JVC HR-S4500U User manual

HR-S4500U
VIDEO CASSETTE RECORDER
INSTRUCTIONS
LPT0025-001C
For Customer Use:
Enter below the Model No. and
Serial No. which are located on the
rear of cabinet. Retain this
information for future reference.
Model No.
Serial No.
T
V
C H
+
T
V
V
O
L
–
T
V
C
H
–
T
V
V
O
L
+
TV
CANCEL
TIMER
START STOP DATE
MENU
OK
CH
POWER
TV/VCR
C. RESET
DBS DAILY(M-F)
AUX
WEEKLY
PROG
CHECK
PROG SP/EP SKIPSEARCH
DISPLAY
ENTER/OSD
CABLE/
DBS
123
456
789
0
2
4
1
3
EXPRESS PROGRAMMING
MULTI BRAND
REMOTE CONTROL UNIT
MBRSET
A/B
PLAY
REW
REC
STOP
PAUSE
FF
TIME
SCAN
REW
INSERT
PAUSE
REC
STOP/EJECT
PLAY
A.DUB
FF
JOG
SHUTTLE
MENU OK
POWER
VIDEO
(MONO)
L –AUDIO– R
REC LINK
S-VHS ET
CH
SP VCR

2EN
Dear Customer,
Thank you for purchasing the JVCVHS video cassette recorder. Before use, please read the safety information and precautions
contained in the following pages to ensure safe use of your newVCR.
CAUTIONS
WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSETHIS
UNITTO RAIN OR MOISTURE.
CAUTION:
This video cassette recorder should be used withAC
120V`, 60Hz only.
To prevent electric shocks and fire hazards, DO NOT use
any other power source.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUGTO WIDE SLOT, FULLY INSERT.
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQU'AU FOND.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
Failure to heed the following precautions may result in
damage to theVCR, remote control or video cassette.
1. DO NOT place theVCR . . .
... in an environment prone to extreme temperatures or
humidity.
... in direct sunlight.
... in a dusty environment.
... in an environment where strong magnetic fields are
generated.
... on a surface that is unstable or subject to vibration.
2. DO NOT block theVCR’s ventilation openings.
3. DO NOT place heavy objects on theVCR or remote control.
4. DO NOT place anything which might spill on top of the
VCR or remote control.
5. AVOID violent shocks to theVCR during transport.
**MOISTURE CONDENSATION
Moisture in the air will condense on theVCR when you move it
from a cold place to a warm place, or under extremely humid
conditions—just as water droplets form on the surface of a glass
filled with cold liquid. Moisture condensation on the head drum
will cause damage to the tape. In conditions where condensa-
tion may occur, keep theVCR’s power turned on for a few hours
to let the moisture dry before inserting a tape.
**ABOUT HEAD CLEANING
Accumulation of dirt and other particles on the video heads
may cause the playback picture to become blurred or inter-
rupted. Be sure to contact your nearest JVC dealer if such
troubles occur.
Note to CATV system installer:
This reminder is provided to call the CATV system
installer's attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of
cable entry as practical.
CAUTION:
Changes or modifications not approved by JVC could void
user's authority to operate the equipment.
nCassettes marked "S-VHS" and "VHS" can be used with this
video cassette recorder. However, S-VHS recordings are
possible only with cassettes marked "S-VHS".
By using S-VHS ET it is possible to record and play back with
S-VHS picture quality onVHS cassettes with thisVCR.
nAs an ENERGY STAR®Partner, JVC has determined that this
product or product model meets the ENERGY STAR®guidelines
for energy efficiency.
VCR Plus+C3and PlusCode are trademarks of Gemstar Develop-
ment Corporation.
TheVCR Plus+ system is manufactured under license from
Gemstar Development Corporation.
DSSTM is an official trademark of DIRECTV, Inc., a unit of GM
Hughes Electronics. PRIMESTAR is a registered service mark of
Primestar Partners, L.P. DISH NetworkTM is a trademark of
Echostar Communications Corporation.
MOVIE ADVANCETM is a trademark of SRT, Inc. A Jerry Iggulden
invention licensed in association with Arthur D. Little Enter-
prises, Inc.

