ENGLISH - 1 -
Contents
Safety Precautions .................................................. 1
Remote Control Buttons ......................................... 2
Control Panel Buttons............................................. 3
Antenna Connections .............................................. 3
Preparation ............................................................... 4
Features .......................................................................... 4
Before Switching on your T ................................. 4
Power connection ............................................................. 4
Aerial Connections ........................................................... 4
How to connect the external equipments .......................... 4
Inserting batteries in the remote control handset .............. 4
Switching the T ON/OFF ....................................... 4
o switch the V on.......................................................... 4
o switch the V off .......................................................... 4
Initial Settings .......................................................... 4
-V LINK .......................................................................... 5
Operating with the onset buttons ...................................... 5
Operating with Remote Control ......................................... 6
Menu System ............................................................ 6
Sound Menu ..................................................................... 6
Picture Menu ................................................................... 7
Feature Menu ................................................................... 8
Install (Installation) Menu.................................................. 9
Using the Decoder (EX -2) function ................................ 10
Program (Programming) Menu ....................................... 10
o start AU O PROGRAM (AU OS ORE) ..................... 10
Other Features ....................................................... 11
Sound Mute ................................................................... 11
Stereo / Bilingual ............................................................ 11
Information on Screen .................................................... 11
o Display the ime........................................................ 11
Picture ........................................................................... 11
VCR / DVD Control Buttons and VCR / / DVD Switch 11
Teletext ................................................................... 11
o operate eletext ......................................................... 11
o select a page of eletext ............................................ 12
o Select Index Page ..................................................... 12
Searching for a teletext page while watching V ............. 12
o Select Double Height ext ......................................... 12
o Reveal concealed Information .................................. 12
o Stop Automatic Page Change .................................... 12
o Select a Subcode Page ............................................. 12
o exit eletext ............................................................... 12
Fastext and optext ....................................................... 12
Connect the External Equipments ....................... 13
Via the Euroconnector .................................................... 13
-V LINK compatible VCR .............................................. 13
RGB mode ..................................................................... 13
EX -2S Mode ................................................................. 13
Via the RCA jacks .......................................................... 13
Via the AN (aerial) socket ............................................. 13
V and Video Recoder (VCR) ......................................... 13
N SC Playback ............................................................. 13
Copy Facility .................................................................. 13
Connecting Headphones ................................................ 13
Tips.......................................................................... 15
Specifications ......................................................... 15
Safety Precautions
1. Power Source
he receiver should be operated only from a 220-240V AC,
50 Hz. outlet. Ensure you select the correct voltage setting
for your convenience.
2. Power Cord
he power supply cord should be placed so that they are not
likely to be walked on or pinched by items placed upon them
or against them. Pay particular attention to cord where they
enter the plug, power outlet, and the point where they exit
from the receiver.
3. Moisture and Water
Do not use this equipment in a humid and damp place (avoid
the bathroom, the sink in the kitchen, and near the washing
machine). Do not expose this equipment to rain or water and
do not place objects filled with liquids on it as this may be
dangerous.
4. Cleaning
Before cleaning, unplug the receiver from the main supply
outlet. Do not use liquid or aerosol cleaners. Use with soft
and dry cloth.
5. Ventilation
he slots and openings on the receiver are intended for venti-
lation and to ensure reliable operation. o prevent overheat-
ing, these openings must not be blocked or covered in any-
way.
6. Lightning
In case of storm and lightning or when going on holiday, dis-
connect the power cord from the wall outlet.
7. eplacement Part
When replacement parts are required, be sure the service
technician has used replacement parts which are specified
by the manufacturer or have the same specifications as the
original one. Unauthorized substitutions may result in fire,
electrical shock, or other hazards.
8. Servicing
Please refer all servicing to qualified personnel. Do not re-
move cover as this may result in electric shock.
9. Flame sources
Do not place naked flame sources on the apparatus.
10. Stand-By
Do not leave your V stand-by or operating condition when you
leave your house.
Warning!
Any intervention contrary to regulations, in particular, any
modification of high voltage or a replacement of the picture
tube may lead to an increased concentration of x-rays. Any
television modified in this way no longer complies with li-
cense and must not be operated.
Instructions for waste disposal:
Packaging and packaging aids are recyclable and should
principally be recycled. Packaging materials, such as foil
bag, must be kept away from children.
Batteries, including those which are heavy metal-free, should
not be disposed of with household waste. Please dispose of
used batteries in an environmentally sound manner. Find out
about the legal regulations which apply in your area.
01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:381

