERRITE

T104 VE-30001963 FERRITE

T107 VE-30001963 FERRITE

[ AV-28BH8ENS / AV-28BH8ENB ]

No. 52086

V-28BH8EPS / AV-28BH8EPB

PRINTED WIRING BOARD PARTS LIST

MAIN P.W. BOARD ASS’Y (VE-20106734)

!Symbol No. Part No. Part Name Description

VARIABLE RESISTOR

VR127 VE-30001041 ADJ RES. 1/6W 1K M VER

VR401 VE-30001058 ADJ RES. 1/6W 22K VER (OTO)

RESISTOR

R101 VE-30000668 SMD RES. 1/10W 33K J

R102 VE-30007782 MF RES. 1/4W 3.9M F

R103 VE-30000855 MF RES. 1/4W 1M F

R104 VE-30000668 SMD RES. 1/10W 33K J

R105 VE-30000452 CF RES. 1/4W 10R J

R106 VE-30000664 SMD RES. 1/10W 3.3K J

R107 VE-30007019 SMD RES. 1/10W 10K F

R108 VE-30007784 MO RES. 5W 33K J(RADIAL)

!R109 VE-30001270 PTC 9 OHM

R116 VE-30001171 MO RES. 2W 4.7K J

!R117 VE-30001257 MG RES. 1/2W 4.7M J

!R118 VE-30009036 FUSE RES. 1/2W 0.1R J

!R119 VE-30009036 FUSE RES. 1/2W 0.1R J

R120 VE-30000814 SMD RES. 1/10W 820R J

R122 VE-30000469 SMD RES. 1/10W 1K J

R123 VE-30000469 SMD RES. 1/10W 1K J

R124 VE-30000480 SMD RES. 1/10W 100K J

R125 VE-30000927 MF RES. 1/4W 220K J

R126 VE-30000664 SMD RES. 1/10W 3.3K J

R127 VE-30000469 SMD RES. 1/10W 1K J

R128 VE-30000536 CF RES. 1/4W 150K J

R129 VE-30007019 SMD RES. 1/10W 10K F

R130 VE-30000721 SMD RES. 1/10W 4.7K J

R134 VE-30000469 SMD RES. 1/10W 1K J

R135 VE-30007790 SMD RES. 1/10W 4.3K F

R136 VE-30000774 SMD RES. 1/10W 680R J

R137 VE-30007021 SMD RES. 1/10W 1K F

R138 VE-30007786 SMD RES. 1/10W 2.55K F

R139 VE-30000774 SMD RES. 1/10W 680R J

R140 VE-30000459 CF RES. 1/4W 100R J

R141 VE-30000475 SMD RES. 1/10W 10K J

R142 VE-30000475 SMD RES. 1/10W 10K J

R143 VE-30007021 SMD RES. 1/10W 1K F

R144 VE-30007788 SMD RES. 1/10W 2.7K F

R145 VE-30000732 SMD RES. 1/10W 470K J

R146 VE-30000469 SMD RES. 1/10W 1K J

!R148 VE-30014023 FUSE RES. 1/2W 0.1R J VISHAY

R149 VE-30007204 MF RES. 1/2W 1.5M F

!R150 VE-30007783 FUSE RES. 1/4W 2.2R J

!R151 VE-30014023 FUSE RES. 1/2W 0.1R J VISHAY

R152 VE-30000659 SMD RES. 1/10W 330R J

R153 VE-30012649 SMD RES. 1/16W 150R J

R154 VE-30012984 SMD RES. 1/16W 91R J

R155 VE-30000712 CF RES. 1/4W 470R J

R156 VE-30001089 MO RES. 2W 1R J

R157 VE-30000534 SMD RES. 1/10W 15K J

R158 VE-30000475 SMD RES. 1/10W 10K J

R159 VE-30000480 SMD RES. 1/10W 100K J

R160 VE-30006923 SMD RES. 1/10W 4.3K J

R202 VE-30007779 MO RES. 5W 47R J(RADIAL)

