K.K. Rocky RFM-DACNF01-P500MH Quick user guide

RFM-DACNF01-P500MH
(FMC DA Board)
Hardware Reference Manual
Ver.1.0
K.K.Rocky
NK building 2F
1-16-7, Kamiochiai, Shinjyuku-Ku,
Tokyo, Japan, 161-0034
TEL ：[phone]
FAX ：[phone]
HP ：http:/www.kkrocky.com/
E-Mail
：
[e-mail]
RFM-DACNF01-P500MH Hardware Reference Manual ver.10

Revision History
Issue Date Changes Made
ver1.0 2017/05/23 First Release
Table of Contents
1) Preface
2) Safety Instructions
………………………………………………………………………………………1. Introduction 1
…………………………………………………………………………………2. Main Components 1
……………………………………………………………………………………3. Block Diagram 1
……………………………………………………………………………………4. Board Layout 3
………………………………………………………………………………5. Board Specifications 3
…………………………………………………………………………………5.1 Output Signals 3
…………………………………………………………………………………………5.2 Power 4
…………………………………………………………………………………………5.3 Jumper 4
……………………………………………………………………………………5.4 Signal Flow 5
…………………………………………………………………………5.5 PLL Clock Distribution 5
………………………………………………………………5.6 FMC Connector Pin Assignment 7
……………………………………………………………………………11. Reference Documents 9
RFM-DACNF01-P500MH Hardware Reference Manual ver.10

－ ⅰ －
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
1) Preface
Thank you for choosing RFM-DACNF01-P500MH FMC board.
This manual describes the features and specifications of the RFM-DACNF01-P500MH FMC board.
Read and understand the contents of this manual before operating this board.
K.K.Rocky reserves the right to revise this document and to make changes without notice.
2) Safety Instructions
Always read the safety instructions carefully.
Cautions
●If smoke or an abnormal odor is detected from the FMC board, power off and
stop using the FMC board.
Continuous use of FMC board under these conditions might cause fire or permanent
damage to the system. Contact K.K.Rocky to test and repair.
●Do not attempt to disassemble and modify this board.
Disassembly and modification could cause fire or electric shock.
Please contact K.K.Rocky for any repair and test service.
●Never allow any liquids to spill on the FMC board, and never expose FMC board
to water or moisture.
Exposure to liquid or moisture could cause electric shock or fire.
●Avoid excessive vibration and any impact or shock to the FMC board.
Neglect could result in any damage on the board.
●Avoid handling the FMC board while it is powered. Only handle by the edges to
minimize the risk of electrostatic discharge damage.
●if the FMC board has been dropped and damaged, stop using the board and
contact K.K.Rocky to repair.
●Never place the board where it will be exposed to excess heat, such as in direct
sunlight, or near heater.

-1-
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
1. Introduction
The RFM-DACNF01-P500MH is an ANSI/VITA57-1 compliant FPGA Mezzanine Card (FMC) which offers one
16bits DA channel up to 500MSPS.
It works on a High Pin Count (HPC) site of FMC carrier board from K.K.Rocky or third party.
2. Main Components
The main components of the board are listed on Table 2-1.
Table 2-1 Main Components
Item Description Remarks
FMC Connector (HPC) ASP-134488-01 (SAMTEC)
DA Converter MAX5888AEGK+D (MAXIM)
PLL Clock Generator D9518-3
EEPROM (I2C) BR24L01AFV-WE2 (Rohm)
External Clock Input Connector MMCX-LR-PC-1 (40) (Hirose) on Front Panel
External Clock Input Connector MMCX-R-PC (40) (Hirose) on Board
(Reference) Mating Cable RF316-01SP1-03SP1-0500 (SAMTEC) This is not shipped with Board
3. Block Diagram
Figure 3-1 shows the block diagram of the board.
Figure 3-1 Block Diagram
AD_SYSCLK
BS_CLK_SEL
PLL_SPI
IN_CLK_SEL0
DA1_PD
DA1_SEL0
DA1_D0
:
DA1_D15
DA1_CLK
DA0_CLK
DA0_PD
DA0_SEL0
DA0_D0
:
DA0_D15
VADJ=2,5V
FMC(HPC)
BS_CLK
IN_CLK_SEL1
D0 0
S
W
1
2
1AD9518(PLL)
REF+ OUT0
OUT1
REF- OUT2
OUT3
CLK
OUT4
SPI OUT5
TCXO
20MHz
CN_CKI
CN_CKIP/N 2
12
2
D1
4
VADJ=2,5V
MAX9123
X4
VADJ=2,5V
MAX5888
IOUTP
IOUTN
CN_DA1_N
CN_DA1_P 16
B0P/N
:
B15P/N
PD
SEL0
CLKP/N
2 X 16
MAX9123
CN_DA0_N
CN_DA0_P
MAX5888
IOUTP
IOUTN
CLKP/N
B0P/N
:
B15P/N
PD
SEL0
2 X 16
Not mounted
16
AD_INCLK_OUT
LPC
22
HPC
LPC
S
W
2
MAX9123
X4
EEPROM SCL
SDA