ENGLISH - 2 -
Remote Control Buttons
= Stand By / Power
0 - 9 = Direct Program
Yellow Button / Factory Settings in Picture Menu
Blue Button
PICTURE = Picture Mode Change
( ) = Programme Up (Cursor Up)
MENU = Menu Button
( ) = Cursor Right / Volume +
( ) = Programme Down (Cursor Down)
eletext / VCR /DVD Control Buttons
= Stereo / Bilingual Button
= VCR / / DVD Switch
= Information Button / -V Link in Program Menu
( ) = Cursor Left / Volume -
AV = AV Button
= eletext Button

ZOOM = Zoom (Picture Size) Change / Red Button

= Hyper Sound / Green Button

= Mute
CAUTION
RISK OF ELECTRIC SHOCK
he lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk
of electric shock of persons.
he exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.



















01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:382

ENGLISH - 3 -
Control Panel Buttons
Antenna Connections
69+6
$947%8
$94768
$947%8
$94768
/
3&K
5
0HQX
3RZHU
3URJUDP
9ROXPH
$XGLR,QSXW
7HUPLQDO
9LGHR,QSXW
7HUPLQDO
+HDGSKRQH
)5217$9
(;7
)5217$9
(;7
&21752/
3$1(/
%877216
&21752/
3$1(/
%877216
$XGLR,QSXW
7HUPLQDO
9LGHR,QSXW
7HUPLQDO
+HDGSKRQH
0HQX
3URJUDP
9ROXPH
01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:383

ENGLISH - 4 -
Preparation
Place V on a solid surface.
For ventilation, leave a space of at least 10 cm free all around
the set. o prevent any fault and unsafe situations, please do
not place any objects on top of the set.
Use this apparatus in tropical and moderate climates.
Features
 It is a remote controlled colour television.
 100 programmes from VHF, UHF bands or cable channels
can be preset.
 It can tune cable channels.
 Controlling the V is very easy by its menu driven system.
 It has two Euroconnector sockets for external devices
(such as video recorder, video games, audio set, etc.)
 Front AV (EX -3) Input available.
 Stereo sound systems (German+Nicam) are available.
 Full function eletext (Fastext, optext).
 It is possible to connect headphone.
 Direct channel access.
 AU O PROGRAM (Automatic Programming System).
 All programmes can be named.
 Forward or backward automatic tuning.
 Sleep timer.
 Child Lock.
 Blue Background.
 Comb Filter : Digital circuitry to make adjustments provid-
ing outstanding picture quality with sharp, crisp edges,
while virtually eliminating dot crawl.
 C I : (Colour ransient Improvement) Improvement of hori-
zontal transitions of chrominance (colour) signals.
 -V Link.
 Automatic sound mute when no transmission.
 When no valid signal is detected, after 5 minutes the V
switches itself automatically to stand-by mode.
 WSS (Wide Screen Signaling).
 N SC Playback.
Before Switching on your TV
Power connection
Imp rtant: he V set is designed to operate on 220-240 V
AC, 50 Hz.
 After unpacking, allow the V set to reach the ambient
room temperature before you connect the set to the mains.
Aerial Connections
 Connect the aerial plug to the aerial input socket located at
the back of the V.
How to connect the external equipments
See C nnect the External Equipments on page 14.
 See the instruction manuals provided with the external de-
vices too.
Inserting batteries in the remote control handset
 Remove the battery cover located on the back of the hand-
set by gently pulling upwards from the indicated part.
 Insert two AA (R6) or equivalent type batteries inside.
 Replace the battery cover.
NOTE: emove batteries from remote control handset when it
is not to be used for a long period. Otherwise it can be damaged
due to any leakage of batteries.
Switching the TV ON OFF
You can operate your TV either using the remote control
handset or directly using the TV onset buttons
To switch the TV on
Your V will switch on in two steps:
1- Press the power button located on the front of the V.
hen the V switches itself to standby mode and the RED
LED located below the V turns on.
2- o switch on the V from stand-by mode either:
Press a digit button on the remote control so that a program-
me number is selected,
or,
Press Standby / Power Button or Programme Up and Down
buttons on the V or on the remote control respectively, so
the V will switch on and the RED Led will turn GREEN.
To switch the TV off
 Press the stand-by button on the remote control, so the V
will switch to stand-by mode and the GREEN LED will be-
come RED, or,
 Press the power button located on the front of the V.
Initial Settings
he message PLEASE CHECK ANTENNA CABLE AUTO.
PROGRAMMING SYSTEM will be displayed when you turn
on your V for the first time.
3/($6( &+(&. $17(11$ &$%/(
$872 352*5$00,1* 6<67(0
/$1*8$*(
&28175<
67$57
3,&785( &$1&(/
(1*/,6+
'
1- Select LANGUAGE with   or   button, then
press the   or   button to select a menu language.
2- Select COUNTRY with   or   button, then press
the   or   button to select the country you are now lo-
cated.
3- Select START with   or   button, then press the
right button to start AUTO PROGRAM
AUTO PROGRAM, (Automatic Programming System) auto-
matically programmes the received channels in your Vs
programme numbers. During AUTO PROGRAM, AUTO
PROGRAM IS RUNNING PLEASE WAIT will be displayed.
After AUTO PROGRAM is finalized, the PROGRAM menu
appears.
o cancel AUTO PROGRAM, press the PICTURE button.
01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:384

