JVCKENWOOD KD-X165 User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
РУCCKИЙ
B5A-2625-00 [Q]
KD-X165 / KD-X163
ЦИФРОВОЙ МЕДИА-РЕСИВЕР
ИHCTPУKЦИЯ ПO ЭKCПЛУATAЦИИ
JS_JVC_KD_X165_Q_C.indd 1JS_JVC_KD_X165_Q_C.indd 1 20/6/2018 11:39:45 AM20/6/2018 11:39:45 AM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
i
Дата изготовления (месяц/год) находится на этикетке
устройства.
В соответствии с Законом Российской Федерации “О защите прав потребителей”
срок службы (годности) данного товара “по истечении которого он может
представлять опасность для жизни, здоровья потребителя, причинять вред его
имуществу или окружающей среде” составляет семь (7) лет со дня производства.
Дополнительные косметические материалы к данному товару, поставляемые
вместе с ним, могут храниться в течение двух (2) лет со дня его производства.
Срок службы (годности), кроме срока хранения дополнительных косметических
материалов, упомянутых в предыдущих двух пунктах, не затрагивает никаких
других прав потребителя, в частности, гарантийного обслуживания JVC, которое
он может получить в соответствии с законом о правах потребителя или других
законов, связанных с ним.
Условия хранения:
Температура: от –30°C до +85°C
Влажность: от 0% до 90%
Декларация соответствия относительно Директивы RE 2014/53/EU
Декларация соответствия относительно Директивы RoHS 2011/65/EU
Производитель:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN
Представительство в ЕС:
JVCKENWOOD Europe B.V.
Amsterdamseweg 37, 1422 AC UITHOORN, THE NETHERLANDS
English
Hereby, JVCKENWOOD declares that the radio equipment
“KD-X165/KD-X163” is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available
at the following internet address:
http://www.jvc.net/cs/car/eudoc/
Français
Par la présente, JVCKENWOOD déclare que l’équipement
radio « KD-X165/KD-X163 » est conforme à la directive
2014/53/UE.
L’intégralité de la déclaration de conformité UE est
disponible à l’adresse Internet suivante :
http://www.jvc.net/cs/car/eudoc/
Deutsch
Hiermit erklärt JVCKENWOOD, dass das Funkgerät
“KD-X165/KD-X163” der Richtlinie 2014/53/EU entspricht.
Der volle Text der EU-Konformitätserklärung steht unter der
folgenden Internetadresse zur Verfügung:
http://www.jvc.net/cs/car/eudoc/
Nederlands
Hierbij verklaart JVCKENWOOD dat de radioapparatuur
“KD-X165/KD-X163” in overeenstemming is met Richtlijn
2014/53/EU.
De volledige tekst van de EU-verklaring van
overeenstemming is te vinden op het volgende
internetadres:
http://www.jvc.net/cs/car/eudoc/
Italiano
Con la presente, JVCKENWOOD dichiara che l΄apparecchio
radio “KD-X165/KD-X163” è conforme alla Direttiva
2014/53/UE.
Il testo integrale della dichiarazione di conformità UE è
disponibile al seguente indirizzo internet:
http://www.jvc.net/cs/car/eudoc/
Español
Por la presente, JVCKENWOOD declara que el equipo de radio
“KD-X165/KD-X163” cumple la Directiva 2014/53/EU.
El texto completo de la declaración de conformidad con la UE
está disponible en la siguiente dirección de internet:
http://www.jvc.net/cs/car/eudoc/
Português
Deste modo, a JVCKENWOOD declara que o equipamento
de rádio “KD-X165/KD-X163” está em conformidade com a
Diretiva 2014/53/UE.
O texto integral da declaração de conformidade da UE está
disponível no seguinte endereço de internet:
http://www.jvc.net/cs/car/eudoc/
Polska
Niniejszym, JVCKENWOOD deklaruje, że sprzęt radiowy
“KD-X165/KD-X163” jest zgodny z dyrektywą 2014/53/UE.
Pełny tekst deklaracji zgodności EU jest dostępny pod
adresem:
http://www.jvc.net/cs/car/eudoc/
Český
Společnost JVCKENWOOD tímto prohlašuje, že rádiové
zařízení “KD-X165/KD-X163” splňuje podmínky směrnice
2014/53/EU.
Plný text EU prohlášení o shodě je dostupný na následující
internetové adrese:
http://www.jvc.net/cs/car/eudoc/
Magyar
JVCKENWOOD ezennel kijelenti, hogy a „KD-X165/KD-X163“
rádióberendezés megfelel a 2014/53/EU irányelvnek.
Az EU konformitási nyilatkozat teljes szövege az alábbi
weboldalon érhető el:
http://www.jvc.net/cs/car/eudoc/
JS_JVC_KD_X165_Q_C.indd iJS_JVC_KD_X165_Q_C.indd i 20/6/2018 11:39:46 AM20/6/2018 11:39:46 AM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ii
Svenska
Härmed försäkrar JVCKENWOOD att
radioutrustningen “KD-X165/KD-X163” är i
enlighet med direktiv 2014/53/EU.
Den fullständiga texten av EU-försäkran
om överensstämmelse finns på följande
Internetadress :
http://www.jvc.net/cs/car/eudoc/
Suomi
JVCKENWOOD julistaa täten, että radiolaite
“KD-X165/KD-X163” on direktiivin 2014/53/EU
mukainen.
EU-vaatimustenmukaisuusvakuutusvaatimus
löytyy kokonaisuudessaan seuraavasta internet-
osoitteesta:
http://www.jvc.net/cs/car/eudoc/
Slovensko
S tem JVCKENWOOD izjavlja, da je radijska
oprema »KD-X165/KD-X163« v skladu z Direktivo
2014/53/EU.