EN 3
IMPORTANT PRODUCT
SAFETY INSTRUCTIONS
Electrical energy can perform many useful functions. But
improper use can result in potential electrical shock or fire
hazards.This product has been engineered and manufactured
to assure your personal safety. In order not to defeat the built-in
safeguards, observe the following basic rules for its installation,
use and servicing.
ATTENTION:
Follow and obey all warnings and instructions marked on your
product and its operating instructions. For your safety, please
read all the safety and operating instructions before you operate
this product and keep this booklet for future reference.
INSTALLATION
1. Grounding or Polarization
(A)Your product may be equipped with a polarized alternating-
current line plug (a plug having one blade wider than the
other).This plug will fit into the power outlet only one way.
This is a safety feature.
If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
(B)Your product may be equipped with a 3-wire grounding-type
plug, a plug having a third (grounding) pin.This plug will
only fit into a grounding-type power outlet.This is a safety
feature.
If you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
2. Power Sources
Operate your product only from the type of power source
indicated on the marking label. If you are not sure of the type of
power supply to your home, consult your product dealer or
local power company. If your product is intended to operate
from battery power, or other sources, refer to the operating
instructions.
3. Overloading
Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or
electric shock.
4. Power Cord Protection
Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
5.Ventilation
Slots and openings in the cabinet are provided for ventilation.
To ensure reliable operation of the product and to protect it
from overheating, these openings must not be blocked or
covered.
• Do not block the openings by placing the product on a bed,
sofa, rug or other similar surface.
• Do not place the product in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
6. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
ANTENNA
LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC – NATIONAL ELECTRICAL CODE
ELECTRIC SERVICE
EQUIPMENT
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
GROUND CLAMP
ANTENNA INSTALLATION
INSTRUCTIONS
1. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the
product, be sure the antenna or cable system is grounded so as
to provide some protection against voltage surges and built-up
static charges. Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit, size of grounding
connectors, location of antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding
electrode.
2. Lightning
For added protection for this product during a lightning storm,
or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna
or cable system.This will prevent damage to the product due to
lightning and power-line surges.
3. Power Lines
An outside antenna system should not be located in the vicinity
of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits as
contact with them might be fatal.

4EN
SERVICING
1. Servicing
If your product is not operating correctly or exhibits a marked
change in performance and you are unable to restore normal
operation by following the detailed procedure in its operating
instructions, do not attempt to service it yourself as opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
2. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a.When the power supply cord or plug is damaged.
b.If liquid has been spilled, or objects have fallen into the
product.
c.If the product has been exposed to rain or water.
d.If the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to its normal operation.
e.If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in
performance—this indicates a need for service.
3. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock or other hazards.
4. Safety Check
Upon completion of any service or repairs to this product, ask
the service technician to perform safety checks to determine
that the product is in safe operating condition.
HOW TO USE THIS INSTRUCTION
MANUAL
●All major sections and subsections are listed in the Table Of
Contents on page 5. Use this when searching for information
on a specific procedure or feature.
●The Index on pages 65–68 lists frequently-used terms, and the
number of the page on which they are used or explained in
the manual. This section also illustrates the controls and
connections on the front and rear panel, the front display
panel and the remote control.
●The Zmark signals a reference to another page for
instructions or related information.
●Operation buttons necessary for the various procedures are
clearly indicated through the use of illustrations at the
beginning of each major section.
BEFORE YOU INSTALL YOUR NEW
VCR . . .
. . . please read the sections/literature listed below.
●”Cautions” on page 2
●”Important Products Safety Instructions” on the previous pages
USE
1. Accessories
To avoid personal injury:
• Do not place this product on an unstable cart, stand, tripod,
bracket, or table. It may fall, causing serious injury to a child
or adult, and serious damage to the product.
• Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the product.
• Use a mounting accessory recommended by the
manufacturer and follow the manufacturer’s instructions for
any mounting of the product.
• Do not try to roll a cart with small casters across thresholds or
deep-pile carpets.
2. Product and Cart Combination
A product and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the product and
cart combination to overturn.
3. Water and Moisture
Do not use this product near water—for example, near a bath
tub, wash bowl, kitchen sink or laundry tub, in a wet basement,
or near a swimming pool and the like.
4. Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-
out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
5. Attachments
Do not use attachments not recommended by the manufacturer
of this product as they may cause hazards.
6. Cleaning
Unplug this product from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning.
7. Heat
The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
PORTABLE CART WARNING
(Symbol provided by RETAC)