ENGLISH - 5 -
You can delete a channel, insert a channel into a programme
number, or re-start AUTO PROGRAM with the PROGRAM
menu. For details, see PROGRAM (Pr gramming) menu
on page 10.
4- If you do not have a -V LINK compatible VCR, press
PICTURE button to exit the menu.
If you have a -V LINK compatible VCR connected to the
EXT.2 terminal, press   button to display T-V LINK
menu. hen follow the operating procedure D wnl ading
data t VCR in the following T-V LINK section.
If the message PLEASE CHECK ANTENNA CABLE AUTO.
PROGRAMMING SYSTEM does not appear, or if you want
to modify the settings later, you can do manually with the
FEATURE, INSTALL and PROGRAM menus.
T-V LINK
When a -V LINK compatible VCR is connected to the EXT.2
erminal on the V, it is easier to set up the VCR and to view
videos. -V LINK uses the following features:
To use T- LINK functions:
A T-V LINK c mpatible VCR means a JVC video cassette
recorder with the -V LINK logo, or with one of the following
logos. However, these VCRs may support some or all of the
features described earlier. For details, see your VCR instruc-
tion manual.
Q-LINK (a trademark of Panasonic Corporation)
Data L gic (a trademark of Metz Corporation)
Easy Link (a trademark of Phillips Corporation)
Megal gic (a trademark of Grundig Corporation)
SMARTLINK (a trademark of Sony Corporation)
Downloading data to CR:
he VCR will automatically download the registered data on
the V channels from the V. his means you do not need to
set up the programme channels on your VCR manually.
he T-V LINK menu will be displayed when you press the
 button while PROGRAM menu is displayed, or when-
ever the INSTALL menu operations are performed.
Press   button to start downloading data to VCR.
 If you do not want to do, press the PICTURE button to
exit the menu.
When FEATURE NOT AVAILABLE... is displayed:
If FEATURE NOT AVAILABLE... is displayed, the download
was not performed correctly. Before trying to download again,
check that:
 he VCR power is turned on
 he VCR is -V LINK compatible
 he VCR is connected to the EX .2 terminal
 he SCAR cable is fully wired.
Direct Rec:
What Y u See Is What Y u Rec rd
You can easy record to VCR the images that you are watch-
ing on the V. For details, read the manual for your VCR,
Use your VCR controls. You cannot carryout Direct Rec us-
ing your Vs control.
79 /,1. 79  9&5
9&5 ,6 5(&25',1*