R203 VE-30000631 SMD RES. 1/10W 2.7K J

R205 VE-30017136 MO RES. 1W 0.56R J

R206 VE-30001080 MO RES. 2W 100R J

R210 VE-30000583 CF RES. 1/4W 220R J

R211 VE-30000721 SMD RES. 1/10W 4.7K J

R212 VE-30000593 SMD RES. 1/10W 2.2K J

R213 VE-30000593 SMD RES. 1/10W 2.2K J

R214 VE-30000593 SMD RES. 1/10W 2.2K J

R215 VE-30000721 SMD RES. 1/10W 4.7K J

R216 VE-30000631 SMD RES. 1/10W 2.7K J

R217 VE-30000593 SMD RES. 1/10W 2.2K J

R218 VE-30000480 SMD RES. 1/10W 100K J

R220 VE-30000590 CF RES. 1/4W 2.2K J

R225 VE-30001086 MO RES. 2W 10K J

R226 VE-30001168 MO RES. 2W 470RJ

R227 VE-30000469 SMD RES. 1/10W 1K J

R228 VE-30000475 SMD RES. 1/10W 10K J

R229 VE-30000727 SMD RES. 1/10W 47K J

R230 VE-30000902 MF RES. 1/4W 1.8K F

!R231 VE-30001229 FUSE RES. 1W 2.2R J

R232 VE-30001027 MF RES. 1/4W 82K J

!R233 VE-30001244 FUSE RES. 1/2W 0.47R J

!R234 VE-30009036 FUSE RES. 1/2W 0.1R J

R235 VE-30000668 SMD RES. 1/10W 33K J

!Symbol No. Part No. Part Name Description

RESISTOR

R236 VE-30000718 CF RES. 1/4W 4.7K J

!R237 VE-30001244 FUSE RES. 1/2W 0.47R J

R238 VE-30000729 CF RES. 1/4W 470K J

!R239 VE-30001215 FUSE RES. 1W 1R J

R240 VE-30000469 SMD RES. 1/10W 1K J

R241 VE-30000818 SMD RES. 1/10W 8.2K J

R242 VE-30000784 CF RES. 1/4W 680K J

R245 VE-30000466 CF RES. 1/4W 1K J

R246 VE-30001027 MF RES. 1/4W 82K J

R250 VE-30000477 CF RES. 1/4W 100K J

R251 VE-30000477 CF RES. 1/4W 100K J

R252 VE-30007789 SMD RES. 1/10W 27K F

R254 VE-30000636 SMD RES. 1/10W 27K J

R255 VE-30001134 MO RES. 2W 2.2R J

R256 VE-30001100 MO RES. 1W 150R J

R257 VE-30001173 MO RES. 1W 0.47R J

R260 VE-30000778 SMD RES. 1/10W 6.8K J

R261 VE-30000778 SMD RES. 1/10W 6.8K J

!R262 VE-30001237 FUSE RES. 1/2W 3.3R J

R264 VE-30001077 MO RES. 2W 10R J

R270 VE-30000541 CF RES. 1/4W 1.5M J

R271 VE-30000744 CF RES. 1/4W 560R J

R272 VE-30000475 SMD RES. 1/10W 10K J

R280 VE-30000727 SMD RES. 1/10W 47K J

R281 VE-30000480 SMD RES. 1/10W 100K J

R318 VE-30000469 SMD RES. 1/10W 1K J

R322 VE-30000594 CF RES. 1/4W 22K J

R323 VE-30000459 CF RES. 1/4W 100R J

R324 VE-30000464 SMD RES. 1/10W 100R J

R327 VE-30000464 SMD RES. 1/10W 100R J

R360 VE-30000659 SMD RES. 1/10W 330R J

R361 VE-30000659 SMD RES. 1/10W 330R J

R362 VE-30000659 SMD RES. 1/10W 330R J

R363 VE-30000659 SMD RES. 1/10W 330R J

R364 VE-30000659 SMD RES. 1/10W 330R J

R365 VE-30000659 SMD RES. 1/10W 330R J

R366 VE-30000659 SMD RES. 1/10W 330R J

R367 VE-30000659 SMD RES. 1/10W 330R J

R368 VE-30000659 SMD RES. 1/10W 330R J

R369 VE-30000659 SMD RES. 1/10W 330R J

R370 VE-30000659 SMD RES. 1/10W 330R J

R371 VE-30000659 SMD RES. 1/10W 330R J

R372 VE-30000659 SMD RES. 1/10W 330R J

R373 VE-30000659 SMD RES. 1/10W 330R J

R374 VE-30000659 SMD RES. 1/10W 330R J

R375 VE-30000659 SMD RES. 1/10W 330R J

R376 VE-30000659 SMD RES. 1/10W 330R J

R378 VE-30000659 SMD RES. 1/10W 330R J

R379 VE-30000659 SMD RES. 1/10W 330R J

R380 VE-30000659 SMD RES. 1/10W 330R J

R381 VE-30000659 SMD RES. 1/10W 330R J

R382 VE-30000659 SMD RES. 1/10W 330R J

R383 VE-30000659 SMD RES. 1/10W 330R J

R384 VE-30000659 SMD RES. 1/10W 330R J

R385 VE-30000659 SMD RES. 1/10W 330R J

R397 VE-30000659 SMD RES. 1/10W 330R J

R398 VE-30000659 SMD RES. 1/10W 330R J

R401 VE-30000665 CF RES. 1/4W 33K J

R403 VE-30000668 SMD RES. 1/10W 33K J

R411 VE-30000721 SMD RES. 1/10W 4.7K J

R412 VE-30000721 SMD RES. 1/10W 4.7K J

R413 VE-30000475 SMD RES. 1/10W 10K J

R414 VE-30000469 SMD RES. 1/10W 1K J

R415 VE-30000517 SMD RES. 1/10W 15R J

R416 VE-30000717 SMD RES. 1/10W 470R J

R417 VE-30000778 SMD RES. 1/10W 6.8K J

R418 VE-30000593 SMD RES. 1/10W 2.2K J

R421 VE-30000563 SMD RES. 1/10W 1.8K J

R422 VE-30000464 SMD RES. 1/10W 100R J

R424 VE-30007021 SMD RES. 1/10W 1K F

R425 VE-30000797 SMD RES. 1/10W 75R J

R428 VE-30000475 SMD RES. 1/10W 10K J

R429 VE-30000475 SMD RES. 1/10W 10K J

R432 VE-30000787 SMD RES. 1/10W 680K J

R437 VE-30000499 SMD RES. 1/10W 1.2K J

R438 VE-30000655 CF RES. 1/4W 330R J

R439 VE-30000560 CF RES. 1/4W 1.8K J

R441 VE-30000751 SMD RES. 1/10W 5.6K J

[ AV-28BH8EPS / AV-28BH8EPB ]