Celotno besedilo direktive EU o skladnosti je
dostopno na tem spletnem naslovu:
http://www.jvc.net/cs/car/eudoc/
Slovensky
Spoločnosť JVCKENWOOD týmto vyhlasuje, že
rádiové zariadenie „KD-X165/KD-X163“ vyhovuje
smernici 2014/53/EÚ.
Celý text EÚ vyhlásenia o zhode nájdete na
nasledovnej internetovej adrese:
http://www.jvc.net/cs/car/eudoc/
Dansk
Herved erklærer JVCKENWOOD, at radioudstyret
“KD-X165/KD-X163” er i overensstemmelse med
Direktiv 2014/53/EU.
EU-overensstemmelseserklæringens fulde ordlyd
er tilgængelig på følgende internetadresse:
http://www.jvc.net/cs/car/eudoc/
Ελληνικά
Με το παρόν, η JVCKENWOOD δηλώνει ότι
ο ραδιοεξοπλισμός «KD-X165/KD-X163»
συμμορφώνεται με την Οδηγία 2014/53/ΕΕ.
Το πλήρες κείμενο της δήλωσης συμμόρφωσης
της ΕΕ είναι διαθέσιμο στην ακόλουθη διεύθυνση
στο διαδίκτυο:
http://www.jvc.net/cs/car/eudoc/
Eesti
Käesolevaga JVCKENWOOD kinnitab, et
„KD-X165/KD-X163“ raadiovarustus on vastavuses
direktiiviga 2014/53/EL.
ELi vastavusdeklaratsiooni terviktekst on
kättesaadav järgmisel internetiaadressil:
http://www.jvc.net/cs/car/eudoc/
Latviešu
JVCKENWOOD ar šo deklarē, ka radio aparatūra
„KD-X165/KD-X163” atbilst direktīvas 2014/53/ES
prasībām.
Pilns ES atbilstības deklarācijas teksts ir pieejams
šādā tīmekļa adresē:
http://www.jvc.net/cs/car/eudoc/
Lietuviškai
Šiuo JVCKENWOOD pažymi, kad radijo įranga
„KD-X165/KD-X163“ atitinka 2014/53/EB
direktyvos reikalavimus.
Visą EB direktyvos atitikties deklaracijos tekstą
galite rasti šiuo internetiniu adresu:
http://www.jvc.net/cs/car/eudoc/
Malti
B’dan, JVCKENWOOD jiddikjara li t-tagħmir
tar-radju “KD-X165/KD-X163” huwa konformi
mad-Direttiva 2014/53/UE.
It-test kollu tad-dikjarazzjoni ta’ konformità huwa
disponibbli fl-indirizz intranet li ġej:
http://www.jvc.net/cs/car/eudoc/
HRVATSKI / SRPSKI JEZIK
JVCKENWOOD ovim izjavljuje da je radio oprema
“KD-X165/KD-X163” u skladu s Direktivom
2014/53/EU.
Cjeloviti tekst deklaracije Europske unije o
usklađenosti dostupan je na sljedećoj internet
adresi:
http://www.jvc.net/cs/car/eudoc/
ROMÂNĂ
Prin prezenta, JVCKENWOOD declară că
echipamentul radio “
KD-X165/KD-X163 ” este în
conformitate cu Directiva 2014/53/UE.
Textul integral al declarației de conformitate UE este
disponibil la urmatoarea adresă de internet:
http://www.jvc.net/cs/car/eudoc/
БЪЛГАРСКИ
С настоящото JVCKENWOOD декларира, че
радиооборудването на “
KD-X165/KD-X163 ” е в
съответствие с Директива 2014/53/ЕС.
Пълният текст на ЕС декларацията за
съответствие е достъпен на следния интернет
адрес:
http://www.jvc.net/cs/car/eudoc/
Turkish
Burada, JVCKENWOOD “ KD-X165/KD-X163 ”
radyo ekipmanının 2014/53/AB Direktifine uygun
olduğunu bildirir.
AB uyumluluk deklarasyonunun tam metni
aşağıdaki internet adresinde mevcuttur.
http://www.jvc.net/cs/car/eudoc/
Русский
JVCKENWOOD настоящим заявляет, что
радиооборудование «KD-X165/KD-X163»
соответствует Директиве 2014/53/EU.
Полный текст декларации соответствия
ЕС доступен по следующему адресу в сети
Интернет:
http://www.jvc.net/cs/car/eudoc/
Українська
Таким чином, компанія JVCKENWOOD заявляє,
що радіообладнання «KD-X165/KD-X163»
відповідає Директиві 2014/53/EU.
Повний текст декларації про відповідність ЄС
можна знайти в Інтернеті за такою адресою:
http://www.jvc.net/cs/car/eudoc/
JS_JVC_KD_X165_Q_C.indd iiJS_JVC_KD_X165_Q_C.indd ii 20/6/2018 11:39:46 AM20/6/2018 11:39:46 AM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2ENGLISH
BEFORE USE
IMPORTANT
• To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe Warnings
and Cautions in this manual.
• Please keep the manual in a safe and accessible place for future reference.
WARNING
• Do not operate any function that takes your attention away from safe driving.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of the output level.
General:
• Avoid using the external device if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit to prevent a short circuit.
CONTENTS
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Cancel the demonstration
2 Set the clock and date
3 Set the basic settings
RADIO 5
AUX 7
USB/ANDROID 7
AUDIO SETTINGS 9
DISPLAY SETTINGS 11
REFERENCES 13
Maintenance
More information
TROUBLESHOOTING 14
INSTALLATION/
CONNECTION 15
SPECIFICATIONS 18
How to read this manual
• Operations are explained mainly using buttons on the faceplate of KD-X165.
