Küschall Compact SA User manual

Küschall®Compact
CompactSA/CompactFF
enActiveWheelchair
ServiceManual
PROVIDER:Keepthismanual.
TheproceduresinthismanualMUSTbeperformedbyaqualied
technician.

©2019 Invacare Corporation
All rights reserved. Republication, duplication or modication i n w hole o r i n p art i s p rohibited w ithout p rior written
permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to
Invacare Corporation or its subsidiaries unless otherwise noted.
Making Life's Experiences Possible is a registered trademark in the U.S.A.

Contents
1General.........................................4
1.1Introduction..................................4
1.2SymbolsinThisManual..........................4
2Safety..........................................5
2.1GeneralSafetyInformation.......................5
2.2Personalsafetyinformation.......................5
2.3Generalrepairinformation.......................5
3ProductOverview.................................7
3.1Mainpartsofthewheelchair.....................7
3.2Dimensions...................................7
4Servicing........................................8
4.1Inspectionchecklist.............................8
4.2Spareparts...................................8
5Reconditioning....................................9
5.1Cleaning.....................................9
5.2Disinfection...................................9
5.3Materials....................................9
6Instructions......................................10
6.1FrameOverview...............................10
6.1.1ReplacingtheRearFrame.....................10
6.1.2ReplacingthefrontFrame.....................10
6.1.3ReplacingtheRetainingLever...................11
6.1.4ReplacingthecentralCross-BracePivotBolt........11
6.1.5CuttingtherearFrametoLength................12
6.2Seat........................................14
6.2.1FrontSeat-to-FloorHeight(FSTF)................14
6.2.2RearSeat-to-FloorHeight(RSTF).................14
6.2.3SeatWidth(SW)............................15
6.2.4Seatdepth(SD).............................15
6.2.5ReplacingtheSeatCover......................15
6.2.6TurningtheSeatLockingMechanism.............15
6.3Backrest.....................................17
6.3.1BackrestHeight.............................17
6.3.2AdjustingtheHeightofstandardBackrests.........17
6.3.3AdjustingtheHeightofHookandLoopadjustable
Backrests.................................17
6.3.4Angle-adjustableBackrest......................17
6.3.5Installinganangle-adjustableBackrest............18
6.3.6AdjustingtheBackrestAngle...................18
6.3.7InstallingtheJointforafoldingBackrest..........19
6.3.8ReplacingPushHandles/ReplacingPushHandles
andBackrest..............................20
6.3.9InstallingstandardPushHandles.................20
6.3.10Installingheight-adjustable,integratedPush
Handles..................................20
6.3.11Installingheight-adjustable,rearsetPush
Handles..................................20
6.3.12Installingangle-adjustableBackrestwith
height-adjustablePushHandles.................21
6.3.13ReplacingthefoldablePushHandle.............21
6.3.14InstallingtheStabilisationBar..................22
6.3.15BackrestPartsforadjustableBackswithrespect
toBackrestHeight..........................23
6.4Legrests.....................................30
6.4.1ReplacingthelockingMechanism................30
6.5Footrests.....................................30
6.5.1ReplacingtheFootPlate(One-pieceFootrest).......30
6.5.2ReplacingtheFootrest(One-pieceFootrest)........31
6.5.3CentringandadjustingtheAngle(One-piece
Footrest).................................31
6.5.4ChangingtheFootrestPosition(One-piece
Footrest).................................31
6.5.5ReplacingtheFootrest(Two-pieceFootrest)........32
6.5.6AdjustingtheHeightoftheFootrest(Two-piece
Footrest).................................32
6.5.7ChangingtheFootrestPosition(Two-piece
Footrest).................................32
6.6Sideparts.....................................33
6.6.1InstallingtheClothes-Guard/Mudguard..........33
6.6.2AdjustingtheClothes-Guard/Mudguard..........33
6.6.3InstallingtheremovableMudguard..............33
6.6.4Clothes-Guard/MudguardSizes.................34
6.6.5InstallingtheHemiArmrestwithHolder...........35
6.6.6InstallingtheKüschallArmrest..................37
6.6.7InstallingtheSideRestinsertable,stepless
height-adjustable...........................38
6.6.8InstallingthetubularArmrest(swivelling)..........39
6.7Castors......................................40
6.7.1ReplacingtheCastorWheel....................40
6.7.2ReplacingtheCastorFork......................40
6.7.3SettingtheSteeringErrorAngle.................41
6.7.4SettingtheTrialAngle........................41
6.7.5Installing/ShiftingtheCastorForkSupporteronthe
Frame...................................42
6.8RearWheels..................................43
6.8.1AdjustingtherearSeat-to-FloorHeight(RSTF)......44
6.8.2TippingStability.............................44
6.8.3AdjustingtherearWheelPositionontheAdapter
Plate....................................44
6.8.4InstallingtheRearWheelExtension..............44
6.8.5ChangingtheWheelCamber...................45
6.8.6EnsuringtheRearWheelsareparallel............45
6.8.7AdjustingtheRemovableAxle..................46
6.8.8InstallingtheAdapterPlatefortheDrumBrake.....46
6.8.9DistanceSleevesforRearWheels................46
6.8.10RepairingorChanginganinnerTube............46
6.8.11Replacingasolidtire........................47
6.8.12Replacingrearwheelspokes...................47
6.9Parkingbrakes.................................48
6.9.1Installingtheparkingbrake....................48
6.9.2Adjustingtheparkingbrake....................48
6.9.3Installing/AdjustingtheDrumBrake..............49
6.10Options.....................................49
6.10.1Installingtheantitipper......................49
6.10.2Adjustingtheheightoftheantitipper............50
6.10.3Installingthetipperaid......................51
6.10.4Adjustingtheheightofthetipperaid............51
6.10.5Installingthecaneholder.....................51
6.10.6Adjustingtheheightofthecaneholder..........52
6.10.7Installingthetransitwheels...................52
6.10.8Adjustingtheheightofthetransitwheels........52
6.10.9InstallingtheOne-Arm-Drive...................52
6.10.10InstallingthePostureBelt....................53
6.10.11Attachingthesnaphooksymbollabels..........54

