JVC HR-P111AG User manual

PAL NTSC
POWER-ONCOLOUR
SYSTEM
STANDBY/REC
SP/LP
/EP
ENGLISH
VIDEO CASSETTE PLAYER
WITH LINE RECORDING
HR-P110AG
LPT0950-001B
Thank you for purchasing this JVC video cassette player. To ensure optimum performance of this
unit, please read this instruction manual thoroughly.
Only cassettes marked “VHS” can be used with this video cassette player.
HR-P111AG
HR-P110AS
CONTENTS
Features .................................. 2
Automatic features.................. 2
Precautions............................. 3
Controls.................................. 4
Wireless remote control.......... 5
On screen display................... 6
Connections ........................... 6
Setting the video channel........ 8
Mode set................................. 9
Setting Of The Colour System
Select Buttons ....................... 10
Playback............................... 11
Recording............................. 13
B.E.S.T. picture system.......... 13
Editing .................................. 14
Troubleshooting.................... 15
Specifications ....................... 16

2Features
Features
●3 system (PAL/MESECAM/NTSC)
●NTSC playback (on PAL television)
●RF output G/K switchable
●Digital auto tracking
●HQ (High Quality)
●Auto playback function
●Repeat playback
●Shuttle search
●Still and slow motion
●Line recording
●B.E.S.T. (Biconditional Equalized Signal
Tracking) picture system
Automatic features
Auto power on
The video cassette player is automatically
turned on when the tape is inserted.
Auto rewind
The video tape is automatically rewound
when the end of the tape is reached during
the play, recording or shuttle search forward
mode.
Auto playback
If the video cassette’s safety tab has been
removed, playback will begin automatically
when the tape is inserted into the video
cassette player.
Power off eject
Even when the video cassette player’s power
is off, pressing the eject button will turn the
power on and eject the tape. Once ejected,
the power will be turned off again
automatically.
Auto head cleaning
When a tape is loaded or ejected the VCP
video head is cleaned automatically.

3
Precautions
Precautions
The rating plate and the safety caution are on the rear of the unit.
WARNING: DANGEROUS VOLTAGE INSIDE
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
When the equipment is installed in a cabinet or a shelf, make sure that it has sufficient space on
all sides to allow for ventilation (10 cm or more on both side, on top and at the rear.)
When discarding batteries, environmental problems must be considered and the local rules or
laws governing the disposal of these batteries must be followed strictly.
Failure to heed the following precautions may result in damage to the player, remote control
or video cassette player.
1DONOT
place the player ...
...in an environment prone to extreme temperatures or humidity.
...in direct sunlight.
...in a dusty environment.
...in an environment where strong magnetic fields are generated.
...on a surface that is unstable or subject to vibration.
2DONOT
block the player's ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may
not be able to get out.)
3DONOT
place heavy objects on the player or remote control.
4DONOT
place anything which might spill on top of the player or remote control.
If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.
5DONOT
expose the apparatus to dripping or splashing.
6DONOT
use this equipment in a bathroom or places with water. Also DO NOT place any
containers filled with water or liquids (such as cosmetics or medicines, flower vases, potted
plants, cups, etc.) on top of this unit.
7DONOT
place any naked flame sources, such as lighted candles, on the apparatus.
8 AVOID violent shocks to the player during transport.
Beware of moisture condensation
Moisture in the air will condense on the VCP when you move it from a cold place to a warm place, or
under extremely humid conditions —just as water droplets form on the surface of a glass filled with
cold liquid. Moisture condensation on the head drum will cause damage to the tape. In conditions
where condensation may occur, keep the VCP’s power turned on for a few hours to let the moisture dry.
When transporting
8Be sure to remove cassette from VCP before packing.
8Avoid violent shocks to the VCP during packing and transport.
The 1button does not completely shut off mains power from the unit, but switches
operating current on and off.
This unit is produced to comply with Standard IEC 60065.
The socket outlet shall be installed near the equipment and easily accessible, or the mains
plug or an appliance coupler shall remain readily operable.
CAUTION
(For HR-P110AS only)
Use the conversion plug depending on the type of your AC wall outlet.