-2-
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
4. Board Layout
Figure 4-1 shows the board layout of RFM-DACNF01-P500MH.
Figure 4-1 Board Layout
Table 4-1 shows the description of connectors.
Table 4-1 Description of connectors
Item Description Remarks
FMC Connector FMC Connector (HPC）ASP-134488-01 (SAMTEC)
CN_CKI External Clock Input (Single End) MMCX-LR-PC-1 (40) (Hirose)
CN_CKIP. CN_CKIN External Clock Input (Differential) MMCX-R-PC (40) (Hirose)
CN_DA1_P, CN_DA1_N Analog output MMCX-LR-PC-1 (40) (Hirose)
5. Board Specifications
5.1 Output Signals
Table 5-1 shows the specifications of analog output.
Table 5-1 Specifications of Analog output
Item Description
Number of Output 1 ch
Resolution 16 bit
DA Update Rate (Max) 500Msps
Output Coupling DC Coupling
Output Impedance 50Ω（Differential）
Output Voltage (Vp-p) 1V (max）
FMC(HPC)
Connector
CN_DA1_P
CN_DA1_N
CN_CKI
JP1 CN_CKIN CN_CKIP

-3-
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
5.2 Power
Table 5-2 shows the required power of the board. All Powers are supplied from FMC carrier board through FMC
connector.
Table 5-2 Power
Item Voltage Current Remarks
12P0V +12V 300mA (Max)
3P3V +3.3V 125mA (Max)
VADJ +2.5V 85mA (Max) not include current to VIO_M2C
3P3VAUX +3.3V 3mA (Max)
Figure 5-1 shows the block diagram of power distribution.
Figure 5-1 Power distribution
5.3 Jumper
Table 5-3 shows the function of JP1.
Table 5-3 JP1 Function
JP1 Setting Description
Off Normal Operation (Disable to write EEPROM)
On Set jumper to enable writing EEPROM
AD9518
Misc
3.3V
3.7V ADP1708
LTC3605
12V
3.3V
VADJ
(2.5V)
VIO_M2C
3P3VAUX
3.3V
ADP1708
LTC3605 ADP1708
X3
1.8V
2.6V
MAX9123
X5
NB6L72
BR24L01AFV
Not Used
LT3060 2V Not Used
3.8V
LTC3605 ADP1708 Not Used
3.3V
3.3V MAX5888
ADP1708
ADG719
MISC

-4-
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
5.4 Signal Flow
Figure 5-2 shows the block diagram of signal flow.
Figure 5-2 Signal Flow Block diagram
DA1 portion is mounted as default for RFM-DACNF01-P500MH.
However DA0 can be mounted as factory option instead of DA1.
5.5 PLL Clock Distribution
Figure 5-3 shows the block diagram of PLL clock distribution.
AD9518-3 clock distribution is described on Table 5-4 and Table 5-5.
Refer to AD9518-3 data sheet for further details of device operation.
S2
D
IN D
L S1
H S2
IN
S1
Ref+
OSC
20MHz
ADG719
2CLK
D0 Q1
D1
NB6L72
SEL0
SEL1
Q0
SEL1 Q1
L D0
H D1
SEL0 Q0
L D0
H D1
BS_CLK1 (LA31_P)
BS_CLK_SEL(LA31_N)
AD_SYSCLKp/n
(CLK0_M2C_P/N)
PLL_nCS (HA21_P)
PLL_SCLK (HA23_N)
PLL_SDIO (HA22_N)
PLL_MON (HA22_P)
PLL_LOCK (HA23_P)
AD_INCLK_OUT(LA33_P)
IN_CLK_SEL1(LA33_N)
IN_CLK_SEL0(HA16_P)
OUT0
OUT2
OUT4
CS
SCLK
SDIO
2
AD9518
CLK
2DAx_D0
CN-DAx-P IOUTP
CN-DAx-N IOUTN 2DAx_D15
PD DAx_PD
MAX5988
SEL0
HPC
DAx_SEL0
DA0～DA1 x=0～1
2
OUT1
Ref- OUT3
Reg:0x01C OUT5
RESET
REFMON
CN_CKI
CN_CKIP/N
LD
PLL_nRST (HA21_N)
MC100EPT21
2
D0
D15
MAX9123 X5