EN 5
CONTENTS
Time Scan ................................................... 38
Variable-Speed Search/Reverse Motion Playback .....38
Skip Search..............................................................39
Time Scan Audio......................................................40
TIMER RECORDING 41
VCR Plus+ Timer Programming ................... 41
VCR Plus+ Setup .........................................43
Express Timer Programming ....................... 45
Check, Cancel And Revise Programs........................47
Auto SP→EPTimer...................................................48
AutoTimer ...............................................................48
Instant Timer Recording (ITR)....................... 49
Automatic Satellite Program Recording ....... 50
EDITING 51
Edit To Or From Another VCR ...................... 51
Edit From A Camcorder ...............................52
Insert Editing .............................................. 54
Audio Dubbing ........................................... 56
SPECIAL FEATURES 57
TV Multi-Brand Remote Control ..............................57
Cable Box Multi-Brand Remote Control...................58
DBS Receiver Multi-Brand Remote Control..............59
Child Lock ...............................................................60
ControlTwo JVCVCRs .............................................60
TROUBLESHOOTING 61
Power ........................................................ 61
Tape Transport............................................ 61
Playback .................................................... 61
Recording ................................................... 61
Timer Recording.......................................... 62
Other Problems .......................................... 63
QUESTIONS AND ANSWERS 64
Playback .................................................... 64
Recording ................................................... 64
Timer Recording.......................................... 64
INDEX 65
List Of Terms ............................................... 65
Front View.................................................. 66
Rear View .................................................. 67
Front Display Panel..................................... 67
Remote Control ........................................... 68
SPECIFICATIONS 69
FOR SERVICING (Only in U.S.A.) 70
WARRANTY (Only in U.S.A.) 71
INSTALLING YOUR NEW VCR 6
Connections ...........................................6
Basic Connections .....................................................6
S-Video Connection...................................................7
INITIAL SETTINGS 8
Plug & Play .................................................. 8
Language ................................................... 10
Clock .......................................................... 11
Preparation ..............................................................11
Semi-Auto................................................................12
Manual ....................................................................13
Tuner .......................................................... 14
Set Receivable Channels ..........................................14
Add Or Delete A Channel........................................15
Cable Box Control....................................... 16
Situate And Connect Controller ...............................16
Set Cable Box Output Channel &
Cable Box Brand......................................................17
DBS Receiver Control................................... 19
Situate And Connect Controller ...............................19
Set DBS Receiver Output Channel &
DBS Receiver Brand ................................................20
SIMPLE PLAYBACK AND RECORDING 22
Simple Playback ......................................... 22
Simple Recording ........................................ 23
PLAYBACK AND RECORDING
FEATURES 24
Playback Features ...................................... 24
Still Picture/Frame-By-Frame Playback .....................24
Slow Motion/Reverse Slow Motion ..........................24
Index Search............................................................25
High-Speed Search ..................................................25
ManualTracking ......................................................25
Video Stabilizer .......................................................26
Instant ReView.........................................................27
Repeat Playback ......................................................27
Counter Reset ..........................................................27
Tape Position Indicator ............................................27
Next-Function Memory............................................27
Superimpose............................................................28
SelectThe Soundtrack..............................................29
Movie Advance........................................................30
AV COMPU LINK Playback .....................................31
Active Video Calibration ............................. 32
Preparation ..............................................................32
Recording ................................................................33
Playback..................................................................33
Recording Features ..................................... 34
Record One Program While Watching Another........34
Display Elapsed RecordingTime ..............................34
DisplayTape Remaining Time ..................................34
S-VHS (SuperVHS), S-VHS ET andVHS ...................35
SuperVHS ET ..........................................................36
Stereo And SAP (Second Audio Program) .................37
To Record SAP Programs..........................................37