4Controls
Controls
Front Panel
ASP/LP/EP button
To select the recording tape speed.
BCassette loading slot
Load the video cassette here.
C7Record button
To start recording.
D#Play button
To start playback.
E¤Stop/Eject button
To stop playback and to eject the video
tape.
FÁFast forward button
To fast forward the video tape and to start
forward shuttle search playback mode.
G1Rewind button
To rewind the video tape and to start
reverse shuttle search playback mode.
HRemote sensor window
For remote control operation.
ISTANDBY/REC indicator
•Lights when the power turns off
(Standby mode) or during recording
mode.
•Blinks during recording pause mode.
JPOWER-ON indicator
Lights when the power turns on.
KCOLOUR SYSTEM button
To set the colour system for recording
and playback (墌pg. 10).
L1button
To turn the power on and off (standby
mode).
Rear Panel
AAC power cord
BRF OUT terminal
CAUDIO/VIDEO IN terminals
DAUDIO/VIDEO OUT terminals
EANT. IN terminal
POWER-ON
COLOUR
SYSTEM
STANDBY/REC
SP/LP
/EP
ANT.IN
RF OUT
OUTIN
AUDIO
VIDEO

5
Wireless remote control
Wireless remote control
When using the remote control for operation of the video cassette player, make sure that it is pointed at the
remote sensor window.
You can also use the player’s remote control to operate a JVC television.
A Transmitting window
B 1button
To turn the power on and off (standby).
C 9PAUSE button
To freeze the picture during playback.
Also to engage the recording pause
mode.
D 3button
To rewind the video tape. Also to start
reverse shuttle search playback.
E7 REC button
Press the 7REC to start recording.
F AUTO button
To enable/disable auto tracking mode.
SP/LP/EP(p) button
•To select the recording tape speed.
•To select JVC TV’s sounds.
G
R/Tbuttons
To select the mode.
Y/Ubuttons
To set the mode.
H MENU button
To access Mode Set screen.
I$ button
To start playback.
J
5button
To fast forward the video tape. Also to
start forward shuttle search playback.
K 8button
To stop playback.
L 0000 button
To reset the tape counter.
M0 EJECT button
Press the 0to eject the cassette. You also
can eject the cassette when the player is
turned off.
N TRACKING +/– buttons
To adjust tracking during playback.
O OK/ button
•To fix the setting.
•To display the information on the
television's display.
NOTES:
●Point the remote control toward the
remote sensor window.
●The maximum operating distance of the
remote control is about 8 m.
●When inserting the batteries, be sure to
insert in the correct directions as indicated
under the battery cover.
●If the remote control doesn’t work
properly, remove its batteries, wait a short
time, replace the batteries and then try
again.
5
5

6On screen display
On screen display
When “O.S.D”is set to “ON”(See “Mode set” 墌pg. 9), various operational indicators appear
on the TV screen.
AOperation mode indicators
BTape speed SP/LP/EP
CColour system indicator
DTape direction
ECounter display
FTape position indicator
GCassette loaded mark
Connections
Make sure that the power to the video cassette player and TV is off before making the following
connections.
NOTE:
If you put a TV set directly on this Video cassette player or install it too close to a TV set, noise
may occur. If this noise occurs, separate the Video cassette player and the TV set.
79
[
SP
NTSC 3.58
– 9 : 59 : 59
+++ +
ANT.IN
RF OUT
OUTIN
AUDIO
VIDEO
Connection A
Connection B

7
Connections
Connection A (basic)
In order to use the video cassette player it
must be connected between the antenna
and the TV.
AConnect your TV antenna cable to the
video cassette player’s ANT. IN
terminal.
BConnect one end of the provided RF
antenna cable to the video cassette
player’s RF. OUT terminal and the
other end to the TV’s antenna
terminal.
CConnect the power cord to your
household AC outlet.
Connection B
For connection of a TV that has VIDEO/
AUDIO IN/OUT terminals. This connection
is necessary to record TV programmes. Use
RCA type pin connection cords (available
from audio/video stores) for connection. This
connection is in addition to connection A.
AFollow steps 1 and 2 of “Connection
A”.
BConnect the TV’s VIDEO OUT and
AUDIO OUT terminals to the video
cassette player’s VIDEO IN and
AUDIO IN terminals.
CConnect the TV’s VIDEO IN and
AUDIO IN terminals to the VCP’s
VIDEO OUT and AUDIO OUT
terminals.
DConnect the power cord to your
household AC outlet.