Küschall®Compact
1General
1.1Introduction
Thisdocumentcontainsimportantinformationabout
assembly,adjustmentandadvancedmaintenanceofthe
product.Toensuresafetywhenhandlingtheproduct,read
thisdocumentandtheusermanualcarefullyandfollow
thesafetyinstructions.
FindtheusermanualonInvacare’swebsiteorcontact
yourInvacarerepresentative.Seeaddressesattheend
ofthisdocument.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthisdocument,makesureyouhavethe
latestversion.YoundthelatestversionasaPDFonthe
Invacarewebsite.
Forpre-saleanduserinformation,seetheusermanual.
Formoreinformationabouttheproduct,forexample
productsafetynoticesandproductrecalls,contactyour
Invacarerepresentative.Seeaddressesattheendofthis
document.
1.2SymbolsinThisManual
Symbolsandsignalwordsareusedinthismanualand
applytohazardsorunsafepracticeswhichcouldresultin
personalinjuryorpropertydamage.Seetheinformation
belowfordenitionsofthesignalwords.
WARNING
Indicatesahazardoussituationthatcould
resultinseriousinjuryordeathifitisnot
avoided.
CAUTION
Indicatesahazardoussituationthatcould
resultinminororslightinjuryifitisnot
avoided.
IMPORTANT
Indicatesahazardoussituationthatcould
resultindamagetopropertyifitisnot
avoided.
Tips
Givesusefultips,recommendationsand
informationforefcient,trouble-freeuse.
Tools
Identiesrequiredtools,componentsand
itemswhichareneededtocarryoutcertain
work.
41659353-A