6EN
INSTALLINGYOUR NEWVCR
CHECK CONTENTS
1
Make sure the package contains all of the accessories
listed in “SPECIFICATIONS” (Zpg. 69).
SITUATE VCR
2
Place theVCR on a stable, horizontal surface.
CONNECT VCR TO TV
3
The connection method you use depends on the type of
TV you have.
RF Connection
● To ConnectTo A TV With NO AV Input Terminals . . .
a– Disconnect theTV antenna from the TV.
b– Connect the TV antenna cable to the ANTENNA
IN jack on the rear of theVCR.
c– Connect the supplied RF cable between theTV
OUT jack on the rear of theVCR and the TV’s
antenna terminal. SetTV on CH3 or CH4 corre-
sponding to the CH3 – CH4 switch setting on the
back of theVCR.
AV Connection
● To ConnectTo A TV With AV InputTerminals . . .
a– Connect the antenna,VCR andTV as shown in
the illustration.
b– Connect an Audio/Video Cable between theAUDIO
OUT andVIDEO OUT jacks on the rear of theVCR
and the AV IN jacks on theTV. Set yourTV in video
input mode or A/V input mode. Refer to the TV
Instruction Manual.
S-VIDEO Connection
● If you have a TV with S-VIDEO input terminals, see
"S-VIDEO Connection" on page 7.
CONNECT VCR TO
POWER SOURCE
4
Connect the power plug to an AC outlet.
●The clock and tuner channels will automatically be
set when the antenna is connected and when the AC
is first connected to theVCR (Zpg. 8).
(If "Auto" or "CH" is displayed on the front display
panel before theVCR is powered on, the clock and
tuner channels are being set automatically. Wait for
the time to be displayed on the front display panel
before powering on theVCR.)
FINAL PREPARATION FOR
USE
5
Power on theVCR and if you are connected to theTV
using the RF connector, select theVCR channel (3 or 4)
by setting the switch on the rear of theVCR as shown in
the illustration.
You can now perform simple playback (Zpg. 22) or
simple recording (Zpg. 23).
NOTES:
● TheVCR channel is the channel on theTV which will display
the audio and video signals from theVCR.TheVCR's CH3-
CH4 switch, on the back of theVCR, sets theVCR channel to
CH3 or CH4.
● The CH3–CH4 switch is preset to the CH3 position.
Set to CH4 if CH3 is used for broadcasting in your area and
set the channel on theTV to correspond to theVCR's CH3–
CH4 switch setting.
● If you are connected to theTV using the RF connector, you may
need to press CH UP and then CH DOWN on theTV when
switching between theTV andVCR input modes, to maintain good
picture quality.
● Even if you are using AV cables to connect yourVCR to your
TV, you must also connect it using the RF cable.This will
ensure that you can record one show while watching another
( Z pg. 34).
● For full identification of theVCR's rear panel, refer to the
Index (REARVIEW Z pg. 67).
Connections
Antenna or Cable
Flat Feeder
Coaxial Cable
AC Power Cord
Back ofVCR
AC Outlet
75 ohm terminal
TV
Matching
Transformer
(Not supplied)
TV OUT
Audio/Video
Cable (supplied)
RF Cable
(supplied)
CH4
CH3
Back ofVCR
ANTENNA IN
(Antenna or Cable input)
Basic Connections

EN 7
ANTENNA IN
CH4
CH3
REMOTE
PAUSE AV COMPULINK
CABLE
BOX
VIDEO
AUDIO
VHF/UHF
L
(MONO)
R
OUT
TV
OUT IN
OUT
S VIDEO
IN
TV OUT
RF Cable (supplied)
MatchingTransformer
(not supplied)
AC Power
Cord
Audio/Video Cable
(supplied)
TV
ANTENNA IN
(Antenna or Cable input)
Back ofVCR
75 ohm terminal
AC Outlet
Antenna or Cable
Flat Feeder
Coaxial Cable
NOTES:
● To make the most of the SuperVHS picture performance we
recommend that you use the supplied S-VIDEO cable to
connect yourVCR to aTV with an S-VIDEO input connector.
● To operate theVCR with yourTV using the S-VIDEO connec-
tion, set yourTV to the AV mode using theTV's remote
control.
You can also use the TV/VCR button on theVCR's remote
control to set yourTV to the AV mode. ( Z pg. 57)
S-VIDEO Connection
CONNECTVCRTOTV
a– Connect both the RF cable and the AV cables to theTV as
explained in step 3of "Basic Connections" (Zpg. 6).
b– Connect the S-Video cable between the S-VIDEO OUT
jack on the rear of theVCR and the S-VIDEO IN jack on
theTV.
S-Video Cable
(supplied)
SVIDEO IN
SVIDEO OUT