8Setting the video channel
Setting the video channel
To watch videos on your TV, it must be set to the same UHF channel as the video cassette
player. This channel is used as the video channel.
This video cassette player has been preset to UHF channel 36.
NOTE:
When you have connected the VIDEO/AUDIO OU T terminals of this video cassette player to
your TV’s video/ audio in terminals (connection B of the “Connections”section), setting the
video channel is not necessary. In this case simply set the TV’s TV/ VCR switch to VCR.
AAccess video channel set mode.
Hold down 0on the video
cassette player until both of the
POWER-ON and STANDBY/REC
indicators light.
BSet video channels.
Set your TV to UHF channel 36.
●If the two vertical white bars appear
clearly on the screen as shown in the
illustration on the right, go to step 3.
●If the two vertical white bars do not
appear clearly, press TRACKING + or
–to set the video cassette player to a
vacant channel between 32 and 40
which is not occupied by any local
station in your area.
●The mode indicators tell channel
position.
The indicators blink different speed
by the channel position as shown on
the right.
CPress OK/ .
●STANDBY/REC indicator goes off.
DSet TV system.
●Set “RF OUT”to “B/G”or “D/K”.
(See “Mode set”(墌pg. 9))
To view picture signals from the video player, set
your TV to the Video Channel .
IMPORTANT:
Before performing the following steps, make sure the player's power is off and there is no
cassette inserted in the player.
TEST SIGNAL:
The channel on
which the screen to
the left appear
clearly in step 2 is
your Video Channel.
POWER-ON STANDBY/REC
POWER ON
indicator
STANDBY/REC
indicator
CH POWER-ON
(green)
STANDBY/REC
(red)
Blinking
Speed
40 - blink fast
39 - blink
38 - blink
37 - blink slow
36 light light -
35 blink - slow
34 blink -
33 blink -
32 blink - fast

9
M ode set
Mode set
You can change various mode setting on the Mode Set screen by following procedure described below.
AAccess the Mode Set screen.
Press MENU.
BSelect the mode.
Press
R
/
T
to move the pointer to the item you want to change.
CSelect the mode setting.
Press Y/U.
DReturn to the normal screen.
Press MENU
.
*The default setting is bold in the table below.
8O.S.D.
ON
OFF
When the function is set to “ON”, various operational
indicators appear on the TV screen.
NOTE:
When you use this video cassette player as the source player for
editing, be sure to set “O.S.D.”to “OFF ”before starting.
8B.E.S.T.
ON
OFF
You can set the B.E.S.T. (Biconditional Equalized Signal
Tracking) system to “ON ”or “OFF ”. (See “B.E.S.T. picture
system”(墌 pg. 13))
8RF OUT
B/G : New Zealand, Kuwait, U.A.E.,
Indonesia, Singapore, Thailand,
Malaysia, Iran, Saudi Arabia.
D/K: Egypt, Morocco, Lebanon, Iraq,
China, Mongolia, Russia.
Set appropriate TV system that matches the system of TV being
used.
O.S.D. ON
ON
B.E.S.T.
RF OUT B/G
[MENU] : EXIT