-5-
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
Figure 5-3 The Block Diagram of Clock Distribution
Table 5-4 AD9518-3 PLL Reference source selection (PLL is enabled)
Setting Remarks
BS_CLK_SEL IN_CLK_SEL0 AD9518-3 Register
0x01C[6,2,1] PLL REF source Input
Hx [0,0,1] TCXO (20MHz) REF1
Lx [0,0,1] BS CLKI (from FMC Carrier) REF1
xH [1,1,0] CN_CKI (Single ended) on Front Panel REF2
xL [1,1,0] CN_CKIP/N (Differential) on FMC REF2
Table 5-5 Sampling Clock Distribution
Clock Source AD9518-3 Register Setting AD Clock
0x1E1[1:0] VCO Divider CH Divider Direct Out
Internal VCO [1,0] 2 to 6 1 1 fVCO ÷(2 to 6)
(fVCO) 2 to 32 0 fVCO ÷{ (2 to 6)×(2 to 32) }
CLK input (fCLK) [0,0] 2 to 6 1 1 fCLK ÷(2 to 6)
IN_CLK_SEL1 (f > 1600MHz) 2 to 32 0 fCLK ÷{ (2 to 6)×(2 to 32) }
0 CN_CKIP/N [0,1] Bypass 1 0 fCLK ÷1
1 CN_CKI (f < 1600MHz) 2 to 32 0 fCLK ÷(2 to 32)
OSC
20MHZ
BS_CLKI
BS_CLK_SEL
FMC
Connector
Filter
÷R
PFD CP
VCO
÷N
÷(2 to 6)
1 0
1
0
÷(2 to 32)
S1
ADG719
S2
0
1REF1 0
1
REF2 CP
1
0
REG
0x01C[6]
LF
22
IN_CLK_SEL0
0
1
D0 Q0
REG
0x1E1[1]
NB6L72
0
1
Q1
CN_CKIP/N REG
0x1E0[2:0]
CLK+
CN_CKI
D1
AD_SYSCLKP/N
FMC
Connector
CLK-
IN_CLK_SEL1 OUT0
REG
0x192[1]
OUT1
2 2
REG
0x1E1[0] REG
0x191[7]
1
0
AD_INCLK_OUT
OUT2
1
0
REG
0x194[7]
REG
0x195[1]
OUT3
÷(2 to 32)
1
0
OUT4
REG
0x197[7] 1
0
REG
0x198[1]
OUT5
÷(2 to 32)
1
0
AD9518