Safety
2Safety
2.1GeneralSafetyInformation
WARNING!
Riskofinjuryordamagetoproperty
–Theproceduresinthismanualmustonlybe
performedbyaqualiedtechnician.
–Useonlyoriginaloptionsandspareparts.
–Donothandlethisproductoranyavailable
optionalequipmentwithoutrstcompletely
readingandunderstandingtheseinstructions
andanyadditionalinstructionalmaterialsuch
asusermanuals,installationmanualsor
instructionsheetssuppliedwiththisproduct
oroptionalequipment.
–Aftereachassembly,checkthatallttingsare
properlytightenedandthatallpartshavethe
correctfunction.
WARNING!
Riskofcontamination
–Cleananddisinfecttheproductbefore
servicing.
IMPORTANT!
Assemblyofoptionalequipmentmightnotbe
describedinthisservicemanual.Refertothe
manual,deliveredwiththeoptionalequipment.
–Additionalmanualscanbeorderedfrom
Invacare.Seeaddressesattheendofthis
document.
–Duetoregionaldifferences,refertoyour
localInvacarecatalogorwebsiteforavailable
optionalequipmentorcontactyourlocal
Invacarerepresentative.Seeaddressesatthe
endofthisdocument.
IMPORTANT!
Somereplacementpartsareonlyavailableas
akit.Alwaysusethecompletenewkitwhen
replacingapart.
–SparepartscanbeorderedfromInvacare.
RefertoyourlocalInvacarewebsitetoaccess
theelectronicsparepartscatalogue(ESPC).
IMPORTANT!
Refertotheusermanualofthisproductfor
informationon
–Technicaldata
–Productcomponents
–Labels
–Additionalsafetyinstructions
Theinformationcontainedinthisdocumentis
subjecttochangewithoutnotice.
2.2Personalsafetyinformation
Thesesafetyinstructionsareintendedtohelpavoid
accidentsduringworkandmustbeobservedunderall
circumstances.
Allemployeescomingintocontactwithcontaminated
productsmustregularlyconsultacompanydoctor.
Workclothingandpersonalprotectiveequipmentmust
beavailableinnecessaryquantitiesandbeinproper
condition.Reliablehandandsurfacedisinfectionmustbe
ensured.
WARNING!
Riskofcontamination
–Cleananddisinfecttheproductbefore
carryingoutrepairs.
2.3Generalrepairinformation
Repairsrequireahighlevelofexpertise.Theseassemblyinstructionsthereforebreakdownthevarioustasksinto
3categories:
RequirementSymbol
Easy–technicalunderstandingrequired■□□
Medium–technicalknowledgerequired■■□
Difcult–technicalknowledgeandexpertiseinassemblingrequired■■■
Therequiredtoolsandtheirsizesarelistedbeforetheinstructions.
IMPORTANT!
–Ifpossible,continuetousetheoldidenticationlabel;ifthisisnotpossible,thenewidenticationlabelmust
containthesameinformationandtheoldserialnumber.(Replacementofsparepartswithserialnumbers).
–Whencomponentsarereplaceditisnecessarytoensurethetraceabilityofthecomponentsreplaced.
–Ifscrewswiththreadlockerareloosened,thesemustbereplacedwithnewscrewswiththreadlocker.
Alternatively,newthreadlockermustbeapplied.
–Ifscrewswithcirclipringsareloosened,thesemustbereplacedwithnewones.
–Partsthatbecomedamagedduringremovalmustbereplacedwithnewones.
–Allboltsmustbetightenedwiththetorquespeciedinthefollowinginstructions.Liquidhigh-strengthand
low-strengthadhesivesareavailable.Afterthetorquespecications,theadhesivetobeused(high-strength
orlow-strength)isindicatedinbrackets.
1659353-A5

Küschall®Compact
Fasteningwithhexagonsocketbolts
Hexagonsocketboltsarenotdesignedtowithstandan
excessiveapplicationofforce.Whentighteningorundoing
ahexagonsocketbolt,forceshouldbeappliedtothenut
whereverpossibletoavoiddamagingthebolt.
Tighteningandundoing
Turnthenutusingasocketspanner(onlyuseanopen-end
spannerifthereisinsufcientspace),usingtheAllenkey
simplytostoptheboltturning.
Tighteningandundoingwhennonutispresent
Ifahexagonsocketboltisscreweddirectlyintoathread,
theboltmustbetightenedusingtheAllenkey.
EnsurethattheAllenkeyisofgoodqualityandnotworn.
61659353-A