8EN
INITIAL SETTINGS
Plug & Play The Plug & Play function sets the clock and tuner channels
automatically when power is first connected to theVCR.The
antenna cable must be connected for the Plug & Play function.
The time and date can be set automatically from clock setting
data that is transmitted by one of the regularTV broadcast
channels. We call thisTV channel the “Host Channel” and it is
a PBS channel in your area.
PLUG & PLAY SETUP
1
Connect the antenna cable to theVCR (Zpg. 6). Then
connect theVCR’s power plug to anAC outlet. Do not
power on theVCR. The clock and tuner channels will
be set automatically.
NOTES:
● Auto clock set is performed first.The auto clock set
function scans all the channels received by yourVCR
to find the Host Channel and then sets the clock.
"Auto" blinks on the front display panel during Auto
clock set.
● Auto channel set is performed next.The auto channel
set function scans all the channels that are receivable
by yourVCR. It then automatically assigns each
receivable channels to the CH
5∞
(+/–) buttons. It
skips non-receivable channels. During auto channel
set the channel numbers are displayed as they are
scanned and set.
● When Plug & Play has been completed successfully the
correct time is displayed.
● If an incorrect time or "– –:– –" appears on the display
panel, see "WhatTo Do If Plug & Play Has Failed" on
next page.
ATTENTION
If you use a cable box, Plug & Play will not function; set
the clock and tuner channels manually. (Zpg.11 – 15)
Auto Clock Set/Auto Tuner Set
IMPORTANT
●Don’t press any buttons on theVCR or remote while Plug
& Play is in progress.
●If you perform Plug & Play successfully, there’s no need to
perform the Clock (Zpg. 11) andTuner (Zpg. 14)
procedures. If, however, you want to add or delete
channels, refer to “Add Or Delete A Channel” on page 15.
During Initial Auto Clock Set
"Auto" blinks. During Auto Channel Set The channel numbers are displayed
as they are scanned and set.
* If an incorrect time or "– –:– –" appears on the display panel, see "WhatTo Do If Plug & Play Has Failed" on next page.
Plug & Play Completed
The current time (including
AM/PM) is displayed.

EN 9
INFORMATION
●If "AUTO CLOCK" is set to "ON" at the Clock Set screen on page 12, the clock will be adjusted automatically by the host
channel every hour on the hour (except for 11:00 PM, midnight, 1:00 AM and 2:00 AM) by the incoming PBS channel clock
setting data. (This automatic clock adjustment can only be performed when theVCR’s power is turned off. The clock will be
adjusted on the hour based on the time displayed on theVCR, not on the actual real time.) The default setting of "AUTO
CLOCK" is "ON".
●If the memory backup fails, because of a power outage or because the AC was removed from theVCR, Plug & Play will be
performed when power is restored to theVCR.
WhatTo Do If Plug & Play Has Failed
●If an incorrect time is displayed on the front display panel, you may be receiving the clock setting data of a PBS channel from
an adjacent time zone, or an incorrect PBS channel from a cableTV system. In this case, perform the Semi-Auto (Zpg. 12) or
Manual Clock Set (Zpg. 13) procedure. Auto channel set has already taken place and it need not be set again.
●If “- -:- -” appears on the display, your antenna cable may not be connected to theVCR or there may not be a Host PBS signal
available in your area. Ensure that the antenna cable is connected correctly.Then power on and power off theVCR; the Plug &
Play function will be automatically reactivated and "Auto" will be displayed on theVCR's front panel. If Plug & Play is not
performed but the antenna cable is connected correctly, perform the Manual Clock Set procedure (Zpg. 13). Auto channel set
has not yet taken place, so please also perform the “Set Receivable Channels” procedure (Zpg. 14).

10EN
INITIAL SETTINGS (cont.)
Language ThisVCR offers you the choice to view on-screen messages in
English, Spanish or French (not including messages superimposed
on theTV picture). Select the desired language using this
procedure.The default setting is "ENGLISH".
TURN ON THE VCR
1
Press POWER.
ACCESS MAIN MENU
SCREEN
2
Press MENU.
ACCESS INITIAL SET
SCREEN
3
At the Main Menu screen,
move the highlight bar
(arrow) to “INITIAL SET”
by pressing CH5∞or
TIME SCAN %fi, then
press OK or TIME SCAN # .
SELECT LANGUAGE
4
Move the highlight bar
(arrow) to "LANGUAGE"
by pressing CH 5∞or
TIME SCAN %fi, then
press OK or TIME SCAN #
to select the desired
language.
RETURN TO NORMAL
SCREEN
5
Press MENU.
Turn on theTV and select theVCR channel 3 or 4 (or AV
mode).
MAIN MENU
FUNCTION SET
TUNER SET
=INITIAL SET
PRESS (5,∞), THEN (OK)
PRESS (MENU) TO END
INITIAL SET
CLOCK SET
=LANGUAGE ENGLISH
GUIDE CHANNEL SET
CABLE BOX SET
DBS RECEIVER SET
SELECT WITH (5,∞) AND (OK)
PRESS (MENU) TO END
POWER
123
456
789
0
2
4
1
3
POWER
OK
MENU
MENU
OK
TIME SCAN
CH5∞