-6-
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
5.6 FMC Connector Pin Assignment
Figure 5-4 shows pin assignment of FMC connector.
K J H G F E D C B A
1 N.C. GND N.C. GND PG_M2C GND N.C. GND CLK_DIR GND
2 GND N.C. PRSNT_M2C_L CLK1_M2C_P GND HA01_P_CC GND N.C. GND N.C.
3 GND N.C. GND CLK1_M2C_N GND HA01_N_CC GND N.C. GND N.C.
4 N.C. GND CLK0_M2C_P GND HA00_P_CC GND N.C. GND N.C. GND
5 N.C. GND CLK0_M2C_N GND N.C. GND N.C. GND N.C. GND
6 GND HA03_P GND N.C. GND HA05_P GND N.C. GND N.C.
7 HA02_P HA03_N LA02_P N.C. HA04_P HA05_N GND N.C. GND N.C.
8 HA02_N GND LA02_N GND HA04_N GND LA01_P_CC GND N.C. GND
9 GND HA07_P GND LA03_P GND HA09_P N.C. GND N.C. GND
10 HA06_P HA07_N LA04_P LA03_N HA08_P HA09_N GND LA06_P GND N.C.
11 HA06_N GND LA04_N GND HA08_N GND LA05_P LA06_N GND N.C.
12 GND N.C. GND LA08_P GND N.C. LA05_N GND N.C. GND
13 HA10_P N.C. LA07_P LA08_N N.C. N.C. GND GND N.C. GND
14 HA10_N. GND LA07_N GND N.C. GND LA09_P LA10_P GND N.C.
15 GND N.C. GND N.C. GND HA16_P LA09_N LA10_N GND N.C.
16 N.C. N.C. N.C. N.C. N.C. N.C. GND GND N.C. GND
17 N.C. GND N.C. GND N.C. GND N.C. GND N.C. GND
18 GND N.C. GND N.C. GND N.C. N.C. N.C. GND N.C.
19 HA21_P N.C. N.C. N.C. N.C. N.C. GND N.C. GND N.C.
20 HA21_N GND N.C. GND N.C. GND N.C. GND N.C. GND
21 GND HA22_P GND N.C. GND N.C. N.C. GND N.C. GND
22 HA23_P HA22_N N.C. N.C. N.C. N.C. GND N.C. GND N.C.
23 HA23_N GND N.C. GND N.C. GND N.C. N.C. GND N.C.
24 GND N.C. GND N.C. GND N.C. N.C. GND N.C. GND
25 N.C. N.C. N.C. N.C. N.C. N.C. GND GND N.C. GND
26 N.C. GND N.C. GND N.C. GND N.C. N.C. GND N.C.
27 GND N.C. GND N.C. GND N.C. N.C. N.C. GND N.C.
28 N.C. N.C. N.C. N.C. N.C. N.C. GND GND N.C. GND
29 N.C. GND N.C. GND N.C. GND N.C. GND N.C. GND
30 GND N.C. GND N.C. GND N.C. TDI SCL GND N.C.
31 N.C. N.C. N.C. N.C. N.C. N.C. TDO SDA GND N.C.
32 N.C. GND N.C. GND N.C. GND 3P3VAUX GND N.C. GND
33 GND N.C. GND LA31_P GND N.C. N.C. GND N.C. GND
34 N.C. N.C. N.C. LA31_N N.C. N.C. N.C. GA0 GND N.C.
35 N.C. GND N.C. GND N.C. GND GA1 12P0V GND N.C.
36 GND N.C. GND LA33_P GND N.C. 3P3V GND N.C. GND
37 N.C. N.C. N.C. LA33_N N.C. N.C. GND 12P0V N.C. GND
38 N.C. GND N.C. GND N.C. GND 3P3V GND GND N.C.
39 GND VIO_B_M2C GND VADJ GND VADJ GND 3P3V GND N.C.
40 VIO_B_M2C GND VADJ GND VADJ GND 3P3V GND N.C. GND
LPC Connector LPC Connector
Note : N.C. means "No Connection"
Figure 5-4 Connector Pin Assignment
(1) Supply +2.5V to VADJ.
(2) FMC loops back VADJ to VIO_B_M2C.
(3) VREF_A_M2C and VREF_B_M2C are not used (N.C.)
(4) When DA0 is mounted When DA1 is mounted,
When they are not mounted, these pins are N.C.