ProductOverview
3ProductOverview
3.1Mainpartsofthewheelchair
ABack
BClothes-guard
CSeat
DFrame
EFootrest
FCastorforkwithcastorwheel
GParkingbrake
HRearwheelwithhandrim
3.2Dimensions
ASeatdepth(SD)320–500mm,inincrementsof
20mm
BBackrestangle
(BA)
82°/86°/90°/94°/98°/102°
CLowerleg
length(LLL)
200–510mm,inincrementsof
10mm
DFrontseat-to-
oorheight
(FSTF)
370–530mm,inincrementsof
10mm
ERearseat-to-
oorheight
(RSTF)
360–500mm,inincrementsof
10mm
FBackrestheight
(BH)
300–510mm,inincrementsof
15mm
GTotallength(TL)70°frameangle:
approx.870–1220mm
80°frameangle:
approx.850–1200mm
HSeatwidth(SW)280–500mm,inincrementsof
20mm
ITotalwidth
(TW)
Totalwidth,
folded
Seatwidth+180mm
approx.290mm
1659353-A7

Küschall®Compact
4Servicing
4.1Inspectionchecklist
GeneralinspectionJL
Istheproductingoodconditionandisit
complete(productandoptionalequipment)?
☐☐
Istheproductfreefromdamageorweaknesses
ofanykind?
☐☐
Doestheproductoperatecorrectlyunder
nominalload?
☐☐
Istheproductfullyfunctionalinaccordancewith
theusermanual?
☐☐
EradicationoffaultsJL
Haveallthefaultsfoundbeeneliminatedand
havefaultycomponentsbeenreplaced?
☐☐
Areallscrews/boltsrmlyttedandisthe
productsecurelyassembled?
☐☐
CompletionofchecksJL
Istheproducttechnicallyandfunctionallysafe?☐☐
Hastheproductbeencleanedanddisinfected?☐☐
Istheidenticationlabeleasilyreadableandisit
securelymountedontheproduct?
☐☐
Istheproductaccompaniedbythelatestrevision
oftheusermanual?
☐☐
4.2Spareparts
WARNING!
Originalsparepartsmustbeusedinallrepairs.
Otherwisethewarrantyandproductdeclaration
ofconformityshallberenderedinvalid.
AllsparepartsmustbeobtainedfromtheInvacare
customerservicedepartment.Anelectronicspareparts
cataloguecanbefoundonyourlocalInvacarewebsite.
WARNING!
Riskofinjuryduetodamagedorwornparts
Somereplacementpartsareonlyavailableas
akit.
–Alwaysusethecompletenewkitwhen
replacingapart.
81659353-A

Reconditioning
5Reconditioning
5.1Cleaning
IMPORTANT!
–Theproductdoesnottoleratecleaningin
automaticwashingplants,withhigh-pressure
cleaningequipmentorsteam.
IMPORTANT!
Dirt,sandandseawatercandamagethe
bearingsandsteelpartscanrustifthesurface
isdamaged.
–Onlyexposethewheelchairtosandand
seawaterforshortperiodsandcleanitafter
everytriptothebeach.
–Ifthewheelchairisdirty,wipeoffthedirtas
soonaspossiblewithadampclothanddry
itcarefully.
1.Removeanyinstalledoptionalequipment(only
optionalequipmentwhichdoesnotrequiretools).
2.Wipedowntheindividualpartsusingaclothorsoft
brush,ordinaryhouseholdcleaningagents(pH=6-
8)andwarmwater.
3.Rinsethepartswithwarmwater .
4.Thoroughlydrythepartswithadrycloth.
Carpolishandsoftwaxcanbeusedonpainted
metalsurfacestoremoveabrasionsandrestore
gloss.
Cleaningupholstery
Forcleaningupholsteryrefertotheinstructionsonthe
labelsoftheseat,cushionandbackrestcover.
5.2Disinfection
Informationonrecommendeddisinfectants
andmethodscanbefoundonhttps://vah-
online.de/en/for-users.
1.Wipedownallgenerallyaccessiblesurfaceswithasoft
clothandordinaryhouseholddisinfectant.
2.Allowtheproducttoair-dry.
5.3Materials
ThecomponentsusedtomanufactureKüschall®
wheelchairsconsistoffollowingmaterials:
FrametubesAluminum
BackresttubesAluminum
CrossstrutsAluminum
Seatcover/BackrestcoverPA/PE/PVC
PushhandlesAluminum/TPE
Clothesguard/MudguardCarbonFiberorPlastic
CastorforksAluminum
LegrestAluminum
FootrestCarbonFiberorPlastic
Supportingparts/
Attachments
Steel/Aluminum
ScrewsandboltsSteel
Allcomponentshaveeitheraprotectivecoatingorare
corrosionresistant.
1659353-A9