No. 52086

V-28BH8EPS / AV-28BH8EPB

!Symbol No. Part No. Part Name Description

RESISTOR

R445 VE-30000814 SMD RES. 1/10W 820R J

R446 VE-30000469 SMD RES. 1/10W 1K J

R447 VE-30000469 SMD RES. 1/10W 1K J

R475 VE-30000524 SMD RES. 1/10W 150R J

R480 VE-30000718 CF RES. 1/4W 4.7K J

R490 VE-30000466 CF RES. 1/4W 1K J

R492 VE-30000503 SMD RES. 1/10W 12K J

R506 VE-30012695 SMD RES. 1/16W 470R J

R509 VE-30000797 SMD RES. 1/10W 75R J

R510 VE-30007021 SMD RES. 1/10W 1K F

R511 VE-30000464 SMD RES. 1/10W 100R J

R512 VE-30000464 SMD RES. 1/10W 100R J

R513 VE-30000457 SMD RES. 1/10W 10R J

R516 VE-30007026 SMD RES. 1/10W 5.1K J

R517 VE-30007026 SMD RES. 1/10W 5.1K J

R518 VE-30000735 SMD RES. 1/10W 4.7R J

R801 VE-30000718 CF RES. 1/4W 4.7K J

R802 VE-30000718 CF RES. 1/4W 4.7K J

R803 VE-30000628 CF RES. 1/4W 2.7K J

R804 VE-30000475 SMD RES. 1/10W 10K J

R805 VE-30000534 SMD RES. 1/10W 15K J

R806 VE-30000531 CF RES. 1/4W 15K J

R807 VE-30000567 SMD RES. 1/10W 18K J

R808 VE-30000734 CF RES. 1/4W 4.7R J

R809 VE-30000717 SMD RES. 1/10W 470R J

R810 VE-30000564 CF RES. 1/4W 18K J

R811 VE-30000717 SMD RES. 1/10W 470R J

R812 VE-30000734 CF RES. 1/4W 4.7R J

R813 VE-30000475 SMD RES. 1/10W 10K J

R819 VE-30000734 CF RES. 1/4W 4.7R J

R820 VE-30000734 CF RES. 1/4W 4.7R J

R900 VE-30012641 SMD RES. 1/16W 10K J

R901 VE-30012641 SMD RES. 1/16W 10K J

R902 VE-30012641 SMD RES. 1/16W 10K J

R903 VE-30000718 CF RES. 1/4W 4.7K J

R904 VE-30000718 CF RES. 1/4W 4.7K J

R905 VE-30000723 CF RES. 1/4W 47K J

R906 VE-30012696 SMD RES. 1/16W 47K J

R907 VE-30012679 SMD RES. 1/16W 3.9K J

R908 VE-30012679 SMD RES. 1/16W 3.9K J

R909 VE-30000531 CF RES. 1/4W 15K J

R910 VE-30000531 CF RES. 1/4W 15K J

R911 VE-30012641 SMD RES. 1/16W 10K J

R912 VE-30000471 CF RES. 1/4W 10K J

R913 VE-30012641 SMD RES. 1/16W 10K J

R914 VE-30000471 CF RES. 1/4W 10K J

R915 VE-30000471 CF RES. 1/4W 10K J

R916 VE-30012695 SMD RES. 1/16W 470R J

R917 VE-30012987 SMD RES. 1/16W 56R J

R918 VE-30012692 SMD RES. 1/16W 4.7K J

R919 VE-30012657 SMD RES. 1/16W 1K J

R920 VE-30012657 SMD RES. 1/16W 1K J

R921 VE-30012657 SMD RES. 1/16W 1K J

R922 VE-30012657 SMD RES. 1/16W 1K J

R923 VE-30012657 SMD RES. 1/16W 1K J

R924 VE-30012696 SMD RES. 1/16W 47K J

R925 VE-30012696 SMD RES. 1/16W 47K J

R926 VE-30012696 SMD RES. 1/16W 47K J

R927 VE-30012696 SMD RES. 1/16W 47K J

R928 VE-30012510 SMD RES. 1/16W 100R J

R929 VE-30012510 SMD RES. 1/16W 100R J

R930 VE-30012641 SMD RES. 1/16W 10K J

R931 VE-30012641 SMD RES. 1/16W 10K J

R932 VE-30012641 SMD RES. 1/16W 10K J

R933 VE-30000718 CF RES. 1/4W 4.7K J

R934 VE-30012692 SMD RES. 1/16W 4.7K J

R935 VE-30012662 SMD RES. 1/16W 2.7K J

R936 VE-30000718 CF RES. 1/4W 4.7K J

R937 VE-30000459 CF RES. 1/4W 100R J

R938 VE-30012509 SMD RES. 1/16W 100K J

R939 VE-30012692 SMD RES. 1/16W 4.7K J

R940 VE-30000500 CF RES. 1/4W 12K J

R941 VE-30000588 SMD RES. 1/10W 220R J

R942 VE-30000588 SMD RES. 1/10W 220R J

R943 VE-30000471 CF RES. 1/4W 10K J

R944 VE-30012641 SMD RES. 1/16W 10K J

R945 VE-30000471 CF RES. 1/4W 10K J

R946 VE-30012657 SMD RES. 1/16W 1K J

R950 VE-30012657 SMD RES. 1/16W 1K J

R951 VE-30012657 SMD RES. 1/16W 1K J

R952 VE-30012657 SMD RES. 1/16W 1K J

R953 VE-30000466 CF RES. 1/4W 1K J

!Symbol No. Part No. Part Name Description

RESISTOR

R955 VE-30012657 SMD RES. 1/16W 1K J

R956 VE-30012510 SMD RES. 1/16W 100R J

R957 VE-30012655 SMD RES. 1/16W 180R J

R958 VE-30014022 SMD RES. 1/16W 47R J

R959 VE-30000466 CF RES. 1/4W 1K J

R960 VE-30000471 CF RES. 1/4W 10K J

R961 VE-30000718 CF RES. 1/4W 4.7K J

R964 VE-30012641 SMD RES. 1/16W 10K J

R965 VE-30012657 SMD RES. 1/16W 1K J

R966 VE-30012641 SMD RES. 1/16W 10K J

R967 VE-30012650 SMD RES. 1/16W 15K J

R968 VE-30000692 SMD RES. 1/10W 3.9K J

CAPACITOR

C100 VE-30000098 MKT CAP. 3.3NF 63V J

C101 VE-30000371 EL CAP. 22UF 50V M

C102 VE-30000294 SMD CAP. 100NF 50V K

C103 VE-30000294 SMD CAP. 100NF 50V K

C104 VE-30012323 MKT CAP. 1NF 100V J WIMA FKI2

C105 VE-30000284 SMD CAP. 1NF 50V K R

C106 VE-30000332 SMD CAP. 4.7NF 50V K

C107 VE-30000263 SMD CAP. 56PF 50V J CH

C108 VE-30000123 PP CAP. 33NF 630V K

C109 VE-30000159 MKP CAP. 4.7NF 1.6KV J

C110 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C111 VE-30000131 MKP CAP. 100NF 250V J

!C112 VE-30000094 MKT CAP. 220NF AC275V M

C114 VE-30000353 EL CAP. 100UF 25V M

!C115 VE-30007858 MKT CAP. 470NF AC275V M (P=22.5

!C118 VE-30007755 MKT CAP. 680NF AC275V M X2

C119 VE-30007754 MKP CAP. 1UF 400V

C120 VE-30007753 MKP CAP. 1NF 1KV

C121 VE-30013690 EL CAP. 220UF 450V M 105°C

!C122 VE-30000447 CER CAP. 4.7NF 4KV M E

C124 VE-30000315 SMD CAP. 220NF 25V Z

C125 VE-30000315 SMD CAP. 220NF 25V Z

C130 VE-30007708 CER CAP. 1NF 1KV K (PULSE)

C131 VE-30006909 EL CAP. 100UF M 250V

C132 VE-30007750 EL CAP. 470UF 35V (H/R 1150MA)

C133 VE-30000409 EL CAP. 470UF 25V M

C134 VE-30007750 EL CAP. 470UF 35V (H/R 1150MA)

C135 VE-30007748 EL CAP. 1000UF 35V M

C136 VE-30007748 EL CAP. 1000UF 35V M

C137 VE-30000284 SMD CAP. 1NF 50V K R

C138 VE-30000224 SMD CAP. 220PF 50V J

C139 VE-30000284 SMD CAP. 1NF 50V K R

C140 VE-30000360 EL CAP. 1000UF 25V M

C141 VE-30000352 EL CAP. 100UF 16V M

C142 VE-30000294 SMD CAP. 100NF 50V K

C143 VE-30000294 SMD CAP. 100NF 50V K

C144 VE-30000352 EL CAP. 100UF 16V M

C145 VE-30000309 SMD CAP. 2.2NF 50V K R

C146 VE-30000359 EL CAP. 1000UF 16V M

C147 VE-30000359 EL CAP. 1000UF 16V M

C148 VE-30000294 SMD CAP. 100NF 50V K

C149 VE-30000294 SMD CAP. 100NF 50V K

C150 VE-30000352 EL CAP. 100UF 16V M

C151 VE-30000284 SMD CAP. 1NF 50V K R

C160 VE-30007081 EL CAP. 4.7UF 50V M (NPL)

C161 VE-30007308 CER CAP. 220PF 1KV K (PULSE)

C162 VE-30007308 CER CAP. 220PF 1KV K (PULSE)

C163 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C165 VE-30016654 SMD CAP. 100NF 16V K R

C166 VE-30000355 EL CAP. 100UF 50V M

C167 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C168 VE-30000294 SMD CAP. 100NF 50V K

C170 VE-30000352 EL CAP. 100UF 16V M

C171 VE-30000352 EL CAP. 100UF 16V M

C172 VE-30016654 SMD CAP. 100NF 16V K R

C173 VE-30000315 SMD CAP. 220NF 25V Z

C201 VE-30000400 EL CAP. 47UF 50V M

C202 VE-30000106 MKT CAP. 47NF 100V J

C203 VE-30000099 MKT CAP. 33NF 63V J

C204 VE-30000345 EL CAP. 10UF 50V M

C206 VE-30000315 SMD CAP. 220NF 25V Z

C207 VE-30000362 EL CAP. 1UF 50V M

C208 VE-30000415 EL CAP. 4.7UF 250V M

C209 VE-30000224 SMD CAP. 220PF 50V J

C210 VE-30000149 MKP CAP. 2.7NF 2KV %3.5

C211 VE-30000179 MKP CAP. 9.1NF 1600V %3.5

[ AV-28BH8EPS / AV-28BH8EPB ]

No. 52086

V-28BH8EPS / AV-28BH8EPB

!Symbol No. Part No. Part Name Description

CAPACITOR

C212 VE-30000137 MKP CAP. 15NF 630V J

C213 VE-30007215 MKP CAP. 1.2UF 250V J

C214 VE-30000415 EL CAP. 4.7UF 250V M

C215 VE-30000167 MKP CAP. 560NF 250V J

C216 VE-30000406 EL CAP. 47UF 250V M (HR)