• English indications are used for the purpose of explanation. You can select the display language from the menu. (Page 5)
• [XX] indicates the selected items.
• (Page XX) indicates references are available on the stated page.
JS_JVC_KD_X165_Q_ENRef_1st.indd 2JS_JVC_KD_X165_Q_ENRef_1st.indd 2 20/6/2018 2:16:17 PM20/6/2018 2:16:17 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
3
ENGLISH
BASICS
To On the faceplate
Turn on the power Press BSRC.
• Press and hold to turn off the power.
Adjust the volume Turn the volume knob.
Press the volume knob to mute the sound or pause playback.
• Press again to cancel. The volume level returns to the previous level before muting or pause.
Select a source • Press BSRC repeatedly.
• Press BSRC, then turn the volume knob within 2 seconds.
Change the display information Press repeatedly. (Page13, 14)
Attach
How to reset
Detach
Faceplate
Your preset
adjustments will be
erased except stored
radio stations.
Volume knob
Detach button
Display window
JS_JVC_KD_X165_Q_ENRef_1st.indd 3JS_JVC_KD_X165_Q_ENRef_1st.indd 3 20/6/2018 2:16:18 PM20/6/2018 2:16:18 PM

4ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Cancel the demonstration
When you turn on the power for the first time (or after you reset the unit),
the display shows: “CANCEL DEMO” “PRESS” “VOLUME KNOB”
1 Press the volume knob.
[YES] is selected for the initial setup.
2 Press the volume knob again.
“DEMO OFF” appears.
Set the clock and date
1 Press and hold .
2 Turn the volume knob to select [CLOCK] , then press the knob.
To adjust the clock
3 Turn the volume knob to select [CLOCKADJUST] , then press the knob.
4 Turn the volume knob to make the settings, then press the knob.
Hour Minute
5 Turn the volume knob to select [CLOCK FORMAT] , then press the knob.
6 Turn the volume knob to select [12H] or [24H] , then press the knob.
To set the date
7 Turn the volume knob to select [DATESET] , then press the knob.
8 Turn the volume knob to make the settings, then press the knob.
Day Month Year
9 Press to exit.
1
2
To return to the previous setting item, press .
Set the basic settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2 until the desired item is selected or activated.
4 Press to exit.
To return to the previous setting item, press .
Default: [XX]
[SYSTEM]
[KEY BEEP] [ON]: Activates the keypress tone. ; [OFF]: Deactivates.
[SOURCE SELECT]
[AM SRC]*[ON]: Enables AM in source selection. ; [OFF]: Disables. (Page 5)
[BUILT-IN AUX]*[ON]: Enables AUX in source selection. ; [OFF]: Disables. (Page 7)
[F/W UPDATE]
[UPDATE SYSTEM]
[F/W UP xxxx] [YES]: Starts upgrading the firmware. ; [NO]: Cancels (upgrading is not
activated).
For details on how to update the firmware, visit
<http://www.jvc.net/cs/car/>.
* Not displayed when the corresponding source is selected.
3
JS_JVC_KD_X165_Q_ENRef_1st.indd 4JS_JVC_KD_X165_Q_ENRef_1st.indd 4 20/6/2018 2:16:18 PM20/6/2018 2:16:18 PM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
[CLOCK]
[TIME SYNC] [ON]: The clock time is automatically set using
the Clock Time (CT) data in FM Radio Data
System signal. ; [OFF]: Cancels.
[CLOCK
DISPLAY]
[ON]: The clock time is shown on the
display even when the unit is turned off. ;
[OFF]: Cancels.
[ENGLISH] Select the display language for menu and music
information if applicable.
By default, [РУССКИЙ] is selected.
[РУССКИЙ]
[ESPANOL]
RADIO
• “ST” or “STEREO” lights up when receiving an FM stereo broadcast with sufficient signal strength.
• The unit switches to FM alarm automatically when receiving an alarm signal from FM broadcast.
Search for a station
1 Press BSRC repeatedly to select FM, FM-LO or AM.
2 Press S/ Tto search for a station automatically.
(or)
Press and hold S/ Tuntil “M” flashes, then press repeatedly to search for a station manually.
Settings in memory
You can store up to 12 stations for FM, 6 stations for FM-LO and 6 stations for AM.
Store a station
While listening to a station...
Press and hold one of the number buttons (1 to 6).
(or)
1 Press and hold the volume knob until “PRESETMODE” flashes.
2 Turn the volume knob to select a preset number, then press the knob.
“MEMORY” appears once the station is stored.
Select a stored station
Press one of the number buttons (1to6).
(or)
1 Press .
2 Turn the volume knob to select a preset number, then press the knob.
GETTING STARTED
JS_JVC_KD_X165_Q_ENRef_1st.indd 5JS_JVC_KD_X165_Q_ENRef_1st.indd 5 20/6/2018 2:16:18 PM20/6/2018 2:16:18 PM

6ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Other settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2 until the desired item is selected/activated or follow the
instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default: [XX]
[TUNERSETTING]
[RADIO TIMER] Turns on the radio at a specific time regardless of the current source.
1 [ONCE]/[DAILY]/[WEEKLY]/[OFF]: Select how often the timer will be
turned on.
2 [FM]/[FM-LO]/[AM]: Select the source.
3 [01] to [12] (for FM)/[01] to [06] (for FM-LO/AM): Select the preset station.
4 Set the activation day*1 and time.
“
 ” lights up when complete.
Radio Timer will not activate for the following cases.
• The unit is turned off.
• [OFF] is selected for [AMSRC] in [SOURCESELECT] after Radio Timer for AM
is selected. (Page 4)
[SSM] FM: [SSM01–06]/[SSM07–12], FM-LO: [SSM01–06]: Automatically
presets up to 12 stations for FM and 6 stations for FM-LO. “SSM” stops flashing
when the first 6 stations are stored. Select [SSM07–12] to store the following
6 stations for FM.