When the VCR is not ready (for example when there is no
tape inserted), NO RECORDING is displayed.
In the following situations, the VCR will stop recording if the
V is turned off, if the V channel or input is changed, or if
the menu is displayed on the V:
 When recording images from an external device connected
to the V. (for example a camcorder)
 When recording a V channel after it has been un-
scrambled on a decoder.
 When recording a V channel by using the Vs output be-
cause the VCRs own tuner cannot properly receive that
channel.
T auto power on/ CR image view:
When the VCR starts playing, the V automatically turns on
and the images from EXT.2 (EXT-2) terminal appear on the
screen.
This functi n d es n t happen if y ur TVs main p wer
is turned ff. Set y ur TVs main p wer t n (standby
m de).
Operating with the onset buttons
Volume setting and programme selection can be made using
the buttons on the right side of the V.
01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:385

ENGLISH - 6 -
V lume Setting:
 Press  - button to decrease volume or  + button to
increase volume, so a volume level scale will be displayed
on the screen.
Pr gramme Selecting:
 Press P/Ch+ button to select next programme or P/Ch-
button to select the previous programme.
Entering Main Menu:
 Press MENU button to enter main menu. In the main
menu select submenu using P/Ch+ or P/Ch- button and
enter the submenu using  + or  - button. o learn
the usage of the menus, refer to Menu System on page 6.
Operating with emote Control
he remote control handset of your V is designed to control
all the functions of the model you selected. he functions will
be described in accordance with the menu system of your
V.
Functions which you can use out of menu system are de-
scribed below.
V lume Setting:
Press  button to increase volume.
Press   button to decrease volume.
Pr gramme Selecting (Previ us r next pr gramme):
 Press   button to select the previous programme.
 Press   button to select the next programme.
Pr gramme Selecting (direct access):
Press digit buttons on the remote control handset to select
programmes between 0 and 9. V will switch to the selected
program after a short delay.
 For a two digit program number enter the second digit after
pressing the first digit within 2 seconds.
Menu System
Your V has been designed with a menu system. Display
MENU (main menu) and enter one of five menus (SOUND,
PICTURE, FEATURE, INSTALL and PROGRAM).
1- Press MENU button to display MENU (main menu).
he menu titles will be displayed in the main menu.
2- Press   or   button to select a menu title, then
press   or   button to enter the menu.
 o exit a menu, press PICTURE button.
 o go to the previous menu, press MENU button.
6281'
3,&785(
)($785(
,167$//
352*5$0
Sound Menu
To change sound settings:
 Press MENU button, now you are in main menu. In the
main menu, SOUND will be the first selected option. Enter
the sound menu pressing   or   button.
Setting olume:
As you enter the sound menu, Volume will be the first select-
ed option.
 Press   button to increase volume.
 Press   button to decrease volume.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
Setting Bass Level:
 Using   or   button select Bass.
 Press   button to increase bass level.
 Press   button to decrease bass level.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
Setting Treble Level:
 Using   or   button select reble.
 Press   button to increase treble level.
 Press   button to decrease treble level.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
Setting Balance:
 Using   or   button select Balance.
 Press   button to change balance rightward.
 Press   button to change balance leftward.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:386