Küschall®Compact
6Instructions
6.1FrameOverview
ARearframe
A1=13Nm
A2=7Nm
BRetaininglever
B1=4Nm
CCross
DFrontframe
D1=13Nm
D2=7Nm
EUpperconnectiontube
FLowerconnectingtube
GSeatlockingmechanism
HLongitudinalstopping
bolts
6.1.1ReplacingtheRearFrame
Allenkey(5mm)/Socketspanner(10)■■□
1.Removethebackrest,see6.3Backrest,page17.
2.LoosenandremoveboltsA1andA2.
3.PullouttherearframeAtotheback.
4.Pushthenewrearframeontotheupperandlower
connectingtubesEandF.
5.ReinsertandtightenboltsA1andA2.
6.1.2ReplacingthefrontFrame
Allenkey(3mm,4mm,5mm)/Socketspanner(10)■■□
101659353-A

Instructions
1.Disassemblebrakes.
2.LoosenandremoveboltsD1andD2onbothsides.
(Onabductionframes,theconnectingtubeFiswelded
ontothefrontframe;inthiscaseloosenA1andD2.)
3.PulloutfrontframeDtothefront.
4.RemoveseatlockingmechanismGwiththreadedinsert
fromoldfrontframeandtitonthenewfrontframe,
6.2.6TurningtheSeatLockingMechanism,page15.
5.Pushthefrontframeontotheupperandlower
connectingtube.
6.ReinsertandtightenboltsD1andD2onbothsides.
7.Setthecastorforkangle,6.7.3SettingtheSteeringError
Angle,page41.
6.1.3ReplacingtheRetainingLever
Allenkey(3mm,4mm,5mm)/Socketspanner(10)■■□
1.Withmudguardorclothesguard,xed:removeA1and
D2,withmudguardorsiderest,insertableandsiderest,
foldable:removeA1andA2.
2.RemoveboltB1.
3.PulltheretainingleverBfromtheupperconnecting
tubeE.
4.RemovesleeveB2.
5.Pushthenewretainingleverovertheupperconnecting
tubeE.
6.PositionsleeveB2withwideedgeinjointB3.
7.SecureretainingleverwithboltB1.
8.Withmudguardorclothesguard,xed:reinsertand
tightenboltsA1andD2,withmudguardorsiderest,
insertableandsiderest,iptoback:reinsertand
tightenboltsA1andA2.
6.1.4ReplacingthecentralCross-BracePivotBolt
IMPORTANT!
–Thepivotboltconnectionmustbereplacedwhenthecentralcross-braceismountedwiththeoldassemblykit.
Theoldassemblykitcanbeeasilyidentiedasfollows:
•ThespacerBisnotincluded.
•NutDisnotacapnut.
Allenkey(5mm)/Socketspanner(10)/MolykoteTP42■■□
1659353-A11