[LOCAL SEEK] [ON]: Searches only FM/FM-LO stations with good reception. ; [OFF]: Cancels.
• Settings made are applicable only to the selected source/station. Once you
change the source/station, you need to make the settings again.
RADIO
[IF BAND] [AUTO]: Increases the tuner selectivity to reduce interference noises from
adjacent FM/FM-LO stations. (Stereo effect may be lost.) ; [WIDE]: Subjects
to interference noises from adjacent FM/FM-LO stations, but sound quality
will not be degraded and the stereo effect will remain.
[MONO SET] [ON]: Improves the FM reception, but the stereo effect will be lost. ;
[OFF]: Cancels.
[NEWSSET]*2 [ON]: The unit will temporarily switch to News Programme if available. ;
[OFF]: Cancels.
[REGIONAL]*2 [ON]: Switches to another station only in the specific region using the “AF”
control. ; [OFF]: Cancels.
[AF SET]*2 [ON]: Automatically searches for another station broadcasting the same
program in the same Radio Data System network with better reception when
the current reception is poor. ; [OFF]: Cancels.
[TI]*2 [ON]: Allows the unit to temporarily switch to Traffic Information if available
(“TI” lights up) while listening to all sources except in AM. ; [OFF]: Cancels.
[PTY SEARCH]*2 Select a PTY code (see below).
If there is a station broadcasting a program of the same PTY code as you have
selected, that station is tuned in.
*1 Selectable only when [ONCE] or [WEEKLY] is selected in step 1.
*2 Selectable only when in FM source.
PTY code
[NEWS], [AFFAIRS], [INFO], [SPORT], [EDUCATE], [DRAMA], [CULTURE], [SCIENCE], [VARIED],
[POP M] (music), [ROCK M] (music), [EASY M] (music), [LIGHT M] (music), [CLASSICS],
[OTHER M] (music), [WEATHER], [FINANCE], [CHILDREN], [SOCIAL], [RELIGION], [PHONE IN],
[TRAVEL], [LEISURE], [JAZZ], [COUNTRY], [NATION M] (music), [OLDIES], [FOLK M] (music),
[DOCUMENT]
JS_JVC_KD_X165_Q_ENRef_1st.indd 6JS_JVC_KD_X165_Q_ENRef_1st.indd 6 20/6/2018 2:16:18 PM20/6/2018 2:16:18 PM

ENGLISH 7
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
USB/ANDROID
Start playback
The source changes automatically and playback starts.
*1 Do not leave the cable inside the car when not using.
*2 You can control Android device using the Android device itself via other media player
applications installed in the Android device.
Preparation:
You can listen to music from a portable audio player via the auxiliary input
jack.
• Select
[ON] for [BUILT-IN AUX] in [SOURCESELECT] . (Page4)
Start listening
1 Connect a portable audio player (commercially available).
3.5 mm stereo mini plug with “L” shaped
connector (commercially available)
Portable audio player
Auxiliary input jack
2 Press BSRC repeatedly to select AUX.
3 Turn on the portable audio player and start playback.
Use a 3-core plug head stereo mini plug for optimum audio
output.
AUX
USB input terminal
USB 2.0 cable*1
(commercially available)
USB cable*1
(commercially available)
USB
ANDROID*2
JS_JVC_KD_X165_Q_ENRef_1st.indd 7JS_JVC_KD_X165_Q_ENRef_1st.indd 7 20/6/2018 2:16:18 PM20/6/2018 2:16:18 PM

8ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
• To directly select USB/ANDROID source, press USB.
To On the faceplate
Reverse/
Fast-forward*3
Press and hold S/ T.
Select a file Press S/ T.
Select a folder*3 Press 2J/ 1K.
Repeat play*3 Press 4repeatedly.
[TRACK REPEAT] / [FOLDER REPEAT] / [ALL REPEAT] :
MP3/WMA/WAV/FLAC file
Random play*3 Press 3repeatedly.
[FOLDERRANDOM] / [ALL RANDOM] / [RANDOM OFF] :
MP3/WMA/WAV/FLAC file
*3 Not applicable for ANDROID.
USB/ANDROID
Select music drive
While in USB source, press 5MODE repeatedly.
Stored songs in the following drive will be played back.
• Selected internal or external memory of a smartphone (Mass Storage
Class).
• Selected drive of a multiple drive device.
Select a file from a folder/list
1 Press .
2 Turn the volume knob to select a folder/list, then press the knob.
3 Turn the volume knob to select a file, then press the knob.
Quick search (applicable only for USB source)
If you have many files, you can search through them quickly.
Turn the volume knob quickly to browse through the list quickly.
• To return to the previous setting item, press .
• To cancel, press and hold .
JS_JVC_KD_X165_Q_ENRef_1st.indd 8JS_JVC_KD_X165_Q_ENRef_1st.indd 8 20/6/2018 2:16:18 PM20/6/2018 2:16:18 PM

ENGLISH 9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
Select a preset equalizer directly
Press EQ-BASS repeatedly.
(or)
Press EQ-BASS, then turn the volume knob within 5seconds.
Preset equalizer:
[FLAT] (default)/ [DRVN3] / [DRVN2] / [DRVN1] / [HARDROCK] / [HIPHOP] / [JAZZ] / [POP] /
[R&B] / [TALK] / [USER] / [VOCALBOOST] / [BASSBOOST] / [CLASSICAL] / [DANCE]
Drive equalizer ( [DRVN 3] / [DRVN 2] / [DRVN 1] ) boosts specific frequencies in the
audio signal to reduce the noise heard from outside the car or running noise
of the tyres.