-7-
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
Table 5-6 shows the signal assignment to FMC connector.
Table 5-6 The Signal Assignment to FMC Connector
Pin# Signal FMC_LOC I/O Function Remarks
C 30 SCL SCL I I2C Clock
C 31 SDA SDA I/O I2C Data
C 34 GA0 GA0 I I2C Address 0
D 35 GA1 GA1 I I2C Address 1
When DA1 is mounted (otherwise N.C.)
K 14 DA1_SEL0 HA10_N I DA1 segment shuffling Mode Select Set High to Activate
K 13 DA1_PD HA10_P I DA1 Power Down Set Low for normal operation
F 4 DA1_CLK HA00_P_CC I DA1 Clock Input
K 7 DA1_B0 HA02_P I DA1 Data 0 (LSB)
K 8 DA1_B1 HA02_N I DA1 Data 1
J 6 DA1_B2 HA03_P I DA1 Data 2
J 7 DA1_B3 HA03_N I DA1 Data 3
F 7 DA1_B4 HA04_P I DA1 Data 4
F 8 DA1_B5 HA04_N I DA1 Data 5
E 6 DA1_B6 HA05_P I DA1 Data 6
E 7 DA1_B7 HA05_N I DA1 Data 7
K 10 DA1_B8 HA06_P I DA1 Data 8
K 11 DA1_B9 HA06_N I DA1 Data 9
J 9 DA1_B10 HA07_P I DA1 Data 10
J 10 DA1_B11 HA07_N I DA1 Data 11
F 10 DA1_B12 HA08_P I DA1 Data 12
F 11 DA1_B13 HA08_N I DA1 Data 13
E 9 DA1_B14 HA09_P I DA1 Data 14
E 10 DA1_B15 HA09_N I DA1 Data 15 (MSB)
When DA0 is mounted (otherwise N.C.)
C 15 DA0_SEL0 LA10_N I DA0 segment shuffling Mode Select Set High to Activate
C 14 DA0_PD LA10_P I DA0 Power Down Set Low for normal operation
D 8 DA0_CLK LA01_P_CC I DA0 Clock Input
H 7 DA0_B0 LA02_P I DA0 Data 0 (LSB)
H 8 DA0_B1 LA02_N I DA0 Data 1
G 9 DA0_B2 LA03_P I DA0 Data 2
G 10 DA0_B3 LA03_N I DA0 Data 3
H 10 DA0_B4 LA04_P I DA0 Data 4
H 11 DA0_B5 LA04_N I DA0 Data 5
D 11 DA0_B6 LA05_P I DA0 Data 6
D 12 DA0_B7 LA05_N I DA0 Data 7
C 10 DA0_B8 LA06_P I DA0 Data 8
C 11 DA0_B9 LA06_N I DA0 Data 9
H 13 DA0_B10 LA07_P I DA0 Data 10
H 14 DA0_B11 LA07_N I DA0 Data 11
G 12 DA0_B12 LA08_P I DA0 Data 12
G 13 DA0_B13 LA08_N I DA0 Data 13
D 14 DA0_B14 LA09_P I DA0 Data 14
D 15 DA0_B15 LA09_N I DA0 Data 15 (MSB)

-8-
RFM-DACNF01-P500MH Hardware Reference Manual ver.10
Table 5-6 The Signal Assignment to FMC Connector (continued)
Pin# Signal FMC_LOC I/O Function Remarks
F 1 AD_PGOOD PG_M2C O Power Good
E 2 BS_CLKp HA01_P_CC O Selected External clock
E 3 BS_CLKn HA01_N_CC O Selected External clock
G 18 IN_CLK_SEL0 HA16_P I CN_CKIP/ CN_CKIN Select
K 19 PLL_nCS HA21_P I PLL (AD9518) Chip Select
K 20 PLL_nRST HA21_N I PLL (AD9518) Reset
J 21 PLL_MON HA22_P O PLL (AD9518) Reference monitor
J 22 PLL_SDIO HA22_N I/O PLL (AD9518) Serial Control Port data I/O
K 22 PLL_LOCK HA23_P O PLL (AD9518) Lock detect
K 23 PLL_SCLK HA23_N I PLL (AD9518) Serial Control port Clock
H 4 SYSCLKp CLK0_M2C_P O PLL (AD9518) LVPECL Output
H 5 SYSCLKn CLK0_M2C_N O PLL (AD9518) LVPECL Output
G 33 BS_CLK LA31_P I PLL Reference Clock from FMC Carrier
G 34 BS_CLK_SEL LA31_N I Reference Clock Select Refer to Table 5-4
G 37 IN_CLK_SEL1 LA33_N I Input Clock Select Refer to Table 5-5
G 36 INCLK_OUT LA33_P O Clock Input Monitor
6. Reference Documents
(1) FPGA Mezzanine Card (FMC) Standard ANSI/VITA 57.1
(2) MAX5888 Data Sheet （MAXIM)
(3) AD9518-3 Data Sheet （Analog Devices)