C222 VE-30000431 CER CAP. 100PF 1KV M

C223 VE-30000351 EL CAP. 10UF 350V M

C225 VE-30000359 EL CAP. 1000UF 16V M

C226 VE-30000356 EL CAP. 100UF 63V M

C228 VE-30000360 EL CAP. 1000UF 25V M

C232 VE-30000225 CER CAP. 220PF 50V J SL

C240 VE-30000354 EL CAP. 100UF 35V M

C250 VE-30000304 SMD CAP. 1.8NF 50V K R

C251 VE-30000359 EL CAP. 1000UF 16V M

C252 VE-30000289 SMD CAP. 10NF 50V K R

C253 VE-30000294 SMD CAP. 100NF 50V K

C254 VE-30000360 EL CAP. 1000UF 25V M

C255 VE-30000294 SMD CAP. 100NF 50V K

C256 VE-30000078 MKT CAP. 1UF 100V M

C257 VE-30000304 SMD CAP. 1.8NF 50V K R

C258 VE-30000322 SMD CAP. 3.3NF 50V K

C305 VE-30000294 SMD CAP. 100NF 50V K

C313 VE-30000189 SMD CAP. 100PF 50V J

C321 VE-30000352 EL CAP. 100UF 16V M

C322 VE-30000352 EL CAP. 100UF 16V M

C324 VE-30000294 SMD CAP. 100NF 50V K

C333 VE-30000294 SMD CAP. 100NF 50V K

C402 VE-30000345 EL CAP. 10UF 50V M

C403 VE-30000393 EL CAP. 3.3UF 50V M

C404 VE-30000284 SMD CAP. 1NF 50V K R

C405 VE-30000284 SMD CAP. 1NF 50V K R

C406 VE-30000220 SMD CAP. 22PF 50V J

C407 VE-30000312 SMD CAP. 22NF 50V K

C408 VE-30000371 EL CAP. 22UF 50V M

C409 VE-30000294 SMD CAP. 100NF 50V K

C410 VE-30000294 SMD CAP. 100NF 50V K

C411 VE-30000109 MKT CAP. 470NF 63V J

C412 VE-30000384 EL CAP. 2.2UF 50V M

C413 VE-30000294 SMD CAP. 100NF 50V K

C414 VE-30000294 SMD CAP. 100NF 50V K

C417 VE-30000294 SMD CAP. 100NF 50V K

C418 VE-30000294 SMD CAP. 100NF 50V K

C419 VE-30000294 SMD CAP. 100NF 50V K

C424 VE-30000387 EL CAP. 33UF 50V M

C427 VE-30000294 SMD CAP. 100NF 50V K

C428 VE-30000294 SMD CAP. 100NF 50V K

C430 VE-30000294 SMD CAP. 100NF 50V K

C440 VE-30000355 EL CAP. 100UF 50V M

C441 VE-30000220 SMD CAP. 22PF 50V J

C442 VE-30000294 SMD CAP. 100NF 50V K

C443 VE-30013411 SMD CAP. 180PF 50V J

C450 VE-30000345 EL CAP. 10UF 50V M

C451 VE-30000294 SMD CAP. 100NF 50V K

C453 VE-30000355 EL CAP. 100UF 50V M

C454 VE-30000294 SMD CAP. 100NF 50V K

C456 VE-30000352 EL CAP. 100UF 16V M

C457 VE-30000294 SMD CAP. 100NF 50V K

C468 VE-30000294 SMD CAP. 100NF 50V K

C478 VE-30000294 SMD CAP. 100NF 50V K

C479 VE-30000362 EL CAP. 1UF 50V M

C491 VE-30000400 EL CAP. 47UF 50V M

C492 VE-30000294 SMD CAP. 100NF 50V K

C494 VE-30000362 EL CAP. 1UF 50V M

C496 VE-30000413 EL CAP. 4.7UF 50V M

C497 VE-30000294 SMD CAP. 100NF 50V K

C498 VE-30000294 SMD CAP. 100NF 50V K

C499 VE-30000362 EL CAP. 1UF 50V M

C500 VE-30000352 EL CAP. 100UF 16V M

C505 VE-30000294 SMD CAP. 100NF 50V K

C506 VE-30000345 EL CAP. 10UF 50V M

C509 VE-30000186 SMD CAP. 10PF 50V D COG

C510 VE-30000186 SMD CAP. 10PF 50V D COG

C511 VE-30000341 SMD CAP. 68NF 50V K

C610 VE-30000074 MKT CAP. 100NF 63V J

C801 VE-30000362 EL CAP. 1UF 50V M

C802 VE-30000362 EL CAP. 1UF 50V M

C804 VE-30000409 EL CAP. 470UF 25V M

C805 VE-30000294 SMD CAP. 100NF 50V K

C806 VE-30000409 EL CAP. 470UF 25V M

C807 VE-30000294 SMD CAP. 100NF 50V K

C808 VE-30000074 MKT CAP. 100NF 63V J

C809 VE-30000074 MKT CAP. 100NF 63V J

C819 VE-30000309 SMD CAP. 2.2NF 50V K R

C820 VE-30000309 SMD CAP. 2.2NF 50V K R

!Symbol No. Part No. Part Name Description

CAPACITOR

C821 VE-30000309 SMD CAP. 2.2NF 50V K R

C822 VE-30000309 SMD CAP. 2.2NF 50V K R

C823 VE-30000345 EL CAP. 10UF 50V M

C900 VE-30000371 EL CAP. 22UF 50V M

C901 VE-30016654 SMD CAP. 100NF 16V K R

C902 VE-30016654 SMD CAP. 100NF 16V K R

C903 VE-30016654 SMD CAP. 100NF 16V K R

C904 VE-30000074 MKT CAP. 100NF 63V J

C905 VE-30000371 EL CAP. 22UF 50V M

C906 VE-30016654 SMD CAP. 100NF 16V K R

C907 VE-30000074 MKT CAP. 100NF 63V J

C908 VE-30016654 SMD CAP. 100NF 16V K R

C909 VE-30016654 SMD CAP. 100NF 16V K R

C910 VE-30016654 SMD CAP. 100NF 16V K R

C911 VE-30000352 EL CAP. 100UF 16V M

C912 VE-30012569 SMD CAP. 33PF 50V J

C913 VE-30012569 SMD CAP. 33PF 50V J

C914 VE-30000371 EL CAP. 22UF 50V M

C915 VE-30016654 SMD CAP. 100NF 16V K R

C916 VE-30016654 SMD CAP. 100NF 16V K R

C917 VE-30016654 SMD CAP. 100NF 16V K R

C918 VE-30016654 SMD CAP. 100NF 16V K R

C919 VE-30000375 EL CAP. 220UF 16V M

C920 VE-30000384 EL CAP. 2.2UF 50V M

C921 VE-30016654 SMD CAP. 100NF 16V K R

C926 VE-30016654 SMD CAP. 100NF 16V K R

C927 VE-30016654 SMD CAP. 100NF 16V K R

C930 VE-30000345 EL CAP. 10UF 50V M

C931 VE-30000243 CER CAP. 330PF 50V J CH

C932 VE-30016654 SMD CAP. 100NF 16V K R

C933 VE-30000294 SMD CAP. 100NF 50V K

C934 VE-30000068 MKT CAP. 1NF 63V K

C935 VE-30000106 MKT CAP. 47NF 100V J

TRANSFORMER

!TR101 VE-30016819 SMPS TRF

TR201 VE-30006743 HORIZONTAL DRIVER TRF

!TR202 VE-30016922 FBT TRF

COIL

L101 VE-30006712 FERRITE BEAD

L102 VE-30007775 PFC COIL 1MH 1KHZ 2A

L106 VE-30006712 FERRITE BEAD

L107 VE-30001960 FERIT BAR

L108 VE-30001960 FERIT BAR

L109 VE-30001960 FERIT BAR

L201 VE-30007771 FIXED COIL 100UH

L202 VE-30007757 INJECTION COIL 6MH AK28

L203 VE-30007770 FILTER COIL 1MH AK28

L204 VE-30012271 LINEARTY COIL 4.3UH VOGT

L205 VE-30007756 BRIDGE COIL 150UH 32KHZ AK28

L206 VE-30006712 FERRITE BEAD

L207 VE-30006712 FERRITE BEAD

L304 VE-30001992 FIXED COIL 10UH Q65 K-A

L401 VE-30001986 FIXED COIL 3.3UH Q65 K

L403 VE-30001979 FIXED COIL 1UH Q45 M-A

L405 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L420 VE-30001996 FIXED COIL 22UH Q40 K