Store your own sound settings
1 Press and hold EQ-BASS to enter
[EASY EQ] setting.
2 Turn the volume knob to select an item, then press the knob.
Refer to [EASYEQ] for setting and the result is stored to [USER] .
• To return to the previous setting item, press .
• To exit, press EQ-BASS.
Other settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2 until the desired item is selected/activated or follow the
instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default: [XX]
[EQSETTING]
[PRESET EQ] Selects a preset equalizer suitable to the music genre.
• Select [USER] to use the settings made in [EASYEQ] or [PROEQ].
[FLAT]/[DRVN 3]/[DRVN 2]/[DRVN 1]/[HARD ROCK]/[HIP HOP]/
[JAZZ]/[POP]/[R&B]/[TALK]/[USER]/[VOCALBOOST]/[BASSBOOST]/
[CLASSICAL]/[DANCE]
[EASYEQ] Adjusts your own sound settings.
• The settings are stored to [USER] in [PRESET EQ].
• The settings made may affect the current settings of [PRO EQ].
[SUB.W SP]*1*2: [00] to [+06] (Default: [+03]
[SUB.W]*1*3: [–08] to [+08] [00]
[BASS]: [LVL–06] to [LVL+06] [LVL00]
[MID]: [LVL–06] to [LVL+06] [LVL00]
[TRE]: [LVL–06] to [LVL+06] [LVL00])
*1, *2, *3: (page 10)
JS_JVC_KD_X165_Q_ENRef_1st.indd 9JS_JVC_KD_X165_Q_ENRef_1st.indd 9 20/6/2018 2:34:16 PM20/6/2018 2:34:16 PM

10 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
[PRO EQ] Adjusts your own sound settings.
• The settings are stored to [USER] in [PRESET EQ].
• The settings made may affect the current settings of [EASYEQ].
1 [BASS]/[MIDDLE]/[TREBLE]: Select a sound tone.
2 Adjust the sound elements of the selected sound tone.
[BASS] Frequency : [60HZ]/[80HZ]/[100HZ]/[200HZ]
Level : [LVL–06] to [LVL+06]
Q : [Q1.0]/[Q1.25]/[Q1.5]/[Q2.0]
(Default : [80HZ]/[LVL00]/[Q1.0])
[MIDDLE] Frequency : [0.5KHZ]/[1.0KHZ]/[1.5KHZ]/[2.5KHZ]
Level : [LVL–06] to [LVL+06]
Q : [Q0.75]/[Q1.0]/[Q1.25]
(Default : [1.0KHZ]/[LVL00]/[Q1.25])
[TREBLE] Frequency : [10.0KHZ]/[12.5KHZ]/[15.0KHZ]/[17.5KHZ]
Level : [LVL–06] to [LVL+06]
Q : [QFIX]
(Default : [10.0KHZ]/[LVL00]/[QFIX])
[AUDIO CONTROL]
[BASS BOOST] [LEVEL+01] to [LEVEL+05] ([LEVEL+01]): Selects your preferred bass boost
level. ; [OFF]: Cancels.
[LOUDNESS] [LEVEL01]/[LEVEL02]: Boosts low or high frequencies to produce a well-
balanced sound at low volume. ; [OFF]: Cancels.
[SUB.W
LEVEL]*1
[SPK-OUT]*2 [SUB.W00] to [SUB.W+06] ([SUB.W+03]): Adjusts the
output level of the subwoofer connected via speaker lead.
(Page 17)
[PRE-OUT]*3 [SUB.W–08] to [SUB.W+08] ([SUB.W00]): Adjusts
the output level of the subwoofer connected to the lineout
terminals (REAR/SW) through an external amplifier.
(Page 17)
[SUBWOOFER SET]*3 [ON]: Turns on the subwoofer output. ; [OFF]: Cancels.
[SUBWOOFER LPF]*1 [FRQ THROUGH]: All signals are sent to the subwoofer. ;
[FRQ55HZ]/[FRQ85HZ]/[FRQ120HZ]: Audio signals with frequencies
lower than 55 Hz/85 Hz/120 Hz are sent to the subwoofer.
[SUB.W PHASE]*1*4 [REVERSE] (180°)/[NORMAL] (0°): Selects the phase of the subwoofer
output to be in line with the speaker output for optimum performance.
[FADER] [POSITIONR06] to [POSITIONF06] ([POSITION00]): Adjusts the front
and rear speaker output balance.
[BALANCE]*5 [POSITIONL06] to [POSITIONR06] ([POSITION00]): Adjusts the left
and right speaker output balance.
[VOLUME ADJUST] [LEVEL–15] to [LEVEL+06] ([LEVEL 00]): Presets the initial volume
level of each source by comparing to the FM volume level. (Before
adjustment, select the source you want to adjust. “VOL ADJ FIX” appears
if FM is selected.)
[AMPGAIN] [LOWPOWER]: Limits the maximum volume level to 25. (Select if the
maximum power of each speaker is less than 50 W to prevent damaging
the speakers.) ; [HIGHPOWER]: The maximum volume level is 35.
[D.T.EXPANDER]
(Digital Track
Expander)
[ON]: Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression. ; [OFF]: Cancels.
[SPK/PREOUT] Depending on the speaker connection method, select the appropriate
setting for the desired output. (See “Speaker output settings” on page
11.)
*1 Displayed only when [SUBWOOFER SET] is set to [ON].
*2 Displayed only when [SPK/PREOUT] is set to [SUB.W/SUB.W].
*3 Displayed only when [SPK/PREOUT] is set to [REAR/SUB.W] or [SUB.W/SUB.W].
*4 Selectable only if a setting other than [FRQTHROUGH] is selected for [SUBWOOFERLPF].