10 Setting O f The Colour System Select Buttons
Setting Of The Colour System Select Buttons
Use the COLOUR SYSTEM button on the
front panel to select the colour system.
Pressing the COLOUR SYSTEM displays the
current setting on the screen. While the
current setting is displayed, press COLOUR
SYSTEM again to change the mode as
illustrated below. The On-Screen display will
show which mode is selected.
●If the mode is changed between different
types of colour signals, the picture might
be distorted at the switching point.
* Appears during playback only.
NOTES:
●In the AUTO mode, NTSC signals will be
automatically recorded as NTSC 3.58.
●In the AUTO mode, NTSC tapes will be
played back as NTSC 3.58.
●SECAM signals will always be recorded as
MESECAM. Select the AUTO or the
MESECAM mode when recording SECAM
signals.
●When playing back a SECAM tape, select
the AUTO or MESECAM mode. The
playback picture will always be
monochrome.
●In the NTSC 4.43 mode, with some TVs,
on-screen displays (Program screen etc.)
may roll up or down and there may be a
loss of colour. When this happens, select
the AUTO mode.
Mode Description
AUTO Usually set to this mode. This
mode automatically detects PAL,
NTSC 3.58, MESECAM and adjusts
to the colour system being
recorded or played back.
When it does not perform properly,
set the colour system manually.
MANUAL For recording, there is a choice of 4
selectable modes; NTSC 3.58/
NTSC 4.43/PAL/MESECAM. Select
the mode that matches the colour
signal being received.
For playback, there is an additional
mode which allows NTSC tapes to
be played back and viewed on PAL
TVs.
To record an NTSC 4.43 signal,
perform the following steps,
A Press and hold 9 , and press 7
to enter Recording Pause
Mode.
B Press COLOUR SYSTEM
repeatedly and select NTSC
4.43 colour mode.
C Press
$
to start recording.

11
Playback
Playback
NTSC, PAL and MESECAM video tapes
can be played back on this video cassette
player. See “Setting Of The Colour System
Select Buttons”on page 10 for details.
Before proceeding:
●Turn on the power of the TV and video
cassette player.
●Make sure that the TV is set to the video
channel or that the TV’s TV/VIDEO switch
is set to VIDEO (See “Setting the video
channel”on page 8 for details).
ALoad a pre-recorded cassette.
If the safety tab on the cassette is
removed, playback will start
automatically.
BPress $to start playback.
“B.E.S.T. PICTURE SYSTEM”appears
on the screen.(when B.E.S.T. is set to
“ON”. (See “Mode set” 墌pg. 9)
8Press ¤or the remote control’s
8
to
stop playback. Then press ¤to
remove the cassette.
To fast forward or rewind the tape:
8From the stop mode, press Áor 1.
Slow motion playback
Slow motion playback is 1/6 of the normal
playback speed. The sound will be cut
during slow motion playback.
During playback:
APress 9for 2 seconds.
8Press $to return to the normal
playback speed.
NOTES:
●If the picture shakes during the slow
mode, use TRACKING +/ –to correct the
picture.
●After approx. 5 minutes, the slow mode
will disengage to protect the video tape.
Still picture and frame advance
Use this feature to freeze the playback
picture and to advance one frame at a time.
The sound will be cut during this mode.
During playback:
APress 9.
The picture will be frozen.
BPress 9repeatedly to advance
frames.
Each time the button is pressed the still
picture will advance one frame.
8Press $to resume normal playback.
NOTES:
●If the picture shakes during the still mode,
use TRACKING +/ –to correct the picture.
●After the picture has been frozen for
approx. 5 minutes, the still mode will
disengage to protect the video tape.
12
2
POWER-ON
COLOUR
SYSTEM
STANDBY/REC
SP/LP
/EP

12 Playback
Shuttle search playback
Use this feature during playback to visually
locate any point on a recorded cassette. The
sound will be cut during shuttle search
operation.
During playback:
APress Áor 1to engage shuttle
search forward or reverse.
8Press Áto 1again to perform high
speed.
NOTE:
Each time you press Áor 1, the search
speed changes between low-speed and
high-speed.
Tracking adjustment
Automatic tracking is adjusted each time a
cassette is inserted in the video cassette
player, you may wish to adjust tracking
manually during playback.
Manual tracking:
APress the remote control’s AUTO.
BPress the remote control’s
TRACKING + or –to adjust tracking.
8Press AUTO to return to automatic
tracking.
Counter reset
APress
0000
to reset the counter.
Repeat playback
Use this feature to repeat playback of a
cassette 100 times.
During playback:
APress $for more than 5 seconds.
The Play indicator will blink slowly
and playback of the cassette will
repeat 100 times automatically.
BPress 8to stop repeat playback.
Tape playback will be stopped and the
repeat playback mode will be cancelled
.
NOTE:
Pressing $, 1, Áor 8also stops repeat
playback.
Rewind playback or power off
When the tape has finished rewinding, the
Video cassette player will playback or turn
itself off.
During stop:
a- For Automatic Start Of Playback
Press 1, then press $within 2
seconds.
b- For Automatic Power Off
Press 1, then press 1within 2
seconds.
ATTENTION:
In the search, still, slow-motion or frame
advance mode,
•the picture will be distorted.
•the noise bars will appear.
•there will be loss of colour.
•the picture may not appear.
However, this is not malfunction.