L421 VE-30001992 FIXED COIL 10UH Q65 K-A

L422 VE-30001994 FIXED COIL 22UH J AXIAL

L423 VE-30001994 FIXED COIL 22UH J AXIAL

L425 VE-30001971 FERRITE BEAT

L426 VE-30001994 FIXED COIL 22UH J AXIAL

L427 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L428 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L429 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L430 VE-30001987 FIXED COIL 4.7UH Q70 K-A

L801 VE-30002170 FTZ/RAD COIL

L802 VE-30002170 FTZ/RAD COIL

L900 VE-30001992 FIXED COIL 10UH Q65 K-A

L901 VE-30001992 FIXED COIL 10UH Q65 K-A

L902 VE-30001992 FIXED COIL 10UH Q65 K-A

L903 VE-30001992 FIXED COIL 10UH Q65 K-A

L904 VE-30001987 FIXED COIL 4.7UH Q70 K-A

DIODE

D101 VE-30001285 DIODE

D102 VE-30001291 DIODE

[ AV-28BH8EPS / AV-28BH8EPB ]

No. 52086

V-28BH8EPS / AV-28BH8EPB

!Symbol No. Part No. Part Name Description

DIODE

D103 VE-30007768 DIODE

D104 VE-30007768 DIODE

D105 VE-30007768 DIODE

D106 VE-30007758 BRIDGE DIODE

D108 VE-30001318 DIODE

D109 VE-30009699 ZENER DIODE

D110 VE-30001301 DIODE

D111 VE-30001299 DIODE

D112 VE-30001302 DIODE

D113 VE-30001302 DIODE

D114 VE-30001302 DIODE

D115 VE-30001285 DIODE

D116 VE-30007760 ZENER DIODE

D117 VE-30001285 DIODE

D118 VE-30007760 ZENER DIODE

D119 VE-30001284 DIODE

D120 VE-30001291 DIODE

D121 VE-30001318 DIODE

D122 VE-30001318 DIODE

D123 VE-30001285 DIODE

D126 VE-30001284 DIODE

D127 VE-30001284 DIODE

D128 VE-30001284 DIODE

D201 VE-30001291 DIODE

D202 VE-30001285 DIODE

D203 VE-30007760 ZENER DIODE

D205 VE-30007763 ZENER DIODE

D206 VE-30007678 DIODE

D207 VE-30007768 DIODE

D208 VE-30001291 DIODE

D209 VE-30001291 DIODE

D210 VE-30001299 DIODE

D211 VE-30001299 DIODE

D212 VE-30001291 DIODE

D213 VE-30001291 DIODE

D214 VE-30007763 ZENER DIODE

D215 VE-30007762 ZENER DIODE

D216 VE-30001285 DIODE

D218 VE-30001291 DIODE

D219 VE-30001291 DIODE

D220 VE-30001284 DIODE

D221 VE-30001284 DIODE

D222 VE-30001284 DIODE

D223 VE-30001285 DIODE

D224 VE-30001285 DIODE

D225 VE-30001318 DIODE

D226 VE-30007760 ZENER DIODE

D227 VE-30001373 ZENER DIODE

D401 VE-30001285 DIODE

D402 VE-30001285 DIODE

D403 VE-30001285 DIODE

D900 VE-30012412 ZENER DIODE

TRANSISTOR

Q101 VE-30007801 TR

Q103 VE-30007802 TR

Q104 VE-30007798 TR

Q105 VE-30007798 TR

Q106 VE-30007802 TR

Q107 VE-30007798 TR

Q108 VE-30007798 TR

Q109 VE-30001457 TR

Q110 VE-30001457 TR

Q112 VE-30001454 TR

Q113 VE-30001428 TR

Q201 VE-30007802 TR

Q202 VE-30016686 TR

Q203 VE-30001458 TR

Q204 VE-30001458 TR

Q205 VE-30007799 TR

Q206 VE-30001457 TR

Q207 VE-30001457 TR

Q208 VE-30001455 TR

Q401 VE-30001457 TR

Q403 VE-30001457 TR

Q405 VE-30001457 TR

Q406 VE-30001457 TR

Q408 VE-30007800 TR

Q415 VE-30001457 TR

Q801 VE-30001457 TR

Q802 VE-30001457 TR

!Symbol No. Part No. Part Name Description

TRANSISTOR

Q900 VE-30001458 TR

Q901 VE-30001457 TR

Q902 VE-30001457 TR

Q903 VE-30001457 TR

Q904 VE-30001457 TR

Q905 VE-30001457 TR

Q906 VE-30001457 TR

Q907 VE-30001457 TR

Q908 VE-30001457 TR

Q909 VE-30001458 TR

Q910 VE-30001457 TR

Q911 VE-30001457 TR

IC101 VE-30007442 IC

!IC102 VE-30015087 IC

IC103 VE-30001506 IC

IC104 VE-30007444 IC

IC105 VE-30001500 IC

IC106 VE-30001668 IC

IC201 VE-30007793 IC

IC202 VE-30001506 IC

IC302 VE-20105614 IC (MEMORY)

IC304 VE-20098889 PR.IC. (MICOM)

IC401 VE-30001494 IC

IC802 VE-30007794 IC

IC900 VE-30013571 IC

OTHERS

!F101 VE-30001732 FUSE 3.15A 250V 5*20

!F102 VE-30009037 FUSE 6.3A 250V 5mm

!F103 VE-30009037 FUSE 6.3A 250V 5mm

!L103 VE-30006744 LINE FILTER 16MH

!L104 VE-30006744 LINE FILTER 16MH

RL2 VE-30002183 RELAY

S133 VE-30000575 SMD RES. 1/10W 2K J

T401 VE-30001724 SER FILTER

TU401 VE-30009637 TUNER

VL401 VE-30002036 ADJ COIL

X900 VE-30006662 XTAL

Z401 VE-30001706 SAW FILTER

Z403 VE-30001692 SAW FILTER

MULTISOUND P.W. BOARD ASS’Y (VE-20103705)

Refer to PARTS LIST in page 10 for this P.W. board

FEATURE BOX P.W. BOARD ASS’Y (VE-20055386)

Refer to PARTS LIST in page 11 for this P.W. board

CRT SOCKET P.W. BOARD ASS’Y (VE-20086313)

Refer to PARTS LIST in page 13 for this P.W. board

FRONT CONTROL P.W. BOARD ASS’Y

(VE-20082481)

Refer to PARTS LIST in page 14 for this P.W. board

FRONT AV & HEADPHONE P.W. BOARD ASS’Y

(VE-20083091)

Refer to PARTS LIST in page 14 for this P.W. board

[ AV-28BH8EPS / AV-28BH8EPB ]

No. 52086

V-28BH8EES / AV-28BH8EEB

PRINTED WIRING BOARD PARTS LIST

MAIN P.W. BOARD ASS’Y (VE-20106738)