Küschall®Compact
1.Removetheoldboltconnectionfromthecross-brace.
2.LubricatebothsidesofdistancepartEslightlywith
MolykoteTP42andremoveexcessgrease.
3.Re-assemblethecross-braceusingonlythenew
assemblykit(SP1537689)containingboltAwith
washer,spacerB,springwasherC,safetycapnutD
anddistancepartE.
D=3Nm(Highstrength)
6.1.5CuttingtherearFrametoLength
Saw,cuttingtemplate,tubedeburrer■■□
1.Referringtothetablebelow,cuttherearframeto
lengthmeasuredfromtheloweredgeofthebackframe
tubeA.
2.Deburrtheouterandinnercutedgesatthebackframe
tube.
3.AttachtheplasticguidebushingEtothebackframe
tubeandinsertthetelescopictubeD.
WARNING!
RiskofBreakageoftheBackrest.
–Whenmountingthetelescopictubes,alwaysmakesure
thattheuppermostholeBofthetelescopictubeis
positionedatleast10mmbelowtheupperedgeCof
therearframetube.
RearFrame-CutoffTableinRelationtoBackrestHeightandmountingType:
Backrestheight
(RH)
300315330345360375390405420435450465480495510
Standard/minipushhandle
lumbarx[mm]420420420435450465480495510525—————
Withoutpushhandle
lumbarx[mm]405420435450465480495405420435450465480495510
Foldablepushhandle
lumbarx[mm]420435450465480495510435450465480495510525—
Height-adjustablepushhandle,rearset
straightx[mm]405420435450465480495510525——————
lumbarx[mm]405420435450465480495405420435450465480495510
121659353-A

Instructions
Backrestheight
(RH)
300315330345360375390405420435450465480495510
Height-adjustablepushhandle,integrated
straightx[mm]390405405405405405405420435450465480495435450
lumbarx[mm]360375390405405405405405405405405405420435450
1659353-A13

Küschall®Compact
6.2Seat
6.2.1FrontSeat-to-FloorHeight(FSTF)
Optionsforchangingthefrontseatheight:
•Replacethecastorwheelwithlargerorsmalleroneor
titatanotherpositiononthecastorfork,see6.7.1
ReplacingtheCastorWheel,page40.
•Replacecastorforkwithalargerorasmallerone,see
6.7.2ReplacingtheCastorFork,page40.
•Installthecastorforkinhighorlowposition,see6.7.5
Installing/ShiftingtheCastorForkSupporteronthe
Frame,page42.
A
B
C
D
E
F
G
H
Therearefourcastorforksizesavailable:
Seatheightfrontwithrespecttoforksize,castorsizeandmountingsituation
Framehighmountedstandardmountedlowmounted
Castorsize3”4”5”6”7”3”4”5”6”7”3”4”5”6”7”
FSTF380A——————————————
FSTF390B——————————————
FSTF400B——————————————
FSTF410CB———A—————————
FSTF420DC———B—————————
FSTF430ECC——B—————————
FSTF440FDC——CB———A————
FSTF450GED——DC———B————
FSTF460HFED—ECC——B————
FSTF470—GFE—FDC——CB———
FSTF480—HGFEGED——DC———
FSTF490——HGFHFED—ECC——
FSTF500———HG—GFE—FDC——
FSTF510————H—HGFEGED——
FSTF520———————HGFHFED—
FSTF530————————HG—GFE—
FSTF540—————————H—HGFE
FSTF550————————————HGF
6’’and7’’castorwheelscannotbeusedonthedynamicframe(80°),ifa2-partangledfootrestisinstalled.
6.2.2RearSeat-to-FloorHeight(RSTF)
Optionsforchangingtherearseat-to-oorheight:
•Replacerearwheelwithalargerorasmallerone.
•Changethepositionoftheadapterplate,see6.8RearWheels,page43.
141659353-A