*5 This adjustment will not affect the subwoofer output.
JS_JVC_KD_X165_Q_ENRef_1st.indd 10JS_JVC_KD_X165_Q_ENRef_1st.indd 10 20/6/2018 2:16:19 PM20/6/2018 2:16:19 PM

ENGLISH 11
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
Speaker output settings [SPK/PRE OUT]
Select the output setting for the speakers [SPK/PRE OUT] , based on the speaker
connection method.
Connection via lineout terminals
For connections through an external amplifier. (Page17)
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
[REAR/REAR] Rear speakers output
[REAR/SUB.W] (default) Subwoofer output
[SUB.W/SUB.W] Subwoofer output
Connection via speaker leads
You can also connect the speakers without using an external amplifier
but still being able to enjoy the subwoofer output with these settings.
(Page17)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
[REAR/REAR] Rear speakers output Rear speakers output
[REAR/SUB.W] Rear speakers output Rear speakers output
[SUB.W/SUB.W] Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[FRQ120HZ] is selected in [SUBWOOFERLPF] and [FRQTHROUGH] is not available.
–
[POSITION R01] is selected in [FADER] and selectable range is [POSITION R06] to
[POSITION 00] .
DISPLAY SETTINGS
Zone identification for brightness settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2 until the desired item is selected/activated or follow the
instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default: [XX]
[DISPLAY]
[DIMMER] Dims the illumination.
[OFF]: Dimmer is turned off. Brightness changes to [DAY] setting.
[ON]: Dimmer is turned on. Brightness changes to [NIGHT] setting.
(See “[BRIGHTNESS]” below.)
[DIMMER TIME]: Set the dimmer on and off time.
1 Turn the volume knob to adjust the [ON] time, then press the knob.
2 Turn the volume knob to adjust the [OFF] time, then press the knob.
(Default: [ON]: [18:00] ; [OFF]: [6:00])
[DIMMER AUTO]: Dimmer turns on and off automatically when you turn off
or on the car headlights.*1
*1 The illumination control wire connection is required. (Page 17)
JS_JVC_KD_X165_Q_ENRef_1st.indd 11JS_JVC_KD_X165_Q_ENRef_1st.indd 11 20/6/2018 2:16:19 PM20/6/2018 2:16:19 PM

12 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
[BRIGHTNESS] Sets the brightness for day and night separately.
1 [DAY]/[NIGHT]: Select day or night.
2 Select a zone. (See the illustration on page 11.)
3 [LEVEL00] to [LEVEL31]: Set the brightness level.
[TEXT SCROLL]*2 [SCROLL ONCE]: Scrolls the display information once. ;
[SCROLL AUTO]: Repeats scrolling at 5-second intervals. ;
[SCROLL OFF]: Cancels.
*1 The illumination control wire connection is required. (Page 17)
*2 Some characters or symbols will not be shown correctly (or will be blank).
DISPLAY SETTINGS
[COLOR] (for KD-X165)
[PRESET] Selects illumination color for the color zone. (See the illustration on
page 11.)
• [COLOR01] to [COLOR49]
• [USER]: The color you have created for [DAYCOLOR] or [NIGHTCOLOR]
is shown.
• [COLORFLOW01] to [COLORFLOW03]: Color changes at different
speeds.
[DAYCOLOR] Stores your own day and night illumination colors for the color zone.
1 [RED]/[GREEN]/[BLUE]: Select a primary color.
2 [00] to [31]: Select the level.
Repeat steps 1 and 2 for all the primary colors.
• Your setting is stored to [USER] in [PRESET].
• [NIGHTCOLOR] or [DAYCOLOR] is changed by turning on or off your
car’s headlights.
[NIGHTCOLOR]
[MENUCOLOR] [ON]: The illumination color of the color zone changes to white color when
settings are performed on menu and list search, except in color setting
mode. ; [OFF]: Cancels.
JS_JVC_KD_X165_Q_ENRef_1st.indd 12JS_JVC_KD_X165_Q_ENRef_1st.indd 12 20/6/2018 2:16:19 PM20/6/2018 2:16:19 PM

ENGLISH 13
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
REFERENCES
Maintenance
Cleaning the unit
Wipe off dirt on the faceplate with a dry silicone or soft cloth.
Cleaning the connector
Detach the faceplate and clean the connector gently
with a cotton swab. Be careful not to damage the
connector.
More information
For: – Latest firmware updates and latest compatible item list
– Any other latest information
Visit <www.jvc.net/cs/car/>.
Playable files
• Playable audio file for USB mass storage class device:
MP3 (.mp3), WMA (.wma), WAV (.wav), FLAC (.flac)
• Playable USB device file system: FAT12, FAT16, FAT32
Even when audio files comply with the standards listed above, playback may be impossible
depending on the types or conditions of media or devices.
• For detailed information and notes about the playable audio files, visit
<www.jvc.net/cs/car/audiofile/>.
About USB devices
• You cannot connect a USB device via a USB hub.
• Connecting a cable whose total length is longer than 5 m may result in abnormal playback.
• This unit cannot recognize a USB device whose rating is other than 5 V and exceeds 1 A.
About Android device
• This unit supports Android OS 4.1 and later.
• Some Android devices (with OS 4.1 and later) may not fully support Android Open Accessory
(AOA) 2.0.
• If the Android device supports both mass storage class device and AOA 2.0, this unit always
play back via AOA 2.0 as priority.
Connector (on the reverse
side of the faceplate)
Change the display information (for KD-X165)
Each time you press , the display information changes.
• If the information is unavailable or not recorded, “NO TEXT”, “NO NAME”, or other information
(eg. station name) appears or display will be blank.