!Symbol No. Part No. Part Name Description

VARIABLE RESISTOR

VR127 VE-30001041 ADJ RES. 1/6W 1K M VER

RESISTOR

R101 VE-30000668 SMD RES. 1/10W 33K J

R102 VE-30007782 MF RES. 1/4W 3.9M F

R103 VE-30000855 MF RES. 1/4W 1M F

R104 VE-30000668 SMD RES. 1/10W 33K J

R105 VE-30000452 CF RES. 1/4W 10R J

R106 VE-30000664 SMD RES. 1/10W 3.3K J

R107 VE-30007019 SMD RES. 1/10W 10K F

R108 VE-30007784 MO RES. 5W 33K J(RADIAL)

!R109 VE-30001270 PTC 9 OHM

R116 VE-30001171 MO RES. 2W 4.7K J

!R117 VE-30001257 MG RES. 1/2W 4.7M J

!R118 VE-30009036 FUSE RES. 1/2W 0.1R J

!R119 VE-30009036 FUSE RES. 1/2W 0.1R J

R120 VE-30000814 SMD RES. 1/10W 820R J

R122 VE-30000469 SMD RES. 1/10W 1K J

R123 VE-30000469 SMD RES. 1/10W 1K J

R124 VE-30000480 SMD RES. 1/10W 100K J

R125 VE-30000927 MF RES. 1/4W 220K J

R126 VE-30000664 SMD RES. 1/10W 3.3K J

R127 VE-30000469 SMD RES. 1/10W 1K J

R128 VE-30000536 CF RES. 1/4W 150K J

R129 VE-30007019 SMD RES. 1/10W 10K F

R130 VE-30000721 SMD RES. 1/10W 4.7K J

R134 VE-30000469 SMD RES. 1/10W 1K J

R135 VE-30007790 SMD RES. 1/10W 4.3K F

R136 VE-30000774 SMD RES. 1/10W 680R J

R137 VE-30007021 SMD RES. 1/10W 1K F

R138 VE-30007786 SMD RES. 1/10W 2.55K F

R139 VE-30000774 SMD RES. 1/10W 680R J

R140 VE-30000459 CF RES. 1/4W 100R J

R141 VE-30000475 SMD RES. 1/10W 10K J

R142 VE-30000475 SMD RES. 1/10W 10K J

R143 VE-30007021 SMD RES. 1/10W 1K F

R144 VE-30007788 SMD RES. 1/10W 2.7K F

R145 VE-30000732 SMD RES. 1/10W 470K J

R146 VE-30000469 SMD RES. 1/10W 1K J

!R148 VE-30014023 FUSE RES. 1/2W 0.1R J VISHAY

R149 VE-30007204 MF RES. 1/2W 1.5M F

!R150 VE-30007783 FUSE RES. 1/4W 2.2R J

!R151 VE-30014023 FUSE RES. 1/2W 0.1R J VISHAY

R152 VE-30000659 SMD RES. 1/10W 330R J

R153 VE-30012649 SMD RES. 1/16W 150R J

R154 VE-30012984 SMD RES. 1/16W 91R J

R155 VE-30000712 CF RES. 1/4W 470R J

R156 VE-30001089 MO RES. 2W 1R J

R157 VE-30000534 SMD RES. 1/10W 15K J

R158 VE-30000475 SMD RES. 1/10W 10K J

R159 VE-30000480 SMD RES. 1/10W 100K J

R160 VE-30006923 SMD RES. 1/10W 4.3K J

R202 VE-30007779 MO RES. 5W 47R J(RADIAL)