13
Recording
Recording
Use the following procedure to record TV
programmes on a blank video tape.
Before proceeding:
●To record TV programmes, the video
cassette player must be connected to the
TV as shown in connection B of the
“Connections”on page 6 section.
●Turn on the power of the TV and video
cassette player.
●Make sure that the video cassette’s safety
tab is intact. If it has been removed, cover
the hole with adhesive tape.
ALoad a blank video tape.
BPress SP/LP/EP (p) to set the
recording speed.
CPress 7to start recording. (On the
remote control unit press 7and $
at the same time.)
The recording indicator will light
during recording.
8Press ¤on the video cassette player
on the remote control press 8to stop
recording.
To stop recording temporarily:
8Press 9.
The recording indicator will blink.
Press $to resume recording.
NOTES:
●To engage recording standby, press 7and
then press 9. The STAN DBY/ REC
indicator will blink during recording
standby. Press $again to start recording.
●If 7does not work, check to see if the
cassette safety tab has been removed.
●The player automatically stops w hen
record-standby continues for more than 5
minutes.
●The video tape will be rewound
automatically when the end of the tape is
reached.
B.E.S.T. picture system
The B.E.S.T. (Biconditional Equalized Signal
Tracking) system checks the condition of the
tape in use during recording and playback,
and compensates to provide the highest
possible recording and playback pictures.
The default setting for both recording and
playback is ‘‘ON’’.
Recording
The video cassette player assesses the quality
of the tape once you initiate recording.
8The player spends approximately 7
seconds assessing the condition of the
tape, then begins recording.
1
3
3
3
2
2
POWER-ON
COLOUR
SYSTEM
STANDBY/REC
SP/LP
/EP
B.E.S.T. takes place at the beginning of
each first SP and first LP (or EP) recording
after inserting the cassette.

14 Editing
NOTES:
●The B.E.S.T. system works only after a tape
has been inserted and the Record mode is
first initiated. It does not work during
recording.
●Once the cassette is ejected, the B.E.S.T.
data is cancelled.
The next time the cassette is used for
recording, B.E.S.T. is re-performed.
Playback
The video cassette player assesses the quality
of the tape once you initiate playback.
When watching a tape recorded with
B.E.S.T. set to on, it is recommended that
you leave B.E.S.T. on during playback as
well.
8The player adjusts the playback picture
quality based on the quality of the tape
in use.
8B.E.S.T. is active during Auto Tracking.
NOTE:
When watching a rental tape, or one
recorded on another video player, set
B.E.S.T. to on or off to your preference.
Editing
Editing To/From Another Recorder
A
Connect the player’s AUDIO and VIDEO
OUT connectors to the recorder’s
AUDIO and VIDEO IN connectors.
BPut the player in the Play mode.
CPut the recorder in the Record mode.
NOTES:
●
NTSC tapes being played back in the NTSC
PLAYBACK ON PAL TV mode cannot be dubbed
to another recorder.
● When you dub an NTSC tape using your recorder
as the playback deck, select NTSC 3.58 (or 4.43)
with the Colour System Output switch.
ATTENTION:
Since the B.E.S.T. system works before
recording actually starts, there is a delay
of approximately 7 seconds after and
on the remote are pressed, or on
the player is pressed.
To make sure you record the desired
scene or programme in its entirely, first
perform the following steps:
1Press and hold 9and 7to engage the
Record Pause mode.
•The player then automatically check
the condition of the tape and, after
approximately 7 seconds, reenters
Record Pause.
2Press $to start recording.
•If you want to bypass the B.E.S.T.
system and begin recording
immediately, set “B.E.S.T.” to “OFF”.
7
$7
Important:
8To edit, both the player and the
recorder must be of the same colour
system. Set “NTSC ”to appropriate
mode. (See “Mode set” 墌pg. 9)
ANT.IN
RF OUT
OUTIN
AUDIO
VIDEO
AUDIO
VIDEO
ANT.IN
RF OUT
OUTIN
TV
Receiver
Player
Recorder Audio/Video signals
VIDEO
CHANNEL