Instructions
Rearseat-to-oorheightwithrespecttotherearwheelsandpositioningontheframe
Rearwheelsize[inch]
Rearseat
height(RSTF)
[mm]22’’24’’25’’26’’
RSTF3701———
RSTF3802———
RSTF39031——
RSTF400/410421—
RSTF4205321
RSTF4306432
RSTF4407543
RSTF450/4608654
RSTF4709765
RSTF48010876
RSTF390—987
RSTF500—1098
1
2
3
4
5
6
7
8
9
10
11
12
6.2.3SeatWidth(SW)
Thepossibleseatwidthrangeisfrom280–500mm.
OncetheSeatwidthisspecied,itisverydifculttochangeit:Thecrossstruts,backrestcover(onstandardbacks)and,
onsomecongurations,thefootrestsmustbereplaced.
6.2.4Seatdepth(SD)
Thepossibleseatdepthrangeisfrom320–500mm.
Toreducetheseatdepth,thecrossstrutsmustbeshortenedandanewappropriatelysizedseatcovertted.Ataseat
depth≥400mm,theframecanbeshortened.
Toenlargetheseatdepth,newcrossstruts,anewappropriatelysizedseatcoverand,dependingontheseatdepth,anew
framemustbeinstalled.
6.2.5ReplacingtheSeatCover
Torxscrewdriver(10)■■□
1.LoosenboltsAandremoveplugB.
2.RemoveseatcoverCincludingplasticrods.
3.Positionnewseatcover.Adjustseatcovertowidth
(seatwidth+25mm).
4.Retightenboltsandreinserttheplugs.
A=4Nm
6.2.6TurningtheSeatLockingMechanism
Iftheseatedgecanbetooeasilyremovedfromtheseatlockingmechanisms,eitherthefronttwoorallfourseat
lockingmechanismscanberotatedby180°:
1659353-A15

Küschall®Compact
Allenkey(3mm)■□□
1.LoosenboltinseatlockingmechanismA.
Screwouttheboltonlytotheextentthat
theseatlockingmechanismcanbeturnedas
otherwisethethreadedinsertcanmoveandis
thendifculttore-position.
2.Turnseatlockingmechanismby180°.
3.Secureboltwithadhesive(low-strength).
4.Retightenthebolt.
A=4Nm(low-strength)
161659353-A

Instructions
6.3Backrest
6.3.1BackrestHeight
Thebackrestheightcanbechangedbyinstallingthe
telescopictubesinanotherpositioninthebackresttubes.
Ifthissettingoptionisinsufcient,thetelescopictubes
canbereplaced.
6.3.2AdjustingtheHeightofstandardBackrests
Allenkeys(3mm,4mm,6mm)/Socketspanner(8,10)■■□
1.PushthebackrestcoverAupwardsandremovethe
bolt,washerandnutBonbothsides.
2.PushthepushhandlesCupwardsordownwardsuntil
youreachtherequiredheight.Replacethebolts,
washersandnutsandtighten.
B=7Nm
Ifthissettingrangeisinsufcient,usenewpush
handletubes.
Ifthebackrestheightwaschangedconsiderably,a
newbackrestcovermayhavetobeinstalled.
6.3.3AdjustingtheHeightofHookandLoopadjustableBackrests
Allenkeys(3mm,4mm,6mm)/Socketspanner(8,10)■□□
1.RemovethebackrestcoverBandmovethehookand
loopbandsCuntiltheboltsAarevisibleonbothsides.
2.RemoveboltsA,washersandnutsandmovethepush
handletubesDtotherequiredheightonbothsides.
3.Reinserttheboltsintotheappropriateholesonboth
sidesandtightenusingwashersandnuts.
A=7Nm
Ifthebackrestheightischangedconsiderably,the
pushhandlesmustbereplaced.Anadditionalhook
andloopbandmayhavetobeinstalledoronemay
havetoberemoved.
6.3.4Angle-adjustableBackrest
Inordertomakethebackrestangleadjustable,anangle-adjustablebackrestcanbetted.
PossibleBackrestAngles:
1659353-A17

Küschall®Compact
PositionDeviationfrom
standardbackrests
Anglebetween
backrestandseat
112°102°
28°98°
34°94°
40°90°
5-4°86°
6-8°82°
7-12°78°
6.3.5Installinganangle-adjustableBackrest
Allenkey(3mm,4mm,5mm)/Socketspanner(8,10)/Open-endspanner(10)■■□
Shorterrearframe(variantIII)required.
1.PushthelowerjointpinBintotherearframeAand
xitusingabolt.
2.SecurebackresttubeFtotheupperjointpinCusing
abolt.
3.Assembletheupperandlowerjointpins(CandB)and
securewithboltD.
4.Setthedesiredbackrestangleandsecureinthenearest
holeusingboltE.
5.PushthesinglehookandloopbandHandthenthe
otherhookandloopbandsIandtheendbandJover
thebackresttubeF.
6.InsertthepushhandletubeGintothebackresttubeF
andinstallattherequiredheightusingboltsK,washers
andnuts.
7.SecuretheendbandJonthepushhandletubeG
usingwasherandscrewL.
D=13Nm
E=13Nm
K=7Nm
L=hand-tight
6.3.6AdjustingtheBackrestAngle
Allenkey(5mm)/Socketspanner(10)/Open-endspanner(10)■■□
181659353-A