ENGLISH - 7 -
Hyper Sound:
You can use this feature to switch on or off Hyper Sound.
Pressing   or   button will turn on or off this feature. If the
current sound system is MONO and the Hyper Sound is set
ON, then the sound will be heard as if it is STEREO. If the
current sound system is STEREO, switching Hyper Sound
on will make the sound deeper. Switching it off will make no
change in MONO and STEREO.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
Hyper Sound can be set On or Off also by GREEN button.
Picture Menu
To change picture settings:
 Press MENU button, now you are in main menu. In the
main menu, select PICTURE using   or   button,
then enter the picture menu pressing   or   button.
6281'
3,&785(
)($785(
,167$//
352*5$0
N te: When Picture Mode is not MANUAL, BRIGH NESS,
CON RAS and COLOUR options can not be reached by
 or   buttons.
Factory Settings:
In the Picture Menu if you press the YELLOW button the ad-
justments switches themselves to the factory settings.
Setting Brightness:
You can change Brightness only when Picture Mode is se-
lected MANUAL.
Using   or   button select Brightness.
 Press   button to increase Brightness.
 Press   button to decrease Brightness.
Setting Contrast:
You can change C ntrast only when Picture Mode is select-
ed MANUAL.
 Using   or   button select Contrast.
 Press   button to increase Contrast level.
 Press   button to decrease Contrast level.
Setting Colour:
You can change C l ur only when Picture Mode is selected
MANUAL.
 Using   or   button select Colour.
 Press   button to increase Colour level.
 Press   button to decrease Colour level.
Setting Sharpness:
 Using   or   button select Sharpness.
 Press   button to increase Sharpness level.
 Press   button to decrease Sharpness level.
Setting Hue (In A mode only) :
 Using   or   button select Hue.
 Press   button to increase Hue level.
 Press   button to decrease Hue level.
Hue adjust is functional only when N SC 3.58/4.43 is applied
in AV mode. It does not appear when other colour systems
used.
Setting CR Mode (In A mode only) :
 Using   or   button select VCR MODE.
 When you watch a picture from your VCR and the picture is
unstable, you may improve it by changing the "VCR MODE"
setting from "ON" to "OFF".
01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:387

ENGLISH - 8 -
Picture Mode
his item is used to change the picture mode. By pressing
 or   button you may choose one of these options:
BRIGHT, STANDARD, SOFT, MANUAL.
Colour Temp
his item is used to change the Colour emperature. By
pressing   or   button you may choose one of these op-
tions: COOL, WARM, NORMAL.
Zoom
his item is used to change the picture size. By pressing  
or   button you may choose one of these options: AUTO,
4:3 and 16:9.
 4:3 his option forces the picture ratio to 4:3 mode.
 16:9 This option forces the picture ratio to 16:9 mode.
 AUTO his allows to change the picture mode automati-
cally, according to the transmission of the selected chan-
nel. For example, your V is 4:3 mode, but the transmis-
sion of that channel is in 16:9 mode. If you select the AU O
mode, the V is switched to 16:9 mode automatically. If the
V is in 4:3 mode and the picture ratio of the channel is
also 4:3, there will be no affect selecting the picture mode
to AU O mode.
WSS feature is only used in V and EX -3 modes. For the
Zoom selection in EX -1 and EX -2 the pin 8 (of Scart) value
is used. In RGB mode the Zoom can be AUTO, 4:3 and
16:9 mode.
Zoom can be set to desired mode by RED button.
Feature Menu
 Press MENU button, now you are in main menu. In the
main menu, select FEATURE, using   or   button.
hen enter the feature menu pressing   or   button.
6281'
3,&785(
)($785(
,167$//
352*5$0
Sleep Timer
he sleep timer is used to turn the V off after a defined peri-
od. Press   or   button to choose a period of time after
selecting this item. he timer can be programmed between
Off and 120 minutes in steps of 10 minutes. (OFF, 010, 020,
030, 040, ......... ,120.)
If sleep timer is activated, at the end of the selected the time,
the V goes automatically to stand-by mode.
6/((37,0(5
&+,/'/2&.
/$1*8$*(
(;7287387
%/8(%$&.*5281'
2))
2))
(1*/,6+
79
2))
Child lock:
You can disable the control panel buttons (except the POW-
ER button) with this item.
Press   or   button to change the setting to On or Off after
selecting this item.
When you set this item to On, the V can be operated only
by using the remote control handset.
6/((37,0(5
&+,/'/2&.
/$1*8$*(
(;7287387
%/8(%$&.*5281'
2))
2))
(1*/,6+
79
2))
Warning: If Child Lock item is set to ON, the V can not be
operated by VCR.
Language:
Menu Language can be selected by pressing   or   button
on Language item.
6/((37,0(5
&+,/'/2&.
/$1*8$*(
(;7287387
%/8(%$&.*5281'
2))
2))
(1*/,6+
79
2))
Setting External Source Output
 You can use this menu to select the internal or external
source that will be output at EXT.2 terminal.
 In the Feature menu select EXT-2 Output using  
or   button. hen select the source you want to be out-
put at EXT.2 pressing   or   button (one of the sources:
TV, EXT-1 or EXT-3 (Fr nt AV).
6/((37,0(5
&+,/'/2&.
/$1*8$*(
(;7287387
%/8(%$&.*5281'
2))
2))
(1*/,6+
79
2))
Blue Background During No-Signal
he Blue Backgr und feature can be set by   or   button
to either On or Off.
01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:388