R203 VE-30000631 SMD RES. 1/10W 2.7K J

R205 VE-30017136 MO RES. 1W 0.56R J

R206 VE-30001080 MO RES. 2W 100R J

R210 VE-30000583 CF RES. 1/4W 220R J

R211 VE-30000721 SMD RES. 1/10W 4.7K J

R212 VE-30000593 SMD RES. 1/10W 2.2K J

R213 VE-30000593 SMD RES. 1/10W 2.2K J

R214 VE-30000593 SMD RES. 1/10W 2.2K J

R215 VE-30000721 SMD RES. 1/10W 4.7K J

R216 VE-30000631 SMD RES. 1/10W 2.7K J

R217 VE-30000593 SMD RES. 1/10W 2.2K J

R218 VE-30000480 SMD RES. 1/10W 100K J

R220 VE-30000590 CF RES. 1/4W 2.2K J

R225 VE-30001086 MO RES. 2W 10K J

R226 VE-30001168 MO RES. 2W 470RJ

R227 VE-30000469 SMD RES. 1/10W 1K J

R228 VE-30000475 SMD RES. 1/10W 10K J

R229 VE-30000727 SMD RES. 1/10W 47K J

R230 VE-30000902 MF RES. 1/4W 1.8K F

!R231 VE-30001229 FUSE RES. 1W 2.2R J

R232 VE-30001027 MF RES. 1/4W 82K J

!R233 VE-30001244 FUSE RES. 1/2W 0.47R J

!R234 VE-30009036 FUSE RES. 1/2W 0.1R J

R235 VE-30000668 SMD RES. 1/10W 33K J

R236 VE-30000718 CF RES. 1/4W 4.7K J

!Symbol No. Part No. Part Name Description

RESISTOR

!R237 VE-30001244 FUSE RES. 1/2W 0.47R J

R238 VE-30000729 CF RES. 1/4W 470K J

!R239 VE-30001215 FUSE RES. 1W 1R J

R240 VE-30000469 SMD RES. 1/10W 1K J

R241 VE-30000818 SMD RES. 1/10W 8.2K J

R242 VE-30000784 CF RES. 1/4W 680K J

R245 VE-30000466 CF RES. 1/4W 1K J

R246 VE-30001027 MF RES. 1/4W 82K J

R250 VE-30000477 CF RES. 1/4W 100K J

R251 VE-30000477 CF RES. 1/4W 100K J

R252 VE-30007789 SMD RES. 1/10W 27K F

R254 VE-30000636 SMD RES. 1/10W 27K J

R255 VE-30001134 MO RES. 2W 2.2R J

R256 VE-30001100 MO RES. 1W 150R J

R257 VE-30001173 MO RES. 1W 0.47R J

R260 VE-30000778 SMD RES. 1/10W 6.8K J

R261 VE-30000778 SMD RES. 1/10W 6.8K J

!R262 VE-30001237 FUSE RES. 1/2W 3.3R J

R264 VE-30001077 MO RES. 2W 10R J

R270 VE-30000541 CF RES. 1/4W 1.5M J

R271 VE-30000744 CF RES. 1/4W 560R J

R272 VE-30000475 SMD RES. 1/10W 10K J

R280 VE-30000727 SMD RES. 1/10W 47K J

R281 VE-30000480 SMD RES. 1/10W 100K J

R318 VE-30000469 SMD RES. 1/10W 1K J

R322 VE-30000594 CF RES. 1/4W 22K J

R323 VE-30000459 CF RES. 1/4W 100R J

R324 VE-30000464 SMD RES. 1/10W 100R J

R327 VE-30000464 SMD RES. 1/10W 100R J

R360 VE-30000659 SMD RES. 1/10W 330R J

R361 VE-30000659 SMD RES. 1/10W 330R J

R362 VE-30000659 SMD RES. 1/10W 330R J

R363 VE-30000659 SMD RES. 1/10W 330R J

R364 VE-30000659 SMD RES. 1/10W 330R J

R365 VE-30000659 SMD RES. 1/10W 330R J

R366 VE-30000659 SMD RES. 1/10W 330R J

R367 VE-30000659 SMD RES. 1/10W 330R J

R368 VE-30000659 SMD RES. 1/10W 330R J

R369 VE-30000659 SMD RES. 1/10W 330R J

R370 VE-30000659 SMD RES. 1/10W 330R J

R371 VE-30000659 SMD RES. 1/10W 330R J

R372 VE-30000659 SMD RES. 1/10W 330R J

R373 VE-30000659 SMD RES. 1/10W 330R J

R374 VE-30000659 SMD RES. 1/10W 330R J

R375 VE-30000659 SMD RES. 1/10W 330R J

R376 VE-30000659 SMD RES. 1/10W 330R J

R378 VE-30000659 SMD RES. 1/10W 330R J

R379 VE-30000659 SMD RES. 1/10W 330R J

R380 VE-30000659 SMD RES. 1/10W 330R J

R381 VE-30000659 SMD RES. 1/10W 330R J

R382 VE-30000659 SMD RES. 1/10W 330R J

R383 VE-30000659 SMD RES. 1/10W 330R J

R384 VE-30000659 SMD RES. 1/10W 330R J

R385 VE-30000659 SMD RES. 1/10W 330R J

R397 VE-30000659 SMD RES. 1/10W 330R J

R398 VE-30000659 SMD RES. 1/10W 330R J

R411 VE-30000747 SMD RES. 1/10W 560R J

R412 VE-30000721 SMD RES. 1/10W 4.7K J

R413 VE-30000475 SMD RES. 1/10W 10K J

R414 VE-30000469 SMD RES. 1/10W 1K J

R415 VE-30000517 SMD RES. 1/10W 15R J

R416 VE-30000717 SMD RES. 1/10W 470R J

R421 VE-30000563 SMD RES. 1/10W 1.8K J

R422 VE-30000464 SMD RES. 1/10W 100R J

R424 VE-30007021 SMD RES. 1/10W 1K F

R425 VE-30000797 SMD RES. 1/10W 75R J

R428 VE-30000475 SMD RES. 1/10W 10K J

R429 VE-30000475 SMD RES. 1/10W 10K J

R440 VE-30000534 SMD RES. 1/10W 15K J

R441 VE-30000818 SMD RES. 1/10W 8.2K J

R445 VE-30000814 SMD RES. 1/10W 820R J

R475 VE-30000524 SMD RES. 1/10W 150R J

R480 VE-30000718 CF RES. 1/4W 4.7K J

R490 VE-30000466 CF RES. 1/4W 1K J

R492 VE-30000503 SMD RES. 1/10W 12K J

R506 VE-30012695 SMD RES. 1/16W 470R J

R509 VE-30000797 SMD RES. 1/10W 75R J

R510 VE-30007021 SMD RES. 1/10W 1K F

R511 VE-30000464 SMD RES. 1/10W 100R J

[ AV-28BH8EES / AV-28BH8EEB ]