Instructions
1.RemovethebackrestcushionBandpushthehookand
loopbandsCupwards,untilthebackrestjointAis
invisible.
2.RemovetheboltD.
3.SlightlyloosenboltE.
4.Setthedesiredbackrestangle,inserttheboltDinthe
nearestholeandtighten.
5.RetightenboltE.
6.Performthesamesettingsonbothsides.
D=13Nm
E=13Nm
VisualCheck
Bylookingfromthesidecheckthatbothbackresttubesarelevelandthusthatthesameanglehasbeensetonbothsides.
6.3.7InstallingtheJointforafoldingBackrest
Allenkey(4mm,5mm)/Socketspanner(10)■■□
Shorterrearframe(variantIII)required.
1.Setthedesiredbackrestangle,insertboltAinthe
nearestposition(Pos.1,2or3)andtightenwith
washerandnut.(Withthecurvedbackresttubes,other
positionscanbeachievedinadditiontothe3positions
specied.)
2.InstalltheintermediatebackresttubeBtothejoint
housingusingboltE,washerandnut.
3.InsertthejointhousingCintotherearframeDand
secureusingboltF,washerandnut.
A=13Nm
E=13Nm
F=7Nm
PossibleBackrestAngles
Position1(rearposition):82°,withcurvedbackresttube90°
Position2(midposition):86°,withcurvedbackresttube94°
Position3(frontposition):90°,withcurvedbackresttube98°
1659353-A19

Küschall®Compact
6.3.8ReplacingPushHandles/ReplacingPushHandlesandBackrest
Ifthepushhandlesarereplacedwithadifferenttypeofpushhandles,e.g.height-adjustableones,itcanhappenthatthe
rearframemustalsobereplaced.
Changingthebackrestheightcanalsomeanthatthecongurationofthehookandloopbandsmustbechanged.
6.3.9InstallingstandardPushHandles
Allenkey(4mm,5mm)/Socketspanner(8,10)/Phillipsscrewdriver(4)■■□
1.PushtheendbandContothetelescopictubeD.
2.PushthebackrestbandsBontothetelescopictube.
3.Secureendbandatthetelescopictubeusingwasher
andscrewF.
4.SecurethetelescopictubeDtotherearframeAat
therequiredheightusingbolt,washerandnutE.
E=7Nm
F=hand-tight
6.3.10Installingheight-adjustable,integratedPushHandles
Allenkey(4mm,5mm)/Socketspanner(8,10)/Phillipsscrewdriver(4)■■□
SpecialrearframerequiredforRH300–465(variantII)
1.PushlowertelescopictubeBanduppertelescopictube
Cintooneanother,insertboltJ,washerandnutand
tighten.
2.Securepre-assembledelement(telescopictubesBand
C)attherequiredheightontherearframeAusing
boltH,washerandnut.
3.PushthehookandloopbandsDandendbandEonto
thetelescopictubes.
4.UsingtheclampboltGsecuretheheightadjustable
pushhandleFthroughthetelescopictubeC.
5.Pushinpushhandlecompletely.
6.SecureendbandEonthetelescopictubeCusing
screwI.
H=7Nm
I=handtight
J=7Nm
6.3.11Installingheight-adjustable,rearsetPushHandles
Allenkey(4mm,5mm)/Socketspanner(8,10)/Phillipsscrewdriver(4)■■□
Thehookandloopbandsmayhavetobereplacedwithnarrowerones,asspaceisrequiredtosecuretheholderon
thetelescopictube.
201659353-A