15
Troubleshooting
Troubleshooting
About Head cleaning
8If the picture playback becomes blurred, it does not mean that the recorded program has
been erased.
8Dirt accumulated on the video heads after long periods of use causes such troubles. In this
case, head cleaning requiring highly technical care is necessary.
8For head cleaning, consult the nearest JVC dealer.
Problem Check point
No power Is the power cord plugged in?
Is the power turned on?
Tape cannot be ejected Was the video cassette player’s ¤button or the 0
EJECT button on the remote control pressed?
No picture Is the TV set to the video channel?
Is a cassette loaded?
Are the connections correct?
No colour Set the Colour System Output switch according to
the recorded tape system.
Shuttle search does not function Is the video cassette player in the playback
mode?
Disturbances in playback picture Is tracking adjusted properly?
Is the TV adjusted properly?
Install this VCP a little way apart from the TV set.
Remote control does not function The batteries are weak.
Replace the batteries.
Auto playback does not function The video cassette’s recording safety tab has
not been removed.
Recording does not function Are the connections correct?
Was the Record button pressed?
The video cassette’s recording safety tab is removed.
The video cassette player does not
function properly
Microcomputer malfunction.
Disconnect the power plug from the AC outlet and
then re-insert it.
The microcomputer will be reset to its initial mode.

16 Specifications
Specifications
Format........................................VHS Standard
Video recording system..............Rotary, slant azimuth helical scan system
Rotary heads ..............................2 video heads
RF output ...................................System B/G, D/K type modulation
UHF ch 32 –40 adjustable (preset ch 36)
Recording (line input)................. PAL, SECAM (MESECAM tape)
NTSC 3.58, NTSC 4.43
Playback (line output)................. PAL, SECAM (MESECAM tape)
NTSC 3.58
NTSC 4.43
Simulated PAL (NTSC tape)
Video
Line input level ....................... 0.5 –2.0 Vp-p/75 ohms, unbalanced
Line output level ..................... 1.0 Vp-p/75 ohms, unbalanced
S/N ratio..................................More than 45 dB
Horizontal resolution ..............More than 250 lines
(PAL/MESECAM)
More than 220 lines (NTSC)
Audio
Line input level ....................... –8 dBs/50 k ohms, unbalanced
Line output level .....................–8 dBs/1 k ohm, unbalanced
Frequency response................. 70 Hz to 10,000 Hz (Normal audio)
Power requirements
Rating ........................................AC 110 V –240 V, 50 Hz /60 Hz
Operating...................................AC 90 V –260 V, 50 Hz /60 Hz
Power consumption ...................12 W
Operation temperature...............5°C to 40°C
Dimensions................................360 mm (W)×98 mm (H)×255 mm (D)
Weight .......................................2.9 kg
Standard accessories
Remote control unit ................... 1
Batteries for remote control........2
RF antenna cable ....................... 1
Conversion plug* .......................1
* Not provided in certain areas.
●Design and specifications subject to change without notice.
COPYRIGHT © 2004 VICTOR COMPANY OF JAPAN LTD.
Printed in China
0604DYR-NF-BJ
EN

This file has been downloaded from:
www.UsersManualGuide.com
User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes..
Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide,
manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product,
documentation manual, user maintenance, brochure, user reference, pdf manual
Downloaded from: https://www.usersmanualguide.com/