Main display
Clock display or will be blank
Supplementary display
Source name Display information: Main (Supplementary)
FM, FM-LO or AM Frequency (Date)
For FM Radio Broadcast Data System stations only:
Station name/Program type (Date) Radio text (Date) Radio text+
(Radio text+) Song title (Artist) Song title (Date) Frequency (Date)
back to the beginning
USB For MP3/WMA/AAC/WAV/FLAC files:
Song title (Artist) Song title (Album title) Song title (Date)
File name (Folder name) File name (Date) Playing time (Date)
back to the beginning
ANDROID Source name (Date)
AUX Source name (Date)
JS_JVC_KD_X165_Q_ENRef_2nd.indd 13JS_JVC_KD_X165_Q_ENRef_2nd.indd 13 29/6/2018 8:23:22 AM29/6/2018 8:23:22 AM

14 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
REFERENCES
Symptom Remedy
General
Sound cannot be heard. • Adjust the volume to the optimum level.
• Check the cords and connections.
“MISWIRING CHECK WIRING
THEN PWR ON” appears.
Turn the power off, then check to be sure the terminals of
the speaker wires are insulated properly. Turn the power
on again.
“PROTECTING SEND SERVICE”
appears.
Send the unit to the nearest service center.
Source cannot be selected. Check the [SOURCESELECT] setting. (Page 4)
The unit does not work at all. Reset the unit. (Page 3)
Correct characters are not
displayed.
• This unit can only display uppercase letters, numbers,
and a limited number of symbols.
• Depending on the display language you have selected
(page 5), some characters may not be displayed
correctly.
Radio
• Radio reception is poor.
• Static noise while listening
to the radio.
Connect the antenna firmly.
USB
Playback order is not as
intended.
The playback order is determined by the file name (USB).
Elapsed playing time is not
correct.
This depends on the recording process earlier (USB).
“NOT SUPPORT” appears and
track skips.
Check whether the track is a playable format.
(Page 13)
“READING” keeps flashing. • Do not use too many hierarchical levels and folders.
• Reattach the device (USB).
TROUBLESHOOTING
Change the display information (for KD-X163)
Each time you press , the display information changes.
• If the information is unavailable or not recorded, “NO TEXT”, “NO NAME”, or other information
(eg. station name) appears or display will be blank.
Main display
Source name Display information: Main
FM, FM-LO or AM Frequency Clock back to the beginning
For FM Radio Data System stations only:
Station name/Program type Radio text Radio text+ Radio text+
song title/Radio text+ artist Frequency Clock back to the
beginning
USB For MP3/WMA/WAV/FLAC files:
Song title/Artist Album title/Artist Folder name File name
Playing time Clock back to the beginning
ANDROID Source name Clock back to the beginning
AUX Source name Clock back to the beginning
Available Cyrillic letters
Available characters Display indications
JS_JVC_KD_X165_Q_ENRef_2nd.indd 14JS_JVC_KD_X165_Q_ENRef_2nd.indd 14 29/6/2018 8:23:23 AM29/6/2018 8:23:23 AM

ENGLISH 15
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
TROUBLESHOOTING
Symptom Remedy
USB
“CANNOT PLAY” flashes and/
or connected device cannot
be detected
• Check whether the connected device is compatible with
this unit and ensure the files are in supported formats.
(Page 13)
• Reattach the device.
“NO DEVICE” Connect a device (USB), and change the source to USB
again.
ANDROID
• Sound cannot be heard
during playback.
• Sound output only from
the Android device.
• Reconnect the Android device.
• Launch any media player application on the Android
device and start playback.
• Relaunch the current media player application or use
another media player application.
• Restart the Android device.
• If this does not solve the problem, the connected Android
device is unable to route the audio signal to unit.
(Page 13)
• If USB connection does not work, connect the Android
device through auxiliary input jack.
“NO DEVICE” or “READING”
keeps flashing.
• Reconnect the Android device.
• If USB connection does not work, connect the Android
device through auxiliary input jack.
Playback is intermittent or
sound skips.
Turn off the power saving mode on the Android device.
“CANNOT PLAY” • Make sure Android device contains playable audio files.
• Reconnect the Android device.
• Restart the Android device.
If you still have troubles, reset the unit. (Page3)
Warning
• The unit can only be used with a 12 V DC power supply, negative ground.
• Disconnect the battery’s negative terminal before wiring and mounting.
• Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire
(black) to prevent a short circuit.
• To prevent short circuit:
– Insulate unconnected wires with vinyl tape.
– Be sure to ground this unit to the car’s chassis again after installation.
– Secure the wires with cable clamps and wrap vinyl tape around the wires that come in contact
with metal parts to protect the wires.
Caution
• For safety’s sake, leave wiring and mounting to professionals. Consult the car audio dealer.
• Install this unit in the console of your vehicle. Do not touch the metal parts of this unit during
and shortly after use of the unit. Metal parts such as the heat sink and enclosure become hot.
• Do not connect the wires of speakers to the car chassis or Ground wire (black), or connect
them in parallel.
• Connect speakers with a maximum power of more than 50 W. If the maximum power of the
speakers is lower than 50 W, change the [AMPGAIN] setting to avoid damaging the speakers.
(Page 10)
• Mount the unit at an angle of less than 30º.
• If your vehicle wiring harness does not have the ignition terminal, connect Ignition wire (red)
to the terminal on the vehicle’s fuse box which provides 12 V DC power supply and is turned on
and off by the ignition key.
• Keep all cables away from heat dissipate metal parts.
• After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are
working properly.
• If the fuse blows, first make sure the wires are not touching car’s chassis, then replace the old
fuse with one that has the same rating.