ENGLISH - 9 -
Install (Installation) Menu
You can store a channel manually, or modify the current set-
tings of a channel (for example, fine-tuning a channel).
You can also changing the colour system, or change the
DECODER(EXT-2) setting.
 Press MENU button to display the main menu.
 Press   or   button to select INSTALL item.
hen   or   button to display the INSTALL menu.
6281'
3,&785(
)($785(
,167$//
352*5$0
N te:
 If you want to modify the current settings of a channel, se-
lect the channel of which you want to modify the setting.
hen display the main menu on screen.
 In AV mode, you can change only the COLOUR SYSTEM
item.
1. PROGRAMME will be the first selected item as you enter
the INSTALL menu. Pressing   or   button select the
programme number where you want to the tuned channel
to be stored. (You may also type the programme number
using the digit buttons.)
N te:
 Do not use PROGRAMME item when you modify the cur-
rent programme numbers setting. If you select other
programme number by mistake, the selected programme
numbers setting will be changed.
2. Press   or   button to select BAND. Using   or
 button to select the band in which you want to search
a channel.
3. Press   or   button to select SEARCH. Press
 or   button to start searching. (Press   button to
search forward. Press   to search backwards.)
 If the found channel is not the desired one, press   or
 button to start searching again.
 o stop searching before a channel is found, press the
reverse direction button. For example, when the V is
searching forward with   button, press   button to
stop searching.
 If you know the channel number which you want to find,
you can find the channel directly. Follow the step 4 to
select the correct standard, then press   or  
to select CHANNEL again, and press   or   button to
select the channel number, or enter the number with the
digit buttons.
4. If the sound or picture is abnormal, change the standard
(broadcasting system) of new channel. Press   or
 button to select STANDARD, then press   or  
button to change the correct one.
 he indicated number will be changed when you change
the standard.
B/G : C02-C12, C21-C73 / S01-S41 / S75-S79
D/K : 01-C12, C21-C69 / S01-S19, S22-S41
L : C01-C73 / S01-S41 / S75-S77
L : C04-C09
5. If the picture is not clear or no colour appears, change the
colour system to display the picture normally. Press
 or   button to select COLOUR SYSTEM, then
press   or   button to choose the correct one.
 In V mode: PAL / SECAM
 In AV mode: AUTO / PAL / SECAM / NTSC 3.58 / NTSC 4.43
6. If the channel reception is poor, fine-tune the channel.
Press   or   to select FINE TUNING, then press
 or   button to fine-tune the channel.
7. After the all settings are completed, store the new
channels setting to the programme number which you se-
lected. Press   or   to select STORE, then
press   or   button to store it. T-V LINK menu will ap-
pear after the V stores the settings.
8. If you do not have a -V LINK compatible VCR, press
PICTURE button to exit the menu.
If you have a -V LINK compatible VCR connected to the
EX -2 terminal, press   button to display T-V LINK
menu. hen follow the operating procedure D wnl ading
the data t VCR on page 5 to transmit the Programme
table data to the VCR.
To change the Colour system:
If the picture is not clear or no colour appears, choose the
correct colour system to display the picture normally.
1. Press   or   button to select COLOUR SYS-
TEM, then press   or   button to choose the correct
one.
 In V mode: PAL / SECAM
 In AV mode: AUTO / PAL / SECAM / NTSC 3.58 / NTSC 4.43
2. Press   or   to select STORE, then press   or
 button to store it.
3. When T-V LINK menu appears, follow the step 4.
4. If you do not have a -V LINK compatible VCR, press
PICTURE button to exit the menu.
If you have a -V LINK compatible VCR connected to the
EXT.2 terminal, follow the operating procedure D wn-
l ading the data t VCR on page 5 to transmit the Pro-
gramme table data to the VCR.
01-ENG-21&2929-AK45-1512UK-(AV-21&29QT4&BU&SU)-50051275.p65 22.06.2004, 11:389