No. 52086

V-28BH8EES / AV-28BH8EEB

!Symbol No. Part No. Part Name Description

RESISTOR

R512 VE-30000464 SMD RES. 1/10W 100R J

R513 VE-30000457 SMD RES. 1/10W 10R J

R518 VE-30000735 SMD RES. 1/10W 4.7R J

R801 VE-30000718 CF RES. 1/4W 4.7K J

R802 VE-30000718 CF RES. 1/4W 4.7K J

R803 VE-30000628 CF RES. 1/4W 2.7K J

R804 VE-30000475 SMD RES. 1/10W 10K J

R805 VE-30000534 SMD RES. 1/10W 15K J

R806 VE-30000531 CF RES. 1/4W 15K J

R807 VE-30000567 SMD RES. 1/10W 18K J

R808 VE-30000734 CF RES. 1/4W 4.7R J

R809 VE-30000717 SMD RES. 1/10W 470R J

R810 VE-30000564 CF RES. 1/4W 18K J

R811 VE-30000717 SMD RES. 1/10W 470R J

R812 VE-30000734 CF RES. 1/4W 4.7R J

R813 VE-30000475 SMD RES. 1/10W 10K J

R819 VE-30000734 CF RES. 1/4W 4.7R J

R820 VE-30000734 CF RES. 1/4W 4.7R J

R900 VE-30012641 SMD RES. 1/16W 10K J

R901 VE-30012641 SMD RES. 1/16W 10K J

R902 VE-30012641 SMD RES. 1/16W 10K J

R903 VE-30000718 CF RES. 1/4W 4.7K J

R904 VE-30000718 CF RES. 1/4W 4.7K J

R905 VE-30000723 CF RES. 1/4W 47K J

R906 VE-30012696 SMD RES. 1/16W 47K J

R907 VE-30012679 SMD RES. 1/16W 3.9K J

R908 VE-30012679 SMD RES. 1/16W 3.9K J

R909 VE-30000531 CF RES. 1/4W 15K J

R910 VE-30000531 CF RES. 1/4W 15K J

R911 VE-30012641 SMD RES. 1/16W 10K J

R912 VE-30000471 CF RES. 1/4W 10K J

R913 VE-30012641 SMD RES. 1/16W 10K J

R914 VE-30000471 CF RES. 1/4W 10K J

R915 VE-30000471 CF RES. 1/4W 10K J

R916 VE-30012695 SMD RES. 1/16W 470R J

R917 VE-30012987 SMD RES. 1/16W 56R J

R918 VE-30012692 SMD RES. 1/16W 4.7K J

R919 VE-30012657 SMD RES. 1/16W 1K J

R920 VE-30012657 SMD RES. 1/16W 1K J

R921 VE-30012657 SMD RES. 1/16W 1K J

R922 VE-30012657 SMD RES. 1/16W 1K J

R923 VE-30012657 SMD RES. 1/16W 1K J

R924 VE-30012696 SMD RES. 1/16W 47K J

R925 VE-30012696 SMD RES. 1/16W 47K J

R926 VE-30012696 SMD RES. 1/16W 47K J

R927 VE-30012696 SMD RES. 1/16W 47K J

R928 VE-30012510 SMD RES. 1/16W 100R J

R929 VE-30012510 SMD RES. 1/16W 100R J

R930 VE-30012641 SMD RES. 1/16W 10K J

R931 VE-30012641 SMD RES. 1/16W 10K J

R932 VE-30012641 SMD RES. 1/16W 10K J

R933 VE-30000718 CF RES. 1/4W 4.7K J

R934 VE-30012692 SMD RES. 1/16W 4.7K J

R935 VE-30012662 SMD RES. 1/16W 2.7K J

R936 VE-30000718 CF RES. 1/4W 4.7K J

R937 VE-30000459 CF RES. 1/4W 100R J

R938 VE-30012509 SMD RES. 1/16W 100K J

R939 VE-30012692 SMD RES. 1/16W 4.7K J

R940 VE-30000500 CF RES. 1/4W 12K J

R941 VE-30000588 SMD RES. 1/10W 220R J

R942 VE-30000588 SMD RES. 1/10W 220R J

R943 VE-30000471 CF RES. 1/4W 10K J

R944 VE-30012641 SMD RES. 1/16W 10K J

R945 VE-30000471 CF RES. 1/4W 10K J

R946 VE-30012657 SMD RES. 1/16W 1K J

R950 VE-30012657 SMD RES. 1/16W 1K J

R951 VE-30012657 SMD RES. 1/16W 1K J

R952 VE-30012657 SMD RES. 1/16W 1K J

R953 VE-30000466 CF RES. 1/4W 1K J

R955 VE-30012657 SMD RES. 1/16W 1K J

R956 VE-30012510 SMD RES. 1/16W 100R J

R957 VE-30012655 SMD RES. 1/16W 180R J

R958 VE-30014022 SMD RES. 1/16W 47R J

R959 VE-30000466 CF RES. 1/4W 1K J

R960 VE-30000471 CF RES. 1/4W 10K J

R961 VE-30000718 CF RES. 1/4W 4.7K J

R964 VE-30012641 SMD RES. 1/16W 10K J

R965 VE-30012657 SMD RES. 1/16W 1K J

R966 VE-30012641 SMD RES. 1/16W 10K J

R967 VE-30012650 SMD RES. 1/16W 15K J

R968 VE-30000692 SMD RES. 1/10W 3.9K J

!Symbol No. Part No. Part Name Description

CAPACITOR

C100 VE-30000098 MKT CAP. 3.3NF 63V J

C101 VE-30000371 EL CAP. 22UF 50V M

C102 VE-30000294 SMD CAP. 100NF 50V K

C103 VE-30000294 SMD CAP. 100NF 50V K

C104 VE-30012323 MKT CAP. 1NF 100V J WIMA FKI2

C105 VE-30000284 SMD CAP. 1NF 50V K R

C106 VE-30000332 SMD CAP. 4.7NF 50V K

C107 VE-30000263 SMD CAP. 56PF 50V J CH

C108 VE-30000123 PP CAP. 33NF 630V K

C109 VE-30000159 MKP CAP. 4.7NF 1.6KV J

C110 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C111 VE-30000131 MKP CAP. 100NF 250V J

!C112 VE-30000094 MKT CAP. 220NF AC275V M

C114 VE-30000353 EL CAP. 100UF 25V M

!C115 VE-30007858 MKT CAP. 470NF AC275V M (P=22.5

!C118 VE-30007755 MKT CAP. 680NF AC275V M X2

C119 VE-30007754 MKP CAP. 1UF 400V

C120 VE-30007753 MKP CAP. 1NF 1KV

C121 VE-30013690 EL CAP. 220UF 450V M 105°C

!C122 VE-30000447 CER CAP. 4.7NF 4KV M E

C124 VE-30000315 SMD CAP. 220NF 25V Z

C125 VE-30000315 SMD CAP. 220NF 25V Z

C130 VE-30007708 CER CAP. 1NF 1KV K (PULSE)

C131 VE-30006909 EL CAP. 100UF M 250V

C132 VE-30007750 EL CAP. 470UF 35V (H/R 1150MA)

C133 VE-30000409 EL CAP. 470UF 25V M

C134 VE-30007750 EL CAP. 470UF 35V (H/R 1150MA)

C135 VE-30007748 EL CAP. 1000UF 35V M

C136 VE-30007748 EL CAP. 1000UF 35V M

C137 VE-30000284 SMD CAP. 1NF 50V K R

C138 VE-30000224 SMD CAP. 220PF 50V J

C139 VE-30000284 SMD CAP. 1NF 50V K R

C140 VE-30000360 EL CAP. 1000UF 25V M

C141 VE-30000352 EL CAP. 100UF 16V M

C142 VE-30000294 SMD CAP. 100NF 50V K

C143 VE-30000294 SMD CAP. 100NF 50V K

C144 VE-30000352 EL CAP. 100UF 16V M

C145 VE-30000309 SMD CAP. 2.2NF 50V K R

C146 VE-30000359 EL CAP. 1000UF 16V M

C147 VE-30000359 EL CAP. 1000UF 16V M

C148 VE-30000294 SMD CAP. 100NF 50V K

C149 VE-30000294 SMD CAP. 100NF 50V K

C150 VE-30000352 EL CAP. 100UF 16V M

C151 VE-30000284 SMD CAP. 1NF 50V K R

C160 VE-30007081 EL CAP. 4.7UF 50V M (NPL)

C161 VE-30007308 CER CAP. 220PF 1KV K (PULSE)

C162 VE-30007308 CER CAP. 220PF 1KV K (PULSE)

C163 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C165 VE-30016654 SMD CAP. 100NF 16V K R

C166 VE-30000355 EL CAP. 100UF 50V M

C167 VE-30009208 CER CAP. 470PF 1KV K (PULSE)

C168 VE-30000294 SMD CAP. 100NF 50V K

C170 VE-30000352 EL CAP. 100UF 16V M

C171 VE-30000352 EL CAP. 100UF 16V M

C172 VE-30016654 SMD CAP. 100NF 16V K R

C173 VE-30000315 SMD CAP. 220NF 25V Z

C201 VE-30000400 EL CAP. 47UF 50V M

C202 VE-30000106 MKT CAP. 47NF 100V J

C203 VE-30000099 MKT CAP. 33NF 63V J

C204 VE-30000345 EL CAP. 10UF 50V M

C206 VE-30000315 SMD CAP. 220NF 25V Z

C207 VE-30000362 EL CAP. 1UF 50V M

C208 VE-30000415 EL CAP. 4.7UF 250V M

C209 VE-30000224 SMD CAP. 220PF 50V J

C210 VE-30000149 MKP CAP. 2.7NF 2KV %3.5

C211 VE-30000179 MKP CAP. 9.1NF 1600V %3.5

C212 VE-30000137 MKP CAP. 15NF 630V J

C213 VE-30007215 MKP CAP. 1.2UF 250V J

C214 VE-30000415 EL CAP. 4.7UF 250V M

C215 VE-30000167 MKP CAP. 560NF 250V J

C216 VE-30000406 EL CAP. 47UF 250V M (HR)

C222 VE-30000431 CER CAP. 100PF 1KV M

C223 VE-30000351 EL CAP. 10UF 350V M

C225 VE-30000359 EL CAP. 1000UF 16V M

C226 VE-30000356 EL CAP. 100UF 63V M

C228 VE-30000360 EL CAP. 1000UF 25V M

C232 VE-30000225 CER CAP. 220PF 50V J SL

C240 VE-30000354 EL CAP. 100UF 35V M

C250 VE-30000304 SMD CAP. 1.8NF 50V K R

C251 VE-30000359 EL CAP. 1000UF 16V M

C252 VE-30000289 SMD CAP. 10NF 50V K R

[ AV-28BH8EES / AV-28BH8EEB ]

This manual suits for next models

Table of contents

Popular TV manuals by other brands

RCA

RCA P56920 user guide

Princess

Princess 68CT8 owner's manual

Panasonic

Panasonic TX-32C300E operating instructions

IKUSI

IKUSI SHC-111 manual

Toshiba

Toshiba 43L1753DB operating instructions

RCA

RCA M50WH92S user guide

Sanyo

Sanyo CE27LD4-B instruction manual

Samsung

Samsung PN51E8000 E- E-manual

Curtis

Curtis LCD2425A instruction manual

Sanyo

Sanyo CP29EF1 Service manual

Sony

Sony KV-27S10 operating instructions

Panasonic

Panasonic TC-14RM12L P Service manual

Sony

Sony BRAVIA KD-75S9005B reference guide

Sanyo

Sanyo CM21KX81 Service manual

Palsonic

Palsonic 6850TGPF owner's manual

Panasonic

Panasonic TX-25XDP3 operating instructions

Philips

Philips 42PF9731D - 1 manual

Loewe

Loewe Spheros R 32 HD+ operating instructions

JVC AV-28BH8ENS User manual

Popular TV manuals by other brands