INSTALLATION/CONNECTION
JS_JVC_KD_X165_Q_ENRef_1st.indd 15JS_JVC_KD_X165_Q_ENRef_1st.indd 15 20/6/2018 2:16:19 PM20/6/2018 2:16:19 PM

16 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Installing the unit (in-dash mounting)
Part list for installation
(A) Faceplate (×1) (B) Trim plate (×1)
(C) Mounting sleeve (×1) (D) Wiring harness (×1)
(E) Extraction key (×2)
Basic procedure
1 Remove the key from the ignition switch, then disconnect
the terminal of the car battery.
2 Connect the wires properly.
See “Wiring connection” on page 17.
3 Install the unit to your car.
See “Installing the unit (in-dash mounting)”.
4 Connect the terminal of the car battery.
5 Detach the faceplate and reset the unit. (Page3)
Removing the unitInstalling the unit without mounting sleeve
1 Remove the mounting sleeve and trim plate from the unit.
2 Align the holes in the unit (on both sides) with the
vehicle mounting bracket and secure the unit with screws
(commercially available).
Use only the specified screws. Using wrong screws might damage
the unit.
Do the required wiring.
(Page 17)
Bend the appropriate tabs to hold the
sleeve firmly in place.
Hook on the top side
Orientate the trim
plate as illustrated
before fitting.
Dashboard of
your car
INSTALLATION/CONNECTION
JS_JVC_KD_X165_Q_ENRef_1st.indd 16JS_JVC_KD_X165_Q_ENRef_1st.indd 16 20/6/2018 2:16:19 PM20/6/2018 2:16:19 PM

ENGLISH 17
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
INSTALLATION/CONNECTION
When connecting to an external amplifier, connect
its ground wire to the car’s chassis to avoid
damaging the unit.
Wiring connection
Fuse (10 A)
Antenna terminal
To the steering wheel remote control adapter
Yellow (A4)
Red (A7)
Yellow (Battery wire)
Pin Color and function
A4 Yellow : Battery
A5 Blue/White : Power control (12 V 350 mA)
A6 Orange/white : Car light control switch
A7 Red : Ignition (ACC)
A8 Black : Earth (ground) connection
B1 Purple
]
: Rear speaker (right)
B2 Purple/black
[
B3 Gray
]
: Front speaker (right)
B4 Gray/black
[
B5 White
]
: Front speaker (left)
B6 White/black
[
B7 Green
]
: Rear speaker (left)*
B8 Green/black
[
* You can also connect a subwoofer speaker directly without an external
subwoofer amplifier. For setting, see page 11.
Unit
Connecting the ISO connectors on some VW/
Audi or Opel (Vauxhall) automobiles
You may need to modify the wiring of the supplied wiring
harness as illustrated below.
Vehicle
A7 (Red)
Ignition wire
(Red)
A4 (Yellow)
Default wiring
Battery wire
(Yellow)
ISO connectors
If your car does not have an ISO terminal
We recommend installing the unit with a commercially
available custom wiring harness specific for your car and
leave this job to professionals for your safety. Consult your
car audio dealer.
Red (Ignition wire)
Light blue/yellow
(Steering remote control
wire)
Rear/subwoofer output
JS_JVC_KD_X165_Q_ENRef_1st.indd 17JS_JVC_KD_X165_Q_ENRef_1st.indd 17 20/6/2018 2:16:19 PM20/6/2018 2:16:19 PM

18 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
SPECIFICATIONS
Tuner
FM Frequency Range FM:
87.5 MHz — 108.0 MHz(50 kHz step)
FM-LO:
65.0 MHz — 74.0 MHz (30 kHz step)
Usable Sensitivity (S/N = 26 dB) 0.71 μV/75 Ω
Quieting Sensitivity (DIN S/N = 46 dB) 2.0 μV/75 Ω
Frequency Response (±3 dB) 30 Hz — 15 kHz
Signal-to-Noise Ratio (MONO) 64 dB
Stereo Separation (1 kHz) FM: 40 dB
AM
(MW)
Frequency Range 531 kHz — 1 611 kHz (9 kHz step)
Usable Sensitivity (S/N = 20 dB) 28.2 μV (29 dBμ)
AM
(LW)
Frequency Range 153 kHz — 279 kHz (9 kHz step)
Usable Sensitivity (S/N = 20 dB) 50 μV (33.9 dBμ)
USB
USB Standard USB 1.1, USB 2.0 (Full speed)
Compatible Devices Mass storage class
File System FAT12/16/32
Maximum Supply Current DC 5 V 1 A
Digital Filter (D/A) Converter 24 Bit
Frequency Response (±1 dB) 20 Hz — 20 kHz
Signal-to-Noise Ratio (1 kHz) 92 dB
Dynamic Range 88 dB
Channel Separation 83 dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
USB
WAV Decode Linear-PCM
FLAC Decode FLAC files, up to 16 bit/48 kHz
Auxiliary
Frequency Response (±3 dB) 20 Hz — 20 kHz
Input Maximum Voltage 1 000 mV
Input Impedance 30 kΩ
Audio
Maximum Output Power 50 W × 4 or
50 W × 2 + 50 W × 1 (Subwoofer = 4 Ω)
Full Bandwidth Power
(at less than 1 % THD)
22 W × 4
Speaker Impedance 4 Ω — 8 Ω
Preout Level/Load (USB) 2 500 mV/10 kΩ load
Preout Impedance ≤ 600 Ω
General
Operating Voltage 12 V DC car battery
Installation Size (W × H × D) 182 mm × 53 mm × 100 mm
Net Weight (includes Trimplate,
Mounting Sleeve)
0.6 kg
Subject to change without notice.
JS_JVC_KD_X165_Q_ENRef_2nd.indd 18JS_JVC_KD_X165_Q_ENRef_2nd.indd 18 29/6/2018 8:23:57 AM29/6/2018 8:23:57 AM
